Fire alarm systems
Units for Hazardous (Ex) areas
• Approved isolator and Intrinsically Safe detectors for conventional zone line input.
General
In hazardous (Ex) areas, Intrinsically Safe
(IS) and approved products are required. To
a zone line input is connected a Galvanic
isolator, to which the intrinsically safe
detectors are connected.
Galvanic isolator MTL5061
The isolator is used to connect the IS detectors and manual call points to a zone line
input. Up to 5 units can be used on the zone
line and an end-of-line resistor is to be
connected in the last unit. The isolator has
two in and outputs (Channel 1 & 2) and is
mounted in a waterproof box (IP66/67).
Supplied with four compression glands for
the cable entries, two 12K e-o-l resistors for
system EBL500 and two 10K e-o-l resistors
for system EBL128.
IS mounting base YBN-R/4 IS
In the base could be plugged a conventional
IS smoke or heat detector.
The base has terminals for the zone line
(in/out) and for an external indicator (LED).
IS smoke detector SLR-E-IS
A conventional IS photoelectric (optical)
smoke detector, to be plugged in the IS
mounting base.
The detector has two built-in LEDs to
indicate that the detector has generated fire
alarm.
IS heat detector DCD-1E-IS
A conventional IS Rate of Rise heat
detector, fixed temperature 60°C (class A1),
to be plugged in the IS mounting base. The
detector has two built-in LEDs to indicate
that the detector has generated fire alarm.
Product applications
The units are used in the systems EBL500
and EBL128 with conventional zone line
inputs available.
Connections, etc. according to connection
diagram for the system respectively.
Page 2
All technical features and data are subject to changes without notice, resulting from continuous development and improvement.
Product Leaflet Date of issue Revision / Date of revision
MEW00319 2002-12-10 4 / 2007-01-29
Type numbers
MTL5061 Galvanic isolator (incl. waterproof box & four compression glands) 1 (2820)
YBN-R / 4 IS Intrinsically safe mounting base (2812)
SLR-E-IS Intrinsically safe photoelectric smoke detector (2810)
DCD-1E-IS Intrinsically safe heat detector (2811)
Technical data
Galvanic
isolator
Base Smoke
detector
Heat
detector
Voltage (V DC)
allowed
nominal
6-35
24
15-30
24
15-30
24
15-30
24
Current consumpt. at nom. volt.
quiescent
active
<400µA
1-40mA
n/a
50 µA
max. 50
mA
35 µA
max. 50
mA
Current consumpt. at nom. volt.
from ext. power supply (mA)
n/a
n/a
n/a
n/a
Ambient temperature (°C)
operating
storage
-20 to +60 -10 to +55
-30 to +70
-10 to +55
-30 to +70
-10 to +55
-30 to +70
Ambient humidity (% RH) max. 95
non cond.
max. 95
non cond.
at 40°C
max. 95
non cond.
at 40°C
max. 95
non cond.
at 40°C
Ingress Protection rating IP66/67
(the box)
IP22
2
IP22 2 IP22
2
Size
h (mm)
175x125x
150
Ø=100x
15
Ø=100x
46 (incl.
base)
Ø=100x
46 (incl.
base)
Weight (g) ~650 50 115 95
Construction / Colour Polycar-
bonate /
grey (RAL
7035)
ABS /
Ivory
white
ABS /
Ivory
white
Polycar-
bonate /
Ivory
white
Approvals, except CE.
BASEEFA
EEx ia IIC
T
amb
=
60°C
n/a
EEx ia IIC
T5, T
amb
=
50°C
II 1 G
EEx ia IIC
T5, T
amb
=
55°C
EN54-7 EN54-5
Zone classification
2
n/a Zone 0, 1
or 2
Category
1, incl.
lower
categories
NOTE! Regarding current consumption for active detectors: All EBL equipment have a
current limitation.
1
Two end-of-line resistors (12K) are included for the system EBL500. Two end-of-line
resistors (10K) are included for system the EBL128. Each has a body surface area > 230 mm
2
and has to be connected in the last unit on the zone line.
2
IP rating not tested. Producer's estimation: IP43.
3
Regarding zone classification: Zone 0 = Category 1, Zone 1 = Category 2 and Zone 2 =
Category 3.
