Panasonic KX-TG6051AL, KX-TG6053AL, KX-TG6052AL User Manual

Download

Page 1

Operating Instructions

5.8 GHz Digital Cordless Answering System

Model No. KX-TG6051AL

with 2 Handsets

Model No.

KX-TG6052AL

with 3 Handsets

KX-TG6053AL

Model shown is KX-TG6051AL.

This unit is compatible with Caller ID. To use this feature, you must subscribe to the appropriate service offered by your service provider/ telephone company.

Charge the handset battery for 7 hours before initial use.

Please read these Operating Instructions before using the unit and save for future reference.

Page 2

Table of Contents

Introduction

Product information . . . . . . . . . . . . . . 3

Accessory information . . . . . . . . . . . . 5

Important safety instructions . . . . . . . 6

For best performance . . . . . . . . . . . . 8

Preparation

Setting up the base unit. . . . . . . . . . 10

Setting up the handset . . . . . . . . . . 10

Controls. . . . . . . . . . . . . . . . . . . . . . 13

Display. . . . . . . . . . . . . . . . . . . . . . . 14

Setting the unit before use . . . . . . . 14

Making/Answering Calls

Making calls. . . . . . . . . . . . . . . . . . . 15

Answering calls . . . . . . . . . . . . . . . . 16

Useful features during a call . . . . . . 16

Phonebook

Handset phonebook . . . . . . . . . . . . 19

Copying handset phonebook items . 20

Caller ID Service

Using Caller ID service . . . . . . . . . . 21

Caller list . . . . . . . . . . . . . . . . . . . . . 23

Programming

Programmable settings . . . . . . . . . . 25

Answering System

Answering system . . . . . . . . . . . . . . 30

Turning the answering system on/off 30

Greeting message . . . . . . . . . . . . . . 31

Listening to messages using the base

unit . . . . . . . . . . . . . . . . . . . . . . . . . 31

Listening to messages using the

handset . . . . . . . . . . . . . . . . . . . . . . 32

Remote operation . . . . . . . . . . . . . . 33

Answering system settings . . . . . . . 34

Voice Mail Service

Using Voice Mail service . . . . . . . . . 36

Multi-unit Operation

Intercom . . . . . . . . . . . . . . . . . . . . . 38

Handset locator . . . . . . . . . . . . . . . . 38

Transferring calls between handsets,

conference calls . . . . . . . . . . . . . . . 39

Useful Information

Wall mounting . . . . . . . . . . . . . . . . . 40

Headset (optional). . . . . . . . . . . . . . 41

Lanyard/strap eyelet . . . . . . . . . . . . 41

Error messages. . . . . . . . . . . . . . . . 42

Troubleshooting . . . . . . . . . . . . . . . 43

Instructions to customer . . . . . . . . . 48

Specifications . . . . . . . . . . . . . . . . . 50

Index

Index . . . . . . . . . . . . . . . . . . . . . . . . 51

Page 3

Introduction

Product information

Thank you for purchasing a Panasonic cordless telephone.

These operating instructions can be used for the following models:

KX-TG6051 KX-TG6052

KX-TG6053

Important:

LThe suffix (AL) in the following model numbers will be omitted in these instructions:

KX-TG6051AL/KX-TG6052AL/KX-TG6053AL

LReferences in these operating instructions to the charger and multiple handsets

are for KX-TG6052/KX-TG6053 users only.

Page 4

Introduction

Notable feature differences among the following models

Model no.

KX-TG6051 rrrr–

KX-TG6052 rrrrr

KX-TG6053 rrrrr

*1 Intercom calls can be made between the handset and base unit. *2 Intercom calls can be made between the handsets.

Answering system

Talking Caller ID

Slow talk

Intercom

\ ⇔ N*1N ⇔ N

Special features

NHandset voice enhancer

This feature clarifies the voice of the person you are talking to, reproducing a more natural-sounding voice that is easier to hear and understand (page 17).

NTalking Caller ID

This feature allows the handset to announce the displayed caller name or phone number when a call is received (page 21).

NSlow Talk

You can slow down the voice of the person you are talking to, making it easier to hear and understand (page 17).

Page 5

Accessory information

Included accessories

Introduction

No. Accessory item

1 AC adaptor for base unit 1 1 1

2 Telephone line cord 1 1 1

3 Wall mounting adaptor 1 1 1

4 Battery 1 2 3

5 Handset cover

6 Charger – 1 2

7 AC adaptor for charger – 1 2

*1 The handset cover comes attached to the handset.

123 4 5

Quantity

KX-TG6051 KX-TG6052 KX-TG6053

123

Additional/replacement accessories

Accessory item Order number

Rechargeable nickel metal hydride (Ni-MH) battery

Headset KX-TCA86AL or KX-TCA92AL

HHR-P107

Page 6

Introduction

Important safety instructions

When using the product, basic safety precautions should always be followed to reduce the risk of fire, electric shock, or personal injury.

1. Read all instructions carefully.

2. Follow all warnings and instructions marked on the product.

3. Unplug the product from power outlets before cleaning. Do not use liquid or aerosol cleaners. Use a cloth for cleaning.

4. Do not use the product near water, for example near a bathtub, wash bowl, kitchen sink, etc.

5. Place the product securely on a stable surface. Serious damage and/or injury may result if the product falls.

6. Do not cover slots and openings on the product. They are provided for ventilation and protection against overheating. Never place the product near radiators, or in a place where proper ventilation is not provided.

7. Use only the power source marked on the product. If you are not sure of the type of power supplied to your home, consult your dealer or local power company.

8. Do not place objects on the power cord. Install the product where no one can step or trip on the cord.

9. Do not overload power outlets and extension cords. This can result in the risk of fire or electric shock.

10. Never push any objects through slots in the product. This may result in the risk of fire or electric shock. Never spill any liquid on the product.

11. To reduce the risk of electric shock, do not disassemble the product. Take the product to an authorised service centre when service is required. Opening or removing covers may expose you to dangerous voltages or other risks. Incorrect reassembly can cause electric shock when the product is subsequently used.

12. Unplug the product from power outlets and take to an authorised service centre when the following conditions occur: A. When the power cord is

damaged or frayed.

B. If liquid has been spilled into the

product.

C. If the product has been exposed

to rain or water.

D. If the product does not work

normally by following the operating instructions. Adjust only controls covered by the operating instructions. Improper adjustment may require extensive work by an authorised service centre.

E. If the product has been dropped

or physically damaged.

F. If the product exhibits a distinct

change in performance.

13. During thunderstorms, avoid using telephones including cordless phones. There is a risk of an electric shock from lightning.

14. Do not use the product to report a gas leak, when in the vicinity of the leak.

SAVE THESE INSTRUCTIONS

Page 7

Introduction

WARNING:

LTo prevent the risk of fire or electrical

shock, do not expose the product to rain or any type of moisture.

LUnplug the product from power

outlets if it emits smoke, an abnormal smell, or makes an unusual noise. These conditions can cause fire or electric shock. Confirm that smoke has stopped emitting and contact an authorised service centre.

LDo not spill liquids (detergents,

cleansers, etc.) onto the telephone line cord plug, or allow it to become wet at all. This may cause a fire. If the telephone line cord plug becomes wet, immediately pull it from the telephone wall jack, and do not use.

LDo not place or use this product near

automatically controlled devices such as automatic doors and fire alarms. Radio waves emitted from this product may cause such devices to malfunction resulting in an accident.

LCompletely insert the AC adaptor/

power plug into the power outlet. Failure to do so may cause electric shock and/or excessive heat resulting in a fire.

LRegularly remove any dust, etc. from

the AC adaptor/power plug by pulling it from the power outlet, then wiping with a dry cloth. Accumulated dust may cause an insulation defect from moisture, etc. resulting in a fire.

CAUTION:

Installation

LNever install telephone wiring during

a lightning storm.

LNever install telephone line sockets in

wet locations unless the socket is specifically designed for wet locations.

LNever touch uninsulated telephone

wires or terminals unless the telephone line has been disconnected at the network interface.

LUse caution when installing or

modifying telephone lines.

LDo not touch the plug with wet hands. LThe AC adaptor is used as the main

disconnect device. Ensure that the AC outlet is installed near the product and is easily accessible.

Battery

To reduce the risk of fire or injury to persons, read and follow these instructions.

LUse only the battery(ies) specified. LDo not dispose of the battery(ies) in a

fire. They may explode. Check with local waste management codes for special disposal instructions.

LDo not open or mutilate the

battery(ies). Released electrolyte is corrosive and may cause burns or injury to the eyes or skin. The electrolyte may be toxic if swallowed.

