Page 1

DVD Home Theater Sound System

1 ALL

Operating Instructions

Model No. SC-HT67

Before connecting, operating or adjusting this product, please read these instructions completely. Please keep this manual for future reference.

As an ENERGY STAR® Partner, Panasonic has determined that this product meets the ENERGY

STAR

guidelines for energy efficiency.

The region number of this unit is “1”. You can play DVD-Video marked “1”, “ALL”, or with a region number including “1”. Example:

See page 5 for details.

The servicenter list and warranty can be found on pages 34 and 35.

RQT6191-P

Page 2

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE SCREWS. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Dear customer

Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully.

System

Main unit

Front and surround speakers

Center speaker

Subwoofer

SC-HT67

SA-HT67

SB-AFC95

SB-PC89

SB-W95

Operations in these instructions are described mainly with the remote control, but you can do the operations on the main unit if the controls are the same.

CAUTION!

THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECI-

Getting started

FIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.

WARNING:

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT DAMAGE, DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS.

CAUTION!

DO NOT INSTALL, OR PLACE THIS UNIT, IN A BOOKCASE, BUILT-IN CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT IS WELL VENTILATED. TO PREVENT RISK OF ELECTRIC SHOCK OR FIRE HAZARD DUE TO OVERHEATING, ENSURE THAT CURTAINS AND ANY OTHER MATERIALS DO NOT OBSTRUCT THE VENTILATION VENTS.

CAUTION:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

≥Reorient or relocate the receiving antenna. ≥Increase the separation between the equipment and re-

ceiver.

≥Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

≥Consult the dealer or an experienced radio/TV technician for

help.

Any unauthorized changes or modifications to this equipment would void the user’s authority to operate this device.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

CAUTION:

TO PREVENT ELECTRIC SHOCK MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.

DANGER

AVOID DIRECT EXPOSURE TO BEAM.

VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.

CAUTION

AVOID EXPOSURE TO BEAM.

RAYONNEMENT LASER VISIBLE ET INVISIBLE EN CAS D’OUVERTURE.

ATTENTION

EXPOSITION DANGEREUSE AU FAISCEAU.

SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING.

ADVARSEL

UNDGÅ UDSÆTTELSE FOR STRÅLING.

AVATTAESSA OLET ALTTIINA NÄKYVÄÄ JA NÄKYMÄTÖN

VARO !

LASERSÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN.

SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA DEL

VARNING

ÄR ÖPPNAD. BETRAKTA EJ STRÅLEN.

SYNLIG OG USYNLIG LASERSTRÅLING NÅR DEKSEL ÅPNES.

ADVARSEL

UNNGÅ EKSPONERING FOR STRÅLEN.

SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG, WENN ABDECKUNG

VORSICHT

GEÖFFNET. NICHT DEM STRAHL AUSSETZEN.

RQT6191

(FDA 21 CFR)

(IEC60825-1)

RQLS0233

(Inside of product)

Page 3

Accessories

Please check and identify the supplied accessories. Use numbers indicated in parentheses when asking for replacement parts.

To order accessories contact 1-800-332-5368 or web site (http://www.panasonic.com).

∏ 1 Remote control

(EUR7502XD0)

∏ 1 AC power supply cord

(RJA0065-1D)

Table of contents

Getting started

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . 14

Disc information . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Disc handling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Simple setup

STEP 1 STEP 2

supply cord . . . . . . . . . . . . . . . . . . . . . . . 8

STEP 3 STEP 4

Control reference guide . . . . . . . . . . . . . . . . . . . . 10

Locating and connecting the speakers. .

Television, antennas and AC power

The remote control . . . . . . . . . . . . . . . . 9

Quick Setup . . . . . . . . . . . . . . . . . . . . . . 9

∏ 2 Batteries

for remote control

∏ 1 AM loop antenna set

(RSA0012)

∏ 1 FM indoor antenna

(RSA0006-J)

∏ 1 Video cable

(RJL1P016B15A)

∏ 1 Sheet of speaker feet

(RFA0631A-K)

Replacements sold in

sets of 4.

∏ 1 Sheet of speaker-cord

stickers

(12 stickers)

One set is extra.

The sheet cannot be

purchased separately.

SUBWOOFER

CENTER

SUBWOOFER

CENTER

SUBWOOFER

FRONT L

FRONT R

SURROUND L

SURROUND R

CENTER

FRONT L

FRONT R

SURROUND L

SURROUND R

FRONT L

FRONT R

SURROUND L

SURROUND R

CENTER

FRONT L

FRONT R

SURROUND L

SURROUND R

Disc operations

Discs—Basic play . . . . . . . . . . . . . . . . . . . . . . . . . 11

Using menus to play MP3 discs . . . . . . . . . . . . . . . . . . . . . . . 12

Resume function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Skipping chapters or tracks . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Fast forward and rewind—SEARCH . . . . . . . . . . . . . . . . . . . . 13

Slow-motion play/Frame-by-frame viewing . . . . . . . . . . . . . . . 13

Starting play from a selected track . . . . . . . . . . . . . . . . . . . . . 13

Disc skip/Cinema . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Marking places to play again—MARKER . . . . . . . . . . . . . . . . . .

Discs—Convenient functions . . . . . . . . . . . . . . . 14

A-B repeat play/Repeat play . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Subtitles/Soundtracks/Angles . . . . . . . . . . . . . . . . . . . . . . . . . 14

Using the disc manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Program play/Random play . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Using On-Screen Menu Icons . . . . . . . . . . . . . . . 16

Common procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Progress indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Disc information/Unit information . . . . . . . . . . . . . . . . . . . . . . 17

Radio operations

The radio: manual tuning . . . . . . . . . . . . . . . . . . . 18

The radio: preset tuning . . . . . . . . . . . . . . . . . . . . 19

Sound quality/sound field operations

Sound field. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

DOLBY DIGITAL/DOLBY PRO LOGIC . . . . . . . . . . . . . . . . . . 21

Changing sound field and quality . . . . . . . . . . . . . . . . . . . . . . 21

SUPER SURROUND/SEAT POSITION/CENTER FOCUS . . 22

Adjusting the bass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Getting started

Other functions

Convenient functions . . . . . . . . . . . . . . . . . . . . . . 23

Muting the volume/Turning off the display . . . . . . . . . . . . . . . . 23

Timer functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Using headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Changing settings . . . . . . . . . . . . . . . . . . . . . . . . . 24

Common procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Entering a password (Ratings)/Changing the delay time . . . . 25

Using the remote control with other equipment . .

Operating a television/Operating a video cassette recorder . . 26

Changing the remote control code . . . . . . . . . . . . . . . . . . . . . 27

Listening to an external source/

Recording to other equipment . . . . . . . . . . . . . 28

Optional antenna connections. . . . . . . . . . . . . . . 29

Reference

Troubleshooting guide . . . . . . . . . . . . . . . . . . . . . 30

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Language code list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Servicenter List . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Product Service . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

RQT6191

Page 4

ELECTRIC SERVICE EQUIPMENT

GROUND CLAMP

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

NEC—NATIONAL ELECTRICAL CODE

IMPORTANT SAFETY INSTRUCTIONS

Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the safety precautions listed below. Keep these operating instructions handy for future reference.

Safety

1. Power source—Connect the unit to a power source of the type

described in these instructions or as marked on the unit.

2. Polarization—The unit is equipped with a polarized power plug

where one blade is wider than the other. This safety feature ensures that the plug fits into your household AC outlet only one way. If the plug doesn’t fit one way, try reversing it. If the plug still doesn’t fit, contact an electrician to replace the obsolete outlet. Do not attempt to defeat the safety purpose of the plug.

3. Power cord protection—Route the AC power supply cord so

that it will not be walked on or pinched by items placed on or

Getting started

against it. Never take hold of the plug or cord with wet hands. Always grasp the plug body firmly when connecting and disconnecting it.

4. Overloading—When connecting the AC power supply cord, be

careful not to overload the household AC outlet, extension cord, or outlet from any other device as this can result in fire or electric shock.

5. Nonuse periods—Turn the unit off when it is not in use. Unplug

the unit from the household AC outlet if it is not to be used for a long time. Unplug the unit during lightning storms.

6. Attachments and accessories—Use only the attachments and

accessories recommended in these operating instructions.

Installation

3. Power lines—Take care when setting up an outdoor antenna

that it is not near overhead power lines, electric lights, or electrical circuits, and that there is no danger of the antenna falling on power lines, electric lights, or electrical circuits. When installing an outdoor antenna, take extreme care not to touch such power lines or circuits, as contact with them can be fatal.

4. Outdoor antenna grounding—If you connect an outdoor an-

tenna, ground the antenna system to protect against voltage surges and built-up static charges. Section 810 of the National Electrical Code, ANSI/NFPA No. 70-1990, provides information about grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. Refer to this diagram.

Placement

1. Ventilation—Situate the unit so that it receives proper ventila-

tion. Do not install in a confined space such as a bookcase or cabinet. Allow at least 10 cm (4 inches) clearance from the rear of the unit. To prevent the risk of electric shock or fire due to overheating ensure curtains and other materials do not obstruct the unit’s ventilation.

2. Foreign material—Ensure objects and liquids do not get into

the unit. Avoid exposing the unit to excessive smoke, dust, mechanical vibration, and shock.

3. Magnetism—Situate the unit away from equipment and devices

that generate strong magnetic fields.

4. Stacking—Do not place heavy objects on top of this unit.

5. Surface—Place the unit on a flat, level surface.

6. Carts and stands—Use the unit only with carts

and stands recommended by the manufacturer. Move carts with care. Sudden stops, excessive force, and uneven surfaces can cause carts to overturn.

7. Wall and ceiling mounting—Do not mount the unit on walls or

ceilings unless specified in the instructions.

Environment

1. Water and moisture—Do not use the unit near water, such as

near a bathtub or swimming pool. Avoid damp basements.

2. Heat—Situate the unit away from heat sources, such as

RQT6191

radiators. Do not situate where temperatures fall below 5oC (41oF) or rise above 35oC (95oF).

Maintenance

(See page 31 for details.)

Unplug the unit from the household AC outlet before cleaning. Clean with a damp cloth. Do not use abrasive pads, scouring powders, or solvents.

Service

1. Damage requiring service—The unit should be serviced by

qualified service personnel if: (a) The AC power supply cord or the plug has been damaged;

or (b) Objects or liquids have gotten into the unit; or (c) The unit has been exposed to rain; or (d) The unit does not operate normally or exhibits a marked

change in performance; or (e) The unit has been dropped or the cabinet damaged.

2. Servicing—Do not attempt to service the unit beyond that de-

scribed in these operating instructions. Refer all other servicing to authorized servicing personnel.

3. Replacement parts—When parts need replacing ensure the

servicer uses parts specified by the manufacturer or parts that have the same characteristics as the original parts. Unauthorized substitutes may result in fire, electric shock, or other hazards.

4. Safety check—After repairs or service, ask the servicer to per-

form safety checks to confirm that the unit is in proper working condition.

Page 5

Disc information

Disc handling

∫ Discs that can be played

LogoDisc type

DVD-Video

DVD-R

Audio CD

Video CD

Indication used in instructions

[DVD-V]

[CD]

(Including CD-R/RW and discs recorded with MP3)

[VCD]

∫ Discs that cannot be played

DVD-Audio, PAL discs, DVD-ROM, DVD-RAM, CD-ROM, CDV, CD-G, iRW, DVD-RW, CVD, SVCD, SACD, Divx Video Discs and Photo CD.

∫ Region Management Information

(DVD-Video only)

This unit responds to the Region Management Information recorded on DVD-Video. This unit’s region number is “1”. You cannot play the disc if the region number on the DVD-Video does not correspond to the region number on the unit. You can play discs with labels containing the region number “1” and

“ALL”. Read the disc’s instructions carefully. e.g.

1 ALL

∫ Playing DVDs and Video CDs

The producer of these discs can control how they are played so you may not always be able to control play as described in these operating instructions. Read the disc’s instructions carefully.

Do not use irregularly shaped discs, such as heart-shaped. (These can damage the unit.)

∫ How to hold a disc

Do not touch the recorded surface.

∫ If the surface is dirty

Wipe it with a damp cloth and then wipe dry.

∫ If the disc is brought from a cold to a warm

environment, moisture may form on the disc

Wipe with a soft, dry, lint-free cloth before using the disc.

∫ Handling precautions

≥Do not write on the label side with a ball-point pen or other writing

instrument.

≥Do not use record cleaning sprays, benzine, thinner, static electric-

ity prevention liquids or any other solvent.

≥Do not attach labels or stickers to discs. (Do not use discs with

exposed adhesive from tape or left over peeled-off stickers.)

≥Do not use scratch-proof protectors or covers. ≥Do not use discs printed with label printers available on the market.

∫ Do not place or store discs in the following

places

≥Locations exposed to direct sunlight ≥Humid or dusty locations ≥Locations directly exposed to a heat vent or heating appliance

∫ To prevent damage

≥Load only 1 disc per tray.

Getting started

∫ CD-R and CD-RW discs

This unit can play CD-DA (digital audio) and video CD format audio CD-R and CD-RW that have been finalized (a process that enables CD-R/CD-RW players to play audio CD-R and CD-RW) upon completion of recording. It may not be able to play some CD-R or CD-RW due to the condition of the recording.

∫ DVD-R discs

Panasonic DVD-R recorded and finalized on a Panasonic DVD video recorder are played as DVD-Video on this unit. It may not be possible to play these discs in all cases due to the type of disc or condition of the recording.

≥Load discs as shown in figure.

8 cm (3q)

12 cm (5q)

≥An adaptor is not needed with 8 cm (3q) discs (singles). ≥Set the system on a flat, level surface.

Do not set it on top of magazines, inclined surfaces, etc.

≥Do not move the system while trays are opening/closing, or when

loaded.

