Panasonic HC-V700PC, HC-V700P, HC-V700EB, HC-V700EC, HC-V700EF Service Manual

...

ORDER NO. VM1202002CE

B27

High Definition Video Camera

Model No. HC-V700P

HC-V700PC HC-V700EB HC-V700EC HC-V700EE HC-V700EF HC-V700EG HC-V700EP HC-V700GC HC-V700GN HC-V700GK HC-V707EG HC-V700MP HC-V700MPC HC-V700MPU HC-V700MGK HC-V707MEG

Colour

(K)...........Black Type

(S)...........Silver Type (only HC-V707EG)

TABLE OF CONTENTS

PAG E PAG E

1 Safety Precautions -----------------------------------------------3

1.1. General Guidelines ----------------------------------------3

1.2. Leakage Current Cold Check ---------------------------3

1.3. Leakage Current Hot Check (See Figure 1.) --------3

1.4. How to Discharge the Capacitor on Flash P.C.B.----------------------------------------------------------4

2Warning--------------------------------------------------------------5

2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices ----------5

2.2. How to Recycle the Lithium Ion Battery (U.S. Only)-----------------------------------------------------------5

2.3. Caution for AC Cord (For EB/GC) ---------------------6

2.4. How to Replace the Lithium Battery -------------------7

3 Service Navigation------------------------------------------------8

3.1. Introduction --------------------------------------------------8

3.2. General Description About Lead Free Solder (PbF) ----------------------------------------------------------8

3.3. Important Notice 1:(Other than U.S.A. and Canadian Market) ------------------------------------------8

3.4. How to Define the Model Suffix (NTSC or PAL model)---------------------------------------------------------9

3.5. Formatting-------------------------------------------------- 10

4 Specifications ---------------------------------------------------- 11 5 Location of Controls and Components------------------ 13 6 Service Mode ----------------------------------------------------- 17

6.1. Built-in Memory Self Check Execution (HCV700M/V707M only)------------------------------------- 18

6.2. Lock Search History Indication ----------------------- 18

6.3. Power ON Self Check Result Display--------------- 19

6.4. Forced full flash emission ------------------------------ 19

6.5. Erasing the lock histories ------------------------------ 20

6.6. Camera data indications while the video playback ---------------------------------------------------- 20

7 Service Fixture & Tools --------------------------------------- 21

7.1. When Replacing the Main P.C.B. -------------------- 21

7.2. Service Position ------------------------------------------ 21

8 Disassembly and Assembly Instructions --------------- 23

8.1. Disassembly Flow Chart for the Unit ---------------- 23

8.2. PCB Location---------------------------------------------- 23

8.3. Disassembly Procedure for the Unit ---------------- 24

9 Measurements and Adjustments -------------------------- 34

9.1. Electric Adjustment --------------------------------------34

10 Factory Setting--------------------------------------------------- 36

10.1. How To Turn On The Factory Settings? ------------ 36

10.2. What Is The Factory Settings? ----------------------- 37

11 Blo ck Diagr am --------------------------------------------------- 38

11.1. Overall Block Diagram ----------------------------------38

11.2. Camera/System Control Circuit Block Diagram----------------------------------------------------- 39

11.3. Video/Audio Signal Process(1) Circuit Block Diagram----------------------------------------------------- 40

11.4. Video/Audio Signal Process(2) Circuit Block Diagram----------------------------------------------------- 41

11.5. Lens Drive Circuit Block Diagram -------------------- 42

11.6. Power Supply Circuit Block Diagram---------------- 43

12 Wiring Connection Diagram --------------------------------- 44

12.1. Interconnection Diagram ------------------------------- 44

1 Safety Precautions

1.1. General Guidelines

1. IMPORTANT SAFETY NOTICE There are special components used in this equipment which are important for safety. These parts are marked by

in the Schematic Diagrams, Circuit Board Layout, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent X-RADIATION, shock, fire, or other hazards. Do not modify the original design without permission of manufacturer.

2. An Isolation Transformer should always be used during the servicing of AC Adaptor whose chassis is not isolated from the AC power line. Use a transformer of adequate power rating as this protects the technician from accidents resulting in personal injury from electrical shocks. It will also protect AC Adaptor from being damaged by accidental shorting that may occur during servicing.

3. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit.

4. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.

5. After servicing, make the following leakage current checks to prevent the customer from being exposed to shock hazards.

1.2. Leakage Current Cold Check

1. Unplug the AC cord and connect a jumper between the two prongs on the plug.

2. Measure the resistance value, with an ohmmeter, between the jumpered AC plug and each exposed metallic cabinet part on the equipment such as screwheads, connectors, control shafts, etc. When the exposed metallic part has a return path to the chassis, the reading should be between 1 MΩ and 5.2 MΩ. When the exposed metal does not have a return path to the chassis, the reading must be infinity.

1.3. Leakage Current Hot Check (See Figure 1.)

1. Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check.

2. Connect a 1.5 kΩ, 10 W resistor, in parallel with a 0.15 μF capacitor, between each exposed metallic part on the set and a good earth ground, as shown in Figure 1.

3. Use an AC voltmeter, with 1 kΩ/V or more sensitivity, to measure the potential across the resistor.

4. Check each exposed metallic part, and measure the voltage at each point.

5. Reverse the AC plug in the AC outlet and repeat each of the above measurements.

6. The potential at any point should not exceed 0.75 V RMS. A leakage current tester (Simpson Model 229 or equivalent) may be used to make the hot checks, leakage current must not exceed 1/2 mA. In case a measurement is outside of the limits specified, there is a possibility of a shock hazard, and the equipment should be repaired and rechecked before it is returned to the customer.

Figure. 1

1.4. How to Discharge the Capacitor on Flash P.C.B.

CAUTION:

1. Be sure to discharge the capacitor on FLASH P.C.B..

2. Be careful of the high voltage circuit on FLASH P.C.B. when servicing.

Before disassembling, perform "6.4. Forced full flash emission" for discharging capacitor. The capacitor also can be discharged according to the following procedures.

[Discharging Procedure]

1. Refer to the disassemble procedure and Remove the necessary parts/unit.

2. Put the insulation tube onto the lead part of Resistor (ERG5SJ102:1kΩ /5W). (an equivalent type of resistor may be used.)

3. Put the resistor between both terminals of capacitor on FLASH P.C.B. for approx. 5 seconds.

4. After discharging confirm that the capacitor voltage is lower than 10V using a voltmeter.

Fig. F1

2Warning

2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices

Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor "chip" components. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD).

1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap, which should be removed for potential shock reasons prior to applying power to the unit under test.

2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly.

3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.

4. Use only an antistatic solder removal device. Some solder removal devices not classified as "antistatic (ESD protected)" can generate electrical charge sufficient to damage ES devices.

5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.

6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or comparable conductive material).

7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material to the chassis or circuit assembly into which the device will be installed.

CAUTION :

Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.

8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD) sufficient to damage an ES device).

2.2. How to Recycle the Lithium Ion Battery (U.S. Only)

2.3. Caution for AC Cord (For EB/GC)

2.3.1. Information for Your Safety

IMPORTANT

Your attention is drawn to the fact that recording of prerecorded tapes or discs or other published or broadcast material may infringe copyright laws.

WARNING

To reduce the risk of fire or shock hazard, do not expose this equipment to rain or moisture.

CAUTION

To reduce the risk of fire or shock hazard and annoying interference, use the recommended accessories only.

FOR YOUR SAFETY

DO NOT REMOVE THE OUTER COVER

To prevent electric shock, do not remove the cover. No user serviceable parts inside. Refer servicing to qualified service

personnel.

2.3.2. Caution for AC Mains Lead

For your safety, please read the following text carefully.

This appliance is supplied with a moulded three-pin mains plug for your safety and convenience. A 5-ampere fuse is fitted in this plug. Should the fuse need to be replaced please ensure that the replacement fuse has a rating of 5 amperes and it is approved by ASTA or BSI to BS1362 Check for the ASTA mark or the BSI mark on the body of the fuse.

If the plug contains a removable fuse cover you must ensure that it is refitted when the fuse is replaced. If you lose the fuse cover, the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer.

If the fitted moulded plug is unsuitable for the socket outlet in your home then the fuse should be removed and the plug cut off and disposed of safety. There is a danger of severe electrical shock if the cut off plug is inserted into any 13-ampere socket.

If a new plug is to be fitted please observe the wiring code as shown below. If in any doubt, please consult a qualified electrician.

2.3.2.1. Important

The wires in this mains lead are coloured in accordance with the following code:

As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:

The wire which is coloured BLUE must be connected to the terminal in the plug which is marked with the letter N or coloured BLACK.

The wire which is coloured BROWN must be connected to the terminal in the plug which is marked with the letter L or coloured RED.

Under no circumstances should either of these wires be connected to the earth terminal of the three pin plug, marked with the letter E or the Earth Symbol.

2.3.2.2. Before Use

Remove the Connector Cover as follows.

2.3.2.3. How to Replace the Fuse

1. Remove the Fuse Cover with a screwdriver.

2. Replace the fuse and attach the Fuse cover.

Blue Neutral Brown Live

2.4. How to Replace the Lithium Battery

2.4.1. Replacement Procedure

1. Remove the MIC P.C.B.. (Refer to Disassembly Procedures.)

2. Unsolder the each soldering point of electric lead terminal for Lithium battery (Ref. No. “B4801” at component side of MIC P.C.B.) and remove the Lithium battery together with electric lead terminal. Then replace it into new one.

NOTE:

The Type No. ML-614S/DK includes electric lead terminals.

NOTE:

This Lithium battery is a critical component. (Type No.: ML-614S/DN Manufactured by Energy Company, Panasonic Corporation) It must never be subjected to excessive heat or discharge. It must therefore only be fitted in requirement designed specifically for its use. Replacement batteries must be of same type and manufacture. They must be fitted in the same manner and location as the original battery, with the correct polarity contacts observed. Do not attempt to re-charge the old battery or re-use it for any other purpose. It should be disposed of in waste products destined for burial rather than incineration.

NOTE:

Above caution is applicable for a battery pack which is for HC-V700/V707/V700M/V707M series, as well.

1. Battery Pack for this model.

3 Service Navigation

3.1. Introduction

This service manual contains technical information, which allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, the information will be followed by service manual to be controlled with original service manual.

3.2. General Description About Lead Free Solder (PbF)

The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this equipment in considering the globally environmental conservation. The normal solder is the alloy of tin (Sn) and lead (Pb). On the other hand, the lead free solder is the alloy mainly consists of tin (Sn), silver (Ag) and Copper (Cu), and the melting point of the lead free solder is higher approx.30°C (86°F) more than that of the normal solder.

Distinction of P.C.B. Lead Free Solder being used

Service caution for repair work using Lead Free Solder (PbF)

• The lead free solder has to be used when repairing the equipment for which the lead free solder is used. (Definition: The letter of “PbF” is printed on the P.C.B. using the lead free solder.)

• To put lead free solder, it should be well molten and mixed with the original lead free solder.

• Remove the remaining lead free solder on the P.C.B. cleanly for soldering of the new IC.

• Since the melting point of the lead free solder is higher than that of the normal lead solder, it takes the longer time to melt the lead free solder.

• Use the soldering iron (more than 70W) equipped with the temperature control after setting the temperature at 350±30°C (662±86°F).

Recommended Lead Free Solder (Service Parts Route.)