LExercise care when handling the

battery(ies). Do not allow conductive materials such as rings, bracelets or keys to touch the battery(ies), otherwise a short circuit may cause the battery(ies) and/or the conductive material to overheat and cause burns.

LCharge the battery(ies) provided, or

identified for use with the product only, in accordance with the instructions and limitations specified in this manual.

Medical

LConsult the manufacturer of any

personal medical devices, such as pacemakers or hearing aids, to determine if they are adequately

Page 8

Introduction

shielded from external RF (radio frequency) energy. (The product operates in the frequency range of

5.76 GHz to 5.84 GHz, and the power output is 200 mW (max.).) Do not use the product in health care facilities if any regulations posted in the area instruct you not to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.

Notice for product disposal, transfer, or return

LThis product can store your private/

confidential information. To protect your privacy/confidentiality, we recommend that you erase the information such as phonebook or caller list entries from the memory before you dispose, transfer or return the product.

Notice

LPlease ensure that a separate

telephone, not dependent on local power, is available for emergency use.

LThis equipment will be inoperable

when mains power fails.

LWhen a failure occurs which results in

the internal parts becoming accessible, disconnect the power supply cord immediately and return the product to an authorised service centre.

LTo minimise the possibility of lightning

damage, when you know that a thunderstorm is coming, we recommend that you: – Unplug the telephone line cord from

the phone socket.

– Unplug the AC adaptor from the AC

power outlet.

LNo “000” or other calls can be made

from this device during a mains power failure.

LThe earpiece on the handset is

magnetised and may retain small metallic objects.

LThis equipment has been tested and

found to comply with AS/NZS CISPR22: 2004 limits for electromagnetic interference. Any modifications to any part of the system or to any peripherals may void the EMC compliance of the system or the peripherals.

For best performance

Base unit location/avoiding noise

The base unit and other compatible Panasonic units use radio waves to communicate with each other.

LFor maximum coverage and noise-

free communications, place your base unit: – at a convenient, high, and central

location with no obstructions between the handset and base unit in an indoor environment.

– away from electronic appliances

such as TVs, radios, personal computers, wireless devices or other phones.

– avoid facing radio frequency

transmitters, such as external antennas of mobile phone cell stations (avoid putting the base unit on a bay window or near a window).

LCoverage and voice quality depends

on the local environmental conditions.

LIf the reception for a base unit location

is not satisfactory, move the base unit to another location for better reception.

Page 9

Environment

LKeep the product away from electrical

noise generating devices, such as fluorescent lamps and motors.

LThe product should be kept free from

excessive smoke, dust, high temperature, and vibration.

LThe product should not be exposed to

direct sunlight.

LDo not place heavy objects on top of

the product.

LWhen you leave the product unused

for a long period of time, unplug the product from the power outlet.

LThe product should be kept away

from heat sources such as heaters, kitchen stoves, etc. It should not be placed in rooms where the temperature is less than 5 °C or greater than 40 °C. Damp basements should also be avoided.

LThe maximum calling distance may

be shortened when the product is used in the following places: Near obstacles such as hills, tunnels, underground, near metal objects such as wire fences, etc.

LOperating the product near electrical

appliances may cause interference. Move away from the electrical appliances.

Introduction

Routine care

LWipe the outer surface of the product

with a soft cloth. Do not use benzine, thinner, or any abrasive powder.

Page 10

Preparation

Setting up the base unit

Connecting the AC adaptor and telephone line cord

Connect the telephone line cord until it clicks into the base unit and telephone line socket (A). Connect the AC adaptor cord (B) by pressing the plug firmly (C). LUse only the included Panasonic AC

adaptor PQLV203AL.

To socket

Hooks

Note:

LThe AC adaptor must remain

connected at all times. (It is normal for the adaptor to feel warm during use.)

LThe AC adaptor should be connected

to a vertically oriented or floormounted AC outlet. Do not connect the AC adaptor to a ceiling-mounted AC outlet, as the weight of the adaptor may cause it to become disconnected.

LThe unit will not work during a power

failure. We recommend connecting a corded telephone to the same telephone line or to the same telephone line socket using a telephone double adaptor.

(230–240 V AC,

50/60 Hz)

LThe unit is not designed to be used

with rotary (pulse dialling) services.

If you subscribe to an ADSL service

Please attach an ADSL filter (contact your ADSL provider) to the telephone line between the base unit and the telephone line socket in the event of the following: – Noise is heard during conversations. – Caller ID features do not function

properly.

To socket

ADSL filter

Setting up the handset

Connecting the AC adaptor

Available model:

KX-TG6052/KX-TG6053

LUse only the included Panasonic AC

adaptor PQLV208AL.

(230–240 V AC, 50/60 Hz)

Bottom of the charger

Fasten the AC adaptor cord to prevent it from being disconnected.

Hooks

Page 11

Preparation

Battery installation/ replacement

Press the notch of the handset cover firmly, and slide it in the direction of the arrow. LIf necessary, remove the old

battery.

2 Insert the battery (A), and press it

down until it snaps into position (B). Then close the handset cover (C,

D).

Important:

LUse only the rechargeable Panasonic

battery noted on page 5.

Battery charge

Place the handset on the base unit or charger for 7 hours before initial use. LWhile charging, “Charging” is

displayed and the charge indicator on the handset lights in amber. When the battery is fully charged, “Charge completed” is displayed and the indicator lights in green.

Base unit:

Charge contacts

LModel shown is KX-TG6051.

Charger:

Available model:

KX-TG6052/KX-TG6053

Charge contacts

Note:

LIf you want to use the handset

immediately, charge the battery for at least 15 minutes.

Page 12

Preparation

LTo ensure that the battery charges

properly, clean the charge contacts of the handset, base unit, and charger with a soft, dry cloth once a month. Clean more often if the unit is subject to the exposure of grease, dust, or high humidity.

LWhen the battery is empty, “Charge

for 7h” is displayed and the charge

indicator does not light for about 5 minutes to concentrate on charging.

Battery level

Battery icon Battery level

5 Fully charged

6 Medium

7 Low

Flashing: needs to be recharged.

8 Empty

Note:

LWhen the battery needs to be

charged, the handset beeps intermittently during use.

Panasonic battery performance

Operation Operating time

While in use (talking)

While not in use (standby)

While using the clarity booster feature (page 17)

Note:

LBattery operating time may be

shortened over time depending on usage conditions and surrounding temperature.

Up to 5 hours

Up to 11 days

Up to 3 hours

LBattery power is consumed whenever

the handset is off the base unit or charger, even when the handset is not in use.

LAfter the handset is fully charged,

displaying “Charge completed”, it may be left on the base unit or charger without any ill effect on the battery.

LThe battery level may not be

displayed correctly after you replace the battery. In this case, place the handset on the base unit or charger and let it charge for 7 hours.

Symbols used in these operating instructions

Symbol Meaning

{ } Button name/ soft key name

i Proceed to the next

“ ” Example: “Alarm”

Example:

{V}/{^}: “Off”

The words in the brackets indicate button names/soft key names on the handset and base unit.

Example:

Unit keys: {C}, {OFF} Soft keys:

{View CID}, {Phonebook}

operation.

The words in quotations indicate the menu on the display.

Press {V} or {^} to select “Off”.

Page 13

Preparation

Controls

Base unit

A B C D

MNL

A Speaker B {GREETING REC} (Recording) C {GREETING CHECK} D {ANSWER ON}

ANSWER ON indicator

E VOLUME {> } {<} F {>} (SKIP) G {MESSAGE}

MESSAGE indicator

H {ERASE} I {STOP} J {LOCATOR} {INTERCOM} K MIC (Microphone) L IN USE indicator M {<} (REPEAT) N Charge contacts

Handset

F G H

C D

G H

A Speaker B Soft keys C Headset socket D {C} (TALK) E Navigator key ({^} {V} {<} {>}) F {s} (SP-PHONE) G {RECALL} {CALL WAIT} H Microphone I Charge contacts J Lanyard/strap eyelet K Charge indicator

Ringer indicator Message indicator

L Receiver M Display N {MENU} O {OFF} P {PAUSE} {REDIAL} Q {HOLD} {INTERCOM}

M N B

Page 14

Preparation

Using the navigator key

The handset navigator key can be used to navigate through menus and to select items shown on the display by pressing {^}, {V}, {<}, or {>}.

Adjusting audio volume

Press

{^}

{V}

repeatedly while talking.

{^}

{<}{>}

{V}

Using the soft keys

The handset features 2 soft keys. By pressing a soft key, you can select the feature shown directly above it on the display.

10:30AM [1] View Phone

CID book

Display

Handset display items

Displayed item

J Voice enhancer is on.

