High Definition Plasma Display
®
PLASMA DISPLAY
+
L
O
V
—
T
U
P
N
I
Y
B
D
N
A
/
T
S
-
R
R
N
E
O
W
R
E
O
P
W
O
P
G
Operating Instructions
TH-42PHD5
Model No.
TH-50PHD5
Before connecting, operating or adjusting this product, please read these instructions completely. Please keep this
manual for future reference.
English
TQBC0480-1
Page 2
Dear Panasonic Customer
Welcome to the Panasonic family of customers. We hope that you will have many years of
enjoyment from your new High Definition Plasma Display.
To obtain maximum benefit from your set, please read these Instructions befo re making any
adjustments, and retain them for future reference.
Retain your purchase receipt also, and note down the model number and serial number of your
set in the space provided on the rear cover of these instructions.
Visit our Panasonic Web Site http://www.panasonic.co.jp/global/
Trademark Credits
VGA is a trademark of International Business Machines Corporation.
•
Macintosh is a registered trademark of Apple Computer, USA.
•
S-VGA is a registered trademark of the Video Electronics Standard Association.
•
Even if no special notation has been made of company or product trademarks, these trademarks have been
fully respected.
Note:
Do not allow a still picture to be displayed for an extended period, as this can cause a permanent after-image to
remain on the High Definition Plasma Display.
Examples of still pictures include logos, video games, computer images, teletext and images displayed in 4:3 mode.
2
Page 3
Table of Contents
Important Safety Notice..............................................4
Safety Precautions......................................................5
Accessories .................................................................7
Accessories Supply....................................................7
Optional Accessories .................................................7
Remote Control Batteries...........................................8
Connections ................................................................9
A V Input Terminals connection.................................10
AV Out......................................................................11
Component/RGB Input connection ..........................12
PC Input Terminals connection ................................13
Serial Terminals connection .....................................15
Basic Controls...........................................................16
Power On/Off and input signal selection ................18
AC cord connection..................................................18
Power On/Off ...........................................................18
Select the input signal..............................................19
Selecting the On-Screen Menu Language...............19
On-Screen Menu Display from Remote Control.....20
ASPECT Controls......................................................22
Adjusting Picture Pos./Size .....................................24
Sound Adjustment ....................................................26
Mute .........................................................................26
Surround Controls ....................................................27
Picture Adjustments .................................................28
Advanced settings....................................................29
Set up TIMER .............................................................30
PRESENT TIME Set ................................................30
TIMER Set ...............................................................31
Screensaver (For preventing after-images)............32
Setup of Screensaver Time......................................33
Side Panel Adjustment.............................................33
Setup for Input Signals.............................................34
Component/RGB-in select .......................................34
3D Y/C Filter – For NTSC AV images ......................34
Colour system / Panasonic Auto..............................35
3:2 Pulldown ............................................................35
Sync .........................................................................36
H-Freq. (kHz)/V-Freq. (Hz).......................................36
Troubleshooting........................................................37
Specifications............................................................38
3
Page 4
Important Safety Notice
WARNING: To prevent damage which may result in fire or shock hazard, do not expose this appliance
to rain or moisture.
Do not place containers with water (flower vase, cups, cosmetics, etc.) above the set.
(including on shelves above, etc.)
WARNING: 1) To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing
to qualified service personnel.
2) Do not remove the earthing pin on the power plug. This apparatus is equipped with a three pin
earthing-type power plug. This plug will only fit an earthing-type power outlet. This is a safety
feature. If you are unable to insert the plug into the outlet, contact an electrician.
Do not defeat the purpose of the earthing plug.
WARNING
This is a class A product. In a domestic environment this product may cause radio interference in which case you
may be required to take adequate measures.
CAUTION
This appliance is intended for use in environments which are relatively free of electromagnetic fields.
Using this appliance near sources of strong electromagnetic fields or where electrical noise may overlap with the
input signals could cause the picture and sound to wobble or cause interference such as noise to appear.
To avoid the possibility of harm to this appliance, keep it away from sources of strong electromagnetic fields.
To prevent electric shock, ensure the grounding pin on the AC cord power plug is securely connected.
4
Page 5
Safety Precautions
WARNING
Setup
This Plasma Display is for use only with the following optional accessories. Use with any other type of optional
accessories may cause instability which could result in the possibility of injury.
(All of the following accessories are manufactured by Matsushita Electric Industrial Co., Ltd.)
Speakers
•
Pedestal
•
Wall stand
•
Mobile stand
•
Wall-hanging bracket (vertical)
•
Wall-hanging bracket (angled)
•
Wall-hanging bracket (Drawer type) TY-WK42DR1
•
Ceiling unit
•
RGB(digital) Terminal Board
•
Always be sure to ask a qualified technician to carry out set-up.
Do not place the Plasma Display on sloped or unstable surfaces.
The Plasma Display may fall off or tip over.
•
Do not place any objects on top of the Plasma Display.
If water is spills onto the Plasma Display or foreign objects get inside it, a short-circuit may occur which could result
•
in fire or electric shock. If any foreign objects get inside the Plasma Display, please consult your local Panasonic
dealer.
.........................................
..........................................
.......................................
....................................
........
........
......................................
...........
TY-SP42PWD3W or TY-SP42P5W-K(TH-42PHD5)
TY-SP50PHD3W or TY-SP50P5W-K(TH-50PHD5)
TY-ST05-K
TY-ST42PW1
TY-ST42PF3
TY-WK42PV1
TY-WK42PR1
TY-CE42PS1
TY-42TM4D
If using the pedestal (optional accessory), leave a space of at least 10 cm at the top, left and right, at least 6 cm
at the bottom, and at least 7 cm at the rear. If using some other setting-up method, leave a space of at least 10
cm at the top, bottom, left and right, and at least 1.9 cm at the rear.
Avoid installing this product near electronic equipment that is easy to receive electromagnetic waves.
It may cause interference in image, sound, etc. In particular, keep video equipment away from this product.
•
When using the Plasma Display
The Plasma Display is designed to operate on 220 - 240 V AC, 50/60 Hz.
Do not cover the ventilation holes.
Doing so may cause the Plasma Display to overheat, which can cause fire or damage to the Plasma Display.
•
Do not stick any foreign objects into the Plasma Display.
Do not insert any metal or flammable objects into the ventilations holes or drop them onto the Plasma Display, as
•
doing so can cause fire or electric shock.
Do not remove the cover or modify it in any way.
High voltages which can cause severe electric shocks are present inside the Plasma Display. For any inspection,
•
adjustment and repair work, please contact your local Panasonic dealer.
Securely insert the power cord plug as far as it will go.
If the plug is not fully inserted, heat may be generated which could cause fire. If the plug is damaged or the wall
•
socket plate is loose, they shall not be used.
Do not handle the power cord plug with wet hands.
Doing so may cause electric shocks.
•
Do not do anything that may damage the power cable. When disconnecting the power cable, pull on the plug
body, not the cable.
Do not damage the cable, make any modifications to it, place heavy objects on top of it, heat it, place it near any
•
hot objects, twist it, bend it excessively or pull it. To do so may cause fire and electric shock. If the power cable is
damaged, have it repaired at your local Panasonic dealer.
If the Plasma Display is not going to be used for any prolonged length of time, unplug the power cord plug
from the wall outlet.
5
Page 6
Safety Precautions
If problems occur during use
If a problem occurs (such as no picture or no sound), or if smoke or an abnormal odour starts to come out
from the Plasma Display, immediately unplug the power cord plug from the wall outlet.
If you continue to use the Plasma Display in this condition, fire or electric shock could result. After checking that
•
the smoke has stopped, contact your local Panasonic dealer so that the necessary repairs can be made.
Repairing the Plasma Display yourself is extremely dangerous, and shall never be done.