• The following 3 types of lead free solder are available through the service parts route. RFKZ03D01KS-----------(0.3mm 100g Reel) RFKZ06D01KS-----------(0.6mm 100g Reel) RFKZ10D01KS-----------(1.0mm 100g Reel)

Note

* Ingredient: tin (Sn) 96.5%, silver (Ag) 3.0%, Copper (Cu) 0.5%, Cobalt (Co) / Germanium (Ge) 0.1 to 0.3%

3.3. Important Notice 1:(Other than U.S.A. and Canadian Market)

1. The service manual does not contain the following information, because of the impossibility of servicing at component level

without concerned equipment/facilities.

a. Schematic diagram, Block Diagram and P.C.B. layout of MAIN P.C.B.. b. Parts list for individual parts for MAIN P.C.B..

When a part replacement is required for repairing MAIN P.C.B., replace as an assembled parts. (Main P.C.B.)

2. The following category is /are recycle module part. Please send it/them to Central Repair Center.

• MAIN P.C.B. (VEP03J48B: HC-V700MP/PC/PU/GK, HC-V707MEG)

• MAIN P.C.B. (VEP03J48C: HC-V700P/PC/EB/EC/EE/EF/EG/EP/GC/GK/GN, HC-V707EG)

3.4. How to Define the Model Suffix (NTSC or PAL model)

There are eight kinds of HC-V700/V707/V700M/V707M.

• a) HC-V700M, V600M (Japan domestic model)

• b) HC-V700P, V700MP

• c) HC-V700PC, V700MPC

• d) HC-V700EB/EC/EF/EG/EP/GN

• e) HC-V707EG, V707MEG

• f) HC-V700EE

• g) HC-V700GK, V700MGK

• h) HC-V700GC, V700MPU

What is the difference is that the “INITIAL SETTING” data which is stored in Flash ROM mounted on Main P.C.B..

3.4.1. Defining methods:

To define the model suffix to be serviced, refer to the rating label and caution label which are putted on the Unit.

NOTE:

After replacing the MAIN P.C.B., be sure to achieve adjustment. The adjustment instruction is available at “software download” on the “Support Information from NWBG/VDBG-AVC” web-site in “TSN system”, together with Maintenance software.

3.5. Formatting

4 Specifications

5 Location of Controls and Components

1 Shoe adaptor release lever

[SHOE ADAPTOR RELEASE]

2 Intelligent auto/Manual button

[iA/MANUAL]

3 Optical image stabilizer button

[ O.I.S.] 4 USB terminal [ ] 5 1080/60p button [1080/60p] (NTSC areas)

6 Power button [ ] 7 Battery release lever [BATT] 8 HDMI mini connector [HDMI] 9 AV multi connector [AV MULTI]

●

Use the AV multi cable (only the supplied cable).

10 Microphone terminal [MIC]

●

A compatible plug-in powered microphone can be used as an external microphone.

●

Audio will be stereo (2 ch) with the external microphone input.

●

(Microphone input level meter) is displayed when the external microphone is connected.

●

When the unit is connected with the AC adaptor, sometimes noise may be heard depending on the microphone type. In this case, please switch to the battery for the power supply and the noise will stop.

123

5 6

AV MULTI

810

1080/50p button [1080/50p] (PAL areas)

11 Speaker 12 Internal stereo microphones 13 Lens cover

●

The lens cover opens in Motion Picture Recording Mode or Still Picture Recording Mode.

14 Built-in flash 15 Step up ring attachment part

(concave) 16 Lens 17 Video light

14 15

18 Shoe adaptor mount

[SHOE ADAPTOR]

19 Status indicator 20 Recording start/stop button 21 LCD monitor (Touch screen)

●

It can open up to 90Q.

●

It can rotate up to 180Q  towards the lens or 90Qtowards the opposite direction.

22 Battery holder

2221

Due to limitations in LCD production technology, there may be some tiny bright or dark spots on the LCD monitor screen. However, this is not a malfunction and does not affect the recorded picture.



23 Tripod receptacle

●

If you attach a tripod with a 5.5 mm (0.22 S) screw or larger, it may damage this unit.

24 SD card cover 25 Access lamp [ACCESS] 26 Card slot

27 Photoshot button [ ] 28 Zoom lever [W/T] (In Motion Picture

Recording Mode or Still Picture Recording Mode) Thumbnail display switch [ / ]/ Volume lever [UVOLT] (In Playback Mode)

29 Mode switch 30 Grip belt

Adjust the length of the grip belt so that it fits your hand.

 Flip the belt.  Adjust the length.  Replace the belt.

31 DC input terminal [DC IN]

●

Do not use any other AC adaptors except the supplied one.







Slide the mode switch to switch between recording and playback.

Operate the mode switch to change the mode to , or .

You can operate by directly touching the LCD monitor (touch screen) with your finger.

■ Touch

Touch and release the touch screen to select icon or picture.

●

Touch the center of the icon.

●

Touching the touch screen will not operate while you are touching another part of the touch screen.

■ Slide while touching

Move your finger while pressing on the touch screen.

Selecting a mode

Motion Picture Recording Mode

Still Picture Recording Mode

Playback Mode

How to use the touch screen

■ About the operation icons

///: These icons are used to switch the menu and thumbnail display page, for item selection and setting etc.

Touch to return to the previous screen such as when setting menus.

About the Touch Menu

Touch (left side)/ (right side) of on the Touch Menu to switch the operation icons.

Touch (left side)/ (right side) of on the Touch Menu.

●

It is also possible to switch the operation icons by sliding the Touch Menu right or left while touching it.

 You can change the operation icons to display.  Displayed only during the Manual Mode.  Displayed only when connected to a TV.

■ To display the Touch Menu

 Touch Menu

edoMkcabyalPedoMgnidroceR

Display of the Touch menu will disappear when no touch operation is performed for a specific period of time. To display it again, touch .



FOCUS

SHTR

IRIS





ALL

'ĺ'



●

Do not touch on the LCD monitor with hard pointed tips, such as ball point pens.

6 Service Mode

1. Indication method of the service menu Set the mode switch “Motion Picture Recording” mode.

2. While the power is turned OFF, keep pressing the “Power” button, “Zoom lever” to W side and “intelligent auto/Manual” button for more than 3 seconds until the top screen of the Service Mode Menu being displayed.

Service mode menu

NOTE:

Do not using service mode except above table of Service mode menu.

3. End method of the top screen of the service mode menu Touch the [ EXIT ] of LCD to end the service mode, and then POWER OFF.

Screen display Contents Function

1 Factory settings Function to throw a product up in a factory shipment state

(When recorded data in Built-in memory, “error display” is done)

3 Built-in memory self check execution

(HC-V700M/V707M only)

Function to check self as for the state of Built-in memory

4 Lock search history indication Display the camera system error cord for three histories saved

in EEPROM

5 Power ON self check result display Power ON self check (function to diagnose correct function of

the device and interface between devices) result display

9 Forced full flash emission Forced full flash emission for discharging the capacitor on

FLASH P.C.B. and set to prohibit charge 10 Erasing the lock histories Erasing the error histories (working time is not erased) 12 Camera data indications while the

video playback

Display the camera informations (Shutter speed, Iris value,

White balance and focal length) while playing recorded video

6.1. Built-in Memory Self Check Execution (HC-V700M/V707M only)

Touch the [ 3 ] of LCD, select Built-in memory self check execution.

Operation specifications

Indication contents

• Built-in memory self check result display Display the Built-in memory self check execution. Displays other than “OK” are abnormalities of Built-in memory.

Touch the [ BAK ] of LCD to end the service mode, and then POWER OFF.

6.2. Lock Search History Indication

Touch the [ 4 ] of LCD, select Lock search history indication.

Operation specifications

Indication contents

• Lock search history indication Display the camera system error cord for three histories saved in EEPROM.

• The error cord contents which are displayed

Touch the [ BAK ] of LCD to end the service mode, and then POWER OFF.

Error code Function

51 Focus control is abnormal 52 Zoom control is abnormal 53 OIS lens control is abnormal 54 Zoom control is abnormal (2) 71 Lens cover open/close is abnormal 73 High temperature is abnormal

6.3. Power ON Self Check Result Display

Touch the [ 5 ] of LCD, select Power ON self check result display.

Operation specifications

Indication contents

• Power ON self check result display Function to diagnose correct function of the device and interface between devices result display.

Display the following communication test result.

- CAM-PWR : communication test between IC3401 and IC1503

- CAM-UNI : Internal communication test of IC3401

Display other than “OK” are abnomalities of each lines.

Cutting of battery connection or AC power supply connection to end the service mode.

6.4. Forced full flash emission

Touch the [ 9 ] of LCD, select Forced full flash execution.

Operation specifications

Indication contents

• Discharging the capacitor without using register. Forced full flash emission for charge capacitor completely discharge. To prevent electric shock, we recommend enforcement before disassembling.

Cutting of battery connection or AC power supply connection to end the service mode.

6.5. Erasing the lock histories

Touch the [ 10 ] of LCD, select erasing the lock histories execution.

Operation specifications

Indication contents

• Erasing the error histories stored in EEPROM. (working time is not erased)

Cutting of battery connection or AC power supply connection to end the service mode.

6.6. Camera data indications while the video playback

Touch the [ 12 ] of LCD, select indicating the camera informations while playing back the recorded video.

Operation specifications

Indication contents

• While playing back the recorded videos, the camera informations (Shutter speed, Iris value, White balance and focal length) are superimposed on the LCD screen.

Press the power button and turn off.

7 Service Fixture & Tools

7.1. When Replacing the Main P.C.B.

7.2. Service Position

This Service Position is used for checking and replacing parts. Use the following Extension cables for servicing.

Table S1 Extension Cable List

No. Parts No. Connection Form 1 RFKZ0487 FP6001(MAIN) - MONITOR FPC 35PIN 0.3 FFC 2 RFKZ0444 PP6001(MAIN) - PS6401(SD HOLDER) 50PIN 0.5 B to B 3 VFK1480 FP6010(MAIN) - ECM HOLL FPC(FRONT CASE UNIT) 6PIN 0.5 FFC 4 VFK1388 FP6004(MAIN) - FP7001(FLASH) 12PIN 0.5 FFC 5 VFK1441 FP6005(MAIN) - LENS BARRIER UNIT 8PIN 0.5 FFC 6 VFK1440 FP4803(SD HOLDER) - OPERATION SW UNIT(TOP CASE UNIT) 10PIN 0.5 FFC

CAUTION-1. (When servicing FLASH P.C.B.)

1. Be sure to discharge the capacitor on FLASH P.C.B.. Refer to “HOW TO DISCHARGE THE CAPACITOR ON FLASH P.C.B.”. The capacitor voltage is not lowered soon even if the AC Cord is unplugged or the battery is removed.

2. Be careful of the high voltage circuit on FLASH P.C.B..

3. DO NOT allow other parts to touch the high voltage circuit on FLASH P.C.B..

8 Disassembly and Assembly Instructions

8.1. Disassembly Flow Chart for the Unit

This is a disassembling chart. When assembling, perform this chart conversely.

8.2. PCB Location

8.3. Disassembly Procedure for the Unit

No. Item Fig Removal

1 Side Case-L Unit (Fig. D1) 2 Screws (A)

1 Screws (B) 2 Screws (C)

(Fig. D2) 2 Screws (D)

1 Screw (E) 2 Locking tabs P6005 (Connector) Side Case-L Unit

2 Top Case Unit (Fig. D3) 1 Screw (F)

1 Screw (G) 1 Rib 5 Locking tabs FP4803 (Flex) P6401 (Connector) Top Case Unit

3ESD P.C.B.