5 Battery level

Example:

[1]

*1 KX-TG6052/KX-TG6053

Meaning

The handset’s extension number (example shown here: handset 1)

Setting the unit before use

Important:

LTo program features by scrolling

through the display menus, see page

25.

Date and time

Set the correct date and time. – To display the date and time when the

calls were received in the caller list.

– To use the available alarm function

(page 29).

– When you play back a message from

the answering system (page 31), the unit announces the day and time it was recorded.

1 {MENU} i {4}{1} 2 Enter the current day, month, and

year by selecting 2 digits for each. Example: 15 August, 2007

{1}{5} {0}{8} {0}{7}

3 Enter the current hour and minute

(12-hour clock format) by selecting 2 digits for each. Example: 9:30

{0}{9} {3}{0}

4 {AM/PM}: Select “AM” or “PM”. 5 {Save} i {OFF}

Note:

LIf you make a mistake when entering

the date and time, press {<}, {>}, {^}, or {V} to move the cursor, then make the correction.

LThe date and time may be incorrect

after a power failure. In this case, set the date and time again.

Page 15

Making calls

1 Dial the phone number.

LTo correct a digit, press {Clear}.

2 Press {C} or {Call}. 3 When you finish talking, press {OFF}

or place the handset on the base unit or charger.

Note:

L“Line in use” is displayed when

someone is talking on the handset or another phone.

Using the speakerphone

1 Dial the phone number, and press

{s}. LSpeak alternately with the other

party.

2 When you finish talking, press

{OFF}.

Note:

LUse the speakerphone in a quiet

environment.

LTo switch to the receiver, press {C}.

Making/Answering Calls

Erasing a number in the redial list

1 {REDIAL} 2 {V}/{^}: Select the desired phone

number.

3 {Erase} i {Yes} i {OFF}

PAUSE button (for PBX/long distance service users)

A pause is sometimes required when making calls using a PBX or long distance service. When storing a calling card access number and/or PIN in the phonebook, a pause is also needed (page 20). For example, if you need to dial the line access number “9” when making outside calls with a PBX:

1 {9} i {PAUSE} i Dial the

phone number.

2 {C}

Note:

LA 3.5 second pause is inserted each

time {PAU SE} is pressed. Press repeatedly to insert longer pauses.

Adjusting the receiver/speaker volume

Press {^} or {V} repeatedly while talking.

Making a call using the redial list

The last 5 phone numbers dialled are stored in the redial list (each 48 digits max.).

1 {REDIAL} 2 {V}/{^}: Select the desired phone

number.

3 {C}

Page 16

Making/Answering Calls

Answering calls

When a call is being received, the ringer indicator flashes rapidly.

1 Press {C} or {s}.

LYou can also answer the call by

pressing any dial key from {0} to {9}, {*}, or {#}. (Any key talk

feature)

2 When you finish talking, press

{OFF}.

Note:

LYou can change the ringer indicator

colour and the ringer tone (page 27,

28). You can also adjust the handset ringer volume (page 28).

Auto talk

This feature allows you to answer a call by simply lifting the handset off the base unit or charger. You do not need to press {C}. To activate this feature, see page 27.

Temporary ringer off

While the handset is ringing for an outside call, you can turn the ringer off temporarily by pressing {OFF}.

Adjusting the base unit ringer volume

Press {>} or {<} repeatedly to select the desired volume.

LTo turn the ringer off, press and hold

{<} until the unit beeps 2 times.

Useful features during a call

HOLD button

This feature allows you to put an outside call on hold.

KX-TG6051 Press {HOLD} during an outside call.

KX-TG6052/KX-TG6053

Press {HOLD} 2 times during an outside call.

LTo release the hold, press {C}. LAnother handset user can take the

call by pressing {C}.

Note:

LIf another phone is connected to the

same line (page 10), you can also take the call by lifting its handset.

LIf a call is kept on hold for more than 6

minutes, an alarm tone starts to sound and the ringer indicator flashes rapidly. After 4 additional minutes on hold, the call is disconnected.

Mute button

While mute is turned on, you can hear the other party, but the other party cannot hear you. To mute your voice, press {Mute}.

LTo return to the conversation, press

{Mute} or {C}.

Note:

LWhen this feature is turned on,

{Mute} flashes.

L{Mute} is a soft key visible on the

handset display during a call.

Page 17

Making/Answering Calls

RECALL button

Pressing {RECALL} allows you to use special features of your host PBX such as transferring an extension call, or accessing optional telephone services.

Note:

LTo change the recall time, see page

28.

Handset clarity booster

This feature can improve sound clarity when the handset is used in an area where there may be interference. During an outside call, this feature is turned on automatically when necessary. You can also turn this feature on or off manually.

1 Press {MENU} during an outside

call.

2 {V}/{^}: Select “Booster on” or

“Booster off”. i {Select}

Note:

LWhen this feature is turned on,

“BOOST” flashes.

LWhen this feature is turned off

manually during a call, it does not turn on automatically during the same call.

LWhile this feature is turned on;

– the battery operating time is

shortened (page 12).

– the maximum number of extensions

that can be used at a time may decrease.

*1 KX-TG6053

Handset voice enhancer

This feature can simulate a band signal above the normal bandwidth limitations, achieving a sound which is close to the actual voice. You can turn this feature on or off depending on the circumstance.

1 Press {MENU} during an outside

call.

2 {V}/{^}: Select “V.E. on” or “V.E.

off”. i {Select}

Note:

LWhen this feature is turned on, J

is displayed.

LDepending on the condition and

quality of your telephone line, this feature may emphasize existing line noise. If it becomes difficult to hear, turn this feature off.

Slow Talk

This feature works to help slow down the incoming audio when you are having a conversation with an outside party.

Important:

LYou cannot use this feature when;

– the handset announces names or

phone numbers while receiving a

call. – you are on an intercom call. – you are on a conference call. – you are listening to messages in the

answering system. – another unit is using the answering

system. – another handset is having an

intercom call with the base unit.

*1 KX-TG6052/KX-TG6053 To turn this feature on or off, press

{Slow} during an outside call.

Note:

LWhen this feature is turned on,

{Slow} flashes.

LKX-TG6052/KX-TG6053:

This feature turns off if another handset starts to have an intercom call with the base unit, or another unit starts to use the answering system.

Page 18

Making/Answering Calls

L{Slow} is a soft key visible on the

handset display during a call.

LThis feature turns off after you hang

up the call.

LThe speed may become close to

normal when the handset receives constant incoming audio for a period of time.

Call share

Available model:

KX-TG6052/KX-TG6053

This feature allows the handset to join an existing outside call. To join the conversation, press {C} when the other handset is on an outside call.

Page 19

Handset phonebook

You can add up to 50 items to the handset phonebook and search for phonebook items by name.

Adding items to the phonebook

{Phonebook}

2 {Add} 3 Enter the name (max. 16

characters). i {Next}

4 Enter the phone number (max. 32

digits). i {Next} i {Save} LTo add other items, repeat from

step 2.

5 {OFF}

Note:

LCaller ID subscribers can use ringer

ID and light-up ID features (page 22).

Phonebook

LTo enter another character that is

located on the same dial key, first press {>} to move the cursor to the next space.

Editing/correcting a mistake

Press {<} or {>} to move the cursor to the character or number you want to erase, then press {Clear}. Enter the appropriate character or number.

LPress and hold {Clear} to erase all

characters or numbers.

Finding and calling a phonebook item

Searching for a name alphabetically by scrolling through all items

1 {Phonebook} i {Search} 2 {V}/{^}: Select the desired item. 3 Press {C} to dial the phone

number.

Character table for entering names

Key Character

{1} &’ (),–./ 1

{2} abcABC2

{3} def DEF3

{4} ghi GHI 4

{5} jklJKL5

{6} mnoMNO6

{7} pqr sPQRS7

{8} tuvTUV8

{9} wxyzWXYZ9

{0} 0Space

{*} ;

{#} #

Searching for a name by initial

1 {Phonebook} i {Search} 2 Press the dial key ({0} – {9}, {#}, or

{*}) that corresponds to the first letter you are searching for (see the character table, page 19). Example: “LISA” Press {5} repeatedly to display the first phonebook entry starting with the initial “L” and go to step 3. LIf there is no item corresponding to

the letter you selected, the next item is displayed.

3 Press {V} to select the desired item. 4 Press {C} to dial the phone

number.

Page 20

Phonebook

Editing items in the phonebook

Find the desired item (page 19). i

{Option}

2 {V}/{^}: “Edit” i {Select} 3 Edit the name if necessary (see the

character table, page 19). i

{Next}

4 Edit the phone number if necessary.

i {Next} i {Save} i {OFF}

Erasing items in the phonebook

Find the desired item (page 19).