If water or foreign objects get inside the Plasma Display, if the Plasma Display is dropped, or if the cabinet
becomes damages, disconnect the power cord plug immediately.
A short circuit may occur, which could cause fire. Contact your local Panasonic dealer for any repairs that need
•
to be made.
CAUTION
When using the Plasma Display
Do not bring your hands, face or objects close to the ventilation holes of the Plasma Display .
Heated air comes out from the ventilation holes at the top of Plasma Display will be hot. Do not bring your hands
•
or face, or objects which cannot withstand heat, close to this port, otherwise burns or deformation could result.
Be sure to disconnect all cables before moving the Plasma Display.
If the Plasma Display is moved while some of the cables are still connected, the cables may become damaged,
•
and fire or electric shock could result.
Disconnect the power cord plug from the wall socket as a safety precaution before carrying out any cleaning.
Electric shocks can result if this is not done.
•
Clean the power cable regularly to prevent it becoming dusty.
If dust built up on the power cord plug, the resultant humidity can damage the insulation, which could result in fire.
•
Pull the power cord plug out from the wall outlet and wipe the mains lead with a dry cloth.
Cleaning and maintenance
The front of the display panel has been specially treated. Wipe the panel surface gently using only a cleaning
cloth or a soft, lint-free cloth.
If the surface is particularly dirty, wipe with a soft, lint-free cloth which has been soaked in pure water or water to
•
which a small amount of neutral detergent has been added, and then wipe it evenly with a dry cloth of the same
type until the surface is dry.
Do not scratch or hit the surface of the panel with fingernails or other hard objects, otherwise the surface may
•
become damaged. Furthermore, avoid contact with volatile substances such as insect sprays, solvents and thinner,
otherwise the quality of the surface may be adversely affected.
If the cabinet becomes dirty, wipe it with a soft, dry cloth.
If the cabinet is particularly dirty, soak the cloth in water to which a small amount of neutral detergent has been
•
added and then wring the cloth dry. Use this cloth to wipe the cabinet, and then wipe it dry with a dry cloth.
Do not allow any detergent to come into direct contact with the surface of the Plasma Display.
•
If water droplets get inside the unit, operating problems may result.
Avoid contact with volatile substances such as insect sprays, solvents and thinner, otherwise the quality of the
•
cabinet surface may be adversely affected or the coating may peel off. Furthermore, do not leave it for long periods
in contact with articles made from rubber or PVC.
6
Page 7
Accessories
Accessories Supply
Check that you have the accessories and items shown
Operating Instruction book
AC cord
Fixing bands
TMME187 × 2
Optional Accessories
Speakers
•
TY-SP42PWD3W
TY-SP42P5W-K
(TH-42PHD5)
Pedestal
•
Remote Control Transmitter
EUR646525
INPUT
SURROUND
VOL
NR
SET UP
SOUND
POS. /SIZE
ASPECT
OFF TIMER
PC
PLASMA DISPLAY
Ferrite core (small size)
J0KF00000018 × 1
TY-ST05-K
Wall stand
•
TY-ST42PW1
Batteries for the Remote
Control Transmitter
(2 × R6 Size)
Ferrite core (large size)
J0KG00000054 × 2
Mobile stand
•
TY-ST42PF3
TY-SP50PHD3W
TY-SP50P5W-K
(TH-50PHD5)
Wall-hanging bracket
•
(vertical)
TY-WK42PV1
RGB(digital) Terminal Board
•
Wall-hanging bracket
•
(angled)
TY-WK42PR1
Wall-hanging bracket
•
(Drawer type)
TY-WK42DR1
TY-42TM4D
For assembling
Full instructions are supplied with each optional accessory for use with this Plasma Display.
Ceiling unit
•
TY-CE42PS1
7
Page 8
Remote Control Batteries
Requires two R6 batteries.
1. Turn the transmitter face down.
Press and slide off the battery
cover.
2. Install the batteries as shown in
the battery compartment.
(Polarity + or – must match the
markings in the compartment.)
3. Replace the cover and slide in
reverse until the lock snaps.
Two "R6" size
Helpful Hint:
For frequent remote control users, replace old batteries with
Alkaline batteries for longer life.
Precaution on battery use
Incorrect installation can cause battery leakage and corrosion that will damage the remote control transmitter.
Observe the following precaution:
1. Batteries shall always be replaced as a pair. Always use new batteries when replacing the old set.
2. Do not combine a used battery with a new one.
3. Do not mix battery types (example: “Zinc Carbon” with “Alkaline”).
4. Do not attempt to charge, short-circuit, disassemble, heat or burn used batteries.
5. Battery replacement is necessary when remote control acts sporadically or stops operating the Plasma Display set.
8
Page 9
Connections
When connecting the speakers, be sure to use only the optional accessory speakers.
Refer to the speaker’s Installation Manual for details on speaker installation.
1
Speakers (Optional accessories)
2
1
2
SPEAKERS
Terminals (R)
SPEAKERS
Terminals (L)
– Cable fixing bands
Secure any excess cables with bands as required.
Pass the attached cable fixing
band through the clip as
shown in the figure.
To secure cables connected to
Terminals, wrap the cable fixing band
around them then pass the pointed end
through the locking block, as shown in
the figure.
1
To tighten:
Pull
2
To loosen:
Push
the catch
Pull
RL
AUDIO
IN
A V Terminals
(see page 10, 11)
S VIDEO
IN
VIDEO
IN
VIDEO
OUT
RL
AUDIO
COMPONENT/RGB IN and Audio
IN Terminals (see page 12)
AUDIO
HD
VD
COMPONENT/RGB INAV
B/CB
/B Y/G
P
PR/CR/R
PC IN SERIAL
From EXIT monitor Terminal
on Computer (see page 13)
From SERIAL Terminal on
Computer (see page 15)
9
Page 10
Connections
AV Input Terminals connection
Connect the signal source equipment.
(Example) When connecting an S VIDEO VCR.
(S VIDEO VCR)
VIDEO signal connection
(VCR)
2×RCA audio
cables
AUDIO
Audio input to
L/R sockets
Audio
OUT
RL
RL
AUDIO
S VIDEO
IN
Video
OUT
IN
AV
S Video
OUT
S VIDEO
Video input to
VIDEO
VIDEO
IN
S VIDEO
socket
OUT
S VIDEO 4 pin socket
Luminance earth
Luminance in
Chrominance earth
Chrominance in
Audio
OUT
RL
(VCR)
Audio
OUT
RL
Video
OUT
Video
OUT
VIDEO
RCA-BNC video cable
AUDIO
2×RCA audio cables
VIDEO
RCA video cable
AUDIO
2×RCA audio cables
Video input to
BNC socket
Audio input to
L/R sockets
Video input to
BNC socket
RCA-BNC adapter plug
Audio input to L/R sockets
RL
AUDIO
IN
S VIDEO
VIDEO
VIDEO
IN
AV
OUT
IN
Note:
Additional equipment and cables shown are not supplied with this set.
10
Page 11
(Example) When connecting 21 pin scart cables.
(VCR)
AV2
(DVD / Satellite Receiver)
Connections
Video input to
BNC socket
Audio input to
L/R sockets
RL
AV1/TV
Video input to
BNC socket
RCA-BNC
adapter plug
Audio input to
L/R sockets
Notes:
(1) Additional equipment, cables and an adaptor plug shown are not supplied with this set.
(2) 21 pin connectors and 21 pin scart plugs are connectors used in Europe.
