TX---32PS11D TX---28PS11D

Colour Television

Operating Instructions

English

TQB0E0010eng ---M

this is an unapproved issue --- for information only

WELCOME

Dear Panasonic Customer, Welcome to the Panasonic family of customers. We hope that you have many years of enjoyment from your new colour television. This is a very advanced television; however, the Quick Start Guide will allow you to use the TV as quickly as possible. You can then read the instructions completely and retain them for future reference.

CONTENTS

Warnings and Precautions 3...........

Accessories 4........................

Quick Start Guide 5...................

Basic Controls 8......................

Menu Structure 9.....................

Using the On Screen Displays 10......

Aspect Controls 11...................

Hold Control 13.......................

Main Menu 14........................

Picture Menu 15......................

Sound Menu 16.......................

Setup Menu 17.......................

Tuning Menu 18......................

Tuning Menu -- Programme edit 19.....

Tuning Menu -- Auto setup 23..........

Tuning Menu -- Manual tuning 24.......

OSD Language 26....................

Q-- Link 27............................

VCR/DVD/ROperation 29.............

Te l e te x t O pe r a ti on 30.................

Audio / Video (AV) Connections 33.....

AV Select and Setup 33...............

Front sockets 33.....................

Rear sockets 34......................

Scart and S-- Video socket

information 35.......................

Tro u blesho oting 36...................

For your guidance 37.................

Specifications 37.....................

WARNINGS AND PRECAUTIONS

D This TV set is designed to operate on 220 --

240V, 50Hz A.C.

D To prevent damage which might result in

electric shock or fire, do not expose this TV set to rain or excessive moisture. This TV must not be exposed to dripping or splashing water and objects filled with liquid, such as vases, must not be placed on top of or above the TV.

H WARNING : HIGH VOLTAGE !!!

Do not remove the rear cover as live parts are accessible when it is removed. There are no user serviceable parts inside.

D Avoid exposing the TV set to direct sunlight

and other sources of heat. To prevent fire, never placeany type of candle or naked flame on top of, or near the TV set.

D Ensure that the mains plug is easily

accessible.

D The On/Off switch on this model does not fully

disconnect the TV from the mains supply. Remove the mains plug from the wall socket when the TV set is not used for a prolonged period of time.

H CABINET AND PICTURE TUBE CARE

Remove the mains plug from the wall socket. The cabinet and picture tube can be cleaned with a soft cloth moistened with mild detergent and water. Do not use solutions containing benzol or petroleum. TV sets can produce static electricity, care must be taken whenever touching the TV screen.

D Adequate ventilation is essential to prevent

failure of electrical components, we recommend that a gap of at least 5cm is left all around this television receiver even when it is placed inside a cabinet or between shelves.

D Ventilation should not be impleded by

covering the ventilation openings with items such as newspapers, tabel cloths and curtains.

H ENVIRONMENT

Batteries, packaging and old equipment should not be disposed of as domestic waste, but in accordance with the applicable regulations.

H TV GAMES / HOME COMPUTERS

Extended use of TV games or home computers with any television set can cause a permanent ‘shadow’ on the screen. This type of irreversible picture tube damage, can be limited by observing the following points:

D Reduce the brightness and contrast levels

to a minimum viewing level.

D Do not operate the television set for a

continuous period of time while using TV games or home computers.

D Thistypeofpicturetubedamage,isnotan

operating defect, and as such is not covered by the Panasonic warranty.

H SLEEP FEATURE

If the set is not switched off when the TV station stops transmitting , it will automatically go to standby mode after 30 minutes. This function will not operate when the TV is in AV mode.

ACCESSORIES

Check that you have the accessories and items shown

Operating Instruction book

Batteries for the Remote Control Transmitter. (2 x R6 (UM3) size)

Remote Control Transmitter (EUR 7628010)

TV Guarantee

Remote control batteries

D Make sure that the batteries are fitted the

correct way round.

D Do not mix old batteries with new batteries.

Remove old, exhausted batteries immediately.

D Do not mix different battery types, i.e. Alkaline

and Manganese or use rechargeable (Ni ---Cd, N i --- M H) b a t t e r ie s .

QUICK S TART GUIDE

Plug in aerial and connect ancillary equipment.

AV1

AV2

AV1

AV2

SATELLITE RECEIVER

VCR / DVD/R

First, ensure that the VCR (DVD/R) is in Standby mode.

Plug in TV and switch on.

QUICK S TART GUIDE

Select your country.

Press the red button

Auto setup will begin, your stations will be located and stored. Use the Programme Edit menu to delete unwanted stations (see page 19). Press the TV/AV button to exit.