2 {Erase} i {Yes} i {OFF}

Chain dial

This feature allows you to dial phone numbers in the handset phonebook while you are on a call. This feature can be used, for example, to dial a calling card access number or bank account PIN that you have stored in the handset phonebook, without having to dial manually.

1 During an outside call, press

{MENU}.

2 {V}/{^}: “Phonebook” i {Select} 3 Find the desired item (page 19). i

{Call}

Note:

LWhen storing a calling card access

number and your PIN in the phonebook as one phonebook item, press {PAUSE} to add pauses after the number and PIN as necessary (page 15).

Copying handset phonebook items

Available model:

KX-TG6052/KX-TG6053

You can copy one or all of the phonebook items from one handset to another.

Important:

LRinger ID and light-up ID for

phonebook items are not copied.

Copying an item

KX-TG6052

1 {MENU} i {#}{1} 2 {V}/{^}: Select the desired item. i

{Send}

3 Press {OFF} after the long beep.

KX-TG6053

1 {MENU} i {#}{1} 2 {V}/{^}: Select the handset to copy

to. i {Next}

3 {V}/{^}: Select the desired item. i

{Send}

4 Press {OFF} after the long beep.

Copying all items

KX-TG6052

1 {MENU} i {#}{2} 2 Press {OFF} after the long beep.

KX-TG6053

1 {MENU} i {#}{2} 2 {V}/{^}: Select the handset to copy

to. i {Send}

3 Press {OFF} after the long beep.

Page 21

Using Caller ID service

This unit is Caller ID compatible. To use Caller ID features (such as displaying caller phone numbers), you must subscribe to Caller ID service. Consult your service provider/telephone company for details.

Caller ID features

When an outside call is being received, the calling party’s telephone number is displayed. Telephone numbers for the last 50 callers are logged in the caller list by the most recent call to the oldest.

LIf the unit cannot receive caller

information, the following is displayed: –“Out of area”: The caller dialled

from an area which does not provide Caller ID service.

–“Private caller”: The caller

requested not to send caller information.

LIf the unit is connected to a PBX

system, caller information may not be received properly. Consult your PBX supplier.

LIf the name display service is

available in your area, the display shows caller names. For further information, please contact your service provider/telephone company.

Missed calls

If a call is not answered, the unit treats the call as a missed call. You can view the number of missed calls by pressing

{View CID}.

Phonebook name display

When the Caller ID number is received and it matches a phone number stored

Caller ID Service

in the phonebook, the stored name from the phonebook is displayed and logged in the caller list.

Call waiting and Caller ID compatible

If you subscribe to Caller ID service, your handset displays the 2nd caller’s information while talking. After you hear a call waiting tone, the caller’s phone number will be displayed. You can answer the 2nd call, keeping the 1st call on hold. Follow your service provider/telephone company instructions using {RECALL}. LIf the phone number is stored in the

phonebook with its name, the caller’s name will also be displayed.

LPlease contact your service provider/

telephone company for details and availability in your area.

For Caller ID Type II users

When you receive a 2nd call during a conversation, you will hear a signal tone following the call waiting tone and the

conversation will be interrupted or muted for a short period of time. This

is not a fault of the product as these events are normal.

LThe tones are generated by your

service provider/telephone company.

Talking Caller ID

This feature lets you know who is calling without looking at the display. To use this feature, you must subscribe to Caller ID service from your service provider/telephone company and turn this feature on (page 28). When a caller information is received, the all supplied handset(s) and base unit announce:

– the caller’s phone number following

every ring.

Page 22

Caller ID Service

– the caller’s customized name

following every ring, if the caller information matches a phone number stored in the handset 1 phonebook. If the handset 1 does not have a link to the base unit (battery is empty, for instance), the other handset(s) unit announce the caller’s phone number. *1 KX-TG6052/KX-TG6053

LUsually the unit announces the

caller’s information after the 2nd ring. Depending on your telephone service provider, the unit may announce the caller’s information later than usual.

LName pronunciation may vary. This

feature may not pronounce all names correctly.

LUsually the unit announces the

caller’s information after the 2nd ring. If you turn on the answering system and set the ring count to “2” (page

34), the unit does not announce the caller’s information. If “Toll saver” is selected and there is a new message, the unit does not announce the caller’s information.

LYour unit may mute one or more rings

in order to announce the caller’s information. Talking Caller ID takes precedence over ringing.

LThe announcement is heard at the

ringer volume (page 15 , 28).

LThis feature can be turned on or off

(page 28).

LFor users in name display service

available areas: – The unit announces the Caller ID

name provided by your telephone service provider.

– The unit announces the customized

phonebook entry name for numbers stored in the handset 1 phonebook.

and the base

– Caller ID service has a limit of how

many characters can be displayed.

If a caller’s name is too long, the

handset may not be able to display

or announce the entire name.

Ringer ID/Light-up ID

This feature can help you identify who is calling by using different ringers and ringer indicator colours for different callers stored in the phonebook. You can assign a different ringer and indicator colour to each phonebook item. When a call is received from a caller stored in the phonebook, the assigned ringer rings and the assigned ringer indicator colour flashes after Caller ID information is displayed. If you select “No Ringer ID” (default) or “No Light-up ID” (default), the handset uses the ringer tone or ringer indicator colour you selected on page 27 when a call is received from that caller.

LThe ringer and indicator colour may

be changed after the 2nd ring.

1 Find the desired item (page 19). i

{Option}

2 To assign a ringer:

{V}/{^}: Select “Ringer ID”. i {Select}

To assign a ringer indicator colour:

{V}/{^}: Select “Light-up ID”. i {Select}

3 {V}/{^}: Select the desired setting. 4 {Save} i {OFF}

Page 23

Caller list

Viewing the caller list and calling back

{View CID}

2 Press {V} to search from the most

recent call, or {^} to search from the oldest call.

3 To call back, press {C}.

To exit, press {OFF}.

Note:

LIf you do not want to dial the area

codes when making calls from the Caller ID list, you can store the area codes which you want the unit to delete automatically (page 23).

LKX-TG6052/KX-TG6053:

Each handset has its own caller list. The number of missed calls may differ between handsets. Even if you viewed the caller list or answered a call on one handset, the same information is still recognized as a missed call in the other handsets.

LA Q is displayed in caller information

which has already been viewed or answered.

LIf an arrow (→ ) is displayed after the

number, the whole phone number is not shown. Press {>} to see the remaining numbers. To return to the previous display, press {<}.

Caller ID Service

1 {MENU} i {0}{4} 2 Enter your area code (max. 8 digits).

LTo correct a digit, press {< } or { > }

to move the cursor, then press

{Clear}. Enter the correct number.

3 {Save} i {OFF}

To erase your area code

Press and hold {Clear} in step 2, press {Save}, then press {OFF}.

Editing a caller’s phone number before calling back

You can edit a phone number in the caller list.

1 {View CID} 2 {V}/{^}: Select the desired item. i

{Select} i {Edit}

3 Add or erase digits to the beginning

of the number as necessary. LTo add a digit, press the desired

dial key.

LTo erase a digit, press {Clear} or

{#}.

4 {C}

Note:

LThe edited phone number is not

saved in the caller list.

Storing your area code

We recommend storing your area code before using Caller ID (page 21). Calls from the same area will be recorded in the caller list without the area code. You do not have to remove it before calling back the caller or storing in the phonebook.

Page 24

Caller ID Service

Storing caller information into the phonebook

{View CID}

2 {V}/{^}: Select the desired item. i

{Select} LTo edit the number, press {Edit},

then edit the number (see step 3 on page 23, “Editing a caller’s phone number before calling back”).

3 {Save}

LIf there is name information for the

caller, skip to step 5.

4 Enter the name (see the character

table, page 19). i {Next} i {Save}

5 {OFF}

Erasing selected caller information

{View CID}

2 {V}/{^}: Select the desired item. 3 {Erase} i {Yes} i {OFF}

Erasing all caller information

1 {View CID} 2 {All erase} i {Yes}

Page 25

Programming

Programmable settings

You can customize the unit by programming the following features using the handset. To access the features, there are 2 methods: – scrolling through the display menus (page 25) – using the direct commands (page 27)

LMainly the direct command method is used in these operating instructions.

Programming by scrolling through the display menus

{MENU}

1 2 Press {V} or {^} to select the desired menu. i {Select}

LIf there is a sub-menu(s), press {V} or {^} to select the desired item. i

{Select}

3 Press {V} or {^} to select the desired setting. i {Save}

LThis step may vary depending on the feature being programmed.