AV Out
AUDIO
IN
S VIDEO
IN
AV
VIDEO
IN
VIDEO
OUT
RL
AUDIO
IN
S VIDEO
MONITOR DEVICE
BNC cable
VIDEO
VIDEO
IN
AV
OUT
IN
(Example) colour CRT monitor
11
Page 12
Connections
Component/RGB Input connection
Component signals (Y, PB, PR) connection
(DVD Player)
Y
Y, PB, P
P
B
P
R
3×RCA
video cables
R
RCA-BNC
adaptor plug
L
R
AUDIO
2×RCA
audio cables
RL
A
U
D
IO
V
D
COMPONENT/RGB IN
P
R
/C
R
H
/R
D
Notes:
(1) Change the “Component/RGB-in” setting in the “Setup” menu to “Component”. (see page 34)
(2) Additional equipment, cables and adaptor plugs shown are not supplied with this set.
RGB signal (R, G, B, HD, VD) connection
Example of input signal source
HDTV-compatible VCR
RGB camera
Computer
5×BNC
RGB cables
AUDIO
2×RCA audio cables
VD
RGB input to
R, G, B, HD, VD
sockets
Audio input to
L/R sockets
RL
AUDIO
RCA-BNC
adaptor-plug
HD
VD
COMPONENT/RGB IN
P
B
/C
Y
B
/G
/B
P
R/CR/R
P
B/CB/B
Y/G
HD
R
B
G
Notes:
(1) Change the “Component/RGB-in” setting in the “Setup” menu to “RGB”. (see page 34)
(2) Additional equipment, cables and adaptor plugs shown are not supplied with this set.
12
Page 13
PC Input Terminals connection
COMPUTER
POWER /
R - STANDBY
G POWER ON
Conversion adapter
(if necessary)
Less than
15
3"
/
16
(10 cm)
Ferrite core (small size)
Audio
–
VOL
+
INPUT
(supplied)
Connections
Ferrite core (large size)
(supplied)
RGB
PC cable
Less than
3"
(10 cm)
15
/
16
D-sub 15p
AUDIO
PC IN
Stereo plug
Connect a cable which matches
the audio output terminal on the computer.
Installing the ferrite core (Small size)
1
2
3
Open
Pull back the tabs
(in two places)
Press the cable
through and close
Installing the ferrite core (Large size)
1
2
3
Open
Pull back the tabs
(in two places)
Press the cable
through and close
Notes:
(1) Computer signals which can be input are those with a horizontal scanning frequency of 15.6 to 1 10 kHz and vertical
scanning frequency of 48 to 120 Hz. (However, the image will not be displayed properly if the signals exceed 1,200
lines.)
(2) The display resolution is a maximum of 768 × 768 dots (TH-42PHD5) / 1,024 × 768 dots (TH-50PHD5) when the
aspect mode is set to “4:3”, and 1,024 × 768 dots (TH-42PHD5) / 1,366 × 768 dots (TH-50PHD5) when the aspect
mode is set to “16:9”. If the display resolution exceeds these maximums, it may not be possible to show fine detail
with sufficient clarity.
(3) The PC input terminals are DDC1/2B-compatible. If the computer being connected is not DDC1/2B-compatible,
you will need to make setting changes to the computer at the time of connection.
(4) Some PC models cannot be connected to the set.
(5) There is no need to use an adapter for computers with DOS/V compatible D-sub 15P terminal.
(6) The computer shown in the illustration is for example purposes only.
(7) Additional equipment and cables shown are not supplied with this set.
(8) Do not set the horizontal and vertical scanning frequencies for PC signals which are above or below the specified
frequency range.
13
Page 14
1
67839
45
10
1514131211
2
Connections
Signal Names for D-sub 15P Connector
Pin No.
1
2
3
OUT
4
5
RL
Pin Layout for PC Input
Terminal
AV/Component/RGB/PC/DVI input signals
RL
AUDIO
IN
AV input
1 NTSC 15.734 59.95
2 PAL 15.625 50
3 PAL60 15.734 59.95
4 SECAM 15.625 50
5 Modified NTSC 15.734 59.95
S VIDEO
IN
AV input
signal name
VIDEO
IN
VIDEO
Signal Name
R
G
B
GND (Ground)
GND (Ground)
AUDIO
frequency(kHz) frequency(Hz)
VD
COMPONENT/RGB INAV
Component/RGB input
horizontal vertical
Pin No.
HD
PR/CR/R
Signal Name
6
7
8
9
10
GND (Ground)
GND (Ground)
GND (Ground)
NC (not connected)
GND (Ground)
P
B/CB/B Y/G
Pin No.
11
12
13
14
15
PC RGB input
Signal Name
GND (Ground)
SDA
HD/SYNC
VD
SCL
AUDIO
SERIALPC IN
Component/RGB/PC/DVI input
signal name
1 525 (480) /60i 15.734 59.94
2 625 (575) /50i 15.625 50
3 525 (480) /60p 31.468 59.94
4 625 (575) /50p 31.25 50
5 750 (720) /60p 45 60
6 1,125 (1,080) /60i 33.75 60
7 1,125 (1,080) /50i 28.125 50
8 1,125 (1,080) /24p 27 24
9 1,125 (1,080) /24sF 27 48
10 640 × 400 @70 31.5 70
11 640 × 480 @60 31.5 59.94
12 Macintosh13” (640 × 480) 35 67
13 640 × 480 @75 37.5 75
14 852 × 480 @60 31.7 60
15 800 × 600 @60 37.9 60
16 800 × 600 @75 46.9 75
17 800 × 600 @85 53.7 85
18 Macintosh16” (832 × 624) 49.7 75
19 1,024 × 768 @60 48.4 60
20 1,024 × 768 @70 56.5 70
21 1,024 × 768 @75 60 75
22 1,024 × 768 @85 68.7 85
23 Macintosh21” (1,152 × 870) 68.7 75
24 1,280 × 1,024 @60 64 60
25 1,280 × 1,024 @75 80 75
26 1,280 × 1,024 @85 91.1 85
27 1,600 × 1,200 @60 75 60
horizontal vertical
frequency(kHz) frequency(Hz)
Mark:
∗
By installing the RGB(digital)Terminal Board(TY-42TM4D)
to this set the PC input signal can be displayed.
Component RGB PC DVI
∗∗∗
∗∗∗
∗∗
∗∗∗
∗∗∗
∗∗∗
∗∗∗
∗∗∗
∗∗∗
∗∗
∗∗∗
∗∗
∗∗
∗∗∗
∗∗∗
∗∗
∗∗
∗∗
∗∗∗
∗∗
∗∗
∗∗
∗∗
∗∗
∗∗
∗∗
∗∗
14
Page 15
SERIAL Terminals connection
Open
Installing the ferrite core
(Large size)
The SERIAL terminal is used when the Plasma Display is controlled by a computer.
COMPUTER
RS-232C
straight cable
Ferrite core
(large size)
(supplied)
SERIAL
Connections
9876
53214
Pin layout for RS-232C
D-sub 9p
Less than
15
3"
/
16
(10 cm)
Notes:
(1) Use the RS-232C cable to connect the computer to the Plasma Display.
(2) The computer shown is for example purposes only.
(3) Additional equipment and cables shown are not supplied with this set.
The SERIAL terminal conforms to the RS-232C interface specification, so that the Plasma Display can be controlled by
a computer which is connected to this terminal.
The computer will require software which allows the sending and receiving of control data which satisfies the conditions
given below. Use a computer application such as programming language software. Refer to the documentation for the
computer application for details.
Communication parameters
Signal level
Synchronization method
Baud rate
Parity
Character length
Stop bit
Flow control
RS-232C compliant
Asynchronous
9600 bps
None
8 bits
1 bit
-
RS-232C Conversion cable
D-sub 9-pin female
2
3
5
4 6
7
8
1 • 9
Details
R X D
T X D
GND
Non use
Shorted
NC
Basic format for control data
The transmission of control data from the computer
starts with a STX signal, followed by the command,
the parameters, and lastly an ETX signal in that
order. If there are no parameters, then the
parameter signal does not need to be sent.