≥Do not put anything except discs in trays. ≥Do not use cleaning discs or discs which are badly warped or

cracked.

RQT6191

Page 6

120

Panasonic

Simple setup

Refer also to “Speaker setup”, a separate guide included with these operating instructions.

STEP

Use only supplied speakers

Using other speakers can damage the unit and sound quality will be negatively affected. Set the speakers up on an even surface to prevent them from falling. Take proper precautions to prevent the speakers from falling if you cannot set them up on an even surface.

Front speakers (1 Left 2 Right) SB-AFC95

Simple setup

≥The left and right speakers are the same.

Main unit

Keep your speakers at least 10 mm (13⁄32q) away from the system for proper ventilation.

Locating and connecting the speakers

Center speaker (5) SB-PC89

≥You can also put this speaker directly under the television. ≥Do not place the center speaker on the main unit as sound quality

will be affected.

≥Vibration caused by the center speaker can disrupt the picture if it

is placed directly on the television. Put the center speaker on a rack or shelf.

Subwoofer (6) SB-W95

Place near the television, on the floor or a sturdy shelf so that it won’t cause vibration. ≥A woofer unit is located on the side of the subwoof-

er. Leave 10-cm (4q) clearance for it to be effective.

Place the front, center, and surround speakers at approximately the same distance from the seating position. The angles in the diagram are approximate.

Attaching the speaker feet

Attach these speaker feet to prevent vibration causing the speakers to move or fall over.

Front (12)/surround (34) speakers

Positioning for best effect

How you set up your speakers can affect the bass and the sound field. Note the following points.

≥Place speakers on flat secure bases. ≥Placing speakers too close to floors, walls, and corners can result

in excessive bass. Cover walls and windows with thick curtain.

Laying downStanding

Center speaker (5)

Surround speakers (3 Left 4 Right) SB-AFC95

Place either side of listening position, or slightly to the rear, about 1 meter (3 feet) higher than ear level. ≥The left and right speakers are the same.

Caution ≥Use the speakers only with the recom-

mended system. Failure to do so may lead to damage to the amplifier and/or the speakers, and may result in the risk of fire. Consult a qualified service person if damage has occurred or if you experience a sudden change in performance.

≥Do not attempt to attach these speakers to

walls using methods other than those described in this manual.

If irregular coloring occurs on your television

These speakers are designed to be used close to a television, but the picture may be affected with some televisions and setup combinations.

If this occurs, turn the television off for about 30 minutes.

The television’s demagnetizing function should correct the problem. If it persists, move the speakers further away from the television.

RQT6191

Page 7

Speaker cords

Attach the stickers to the speaker cords.

≥Attach the numbered stickers to the end of the speaker

cords so the numbers match the positions of the speakers shown in the diagram.

FRONT L

SUBWOOFER

FRONT L

FRONT R

SURROUND L

SURROUND R

CENTER

SUBWOOFER

FRONT L

FRONT R

SURROUND L

SURROUND R

CENTER

FRONT L

FRONT R

SURROUND L

SURROUND R

CENTER

SUBWOOFER

FRONT L

FRONT R

SURROUND L

SURROUND R

CENTER

About 10 cm (4")

FRONT L

≥Connect the cords to the terminals of same color so the num-

bers on the stickers match the numbers under the terminals.

≥Never short-circuit positive (i) and negative (j) speaker wires. ≥Be sure to connect only positive (red or gray) wires to positive

(i) terminals and negative (black or gray with blue stripe) wires to negative (j) terminals. Incorrect connection can damage the speakers.

≥After you have completed setup and connection, wind the ex-

cess cord and keep together with string.

≥

The speaker nets cannot be removed.

Notes on speaker use

≥You can damage your speakers and shorten their useful life if

you play sound at high levels over extended periods.

Reduce the volume in the following cases to avoid damage.

–When playing distorted sound. –When the speakers are receiving howling from a micro-

phone or record player, noise from FM broadcasts, or continuous signals from an oscillator, test disc, or electronic instrument.

–When adjusting the sound quality. –When turning the unit on or off.

Black

+ Red

- Black

Twist the vinyl tip and pull off.

CENTER

SUBWOOFER

Subwoofer

Gray

SURROUND

FRONT

ENTER

Center speaker

Blue

Surround speaker (right)

Red

+ Gray (no stripe)

- Gray with blue stripe

FRONT L

FRON

Surround speaker (left)

T R

Front speaker (right)

Simple setup

Front speaker (left)

Attaching to a wall

Front and surround speakers can be attached to a wall. Atttach four speaker feet to each speaker, ensuring they do not cover the holes. Set the speaker onto screws and slide through bracket to lock into position.

Screw (not included)

30–35 mm (13⁄16q–13⁄8q)

7–9 mm (9⁄32q–23⁄64q)

Note

The wall or pillar on which the speakers are to be attached should be capable of supporting 5 kg (11 Ib.) per screw.

Speaker feet (included)

Ø7.5– 9.5 mm (19⁄64q–3⁄8q)

Speaker feet (included)

Attaching to speaker stands

Ensure the following conditions are met when you purchase your speaker stands. ≥Observe the diameter and length of the screws and the distance

between screws as shown in the diagram.

≥The stands must be able to support over 5 kg (11 lb.). ≥The stands must be stable even if the speakers are in a high

position.

5 mm (13⁄64q),

Attach the stands with these holes.

pitch 0.8 mm (1⁄32q)

Plate thickness plus 7 to 10 mm (plus 9⁄32q to 25⁄64q)

Speaker stand (not included)

60 mm (223⁄64q)

RQT6191

Page 8

Simple setup

STEP

Connect directly to your television.

Do not connect the unit through a video cassette recorder, because the picture may not be played correctly due to the copy guard.

Simple setup

To household AC outlet (AC 120 V, 60 Hz)

Television (not included)

Television, antennas and AC power supply cord

VIDEO

Video cable

(included)

Adhesive tape

FM indoor antenna

(included) Fix the other end of the antenna where reception is best.

AM loop antenna (included) Keep loose antenna cord away from other wires and cords.

AM loop antenna holder (included)

To attach to a wall or other surface

Turn the antenna to the angle of best reception and least interference.

Screw

(included)

AC IN~

AC power supply cord

(included)

Note

The included AC power supply cord is for use with this unit only. Do not use it with other equipment.

Conserving power

The unit consumes power (approx. 0.25 W) even when it is turned off with [Í]. To save power when the unit is not to be used for a long time, unplug it from the household AC outlet. Remember to reset the radio stations and any other memory items before using the unit again.

For your reference

Information you enter into the unit’s memory remains intact for up to a week after the AC power supply cord is disconnected.

RQT6191

FM ANT

AM ANT

75 Ω

GND

LOOP

EXT

Audio cable

(not included)

To listen to the television through this unit

TV’s AUDIO OUT terminals

AUDIO

VIDEO

OUT

S-VIDEO

OUT

S video cable (not included)

LOOP ANT

HOLDER

For better images

The S-VIDEO OUT terminal achieves a more vivid picture than the VIDEO OUT terminal by separating the chrominance (C) and luminance (Y) signals before transmitting them to the television. (Actual results depend on the television.)

TV’s S-VIDEO IN terminal

Page 9

STEP

ENTER

VCR TV

TUNER/BAND

AUX

TV/VIDEO

FL DISPLAY

TOP MENU

SKIP

PLAYPAUSE

DISC SKIP CHANNEL VOLUME

SFC

MUTING

SUBWOOFER

LEVEL

STOP

RETURNDISPLAY

SLOW /SEARCH

DVD/CD

MAIN UNIT

ANGLEAUDIOSUB TITLE

SETUP

123

456

789

CH SELECT

TEST

MIX 2ch

DISC1 DISC2

DISC4 DISC5

DISC3

RETURN

3·4·5·6

2·6

SUPER

SURROUND

MARKER

SEAT

POSITION

CENTER

FOCUS

PRO LOGIC

The remote control

∫ Batteries

R6, AA, UM-3

≥Insert so the poles (i and j) match those in the remote control. ≥Do not use rechargeable type batteries.

STEP

Quick Setup

Do not;

≥mix old and new batteries. ≥use different types at the same time. ≥heat or expose to flame. ≥take apart or short circuit. ≥attempt to recharge alkaline or manganese batteries. ≥use batteries if the covering has been peeled off.

Mishandling of batteries can cause electrolyte leakage which can damage items the fluid contacts and may cause a fire.

Remove if the remote control is not going to be used for a long period of time. Store in a cool, dark place.

∫ Use

Aim at the sensor, avoiding obstacles, at a maximum range of 7 m (23 feet) directly in front of the unit.

2 Press [SETUP] to show the QUICK

SETUP screen.

SETUP

SELECT

ENTER RETURN

QUICK SETUP

Select the menu language.

English Français Español

Simple setup

Remote control only

The QUICK SETUP screen appears when you press [SETUP] the first time after purchase and assists you to make necessary settings.

Preparation

Turn on the television and select the appropriate video input on the television to suit the connections for the player.

1 Press [DVD/CD] to turn on the unit.

The unit comes on automatically and “DVD/CD” is selected as the source.

3 Press [3, 4] to select the menu lan-

guage and press [ENTER].

4 Press [3, 4] to select “Yes” to con-

tinue and press [ENTER].

5 Press [3, 4] to select the item and

press [ENTER].

≥Audio Language (For setting details ➡ page 24) ≥Subtitle Language (For setting details ➡ page 24) ≥TV Aspect (For setting details ➡ below)

6 Press [ENTER] and then [SETUP] to

end the settings.

To return to the previous screen

Press [RETURN].

∫ TV Aspect

Select “4:3” (regular) or “16:9” (widescreen) to suit your television. If you have a regular 4:3 television, you can also select how video on some discs is shown (➡ page 24, Video—TV Aspect). ≥4:3 Pan&Scan (Factory preset)

The pan and scan (the original widescreen images are converted for viewing on a regular television) version of the video is automatically selected if recorded on the disc.

≥4:3 Letterbox

The letterbox (the original widescreen images appear with black bands above and below) version of the video is automatically selected if recorded on the disc.

RQT6191

Page 10

Control reference guide

ENTER

VCR TV

TUNER/BAND

AUX

TV/VIDEO

FL DISPLAY

TOP MENU MENU

SKIP

PLAYPAUSE

DISC SKIP CHANNEL VOLUME

SFC

MUTING

SUBWOOFER

LEVEL

STOP

RETURNDISPLAY

SLOW /SEARCH

DVD/CD

MAIN UNIT

DISC

MANAGER

ANGLEAUDIOSUB TITLE

SETUP

TV VOL

123

456

789

PLAY MODE

CH SELECT

TEST

MIX 2ch

DISC1 DISC2

DISC4 DISC5

DISC3

CANCEL

CINEMA

P.MEMORY

TIMER

DISC

B D

; =

A-B

REPEAT

SUPER

SURROUND

MARKER

REPEAT

SEAT

POSITION

CENTER

FOCUS

PRO LOGIC

M O

Getting started

10/ENTER

How to open the remote control

POWER

DISC 1 2 3 4 5

/ I

Buttons 7, 8, and K function the same as the controls on the remote control.

]

WAKE

^`_ab

RQT6191

X 8

YZ[ \U

TUNE MODE

FM MODE

MEMORY

OPEN/CLOSE

VOLUME

SUBWOOFER LEVEL

SFC

DISC SKIP

TUNING

SELECTOR

DOWN UP

PHONES

Remote control

Page

1 Power button [Í] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2 FL display button [FL DISPLAY] . . . . . . . . . . . . . . . . . . . . 23

3 Top menu button [TOP MENU] . . . . . . . . . . . . . . . . . . . 11, 12

4 Cursor buttons [3, 4, 2, 1]/Enter button [ENTER] . . . . . 9

5 Display button [DISPLAY] . . . . . . . . . . . . . . . . . . . . . . . . . . 16

6 Basic operation buttons

7 Disc skip button [DISC SKIP] . . . . . . . . . . . . . . . . . . . . . . . 11

8 Sound field control button [SFC] . . . . . . . . . . . . . . . . . . . . 21

9 Channel select buttons [

: Initial settings button [SETUP] . . . . . . . . . . . . . . . . . . . . 9, 25

; Subtitle button [SUB TITLE] . . . . . . . . . . . . . . . . . . . . . . . . 14

< Speaker channel select button [CH SELECT] . . . . . . . . . . 21

= Test button [TEST] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

> Numbered buttons (1–9, 0, S10/ENTER) . . . . . . . . . . . . . . 11

? Disc button [DISC] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

@ Disc manager button [DISC MANAGER] . . . . . . . . . . . . . . 15

A Play mode button [PLAY MODE] . . . . . . . . . . . . . . . . . . . . 15

B Cinema button [CINEMA] . . . . . . . . . . . . . . . . . . . . . . . . . . 13

C TV volume buttons [

D Position memory button [P.MEMORY] . . . . . . . . . . . . . . . 12

Equipment buttons and indicators

Select the equipment you want to operate.

≥Press [DVD/CD] to operate this unit. ≥Press [VCR] to operate a video cassette recorder. ≥Press [TV] to operate a television.

These buttons light for a few seconds to indicate the remote control mode.

F Input select buttons

[DVD/CD, MAIN UNIT, VCR, TV, TUNER/BAND, AUX]

Pressing [DVD/CD] or [TUNER/BAND] also turns the unit on. [TUNER/BAND] also switches radio bands.

TV/Video button [TV/VIDEO] . . . . . . . . . . . . . . . . . . . . . . . . .

Menu button [MENU] . . . . . . . . . . . . . . . . . . . . . . . . . . . .