4 {OFF}

Main menu Sub-menu 1 Sub-menu 2 Page

Message play ––32 V.M. access ––36 Alarm ––29 Ringer setting Ringer volume ––

Ringer tone –– Ring colour ––

Set date & time Date and time

Time adjustment Voice enhancer ––17 Copy phonebook

(KX-TG6052/

KX-TG6053)

Talking CallerID ––21 Customer support ––29

Copy 1 item –20

Copy all items –20

*1, *2

–14

––

Page 26

Programming

Main menu Sub-menu 1 Sub-menu 2 Page

Initial setting Set answering Ring count

Recording time

Remote code Voice Mail Store VM access# Message alert – 35, 37 LCD contrast –– Key tone –– Auto talk –16 Set area code –23 Set tel line Set dial mode

Set recall time

Set line mode Set base unit Ringer tone

Talking CallerID Registration HS registration 47

Deregistration 47

*1 If you program these settings using one of the handsets, you do not need to

program the same item using another handset (KX-TG6052/KX-TG6053).

*2 This feature allows the unit to automatically adjust the date and time setting when

caller information is received. To use this feature, set the date and time first.

–

Page 27

Programming

Programming using the direct commands

{MENU}

1 2 Enter the desired feature code. 3 Enter the desired setting code. i {Save}

LThis step may vary depending on the feature being programmed.

4 {OFF}

Note:

LIn the following table, < > indicates the default setting. LIf you make a mistake or enter the wrong code, press {OFF}, then start again from

step 1.

Feature Feature

code

Alarm {8}{1}: Once {0}: <Off>–29 Auto talk Copy phonebook

(1 item) Copy phonebook

(all items)

Date and time {4}{1} – r 14 Deregistration {0}{0}{2} ––47 HS

registration Key tone LCD contrast

(Display contrast)

Message alert {0}{#} {1}: On {0}: <Off> – 35, 37 Message play {2} ––32 Recording time {0}{6}{2}{1}: 1min {2}: 2min

Remote code {0}{6}{3} Default: 11 r 34 Ring colour

(Ringer indicator colour)

Ring count {0}{6}{1}{2}–{7}: 2–7 rings <4>

{0}{3}{1}: On {0}: <Off>–16

{#}{1} ––20

{#}{2} ––20

{0}{0}{1} ––47

{0}{2}{1}: <On> {0}: Off ––

{0}{1}{1}–{6}: Level 1–6 <3> – –

{1}{4}{1}: <Colour1>=Amber

Setting code System

setting

r 35

{3}: <3min>

––

{2}: Colour2=Green {3}: Colour3=Red {4}: Multicolour

r 34

{0}: Toll saver

Page

Page 28

Programming

Feature Feature

code

Ringer tone

{0}{*}{1}{1}–{3}: Tone <1>–3 r –

Setting code System

setting

Page

(Base unit)

Ringer tone

(Handset) Ringer volume

(Handset)

{1}{2}{1}–{3}: Tone <1>–3

{4}–{7}: Melody 1–4

{1}{1}{1}: Low {2}: Medium

{3}: <High> {0}: Off

––

Set area code {0}{4} ––23 Set dial mode {0}{5}{1} – r 45 Set recall

time

{0}{5}{2}{1}: 700ms {2}: 600ms

{3}: 400ms {4}: 300ms

r 17

{5}: 250ms {6}: 110ms {7}: <100ms> {8}: 90ms

Set line mode Store VM

{0}{5}{3}{1}: A {2}: <B> r –

{0}{7}{1} – r 36

access# Talking

{9}{1}: <On> {0}: Off –21

CallerID

(Handset)

Talking

{0}{*}{4}{1}: <On> {0}: Off r 21

CallerID

(Base unit)

Time adjustment

{4}{2}{1}:

{0}: Manual

Caller ID[auto]

r –

(Caller ID subscribers only)

V.M. access {3} ––36 Voice enhancer {5}{1}: On {0}: <Off>–17

*1 If “System setting” column is checked, you do not need to program the same item

using another handset (KX-TG6052/KX-TG6053).

*2 If you subscribe to Caller ID service and want to view the caller’s information after

lifting up the handset to answer a call, turn off this feature. *3 KX-TG6052/KX-TG6053 only *4 Turn this feature off if you prefer not to hear key tones while you are dialling or

pressing any keys, including confirmation tones and error tones. *5 The recall time depends on your telephone exchange or host PBX. Consult your

PBX supplier if necessary.

You can access your service provider/telephone company “Call Waiting” service

Page 29

Programming

by having the recall time set at 100 ms, and then follow your service provider/

telephone company “Call Waiting” instructions to operate this service. *6 Generally, the line mode setting should not be adjusted. If “Line in use” is not

displayed when another phone connected to the same line is in use, you need to

change the line mode to “A”. *7 This feature allows the unit to automatically adjust the date and time setting when

caller information is received. To use this feature, set the date and time first.

Alarm

An alarm will sound once for 3 minutes at the set time.

Set the date and time beforehand (page 14).

1 {MENU} i {8} 2 {V}/{^}: “Once” i {Select}

L To turn off the alarm, select “Off”. i {Select} i {OFF}

3 Set the desired date and time. i {Save} 4 {V}/{^}: Select the desired ringer tone. i {Save}

L We recommend selecting a different ringer tone from outside call.

5 {OFF}

Note:

LTo stop the alarm, press any dial key or place the handset on the base unit or

charger.

LWhen the handset is in use, the alarm will not sound until the handset is in standby

mode.

Customer support

The handset can display the Internet address where you can download the operating instructions or get further information for this product using your computer. {MENU} i {V}/{^}: “Customer support” i {Select} i {OFF}

Page 30

Answering System

Answering system

This unit contains an answering system which can answer and record calls for you when you are unavailable to answer the phone.

Important:

LOnly 1 person can access the

answering system at a time.

LWhen callers leave messages, the

unit records the day and time of each message. Make sure the date and time have been correctly set (page

14).

Memory capacity

The total recording capacity (including your greeting message) is about 16 minutes. A maximum of 64 messages can be recorded.

LIf the message memory becomes full,

the ANSWER ON indicator flashes rapidly (if the answering system is turned on). Erase unnecessary messages (page 31).

LWhen the message memory

becomes full, the greeting message is different depending on your situation: – If you use the prerecorded greeting

message, the unit automatically switches to another prerecorded greeting message asking callers to call again later.

– If you recorded your own greeting

message, the same message is still announced to callers even though their messages are not recorded.

Turning the answering system on/off

Press {ANSWER ON} to turn on/off the answering system. LWhen the answering system is turned

on, the ANSWER ON indicator lights.

LWhen the answering system is turned

off, the ANSWER ON indicator turns off.

Screening calls

While a caller is leaving a message, you can listen to the call through the base unit’s speaker. To adjust the speaker volume, press {>} or {<} repeatedly. You can answer the call by pressing {C} on the handset.

Turning off the call screening feature

When the base unit is not in use, press {GREETING CHECK}, then press and hold {<} until the base unit beeps. OR While screening a call, press and hold {<} until the sound goes off.

Note:

LIf you adjust the speaker volume

while listening to messages or talking on the intercom, the speaker volume for call screening is turned on again.

Page 31

Answering System

Greeting message

When the unit answers a call, callers are greeted by a greeting message. You can record your own greeting message or use a prerecorded greeting message.

Recording your greeting message

You can record your own greeting message (max. 2 minutes). If you do not record a greeting message, a prerecorded greeting message is used.

1 {GREETING REC} 2 Within 10 seconds, press

{GREETING REC} again.

3 After the base unit beeps, speak

clearly about 20 cm away from the MIC.

4 To stop recording, press {STOP}.

Using a prerecorded greeting message

If you erase or do not record your own greeting message, the unit plays a prerecorded greeting message for callers and ask them to leave messages.

Playing back the greeting message

Press {GREETING CHECK}.

Erasing your greeting message

Press {GREETING CHECK}, and then press {ERASE} while your greeting message is playing.

Listening to messages using the base unit

When new messages have been recorded, the MESSAGE indicator on the base unit flashes. Press {MESSAGE}.

LThe base unit plays new messages. LWhen you have no new messages,

the base unit plays back all messages.

Operating the answering system

Key Operation

{>} or {<} Adjust the speaker

volume

{<} Repeat message

(during playback)

{>} Skip message

(during playback)

{STOP} Pause message

–To resume

playback, press {MESSAGE}.

– To stop playback

completely, press

{STOP} again.

{ERASE} Erase message

currently playing

*1 If pressed within the first 5 seconds

of a message, the previous message is played.

Erasing all messages

Press {ERASE} 2 times while the unit is not being used.