STX
Start
(02h)
3-character
command (3bytes)
Notes:
(1) If multiple commands are transmitted, be sure to
wait for the response for the first command to
come from this unit before sending the next
command.
(2) If an incorrect command is sent by mistake, this
unit will send an “ER401” command back to the
computer.
Colon Parameter(s)
(1 - 5 bytes)
Command
Command
PON
POF
AVL
ETX:C2C1 C3 P2P1 P3 P4 P5
End
(03h)
AMT
IIS
Parameter
None
None
**
0
1
None
VID
YP1
Power ON
Power OFF
Volume 00 - 63
Audio mute OFF
Audio mute ON
Input select (toggle)
AV Mode
Component / RGB mode (processed as a
Control details
Y/PB/PR or RGB signals as set by this unit)
PC Mode
Screen mode select (toggle)
4 : 3
Zoom
16 : 9
Just
Panasonic Auto
DAM
RG1
None
NORM
ZOOM
FULL
JUST
SELF
With the power off, this display responds to PON command only .
15
Page 16
Basic Controls
Main Power On/Off Switch
Power Indicator
The Power Indicator will light.
Power-OFF...Indicator not illuminated
•
(The unit will still consume some power as
long as the power cord is still inserted into
the wall outlet.)
Stand-by ....Red
•
Power-ON......Green
•
Stand-by (ON/OFF) button
The Plasma Display must first be plugged into the wall outlet
and turnded on at the power switch (see page 18).
Press this button to turn the Plasma Display On, from Stanby mode.
Press it a g a i n t o t u r n t h e P l a s m a D i s p l a y Of f t o S tanby m o d e .
Status button
Press the “Status” button to display the current system status.
AV
4:3
R - STANDBY
G POWER ON
TH-50PHD5
INPUT
INPUT button
(AV(S Video), Component/RGB and
PC Mode Selection)
Press
the “INPUT” button to select AV
(S Video),
input signal modes sequentially.
(see page 19)
Component
1
2
—
VOL
/RGB and PC
(see page 25, 26, 28, 29)
+
V olume Adjustment
Press the Volume Up “+”
or Down “–” button to
increase or decrease the
sound volume level.
N button
Off timer 90
1 AV(S Video), Component/RGB, PC mode
2 Aspect mode (see page 22)
3 Off timer
The off timer indicator is displayed only when the off timer has
been set.
PICTURE POS./SIZE button
(see page 24)
3
Press the “PC” mode selection button to select
the PC mode.
This button is used to switch directly to PC mode.
PICTURE button
(see page 28)
PC button
16
Page 17
Basic Controls
SURROUND button
(see page 27)
SURROUND
NR
INPUT button
(AV(S Video), Component/RGB and PC Mode
Selection)
Press to select AV(S Video), Component/RGB and PC
input signal modes sequentially. (see page 19)
Sound mute On/Off (see page 26)
INPUT
V olume Adjustment
Press the Volume Up “+” or Down “–” button to
increase or decrease the sound volume level.
VOL
R button (see page 21)
ACTION button
Press to make selections
POSITION buttons
POS. /SIZE
PC
PLASMA DISPLAY
SOUND
SET UP
ASPECT
OFF TIMER
SET UP button (see page 20)
SOUND button (see page 26)
ASPECT button
Press to adjust the aspect. (see page 22)
OFF TIMER button
The Plasma Display can be preset to switch to stand-by
after a fixed period. The setting changes to 30 minutes,
60 minutes, 90 minutes and 0 minutes (off timer
cancelled) each time the button is pressed.
30 60
90
0
When three minutes remain, “Off timer 3” will flash.
The off timer is cancelled if a power interruption occurs.
17
Page 18
Power On/Off and input signal selection
AC cord connection
Connecting the AC cord plug to the Plasma Display.
Power On/Off
Connecting the plug to the Wall Outlet
Note:
Main plug types vary between countries. The power
plug shown at left may, therefore, not be the type
fitted to your set.
INPUT
—
VOL
+
R - STANDBY
G POWER ON
R - STANDBY
G POWER ON
TH-50PHD5
Power Indicator
Remote Control Sensor
When the Power is turned on for the
first time, the Language selection
screen is displayed.
From the second time on, language
selection can be done from the setup
menu. (see page 19)
Select the desired language using the
and
keys and press the ACTION
button.
INPUT
OSD Language
English (UK
Deutsch
Fran ais
Italiano
p
a ol
Es
ENGLISH (US
Select
Press the Power switch on the Plasma Display to turn
the set on Power-On.
Power Indicator: Green
Example: The screen below is displayed for a while
after the Plasma Display is turned on.
(setting condition is an example.)
From the second time on, the below screen
is
displayed for a while (setting condition is
)
an example).
AV
4:3
)
Set
Press the
button on the remote control to turn the
Plasma Display off.
Power Indicator: Red (standby)
18
SURROUND
VOL
NR
Press the
button on the remote control to turn the
Plasma Display on.
Power Indicator: Green
Turn the power to the Plasma Display set off by pressing
the
switch on the Plasma Display , when the Plasma
Display is on or in standby mode.
Page 19
Power On/Off and input signal selection
AV Component PC
Select the input signal
INPUT
— VOL +
R - STANDBY
G POWER ON
INPUT
Press the INPUT button to select the input
A V signal desired from equipment such as a
VCR which has been connected to the
Plasma Display .
Input signals will change as follows:
For Component Input (see page 34)
INPUT
— VOL +
For RGB Input (see page 34)
AV RGB PC
INPUT
SURROUND
VOL
Selecting the On-Screen Menu Language
SET UP
Press to display the Set Up menu.
INPUT
SURROUND
VOL
NR
SOUND
SET UP
Press to select the OSD Language.
Press to select your
preferred language.
Selectable languages
English(UK)
Deutsch
Français
Italiano
Español
ENGLISH(US)
.......
(Chinese)
Setup
Component/RGB-in select
Signal
Screensaver
OSD Language
Set up TIMER
English (UK
RGB
)
19
Page 20
On-Screen Menu Display from Remote Control
To Picture adjust menu
(see page 28)
Normalise
Picture Mode
Contrast
Brightness
Colour
Tint
Sharpness
White balance
Advanced settings
Normal
Normal
20
0
0
0
0
Normal
T o Advanced Settings
(see page 28, 29)
Advanced Settings
Normalise
Black extension
W/B High R
W/B High B
W/B Low R
W/B Low B
Gamma
Normal
0
0
0
0
0
To Sound adjust menu
(see page 26)
Sound
Normalise
Sound Mode
Bass
Treble
Balance
Surround
Normal
Normal
0
0
0
On
2. 2
On
INPUT
SURROUND
VOL
NR
POS. /SIZE
PC
SOUND
SET UP
ASPECT
OFF TIMER
Press to select each item.
Setup
Component/RGB-in select
Signal
Screensaver
OSD Language
Set up TIMER
Setup
Component/RGB-in select
Signal
Screensaver
OSD Language
Set up TIMER
RGB
English (UK
RGB
English (UK
)
)
To Picture Pos./Size adjust
menu (see page 24)
During “AV(S Video)” and
“Component” input signal modes.
Picture Pos./Size
Normalise
Normal
H-Pos
H-Size
V-Pos
V-Size
During “RGB” and “PC”
input signal modes.
Picture Pos./Size
Normalise
Normal
H-Pos
H-Size
V-Pos
V-Size
Clock Phase
PLASMA DISPLAY
Setup
Component/RGB-in select
Signal
OSD Language
Screensaver
Set up TIMER
English (UK
RGB
)
20
Page 21
On-Screen Menu Display from Remote Control
Press to access
each adjust screen.
