Operating Instructions

Vacuum Cleaner MC-E464, MC-E468, MC-E469

Shop Panasonic

For Accessories and Consumables visit our web site at

www.panasonic.co.uk

(for customers in the UK only)

Panasonic

We would recommend that you read these Operating Instructions before attempting to operate the unit and that you note the Important Safety Instructions. Please keep in a safe place with your Authorised Dealer Service booklet. This product complies with the directives 73/23/EEC and 89/336/EEC.

TABLE OF CONTENTS

ASA

Page Page

• Caution for AC Mains Lead (UK, IRL only) . . . . . .2 H) Floor scratch prevention . . . . . . . . . . . . . . . . . .7

• Important Safety Instructions for the user . . . . . .3 I) How to use the accessories . . . . . . . . . . . . . . . .8

• Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 J) Dust bag change indicator . . . . . . . . . . . . . . . . .8

• Identification of main parts . . . . . . . . . . . . . . . . . .4 MAINTENANCE AND SERVICING

HOW TO ASSEMBLE / OPERATE YOUR CLEANER • How to change the dust bag . . . . . . . . . . . . . . . .9

A) Handle assembly . . . . . . . . . . . . . . . . . . . . . . . .5 • Filter care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

B) Power cord release / storage . . . . . . . . . . . . . . .5 • Blockages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

C) ON/OFF Switch . . . . . . . . . . . . . . . . . . . . . . . . .5 • Maintenance for the rotary brush . . . . . . . . . . .10

D) Variable power control . . . . . . . . . . . . . . . . . . . .6 • Servicing and repairs . . . . . . . . . . . . . . . . . . . . .11

E) Handle adjustment by foot pedal . . . . . . . . . . . .6 • Trouble shooting guide . . . . . . . . . . . . . . . . . . .12

F) Beater bar switch (except MC-E464) . . . . . . . . .7 • Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . .12

G) Automatic height adjustment . . . . . . . . . . . . . . .7 • Consumables / Accessories . . . . . . . . . . . . . . .13

CAUTION FOR AC MAINS LEAD ( UK, IRL only )

FOR YOUR SAFETY PLEASE READ THE FOLLOWING TEXT CAREFULLY

This appliance is supplied with a moulded three pin mains plug for your safety and convenience. A 13 amp fuse is fitted in this plug. Should the fuse need to be replaced please ensure that the replacement fuse has a rating of 13 amps and that it is approved by ASTA or BSI to BS1362. Check for the ASTA mark or the BSI mark on the body of the fuse. If the plug contains a removable fuse cover you must ensure that it is refitted when the fuse is replaced. If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY. THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IF THE CUT OFF PLUG IS INSERTED INTO ANY 13 AMP SOCKET. If a new plug is to be fitted please observe the wiring code as shown below. If in any doubt please consult a qualified electrician.

IMPORTANT: The wires in this mains lead are coloured in accordance with the following code:

Blue : Neutral

Brown : Live As the colours of the wire in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured BLUE must be connected to the terminal in the plug which is marked with the letter N or coloured BLACK. The wire which is coloured BROWN must be connected to the terminal in the plug which is marked with the letter L or coloured RED. Under no circumstances should either of these wires be connected to the earth terminal of the three pin plug, marked with the letter E or the Earth Symbol

How to replace the Fuse:

• There are two types of the supplied AC Mains Lead : A and B as shown below. 1 Open the fuse compartment with a screwdriver. 2 Replace the fuse and fuse cover if detachable.

TYPE A

TYPE B

Fuse cover Part No.: AMC8D48C0000.

IMPORTANT SAFETY INSTRUCTIONS FOR THE USER

W A L

T O

W A

L L C

L E A

N I N

CLEAN FILTER

W A L

T O

W A

L L C

L E A

N I N

C LE

AN FIL

TER

CLEAN FILTER

When using this vacuum cleaner, please observe these basic precautions. WARNING: To reduce the risk of fire, electric shock, or injury:

• Do not leave the vacuum cleaner plugged in to mains socket. Unplug from the socket when not in use and

before cleaning the appliance or undertaken maintenance operations.

• Electric shocks can occur if used outdoors or on wet surfaces.

• This appliance is not intended for use by young children or infirm persons without supervision; young

children should be supervised to ensure that they do not play with the appliance.

• Do not use with damaged cord or plug. If the vacuum cleaner is not working as it should be, or has been

dropped, damaged, left outdoors, or come into contact with water, consult an authorised Panasonic Service Centre.

• Do not pull or carry by power cord, use power cord as a handle, close a door on power cord, pull power

cord around sharp edges or corners. Do not run vacuum cleaner over the power cord. Keep power cord away from heated surfaces.

• Do not handle plug or vacuum cleaner with wet hands.

• Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair and

anything that may block or reduce air flow.

• Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.

• Do not use the vacuum cleaner without filters and / or dust bag in place. Never try to patch a broken dust bag.

• Turn off all controls before unplugging.

• Use extra care when cleaning on stairs.

• Do not use to pick up flammable or combustible liquids such as gasoline or use in areas where they may be present.

• This appliance should be serviced by an authorised Panasonic Service Centre, and only genuine Panasonic

spare parts should be used.

• Keep feet, fingers and hands away from the beater bar. (It may cause injury).

NOTE: These vacuum cleaners are designed for general household use only and are not suitable for use in a garage, garden or to suck up liquids.

CAUTIONS

1) To avoid any possible damage to the mains cable, never run over the power cord or allow it to become caught in the beater bar when using the vacuum cleaner.

4) To avoid damaging the machine or the dust bag, never let the vacuum cleaner pick up wet matter, mud, burning ashes or large and sharp objects.

2) Do not run the vacuum cleaner over tassels or fringes of rugs or mats as they could get caught up in the beater bar and may cause damage to the brush and belt.

5) Do not pull on the power cord when disconnecting the appliance from the mains, always pull on the plug body itself.

3) Keep the vacuum cleaner away from heat sources such as radiators, fires, direct sunlight, etc.

6) To avoid injury, keep your fingers and hands away from the beater bar, and never put them between the cleaner bodies.

IDENTIFICATION OF MAIN PARTS

A-1) Handle

J) Dust bag check indicator

D) Variable power control

(MC-E469 only)

Carrying handle

Clean air filter

B-2) Cord clip

C) ON/OFF Switch

Dust bag cover

Furniture guard

Cleaning head

Paper dust bag

F) Beater bar switch

(except MC-E464)

Extension wand

E) Foot pedal

A-3) Upper cord hook

B-1) Power cord

A-2) Hose clip

A-3) Lower

cord hook/ Carrying handle

Crevice nozzle

Dusting brush

Hose

HOW TO ASSEMBLE / OPERATE YOUR CLEANER

A) HANDLE ASSEMBLY

Hose clip

Upper cord hook

Lower cord hook/ Carrying handle

1) Insert the base of the handle into the top of the body of the machine as shown. Push in handle and tighten the screw.

IMPORTANT: Do not overtighten the screw.

2) Set the hose around the hose clip.

NOTE: Always place the hose in the clockwise direction.

B) POWER CORD RELEASE / STORAGE

3) Turn the upper cord hook in the upright position and wind the power cord around the upper and lower cord hooks.

C) ON / OFF SWITCH

1) Turn the upper hook to release the power cord for instant use.

NOTE: To avoid any possible damage to the power cord, never run over the cord or allow it to become caught in the beater bar.

2) Fix the power cord by the cord clip to help secure the cord during use.

To start or stop the vacuum cleaner push the switch button to " I " to turn ON and to " O " to turn OFF.