Page 32

Answering System

Listening to messages using the handset

When new messages have been recorded: –“New message” is displayed. – The message indicator on the

handset flashes slowly if the message alert feature is turned on (page 35).

1 {MENU} 2 {V}/{^}: “Message play” i

{Select} LThe handset plays new messages. LWhen you have no new messages,

the handset plays back all messages.

3 When finished, press {OFF}.

Note:

LTo switch to the receiver, press {C}.

Voice guidance

If you do not press any buttons after the last message is played back, the handset’s voice guidance starts. Operate the answering system by following the guidance as necessary.

Calling back (Caller ID subscribers only)

If Caller ID information was received for the call, you can call the caller back while listening to the message.

1 Press {Select} during playback.

LTo edit the number, press {Edit},

then edit the number (see step 3 on page 23, “Editing a caller’s phone number before calling back”).

2 {Call}

Operating the answering system

You can also operate the answering system by pressing dial keys on the handset during playback.

Key Operation

{^} or {V} Adjust the receiver/

{1} or {<} Repeat message

{2} or {>} Skip message (during

{4} Play new messages

{5} Play all messages

{8} Turn answering system

{9} Stop playback

{0} Turn answering system

{*}{4} or {Erase}

{*}{5} Erase all messages

*1 If pressed within the first 5 seconds

of a message, the previous message is played.

*2 To resume operation, press a

command key within 15 seconds, or the voice guidance will start.

speaker volume

(during playback)

playback)

off

Erase message currently playing

Page 33

Remote operation

Using a touch tone phone, you can call your phone number from outside and access the unit to listen to messages. The unit’s voice guidance prompts you to press certain dial keys to perform different operations.

Important:

LIn order to operate the answering

system remotely, you must first set a remote code (page 34). This code must be entered each time you operate the answering system remotely.

Using the answering system remotely

Dial your phone number from a touch tone phone.

2 After the greeting message starts,

enter your remote code (page 34). LThe unit plays back new

messages.

LThe voice guidance informs you of

the available commands.

3 Control the unit using remote

commands (page 33).

4 When finished, hang up.

Voice guidance

During remote operation, the unit’s voice guidance starts and prompts you to press {1} to perform a specific operation, or press {2} to listen to more available operations. Operations are presented by voice guidance in the following order: – Play back all messages – Play back new messages – Record a message – Erase all messages

Answering System

Note:

LIf you do not press any dial keys

within 10 seconds after a voice guidance prompt, the unit disconnects your call.

Remote commands

You can press dial keys to access certain answering system functions without waiting for the voice guidance to prompt you.

Key Remote command

{1} Repeat message

(during playback)

{2} Skip message (during

playback)

{4} Play new messages

{5} Play all messages

{9} Stop playback

{0} Turn answering system

off

{*}{4} Erase message

currently playing

{*}{5} Erase all messages

*1 If pressed within the first 5 seconds

of a message, the previous message is played.

*2 To resume operation, enter a remote

command within 15 seconds, or the voice guidance starts.

Page 34

Answering System

Turning on the answering system remotely

If the answering system is off, you can turn it on remotely.

1 Dial your phone number. 2 Let the phone ring 15 times.

LThe unit answers your call with the

greeting message.

LYou can hang up, or if you call from

a touch tone phone, you can enter your remote code and begin remote operation (page 33).

Skipping the greeting message to leave a message

You can leave a message just as any outside caller can. Call your phone number. When the answering system picks up, press {*} to skip the greeting message and record your message after the beep.

Answering system settings

Remote code

A remote code must be entered when operating the answering system remotely. This code prevents unauthorised parties from listening to your messages remotely. The default setting is “11”.

1 {MENU} i {0}{6}{3} 2 Enter the desired 2-digit remote

code. i {Save} i {OFF}

Ring count

You can change the number of times the phone rings before the unit answers calls. The default setting is “4”. “Toll saver”: The unit answers on the 2nd ring when new messages have been recorded, and on the 4th ring when there are no new messages. If you call your phone from outside to listen to new messages (page 33), you will know that there are no new messages when the phone rings for the 3rd time. You can then hang up without being charged for the call.

1 {MENU} i {0}{6}{1} 2 {V}/{^}: Select the desired setting. 3 {Save} i {OFF}

For Service Provider Voice Mail Subscribers

To receive Voice Mail and use answering system properly, please note the following:

L“Voice Mail” is a service provided by

your service provider/telephone company. You will need to first

Page 35

Answering System

subscribe or activate this service through your service provider/ telephone company. Consult your service provider/telephone company on how to operate this service and how you will be notified that you have messages on your Voice Mail. To use this service you will be required to leave your answering machine off on your unit. This will allow the Voice Mail to receive any messages.

LTo use the unit’s answering machine

rather than the Voice Mail service provided by your service provider/ telephone company, please consult your service provider/telephone company to have it removed or deactivated permanently or temporarily. Alternatively you can leave this service connected and change the “Ring count” to a shorter duration on your unit so your unit’s answering machine can pick up the call prior to the Voice Mail provided by your service provider/telephone company.

Caller’s recording time

You can change the maximum message recording time allotted to each caller. The default setting is “3min”.

1 {MENU} i {0}{6}{2} 2 {V}/{^}: Select the desired setting. 3 {Save} i {OFF}

Important:

LIf there are new Voice Mail messages

present (page 36), the message indicator also flashes slowly.

1 {MENU} i {0}{#} 2 {V}/{^}: Select the desired setting. 3 {Save} i {OFF}

Note:

LWhile message alert is on, battery

operating time is shortened (page

12).

Message alert

You can select whether or not the message indicator on the handset flashes slowly when new messages are recorded. The default setting is “Off”.

Page 36

Voice Mail Service

Using Voice Mail service

Voice Mail is an automatic answering service offered by your service provider/ telephone company. After you subscribe to this service, the service provider/telephone company’s Voice Mail system will answer calls for you when you are unavailable to answer the phone or when your line is busy. Messages are recorded by the service provider/telephone company, not your telephone.

Important:

LTo use the Voice Mail service

provided by your service provider/ telephone company rather than the unit’s answering system, turn off the answering system (page 30).

Storing the Voice Mail (VM) access number

In order to listen to your Voice Mail messages, you must dial your service provider/telephone company’s Voice Mail access number. Once you have stored your Voice Mail access number, you can dial it automatically (page 36).

1 {MENU} i {0}{7}{1} 2 Enter your access number (max. 32

digits). i {Save} i {OFF}

Note:

LWhen storing your Voice Mail access

number and your mailbox password, press {PAU SE} to add pauses (page

15) between the access number and the password as necessary. Consult your service provider/telephone company for the required pause time.

Example:

0222333444

VM access number

To erase the Voice Mail access number

Repeat step 1, then press and hold

{Clear} until all digits are erased. Press {Save}, then press {OFF}.

PPPP 8888

Pauses Password

Listening to Voice Mail messages

If compatible with message indication signals provided by your service provider/telephone company, the unit lets you know that you have new Voice Mail messages in the following ways: –“New Voice Mail” is displayed on

the handset.

– The message indicator on the

handset flashes slowly if message alert feature is turned on (page 37).

1 Press {C}, then press {VM} within

15 seconds. OR

{MENU} i{V}/{^}: “V.M. access” i {Select}

LThe speakerphone turns on.

2 Follow the prerecorded instructions. 3 When finished, press {OFF}.

Note:

LIf {VM} is not displayed, the Voice

Mail access number has not been stored. Store the number (page 36).

LIf the handset still indicates there are

new messages even after you have listened to all new messages, turn it off by pressing and holding {OFF} until the handset beeps.

Page 37

Message alert

You can select whether or not the message indicator on the handset flashes slowly when there are new recorded messages in the Voice Mail system. The default setting is “Off”.

Important:

LIf there are new answering system

messages present (page 30), the message indicator also flashes slowly.

1 {MENU} i {0}{#} 2 {V}/{^}: Select the desired setting. 3 {Save} i {OFF}

Note:

LWhile message alert is on, battery

operating time is shortened (page

12).

Voice Mail Service

Page 38

Multi-unit Operation

Intercom

Intercom calls can be made: – between handsets

(KX-TG6052/KX-TG6053)

– between the handset and base unit

Note:

LIf you receive an outside call while

talking on the intercom, you hear 2 tones. To answer the call, press

{OFF}, then press {C}.

LWhen paging a unit for an intercom

call, the paged unit beeps for 1 minute.

Making an intercom call

Handset

KX-TG6051

1 {INTERCOM}

LTo stop paging, press {OFF}.

2 When you finish talking, press

{OFF}.

KX-TG6052/KX-TG6053

1 {INTERCOM} 2 {V}/{^}: Select the desired unit. i

{Select} LTo stop paging, press {OFF}.