(HC-V700M/V707M only)

(Fig. D4) 2 Screws (H)

FP3201 (Flex) ESD P.C.B.

4 Front Case Unit (Fig. D5) 1 Screw (I)

2 Screws (J) P4801 (Flex)

(Fig. D6) P7001(Connector)

P7002 (Connector) 2 Locking tabs 1 Rib

(Fig. D7) FP6010 (Flex)

Front Case Unit

5 Lens Frame Unit (Fig. D8) 1 Screw (K)

3 Screws (L) 2 Locking tabs 1 Projection Part 1 Rib FP4802 (Flex) FP6004 (Flex) FP6005 (Flex) Lens Frame Unit

(Fig. D9) Discharge the capacitor

6 Lens Unit (Fig. D10) FP6008 (Flex)

P6001 (Connector) Lens Unit

7 Main P.C.B.

SD Holder P.C.B.

(Fig. D11) 4 Screws (M)

Batt Frame Heat Radiation Plate Unit

(Fig. D12) P6003 (Connector)

FP6001 (Flex)

(Fig. D13) FP3201 (Flex)

Main P.C.B. SD Holder P.C.B.

8 Monitor P.C.B. &

Light Guide Plate Unit LCD Panel Unit

(Fig. D14) 1 Screw (O) (Fig. D15) 1 Screw (P)

2 Screws (Q) 6 Locking tabs LCD Case (T) Unit FP901 (Flex) FP904 (Flex) FP905 (Flex)

(Fig. D16) 3 Locking tabs

Monitor P.C.B. & Light Guide Plate Unit LCD Panel Unit

9 Monitor P.C.B. (Fig. D17) 1 Locking tab

1 Hanging part Monitor P.C.B.

10 MOS Unit

IR Filter

(Fig. D18) 3 Screws (S)

MOS Shield Case Unit Lens Sheet MOS Unit MOS Cushion IR Filter

11 2nd Lens Frame Unit

Stepping Motor 4th Lens Frame Unit Stepping Motor

(Fig. D19) 3 Screws (T)

Solder (4 points) 2 Projection Part 2nd Lens Frame Unit Stepping Motor

(Fig. D20) 2 Screws (U)

Solder (6 points) 2 Projection Part 4th Lens Frame Unit Stepping Motor

No. Item Fig Removal

8.3.1. Removal of the Side Case-L Unit

(Fig. D1)

(Fig. D2)

8.3.2. Removal of the Top Case Unit

(Fig. D3)

8.3.3. Removal of the ESD P.C.B. Unit (HC-V700M/V707M only)

(Fig. D4)

8.3.4. Removal of the Front Case Unit

(Fig. D5)

(Fig. D6)

(Fig. D7)

8.3.5. Removal of the Lens Frame Unit

(Fig. D8)

(Fig. D9)

8.3.6. Removal of the Lens Unit

(Fig. D10)

8.3.7. Removal of the Main P.C.B. and SD Holder P.C.B.

(Fig. D11)

(Fig. D12)

(Fig. D13)

8.3.8. Removal of the Monitor P.C.B. & Light Guide Plate Unit and LCD Panel Unit

(Fig. D14)

(Fig. D15)

(Fig. D16)

8.3.9. Removal of the Monitor P.C.B.

(Fig. D17)

8.3.10. Removal of the MOS Unit and IR Filter

(Fig. D18)

8.3.11. Removal of the 2nd Lens Frame Unit Stepping Motor and 4th Lens Frame Unit Stepping Motor

(Fig. D19)

(Fig. D20)

9 Measurements and Adjustments

9.1. Electric Adjustment

• Adjustment method is different from a conventional High definition video camera.

• An exclusive jig and PC (including software for adjustment “Tatsujin”) are necessary for electric adjustment.

• A USB driver for service is necessary to communication with PC.

• Connection method of the main unit and an exclusive adjustment jig as follows

9.1.1. Adjustment Procedure

• Connect the main unit to PC with USB. The adjustment instruction is available at "Software download" on the "Support Information from NWBG/VDBG-AVC" web-site in "TSN System".

Figure of connection

Figure of image when adjustment

Part Number of jig

• Only a necessary jig mentions it in setup of electric adjustment.

No. Part Name Part Number Remarks

1 PC -----2 AC Adaptor -----3 USB Cable -----4 Adjustment Software (Tatsujin) -----5 C4 Filter VFK1164LBB4 The same as C12 Filter (VFK1164LBB12). 6 C8 Filter VFK1164LBB8

Adjustment Items

• Adjustment item as follows. The adjustment instruction is available at "Software download" on the "Support Information from NWBG/VDBG-AVC" web-site in "TSN System".

10 Factory Setting

10.1. How To Turn On The Factory Settings?

1. Set the mode switch “Motion Picture Recording” mode.

3. Touch the [ 1 ] of LCD.

4. Touch the [ YES ] of LCD.

5. After few seconds “END” is displayed or “ESD NODATA” as “NG” is displayed on LCD monitor. Cutting of battery connection or AC power supply connection as a completion of the “FACTORY SETTINGS”. (After recording at least once, even if the physical format of the build-in memory will be performed, “ESD NODATA” as “NG” is indicated, but “FACTORY SETTINGS” is completed.)

10.2. What Is The Factory Settings?

The factory settings clean up and/or refresh the following settings.

1. MENU, MODE, ADJUSTMENT VALUE.

2. SD card format.

3. Reset the folder number and file number of still pictures. (Setting the folder number is 100, and file number is 0.)

4. Clear the mechanism lock information.

5. Clear the service mode information contents.

6. Close the lens cover

7. Initialize the VIERA Link Physical Address.

(HC-V700M/V707M) If the "Factory Settings" is completed, physical format of the build-in memory is not performed, execute physical format according to the following procedure.

The setting position of factory settings:

Name Setting position

Mode switch Motion picture recording mode

11 Block Diagram

11.1. Overall Block Diagram

OVERALL BLOCK DIAGRAM

IRIS

LENS(F1.8-3.5 21x)

IC701 LENS/OIS DRIVE

IC7001 FLASH CHARGE CONTROL

SD CARD

SPEAKER

ECM

OPERATION

TOUCH PANEL

DC IN

BATTERY

FLASH

SHUTTER

IC101 MOS IMAGE SENSOR

A/V MULTI TERMINAL

HDMI mini CONNECTOR

ZOOM/ FOCUS MOTOR/ OIS

Analog

IC6401 GYRO SENSOR (PIT/YAW)

IC6411 GYRO SENSOR (ROLL)

IC3403 NAND FLASH ROM/ 512Mbit

IC3402 DDR MOBILE RAM/ 512Mbit

IC3401 MPEG CODEC (SPICa)

IC1001 POWER

IC1502 BATTERY MONITOR

NOTE

: VIDEO SIGNAL

: AUDIO SIGNAL

: CLK or CONTROL LINE

LED LIGHT

X3402 OSC

(54MHz)

IC102,302 GATE IC

IC4801 3D

ADAPTOR

DET.

IC901 LCD DRIVER

COLOR LCD P

ANEL

IC3701 AVIO

INTERNAL MEMORY

IC705,707 LENS SHUTTER DRIVE

X2303

(32.768kHz)

IC1503 RTC/CHARAGE/ POWER CONTROL

USB TERMINAL

IC301,304,703,704,1002,1011, 1301,1421,1431,1471 REGULATOR

HC-V700M/V707M/V700/V707 OVERALL BLOCK DIAGRAM

IC706 MOTOR DRIVE

IC761 ROLL GYRO AMP

IC2301 RESET

IC1501 VOLTAGE DET.

IC902 MAGNETIC SENSOR

EXT. MIC

Analog

IC4803 MIC AMP

/16GB

IC3405 RESET

IC3201

HC-V700M/V707M only

11.2. Camera/System Control Circuit Block Diagram

IC3401

(MEPEG CODEC)

CAMERA/SYSTEM CONTROL CIRCUIT BLOCK DIAGRAM

TOP CASE OPERATION SWITCH UNIT

X2303

(32.768kHz)

PW REG3V

S6001

LCD OPEN/CLOSE

CARD LED B

STANDBYLED B

KEYIN2

KEYIN4

POWER LED B

KEYIN1

D6401

CARD

LED

PW REG3V

QR6402

FP4803

STANDBY LED

AVREF

VTR KEY 4

VTR KEY 1

ZOOMAD

FP905

X RIGHT

Y BOT

X LEFT

Y TOP

POWER LED

PW REG3V

V31

N29

P29

P30

P31

C28

B28

A29

B29

D27

U30

PW REG3V

QR6006

QR6403

R30

QR3413 QR3411

QR3412

QR3410

A27

S6551

TOUCH PANEL

UNIT

QR6007

S/S SW

S6404

1080/60P

RL6551

RL6552

A28

W29

IC1503

(RTC/CHARGE/POWER CONTROL)

S6401

POWER ON/OFF

/SWIN1

/SWIN2

XIN

XOUT

LED

IC902

(MAGNETIC SENSOR)

431

VDD

OUT

GND

MODE SWITCH

ZOOM LEVER

PHOTO SHOT BUTTON

HC-V700M/V707M/V700/V707 CAMERA/SYSTEM CONTROL CIRCUIT BLOCK DIAGRAM

AD TPY RIGHT

AD TPY LEFT

AD TPX TOP

SEL2 ON LOW

SEL2 ON HI

LCD RVS

SEL1 ON HI

SEL1 ON LOW

AD TPX BOT

DI CHA

DO CHA

CLK CHA

CS CHA

L31

L30

L29

K31

SCK

SDI

SDO

CH3422

CH3423

CH3424

QR3403

PW RTCVREG32

ZSW (To IC701-49)

IC101

(MOS IMAGE SENSOR)

AJ30

LVACH1DOP LVACH1DOM

LVACH2DOP

LVACH2DOM

LVACH3DOP LVACH3DOM

LVACH4DOP

LVACH4DOM

LVACLKP

LVACLKM

AJ31 AH28

X3402

(54MHz)

1432

IC302

(GATE IC)

CH301

CH3419 CH3420 CH3421CK104 CK108

PW MOS1.8V

SDOD0P SDOD0M SDOD1P

AH29

AH30 AH31

SDOD1M SDOD2P SDOD2M

AG28

SDOD3P

AG29

AG30 AG31

SDOD3M SDOD4P SDOD4M

RL3401 RL3402 RL3403 RL3404

IC3405

(RESET)

XRST

VDD

PW REG3V

AB31

CKIN

AE1

MOSCLK ON H

B16

GLVDL PORL

AF25

IC3403

(NAND FLASH ROM/512Mbit)

VCC(CORE)

VCC(IO)