I Return button [RETURN] . . . . . . . . . . . . . . . . . . . . . . . . 9, 25

J Muting button [MUTING] . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

K Subwoofer level button [SUBWOOFER LEVEL] . . . . . . . . 22

L Volume buttons [

M Angle button [ANGLE] . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

N Audio button [AUDIO] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

O Marker button [MARKER] . . . . . . . . . . . . . . . . . . . . . . . . . . 13

P Mix 2ch button [MIX 2ch] . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Q Sound field and effect buttons . . . . . . . . . . . . . . . . . . . 21, 22

R Cancel button [CANCEL] . . . . . . . . . . . . . . . . . . . . . . . . . . 13

S Repeat buttons [REPEAT, A-B REPEAT] . . . . . . . . . . . . . 14

T Timer button [TIMER] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

X, CHANNEL] . . . . . . . . . 19, 26

s TV VOL

s, VOLUME] . . . . . . . . . . . . . . . . . 11, 18

r] . . . . . . . . . . . . . . . . . . . 26

11, 12

Main unit

U Standby/on switch [POWER] . . . . . . . . . . . . . . . . . . . . . . . 11

Press to switch the unit from on to standby mode or vice versa. In standby mode, the unit is still consuming a small amount of power.

Standby/on indicator [Í/I]

When the unit is connected to the AC mains supply, this indicator lights red in standby mode and lights green when the unit is turned on.

V Disc indicators [DISC 1–5] . . . . . . . . . . . . . . . . . . . . . . . . . 11

W Wake timer indicator [WAKE] . . . . . . . . . . . . . . . . . . . . . . . 23

X Display

Y Stop, tune mode button [∫, TUNE MODE] . . . . . . . . . 11, 18

Z Pause, FM mode button [;, FM MODE] . . . . . . . . . . . 11, 18

[ Play, memory button [1, MEMORY] . . . . . . . . . . . . . . 11, 19

\ Volume control [VOLUME, DOWN, UP] . . . . . . . . . . . . 11, 18

] Disc tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

^ Open/close button [< OPEN/CLOSE] . . . . . . . . . . . . . . . . 11

_ Skip/search, tuning buttons

[:/6, 5/9,

` Headphone jack [PHONES] . . . . . . . . . . . . . . . . . . . . . . . . 23

a Remote control signal sensor

b Input select button [SELECTOR] . . . . . . . . . . . . . . . . . . . . 11

X TUNING

W] . . . . . . . . . . . . . . . 13, 18

Page 11

ENTER

VCR TV

TUNER/BAND

AUX

TV/VIDEO

FL DISPLAY

TOP MENU

SKIP

PLAYPAUSE

DISC SKIP CHANNEL VOLUME

SFC

MUTING

SUBWOOFER

LEVEL

STOP

RETURNDISPLAY

SLOW /SEARCH

DVD/CD

MAIN UNIT

DISC

MANAGER

A-B

REPEAT

SUPER

SURROUND

ANGLEAUDIOSUB TITLE

SETUP

TV VOL

123

MARKER

456

789

PLAY MODE

CH SELECT

TEST

MIX 2ch

DISC1 DISC2

DISC4 DISC5

DISC3

CANCEL

REPEAT

CINEMA

P.MEMORY

TIMER

DISC

SEAT

POSITION

CENTER

FOCUS

PRO LOGIC

RETURN

3, 4, 2, 1

ENTER

TOP MENU

∫

STOP

:, 9

SKIP

; PAUSE

Discs—Basic play

SUB TITLE

3 Press [<] to open the disc tray and in-

sert a disc.

Press again to close and start play.

Label must face upward. (With double-sided discs, load so the label for the side you want to play faces up.)

Repeat steps 2 and 3 to insert other discs.

4 If play doesn’t start after step 3

Press [1] (PLAY).

[CD] (MP3 discs)

Group and track names are displayed on the television. Press [SUB TITLE] to change the display.

Lights during play.

Center speaker

DVD

DIGITAL

Front speakers

Disc operations

Numbered

buttons

DISC 1 2 3 4 5

/ I

Disc indicators

Í/I POWER

POWER

Disc tray

[DVD-V] [CD] [VCD]

Preparation

≥Turn on the television and select the appropriate video input on the

television to suit the connections for the player.

≥Press [Í/I POWER] to turn on the unit.

1 Press [SELECTOR] to select “DVD/

CD” as the source.

Each time you press the button:

WAKE

10/ENTER

∫

MEMORY

TUNE MODE

FM MODE

;

OPEN/CLOSE

:/6, 5/9

DVD/CD>FM>AM>TV>VCR>AUX

^---------------------------------------------------------}

Remote control: Press [DVD/CD].

2 Press [DISC SKIP] to select a tray.

The indicator lights. Play starts if a disc is in the tray. (One touch play)

Remote control:

Press [DISC] and then press [1]–[5] corresponding to the required tray.

Lights if disc is DVD.

Lights when Dolby Digital

Surround speakers

is detected.

5 Adjust the volume.

∫ To stop play

Press [∫] (➡ page 12, Resume function).

VOLUME

SUBWOOFER LEVEL

DISC SKIP

SFC

SELECTOR

TUNING

DOWN UP

PHONES

∫ To pause play

Press [;] during play. Press [1] (PLAY) to restart play.

Note

≥If “$” appears on the television

The operation is prohibited by the unit or disc.

≥The disc continues to rotate while the menu is displayed even after

you finish playing an item. Press [∫] when you finish to preserve the unit’s motor and your television screen.

≥Volume may be lower when playing DVDs than when playing other

discs or during television broadcasts. If you turn the volume up, be sure to reduce the volume again before playing other sources so that a sudden increase in output does not occur.

When a menu appears on the television

[DVD-V] [VCD]

Remote control only

Press the numbered buttons to select an item.

To select a 2-digit number

Example: To select item 23, press [S10/ENTER] ➡ [2] ➡ [3]. ≥When playing DVDs, you can also use [3, 4, 2, 1] to select

items. Press [ENTER] to confirm your selection.

Play of the selected item now begins.

Other buttons used to operate menus

Read the disc’s instructions for further details about operation. [9]: Shows the next menu. [:]: Shows the previous menu. [RETURN]: Shows the menu screen. [VCD] [TOP MENU]: Shows the first menu screen. [DVD-V] [MENU]: Shows the menu screen. [DVD-V]

RQT6191

Page 12

Discs—Basic play

ENTER

VCR TV

TUNER/BAND

AUX

TV/VIDEO

FL DISPLAY

TOP MENU

SKIP

PLAYPAUSE

DISC SKIP CHANNEL VOLUME

SFC

MUTING

SUBWOOFER

LEVEL

STOP

RETURNDISPLAY

SLOW /SEARCH

DVD/CD

MAIN UNIT

DISC

MANAGER

A-B

REPEAT

SUPER

SURROUND

ANGLEAUDIOSUB TITLE

SETUP

TV VOL

123

MARKER

456

789

PLAY MODE

CH SELECT

TEST

MIX 2ch

DISC1 DISC2

DISC4 DISC5

DISC3

CANCEL

REPEAT

CINEMA

P.MEMORY

TIMER

DISC

SEAT

POSITION

CENTER

FOCUS

PRO LOGIC

P.MEMORY

∫

STOP

6, 5

SLOW/SEARCH

:, 9

SKIP

1 PLAY

MARKER

1–5

DISC

CINEMA

DISC SKIP

CANCEL

; PAUSE

3, 4, 2, 1

ENTER

TOP MENU

Disc operations

Numbered

buttons

10/ENTER

To show other pages

Press [3, 4, 2, 1] to select “Prev” or “Next” and press [ENTER]. After listing all the tracks in one group, the list for the next group appears.

To close the file list screen

Press [TOP MENU] or [MENU].

Using the tree screen to find a group

1 Press [1] while a track is highlighted

to display the tree screen.

File list

G 8 T 14 Total 123

SELECT

ENTER RETURN

You cannot select groups that contain no compatible files.

Tree

MP3 music

001 My Favorite 001 Brazilian pops 002 Chinese pops 003 Czech pops 004 Hungarian pops 005 Liner notes 006 Japanese pops 007 Mexican pops 008 Philippine pops 009 Swedish pops 001 Momoko 002 Standard number 001 Piano solo 002 Vocal

G 8/16

2 Press [3, 4] to select a group and

press [ENTER].

The file list for the group appears.

For your reference

≥Press [2, 1] to jump layers in the tree screen.

Refer to the glossary on page 32 for more information about MP3.

Using menus to play MP3 discs

[CD] (MP3 discs)

This unit can play MP3 files recorded on CD-R/RW with a computer. Files are treated as tracks and folders are treated as groups.

Naming folders and files

At the time of recording, prefix folder and file names with 3-digit numbers in the order you want to play them (this may not work at times).

1 Press [TOP MENU] or [MENU].

2 Press [3, 4] to select the track and

RQT6191

A file list appears. Group name

press [ENTER].

Play starts and continues to the last track in the last group. “0” indicates the track currently playing.

Total

SELECT

ENTER RETURN

File list

No Group: 001 My Favorite Tree

001 Both Ends Freezing

002 Lady Starfish

003 Life on Jupiter

004 Metal Glue

005 Paint It Yellow

006 Pyjamamama

007 Shrimps from Mars

008 Starperson

009 Velvet Cuppermine

010 Ziggy Starfish

NextPrev

Example: MP3

root

001001

001.mp3

002.mp3

003.mp3

002

003

001.mp3

002.mp3

003.mp3

001.mp3

002.mp3

003.mp3

004.mp3

Resume function

[DVD-V] [CD] [VCD] (When the elapsed play time is displayed)

“RESUME” lights on the display when the unit has recorded the position at which you stopped play.

RESUME

Press [1] (PLAY) to start play from that position. (When playing DVD-Video ➡ Chapter Preview below) ≥The position is cleared when:

–The unit is turned off. –The disc is changed or removed. –A source other than DVD/CD is selected.

≥Press [∫] to clear the position.

Position Memory function

During play

Press [P.MEMORY] to memorize a position.

The message “Position memorized” appears on the television. This position is saved even if you change or remove the disc, change the source, or turn the unit off. When you reselect or reinsert the disc, reselect DVD/CD, or turn the unit on, “RESUME” lights on the display. Press [1] (PLAY) to start play from the memorized position. The position is cleared. (When playing DVD ➡ Chapter Preview below)

To clear the position before play

Press [∫]. ≥You can memorize positions on up to five different discs at a time.

When you memorize another position, the earliest position is replaced.

Chapter Preview [DVD-V]

The message “Press PLAY to Preview Chapters” appears immediately after you press [1] (PLAY).

Press [1] (PLAY) while the message is displayed and the beginning portions of each chapter up to the current one are played. Full play resumes from the point where you pressed [∫] or [P.MEMORY]. (This feature works only within a title.) If you do not press [1] (PLAY), the message disappears and play starts from where you pressed [∫] or [P.MEMORY].

Page 13

Skipping chapters or tracks

Disc skip

[DVD-V] [CD] [VCD]

Press [:] or [9].

≥Each press increases the number of skips. ≥Press [:/6, 5/9] on the main unit.

Fast forward and rewind—SEARCH

[DVD-V] [CD] [VCD]

During play

Press [6] or [5].

≥Press and hold [:/6, 5/9] on the main unit.

≥Audio will be heard during search. You can turn this audio off if you

want to (➡ page 24, Audio—Audio during Search).

Slow-motion play

[DVD-V] [VCD]

While paused

Press [6] or [5].

≥Press and hold [:/6, 5/9] on the main unit.

Frame-by-frame viewing

[DVD-V] [VCD]

Remote control only While paused

Press [2] or [1].

The frame changes each time you press the button.

[DVD-V] [CD] [VCD]

Press [DISC SKIP].

Play starts from the beginning of the disc in the next tray. You will skip to tray 1 when the current tray is 5.

Note

[DISC SKIP] does not work during program and random play or while the disc manager is on.

Cinema

[DVD-V] [VCD]

Remote control only

You can change the picture quality for movie viewing.

Press [CINEMA].

Cin.1

Each time you press the button:

[>Cin.1: Mellows images and enhances detail in dark scenes. l

;

l Cin.2: Sharpens images and enhances detail in dark scenes. l

;

{= Nor.: Normal mode (Factory preset)

For your reference

You can make finer adjustments to the picture if desired (➡ page 17, Digital picture mode— User mode).

Disc operations

≥The frames change in succession if you press and hold the button. ≥Pressing [;] also activates forward frame-by-frame.

Note

≥

The speed of search and slow-motion increases up to 5 steps.

≥Press [1] (PLAY) to restart play. ≥You cannot move backwards with Video CD during frame-

by-frame and slow-motion.

When playing Video CDs with playback control

Pressing buttons to perform skip, search or slow-motion may take you to a menu screen.

Starting play from a selected track

[CD] [VCD]

Remote control only

1 Press [DISC]. 2 Press [1]–[5] to select a disc. 3 Wait for the disc to change and play to start

Press the numbered buttons to select the track.

To select a 2-digit number

Example: To select track 23, press [S10/ENTER] ➡ [2] ➡ [3].

Play starts from the selected item.

Note

≥This works only when stopped with some discs. ≥MP3 discs

Press [ENTER] after pressing the numbered buttons. (You do not have to press [S10/ENTER].)

Marking places to play again— MARKER

[DVD-V] [CD] [VCD]

(When the elapsed play time is displayed) Remote control only

You can mark up to 5 points on a disc to return to later.

1 During play

Press [MARKER].

✱✱✱✱✱

2 Press [ENTER] at the point you want

to mark.

To select another marker, press [2, 1].

To play from a marked position

Press [2, 1] to select a marker number and press [ENTER].

To clear a marker

Press [2, 1] to select a marker number and press [CANCEL].

Note

≥Some subtitles may fail to appear around the marker. ≥All the markers are cleared when:

–The unit is turned off. –The disc is changed or removed. –A source other than DVD/CD is selected.