TV/AV

If you are installing a new Q --- Link compatible VCR (DVD/R), you can now switch it ON. Downloaded tuning data will match the television’s. If you are installing a new NEXTVIEWLINK compatible VCR (DVD/R), you will need to initiate download manually. See the VCR (DVD/R) handbook for details.

D If the VCR (DVD/R) has not accepted download data from the TV, you may need to select the

Download option from the VCR (DVD/R)’s menu.

D If Q ---Link is not operating correctly, check it is connected to the television’s AV1 or AV2 socket,

the SCART lead is a “full function” type, and the VCR (DVD/R) is compatible with Q---Link, NEXTVIEWLINK or similar technologies. Ask your dealer for further details.

D For further information on Q ---Link and connecting equipment, see pages 27, and 28.

Slight tilting of the picture may be noticeable or coloured patches may sometimes appear at the corners of the screen (colour purity). The Geomagnetic Correction feature can be used to eliminate them, if necessary:

First, ensure the ATP and Q--- Link download procedures are complete. The screen should not be showing any On ---Screen Display menus. Using the remote control keys indicated, access the Geomagnetic Correction menu option and follow the procedure below (for a full explanation of the On Screen Display menu system see page 10) :

QUICK S TART GUIDE

Press the MAIN menu button

Move to the SETUP menu option

Access the SETUP menu

Move to the Geomagnetic menu option

Access the Geomagnetic menu

Adjust the picture tilt as necessary

Press the TV/AV button to exit

TV/AV

The function ’geomagnetic correction’ is also accessible from the front panel.

Pressandreleaseheretoopenflap

Press the F button repeatedly until the Geomagnetic Correction feature is displayed.

Press the + or --- buttons repeatedly until the picture appears to be level.

Press the F button again to return to normal viewing. Close the flap to prevent damage.

Youarenowreadytobeginviewingprogrammes

The cursor controls provide the two basic functions:

--- / v

Adjust Volume

Change Programme

BASIC CONTROLS : FRONT PANEL AND REMOTE CONTROL

MAINS Power On/Off switch

Red light indicates Standby mode.

STR (Normalisation store) Used to store

tuning and other function settings

F (Function select)

Displays the O n Screen Display functions, use

repeatedly to select from the available functions

-- Volume, Contrast, Brightness, Colour,

Sharpness, Tint (in NTSC mode), Bass, Treble,

Balance, Tuning mode and Geomagnetic

Correction.

Headphone socket (see page 33)

TV/AVswitch(seepage33)

Increases or decreases the programme position by one. When a function is already displayed, press to increase or decrease the selected function.

RCA Audio/Video sockets (page 33)

S---VHSsocket(seepage33)

Standby ON/OFF switch Switches

TV On or Off standby.

Status button

Press to display programme

position, programme name,

channel number, TV system, time

stereo mode

and programme table.

Aspect button (see page 11)

O K ke y --- U s ed t o s t o r e a n d

confirm tuning, OSD functions

and other settings

Menu button

Press to access the Main,

Picture, Sound and Setup menus

(see page 10)

Teletext buttons (see page 30)

Direct Channel Access

During normal TV viewing or

when in the Tuning, Programme

edit or Manual tuning menus, press and then enter channel

number using the numeric

buttons

VCR / DVD buttons (see page 29)

Ambience on/off

Sound mute On/Off

Direct TV Record button(see page 27)

N(Normalise)button Resets all settings to their default levels

Cursor buttons to make selections and adjustments

Switch between viewing TV or AVinput(seepage33)

Coloured buttons used for Programme Edit functions (see page 19) Teletext functions (see page

30) AV selection (see page 33)

Programme / channel change buttons (0-- 9) and Teletext pagebuttons(seepage30)

Programme position for selection of two digit programmes (10 -- 99) using numeric buttons. Press the “C” and “---/ --- --- ” buttons for Direct Channel Access in hyperband.

MENU STRUCTURE

Main Menu

Viewing Mode Picture Menu Sound Menu Setup Menu

ASPECT

Aspect Controls

Panasonic Auto (wide) 16:9 14:9 Just 4:3 Zoom 1 Zoom 2 Zoom 3

Picture Menu

Viewing Mode Contrast Brightness Colour Sharpness Tint (NTSC only) Colour balance P-NR

Sound Menu

Volume Bass Treble Balance MPX Mode Ambience

Setup Menu

AV1 out AV2 out Teletext Off timer Flicker reduction Q-LinkSelect Text language Tuning menu OSD language Geomagnetic

Tuning Menu

Programme edit Auto setup Manual tuning Fine tuning Colour system Volume Correc. Decoder (AV2)

