Audio Video
PRODUCT SELECTION
GUIDE
AV Offering
Tilt-Up Table Box
• Unique leaf spring
design will last a
lifetime
• Removable front
faceplate for custom
designs and updates
Cable Nook
Table Box
• Comes prepopulated
with power outlets and
USB charging ports
• Removable faceplates
for custom designs
accessories
In Wall Box
• Easily organize active
AV equipment and
cables
• Power knockout
and equipment
accessories
Above Floor Raceway
• ADA compliant pathway
for data and power
• Cost effective solution
for applications without
under floor access
accessories
Panduit's Audio Video products connect users from the classroom to the conference room, and
spaces in between, to bring a total quality solution that is complimentary to our award-winning
structured cabling solution. Some featured highlights of our Audio Video solutions include unique
designs, organization and space saving opportunities, easy of connectivity and high quality highbit rate audio and 4K video capabilities. We've set our standards high in order to drive value and
deliver solutions that go beyond end-to-end in the spaces that matter most.
2
www.panduit.com
HDBaseT
Transmitter and
Receiver Boxes
• Smallest HDBaseT
extender boxes on the
market today with 4K
video extension
Part List
HDMI Patch
Part Number Description
HDMI1MBL HDMI 1M Patch Cord, Black
HDMI2MBL HDMI 2M Patch Cord, Black
HDMI4MBL HDMI 4M Patch Cord, Black
HDMI1MBL
CMHDBTBRX
CMBBSWH
CMBBLWH
PND100
CMHDBTBTX
*Replace BL with WH for white
HDBaseT Extenders
Part Number Description
CMHDBTBTX HDBaseT Transmitter Box
CMHDBTBRX HDBaseT Receiver Box
CMHDBTWPTX HDBaseT Wallplate Transmitter
CMHDBTWRX HDBaseT Receiver Box With Audio De-embedding
In Wall Boxes
Part Number Description
CMBBSWH Small In-wall box
CMBBLWH Large In-wall box
CMBBCMR Cable Management D ring
CMBBRKT Equipment bracket
Table Boxes
Part Number Description
PND100 Cable Nook Box
PND110 Tilt Up Table Box
PND400 Retractable HDMI Cable for Cable Nook Box with Mounting
Bracket
Frame Faceplates and Inserts
Part Number Description
CBIW Single Gang Faceplate Frame
CBIW-2G Double Gang Faceplate Frame
CHF2MIW-X Two Module 1/3 Insert for Mini-Com
NKHF2MIW-X Two Module 1/3 Insert for NetKey
CHBHIW Hooded Insert, off white
*Replace IW with WH, EI, BL for white, electric ivory and black respectively
®
Modules
®
Modules
PND110
PND400
GFCI Faceplates and Inserts
Part Number Description
CFGBIW Brush Insert, off white
CPGIW Single Gang Rectangular Faceplate
CPGIW-2G Double Gang Rectangular Faceplate
CFG4IW Mini-Com
CFG2IW Mini-Com
NKG4IW NetKey
NKG2IW NetKey
*Replace IW with WH, EI, BL for white, electric ivory and black respectively
®
Four Module Rectangular Adapter
®
Two Module Rectangular Adapter
®
Four Module Rectangular Adapter
®
Two Module Rectangular Adapter
www.panduit.com
3
Part List
Part List
AFR4BCBL6
Above Floor Raceway
Part Number Description
AFR4BCBL6 6 foot Above Floor Raceway Base and Cover, Black
AFR4JB2SBL AFR Power Rated Two Piece Snap Together Junction Box, Black
AFR4TRT70BL AFR Transition Fitting from Above Floor Raceway to T70, Black
AFR4RABL AFR Right Angle Fitting, Black
AFR4CCBL AFR Coupler Fitting, Black
AFR4ECBL AFR End Cap Fitting, Black
*Replace BL with IW or OS for international white or ofce slate respectively
AFR4BCIW6
AFR4BCOS6
CMHDMIBL
NKHDMIBL
Mini-Com® Modules
Part Number Description
CMBBL-X Blank Module
CJ688TGBL Category 6 Jack
CJ6X88TGBL Category 6A Jack
CMHDMIBL 2-Position HDMI Module
CMUSBAABL USB Module
CM35MSCBLY 3.5 Stereo Coupler
*Additional colors available, please see Panduit.com
NetKey® Modules
Part Number Description
NKBMBL-X Blank Module
NK688MBL Category 6 Jack
NK6X88MBL Category 6A Jack
NKHDMIBL 1-Position HDMI Module
NKUSBAABL USB Module
NK35MSCBL 3.5 Stereo Coupler
*Additional colors available, please see Panduit.com