RQT6191

Page 14

Discs—Convenient functions

ENTER

VCR TV

TUNER/BAND

AUX

TV/VIDEO

FL DISPLAY

TOP MENU

SKIP

PLAYPAUSE

DISC SKIP CHANNEL VOLUME

SFC

MUTING

SUBWOOFER

LEVEL

STOP

RETURNDISPLAY

SLOW /SEARCH

DVD/CD

MAIN UNIT

DISC

MANAGER

A-B

REPEAT

SUPER

SURROUND

ANGLEAUDIOSUB TITLE

SETUP

TV VOL

123

MARKER

456

789

PLAY MODE

CH SELECT

TEST

MIX 2ch

DISC1 DISC2

DISC4 DISC5

DISC3

CANCEL

REPEAT

CINEMA

P.MEMORY

TIMER

DISC

SEAT

POSITION

CENTER

FOCUS

PRO LOGIC

∫

STOP

1–5

PLAY MODE

DISC

MANAGER

DISC

1 PLAY

REPEAT A-B REPEAT

:, 9

SKIP

SUB TITLE

ANGLE

AUDIO

A T

ALL DISC

Repeat play

During play

Press [REPEAT].

Each time you press the button:

[DVD-V] [CD] (MP3 disc)

Chapter_--)Title_--)OFF Track_)Group_)OFF ^------------------------------------} ^-----------------------------------}

3, 4, 1

Disc operations

Numbered

buttons

10/ENTER

Remote control only

A-B repeat play/Repeat play

[DVD-V] (When the elapsed play time is displayed)

[CD] [VCD]

You can repeat a section between points A and B within a title or track.

A-B repeat play

C T

OFF

T G

OFF

[CD] [VCD]

Repeat on()OFF

You can repeat tracks as follows depending on the DISC MANAGER setting

(➡ page 15)

Normal or 1-TRACK ALL-DISC 1-DISC

If the Video CD has playback control

Press [∫].

Press the numbered buttons to select a track to start play (➡ page 13).

3. Press [REPEAT] (➡ above).

Note

You cannot use repeat play to repeat an entire DVD-Video or an entire MP3 disc.

∫ To repeat only your favorite tracks

[CD] [VCD]

Start program play (➡ page 15) and press [REPEAT] to display the repeat mode you like.

Subtitles/Soundtracks/Angles

[DVD-V]

Some DVDs have multiple soundtracks, subtitle languages and camera angles, and you can change these during play. ≥“–” or “– –” is displayed instead of the language number in circum-

stances such as when no language is recorded on the disc.

1 During play

Press [A-B REPEAT] at the starting point (A).

RQT6191

2 Press [A-B REPEAT] at the finishing

To cancel

Press [A-B REPEAT] until “ ” is displayed.

Note

≥Some subtitles recorded around point A or B may fail to appear. ≥The unit automatically determines the end of a title/track as point B

when the end of the title/track is reached.

✱

point (B).

A B

A-B repeat starts.

✱ ✱

Subtitles

During play

Press [SUB TITLE].

The number changes each time you press the button.

English

I love you

≥In some cases, the subtitle language is not changed to the

selected one immediately.

≥If the subtitles overlap closed captions recorded on discs, turn the

subtitles off.

To clear/display the subtitles

1. Press [SUB TITLE].

2. Press [1].

3. Press [3, 4] to select “OFF” or “ON”.

French

Je t’aime

Page 15

Soundtracks

3/2.1 ch

Digital

1 English

RANDOM

ALL DISC

During play

Press [AUDIO].

The number changes each time you press the button.

Program play/Random play

[CD] [VCD]

While stopped

Press [PLAY MODE] to select the play mode.

The mode changes as follows each time you press the button.

Program play Random play

≥You can also use this button to turn the vocals on and off on

karaoke discs. Read the disc’s instructions for details.

≥Refer to [B] on page 17 for audio signal type details. ≥[VCD]

Audio changes as follows each time you press [AUDIO]: LR>L>R

^--------------}

This may not work with some discs.

Angles

“ANGLE” lights on the unit’s display when this is available.

During play

Press [ANGLE].

The number changes each time you press the button.

Using the disc manager

[CD] [VCD]

The disc manager allows you to choose one track or disc to play or to play all five discs in succession.

1 While stopped

Press [DISC MANAGER] to select the desired method.

Each time you press the button:

ALL DISC

(1-TRACK): One track play

(1-DISC): Plays one disc.

(ALL-DISC):

Plays five discs in succession.

DISC

Normal play All disc random play

After selecting the mode, follow the steps for the mode.

PRGM

Program play

To play a maximum of 24 tracks in a programmed order

Select tracks from any disc.

1 Press [DISC] and [1]–[5] to select the

disc.

2 Press the numbered buttons to select

a track.

≥Repeat steps 1 and 2 to program other tracks. ≥Step 1 is unnecessary when programming tracks on the

same disc.

3 Press [1] (PLAY).

Play now begins in the programmed sequence.

When play is stopped and the program contents are shown on the display, you can also do the following. ≥To add tracks

Repeat steps 1 and 2.

≥To check program contents

Press [:] or [9].

≥To clear tracks

Press [CANCEL] to clear the last track in the program, or press [:] or [9] to select a track and press [CANCEL].

≥To clear the whole program

Press [∫] so “CLEAR” is displayed. (If “CLEAR” is not displayed, start and stop play, then press [∫] again.)

Note

Discs or tracks the unit cannot find can be programmed but are canceled during play. This is also the case if you program DVD-Video and MP3 discs.

Disc operations

(NORMAL): Normal play (off)

2 Select the disc and track.

≥When selecting “1-DISC”, press [DISC] and [1]– [5]. ≥When selecting “1-TRACK”, press the numbered buttons.

To select a 2-digit number

Example: To select track 23: press [S10/ENTER] ➡ [2] ➡ [3]. You can also select the track by pressing [:] and [9].

3 Press [1] (PLAY).

To cancel disc manager

Press [∫].

To play a track or disc repeatedly

Press [REPEAT] during disc manager play.

Note

≥

You cannot use the disc manager while “RANDOM” or “PRGM” are on.

≥

When playing video CDs with playback control in the “A” or “ALL DISC” mode, you can play the disc without having to operate the disc’s menus.

≥The disc manager skips any DVD and MP3 discs that are loaded.

Random play

To play tracks on the current disc randomly

Press [1] (PLAY).

Play now begins in random order.

All disc random play

To play tracks on all discs randomly

Press [1] (PLAY).

Play now begins in random order. ≥DVD and MP3 discs are skipped during all disc random play.

Normal play

The program or random mode is canceled (normal play mode is restored) when:

–The unit is turned off. –The disc is changed or removed. –A source other than DVD/CD is selected.

The program is retained in memory.

RQT6191

Page 16

Using On-Screen Menu Icons

ENTER

VCR TV

TUNER/BAND

AUX

TV/VIDEO

FL DISPLAY

TOP MENU MENU

SKIP

PLAYPAUSE

DISC SKIP CHANNEL VOLUME

SFC

MUTING

SUBWOOFER

LEVEL

STOP

RETURNDISPLAY

SLOW /SEARCH

DVD/CD

MAIN UNIT

DISC

MANAGER

MIX 2ch

SUPER

SURROUND

TEST

PRO LOGIC

ANGLEAUDIOSUB TITLEACTION

TV VOL

123

CH SELECT

456

789

PLAY MODE

GROUP PAGE MARKER

DISC1 DISC2

DISC4 DISC5

DISC3

CANCEL

CENTER

FOCUS

CINEMA

P.MEMORY

TIMER

REPEAT

A-B

REPEAT

SEAT

POSITION

DISC

3, 4, 2, 1

ENTER

1 2 3 ✱✱

OFF

DISPLAY RETURN

2 [Unit\information\only]

While the leftmost icon is highlighted

Press [3, 4] to select the menu.

Each time you press the button:

[>Play menu l l l;: l>Display menu l l l;: l>Audio menu l l l;: {>Video menu

I P B

OFF

Nor.

Disc operations

Numbered

buttons

10/ENTER

[DVD-V]

Remote control only

On-Screen Menu Icons are menus that contain information about the disc or unit. These menus allow you to perform operations by changing this information.

Common procedures

1 Press [DISPLAY].

Each time you press the button:

RQT6191

[>Disc information l

1 : 46 : 50

l l; l>Progress indicator l

T C

l l; l>Unit information l l l; {=Original display

≥The screens depend on disc contents.

OFF

1 ENG 3/2.1 ch

1 2 3 ✱✱

Digital

CANCEL

ENG

1 : 23 : 54

3 Press [2, 1] to select the item. 4 Press [3, 4] to select the setting.

≥Items with “3” or “4” above and below can be changed by

[3, 4].

≥Press [ENTER] if the setting does not change after pressing

[3, 4].

≥Some items require different operations. Read the explana-

tions on the following pages.

For your reference

≥Depending on the condition of the unit (playing, stopped, etc.) and

the type of software you are playing, there are some items that you cannot select or change.

≥When numbers are displayed (e.g. title No.), the numbered buttons

are also effective for setting. After entering the numbers, press [ENTER] to register the setting.

To clear the menus

Press [RETURN] until the menus disappear.

∫ To change the position of the menus

1. Press [2, 1] to select the rightmost icon.

2. Press [3, 4] to move the menus.

(There are 5 positions.)

Progress indicator

Indicates how far you have played through an item.

T C

bc d e

a Current position b Title number c Chapter number d Condition – play, pause, or slow/search e Time (When the elapsed play time is displayed)

≥Press [3, 4] to show the elapsed play time or remaining time

for the title.

≥Select a position to start play by specifying a time with the num-

bered buttons.

1 : 23 : 54

Page 17

Disc information

Unit information

T2C

1 : 46 : 50

1 ENG 3/2.1 ch

Icon Content

Title number

Chapter number

Time

≥Press [3, 4] to show the

1 : 46 : 50

≥Select a position to start play by

Digital

1 ENG 3/2.1 ch

Vocal

1 ✱

OFF

ENG

Soundtrack

a Soundtrack language

b Audio signal type

Karaoke vocal on/off

(Karaoke DVD only) Solo: OFF or ON Duet: OFF, V1iV2, V1 or V2

Subtitle language

(See [A] below for language abbreviations.)

Subtitles on/off

ON()OFF

Angle number

[A][A]

[A] Audio/Subtitle language

[A][A]

ENG: English FRA: French DEU: German ITA: Italian ESP: Spanish NLD: Dutch

[B][B]

[B] Signal type/data

[B][B]

LPCM/ÎDigital: Signal type k (kHz): Sampling frequency b (bit): Number of bits ch (channel): Number of channels

Example:

3/2 .1ch

SVE: Swedish NOR: Norwegian DAN: Danish POR: Portuguese RUS: Russian JPN: Japanese

Digital

elapsed play time or remaining time for the title.

specifying a time with the numbered buttons.

(See [A] below for language abbreviations.)

(See [B] below for details.)

ENG

CHI: Chinese KOR: Korean MAL: Malay VIE: Vietnamese THA: Thai ¢: Others

Play menu

Icon

OFF

1 2 3 ✱✱

Display menu

I P B

OFF

Audio menu

OFF

Video menu

Nor.

Content

A-B repeat (➡ page 14)

[ENTER] (start point) ➡ [ENTER] (finish point) To cancel: [ENTER]

Repeat play (➡ page 14) Chapter (C)()Title (T)()OFF

^-----------------------------------------------J

Marker (➡ page 13) You can mark up to 5 positions to play again. [ENTER] (The unit is now ready to accept markers.)

To mark a position [ENTER] (at the desired point) To mark another position: [2, 1] ➡ [ENTER]

To recall a marker: [2, 1] ➡ [ENTER]

To erase a marker: [2, 1] ➡ [CANCEL]

Disc operations

I/P/B display (➡ page 32)

ON()OFF Displays the picture type (I/P/B) in the still picture mode.

(Dolby Digital, 3-channel or over only)

Dialogue Enhancer

ON()OFF The volume of the dialogue from the center channel is raised when you select “ON”.

Digital picture mode

Nor.: Normal mode Cin.1/Cin.2: Cinema mode (➡ page 13) User: User mode The following items are also displayed when you select “User”.

Contrast (j7 to i7) Increases the contrast between white and black parts of the picture.

Brightness (0 to i15) Brightens the picture.

Color (j7 to i7) Adjust the shade of the picture’s color.

.1: Subwoofer signal

(not displayed if there is no subwoofer signal)

.0: No surround .1: Mono surround .2: Stereo surround (left/right)

.1: Center .2: Front leftiFront right .3: Front leftiFront rightiCenter

RQT6191

Page 18

ENTER

VCR TV

TUNER/BAND

AUX

TV/VIDEO

FL DISPLAY

TOP MENU

SKIP

PLAYPAUSE

DISC SKIP CHANNEL VOLUME

SFC

MUTING

SUBWOOFER

LEVEL

STOP

RETURNDISPLAY

SLOW /SEARCH

DVD/CD

MAIN UNIT

DISC

MANAGER

ANGLEAUDIOSUB TITLE

SETUP

123

456

789

PLAY MODE

CH SELECT

TEST

MIX 2ch

DISC1 DISC2

DISC4 DISC5

DISC3

CANCEL

REPEAT

r, s

VOLUME

TUNER/BAND

The radio: manual tuning

3 Press [TUNING (

X or

W)] to select the

frequency of the required station.

MARKER

POSITION

CENTER FOCUS

SUPER

SURROUND

DISC

10/ENTER

PRO LOGIC

Radio operations

Í/I POWER

POWER

DISC 1 2 3 4 5

/ I

WAKE

Radio stations can be tuned manually by selecting the station’s frequency or they can be preset into channels to make it easy to tune (➡ page 19).

Preparation

Press [Í/I POWER] to turn on the unit.

1 Press [SELECTOR] to select “FM” or

OPEN/CLOSE

TUNING

FM MODETUNE MODE

TUNE MODE

FM MODE

MEMORY

“AM”.