Press the R buttun to return to
“Setup” menu.
R
To Signal screen for A V
(see page 34, 35)
Signal
3D Y/C Filter (NTSC
Colour system
3:2 Pulldown
Panasonic Auto (4:3
)
)
On
Auto
Off
4 : 3
To Signal screen for
Component (see page 35)
[
]
Signal
AV
3:2 Pulldown
[
Component
Off
To Signal screen for RGB
(see page 36)
]
Signal
Sync
-
Freq. kHz
H
31.5
60.0
-
Freq. Hz
V
H & V
Note:
“Signal” setup menu displays different setting condition for each input signals. (see page 19)
To setup Screensaver
(see page 32)
Press to select
each time adjust
screen.
Screensaver
Function
Mode
Start Time
Finish Time
SP Adjustment
White bar scroll
off
0:00
0:00
High
Press to display each
adjust screen.
R
Press the R buttun to return
to “Screensaver” menu.
[
]
RGB
Start Time
Start Ttime
Hours Adjustment
Minutes Adjustment
Finish Time
Finish Time
Hours Adjustment
Minutes Adjustment
Periodic Time
Periodic Time
Hours Adjustment
Minutes Adjustment
Operating Time
Operating Time
Hours Adjustment
Minutes Adjustment
To Signal screen for PC
(see page 36)
H & V
0 : 00
00
00
0 : 00
00
00
0:00
00
00
0 : 00
00
00
[
PC
Signal
Sync
H
-
Freq. kHz
31.5
60.0
-
Freq. Hz
V
]
To Set up Timer selection
screen (see page 30)
Set up TIMER
PRESENT TIME
POWER ON Function
POWER ON Time
POWER OFF Function
POWER OFF Time
0:52
Off
0:00
Off
0:00
Press to select each Timer
adjustment items.
When select Timer
adjustment item, press
this button to Set up
TIMER screen.
R
Press the R buttun to return
to “Setup” menu.
PRESENT TIME Setup
PRESENT TIME
Hours Adjustment
Minutes Adjustment
POWER ON Setup
POWER ON Time
Hours Adjustment
Minutes Adjustment
POWER OFF Setup
POWER OFF Time
Hours Adjustment
Minutes Adjustment
99 : 99
00
00
0 : 00
00
00
0 : 00
00
00
21
Page 22
ASPECT Controls
The Plasma Display will allow you to enjoy viewing the picture at its maximum size, including wide screen cinema
format picture.
INPUT
SURROUND
VOL
NR
POS. /SIZE
PC
SOUND
SET UP
ASPECT
OFF TIMER
ASPECT
ASPECT button
The aspect mode changes each time the ASPECT button
is pressed.
4 : 3 Zoom 16 : 9
Panasonic Auto Just
Notes:
(1) During RGB and PC input signal modes, the mode switches between
“4:3”, “Zoom” and “16:9” only.
(2) For a 1,125i (1,080i), 750p (720p) signal input during “Component”
input signal mode, the mode is set to “16:9” mode, and switching is
not possible.
For a 525i (480i), 625i (575i), 525p (480p) and 625p (575p) signal
input during “Component” input signal mode, “Panasonic Auto” can
not be selected.
(3) The aspect mode is memorized separately for each input terminal
(AV(S Video), Component, RGB and PC).
PLASMA DISPLAY
22
Page 23
ASPECT Controls
Mode
4 : 3
Zoom
16 : 9
Just
4
4 : 3
3
4
3
4
3
4
3 9
16
Zoom
9
16
16 : 9
9
16
Just
4:3 will display a 4:3 picture at its standard 4:3 size.
Zoom mode magnifies the central section of the
picture.
16:9 will display the picture at its maximum size but
with sight elongation.
Just mode will display a 4:3 picture at its maximum
size but with aspect correction applied to the center
of the screen so that elongation is only apparent at
the left and right edges of the screen. The size of
Explanation
the picture will depend on the original signal.
416
Panasonic Auto
39
The display will automatically become enlarged
(depending on the picture source), allowing you to
view the picture at its maximum size.
Note:
Panasonic
Auto
For an elongated image
4
3
For a 4:3 image
Image is expanded
Changes in accordance
with the Panasonic Auto
mode setting (see page
35)
Panasonic Auto mode is designed to automatically
adjust the aspect ratio to handle a mix of 16:9 and
4:3 program material. Certain 4:3 program material,
such as stock market data screens, may
occasionally cause the image size to change
unexpectedly. When viewing such programs, it is
recommended that the ASPECT be set to 4:3.
Notes:
(1) Do not allow the picture displayed in 4:3 mode for an extended period, as this can cause a parmanent after-image
to remain on the Plasma Display Panel.
(2) The S Video terminal on this set can detect specially encoded signals that are compatible with a wide screen
monitor. When a full image from the S Video terminal of specially encoded video is detected by the set, the screen
size is automatically set to 16:9 mode.
23
Page 24
Adjusting Picture Pos./Size
Adjusting screen
1
POS. /SIZE
2
During “AV(S Video)” and
“Component” input signal modes.
Picture Pos./Size
Normalise
Normal
H-Pos
H-Size
V-Pos
V-Size
Press to display the Picture Pos./Size
menu.
Press to select H-Pos/H-Size/V-Pos/VSize/Clock Phase.
During “RGB” and “PC”
input signal modes.
Picture Pos./Size
Normalise
Normal
H-Pos
H-Size
V-Pos
V-Size
Clock Phase
N
POS. /SIZE
PC
SURROUND
SOUND
INPUT
VOL
R
SET UP
ASPECT
OFF TIMER
3
R
Press to adjust Pos./Size.
PLASMA DISPLAY
Press to exit from adjust mode.
Notes:
(1) Adjustment details are memorized separately for different input signal formats (Adjustments for component
signals are memorized for 525i (480i), 625i (575i), 525p (480p), 1,125i (1,080i) and 625p (575p), 750p (720p)
each, and RGB/PC signals are memorized for each frequency.)
(2) If a “Cue” or “Rew” signal from a VCR or DVD player is received, the picture position will shift up or down. This
picture position movement cannot be controlled by the Picture Pos./Size function.
24
Page 25
Adjusting Picture Pos./Size
H-Pos
H-Size
V-Pos
When the Position Left
When the Position Left
When the Position Left
“ ”
button is pressed.
“ ”
button is pressed.
“ ”
button is pressed.
When the Position Right
When the Position Right
When the Position Right
“ ”
button is pressed.
“ ”
button is pressed.
“ ”
button is pressed.
When the Position Left
V-Size
Clock Phase
(RGB/PC in Mode)
Flickering and distortion can be eliminated by using the Position Left
to carry out adjustment.
N
Helpful Hint ( /
While the Picture Pos./Size display is active, if either the N button on the remote control is pressed at any time or the
(ACTION button) is pressed during “Normalise”, then all adjustment values are returned to the factory settings.
“ ”
button is pressed.
Normalise
When the Position Right
Normalisation)
“ ”
“ ”
button is pressed.
or Right
“ ”
button
25
Page 26
Sound Adjustment
1
Select to adjust each item.
2
Bass
Adjusts low sounds
Treble
Adjusts high sounds
Balance
Adjusts left and right
volumes
SOUND
Press to display the Sound menu.
Press to select the desired adjustment menu.
Select the desired level by listening to the sound.
Sound
Normalise
Sound Mode
Bass
Treble
Balance
Surround
Normal
Normal
0
0
0
On
Normal
Auto
INPUT
SURROUND
VOL
N
PICTURE SET UP
Emits the original sound.
Automatically controls
proper volume level.
