Page 1
9/12/2019 NI-E660SR_SpecSheet
MORE DETAILS
Design
Color (Iron / Water Tank) White w/ Violet
Soleplate Style U-Shape
Steam Circulating Soleplate Yes Yes
Soleplate Finish Stainless Steel with Non-Stick Coating
Water Tank Built-In
Iron Handle Molded Plastic
Wide Water Refill Yes
Cord Design Retractable Cord Reel (On Base)
Temperature Control Fixed Dial w/ Rotating Indicator
Temperature Ready Indicator Light On / Off
Heat Resistant Carrying Case N/A
PERFORMANCE
Easy Glide - Curved Soleplate Yes
Time Saving - Multi-Directional Soleplate N/A
Selectable Fabric / Temperature Dial 5 Fabric Settings
Choose Steam or Dry Operation Dry / Steam Position Selector
Adjustable Steam Amount High / Low / Dry
Extra Jet-of-Steam Yes
Water Mist Spray
Water Tank Capacity (oz.) 7.1
CONVENIENCE
Vertical Steam Yes
Automatic Water Seal N/A
Steam Circulating Iron with Curved Non-Stick Stainless-Steel Soleplate NI-E660SR NI-
E660SR
1/2
Page 2
9/12/2019 NI-E660SR_SpecSheet
Stay Clean Steam Vents Anti-Calcium System
Quick Reference Fabric / Temp. Chart On Dial Setting
Easy Storage / Carrying Case w/ Handle N/A
SAFETY
Auto Shut-Off In Flat Position (after 1 min) In Side Position, (after 1 min) in Heel Rest Position (after 10 m
POWER
Power Supply 120 Volts; 60 Hz
Rated Power 10 Amps,1200 Watts
Iron - Temperature Range 176 F - 392 F
DIMENSIONS
Unit (H x W x D) (in.) 5-5/6 x 4-7/16 x 10-1/16
Carton (H x W x D) (in.) 6-1/4 x 4-7/8 x 11-7/8
WEIGHT
Unit (lbs.) 3.3
Carton (lbs.) 3.5
ADDITIONAL
UPC Code 8-85170 21794-2
Limited Warranty 1 Year
UPC885170217942
2/2