3 When you finish talking, press

{OFF}.

Answering an intercom call

Handset

Press {C} or {s} to answer the page.

2 When you finish talking, press

{OFF}.

Base unit

1 Press {INTERCOM} to answer the

page.

2 When you finish talking, press

{INTERCOM}.

Note:

LWhen the ringer volume is set to off,

the handset or the base unit rings at a low level for intercom calls.

Handset locator

You can locate a misplaced handset by paging it.

1 Base unit:

{LOCATOR} LThe handset beeps for 1 minute.

2 To stop paging:

Base unit: Press {LOCATOR}. Handset:

Press {INTERCOM}, then press {OFF}.

Base unit

1 {INTERCOM}

LAll the registered handsets beep

for 1 minute.

LTo stop paging, press

{INTERCOM}.

2 When you finish talking, press

{INTERCOM}.

Page 39

Transferring calls between handsets, conference calls

Available model:

KX-TG6052/KX-TG6053

Outside calls can be transferred between 2 handsets. 2 handsets can have a conference call with an outside party.

1 During an outside call, press

{INTERCOM} to put the call on hold.

2 KX-TG6052

Press the right soft key.

KX-TG6053

{V}/{^}: Select the desired unit. i {Transfer}

3 Wait for the paged party to answer.

LIf the paged party does not answer,

press {C} to return to the outside call.

4 To complete the transfer:

Press {OFF}. LThe outside call is being routed to

the handset.

To establish a conference call:

Press {Conf}. LTo leave the conference, press

{OFF}. The other parties can

continue the conversation.

LTo put the outside call on hold,

press {HOLD}. To resume the conference, press {Conf}.

Multi-unit Operation

Answering transferred calls

Press {C} to answer the page. LAfter the paging party disconnects,

you can talk to the outside caller.

Page 40

Useful Information

Wall mounting

Base unit

Insert the hooks on the wall

mounting adaptor into the holes 1 and 2 on the base unit.

3 Tuck the telephone line cord inside

the wall mounting adaptor and connect the cord. Drive the screws (not included) into the wall. Mount the unit, and then slide it down. Connect the AC adaptor to power outlet (page 10).

AC adaptor cord

2 While pressing down the lever (A),

press it in the direction of the arrow (B) until it is secure.

Wall mount template for the base unit

Screws

83 mm

To socket

(230–240 V AC, 50/60 Hz)

To remove the wall mounting adaptor

While pushing down the release lever (A), remove the adaptor (B).

83 mm

Page 41

Useful Information

Charger

Available model:

KX-TG6052/KX-TG6053

Drive the screws (not included) into the wall.

25.4 mm

Screws

(230–240 V AC, 50/60 Hz)

2 Mount the charger (A), then slide it

down (B) and to the right (C) until it is secure.

Headset (optional)

Connecting a headset to the handset allows hands-free phone conversations. We recommend using the Panasonic headset noted on page

LHeadset shown is KX-TCA86AL.

Note:

LOnly telecommunications compliance

labelled headsets should be plugged into the headset socket on the handset.

Switching a call between the headset and handset speakerphone

To switch to the handset speakerphone, press {s}. To return to the headset, press {C}.

Wall mount template for the charger

25.4 mm

Lanyard/strap eyelet

If you have a lanyard/strap (not included), you can hang your handset from your neck or wrist. Thread it through the eyelet as shown and pull to tighten it.

Page 42

Useful Information

Error messages

If the unit detects a problem, one of the following messages is shown on the display.

Display message Cause/solution

Busy LThe called unit is in use.

LThe handset you tried to copy phonebook items

to is in use. Try again later.

LThe handset you are calling is too far from the

base unit.

Error!! LThe handset’s registration has failed. Move the

handset and base unit away from all electrical appliances and try again.

LAnother handset user tried to send phonebook

items to you but there was an error. Have the other handset user re-send the items to you (page 20).

---Incomplete--Phonebook full

Invalid LThere is no handset registered to the base unit

No items stored LYour phonebook or redial list is empty. No link to base.

Move closer to base, try again.

Phonebook full L There is no space to store new items in the

Please lift up and try again.

System is busy. Please try again later.

LThe destination handset’s phonebook memory is

full. Erase unnecessary items from the destination handset’s phonebook (page 20).

matching the extension number you entered.

LThe handset has lost communication with the

base unit. Move closer to the base unit, and try again.

LConfirm that the base unit’s AC adaptor is

plugged in.

LThe handset’s registration may have been

cancelled. Re-register the handset (page 47).

phonebook. Erase unnecessary items (page 20).

LA handset button was pressed while the handset

was on the base unit or charger. Lift the handset and press the button again.

LOther units are in use and the system is busy. Try

again later.

LAnother user is listening to messages. Try again

later.

LThe handset’s registration may have been

cancelled. Re-register the handset (page 47).

Page 43

Useful Information

Display message Cause/solution

Store VM access# L You have not stored the Voice Mail access

number. Store the number (page 36).

*1 KX-TG6052/KX-TG6053

Troubleshooting

General use

Problem Cause/solution

The unit does not work. LMake sure the battery is installed correctly and

fully charged (page 11).

LCheck the connections (page 10). LUnplug the base unit’s AC adaptor to reset the

unit. Reconnect the adaptor and try again.

LThe handset has not been registered to the

base unit. Register the handset (page 47).

I cannot hear a dial tone. LConfirm the telephone line cord is properly

connected (page 10).

LDisconnect the unit from the telephone line and

connect a known working telephone. If the working telephone operates properly, contact our service personnel to have the unit repaired. If the working telephone does not operate properly, contact your service provider/ telephone company.

The communication between the base unit and the handset is unstable.

The indicator on the top right of the handset flashes slowly.

LThe handset may not be properly registered. Try

to re-register the handset (page 47).

LNew messages have been recorded. Listen to

the new messages (page 31).

LNew Voice Mail messages have been recorded.

Listen to the new Voice Mail messages (page

36).

Programmable settings

Problem Cause/solution

I cannot program items. L Programming is not possible while either the

base unit or another handset is being used. Try again later.

Page 44

Useful Information

Problem Cause/solution

I cannot set the alarm. L In order to set the alarm, you must first set the

date and time (page 14).

LThe handset has lost communication with the

base unit. Move closer to the base unit, and try again.

While programming, the handset starts to ring.

Battery recharge

Problem Cause/solution

I fully charged the battery, but 7 continues to flash, or 8 is displayed.

The handset display is blank.

While charging, the charge indicator does not light and “Charge for 7h” is displayed.

Making/answering calls, intercom

Problem Cause/solution

Static is heard, sound cuts in and out. Interference from other electrical units.

The handset does not ring. LThe ringer volume is turned off. Adjust it (page

The base unit does not ring.

LA call is being received. Answer the call and

start again after hanging up.

LClean the charge contacts and charge again

(page 12).

LThe battery may need to be replaced with a new

one (page 11).

LConfirm that the battery is properly installed. LFully charge the battery (page 11).

LThe battery is empty. The charge indicator does

not light in order to concentrate on charging. After about 5 minutes, the charge indicator lights and “Charging” is displayed.

LMove the handset and base unit away from

other electrical appliances.

LMove closer to the base unit. LTurn on the clarity booster feature (page 17). LIf your unit is connected to a telephone line with

ADSL service, we recommend connecting an ADSL filter between the base unit and the telephone line socket. Contact your ADSL provider for details.

28).

LThe ringer volume is turned off. Adjust it (page

16).

Page 45

Useful Information

Problem Cause/solution

I cannot make a call. LAnother handset is in use. Try again later.

LIf the above remedy does not solve the problem,

set the dialling mode. Press {MENU} {0} {5} {1} {Save} {OFF}.

LThe unit is not designed to be used with rotary

(pulse dialling) services.

I cannot have a conversation using the headset.

I cannot page the handset. LThe called handset is too far from the base unit.

I cannot page the base unit.

The Slow Talk feature does not work.

*1 KX-TG6052/KX-TG6053

Caller ID

Problem Cause/solution

The handset does not display the caller’s phone number.

LMake sure that an optional headset is

connected properly (page 41).

LIf “SP-phone” is displayed on the handset,

press {C} to switch to the headset.

LWe recommend using the Panasonic headset

noted on page 5.

LThe called handset is in use. Try again later.

LThe base unit is in use. Try again later.

LIf you are on a conference call, you cannot use

the Slow Talk feature.

LYou have not subscribed to Caller ID service.

Contact your service provider/telephone company to subscribe.

LIf your unit is connected to any additional

telephone equipment such as a Caller ID box or cordless telephone line socket, disconnect the unit from the equipment and plug the unit directly into the wall socket.