SOUND
R
Surround (see next page)
Select On or Off
To end adjustments
•
R
Press the R button
Note:
Press the SURROUND button to directly turn the surround effect On and Off. (see next page)
Bass, Treble and Surround settings are memorized separately for each Sound mode. (Normal, Auto)
N
Helpful Hint ( /
While the “Sound” menu is displayed, if either the N button on the remote control is pressed at any time or the
(ACTION button) is pressed during “Normalise”, then all adjustment values are returned to the factory settings.
Normalise
Normalisation)
Mute
Useful when answering the phone or receiving unexpected visitors.
26
Press this button to mute the sound.
Press again to reactivate sound. Sound is also reactivated when power is turned off or
volume level is changed.
Page 27
Surround Controls
INPUT
SURROUND
VOL
NR
PICTURE SET UP
POS. /SIZE
PC
SOUND
ASPECT
OFF TIMER
SURROUND
SURROUND Button
The benefits of surround sound are enormous. You can be
completely enveloped in sound; just as if you were at a
concert hall or cinema.
The surround setting switches on and off each time the
SURROUND button is pressed.
On Off
Surround
Note:
The surround settings are memorized separately for each Sound mode.
(Normal, Auto).
On
PLASMA DISPLAY
27
Page 28
Picture Adjustments
1
2
Picture Mode
Contrast
Brightness
Colour
Tint
Sharpness
White balance
Advanced settings
Select to adjust each item.
Normalise
Normal
Press to display the Picture menu.
Press to select the menu to adjust.
Select the desired level by looking at the picture
behind the menu.
Press the left
modes.
Normal
20
0
0
0
0
Normal
On
Normal
For viewing in standard (evening lighting)
environments.
This menu selects the normal levels of
Brightness and Contrast.
Normalise
Picture Mode
Contrast
Brightness
Colour
Tint
Sharpness
White balance
Advanced Settings
or right
button to switch between
Normal Dynamic
Cinema
Normal
Normal
20
0
0
0
0
Normal
On
Press the left
or right
select “On”. Press the down
button to
button to
enter Advanced Settings mode.
Advanced Settings On
Enables fine picture adjustment at a
professional level (see next page).
Advanced Settings
Normalise
Black extension
W/B High R
W/B High B
W/B Low R
W/B Low B
Gamma
Normal
0
0
0
0
0
2. 2
Advanced Settings Off
Displays images with settings of the
Picture menu.
N
Helpful Hint ( /
Normalise
Dynamic
For viewing in brighter environments.
This menu selects higher than normal
Brightness and Contrast
.
levels of
Cinema
Ideal for movies.
Note:
If you would like to change the picture and colour of
the selected Picture menu to something else, adjust
using the items in the Picture menu. (see next page)
Press the left
or right
button to switch between
modes.
Normal Cool Warm
Normalisation)
While the “Picture” menu is displayed, if either the N button on the remote control is pressed at any time or the
(ACTION button) is pressed during “Normalise”, then all adjustment values are returned to the factory settings.
28
Page 29
Picture Adjustments
Item
Contrast
Brightness
Colour
Tint
(NTSC only)
Sharpness
Note:
In PICTURE, there is not a noticeable change even when contrast is increased with a bright picture or reduced with a
dark picture.
Effect Adjustments
Selects the proper brightness and
Less More
Darker Brighter
Less More
Reddish Greenish
Less More
density for the room.
Adjusts for easier viewing of dark pictures
such as night scenes and black hair.
Adjusts colour saturation.
Adjust for nice skin colour.
Adjusts picture sharpness.
Notes:
(1)
“Colour” and , “Tint”
be adjusted for “RGB” and “PC”
input signal modes.
(2) You can change the level of each
function (Contrast, Brightness,
Colour, Tint, Sharpness) for each
Picture menu.
(3) The setting details for normal,
dynamic and cinema respectively
are memorized separately for each
input mode (A V(S V ideo), Component,
RGB and PC).
(4) The “Tint” setting can be adjusted
for NTSC signal only during “AV
(S Video),” input signal.
settings cannot
Advanced Settings
Item
Black
extension
W/B High R
W/B High B
W/B Low R
W/B Low B
Gamma
Notes:
(1) Carry out “W/B” adjustment as follows.
A Adjust the white balance of the bright sections using the “W/B High R” and “W/B High B” settings.
B Adjust the white balance of the dark sections using the “W/B Low R” and “W/B Low B” settings.
C Repeat steps A and B to adjust.
Steps A and B affect each other’s settings, so repeat each step in turn to make the adjustment.
(2) The adjustment values are memorized separately for each input mode (AV(S Video), Component, RGB and PC).
(3) The adjustment range values should be used as an adjustment reference.
Effect
Less More
Less More
Less More
Less More
Less More
Down Up
Details
Adjusts the dark shades of the image in gradiation.
Adjusts the white balance for light red areas.
Adjusts the white balance for light blue areas.
Adjusts the white balance for dark red areas.
Adjusts the white balance for dark blue areas.
2.0
2.2
2.5
Helpful Hint ( /
On the remote control unit, while the “Advanced settings” menu is displayed, if either the N button is pressed at any
time or the
factory settings.
(ACTION button) is pressed during “Normalise”, then all adjustment values are returned to the
N
Normalise
Normalisation)
29
Page 30
Set up TIMER
The timer can switch the Plasma Display On or Off.
Before attempting Timer Set, confirm the PRESENT TIME and adjust if necessary.
Then set POWER ON Time / POWER OFF Time.
Display the Set up TIMER screen
SET UP
INPUT
SURROUND
VOL
NR
SOUND
SET UP
1
2
PRESENT TIME Set
Press to display the
Setup menu screen.
Press to select
Set up TIMER.
Press to display
the Set up TIMER
screen.
Setup
Component/RGB-in select
Signal
Screensaver
OSD Language
Set up TIMER
Set up TIMER
PRESENT TIME
POWER ON Function
POWER ON Time
POWER OFF Function
POWER OFF Time
English (UK
RGB
)
0:52
Off
0:00
Off
0:00
To set up PRESENT TIME, follow the procedure described below.
Press to select PRESENT TIME.
1
Press to display the PRESENT TIME
Setting screen.
Press to select Hours Adjustment / Minutes
2
Adjustment.
Press to set up Hours or Minutes.
button: Forward
button: Back
Press to store PRESENT TIME Setup.
PRESENT TIME Setup
PRESENT TIME
Hours Adjustment
Minutes Adjustment
PRESENT TIME Setup
PRESENT TIME
Hours Adjustment
Minutes Adjustment
99 : 99
00
00
0 : 52
00
52
30
Page 31
TIMER Set
Setup TIMER
1
2
Press to select
POWER ON Time/POWER OFF Time.
Press to display the POWER ON Setup/
POWER OFF Setup screen.
Press to select Hours Adjustment/
Minutes Adjustment.
Press to adjust each time.
Press to complete POWER ON Time/
POWER OFF Time.
Set up TIMER
PRESENT TIME
POWER ON Function
POWER ON Time
POWER OFF Function
POWER OFF Time
POWER ON Setup
POWER ON Time
Hours Adjustment
Minutes Adjustment
POWER OFF Setup
POWER OFF Time
Hours Adjustment
Minutes Adjustment
0:52
Off
0:00
Off
0:00
0 : 52
00
52
0 : 00
00
00
3
4
Press to select POWER ON
Function/POWER OFF Function.
Press to select On.
R
Press twice to exit from Setup.
Set up TIMER
PRESENT TIME
POWER ON Function
POWER ON Time
POWER OFF Function
POWER OFF Time
0:52
On
0:00
On
0:00
Note:
Timer function will not work unless “PRESENT TIME” is set.
31
Page 32
Screensaver (For preventing after-images)
Do not display a still picture, especially in 4:3 mode, for any length of time.
If the display must remain on, a Screensaver should be used.
1
SET UP
2
Reversal / Scroll selection
3
Press to display the Setup menu screen.