Each time you press the button: DVD/CD>FM>AM>TV>VCR>AUX

^---------------------------------------------------------}

≥Remote control: Press [TUNER/BAND].

2 Press [TUNE MODE] to select “MANU-

AL”.

Each time you press the button: MANUAL(>PRESET

RQT6191

MHz

SEAT

PROGRESSIVE OUT

SUBWOOFER LEVEL

DISC SKIP

SELECTOR

TUNING

DOWN UP

PHONES

SELECTOR

VOLUME DOWN, UP

VOLUME

Displayed when a stereo FM broadcast is being received.

STEREO

TUNED

MHz

Displayed when a radio station is tuned.

Press and hold [TUNING (XorW)] until the frequency starts

scrolling to start automatic tuning. Tuning stops when a station is found.

4 Adjust the volume.

If noise is excessive in FM

Press [FM MODE] to display “MONO”.

MONO

TUNED

This mode improves sound quality if reception is weak but broadcasts are heard in monaural. Press [FM MODE] again to cancel the mode. The mode is also canceled when you changed the frequency.

Turn “MONO” off for normal listening. Stereo and monaural broadcasts are automatically played as they are received.

FM frequency step

The step is factory-set to 0.2 MHz, but you can change it to receive broadcasts allocated 0.1-MHz steps.

1 Press [SELECTOR] to select “FM”. 2 Press and hold [SELECTOR].

After a few seconds the display changes to show the current minimum frequency. Continue to hold the button down. The minimum frequency changes and the step is changed.

To return to the original step, repeat the above steps.

Note

Any FM frequencies preset in channels will be changed by this procedure. Preset them again.

MHz

Page 19

ENTER

VCR TV

TUNER/BAND

AUX

TV/VIDEO

FL DISPLAY

TOP MENU

SKIP

PLAYPAUSE

DISC SKIP CHANNEL VOLUME

SFC

MUTING

SUBWOOFER

LEVEL

STOP

RETURNDISPLAY

SLOW /SEARCH

DVD/CD

MAIN UNIT

DISC

MANAGER

ANGLEAUDIOSUB TITLE

SETUP

123

456

789

PLAY MODE

CH SELECT

TEST

MIX 2ch

DISC1 DISC2

DISC4 DISC5

DISC3

CANCEL

REPEAT

DISC

TUNER/BAND

r, s

VOLUME

W, X

CHANNEL

The radio: preset tuning

MHz

Manual presetting

Main unit only

Preset the stations one at a time.

1 Tune to the station (➡ page 18). 2 Press [MEMORY] twice.

Numbered

buttons

POWER

DISC 1 2 3 4 5

/ I

10/ENTER

WAKE

OPEN/CLOSE

XTUNINGW

MARKER

SEAT

POSITION

CENTER

FOCUS

SUPER

SURROUND

PRO LOGIC

MEMORY

DISC SKIP

MEMORY

TUNE MODE

FM MODE

TUNING

PHONES

VOLUME DOWN, UP

VOLUME

PROGRESSIVE OUT

SUBWOOFER LEVEL

SELECTOR

DOWN UP

SELECTOR

3 Press [TUNING (

X or

W)] to select a

channel.

4 Press [MEMORY].

The station occupying a channel is erased if another station is preset in that channel.

Selecting channels

1 Press [TUNER/BAND] to select “FM”

or “AM”.

≥Main unit: Press [SELECTOR].

Each time you press the button: DVD/CD>FM>AM>TV>VCR>AUX

^---------------------------------------------------------}

2 Press the numbered buttons or

[CHANNEL (

W W

W or

W W

channel.

To select a 2-digit number

Example: To select channel 12, press [S10/ENTER] ➡ [1] ➡ [2]. ≥Main unit: Press [TUNING (XorW)] while “PRESET” is

selected.

X)] to select the

Radio operations

There are two methods of presetting stations. Automatic presetting: The stations the tuner can receive are

preset.

Manual presetting: You can select the stations to preset and

Up to 12 stations can each be set in the FM and AM bands.

the order they are preset in.

Automatic presetting

Main unit only

1 Tune to “FM 87.9 MHz” (➡ page 18). 2 Press and hold [MEMORY].

The FM stations the unit can receive are preset.

MHz

3 Tune to “AM 520 kHz” (➡ page 18).

4 Press and hold [MEMORY].

The last station to be preset is displayed when presetting finishes.

The AM stations the unit can receive are preset.

kHz

3 Adjust the volume.

RQT6191

Page 20

Sound field

Note

≥Dolby Pro Logic and Super Surround cannot be used if headphones are connected. ≥You may experience a reduction in sound quality when these sound field systems and effects are used with some sources. If this occurs, turn the

surround system or effect off.

Sound field system Features Software

DOLBY DIGITAL

(➡ page 21)

DOLBY PRO LOGIC

(➡ page 21)

MUSIC

SUPER SURROUND

(➡ page 22)

MOVIE

≥Dolby Digital is a digital encoding

system used on DVD to carry surround sound. It was originally developed for use in cinemas.

≥This unit automatically recognizes

and decodes Dolby Digital.

Dolby Pro Logic is a decoding system that was developed to get a better sense of presence from sources encoded with Dolby Surround. The feeling of position has been improved by the addition of a separate center speaker channel.

≥This mode adds surround effects

to stereo sources.

≥You can adjust the volume of the

surround speakers to get the best surround effect.

≥This mode adds surround effects

to movie software that hasn’t been recorded with the above systems.

≥You can adjust the volume of the

surround speakers to get the best surround effect.

Software encoded with Dolby Digital can be identified with this mark.

≥DVD

Software encoded with Dolby Surround can be identified with this mark.

≥DVD ≥CD, Video CD ≥Laser Disc ≥Video tape ≥Radio

Any stereo sound source.

Other effects

Seat position Center focus

—

Seat position

SFC (Sound Field Control)

Sound quality/sound field operations

(➡ page 21)

Use SFC effects to change the sound quality and add reverberation.

Seat position (➡ page 22)

≥This mode helps maintain

the sound position even if the listening position itself is changed.

RQT6191

Any source.

—

Center focus (➡ page 22)

≥This mode makes it seem like

the sound from the center speaker is coming from within the television.

≥You can select one of two levels.

≥The center speaker should be

placed above the television.

Page 21

ENTER

VCR TV

TUNER/BAND

AUX

TV/VIDEO

FL DISPLAY

TOP MENU

SKIP

PLAYPAUSE

DISC SKIP CHANNEL VOLUME

SFC

MUTING

SUBWOOFER

LEVEL

STOP

RETURNDISPLAY

SLOW /SEARCH

DVD/CD

MAIN UNIT

DISC

MANAGER

A-B

REPEAT

ANGLEAUDIOSUB TITLE

SETUP

TV VOL

123

456

789

PLAY MODE

CH SELECT

TEST

MIX 2ch

DISC1 DISC2

DISC4 DISC5

DISC3

CANCEL

REPEAT

CINEMA

P.MEMORY

TIMER

DISC

3, 4

PRO LOGIC

SFC

CH SELECT

TEST

SEAT

POSITION

SUPER

SURROUND

MARKER

CENTER

FOCUS

PRO LOGIC

MIX 2ch

10/ENTER

DOLBY PRO LOGIC

1 Press [Î PRO LOGIC].

SEAT POSITION CENTER FOCUS

PRO LOGIC

2 Play a Dolby Surround source.

To cancel

Press [Î PRO LOGIC].

Note

Turn Dolby Pro Logic off when playing a DVD recorded with Dolby Digital. The surround effects will not be reproduced correctly if this is left on.

Speaker level adjustments

If the level of the speakers appears to be different while listening to a source, adjust the level of the speakers to the same apparent level.

Preparation

DOLBY DIGITAL: Turn off the other sound field systems. DOLBY PRO LOGIC: Press [Î PRO LOGIC].

1 Press [TEST] to output a test signal.

Remote control only

DOLBY DIGITAL

Play a DOLBY DIGITAL source.

“Î DIGITAL” lights.

DVD

To add power to the bass from the subwoofer ➡ page 22.

To down-mix Dolby Digital (5.1 ch) signals to 2 channels (Front L/R)

Press [MIX 2ch] during play. To cancel, press [MIX 2ch] again.

DVD

DIGITAL

DIGITALMIX2ch

SEAT POSITION CENTER FOCUS

Lch: Front left (j16 dB to 0 dB) Cch: Center (i6 dB to j10 dB) Rch: Front right (j16 dB to 0 dB) RSch: Right surround (i6 dB to j10 dB) LSch: Left surround (i6 dB to j10 dB) ≥The surround channel for Dolby Pro Logic is monaural so the

indicator appears as “Sch” instead.

2 Press [3] (to increase) or [4] (to decrease). To stop the test signal, press [TEST] again.

To adjust speaker level during play

1. Press [CH SELECT] to select the speaker.

Lch>Cch>Rch>RSch>LSch>SWch

^--------------------------------------------------------------}

SWch: Subwoofer (i10 dB to j10 dB)

Dolby Pro Logic

≥The surround channel is monaural so the indicator appears as

“Sch” instead.

≥“SWch” does not appear.

2. Press [3] (to increase) or [4] (to decrease).

Changing sound field and quality

Press [SFC] to select a setting.

HEAVY CLEAR SOFT DISCO LIVE HALL FLAT

Each time you press the button:

HEAVY:Adds punch to rock (factory preset). CLEAR:Clarifies higher sounds. SOFT: For background music. DISCO: LIVE: Makes vocals more alive. HALL: Expands sound to make you feel like you were in a hall. FLAT: Canceled (no effect is added).

Reverberates sound to make you feel like you were in a disco.

Sound quality/sound field operations

RQT6191

Page 22

Sound field

ENTER

VCR TV

TUNER/BAND

AUX

TV/VIDEO

FL DISPLAY

TOP MENU

SKIP

PLAYPAUSE

DISC SKIP CHANNEL VOLUME

SFC

MUTING

SUBWOOFER

LEVEL

STOP

RETURNDISPLAY

SLOW /SEARCH

DVD/CD

MAIN UNIT

DISC

MANAGER

A-B

REPEAT

ANGLEAUDIOSUB TITLE

SETUP

TV VOL

123

456

789

PLAY MODE

CH SELECT

TEST

MIX 2ch

DISC1 DISC2

DISC4 DISC5

DISC3

CANCEL

REPEAT

CINEMA

DISC

SUPER SURROUND

SEAT POSITION

CENTER FOCUS

SUBWOOFER LEVEL

SELECT

SEAT

POSITION

SUPER

SURROUND

MARKER

CENTER

FOCUS

PRO LOGIC

SEAT POSITION

Using this function makes you feel like you are sitting in the ideal seating position (in the center of the circle formed by the speakers), even if you cannot due to the layout of your room.

1 Press [SEAT POSITION].

3, 4 2, 1

10/ENTER

Remote control only

SUPER SURROUND

SEAT POSITION

2 While “1” is flashing

Press [3, 4, 2, 1] to select a position.

SEAT POSITION

To cancel

Press [SEAT POSITION] to clear “1”.

CENTER FOCUS

You can make the sound of the center speaker seem like it is coming from within the television. Place the center speaker above the television.

Press [CENTER FOCUS].

CENTER FOCUS

Press [SUPER SURROUND] to select “MUSIC” or “MOVIE”.

Each time you press the button:

[>MUSIC l

l l

SUPER

SRND

l l

Sound quality/sound field operations

l; l>MOVIE l l l l

l l; {=STEREO SOUND (off)

To cancel

Press [SUPER SURROUND] to select “STEREO SOUND”.

Note

Turn super surround off when playing a DVD recorded with Dolby Digital. The surround effects will not be reproduced correctly if this is

left on.

To adjust the surround speaker level

While playing a source

1 Press [CH SELECT]. 2 Press [3] (to increase) or [4] (to decrease).

RQT6191

Each time you press the button: CENTER FOCUS 1>CENTER FOCUS 2>OFF ^_______----------------------------------}

The CENTER FOCUS 2 enhances the effect and makes it easier to hear dialogue even at low volume.

To cancel

Press [CENTER FOCUS] to clear “1”.

Adjusting the bass

SEAT POSITION

Press [SUBWOOFER LEVEL].

Each time you press the button: SUB W 1>SUB W 2>SUB W 3>SUB W 4>SUB W 0 (off) ^_______---------------------------------------------------------}

Note

You cannot adjust the bass while you are using headphones (“ERROR” appears on the display).

Page 23

Convenient functions

ENTER

VCR TV

TUNER/BAND

AUX

TV/VIDEO

FL DISPLAY

TOP MENU

SKIP

PLAYPAUSE

DISC SKIP CHANNEL VOLUME

SFC

MUTING

SUBWOOFER

LEVEL

STOP

RETURNDISPLAY

SLOW /SEARCH

DVD/CD

MAIN UNIT

DISC

MANAGER

A-B

REPEAT

ANGLEAUDIOSUB TITLE

SETUP

TV VOL

123

456

789

ENTER

PLAY MODE

CH SELECT

TEST

MIX 2ch

DISC1 DISC2

DISC4 DISC5

DISC3

CANCEL

REPEAT

CINEMA

P.MEMORY

TIMER

DISC

MUTING

TUNER/BAND

DVD/CD

TIMER

FL DISPLAY

r, s

VOLUME

MARKER

SEAT

POSITION

CENTER

FOCUS

SUPER

SURROUND

PRO LOGIC

Turning off the display

Remote control only

The display and all indicators, except for the standby/on indicator, are turned off for better television viewing.

Press [FL DISPLAY].

To cancel, press [FL DISPLAY] again.

Timer functions

Remote control only

The SLEEP timer can turn the unit off after a set time and the WAKE timer can turn it on. You can use only one timer at a time.