OUT

BUS283 A D1P BUS283 A D1M BUS283 A D2P

BUS283 A D2M

BUS283 A D3P BUS283 A D3M BUS283 A D4P

BUS283 A D4M

BUS283 A CKP BUS283 A CKM

AF28

LVBCH1DOP LVBCH1DOM

LVBCH2DOP

LVBCH2DOM

LVBCH3DOP LVBCH3DOM

LVBCH4DOP

LVBCH4DOM

LVBCLKP

LVBCLKM

AF29 AE28

SDODAP

SDODAM

SDOD9P

AE29

AF30 AF31

SDOD9M SDOD8P SDOD8M

AE30

SDOD7P

AE31 AD28 AD29

SDOD7M SDOD6P SDOD6M

RL3405 RL3406 RL3407 RL3408

BUS283 B D1P BUS283 B D1M BUS283 B D2P

BUS283 B D2M

BUS283 B D3P BUS283 B D3M BUS283 B D4P

BUS283 B D4M

XVD CAM

HDL BUSY

AF24

XHD CAM

DO SENS

AH22

S SENS SDO

CLK SENS

AF21

SCK

S SENS SCK

CS SENS

AH21

SCS

S SENS CS

MOS RST

AE20

RST N

E MOS RST

MOSCLK ON H

BUS283 B CKP BUS283 B CKM

BUS324 A D0P BUS324 A D0M BUS324 A D1P

BUS324 A D1M

BUS324 A D2P BUS324 A D2M BUS324 A D3P

BUS324 A D3M

BUS324A CKP BUS324 A CKM

BUS324 B D0P BUS324 B D0M BUS324 B D1P

BUS324 B D1M

BUS324 B D2P BUS324 B D2M BUS324 B D3P

BUS324 B D3M

VD SENS HD SENS

SDATA SENS

SCK SENS

SCS SENS

RST SENS

PSV

RST SENS

MCLK

CLK54 MOS

BUS324 B CKP BUS324 B CKM

1432

IC102

(GATE IC)

PW MOS1.8VD

CK107

CK105

CK102

CK103

CK106

PW FROM1.8V

11.3. Video/Audio Signal Process(1) Circuit Block Diagram

1 MOS

SENSOR

CAMERA SECTION

IC3401

(MPEG CODEC)

VIDEO/AUDIO SIGNAL PROCESS(1)CIRCUIT BLOCK DIAGRAM

USBTERMINAL

D-

D+

D1N LCD

D1P LCD

ABCK1

SCL AVIO

SDA AVIO

Y PB PR

AODAT

AODAT0

AIDAT0

CLK B1

JK6402

ADM0

ADM15

ECLK NFCYC

XECS0 XNFCE

XEWE XNFWE

XERE XNFRE

XAVD NFALE

NANDRYBY

FROM INT XNFWP

AC4

C2 D1 E4

LPD0CLK

LPD0XCLK

LPD0CKE

LPD0CS

LPD0WE

LPD0CAS

LPD0RAS

P2 N4P1M3 N3 R4

LPD0BA1

LPD0BA0

T4 R3N2

AMCK

CLK12 M

ALRCK1 CLK LR1

A13 A12

N30 N31

A14

MEMORY CONTROL

MAIN CPU

HDMI

CONTROL

CAMERA

DSP

H.264

MPEG2

JPEG

AC3/5.1CH

PROCESSOR

HDMI DMA I/F

CAMERA SIGNALP ROCESSOR

AUDIO DSP

DATA

IC3403

(NAND FLASH ROM/512M-bit)

AL7

AK7

D0P LCD

AL5

D0N LCD

AK5

CLKP LCD

AL6

AK11

AJ11

AL11

AE11

AF11

18 19 36 53 56

1478

21 28

CTL SIG

AIDAT

AL24

AL25

Y31

HC-V700M/V707M/V700/V707 VIDEO/AUDIO SIGNAL PROCESS(1) CIRCUIT BLOCK DIAGRAM

CLK+

CLK-

LCD LVDS1P

LCD LVDS1N LCD LVDS0P

LCD LVDS0N

LCD LVDSCLKP LCD LVDSCLKN

USB ID DET L

PW 3.2V

S CLKAVIO S SDA

AVIO

G HDYSDY G PBSDC

G PR

VREF

E A

VIO RST

AJ10 B14

EAVIO RST

CLKN LCD

AK6

DO LCD

AL9

CLK LCD

AK9

S DO LCD

S CLK LCD S CS LCD

CS LCD

AK10

STREAM CONTROL

AJ30

LVACH1DOP LVACH1DOM

LVACH2DOP

LVACH2DOM

LVACH3DOP LVACH3DOM

LVACH4DOP

LVACH4DOM

LVACLKP

LVACLKM

AJ31 AH28 AH29

AH30 AH31 AG28

AG29

AG30 AG31

BUS283 A D1P BUS283 A D1M BUS283 A D2P

BUS283 A D2M

BUS283 A D3P BUS283 A D3M BUS283 A D4P

BUS283 A D4M

BUS283 A CKP BUS283 A CKM

AF28

LVBCH1DOP LVBCH1DOM

LVBCH2DOP

LVBCH2DOM

LVBCH3DOP LVBCH3DOM

LVBCH4DOP

LVBCH4DOM

LVBCLKP

LVBCLKM

AF29 AE28 AE29

AF30 AF31 AE30

AE31

AD28 AD29

BUS283 B D1P BUS283 B D1M BUS283 B D2P

BUS283 B D2M

BUS283 B D3P BUS283 B D3M BUS283 B D4P

BUS283 B D4M

BUS283 B CKP BUS283 B CKM

IC3402

(DDR MOBILE RAM/512M-bit)

28 40

11 13 29 33 47 49

LPD0DQ0

LPD0DQ31

LPD0DM0

LPD0DM3

LPD0DQS0

LPD0DQS3

LPD0A0

LPD0A13

ADDRESS CTL SIG

17 26714 5259

62 71 73 85

DATA

DATA2+

DATA2-

DATA1+

DATA1-

DATA0+

DATA0-

HPD

SCL

SDA

CEC

1 8

FL6001

3 6

1 8

FL6002

3 6

PW 3.2V

JK6003

HDMI CONNECTOR

AK18

TX2P

AK14

AJ13

CEC

HPD

AK13

SDA

AL13

SCL

AL18

TX2M

AK17

TX1P

AL17

TX1M

AK16

TX0P

AL16

TX0M

AK15

TXCP

AL15

TXCM

QR3402

Q3401

QR3401

To IC901 (LCD COLOR DRIVER)

To LCD UNIT

To IC3701 (AVIO)

CH3426 CH3425

PW REG3V

VRO

B13

7 8 9 1 2 5

D0 D1 D2 D3

CMD

CLK

C.DET

U3 V1 U2

V3 T2 T1

HS3901 (SD CARD CONNECTOR)

CD0 CD1

CD2 CD3 CMD SDCLK

CDT

INTERNAL MEMORY/16GB

DAT0 DA

T1 DAT2 DAT3

G20 F20 F21 G21

C20

C19

CLK

CMD

SDCLK2

SDCMD2

H3 H4

H5 J2

SDDATA2 0 SDDATA2 1

SDDATA2 2 SDDATA2 3

HC-V700M/V707M only

IC3201

11.4. Video/Audio Signal Process(2) Circuit Block Diagram

ECM[R]

ECM[L]

IC4803

(MIC AMP)

816

Q4801

V-

V+

PW REG5V

PW 5V

PW REG5V

IC3701

(AVIO)

VIDEO/AUDIO SIGNAL PROCESS(2)CIRCUIT BLOCK DIAGRAM

SDIN

C BUS

LOGIC

CHARGE PUMP

AUDIO CODEC

SCL

SDA

ADRSEL

PRST

C PB IN

PR IN

Y IN

JK6002 (AV JACK)

VOUT

PLUGIN L

HDYOUT

PBOUT

PROUT

LOUT

ROUT

CLAMP

MUTE

GCA

LPF

DAC0

ADC0

ADC1

ADC2

EVR

SP N

SP P

SPEAKER

VOL

HPOUTL

HPOUT R

VCOMHP

VCOMHP FB

HD/SD LPF

Pb/C LPF

Pr/C LPF

28 26

YLPOUT

YDRIN

HDY OUT

PB OUT

PR OUT

V OUT

G HDYSDY

G PBSDC

G PR

S CLKAVIO

S SDAAVIO

EAVIO RST

AODAT0

MUTE

LPF

MIC SUPPLY

LINEOUTL

GNDAU

VOL

LINEOUT R

EVR

PW SPK3.2V

VCC SP

LPFALC

LPF

ALC

LPF

ALC

LPFALC

LPF

ALC

LPF

ALC

DET

LINEIN R

LINEIN

INT0 L

INT1 L

INT2 L

INT2 R

INT1 R

EXT1 L

EXT1 R

EXT2 L

EXT2 R

INT0 R

INT0 R2

INT0 L2

EXT0 L

EXT0 R

REG

P C1

GND P

P C2

VSS OUT

VREG

MUTE

MCLK

MIC VCC

BCLK1

WCLK1

CLK LR1

CLK B1

CLK12 M

SDOUT

AIDAT0

WCLK0

BCLK0

RL3707

RL3706

RL3705

RL3704

RL3701

HC-V700M/V707M/V700/V707 VIDEO/AUDIO SIGNAL PROCESS(2) CIRCUIT BLOCK DIAGRAM

EXT MIC

JK6001

MIC AMP

Q4901-4904, 4907,4908

LCD UINT

IC901

(LCD COLOR DRIVER)

D0+

D0-

R2 R3

G2 G3

G6 G7

PCLK

OUTPUT

CONFIGURATION

AND

POWER MANAGEMENT

PROTOCOL PARSING,

PARITY DETECTION,

ADVANCED

FRAME MIXING,

SYNC WORD

DECODING

DESERIALIZER

D1+

D1-

CLK+

CLK-

F/XS

XSD LS0 PSEL0 FM

FSS LS1 PSEL1

F2 G2 D4 D3 D5 E5 E4 E3

PLL

FSS

DDR SDR

PW REG1.8V

LCD LVDS1P

LCD LVDS1N

LCD LVDS0P

LCD LVDS0N

LCD LVDSCLKP

LCD LVDSCLKN

To IC3401 (MPEG CODEC)

N x PCLK

S DO LCD

S CLK LCD

S CS LCD

PLUG IN L

(To IC3401-E30)

EXT MIC L (To IC3401-AF10)

R6 R7

11.5. Lens Drive Circuit Block Diagram

LENS DRIVE CIRCUIT BLOCK DIAGRAM

FILTER

MOS

4G ZOOM MOTOR

IC701

(LENS/OIS DRIVE)

4G ZAP

4G ZAN

4G ZBN

4G ZBP

2G ZAP

2G ZBP

IC3401

(MPEG CODEC)

IRIS MOT

FOCUS MOTOR

FP6008

2G ZBN

2G ZAN

HALL

SENSOR

HALL

SENSOR

OIS UNIT

FP6008

PIT DRV+

PIT DRV-

PIT HO+

PIT HIN+

YAW DRV-

YAW DRV+

YAW HIN+

YAW HO-

PIT HO-

YAW HO+

IRM+

IRM-

FP6008

IR HO+

IR HIN+

IR HO-

IR HIN-

HALL

SENSOR

6 7 8

3 2 1

Q7005

PW REG3V

QR751

LESBALED CNT

PMP

IRHOP

IRHON

YMP

PHON

YMN

PHOP

PHINP

PMN

IRHINP

IRMP

IRMN

ZAP

ZAN

ZBN

ZBP

AFAN

AFAP

YHON

YHOP

YHINP

PW GYRO3V

GCSB

GSCK

GSI

GSO

GYRO1

NSCS

SCK

SDI(V2L)

SDO(L2V)