Press to select the Screensaver.
Press to select the Screensaver screen.
Press to select the Function.
Press to select the desired function.
White bar scroll Image Reversal
White bar scroll : The white bar will scroll from left to right.
Setup
Component/RGB-in select
Signal
Screensaver
OSD Language
Set up TIMER
Screensaver
Function
Mode
Periodic Time
Operating Time
SP Adjustment
English (UK
White bar scroll
Interval
RGB
)
0:00
0:00
High
Image Reversal : Negative image will be displayed on the screen.
Mode selection
4
Press to select the Mode.
Press to select each mode items.
Off
Interval : Operates when Periodic Time and Operating Time are setup and those
times arrive.
Time Designation : Operates when Start Time and Finish Time are setup and those
times arrive.
On : Operates when the (ACTION) is pressed.
If the Mode is at On, the menu screen will disappear and the Screensaver
will be activated.
To stop the Screensaver under On, press the R button.
After selecting Time Designation or Interval, the relevant Time Setup will become available for selection and the
Operating Time may be set. (Time cannot be set when “Mode” is “on” or “off.”)
Screensaver
Function
Mode
Start Time
Finish Time
SP Adjustment
White bar scroll
Time Designation
0:00
0:00
Mid
32
Screensaver
Function
Mode
Start Time
Finish Time
SP Adjustment
White bar scroll
Time Designation
0:00
0:00
Mid
Screensaver
Function
Mode
Periodic Time
Operating Time
SP Adjustment
White bar scroll
Interval
0:00
0:00
High
Screensaver
Function
Mode
Start Time
Finish Time
SP Adjustment
White bar scroll
off
0:00
0:00
High
Page 33
Screensaver (For preventing after-images )
Setup of Screensaver Time
5
6
Screensaver
Function
Mode
Start Time
Finish Time
SP Adjustment
White bar scroll
Time Designation
0:00
0:00
Mid
Press to select Start Time/ Finish Time
(When Time Designation is selected).
Press to select Periodic Time/ Operating
Time (When Interval is selected).
Press to select each Time Adjustment
screen.
Screensaver
Function
Mode
Periodic Time
Operating Time
SP Adjustment
White bar scroll
Interval
0:00
0:00
High
Press to select Hours Adjustment/
Minutes Adjustment.
Press to Setup Hours or Minutes.
button: Forward
button: Back
Press to store settings.
Start Time
Start Ttime
Hours Adjustment
Minutes Adjustment
Finish Time
Finish Time
Hours Adjustment
Minutes Adjustment
Periodic Time
Periodic Time
Hours Adjustment
Minutes Adjustment
Operating Time
Operating Time
Hours Adjustment
Minutes Adjustment
0 : 00
00
00
0 : 00
00
00
0:00
00
00
0 : 00
00
00
Note:
Timer function will not work unless “PRESENT TIME” is set.
Side Panel Adjustment
Do not display a picture in 4:3 mode for an extended period, as this can cause
an after-image to remain on the side panels either side of the display field.
To prevent the appearance of such an after-image, illuminate the side panels.
1
2
To display the Screensaver screen.
(Refer to the previous page, operation guide steps 1 and 2)
Press to select the SP Adjustment.
Press to select Off, Low, Mid, High.
Off Low Mid High
Screen Display
Screensaver
side panel
4:3
after-images
White bar scroll
Time Designation
0:00
0:00
Mid
3
R
Press to exit from Screensaver.
Function
Mode
Start Time
Finish Time
SP Adjustment
Notes:
• Setting the side panel to High mode for an extended period may result in occurrence of after-images.
• The side panels may flash (alternate black/white) depending on the picture being shown on the screen. In such an
occurrence, use the Cinema mode.
33
Page 34
Setup for Input Signals
Component/RGB-in Select
Select to match the signals from the source connected to the Component/RGB input terminals.
SURROUND
INPUT
VOL
“Component”
“RGB”
1
2
SET UP
Press to display the Setup menu screen.
Press to select the “Component/RGB-in
select”.
Y, PB, PR signals
R, G, B, HD, VD signals
Press to select the desired mode.
N
PICTURE SET UP
POS. /SIZE
SOUND
R
ASPECT
Setup
Component/RGB-in select
OSD Language
Set up TIMER
Component RGB
R
Press to exit from adjust mode.
Signal
Screensaver
RGB
English (UK
)
3D Y/C Filter – For NTSC AV images
Select “Signal” from the “Setup” menu during AV(S Video) input signal
mode. (“Signal [AV]” menu is displayed.)
Press to select the “3D Y/C Filter (NTSC)”
Press to set On/Off.
R
Press to exit from adjust mode.
Note:
When On, this setting only affects NTSC input signals.
Setup
Component/RGB-in select
Signal
Screensaver
OSD Language
Set up TIMER
Press
Signal
3D Y/C Filter (NTSC
Colour system
3 : 2 Pulldown
Panasonic Auto (4:3
English (UK
(ACTION) button
)
)
RGB
On
Auto
Off
4 : 3
)
[
]
AV
34
Page 35
Colour system / Panasonic Auto
Auto PAL SECAM M.NTSC NTSC
Setup for Input Signals
Select Signal from the “Setup” menu during AV(S Video) input
signal mode.(“Signal [A V]” menu is displayed.)
Press to select the “Colour System” or “Panasonic
Auto”.
Press to select each functions.
If the picture image becomes unstable:
With the system set on Auto, under conditions of
low level or noisy input signals the image may in
rare cases become unstable. Should this occur, set
the system to match the format of the input signal.
Mode
Colour system
Set the colour system to match the input signal. If set to “Auto”, the colour system is determined
automatically.
Function
Setup
Component/RGB-in select
Signal
Screensaver
OSD Language
Set up TIMER
Press
Signal
3D Y/C Filter (NTSC
Colour system
3 : 2 Pulldown
Panasonic Auto (4:3
(ACTION) button
English (UK
)
)
RGB
On
Auto
Off
4 : 3
)
[
]
AV
Panasonic Auto
(4:3)
Set to “4 : 3” to view 4:3 images in an unchanged format when Panasonic Auto is
selected. If you would like to view 4:3 images in “Just” format, set to “Just”.
3:2 Pulldown
When on, the display attempts to reproduce a more natural interpretation of sources such as movie pictures, which are
recorded at 24 frames per second.
If the picture is not stable, turn the setting to off.
Select “Signal” from the “Setup” menu during AV(S Video) or Component
input signal mode.(“Signal [AV]” menu is displayed.)
Press to select 3:2 Pulldown.
Press to set On/Off.
Note:
When On, this setting only affects the following signal input:
• NTSC signal input during “AV(S Video)” input signal mode.
• 525i(480i) signal input during “Component” input signal mode.
Setup
Component/RGB-in select
Signal
Screensaver
OSD Language
Set up TIMER
Press
Signal
3D Y/C Filter (NTSC
Colour system
3 : 2 Pulldown
Panasonic Auto (4:3
English (UK
(ACTION) button
)
)
RGB
On
Auto
Off
4 : 3
)
[
]
AV
R
Press to exit from adjust mode.
Signal
3 : 2 Pulldown
[
Component
]
Off
35
Page 36
Setup for Input Signals
Sync
Select Signal from the “Setup” menu during RGB or PC input signal mode.
Press to adjust.
Setup
Component/RGB-in select
Signal
Screensaver
OSD Language
Set up TIMER
Press
Signal
English (UK
(ACTION) button
RGB
[
)
RGB
]
R
Press to exit from adjust mode.
Setting RGB sync signal:
Confirm that the input is set to RGB input (this setting is valid only for RGB input).
H & V:
on G: Uses a synchronized signal on the Video G signal, which is input
on VIDEO: Compatible with the scart plug (Europe)
The H and V sync signals are input from the HD/VD connector.
from the G connector.