Preparation

Select the desired source. ≥Disc

Press [DVD/CD] to display “DVD/CD”, and insert an Audio CD, etc.

≥The radio

Press [TUNER/BAND] to select “FM” or “AM” and tune in the desired station.

1 Press [TIMER] to select the timer.

Each time you press the button: SLEEP_--)WAKE_--)OFF

^__________}

WAKE indicator

POWER

DISC 1 2 3 4 5 / I

WAKE

PROGRESSIVE OUT

DISC SKIP

TUNE MODE

FM MODE

OPEN/CLOSE

MEMORY

TUNING

PHONES

Muting the volume

Remote control only

Press [MUTING].

Volume is reduced to minimum.

To cancel

Press [MUTING] again or reduce the volume to minimum (–– dB), then raise it to the required level. Muting is also canceled when the unit is turned off.

VOLUME DOWN, UP

SUBWOOFER LEVEL

SELECTOR

DOWN UP

2 Within 5 seconds,

Press and hold [TIMER] and release when the timer you require is displayed.

The display changes as follows:

≥SLEEP (in minutes)

≥30_--)60_--)90

^---------------------------}

VOLUME

≥WAKE (in hours)

≥5H_--)7H_--)9H

^-----------------------------}

≥SLEEP starts working immediately. ≥WAKE starts working when you switch the unit to standby.

(The “WAKE” indicator lights up.)

Other functions

To cancel the timer

Press [TIMER] to select “OFF”.

To check the setting

Press [TIMER] once.

≥If you set SLEEP, the time remaining appears. ≥If you set WAKE, the setting appears.

To change the setting

Repeat the procedure from the beginning.

Using headphones

1 Reduce the volume and connect the

headphones (not included).

Headphone plug type: 6.3 mm (1⁄4q) stereo

Adjust headphone volume with [VOLUME].

Audio is automatically switched to stereo (2-channel). If sound is distorted, turn on dynamic range compression (➡ page 24, Audio—D. Range Compression).

Note

Avoid listening for prolonged periods of time to prevent hearing damage.

RQT6191

Page 24

Changing settings

This chart shows the settings for this unit. Change the settings to suit your preferences and to suit the unit to the environment in which it is being used. These settings are retained in memory until they are changed, even if the unit is turned off. See page 25 for details on menu operation.

≥Underlined items are the factory preset.

Menus

Disc

[DVD-V]

Video

Audio

Other functions

Display

Others

Audio

Choose the preferred audio language.

Subtitle

Choose the preferred subtitle language.

Menus

Choose the preferred language for disc menus.

Ratings (➡ page 25) Set a ratings level to limit DVD-Video play.

≥The password screen is shown if you choose levels 0 to 7 or if

≥Select “Level 0” to prevent play of discs that do not have ratings

TV Aspect (➡ page 9) Choose the setting to suit your television and preference.

Still Mode (➡ page 32) Specify the type of picture shown when paused.

Black Level Control

Change the black level of the picture.

Speaker Setting [DVD-V] (➡ page 25) (Dolby Digital only) Set the delay time for your center and surround speakers.

D. Range Compression [DVD-V] (Dolby Digital only) Change the dynamic range for late night viewing.

Audio during Search

Choose whether to have sound during search.

Menu Language

Choose the preferred language for these menus and the onscreen messages.

On-Screen Messages

Choose whether to show on-screen messages or not.

QUICK SETUP

Answer questions to make basic settings.

Items

you choose “Ratings” when levels 0 to 7 have been selected.

levels recorded on them.

Options

English French Spanish Original Other ¢¢¢¢ Original: The original language of each disc will be

selected.

Other ¢¢¢¢: Input a code number with the numbered

buttons (➡ page 32).

Automatic English French Spanish Other ¢¢¢¢ Automatic: If the language selected for “Audio” is not

available, subtitles of that language will automatically appear if available on that disc.

English French Spanish Other ¢¢¢¢

Setting ratings (When level 8 is selected)

8 No Limit : All DVD-Video can be played. 1 to 7: Prohibits play of DVD-Video with corresponding

ratings recorded on them.

0 Lock All: Prohibits play of all DVD-Video.

Changing ratings (When level 0–7 is selected)

Unlock Player Change Level Change Password Temporary Unlock

4:3 Pan&Scan 4:3 Letterbox 16:9

Automatic Field Frame

Lighter Darker

Center: 0/1.3/2.6/3.9/5.3 ms Surround (L/R): 0/5.3/10.6/15.9 ms

Off On Turn dynamic range compression on in the following cases.

≥For clear dialogue when listening at low volume. ≥When sound is distorted while playing multi-channel DVD

through two channels (when headphones are connected or when using the MIX 2ch mode.)

On Off

English Français Español

On Off

Yes No

RQT6191

Page 25

ENTER

VCR TV

TUNER/BAND

AUX

TV/VIDEO

FL DISPLAY

TOP MENU

SKIP

PLAYPAUSE

DISC SKIP CHANNEL VOLUME

SFC

MUTING

SUBWOOFER

LEVEL

STOP

RETURNDISPLAY

SLOW /SEARCH

DVD/CD

MAIN UNIT

DISC

MANAGER

A-B

REPEAT

ANGLEAUDIOSUB TITLE

SETUP

TV VOL

123

456

789

PLAY MODE

CH SELECT

TEST

MIX 2ch

DISC1 DISC2

DISC4 DISC5

DISC3

CANCEL

REPEAT

CINEMA

DISC

RETURN

3, 4, 2, 1

ENTER

SETUP

CANCEL

DVD/CD

Numbered

buttons

10/ENTER

Common procedures

Remote control only

See page 24 for menu and option details.

Preparation

Press [DVD/CD] to select “DVD/CD”.

MARKER

SEAT

POSITION

CENTER

FOCUS

SUPER

SURROUND

PRO LOGIC

Entering a password (Ratings)

[DVD-V]

The password screen is shown when you select levels 0 to 7.

Input a 4-digit password with the numbered buttons and press [ENTER]. ≥If you enter a wrong number, press [CANCEL] to erase it before

you press [ENTER].

≥The lock symbol appears closed to show the rating is locked. ≥Do not forget your password.

2. Press [ENTER] to confirm the 4 digits.

Now, when you insert a DVD-Video that exceeds the ratings limit you set, a message appears on the television. Follow the on-screen instructions.

Changing the delay time

[DVD-V]

(Dolby Digital, center and surround speakers only)

For optimum listening with 5.1-channel sound, all the speakers, except for the subwoofer, should be the same distance from the seating position. If you have to place the center or surround speakers closer to the seating position, adjust the delay time to make up for the difference.

Center delay time

SETUP

Exit

SELECT

ENTER RETURN

Exit

Changing the delay time

Press [3, 4, 2] to select the delay time box and press [ENTER].

2. Press [3, 4] to adjust the delay time and press [ENTER].

Surround delay time

Center speaker

1 Press [SETUP] to show the menus.

SETUP

SELECT

ENTER RETURN

≥The QUICK SETUP screen appears when you press

[SETUP] the first time after purchase (➡ page 9).

2 Press [2, 1] to select the menu’s tab.

The screen changes to display the menu.

Disc Video Audio Display Others

^__________------------------------------------------------J

3 Press [3, 4] to select the item you

4 Press [3, 4] to select the option and

To return to the previous screen

Press [RETURN].

When you are finished

Press [SETUP].

want to change and press [ENTER].

press [ENTER].

The screen now shows the menu again.

Disc

TAB

Audio

Subtitle

Menus

Ratings

English

Automatic

English

Level 8

() () () ()

Surround speaker

Values

If distance a or b is greater than or equal to distance c, set to “0”. If distance a or b is less than distance c, set as follows.

a Center speaker

Difference

Approx. 50 cm (11⁄2 feet)

Approx. 100 cm (3 feet)

Approx. 150 cm (5 feet)

Approx. 200 cm (6 feet)

Setting

1.3 ms

2.6 ms

3.9 ms

5.3 ms

b Surround speakers

Difference

Approx. 200 cm (6 feet)

Approx. 400 cm (12 feet)

Approx. 600 cm (18 feet)

Setting

5.3 ms

10.6 ms

15.9 ms

When you are finished

Press [2] to select “Exit” and press [ENTER].

Other functions

RQT6191

Page 26

Using the remote control with other equipment

ENTER

VCR TV

TUNER/BAND

AUX

TV/VIDEO

FL DISPLAY

TOP MENU

SKIP

PLAYPAUSE

DISC SKIP CHANNEL VOLUME

SFC

MUTING

SUBWOOFER

LEVEL

STOP

RETURNDISPLAY

SLOW /SEARCH

DVD/CD

MAIN UNIT

DISC

MANAGER

A-B

REPEAT

ANGLEAUDIOSUB TITLE

SETUP

TV VOL

123

456

789

PLAY MODE

CH SELECT

TEST

MIX 2ch

DISC1 DISC2

DISC4 DISC5

DISC3

CANCEL

REPEAT

CINEMA

P.MEMORY

TIMER

DISC

Remote control only

DVD/CD

∫

STOP

W, X

CHANNEL

Numbered

buttons

10/ENTER

MARKER

SEAT

POSITION

CENTER

FOCUS

SUPER

SURROUND

PRO LOGIC

VCR

TV/VIDEO

6, 5

SLOW/SEARCH

1 PLAY

s TV VOL r

Operating a television

Switching to television operation mode

Press [TV].

The button lights. The main unit also switches to television input.

Turning the television on/off

Press [Í].

Changing channels

Press [CHANNEL (

Wor

X)].

You can also select the channel with the numbered buttons.

To select a 2-digit number

Example: To select channel 23, press [S10/ENTER] ➡ [2] ➡ [3].

Adjusting the volume

s s

Press [TV VOL (

s or

s s

r)].

Switching the television’s video input mode

Press [TV/VIDEO].

Operating a video cassette recorder

Switching to video cassette recorder operation mode

Press [VCR].

The button lights. The main unit also switches to VCR input.

Turning the video cassette recorder on/off

Press [Í].

Other functions

RQT6191

Changing channels

Press [CHANNEL (

Wor

X)].

Channels 1 to 10 can also be selected with the numbered buttons. [0] selects channel 10.

Starting play

Press [1] (PLAY).

Fast-forwarding and rewinding

Press [6] or [5].

To stop play

Press [∫].

Note

≥Some models cannot be operated by this remote control. ≥To prevent accidental operation, press [DVD/CD] after oper-

ation so the unit is ready to operate this unit.

Page 27

ENTER

VCR TV

TUNER/BAND

AUX

TV/VIDEO

FL DISPLAY

TOP MENU

SKIP

PLAYPAUSE

DISC SKIP CHANNEL VOLUME

SFC

MUTING

SUBWOOFER

LEVEL

STOP

RETURNDISPLAY

SLOW /SEARCH

DVD/CD

MAIN UNIT

DISC

MANAGER

A-B

REPEAT

ANGLEAUDIOSUB TITLE

SETUP

TV VOL

123

456

789

PLAY MODE

CH SELECT

TEST

MIX 2ch

DISC1 DISC2

DISC4 DISC5

DISC3

CANCEL

REPEAT

CINEMA

P.MEMORY

TIMER

DISC

VCR

Changing the remote control code

This remote control can operate Panasonic and Technics audiovisual equipment that have remote control sensors. You may need to change the remote control code. It can also operate some other brands of televisions and video cassette recorders. Check the table for the brand and enter the code as follows.

Aiming the remote control at the television or video cassette recorder, carefully and slowly

While pressing and holding [TV] or [VCR], press the numbered buttons to enter the code number.

The remote control outputs the on/off signal. If the code is correct, the equipment turns on or off. If it doesn’t, try entering another code.

Numbered

buttons

10/ENTER

MARKER

SEAT

POSITION

CENTER

FOCUS

SUPER

SURROUND

PRO LOGIC

≥Note that this remote control cannot operate some equipment and

that it may not be able to perform some operations.

≥Reenter the codes after you change the batteries.

Other functions

14, 15

Philco: 06, 07 Philips: 06 Pioneer: 02, 10, 19 Quasar: 02 RCA: 03, 07, 09, 13,

Sanyo: 14 Sharp: 08, 21 Sylvania: 06, 07, 15 Symphonic: 17 Toshiba: 10, 21 Zenith: 18, 20

Television code list

Panasonic: 01, 02, 26 Sony: 04 Fisher: 14 G-E: 02, 03, 07, 09 Gold Star: 07, 15 Hitachi: 05, 07 JVC: 12 LXI: 03, 06, 07, 10,

Magnavox: 06, 07, 11, 15,

Mitsubishi: 07, 15, 16, 21 NEC: 07, 15

23, 24, 25

Video cassette recorder code list

Panasonic: 01, 02, 09, 33 Sony: 05, 06, 07, 35,

36, 37

Fisher: 13, 14, 15, 18,

34 Funai: 08, 30 G-E: 02, 03, 11 Gold Star: 27 Hitachi: 09, 10, 11 JVC: 19, 25, 31, 38,

39, 40 LXI: 10, 13, 14, 15,

18, 27, 30 Magnavox: 02, 09, 12 Mitsubishi: 21, 22, 28, 29

NEC: 19, 25, 31, 38 Philco: 02, 09, 12, 30 Philips: 02, 09, 12 Pioneer: 09 Quasar: 01, 02, 09, 33 RCA: 02, 03, 04, 09,

Sanyo: 14, 18, 34 Sharp: 16, 17 Shintom: 32 Sylvania: 02, 09, 12, 30 Symphonic: 30 Toshiba: 23, 24 Zenith: 20

10, 11, 12, 23, 24, 26

RQT6191

Page 28

Listening to an external source/Recording to other equipment

ENTER

VCR TV

TUNER/BAND

AUX

TV/VIDEO

FL DISPLAY

TOP MENU

SKIP

PLAYPAUSE

DISC SKIP CHANNEL VOLUME

MUTING

SUBWOOFER

STOP

RETURNDISPLAY

SLOW /SEARCH

DVD/CD

MAIN UNIT

VCRDVD/CD

AUXTUNER/BAND

≥Turn the unit off before making connections. ≥Refer to the manual of the other unit for details.