DAC LD

NPORI

HD225

NSCS LEN

SCK LEN

SDO LEN

VD60

FLASH

AFBN

FP6008

FMR B

FMR A

FOCUS

MR UNIT

MRA

MRB

AFBP

PW 3.2V

AL28

AK27

J30

J31

K29

G19

U31

CH712

CH727

CH728

CH711

CH726

CH7001

CH7002

CH7003

CH713

CH718

CH719

CH720

SDI LEN

DACLD LEN

E LENS RST

K30

J29

D30

CH721

CH722

CH723

PWMOUT1

PWMOUT2

FP6005

SHTR OPEN

OP LED

LENSBA MTA-

LENSBA MT B-

LENSBA MTA+

LENSBA MT B+

LENS

BARRIER

(GYRO SENSOR: PIT/YAW)

MOSI

MISO

CSB

CL6401

CL6406

CL6402

CL6403

SCLK

CL6404

VCC

VDD

PW GYRO3V

IC6411

IC6401

(GYRO SENSOR: ROLL)

IC761

(ROLL GYRO AMP)

NDHB

1 3

VOUT

CL6422

VREF

CL6411

VDD

PW REG1.8V

VccA

IC7001

(FLASH CHARGE CONTROLLER)

VREF

SDP

I/V

SDP

START

DRIVER

MAX ON

TIME

START

RADJ

UVLO

VCC

STB

FULL

SDP

STB

UVLO

TSD

MAX.ON

MAX. ON

OFF

LOGIC

MAX OFFTIME

VCC

PGND

RPGND

GND

FULL

IGBT IN

IGBT OUT

OFF

TRIGEND

W30

CHARGE

D17

CHAEND

T7001

PW STNOREG

TL7003

C7004

(For Flash Charge)

TL7002

TL7001

2GZOOM ENC

P 2GZABS LEN 4GZABS LEN

FP6008

4G ZLEDCONT

4G ZABS

2G ZABS

TOUT

QR775

2G ZLEDCONT

AA30

F31

2GZABS LEN

F30

F29

P 4GZABS LEN

E31

LENS TEMP

A25

GPIOB18

R29

LEDCONT LEN

ENABLE

FP6008

FMT+

FMT-

2G ZOOM MOTOR

IC4801

(3DADAPTOR DET.)

OUT

PW REG3V

PW 5V

VDD

GND

RL4805

D4301

FP6010

3D DET L

LED LIGHT CA

HD STBY LIGHT ON H

E29 W31

4GZOOM ENC

HC-V700M/V707M/V700/V707 LENS DRIVE CIRCUIT BLOCK DIAGRAM

CH715

CH714

CH717

CH716

IC706

(MOTOR DRIVE)

5 6

MREF

LIN PWM

VCC

QR773

Q773

PW LENS3.2V

Q6423

Q6421

(LENS SHUTTER DRIVE)

MN1

MN2

MP1

MP2

STB

SYSCK

IC705

FULLLENSBA H

Y30

IC707

(LEVEL SHIFTER)

CLK27LENS

AL27

PW REG3V

VccB

CK27M

PIT HIN-

YAW HIN-

FOCUS

ZOOM2

ZOOM1

11.6. Power Supply Circuit Block Diagram

POWER SUPPLY CIRCUIT BLOCK DIAGRAM

CL1461

DCG

LX7

FLT7

INV6

VREF5 INV4

VCC

INV7

PGND4 STB6

HS6L

HX567

LED

VO2S

LX1

PGND13

LX3

VO2

LX22

HX13

SELDRV

SCP

LX21

PGND2

INV1

STB5

HX4

UDSEL

VO7

VREGA

HX2

LX4

PWM7

STB1234

INV3

LX5

INV5

GND

PGND567

LX6

22 21 1820 1719 16 15 14 13 12

23 24 25 26 27 28 29 30 31 32 33

11 10 9 8 7 6 5 4 3 2

37 38 3940 413435 36

IC1001

(POWER)

JK6701

JK6401

HC-V700M/V707M/V700/V707 POWER SUPPLY CIRCUIT BLOCK DIAGRAM

BATTERY

DC IN

PW SPK3.2V

PW LENS3.2V

PW 3.2V

PW REG3V

CL1331

CL1422

PW VBUS

PW 5V

PW HDM5V

PW RTCVREG32

CL1301

CL1011

CL1421

CL1321

FUSE RESISTOR:

PW SD3.2V

1 3

QR1002

QR1001

QR1101

IC1301

(REGULATOR)

GND

VOUT

VIN

VBUS ON H (From IC3401-U29)

CL1351

CL1371

CL1471

IC1471

(REGULATOR)

GND

VOUT

VIN

NCCONT

VOUT

VIN

VCONT

IC1011

(REGULATOR)

GND

Q1501

2 3 4

IC1502

(BATTERY MONITOR)

1 2 3

5 6 7

23 22

313029

9 10 11 12

VSS CS

AFE DI AFE CLKIN

/RESET

OUT

LED CONT A0 VDD

AN0 P07

VIN12

BAT ON H

RIN

ISENS0

ISENS1

VREG

VNVSS

AFE DO

P01

VSS

20 19 18

CHG ON H

VIN2

T IN P06

13 14 15 16

AFE CLK OUT

BKUP CONT

RXD

TXD

28 27 26 25

VCC

AN3

AN2

AN1

Q1502

2 3 4

1 2 3

Q1503

IC3401

(MPEG CODEC)

DI CHA

DO CHA

CLK CHA

CS CHA

SW NOREG

FGMICOM RXD

FGMICOM TXD

FGMICOM SCK

CS FG

L31

L30

L29

K31

H31

H30

H29

G31 B25

T31

IC1501

(VOLTAGE DET.)

413

OUT

VSS

VDD

QR1503

PW STNOREG (To FLASH)

R1001

R1261

IC2301

(RESET)

124

VDD

GNDCDOUT

QR2308

CL1102

CL1105

CL1101

CL1103

Q1504

PW REG3V

BL CONT (From IC3401-AF7)

BATT RXD

AL29

USB DET H

T30

BATT TXD

G29

FG RST H

IC1503

(RTC/CHARGE/POWER CONTROL)

/SWIN3

VREG32

WKUP

USB

OUT

USBSW

T DEC

VREG25

(R1001/R1261/R6409)

Please check the Fuse Resistor when an output voltage does not output.

IP1502

IP6401

USBTERMINAL

VBUS

JK6402

IC1431

(REGULATOR)

324

VIN

VOUT

STBY

GND

PW PLL1.1V

PW LENS1.5V

PW VID1.1V

CL1381

PW 5.4V

PW REG1.8V

PW FROM1.8V

PW SENS1.8V

CH1231

CH1101

ADPSW

PWSW

ADP

VADP

USB DET

BAT

VUSB

ISNS

TDET

SCK

SWIN4

WKUP RST

CL1341

PW CAM1.2V

IC703

(REGULATOR)

324

VIN

VOUT

STBY

GND

D902-906

(LCD BACK LIGHT)

SDI

SDO

S6401

POWER ON/OFF

LI BATT

/SWIN1

B4801

COINBAT

DVIN

CHG EN

FULLSET

BATSET

USB EN

USB WK CNT

CL1001

CL1002

6 45

IC1421

(REGULATOR)

IC304

(REGULATOR)

NOISE

VIN

VOUTVOUT

GND

STBY

IC1002

(SWITCHING REGULATOR)

17 18 19

141312

1 2 3 4

PVCC PVCC

VCC STB

GND

PVCC

LX1

P GND

INV

GND

9 8 7

P GND

LX2

VOUT

P GND

R6409

CH3422

CH3423

CH3424

QR3403

IC704

(REGULATOR)

324

VIN

VOUT

STBY

GND

PW LENS3V

PW MOS1.8V

324

VIN

VOUT

STBY

GND

IC301

(REGULATOR)

GND

OUT

NCCE

MOSSENS ON H (From IC3401-AF20)

PW MOS3.3V

VCONT

12 Wiring Connection Diagram

12.1. Interconnection Diagram

HC-V700M/V707M/V700/V707 INTERCONNECTION DIAGRAM

INTERCONNECTION DIAGRAM

MAIN P.C.B. (FOIL SIDE)

(COMPONENT SIDE)

FLASH P.C.B. (FOIL SIDE)

(COMPONENT SIDE)

SD HOLDER P.C.B. (FOIL SIDE)

MONITOR P.C.B. (FOIL SIDE)

(COMPONENT SIDE)

FP6005

8765432

LENSBA MT B

LENSBA MT A

LENSBA MT B

LENSBA MT A

OP LED

D GND

SHTR OPEN

FP6004

121110

987654321

D GND

IGBT GND

CHAEND

TRIGEND

CHARGE

PW 3R2V

PW STNOREG

2G ZAN

2G ZAP

FMR VCC

FMR GND

FMR A

FMT

PITDRV+

PITHO+

PITHO

YAWHIN

YAWHIN+

YAWDRV

IRHO+

IRHO

IRM

2G ZLEDCONT

2G&4GZENCVCC&TVCC

4G ZABS

4G ZAN

4G ZAP

246

101214161820222426283032343638

2G ZBP

2G ZBN

FMR B

FMR GND

FMT+

PITDRV

PITHIN

PITHIN+

YAWHO+

YAWHO

YAWDRV+

IRHIN+

IRHIN

IRM+

TOUT

2G ZABS

4G ZLEDCONT

4G ZBN

4G ZBP

13579

13151719212325272931333537

PP6001

CARD LED B

NOREG NOREG NOREG NOREG NOREG

NOREG E KEYIN2 ZOOMAD

VTR KEY 1 PW REG3V

POWER LED

STANDBY LED

SP OUT1 SP OUT2

E CARD DET PW SD3R2V PW SD3R2V PW SD3R2V

ID VBUS VBUS

E CARD PRO

E KEYIN4

POWER SW

SD CMD

D GND SD DATA2 SD DATA3 SD DATA0 SD DATA1

D GND

SD CLK

D GND

S GYRO CSB S GYRO SCK

S GYRO SO

S GYRO SI

PW GYRO3V

G EPGYRO REF

G EPGYROR

GYRO GND GYRO GND

D GND

D+

DD GND D GND D GND

25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10

9 8 7 6 5 4 3 2 1

26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50

FP6008

P6003

65432

BATT

BATT +

FP6001

FP6002

eSD2 DAT3

eSD2 DAT1

eSD2 CMD

eSD2 CLK

eSD2 VDD

eSD1 DAT3

eSD1 DAT1

eSD1 CMD

eSD1 CLK

eSD1 D GND

eSD1 VDD

13579

1315171921

246

1012141618

eSD2 DAT0

eSD2 DAT2

eSD2 D GND

eSD2 VDD

eSD1 DAT0

eSD1 DAT2

eSD1 D GND

eSD1 VDD

E KEYIN4

GND

P6005

PS6401

CARD LED B

NOREG

E KEYIN2

ZOOMAD

VTR KEY 1

PW REG3V

POWER LED

STANDBY LED

SP OUT1

SP OUT2

E CARD DET

PW SD3R2V

VBUS

E CARD PRO

E KEYIN4

POWER SW

SD CMD

D GND

SD DATA2

SD DATA3

SD DATA0

SD DATA1

D GND

SD CLK

D GND

S GYRO CSB

S GYRO SCK

S GYRO SO

S GYRO SI

PW GYRO3V

G EPGYRO REF

G EPGYROR

GYRO GND

D GND

D+

D-

D GND

25242322212019181716151413

121110

987654321

26272829303132333435363738394041424344454647484950

GND

AVREF

GND

AVREF

POWER LED

9 7 5 3 1

VTR KEY 1

ZOOMAD VTR KEY 4 LED GND

STANDBY LED

8 6 4 2

FP4803

SP OUT2

SP OUT1

P6401

FP901

FP7001

12 11 10 9 8 7 6 5 4 3 2 1

PW STNOREG PW STNOREG

PW 3R2V CHARGE TRIGEND

CHAEND IGBT GND IGBT GND

D GND D GND D GND D GND

XENON

XENON+

1 2

P7001

TRIG

D GND

2 1

P7002

P6701

1 2 3 4 5 6

BATT + BATT +

T D

BATT

JK6701

123

RL6552

RL6551

FP3201

987654321

DAT3

DAT0

DAT1

DAT2

CMD

GND

CLK

GND

VDD

MOS UNIT

LENS UNIT

LENS

BARRIER

Y TOP

X LEFT

Y BOT

X RIGHT

4 3 2 1

FP905

TOUCH PANEL

LCD UNIT

FLASH

BATTERY

TOP OPERATION

SPEAKER

BATTERY CATCHER P.C.B. (FOIL SIDE)