LIf your unit is connected to a telephone line with

ADSL service, we recommend connecting an ADSL filter between the base unit and the telephone line socket. Contact your ADSL provider for details.

LOther telephone equipment may be interfering

with this unit. Disconnect the other equipment and try again.

LThe caller requested not to send caller

information (page 21).

Page 46

Useful Information

Problem Cause/solution

The handset or base unit does not announce the displayed caller names or phone numbers.

*1 KX-TG6052/KX-TG6053

Answering system

Problem Cause/solution

I cannot listen to messages from a remote location.

The unit does not record new messages.

I cannot operate the answering system.

LThe handset or base unit’s ringer volume is

turned off. Adjust it (page 16, 28).

LThe Talking Caller ID feature is turned off. Turn it

on (page 28).

LThe ring count for the answering system is set to

“2” or “Toll saver”. Select a different setting (page 34).

LIf the base unit and another handset are having

an intercom call, your handset does not announce caller information.

LA touch tone phone is required for remote

operation.

LEnter the remote code correctly (page 34). LThe answering system is off. Turn it on (page

34).

LThe answering system is off. Turn it on (page 30,

34).

LThe message memory is full. Erase

unnecessary messages (page 31, 32).

LIf you subscribe to the Voice Mail service,

messages are recorded by the service provider/ telephone company not your telephone (page

34).

LSomeone is operating the answering system. LIf someone is talking on a conference call, you

cannot operate the answering system. Try again later.

Page 47

Registration

Problem Cause/solution

The handset registration may have been cancelled or the communication between the base unit and the handset is unstable.

LRe-register the handset.

1 Handset: {MENU} i {0}{0}{1} 2 Base unit: Press and hold {LOCATOR} until

the IN USE indicator flashes.

3 Handset: Press {OK}, then wait until a beep

sounds. i {OFF}

If the registration fails, try to deregister the handset first:

KX-TG6051

Press {MENU} i {0}{0}{2} i {3}{3}{5} i {OK} i {1}, then re-register it again.

KX-TG6052/KX-TG6053

Use another handset to deregister the unstable handset. Press {MENU} i {0}{0}{2} i {3}{3}{5} i {OK} i {1}, {2}, or {3} (The handset number which you want to cancel). Try to re-register it again.

LIf the above remedy does not solve the problem,

consult your nearest Panasonic service centre.

Useful Information

Page 48

Useful Information

Instructions to customer

Installation

Attached to this apparatus is an approval label. This label is evidence that it is a “Permitted Attachment” which has been authorised to be connected to your telephone service. Conditions relating to connection and operation of this Permitted Attachment are contained in Telecommunications General By-Law 220 (5). You are authorised to install this Permitted Attachment yourself by plugging it into the line socket of any regular telephone. You may connect it in place of your existing telephone or to any spare telephone socket installed in your premises. To disconnect your existing telephone you must first remove its plug from the line socket. You can then insert the plug of your Permitted Attachment into the socket and use your equipment. If the plug of your existing telephone cannot be readily removed, you will have to remove the screw securing it. To do this proceed as follows:

1. Loosen screw “A” sufficiently to remove the socket cover. (See Fig. 1.)

2. Remove screw “B” and withdraw the plug. (See Fig. 2.)

3. Replace screw “B”. (See Fig. 3.) Ensure that it screws completely into the socket

recess. (If the screw is too long, increase the hole depth or replace the screw with one 5 mm shorter.)

4. Replace socket cover and tighten screw “A”. (See Fig. 4.)

SOCKET

SCREW “A”

PLUG

SCREW “B”

Fig. 1

TELEPHONE CORD

Connect to the PLUG

( )

as shown in Fig. 1.

SCREW “A”

SCREW “B”

Fig. 3

Fig. 2

Fig. 4

SOCKET

Page 49

Useful Information

If you are satisfied with the operation of your telephone service after plugging in your Permitted Attachment, your installation is completed. You will be unable to connect this Permitted Attachment if your telephone service consists only of a wall phone or an old style telephone which is not connected by means of a modern plug and socket. In such cases a new socket will need to be installed. Should the Permitted Attachment not operate when plugged into a socket, it is either faulty or unsuitable for operation with your telephone service. It should be returned to the store where purchased or an Authorised Service Centre.

Service difficulties

If at any time a fault occurs on your telephone service, carry out the following checks before you call for service: LDisconnect the Permitted Attachment and try using the service with the normal

telephone.

LIf the telephone service then operates satisfactorily, the fault is in your Permitted

Attachment. Leave the Permitted Attachment disconnected and report the fault to its supplier or agent to arrange for repair.

LIf when using the telephone the service is still faulty, report the fault to “Service

Difficulties and Faults” for attention. You are required to keep this Permitted Attachment in good working order while it is connected to your telephone service. Its construction or internal circuit must not be modified in any way without permission.

WARNING:

This cordless telephone system does not incorporate provision for secrecy of conversations. Appropriately tuned radio equipment and other cordless telephone systems in close proximity may be used by a third party to monitor and possibly interrupt conversations in progress when this system is on radio operation.

Page 50

Useful Information

Specifications

General

Operating environment

Frequency 5.76 GHz – 5.84 GHz

Base unit

Dimensions Approx. height 97 mm × width 120 mm × depth 144 mm

Mass (Weight) Approx. 270 g

Power consumption Standby: Approx. 1.5 W, Maximum: Approx. 4.5 W

Power output 200 mW (max.)

Power supply AC adaptor (230–240 V AC, 50/60 Hz)

Handset

Dimensions Approx. height 156 mm × width 48 mm × depth 33 mm

Mass (Weight) Approx. 160 g

Power output 200 mW (max.)

Power supply Ni-MH battery (3.6 V, 650 mAh)

Charger (KX-TG6052/KX-TG6053)

Dimensions Approx. height 68 mm × width 82 mm × depth 87 mm

Mass (Weight) Approx. 80 g

Power consumption Standby: Approx. 0.8 W

Power supply AC adaptor (230–240 V AC, 50/60 Hz)

Note:

LDesign and specifications are subject to change without notice. LThe illustrations in these instructions may vary slightly from the actual product.

5 °C – 40 °C

Maximum: Approx. 3.2 W

Page 51

Index

A Alarm: 29

Answering calls Answering system

Erasing messages Listening to messages

Turning on/off Area code Auto talk

B Battery

Booster (Clarity booster)

C Call screening

Call share Call waiting and Caller ID compatible Caller ID edit Caller ID service Caller list Chain dial CID (Caller ID) Conference calls Connections Customer support

D Date and time

Deregistration Display

Contrast

E Error messages G Greeting message H Handset locator

Headset, optional Hold

: 16

I Intercom K Key tone L Light-up ID

Line mode

M Making calls

Memory capacity (message recording) Message alert Missed calls Mute

: 16

: 30, 32, 33, 34

: 23

: 16

: 11, 12

: 30

: 18

: 21

: 23

: 21

: 23, 24

: 20

: 23

: 39

: 10

: 14 : 47

: 27

: 42

: 38

: 41

: 38

: 27

: 22

: 28

: 15

: 30

: 35, 37

: 21

: 31, 32, 33

: 17

: 29

: 31

N Navigator key P Pause

Phonebook Phonebook copy Power failure

R Recall

Recording time Redial list Registration Remote code Remote operation Ring colour Ring count Ringer ID Ringer off Ringer tone

S Slow Talk

Soft keys SP-phone

T Talking Caller ID

Time adjustment Toll saver Transferring calls Troubleshooting

V VE (Voice Enhancer)

VM (Voice Mail) Voice guidance Voice Mail access number Volum e

Base unit ringer Handset ringer Receiver Speaker

W Wall mounting

: 14

: 15

: 19

: 20

: 10

: 17, 28

: 35

: 15

: 47

: 34

: 33

: 27

: 34

: 22

: 16, 28

: 28

: 17

: 14

: 15

: 21

: 28

: 34

: 39

: 43

: 36

: 32, 33

: 16

: 28

: 15

: 40, 41

: 17

: 36

Page 52

We recommend keeping a record of the following information for future reference.

Serial No. Date of purchase

(found on the bottom of the base unit)

Name and address of dealer

Attach your purchase receipt here.

Customer Support Centre Tel. No.: 132600 or website www.panasonic.com.au

N52

Sales Department: Panasonic Australia Pty. Limited

Austlink Corporate Park, 1 Garigal Road, Belrose NSW 2085, Australia

Panasonic Communications Co., Ltd.

1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan

This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic Communications Co., Ltd. © 2007 Panasonic Communications Co., Ltd. All Rights Reserved.

PQQX15820ZA DC0907PN0