OSD language

Deutsch English Français Italiano ELLHNIKA Čeština Română Polski Español Norsk Dansk Svenska Magyar Russkij Slovensky Srpski Nederlands Suomi Türkçe Português Hrvatski Bulgarian Slovensko

Geomagnetic correction

Programme edit

Delete Add Move Download

Auto Setup

Warning

Country

Deutschland Österreich France Italia España Portugal Nederland Danmark Sverige Norge Suomi Belgium Schweiz ELLADA Polska Česká republika Magyarország E.Eu

Manual tuning

USING THE ON SCREEN DISPLAYS

This TV has a comprehensive system of On Screen Display menus to access

adjustments and options

Menu Title

Sub-- menus

∧

−

∨

Main Menu

Viewing Mode Dynamic

Picture Menu Access

Sound Menu Setup Menu

Select

Access

Exit

Instructions

Picture Menu

Viewing Mode Dynamic

Contrast Brightness Colour Sharpness Colour Balance Normal P-NR Off

Some selections, for example, Contrast, Brightness, Colour and Sharpness will allow you to increase or decrease their level. Some selections, for example, Off timer,allowachoicetobemade. Some selections, for example Tuning menu, will lead to a further menu.

TheMENU buttonisusedtoopenthemainmenuandalsotoreturntotheprevious menu.

Indicator for options

Selection bar

The up and down cursor buttons are used to move the cursor up and down the menus.

The left and right cursor buttons are used to access menus, adjust levels or to select from a range of options.

The OK button used to store and confirm tuning, OSD functions and other settings

The TV/AV button is used to exit the menu system and return to the normal viewing screen.

N (Normalise) button --- resets all settings to their default levels

TV/AV

Last Position Memory

Certain functions have a last position memory, i.e. the setting at the time of switch-- off will be the setting used when the receiver is switched on again.

ASPECT CONTROLS

The widescreen TV will allow you to enjoy vi ewing the picture at its optimum

size and aspect, including widescreen ‘cinema format’ pictures.

Press the ASPECT button repeatedly to move through the seven aspect options: Panasonic Auto, 16:9, 14:9, Just, 4:3, Zoom1,Zoom2 and Zoom3. OR Press the ASPECT button then use the RED or GREEN buttons to move in either direction through the seven aspect options.

Panasonic Auto

ASPECT

Panasonic Auto determines the best aspect ratio to use to display the picture you are viewing. It does this using a four step process to determine if the picture being viewed is a widescreen picture. If Panasonic Auto detects a widescreen signal it switches into 16:9 widescreen mode. If Panasonic Auto does not detect a widescreen signal then this advanced TV set enhances the picture for optimum viewing pleasure. The text shown on the screen indicates how Panasonic Auto determined which ratio to use: ’WIDE’ appears in the top left of the screen if a widescreeen identification signal (WSS) is found or a signal is found through a Scart socket. Panasonic Auto switches into 16:9 widescreen ratio. ’Panasonic Auto’ appears in the top left of the screen if black stripes above and below the picture are detected. Panasonic Auto chooses the best ratio and expands the picture to fill the screen. This process can take several minutes, depending how dark the picture is. Equally , you may prefer to select one of the other modes available to view the picture.

Notes:

D If, in Panasonic Auto mode, you experience problems with the screen display size when playing

back widescreen format recordings from your VCR (DVD/R) then it is possible that the tracking control of your VCR (DVD/R) requires adjustment (your VCR (DVD/R) instruction book will contain adjustment details).

D The widescreen aspect ratios of different films and programmes can vary. If these are wider than a

standard 16:9 aspect picture then a black band may be visible at the top and bottom of the screen.

16:9

16:9 will display a true 16:9 (anamorphic) picture

with no aspect distortions.

Panasonic Auto

<< >>

16:9

<< >>

16:9 (Full)

ASPECT CONTROLS

14:9

14:9 will display a true 14:9 picture with no

aspect distortions.

Just

Usethismodewhenyouwishtoexpanda4:3 picture to fill the whole screen (rather than watching a programme with black stripes down the left and right sides of the picture). The 4:3 picturewillbestretchedhorizontallysothatthe image fills the screen, this is done in such a way that the stretching is only obvious at the left and right edges of the s creen.

4:3

4:3 will display a 4:3 picture at its standard 4:3

size with no aspect distortions.

14:9

<< >>

14:9

Just

<< >>

Just

4:3

Zoom1

Zoom1 will display 16:9 letterbox or 4:3 pictures

with no aspect distortions

<< >>

4:3

Zoom1

<< >>

Zoom 1