(COMPONENT SIDE)

SS SW P.C.B. (COMPONENT SIDE)

(FOIL SIDE)

ESD P.C.B. (FOIL SIDE)

ESD FPC

MONITOR FPC

FP6003

D GND

MIC OUT R

MIC OUT L

642

COIN BATT+

MIC5V

MIC GND

531

P6001

A3.3V A3.3V A4.0V RSTN

SDI

SCS D1.2V D1.2V D1.2V MCLK

BUS283 A D4P BUS283 A D4M BUS283 A CKP BUS283 A CKM BUS283 A D2P BUS283 A D2M BUS283 A D3P BUS283 A D3M BUS283 A D1P BUS283 A D1M

A3.3V A3.3V

SCK

VD D3.3V D1.2V D1.2V D1.8V D1.8V

BUS283 B D1P BUS283 B D1M BUS283 B D3P BUS283 B D3M BUS283 B D2P BUS283 B D2M BUS283 B CKP BUS283 B CKM BUS283 B D4P BUS283 B D4M

40 38 36 34 32 30 28 26 24 22 20 18 16 14 12 10

8 6 4 2

39 37 35 33 31 29 27 25 23 21 19 17 15 13 11

9 7 5 3 1

65432

FP4802

65432

G MIC OUT L

MIC GND

G MIC OUT R

PW REG5V

D GND

COIN BATT+

FP4801

6 5 4 3 2 1

ECM[L] ECM[L]

GND

GND ECM[R] ECM[R]

MIC

FP6010

6 5 4 3 2 1

LED LIGHT CA LED LIGHT CA LED LIGHT AN

D GND

PW REG3V

3D DET L

1 2 3 4 5 6

HALL LED FPC

FP904

VS C1N C2N

VCIX2

CXP VCIM

VCOML

VSS1

VDDL

HSYNC

DG0 DG2 DG4 DG6 DR0 DR2 DR4 DR6 SDA

SCEN

C3P C4P VGL

44 42 40 38 36 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2

C1P C2P VSS2

VCI

CXN

VCOMH

VGM VDDIO1 VSYNC DCLK

DG1

DG3

DG5

DG7

DR1

DR3

DR5

DR7

SCL

VGH

C3N

C4N

45 43 41 39 37 35 33 31 29 27 25 23 21 19 17 15 13 11 9 7 5 3 1

PW REG1R8V PW REG1R8V

D GND

D1 P

D1 N D GND CLK P CLK N D GND

D0 P

D0 N D GND

PW REG3V

S DO LCD S CS LCD

S CLK LCD

D GND D GND D GND D GND D GND

PW LCDBL H PW LCDBL H PW LCDBL L PW LCDBL L

LCD RVS S AD TPX TOP S AD TPYLEFT S AD TPX BOT

S ADTPYRIGHT

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30

S ADTPYRIGHT

S AD TPYLEFT

LCD RVS

PW LCDBL L

PW LCDBL H

D GND

S CS LCD

PW REG3V

GNDNCGNDNCGNDNCGND

PW REG1R8V

246

10121416182022242628303234

S AD TPX BOT

S AD TPX TOP

PW LCDBL L

PW LCDBL H

D GND

S CLK LCD

S DO LCD

PW REG3V

D0 N

D0 P

CLK N

CLK P

D1 N

D1 P

PW REG1R8V

13579

1315171921232527293133

MIC AMP P.C.B. (FOIL SIDE)

HC-V700M/V707M only

ECM RELAY FFC

FLASH FFC

Model No. : HC-V700/V700M/V707/V707M Schematic Diagram Note

Model No. : HC-V700/V700M/V707/V707M Parts List Note

Model No. : HC-V700/V700M/V707/V707M Main Connection (Main P.C.B.)

Model No. : HC-V700/V700M/V707/V707M Video (Main P.C.B.)

Model No. : HC-V700/V700M/V707/V707M Lens Drive (Main P.C.B.)

Model No. : HC-V700/V700M/V707/V707M AVIO (Main P.C.B.)

Model No. : HC-V700/V700M/V707/V707M HDMI (Main P.C.B.)

Model No. : HC-V700/V700M/V707/V707M Charge/RTC (Main P.C.B.)

Model No. : HC-V700/V700M/V707/V707M EXTMIC (Main P.C.B.)

Model No. : HC-V700/V700M/V707/V707M LED Light (Main P.C.B.)

Model No. : HC-V700/V700M/V707/V707M Power (Main P.C.B.)

Model No. : HC-V700/V700M/V707/V707M MOS Connection (Main P.C.B.)

Model No. : HC-V700/V700M/V707/V707M SD Holder (SD Holder P.C.B.)

Model No. : HC-V700/V700M/V707/V707M Monitor (Monitor P.C.B.)

Model No. : HC-V700/V700M/V707/V707M Main P.C.B. (Component Side)

Model No. : HC-V700/V700M/V707/V707M Main P.C.B. (Foil Side)

Model No. : HC-V700/V700M/V707/V707M SD Holder P.C.B. (Component Side)

Model No. : HC-V700/V700M/V707/V707M SD Holder P.C.B. (Foil Side)

Model No. : HC-V700/V700M/V707/V707M Monitor P.C.B. (Component Side)

Model No. : HC-V700/V700M/V707/V707M Monitor P.C.B. (Foil Side)

Model No. : HC-V700/V700M/V707/V707M Parts List

Safety

Ref.

No.

Part No. Part Name & Description Q'ty Remarks

C301 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C302 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C303 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C304 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C305 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C309 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C310 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C314 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C316 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C502 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C504 F1G1E1030005 C.CAPACITOR CH 25V 0.01U 1 C505 F1G1H102A640 C.CAPACITOR CH 50V 1000P 1 C701 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C702 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C703 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C704 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C705 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C706 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C708 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C709 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C713 F1G1H101A644 C.CAPACITOR CH 50V 100P 1 C714 F1G1H101A644 C.CAPACITOR CH 50V 100P 1 C715 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C716 F1L1A103A016 C.CAPACITOR CH 10V 0.01U 1 C718 F1G1E1030005 C.CAPACITOR CH 25V 0.01U 1 C719 F1G1E1030005 C.CAPACITOR CH 25V 0.01U 1 C720 F1G1E1030005 C.CAPACITOR CH 25V 0.01U 1 C721 F1G1E1030005 C.CAPACITOR CH 25V 0.01U 1 C722 F1G1E1030005 C.CAPACITOR CH 25V 0.01U 1 C723 F1G1E1030005 C.CAPACITOR CH 25V 0.01U 1 C724 F1G1E1030005 C.CAPACITOR CH 25V 0.01U 1 C725 F1G1E1030005 C.CAPACITOR CH 25V 0.01U 1 C726 F1G1E1030005 C.CAPACITOR CH 25V 0.01U 1 C727 F1G1E1030005 C.CAPACITOR CH 25V 0.01U 1 C741 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C742 F1G1H472A571 C.CAPACITOR CH 50V 4700P 1 C743 F1G1H472A571 C.CAPACITOR CH 50V 4700P 1 C765 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C767 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C771 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C772 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C781 F1G1E1030005 C.CAPACITOR CH 25V 0.01U 1 C901 F1G1E1040001 C.CAPACITOR CH 25V 0.1U 1 C902 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C903 F1H0J4750004 C.CAPACITOR CH 6.3V 4.7U 1 C904 F1G1H220A644 C.CAPACITOR CH 50V 22P 1 C905 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C906 F1H1A105A036 C.CAPACITOR CH 10V 1U 1 C907 F1H1A105A036 C.CAPACITOR CH 10V 1U 1 C908 ECJ1VB1C105K C.CAPACITOR CH 16V 1U 1 C909 F1H1E105A116 C.CAPACITOR CH 25V 1U 1 C910 F1H1A105A036 C.CAPACITOR CH 10V 1U 1 C911 F1H1A105A036 C.CAPACITOR CH 10V 1U 1 C912 F1H1A105A036 C.CAPACITOR CH 10V 1U 1 C913 F1H1A105A036 C.CAPACITOR CH 10V 1U 1 C914 F1H1A105A036 C.CAPACITOR CH 10V 1U 1 C915 F1H1A105A036 C.CAPACITOR CH 10V 1U 1 C916 F1H1A105A036 C.CAPACITOR CH 10V 1U 1 C917 F1H1A105A036 C.CAPACITOR CH 10V 1U 1 C918 F1H1A105A036 C.CAPACITOR CH 10V 1U 1 C919 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C920 F1H1A105A036 C.CAPACITOR CH 10V 1U 1

Model No. : HC-V700/V700M/V707/V707M Parts List

Safety

Ref.

No.

Part No. Part Name & Description Q'ty Remarks

C921 F1H1A105A036 C.CAPACITOR CH 10V 1U 1 C922 F1H1A105A036 C.CAPACITOR CH 10V 1U 1 C924 F1G1H220A644 C.CAPACITOR CH 50V 22P 1 C925 F1G1H220A644 C.CAPACITOR CH 50V 22P 1 C926 F1G1H220A644 C.CAPACITOR CH 50V 22P 1 C927 F1G1H220A644 C.CAPACITOR CH 50V 22P 1 C928 F1G1H220A644 C.CAPACITOR CH 50V 22P 1 C929 F1G1H220A644 C.CAPACITOR CH 50V 22P 1 C930 F1G1H220A644 C.CAPACITOR CH 50V 22P 1 C931 F1G1H220A644 C.CAPACITOR CH 50V 22P 1 C932 F1G1H220A644 C.CAPACITOR CH 50V 22P 1 C933 F1G1H220A644 C.CAPACITOR CH 50V 22P 1 C934 F1G1H220A644 C.CAPACITOR CH 50V 22P 1 C935 F1G1H220A644 C.CAPACITOR CH 50V 22P 1 C936 F1G1H220A644 C.CAPACITOR CH 50V 22P 1 C937 F1G1H220A644 C.CAPACITOR CH 50V 22P 1

C938 F1G1H220A644 C.CAPACITOR CH 50V 22P 1 C1001 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C1012 F1G1H102A640 C.CAPACITOR CH 50V 1000P 1 C1013 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C1061 F1H0J4750004 C.CAPACITOR CH 6.3V 4.7U 1 C1101 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C1102 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C1103 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C1161 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C1221 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C1222 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C1231 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C1232 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C1242 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C1251 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C1252 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C1261 F1H1E105A116 C.CAPACITOR CH 25V 1U 1 C1271 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C1272 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C1273 F1G1H220A644 C.CAPACITOR CH 50V 22P 1 C1281 F1H0J2250008 C.CAPACITOR CH 6.3V 2.2U 1 C1282 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C1283 F1G1H152A640 C.CAPACITOR CH 50V 1500P 1 C1284 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C1285 F1G1H121A644 C.CAPACITOR CH 50V 120P 1 C1303 F1G1H102A640 C.CAPACITOR CH 50V 1000P 1 C1304 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C1332 F3F0G476A030 E.CAPACITOR CH 4V 47U 1 C1356 F3F0G476A030 E.CAPACITOR CH 4V 47U 1 C1422 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C1431 F1H0J4750004 C.CAPACITOR CH 6.3V 4.7U 1 C1471 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C1501 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C1502 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C1503 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C1506 F1L1A103A016 C.CAPACITOR CH 10V 0.01U 1 C1507 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C1508 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C1511 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C1512 F1H1E105A116 C.CAPACITOR CH 25V 1U 1 C1515 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C1516 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C1518 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C1519 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C1520 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C1521 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1

Model No. : HC-V700/V700M/V707/V707M Parts List

Safety

Ref.