The composite video signal input from the VIDEO input terminal is
used by dividing the sync signals.
Sync
Signal
Sync
Sync
Sync
Sync
-
Freq. kHz
H
V
H
V
31.5
60.0
-
Freq. Hz
-
Freq. kHz
31.5
60.0
-
Freq. Hz
H & V
[
PC
H & V
H & V
on G
on VIDEO
]
Setting PC sync signal:
Confirm that the input is set to PC input (this setting is valid only for PC input).
H & V: The H and V sync signals are input from the HD/VD connector.
on G: Uses a synchronized signal on the Video G signal, which is input from
the G connector.
H-Freq. (kHz)/V-Freq. (Hz)
Displays the H (Horizontal)/V (Vertical) frequencies.
This display is valid only for RGB input and PC input.
Display range:
Horizontal 15.6 - 110 kHz
Vertical 48 - 120 Hz
36
Sync
Sync
H-Freq. kHz
V
-
Freq. Hz
31.5
60.0
H & V
on G
Page 37
Troubleshooting
Before you call for service, determine the symptoms and make a few simple checks as shown below.
Interference
Normal Picture
No Picture
No Picture
Symptoms
Sound
Noisy Sound
No Sound
No Sound
Normal Sound
Checks
Electrical Appliances
Cars/Motorcycles
Fluorescent light
V olume
(Check whether the mute function has been
activated on the remote control.)
Not plugged into AC outlet
Not switched on
Picture and Brightness/Volume setting
(Check by pressing the power switch or
stand-by button on the remote control.)
If a signal with a non-applicable colour
system format, or frequency is input, only
the input terminal indication is displayed.
No Colour
Plasma Display panel
Symptoms
Some parts of the screen
do not light up
After-images appear
Colour controls set at minimum level
(see page 28, 29)
Colour system (see page 35)
Normal Sound
Check
The plasma display panel is manufactured using an extremely high level of
precision technology, however, sometimes some parts of the screen may be
missing picture elements or have luminous spots. This is not a malfunction.
Do not allow a still picture to be displayed for an extended period, as this can
cause a permanent after-image to remain on the Plasma Display.
Examples of still pictures include logos, video games, computer images, teletext
and images displayed in 4:3 mode.
Note:
The permanent after-image on the Plasma Display resulting from fixed image use
is not an operating defect and as such is not covered by the Warranty.
This product is not designed to display fixed images for extended periods of time.
Whirring sounds can be
heard from the display unit.
The display unit is fitted with a cooling fan to dissipate heat generated during normal
use.The whirring sound is caused by rotation of the fan and is not a malfunction.
37
Page 38
Specifications
TH-42PHD5 TH-50PHD5
Power Source
Power Consumption
Normal use
Stand-by condition
Power off condition
Plasma Display panel
Contrast Ratio
Screen size
Operating condition
Temperature
Humidity
Applicable signals
Colour System
Scanning format
PC signals
220 - 240 V AC, 50/60 Hz
375 W 495 W
3.0 W 3.0 W
1.7 W 1.7 W
Drive method AC type Drive method AC type
42-inch, 16:9 aspect ratio 50-inch, 16:9 aspect ratio
3000:1
920 mm (W) × 518 mm (H) × 1,056 mm (diagonal) 1,106 mm (W) × 622 mm (H) × 1,269 mm (diagonal)
No. of pixels No. of pixels
786,432 (1,024 (W) × 768 (H)) [3,072 × 768 dots] 1,049,088 (1,366 (W) × 768 (H)) [4,098 × 768 dots]
0 °C - 40 °C
20 % - 80 %
NTSC, PAL, PAL60, SECAM, Modified NTSC
525i (480i), 625i (575i), 525p (480p), 625p (575p), 750p (720p), 1,125/60i, 50i,
24p, 24sF (1,080/60i, 50i, 24p, 24sF) ······ SMPTE 274M
XGA display
VGA, SVGA, XGA
SXGA, UXGA (compressed)
Horizontal scanning frequency 15.6 - 110 kHz
Vertical scanning frequency 48 - 120 Hz
Connection terminals
AV
COMPONENT/RGB
PC
SERIAL
SPEAKERS (6 Ω)
Video IN/OUT (BNC)
S Video IN (MINI DIN 4PIN)
AUDIO IN (RCA PIN JACK × 2)
Y/G (BNC)
PB/B (BNC)
PR/R (BNC)
HD (BNC)
VD (BNC)
AUDIO IN (RCA PIN JACK × 2)
(HIGH-DENSITY D-SUB 15PIN)
AUDIO IN (M3 JACK)
EXTERNAL CONTROL TERMINAL (D-SUB 9PIN)
16W [8 W + 8 W] (10 % THD) 16W [8 W + 8 W] (10 % THD)
For TY-SP42PWD3W or For TY-SP50PHD3W or
TY-SP42P5W-K TY-SP50P5W-K
1.0 Vp-p (75-ohm or high impedance)
Y: 1 Vp-p (75-ohm), C: 0.286 Vp-p (75-ohm)
0.5 Vrms (high impedance)
1.0 Vp-p/composite (75-ohm)
0.7 Vp-p/non-composite (75-ohm)
0.7 Vp-p (75-ohm)
0.7 Vp-p (75-ohm)
1.0 - 5.0 Vp-p (high impedance)
1.0 - 5.0 Vp-p (high impedance)
0.5 Vrms (high impedance)
R,G,B/0.7 Vp-p (75-ohm)
HD, VD/1.0 - 5.0 Vp-p (high impedance)
0.5 Vrms (high impedance)
RS-232C COMP ATIBLE
38
Page 39
Accessories Supplied
Remote Control Transmitter
Batteries
Fixing bands
Ferrite core
Optional Supplied
Speakers
Pedestal
Wall stand
Mobile stand
Wall-hanging bracket
(vertical)
Wall-hanging bracket
(angled)
Wall-hanging bracket
(Drawer type)
Ceiling unit
RGB(digital)
Terminal Board
Dimensions
(W × H × D)
Specifications
TH-42PHD5 TH-50PHD5
EUR646525
2 × R6 Size
TMME187 × 2
J0KF00000018 × 1, J0KG00000054 × 2
TY-SP42PWD3W or TY-SP50PHD3W or
TY-SP42P5W-K TY-SP50P5W-K
TY-ST05-K
TY-ST42PW1
TY-ST42PF3
TY-WK42PV1
TY-WK42PR1
TY-WK42DR1
TY-CE42PS1
TY-42TM4D
1,020 mm × 610 mm × 89 mm 1,210 mm × 724 mm × 98 mm
1,020 mm
89 mm
1,210 mm
98 mm
Mass (Weight)
610 mm
INPUT
— VOL +
POWER /
R - STANDBY
G POWER ON
—
VOL
+
INPUT
POWER /
R - STANDBY
G POWER ON
724 mm
approx. 30.0 kg net (main unit only) approx. 43.0 kg net (main unit only)
approx. 34.2 kg (with speakers) approx. 47.6 kg (with speakers)
Notes:
(1) Design and specifications are subject to change without notice. Weight and dimensions shown are approximate.
(2) This equipment complies with the EMC standards listed below.
EN55022, EN61000-3-2, EN61000-3-3, EN61000-6-2.
39
Page 40
Customer’ Record
The model number and serial number of this product can be found on its back cover. You should note this serial
number in the space provided below and retain this book, plus your purchase receipt, as a permanent record of
your purchase to aid in identification in the event of theft or loss, and for Warranty Service purposes.
Model Number Serial Number
Matsushita Electric Industrial Co., Ltd.
Web Site : http://www.panasonic.co.jp/global/
Printed in Japan
MBS0602S1072(MS)
Loading...
