Panasonic PT-RZ370U, PT-RZ370E, PT-RW330U, PT-RW330E Product Sheet

1-Chip DLP™ Projectors

PT-RZ370
PT-RW330

Beyond Ordinary Projection—
Solid Reliability with the
LED/Laser-Combined Light Source

Start projecting as soon as you turn on the power

Many projector issues have
been addressed with the new
LED / L a s e r-co m b i n e d lig h t
source. From the moment you
turn on the projector, you’ll
notice the difference with the
quick on and immediate full
brightness . No more lamp s
and air filters, which lets you enjoy maintenance-free use for about
20,000 hours*

1

while maintaining excellent brightness and picture
quality. To enhance permanent installation use, we’ve added DIGITAL
LINK support so you can transmit video, audio and control signals

up to 100 meters (328 feet)
over a single LAN cable.*

2

System capabilities have also
been improved with 2× zoom
and an exc ept ional ly wide
lens shift range, thus provid-
ing superb flexibility for easy
first tim e a nd replacement

installations. And the Total Cost of Ownership (

TCO) has been

reduced because you no longer have to keep replacement lamps on
hand. The next-generation PT-RZ370/RW330 projectors have swept
away the weak points of conventional projectors.

SOLID SHINE series uses the newly developed LED/Laser-combined light source

SOLID SHINE series projectors provide solid
reliability and long-lasting brightness unprece-
dented by conventional lamp-based projectors.

Approximately 20,000 hours*

1

of maintenance-free operation

No need to replace the light source or air filter, providing a
dramatic reduction in the Total Cost of Ownership (

TCO).

Long-lasting picture quality

Excellent picture quality and brightness are maintained for a
long time.

Superb color reproduction

Beautiful, vivid colors exceeding the levels of conventional pro-
jectors.

Quick start, quick off

The image appears almost instantly upon powering up, and
there is no need for cooling after turning the power off. The
power can be turned on immediately after being turned off, and
it can be turned on/off as many times as you want.

Full HD

PT-RZ370

3,500 lm

WXGA

PT-RW330

3,500 lm

PT-RZ370/RW330 Optical Structure Image

Phosph or wheel
(changes from
blue to green)

LED (blue)

LED (red)

Light sensor for
SOLID SHINE drive

Laser (blue)

DLP™ chip

Projection lens

Conden ser
lens

1