No.

Part No. Part Name & Description Q'ty Remarks

C1522 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C1523 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C2301 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C2304 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C2305 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C2310 F1G1H8R0A642 CAPACITOR 1 C2311 F1L1A103A016 C.CAPACITOR CH 10V 0.01U 1 C3401 F1H0J106A009 C.CAPACITOR CH 6.3V 10U 1 C3402 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C3403 F1H0J4750004 C.CAPACITOR CH 6.3V 4.7U 1 C3406 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3407 F3G0J107A017 C.CAPACITOR CH 6.3V 100U 1 C3408 F1H0J106A009 C.CAPACITOR CH 6.3V 10U 1 C3409 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3410 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3411 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3412 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3413 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3414 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3415 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3416 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3417 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3418 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3419 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3420 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3421 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3423 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C3424 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C3425 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3426 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3427 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3428 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3429 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3430 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C3431 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C3432 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3433 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3434 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3435 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3436 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3437 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3438 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3439 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3440 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3441 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3442 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3443 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C3444 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C3445 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C3446 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C3447 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C3449 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3450 F1L1A103A016 C.CAPACITOR CH 10V 0.01U 1 C3451 F1G1H472A571 C.CAPACITOR CH 50V 4700P 1 C3452 F1H0J106A009 C.CAPACITOR CH 6.3V 10U 1 C3453 F1L1A103A016 C.CAPACITOR CH 10V 0.01U 1 C3454 F1L1A103A016 C.CAPACITOR CH 10V 0.01U 1 C3455 F1L1A103A016 C.CAPACITOR CH 10V 0.01U 1 C3456 F1L1A103A016 C.CAPACITOR CH 10V 0.01U 1 C3457 F1G1H102A640 C.CAPACITOR CH 50V 1000P 1 C3459 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3460 F1H0J106A009 C.CAPACITOR CH 6.3V 10U 1

Model No. : HC-V700/V700M/V707/V707M Parts List

Safety

Ref.

No.

Part No. Part Name & Description Q'ty Remarks

C3461 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C3462 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C3464 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3465 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3466 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C3468 F1L1A103A016 C.CAPACITOR CH 10V 0.01U 1 C3469 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3470 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C3471 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C3472 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3473 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3474 F1G1E1030005 C.CAPACITOR CH 25V 0.01U 1 C3702 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C3703 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C3706 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C3707 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C3708 F1H0J4750004 C.CAPACITOR CH 6.3V 4.7U 1 C3709 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C3710 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C3711 F1L1A103A016 C.CAPACITOR CH 10V 0.01U 1 C3712 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C3713 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C3714 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C3715 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C3716 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C3719 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C3720 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C3721 F3F0J226A032 T.CAPACITOR CH 6.3V 22U 1 C3722 F1J0J106A049 C.CAPACITOR CH 6.3V 10U 1 C3906 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C3907 F3G0J107A017 C.CAPACITOR CH 6.3V 100U 1 C3908 F1G1E1030005 C.CAPACITOR CH 25V 0.01U 1 C3909 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C3910 F1G1E1030005 C.CAPACITOR CH 25V 0.01U 1 C3911 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C3956 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 V700MP,MPC,MPU,MGK, V707MEG C4901 F1G1H472A571 C.CAPACITOR CH 50V 4700P 1 C4902 F1G1H472A571 C.CAPACITOR CH 50V 4700P 1 C4903 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C4905 F3F0J226A032 T.CAPACITOR CH 6.3V 22U 1 C4906 F3F0J226A032 T.CAPACITOR CH 6.3V 22U 1 C4908 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C4909 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C4910 F3F0J226A032 T.CAPACITOR CH 6.3V 22U 1 C4913 F1H0J4750004 C.CAPACITOR CH 6.3V 4.7U 1 C4914 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C4915 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C6001 F1G1E1040001 C.CAPACITOR CH 25V 0.1U 1 C6002 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C6005 F1G1H472A571 C.CAPACITOR CH 50V 4700P 1 C6006 F1G1H472A571 C.CAPACITOR CH 50V 4700P 1 C6018 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C6019 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C6023 F1L0J1040001 C.CAPACITOR CH 6.3V 0.1U 1 C6098 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C6402 F1G1E1030005 C.CAPACITOR CH 25V 0.01U 1 C6403 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C6404 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C6405 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C6407 F1G1C104A077 C.CAPACITOR CH 16V 0.1U 1 C6408 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1 C6412 F1H1E105A116 C.CAPACITOR CH 25V 1U 1

Model No. : HC-V700/V700M/V707/V707M Parts List

Safety

Ref.

No.

Part No. Part Name & Description Q'ty Remarks

C6421 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 (MAIN P.C.B.) C6421 F1J1A106A043 C.CAPACITOR CH 10V 10U 1 (SD HOLDER P.C.B.)

D901 DZ2J200M0L DIODE 1 E.S.D.

D902 B3AFB0000426 DIODE 1 E.S.D.

D903 B3AFB0000426 DIODE 1 E.S.D.

D904 B3AFB0000426 DIODE 1 E.S.D.

D905 B3AFB0000426 DIODE 1 E.S.D.

D906 B3AFB0000426 DIODE 1 E.S.D.

D908 B0JCCD000003 DIODE 1 E.S.D.

D909 B0JCCD000003 DIODE 1 E.S.D. D1261 B0JCMD000052 DIODE 1 E.S.D. D1271 B0JCGD000016 DIODE 1 E.S.D. D1503 B0JCMC000019 DIODE 1 E.S.D. D1505 DB2S31100L DIODE 1 E.S.D. D2301 DB2S31100L DIODE 1 E.S.D. D3401 DB2S31100L DIODE 1 E.S.D. D6401 B3AAB0000343 DIODE 1 E.S.D.

FL3401 F1H0J105A037 FILTER 1 FL6001 J0ZZB0000122 FILTER 1 FL6002 J0ZZB0000122 FILTER 1 FL6004 F1H0J105A037 FILTER 1

FP901 K1MY30BA0385 CONNECTOR 30P 1 FP904 K1MY45BA0235 CONNECTOR 45P 1 FP905 K1MN04BA0262 CONNECTOR 4P 1

FP4803 K1MN10A00074 CONNECTOR 10P 1 FP6001 K1MY35AA0199 CONNECTOR 35P 1 FP6002 K1MY21BA0281 CONNECTOR 21P 1 V700MP,MPC,M PU ,MGK, V707MEG FP6003 K1MN06A00065 CONNECTOR 6P 1 FP6004 K1MN12BA0108 CONNECTOR 12P 1 FP6005 K1MN08BA0108 CONNECTOR 8P 1 FP6008 K1MY39AA0199 CONNECTOR 39P 1 FP6010 K1MN06BA0108 CONNECTOR 6P 1 HS3901 K1NA09E00098 SD CARD SLOT 1

IC301 C0DBGGC00007 IC 1 E.S.D. IC302 C0JBAA000479 IC 1 E.S.D. IC304 C0DBGYY01173 IC 1 E.S.D. IC701 C1AB00003719 IC 1 E.S.D. IC703 C0DBGYY01172 IC 1 E.S.D. IC704 C0DBGYY02595 IC 1 E.S.D. IC705 C1AB00003450 IC 1 E.S.D. IC706 C0GBC0000028 IC 1 E.S.D. IC707 C0JBAZ002875 IC 1 E.S.D. IC761 C0ABGA000035 IC 1 E.S.D. IC901 C1CB00002847 IC 1 E.S.D. IC902 B4ZZ00000031 IC 1 E.S.D.

IC1001 C1ZBZ0004347 IC 1 E.S.D. IC1002 VUEALLPT033 IC 1 E.S.D. IC1011 C0CBCDC00073 IC 1 E.S.D. IC1301 C0CBCCC00157 IC 1 E.S.D. IC1421 C0CBCYY00078 IC 1 E.S.D. IC1431 C0DBGYY00534 IC 1 E.S.D. IC1471 C0DBGHD00008 IC 1 E.S.D. IC1501 C0EBY0001291 IC 1 E.S.D. IC1502 C1ZBZ0004145 IC 1 E.S.D. IC1503 C0DBDYY00042 IC 1 E.S.D. IC2301 C0EBE0000442 IC 1 E.S.D. IC3401 C1AB00003898 IC 1 E.S.D. IC3402 C3ABSY000099 IC 1 E.S.D. IC3403 TC58RYM9C12A IC 1 E.S.D. IC3405 C0EBY0000906 IC 1 E.S.D. IC3701 NN12924A-BB IC 1 E.S.D. IC6401 EWTS9PSL1A IC 1 E.S.D.

Model No. : HC-V700/V700M/V707/V707M Parts List

Safety

Ref.

No.

