Panduit Bundle Catalog Page

Bundle

Ultra-Cinch™ Hook & Loop Cable Ties

A.

System

Overview

B1.

Cable

Ties

● Unique material with hooks and loops on same side

allows user to secure a greater range of bundle
diameters, including smaller bundles

● Soft, premium material is safe to use on high performance

cabling, protecting against over-tensioning

● Adjustable, releasable, and re-usable multiple times –

ideal for applications requiring frequent moves, adds,
or changes

● Low profile contoured cinch ring provides extra strength

and bundle tightness while reducing overall bundle size

● Grommet (UGCTC and UGCTE styles) offers strength

and assures reliable installations that resist pullout when
bundling and mounting cables within cabinet applications

● Tapered tip facilitates easy, snag-free threading to

speed installation

● Use flat-head screws for grommet applications

shown below

Note: Minimum 2" overlap required to achieve loop
tensile rating.

UGCTC UGCTEUCT

UGCTC

Bundle is centered

over mounting point

UGCTE

Bundle is offset from

mounting point

B2.

Cable

Accessories

B3.

Stainless

Steel Cable

Ties &

Accessories

C1.

Wiring

Duct

C2.

Abrasion

Protection

C3.

Cable

Management

D1.

Terminals

D2.

Power

Connectors

D3.

Grounding

Connectors

Part Number

Length Width

Max.

Bundle Dia.

Min. Loop

Tensile Str.

Std.

Pkg.

Qty.

Cinch Ties

UCT3S-X0 12.0 305 0.850 21.6 3.00 76 50 222 10 100

UCT5S-X0 18.0 457 0.850 21.6 5.00 127 50 222 10 100

Cinch Ties – Center Mount Grommet (Bundle is centered over mounting point)

UGCTC3S-X0 12.0 305 0.850 21.6 3.00 76 50 222 10 100

UGCTC5S-X0 18.0 457 0.850 21.6 5.00 127 50 222 10 100

Cinch Ties – End Mount Grommet (Bundle is offset from mounting point)

UGCTE3S-X0 12.0 305 0.850 21.6 3.00 76 50 222 10 100

UGCTE5S-X0 18.0 457 0.850 21.6 5.00 127 50 222 10 100

Note: 1/4" (6mm) diameter mounting hole on grommet style cinch ties.

Flat Head Screws for Grommet Cinch Ties

Std.

Std.

Pkg.

Part Number Part Description
UCTGS1224-X 12-24 UNC x 5/8mm (.625") flat head phillips screw 10 100

UCTGSM5-X M5 x 16mm flat head phillips screw 10 100

UCTGSM6-X M6 x 16mm flat head phillips screw 10 100

Qty.

Ctn.
Qty.

Std.
Ctn.
Qty.In. mm In. mm In. mm Lbs. N
