Bright, Full HD (1920 x 1080) Professional LCD Display
of
Versatile Functions for Public Information Displays
In addition to the high resolution of Full-HD and the
wide viewing angle of the IPS panel, the LF5 Series
features 500-cd/m
This makes it possible to display crisp, clear
images even in bright places, for signage with
excellent information transmission performance.
2
brightness and 9-ms response.
Brightness
2
(500 cd/m
)
Wide viewing angle
with an IPS panel
Anti image
sticking panel
Portrait
use possible
Optimal Utility for Signage Use
Capable of Continuous, 24-Hour Operation*
Long-life components are incorporated in anticipation of use in harsh
environments. This enables continuous, stable, 24-hour operation.
It also makes this long-term, clear display ideal for signage use in public
spaces such as airports and train stations.
*Continuous 24-hour operation may cause image retention or other problems in the LCD screen,
depending on the display content.
Specifications
TH-47LF5U
DISPLAY PANEL
CONNECTION
TERMINAL
CONTROL
TERMINAL
AUDIO
ELECTRICAL
MECHANICAL
ENVIRONMENTAL
Screen Size (Diagonal)
Aspect Ratio
Effective Display Area (W x H)
Number of Pixels (H x V)
Brightness (Typ)
Contrast Ratio
Response Time
Viewing Angle (Horizontal/Vertical)
Orientation
HDMI IN
DVI-D IN
PC IN
AUDIO IN (L/R)
Serial
AUDIO OUT
Power Requirements
Power Consumption
Power Off Condition
Stand-by Condition
Dimensions (W x H x D)
Bezel Width
Weight
Cabinet Material/Color
Mounting Method
Operating Environment
46.9-inch (1,192 mm)
40.9" x 23.0" (1,039 x 584 mm) 36.6” x 20.6" (930 x 523 mm)
HDMI TYPE A Connector x 2 (Deep Color Compatible)
DVI-D 24 pin (HDCP Compatible) x 1
MINI D-SUB 15 pin x 1, Plug & Play (VESA DDC 2B)
(EXTERNAL CONTROL TERMINAL), RS-232C Compatible
RCA pin (L/R) x 1 set, Output level: Variable (-∞ - 0 dB)
300 W
0.3 W
0.5 W
42.5" x 24.6" x 4.6"
(1,079 x 624 x 117 mm)
0.73" (18.6 mm)
Approx. 54.1 lbs (24.5 Kg)
VESA 15.8" x 15.8" (400 x 400 mm)
Temperature: 32 °F to 104 °F (0 °C to 40 °C)
Humidity 20% to 80% (Non Condensation)
16:9
1,920 x 1,080 pixels
500 cd/m
1,200 : 1
9 ms (G to G)
178° / 178°
Landscape / Portrait
M3 Jack x 1
D-SUB 9 pin x 1
110-127 V AC, 50 Hz / 60 Hz
Plastic / Black
Input Search Function
If the input signal is not detected for some reason, another input with a
signal is automatically selected for reliable operation. The display will not
remain in a no-signal condition, making it well suited to signage use that
produces advertising revenue.
TH-42LF5U
42.0-inch (1,067 mm)
2
38.2” x 22.1” x 4.6”
(968 x 561 x 116 mm)
0.72" (18.3 mm)
Approx. 44.1 lbs (20.0 Kg)
260 W
0.3 W
0.5 W
Stylish and
Energy Saving Design
Narrow Bezel and Multi Display
The bezel on the TH-42LF5U
is only 0.72" (18.3 mm) wide
[0.73" (18.6 mm) on the
TH-47LF5U]. It is a most
suitable model for multi
screen display. The video
image and graphics can be
displayed in greatly by using
g
two or more displays. The
effect of the digital signage of
a high noteworthy level is
achieved by decorating the
wall with the video image.
Eco Mode
The light sensor detects the ambient light level and
control the brightness of the backlight accordingly.
This maintains optimum display brightness. It also
helps to save energy by reducing the backlight
power consumption.
Optional Accessory
Pedestal
TY-ST42P50
0.72-inch
(18.3 mm)
Design and specifications are subject to change without notice.
Simulated pictures on screen.
As of June 5, 2012.
CT12-U01PFLF5-CR