(Cables and equipment not included.)

Audio cable (not included)

White (L)

Red (R)

Video cassette recorder (not included)

You can playback the sound from a video cassette recorder through this unit’s speaker.

Other functions

AUDIO

OUT

AUX LINE

VCR

AUDIO

OUT

A B

PLAY

OUT

e.g. Tape deck (not included)

REC

1 Press [VCR].

≥Main unit: Press [SELECTOR].

Each time you press the button: DVD/CD>FM>AM>TV>VCR>AUX

^---------------------------------------------------------}

2 Start play.

[A][A]

[A] You can playback the sound from a tape deck/laser

[A][A]

disc player, etc., through this unit’s speaker.

1 Press [AUX].

≥Main unit ➡ see above.

2 Start play.

[B][B]

[B] You can record sound from the radio or discs, etc. to a

[B][B]

tape deck.

1 ≥Disc

Press [DVD/CD] to select “DVD/ CD”.

≥The radio

Press [TUNER/BAND] to select “FM” or “AM”.

≥Main unit ➡ see above.

2 Start recording and play.

When connecting a record player

We recommend using a record player with a built-in phono equalizer. If your player doesn’t have a built-in equalizer, connect it first to a separate equalizer and then connect that to this unit.

RQT6191

Page 29

Optional antenna connections

Use outdoor antennas if radio reception is poor.

[A][A]

[A]

FM outdoor antenna (Using a television antenna)

[A][A]

≥Disconnect the FM indoor antenna. ≥The antenna should be installed by a competent technician.

[B][B]

[B] AM outdoor antenna (Using a vinyl wire)

[B][B]

Run a piece of vinyl wire horizontally across a window or other convenient location. Leave the loop antenna connected.

FM ANT

FM outdoor antenna

AM ANT

EXT

LOOP

GND

75h

1 Remove a piece of the outer insulator.

2 Twist the shield braid.

3 Expose the core wire.

15 mm (19⁄32q)

75 ≠ coaxial cable (not included)

30 mm (13⁄16q)

Shield braid

Core wire

Note

Disconnect the outdoor antenna when the unit is not in use. Do not use the outdoor antenna during an electrical storm.

FM ANT

75h

GND

AM ANT

LOOP

EXT

AM outdoor antenna

5–12m

(14– 40 feet)

AM loop antenna

Other functions

RQT6191

Page 30

Troubleshooting guide

Before requesting service, make the below checks. If you are in doubt about some of the check points, or if the remedies indicated in the chart do not solve the problem:

Contact the Panasonic Customer Call Center at 1-800-211-7262, or e-mail [email protected], or web site (http:// www.panasonic.com).

Reference pages are shown as black circled numbers 8.

Power

No power.

The unit is automatically switched to the standby mode.

Operation

≥Insert the AC power supply cord securely into the household AC outlet. 8

≥≥

≥The unit was switched to standby by the sleep timer.

≥≥

No response when buttons pressed.

No operations can be performed with the remote control.

Play fails to start even when [1] (PLAY) is pressed. Play starts but then stops immediately.

Alternative languages fail to be selected.

No menu play.

No subtitles.

Soundtrack and/or subtitle language is not the one selected with the SETUP menus.

Angle cannot be changed.

Reference

The SETUP menu cannot be accessed.

You have forgotten your ratings password.

Reset all the settings to Factory Preset.

≥Some operations may be prohibited by the disc. ≥The unit may not be operating properly due to lightning, static electricity or some other external

factor.

Reset procedure:

Press [Í] to switch the unit to the standby mode and then back to ON. Alternatively, press [Í] to switch the unit to the standby mode, disconnect the AC power supply cord, and then reconnect it.

≥Check the batteries are installed correctly. 9 ≥The batteries are depleted: Replace them with new ones. 9 ≥Point the remote control at the remote control sensor and operate. ≥It may be in the television or video cassette recorder operation mode. Press [DVD/CD] to operate

this unit.

≥If the remote control doesn’t operate the television or video cassette recorder, try changing the

code. This remote control cannot operate some televisions or video cassette recorders. J K

≥Condensation has formed: Wait 1 to 2 hours for it to evaporate. ≥This unit cannot play discs other than DVD-Video, CD and Video CD. 5 ≥This unit cannot play DVD-Video with a region number other than “1”, “ALL” or multiple region

numbers including “1”. 5

≥The disc may be dirty and may require cleaning. 5 ≥Ensure that the disc is installed with the label of the side to be played facing upwards. ;

≥An alternative language is not selected with discs which do not contain more than one language. ≥In the case of some discs, the alternative language cannot be selected with [AUDIO] or [SUB

TITLE]. Try selecting it from the disc’s menu if one is available. ;

≥Menus are only displayed if they are recorded on the disc.

≥Subtitles appear only with discs that contain them. ≥Subtitles are cleared from the television. Display the subtitles. >

≥The language is not recorded on the disc.

≥This function is dependent on software availability. Even if a disc has a number of angles

recorded, these angles may be recorded for specific scenes only. ?

≥Select “DVD/CD” as the source. ≥Cancel program and random play. ?

≥While stopped, press and hold [∫] on the unit and [S10/ENTER] on the remote control for about

3 seconds until “Initialized” disappears from the television. Turn the unit off and on again. All settings will return to the default values.

Sound

No sound. Distorted sound.

Humming heard during play.

No sound from the subwoofer.

≥Check the connections. 7 8 L ≥Turn the volume up. ≥Turn muting off. G ≥Switch off the unit, determine and correct the cause, then switch the unit on.

≥An AC power supply cord or fluorescent light is near the cables. Keep other appliances and cords

≥Check that the subwoofer has not been set to “0”. F

RQT6191

Causes include:

–Shorting (bare wires touching) of positive and negative speaker wires. 7 –Using speakers with an impedance lower than that rated for this unit. Q –Straining of the speakers through excessive volume or power. –Using the unit in a hot environment without proper ventilation.

away from this unit’s cables.

Page 31


Picture distorted.

No picture.

The picture shown on the television is not normal. (The sides of the picture are cut off or black bands appear at the top and bottom of the screen.)

Picture quality is poor.

The picture on the television disappears or stripes appear on the screen.

Listening to the radio

Noise is heard. The stereo indicator flickers or doesn’t light. Sound is distorted.

A beat sound is heard.

A low hum is heard during AM broadcasts.

≥Some distortion is normal during SEARCH.

≥Ensure that the television is connected properly. 8 ≥Make sure the television is on. ≥Ensure the television’s video input setting (e.g., VIDEO 1) is correct.

≥Go to the Video menu in the SETUP screen, and change “TV Aspect” to suit your television. You

may also need to change the screen mode on the television itself. 9 H

≥Ensure that the unit is connected directly to the television, and is not connected through a video

cassette recorder.

≥Check the settings in the On-Screen Menu Icons’ video menu. A

≥The location and orientation of the antenna are incorrect. If you are using an indoor antenna,

change to an outdoor antenna. M The television antenna wire is too close to the unit. Separate the antenna wire of the television from the unit.

≥Adjust the position of the FM or AM antenna. 8 ≥Use an outdoor antenna. M

≥Turn the television off or separate it from the unit.

≥Separate the antenna from other cables and cords.

Unit displays

This unit’s display is off.

“NO PLAY”

“NO DISC”

“F61”

“DTS NO AUDIO”

“DTS CD”

“DVD U11”

“ERROR”

“DVD H∑∑”

∑∑ stands for a number.

“TAKE OUT DISC”

Television displays

No on-screen display.

On-Screen Menu Icons not displayed or only partially displayed on the television.

The disc’s menu is displayed in a different language.

≥Press [FL DISPLAY] to turn the display on. G

≥You inserted a disc the unit cannot play; insert one it can. 5

≥You haven’t inserted a disc; insert one. ≥You haven’t inserted the disc correctly; insert it correctly. ;

≥Check and correct the speaker cord connections. 7

If this does not fix the problem, there is a power supply problem.

≥This unit is unable to decode DTS signals.

≥The disc is dirty. Wipe it with a soft cloth. 5

≥Incorrect operation performed. Read the instructions and try again.

≥Trouble is likely to have occurred. The number following “H” depends on the status of the unit.

Reset procedure:

Press [Í] to switch the unit to the standby mode and then back to ON. Alternatively, press [Í] to switch the unit to the standby mode, disconnect the AC power supply cord, and then reconnect it.

≥If the service numbers fail to clear, note the service number and contact a qualified service person.

≥A problem has occurred with the tray mechanism. The tray will open automatically. Take out the

disc and close the tray. The unit will make the disc changing noises for a few moments and then should operate normally.

≥Go to Display in the SETUP menus, and select “On” for “On-Screen Messages”. H

≥Press [3, 4] while the rightmost icon is highlighted to move them down. @

≥Go to Disc in the SETUP menus, and select the preferred language for “Menus”. H

Reference

Maintenance

To clean this unit, wipe with a soft, damp cloth.

≥Never use alcohol, paint thinner or benzine to clean this unit. ≥Before using chemically treated cloth, read the instructions that came with the cloth carefully.

RQT6191

Page 32

Glossary

Bitstream

This is the digital form of multiple channel audio data (e.g., 5.1 channel) before it is decoded into its various channels.

Decoder

A decoder restores the coded audio signals on DVDs to normal. This is called decoding.

Dolby Digital

This is a method of coding digital signals developed by Dolby Laboratories. Apart from stereo (2-channel) audio, these signals can also be 5.1-channel audio. A large amount of audio information can be recorded on one disc using this method.

Dolby Pro Logic

A surround system where a 4-channel audio track is recorded as 2 channels and then is restored to 4 channels for play. The surround channel is monaural and can reproduce up to 7 kHz.

Dynamic range

Dynamic range is the difference between the lowest level of sound that can be heard above the noise of the equipment and the highest level of sound before distortion occurs.

Frame still and field still

Frames are the still pictures that go together to make a moving picture. There are about 30 frames shown each second. One frame is made up of two fields. A regular television shows these fields one after the other to create frames. A still is shown when you pause a moving picture. A frame still is made up of two alternating fields, so the picture may appear blurred, but overall quality is high. A field still is not blurred, but it has only half the information of a frame still so picture quality is lower.

I/P/B

MPEG 2, the video compression standard adopted for use with DVDVideo, codes frames using these 3 picture types. I: Intra coded picture (I-picture)

This is the standard picture and is a complete picture in itself. This means it has the best picture quality and is the best to use when adjusting the picture.

P: Predictive coded picture (P-picture)

This picture is calculated based on past I or P-pictures.

B: Bidirectionally-predictive coded picture (B-picture)

This picture is calculated by comparing past and future I and Ppictures so it has the lowest volume of information.

Linear PCM (pulse code modulation)

These are uncompressed digital signals, similar to those found on CDs.

MP3

A method of compressing audio, MPEG Audio Layer 3 (MP3) allows audio to be reduced to up to one tenth its original size without overtly hurting audio quality.

When creating MP3 files to play on this unit

≥Disc formats: ISO9660 level 1 and level 2 (except for extended for-

mats)

≥Files: MP3 files with the suffix “.mp3” or “.MP3”

≥This unit is compatible with multi-session but if there are a lot of

sessions it takes more time for play to start. Keep the number of sessions to a minimum to avoid this.

≥This unit is not compatible with ID3 tags. ≥This unit is not compatible with files with a sampling rate of 32 kHz.

Playback control (PBC)

If a Video CD has playback control, you can select scenes and information with menus.

Reference

Language code list

Abkhazian: 6566 Afar: 6565 Afrikaans: 6570 Albanian: 8381 Ameharic: 6577 Arabic: 6582 Armenian: 7289 Assamese: 6583 Aymara: 6588 Azerbaijani: 6590 Bashkir: 6665 Basque: 6985 Bengali; Bangla: 6678 Bhutani: 6890 Bihari: 6672 Breton: 6682 Bulgarian: 6671 Burmese: 7789 Byelorussian: 6669 Cambodian: 7577 Catalan: 6765

Chinese: 9072 Corsican: 6779 Croatian: 7282 Czech: 6783 Danish: 6865 Dutch: 7876 English: 6978 Esperanto: 6979 Estonian: 6984 Faroese: 7079 Fiji: 7074 Finnish: 7073 French: 7082 Frisian: 7089 Galician: 7176 Georgian: 7565 German: 6869 Greek: 6976 Greenlandic: 7576 Guarani: 7178 Gujarati: 7185

RQT6191

Hausa: 7265 Hebrew: 7387 Hindi: 7273 Hungarian: 7285 Icelandic: 7383 Indonesian: 7378 Interlingua: 7365 Irish: 7165 Italian: 7384 Japanese: 7465 Javanese: 7487 Kannada: 7578 Kashmiri: 7583 Kazakh: 7575 Kirghiz: 7589 Korean: 7579 Kurdish: 7585 Laotian: 7679 Latin: 7665 Latvian, Lettish: 7686 Lingala: 7678

Lithuanian: 7684 Macedonian: 7775 Malagasy: 7771 Malay: 7783 Malayalam: 7776 Maltese: 7784 Maori: 7773 Marathi: 7782 Moldavian: 7779 Mongolian: 7778 Nauru: 7865 Nepali: 7869 Norwegian: 7879 Oriya: 7982 Pashto, Pushto: 8083 Persian: 7065 Polish: 8076 Portuguese: 8084 Punjabi: 8065 Quechua: 8185 Rhaeto-Romance: 8277

Romanian: 8279 Russian: 8285 Samoan: 8377 Sanskrit: 8365 Scots Gaelic: 7168 Serbian: 8382 Serbo-Croatian: 8372 Shona: 8378 Sindhi: 8368 Singhalese: 8373 Slovak: 8375 Slovenian: 8376 Somali: 8379 Spanish: 6983 Sundanese: 8385 Swahili: 8387 Swedish: 8386 Tagalog: 8476 Tajik: 8471 Tamil: 8465 Tatar: 8484

Telugu: 8469 Thai: 8472 Tibetan: 6679 Tigrinya: 8473 Tonga: 8479 Turkish: 8482 Turkmen: 8475 Twi: 8487 Ukrainian: 8575 Urdu: 8582 Uzbek: 8590 Vietnamese: 8673 Volapük: 8679 Welsh: 6789 Wolof: 8779 Xhosa: 8872 Yiddish: 7473 Yoruba: 8979 Zulu: 9085

Page 33

Specifications

AMPLIFIER SECTION

FTC TTL POWER OUTPUT 250 W

120 Hz–20 kHz, 1.0 % total harmonic distortion

FRONT 28 W per ch (6 ≠) CENTER 28 W (6 ≠) SURROUND 28 W per ch (6 ≠)

45 Hz–120 Hz, 1.0 % total harmonic distortion

SUBWOOFER 110 W (6 ≠)

RMS TTL POWER OUTPUT 350 W

1 kHz, 10 % total harmonic distortion

FRONT 38 W per ch (6 ≠) CENTER 38 W (6 ≠) SURROUND 38 W per ch (6 ≠)

100 Hz, 10 % total harmonic distortion

SUBWOOFER 160 W (6 ≠)

Input sensitivity/input impedance

AUX 250 mV,10 k≠

FM TUNER SECTION

Frequency range 87.9–107.9 MHz (200 kHz steps)

87.5– 108.0 MHz (100 kHz steps)

Sensitivity 16.0 dBf (1.7 ¨V, IHF) Antenna terminals 75 ≠ unbalanced

AM TUNER SECTION

Frequency range 520–1710 kHz (10 kHz steps) Sensitivity

S/N 20 dB at 1000 kHz 600 ¨V/m

DISC SECTION

Disc

DVD 8 cm (3z)/12 cm (5z) single-sided, single-layer

8 cm (3z)/12 cm (5z) single-sided, double-layer

8 cm (3z)/12 cm (5z) double-sided, double-layer

(One layer per side)

CD/VCD 8 cm (3z)/12 cm (5z) (CD-R/RW)

Video

Signal system NTSC Output level Composite video 1 Vp-p (75 ≠)

S-video Y 1 Vp-p (75 ≠) S-video C 0.286 Vp-p (75 ≠)(NTSC)

Audio

Sampling frequency

CD 44.1 kHz

DVD 48 kHz/96 kHz Decoding 16/20/24 bit linear Wow and flutter Below measurable limit D/A converter Delta-sigma DAC

Pick up

Beam Source Semiconductor Laser Wavelength

CD/VCD 790 nm DVD 658 nm

SPEAKER SECTION

[Front\and\surround\speakers\SB-AFC95]

Type 1 way 1 speaker system Bass-ref. Full range 8 cm (31⁄8z) cone type Impedance 6 ≠ Input power

MUSIC 60 W

Output sound pressure level 79 dB/W (1 m) Frequency range 80 Hz–22 kHz (j16 dB)

Dimensions (W

Mass Approx. 0.8 kg (1.8 Ib.)

[Center\speaker\SB-PC89]

Type 1 way 1 speaker system Bass-ref. Full range 8 cm (31⁄8z) cone type Impedance 6 ≠ Input power

MUSIC 60 W

Output sound pressure level 79 dB/W (1 m) Frequency range 80 Hz–22 kHz (j16 dB)

Dimensions (W

Mass Approx. 0.8 kg (1.8 Ib.)

[Subwoofer\SB-W95]

Type 1 way 1 speaker system Bass-ref. Woofer 17 cm (63⁄4z) cone type Impedance 6 ≠ Input power

MUSIC 200 W

Output sound pressure level 80 dB/W (1 m) Frequency range 42 Hz–1.5 kHz (j16 dB)

Dimensions (W

Mass Approx. 4 kg (8.8 Ib.)

kD) 88k135k112 mm

kD) 135k88k112 mm

kD) 173k315k300 mm

110 Hz–20 kHz (j10 dB)

(315⁄32zk511⁄32zk47⁄16z)

110 Hz–20 kHz (j10 dB)

(511⁄32zk315⁄32zk47⁄16z)

46 Hz–900 Hz (j10 dB)

(613⁄16zk1213⁄32zk1113⁄16z)

GENERAL

Power supply AC 120 V, 60 Hz Power consumption 190 W Dimensions (W

Mass Approx. 8.4 kg (18.5 Ib.)

Power consumption in standby mode 0.25 W

kD) 430k114k368 mm

(1615⁄16zk41⁄2zk141⁄2z)

Reference

Note

1. Specifications are subject to change without notice. Mass and dimensions are approximate.

2. Total harmonic distortion is measured by the digital spectrum analyzer.

RQT6191

Page 34

Servicenter List

For Product Information, Operating Assistance, Literature Request, Dealer Locations, and all Customer Service inquiries please contact: 1-800-211-PANA (7262), Monday–Friday 9 am–9 pm; Saturday–Sunday 9 am–7 pm, EST.

Web Site: http://www.panasonic.com You can purchase parts, accessories or locate your nearest servicenter by visiting our Web Site.

Accessory Purchases:

1-800-332-5368 (Customer Orders Only) Panasonic Services Company 20421 84th Avenue South, Kent, WA 98032 (6 am to 5 pm Monday–Friday; 6 am to 10:30 am Saturday; PST) (Visa, MasterCard, Discover Card, American Express, Check)

Factory Servicenters Locations

CALIFORNIA

6550 Katella Avenue Cypress, CA 90630

800 Dubuque Avenue S. San Francisco CA 94080

3878 Ruffin Road Suite A San Diego, CA 92123

FLORIDA

3700 North 29th Avenue Suite 102 Hollywood, FL 33020

Reference

GEORGIA

8655 Roswell Road Suite 100 Atlanta, GA 30350

ILLINOIS

1709 North Randall Road Elgin, IL 60123

MASSACHUSETTS

60 Glacier Drive Suite G Westwood, MA 02090

MINNESOTA

7850-12th Avenue South Airport Business Center Bloomington, MN 55425

OHIO

2236 Waycross Road Civic Center Plaza Forest Park, OH 45240

PENNSYLVANIA

2221 Cabot Blvd. West Suite B Langhorne, PA 19047

TEXAS

13615 Welch Road Suite 101 Farmers Branch TX 75244

WASHINGTON

20425-84th Avenue South Kent, WA 98032

HAWAII

99-859 Iwaiwa Street Aiea, Hawaii 96701 Phone (808) 488-1996 Fax (808) 486-4369

Matsushita Electric of Puerto Rico, Inc. Panasonic Sales Company/Factory Servicenter:

Ave. 65 de Infanteria, Km. 9.5, San Gabriel Industrial Park, Carolina, Puerto Rico 00985

Phone (787) 750-4300 Fax (787) 768-2910

RQT6191

Service in Puerto Rico

F08130 As of AUG ’01

Page 35

Limited Warranty

Panasonic Consumer Electronics Company, Division of Matsushita Electric Corporation of America

One Panasonic Way Secaucus, New Jersey 07094

Panasonic/Technics Audio Products

Limited Warranty

Panasonic Consumer Electronics Company or Panasonic Sales Company (collectively referred to as “the Warrantor”) will repair or replace this product with new or refurbished parts or equivalent product, free of charge in the U.S.A. or Puerto Rico, in the event of a defect in materials or workmanship as follows (all time periods commence from the date of original purchase): AUDIO PRODUCTS—labor and parts for one (1) year. ALL AUDIO RACKS (cabinets)—parts only 30 days. TECHNICS STAND ALONE SPEAKERS, SUBWOOFER SPEAKERS— labor and parts for three (3) years. USB READER-WRITER, PERSONAL COMPUTER CARD ADAPTERS— (when applicable)— exchange defective unit with a new or refurbished one for one (1) year. ACCESSORIES— HEADPHONES, CARTRIDGES, MICROPHONES, ADAPTERS—labor and parts for ninety (90) days.

RECHARGEABLE BATTERIES—(when applicable)—exchange defective item for new one for ten (10) days. Non-rechargeable batteries are not warranted.

SD MEMORY CARDS, RECHARGEABLE BATTERY PACKS— (when applicable)— exchange defective item for new one for ninety (90) days. Non-rechargeable battery packs are not warranted.

Carry-in or mail-in service in the U.S.A. can be obtained during the warranty period by contacting a Panasonic Services Company (PASC) Factory Servicenter listed in the Servicenter Directory. Or call toll free, 1-800-211-7262 to locate a PASC authorized Servicenter. Carry-in or mail-in service in Puerto Rico can be obtained during the warranty period by calling the Panasonic Sales Company telephone number listed in the Servicenter Directory.

This warranty is extended only to the original purchaser. A purchase receipt or other proof of date of original purchase will be required before warranty service is rendered.

Panasonic Sales Company, Division of Matsushita Electric of Puerto Rico, Inc.

Ave. 65 de Infantería, Km. 9.5 San Gabriel Industrial Park, Carolina, Puerto Rico 00985

This warranty only covers failures due to defects in materials and workmanship which occur during normal use and does not cover normal wear to the stylus (when applicable) or a dealer installed cartridge or stylus. The warranty does not cover damages which occur in shipment or failures which are caused by products not supplied by the warrantor, or failures which result from accident, misuse, abuse, neglect, mishandling, faulty installation, misapplication, set-up adjustments, maladjustment of consumer controls, improper operation or maintenance, improper antenna, inadequate signal reception or pick-up, alteration, modification, power line surge, improper voltage supply, lightning damage, commercial use, such as; hotel, office, restaurant, or other business or rental use of the product, or service by anyone other than a PASC Factory Servicenter or a PASC authorized Servicenter, or damage that is attributable to acts of God.

LIMITS AND EXCLUSIONS

There are no express warranties except as listed above.

THE WARRANTOR SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, INCLUDING WITHOUT LIMITATION, DAMAGE TO TAPES, RECORDS OR DISCS. ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY, AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO THE APPLICABLE WARRANTY PERIOD SET FORTH ABOVE. Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the above exclusions or limitations may not apply to you.

This warranty gives you specific legal rights and you may also have other rights which vary from state to state.

If a problem with this product develops during or after the warranty period, you may contact your dealer or Servicenter. If the problem is not handled to your satisfaction, then write to the Consumer Affairs Department at the company address indicated above.

If you ship the product Carefully pack and send it prepaid, adequately insured and preferably in the original carton. Attach a postage-affixed letter, detailing the complaint, to the outside of the carton.

Do NOT send the product to the Executive or Regional Sales offices. They are NOT equipped to make repairs

Product Service

1. Damage requiring service —The unit should be serviced by qualified service personnel if:

(a) The AC power supply cord or AC adaptor has been damaged; or (b) Objects or liquids have gotten into the unit; or (c) The unit has been exposed to rain; or (d) The unit does not operate normally or exhibits a marked change in performance; or (e) The unit has been dropped or the cabinet damaged.

2. Servicing —Do not attempt to service the unit beyond that described in these operating instructions. Refer all other servicing to authorized servicing personnel.

3. Replacement parts —When parts need replacing ensure the servicer uses parts specified by the manufacturer or parts that have the same characteristics as the original parts. Unauthorized substitutes may result in fire, electric shock, or other hazards.

4. Safety check —After repairs or service, ask the servicer to perform safety checks to confirm that the unit is in proper working condition.

The servicer will require all components to service your system. Therefore, should service ever be necessary, be sure to bring the entire system.

Product information

For product information or assistance with product operation:

Reference

Contact the Panasonic Customer Call Center at 1-800-211-7262, or e-mail [email protected], or web site (http:// www.panasonic.com).

RQT6191

Page 36

Listening caution

EST. 1924

Selecting fine audio equipment such as the unit you’ve just purchased is only the start of your musical enjoyment. Now it’s time to consider how you can maximize the fun and excitement your equipment offers. This manufacturer and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or distortion—and, most importantly, without affecting your sensitive hearing.

We recommend you to avoid prolonged exposure to excessive noise.

Sound can be deceiving. Over time your hearing “comfort level” adapts to higher volumes of sound. So what sounds “normal” can actually be loud and harmful to your hearing. Guard against this by setting your equipment at a safe level BEFORE your hearing adapts. To establish a safe level:

≥Start your volume control at a low setting. ≥Slowly increase the sound until you can hear it comfortably and clearly, and without distortion.

Once you have established a comfortable sound level: ≥Set the dial and leave it there.

Taking a minute to do this now will help to prevent hearing damage or loss in the future. After all, we want you listening for a lifetime.

User memo:

DATE OF PURCHASE DEALER NAME DEALER ADDRESS

TELEPHONE NUMBER

The model number and serial number of this product can be found on either the back or the bottom of the unit. Please note them in the space provided below and keep for future reference.

Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories.

Apparatus Claims of U.S. Patent Nos. 4,631,603, 4,577,216, and 4,819,098, licensed for limited viewing uses only.

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Panasonic Consumer Electronics Company, Division of Matsushita Electric Corporation of America

One Panasonic Way Secaucus, New Jersey 07094

http://www.panasonic.com

Panasonic Sales Company, Division of Matsushita Electric of Puerto Rico, Inc. (“PSC”)

Ave. 65 de Infantería, Km. 9.5 San Gabriel Industrial Park, Carolina, Puerto Rico 00985

MODEL NUMBER!

SERIAL NUMBER

C 2001 Matsushita Electric Industrial Co., Ltd.

Printed in Singapore

RQT6191-P

F1201NK0