Part No. Part Name & Description Q'ty Remarks

IC6411 L2ES00000038 IC 1 E.S.D. IP1502 K5H402YA0080 IC PROTECTOR 1 IP6401 K5H402YA0080 IC PROTECTOR 1 JK6001 K2HC106E0009 JACK, A/V 1 JK6002 K2HZ112E0001 JACK, AV MULTI 1 JK6003 K1FA119E0020 JACK, HDMI 1 JK6401 K2EBYB000003 JACK, DC 1 JK6402 K2HZ105E0013 JACK, USB 1

L301 G1C100MA0072 CHIP INDUCTOR 10UH 1

L303 G1C100MA0072 CHIP INDUCTOR 10UH 1 L1221 G1C3R3MA0249 CHIP INDUCTOR 3.3UH 1 L1231 G1C100MA0249 CHIP INDUCTOR 10UH 1 L1241 G1C3R3MA0392 CHIP INDUCTOR 3.3UH 1 L1251 G1C4R7ZA0240 CHIP INDUCTOR 4.7UH 1 L1261 G1C6R8MA0061 CHIP INDUCTOR 6.8UH 1 L1271 G1C6R8MA0478 CHIP INDUCTOR 6.8UH 1 L1281 G1C4R7MA0478 CHIP INDUCTOR 4.7UH 1 L1501 G1C4R7ZA0240 CHIP INDUCTOR 4.7UH 1 L3401 G1C100MA0495 CHIP INDUCTOR 10UH 1 L3402 G1C100MA0408 CHIP INDUCTOR 10UH 1 L3404 G1C100MA0495 CHIP INDUCTOR 10UH 1 L3405 G1C100MA0495 CHIP INDUCTOR 10UH 1 L3702 G1C4R7MA0073 CHIP INDUCTOR 4.7UH 1 L3704 G1C100KA0115 CHIP INDUCTOR 10UH 1 LB301 J0JBC0000099 FILTER 1 LB501 J0JCC0000276 FILTER 1 LB502 J0JCC0000276 FILTER 1 LB503 J0JCC0000276 FILTER 1 LB504 J0JCC0000276 FILTER 1 LB901 J0JBC0000099 FILTER 1

LB3401 J0JBC0000099 FILTER 1 LB3402 J0JBC0000099 FILTER 1 V700MP,MPC,MPU,MGK, V707MEG LB3951 J0JGC0000059 FILTER 1 V700MP,MPC,MPU,MGK, V707MEG LB6001 J0JCC0000276 FILTER 1 LB6002 J0JCC0000276 FILTER 1 LB6003 J0JCC0000276 FILTER 1 LB6004 J0JCC0000276 FILTER 1 LB6006 J0JCC0000408 FILTER 1 LB6007 J0JCC0000408 FILTER 1 LB6008 J0JCC0000276 FILTER 1 LB6009 J0JCC0000276 FILTER 1 LB6010 J0JCC0000276 FILTER 1 LB6011 J0JCC0000408 FILTER 1 LB6020 J0JCC0000276 FILTER 1 LB6021 J0JCC0000276 FILTER 1 LB6022 J0JCC0000276 FILTER 1 LB6401 J0JJC0000015 FILTER 1 LB6402 J0JJC0000015 FILTER 1

P6001 K1KY40AA1067 CONNECTOR 40P 1 P6003 K1KY06BA0314 CONNECTOR 6P 1 P6005 K1KA02BA0014 CONNECTOR 2P 1 P6401 K1KA02BA0014 CONNECTOR 2P 1

PP6001 K1KY50BA0095 CONNECTOR 50P 1 PS6401 K1KB50AA0094 CONNECTOR 50P 1

Q773 B1ADGD000013 TRANSISTOR 1 E.S.D. Q1501 B1MBDDA00024 TRANSISTOR 1 E.S.D. Q1502 MTM684110LBF TRANSISTOR 1 E.S.D. Q1503 B1CHQC000007 TRANSISTOR 1 E.S.D. Q1504 FK3303010L TRANSISTOR 1 E.S.D. Q3401 B1CFGD000003 TRANSISTOR 1 E.S.D. Q3901 B1ADKB000015 TRANSISTOR 1 E.S.D. Q4901 DSC300100L TRANSISTOR 1 E.S.D.

Model No. : HC-V700/V700M/V707/V707M Parts List

Safety

Ref.

No.

Part No. Part Name & Description Q'ty Remarks

Q4902 DSA300100L TRANSISTOR 1 E.S.D. Q4903 DSC300100L TRANSISTOR 1 E.S.D. Q4904 DSA300100L TRANSISTOR 1 E.S.D. Q4907 DSC300100L TRANSISTOR 1 E.S.D. Q4908 DSC300100L TRANSISTOR 1 E.S.D. Q6421 DSC300100L TRANSISTOR 1 E.S.D. Q6423 DSA300100L TRANSISTOR 1 E.S.D. QR751 DRA3143T0L TRANSISTOR-RESISTOR 1 E.S.D. QR773 DRC3143Z0L TRANSISTOR-RESISTOR 1 E.S.D. QR775 DRC3143T0L TRANSISTOR-RESISTOR 1 E.S.D.

QR1001 DRC3143E0L TRANSISTOR-RESISTOR 1 E.S.D. QR1002 DRA3124X0L TRANSISTOR-RESISTOR 1 E.S.D. QR1101 DRC3114E0L TRANSISTOR-RESISTOR 1 E.S.D. QR1503 DRC3144E0L TRANSISTOR-RESISTOR 1 E.S.D. QR2308 DRA3144E0L TRANSISTOR-RESISTOR 1 E.S.D. QR3401 DRC3144W0L TRANSISTOR-RESISTOR 1 E.S.D. QR3402 DRA3144E0L TRANSISTOR-RESISTOR 1 E.S.D. QR3403 DRC3114T0L TRANSISTOR-RESISTOR 1 E.S.D. QR3410 DRC3143T0L TRANSISTOR-RESISTOR 1 E.S.D. QR3411 DRA3143T0L TRANSISTOR-RESISTOR 1 E.S.D. QR3412 DRC3143T0L TRANSISTOR-RESISTOR 1 E.S.D. QR3413 DRA3143T0L TRANSISTOR-RESISTOR 1 E.S.D. QR6006 DRA3124X0L TRANSISTOR-RESISTOR 1 E.S.D. QR6007 DRA3124X0L TRANSISTOR-RESISTOR 1 E.S.D. QR6008 DRC3114E0L TRANSISTOR-RESISTOR 1 E.S.D. QR6402 DRA9114T0L TRANSISTOR-RESISTOR 1 E.S.D. QR6403 DRA9114T0L TRANSISTOR-RESISTOR 1 E.S.D.

R302 ERJ1GEJ102 M.RESISTOR CH 1/20W 1K 1

R304 ERJ1GEJ272 M.RESISTOR CH 1/20W 2.7K 1

R305 ERJ2GEJ470 M.RESISTOR CH 1/16W 47 1

R310 ERJ2GEJ102Y M.RESISTOR CH 1/10W 1K 1

R711 ERJ2RHD103 M.RESISTOR CH 1/16W 10K 1

R712 ERJ2RHD103 M.RESISTOR CH 1/16W 10K 1

R713 ERJ1GE0R00C M.RESISTOR CH 1/20W 0 1

R714 ERJ1GEJ103 M.RESISTOR CH 1/20W 10K 1

R715 ERJ1GEJ103 M.RESISTOR CH 1/20W 10K 1

R716 ERJ1GEJ102 M.RESISTOR CH 1/20W 1K 1

R717 ERJ2RHD682X M.RESISTOR CH 1/10W 6.8K 1

R719 D0YAR0000007 M.RESISTOR CH 1/10W 0 1

R741 ERJ2RHD103 M.RESISTOR CH 1/16W 10K 1

R742 ERJ2RHD103 M.RESISTOR CH 1/16W 10K 1

R743 ERJ2RHD104 M.RESISTOR CH 1/16W 100K 1

R744 ERJ2RKD124 M.RESISTOR CH 1/16W 120K 1

R745 ERJ2RHD103 M.RESISTOR CH 1/16W 10K 1

R746 ERJ2RHD103 M.RESISTOR CH 1/16W 10K 1

R751 ERJ1GEJ181 M.RESISTOR CH 1/20W 180 1

R752 ERJ1GEJ470 M.RESISTOR CH 1/20W 47 1

R766 ERJ2RHD683 M.RESISTOR CH 1/16W 68K 1

R767 ERJ2GEJ222 M.RESISTOR CH 1/10W 2.2K 1

R771 ERJ1GEJ473 M.RESISTOR CH 1/20W 47K 1

R772 ERJ1GEJ821 M.RESISTOR CH 1/20W 820 1

R775 ERJ1GEJ221 M.RESISTOR CH 1/20W 220 1

R776 ERJ1GEJ473 M.RESISTOR CH 1/20W 47K 1

R778 ERJ1GEJ473 M.RESISTOR CH 1/20W 47K 1

R779 ERJ1GEJ221 M.RESISTOR CH 1/20W 220 1

R781 ERJ2GEJ223 M.RESISTOR CH 1/16W 22K 1

R785 ERJ2RHD103 M.RESISTOR CH 1/16W 10K 1

R786 ERJ2RHD683 M.RESISTOR CH 1/16W 68K 1

R791 ERJ2GEJ391 M.RESISTOR CH 1/16W 390 1

R792 ERJ2GEJ391 M.RESISTOR CH 1/16W 390 1

R793 ERJ2GEJ221 M.RESISTOR CH 1/16W 220 1

R907 ERJ2GEJ104 M.RESISTOR CH 1/10W 100K 1

Model No. : HC-V700/V700M/V707/V707M Parts List

Safety

Ref.

No.

Part No. Part Name & Description Q'ty Remarks

R913 ERJ2GEJ151 M.RESISTOR CH 1/10W 150 1

R914 ERJ2GEJ151 M.RESISTOR CH 1/10W 150 1

R915 ERJ2GEJ820 M.RESISTOR CH 1/16W 82 1 R1001 D1JBR102A006 FUSE RESISTOR 1 R1101 ERJ2RKD124 M.RESISTOR CH 1/16W 120K 1 R1107 ERJ1GEJ103 M.RESISTOR CH 1/20W 10K 1 R1161 ERJ2GEJ180X M.RESISTOR CH 1/10W 18 1 R1232 ERJ2RKD474X M.RESISTOR CH 1/16W 470K 1 R1233 ERJ2RHD203 M.RESISTOR CH 1/16W 20K 1 R1234 ERJ2RKD394 M.RESISTOR CH 1/16W 390K 1 R1242 ERJ2RKD434 M.RESISTOR CH 1/16W 430K 1 R1243 ERJ2RHD203 M.RESISTOR CH 1/16W 20K 1 R1244 ERJ2RKD824 M.RESISTOR CH 1/16W 820K 1 R1252 ERJ2RKD364 M.RESISTOR CH 1/16W 360K 1 R1253 ERJ2RHD333X M.RESISTOR CH 1/16W 33K 1 R1254 ERJ2RKD105 M.RESISTOR CH 1/16W 1M 1 R1261 D1JBR095A023 FUSE RESISTOR 1 R1272 ERJ2RKD304 M.RESISTOR CH 1/16W 300K 1 R1273 ERJ2RHD182 M.RESISTOR CH 1/16W 1.8K 1 R1274 ERJ2RHD513 M.RESISTOR CH 1/16W 51K 1 R1275 ERJ2GEJ513X M.RESISTOR CH 1/16W 51K 1 R1276 ERJ2GEJ103 M.RESISTOR CH 1/10W 10K 1 R1282 ERJ2RHD823 M.RESISTOR CH 1/16W 82K 1 R1283 ERJ2GEJ752X M.RESISTOR CH 1/10W 7.5K 1 R1284 ERJ2GEJ472 M.RESISTOR CH 1/10W 4.7K 1 R1285 ERJ2RHD513 M.RESISTOR CH 1/16W 51K 1 R1286 ERJ2RHD162X M.RESISTOR CH 1/16W 1.6K 1 R1287 ERJ2RHD153X M.RESISTOR CH 1/16W 15K 1 R1424 ERJ2RHD272 M.RESISTOR CH 1/16W 2.7K 1 R1434 D0YAR0000007 M.RESISTOR CH 1/10W 0 1 R1435 ERJ2GEJ102Y M.RESISTOR CH 1/10W 1K 1 R1501 D1BDR020A099 RESISTOR 1 R1502 ERJ1GEJ101 M.RESISTOR CH 1/20W 100 1 R1503 ERJ1GEJ101 M.RESISTOR CH 1/20W 100 1 R1507 ERJ1GEJ473 M.RESISTOR CH 1/20W 47K 1 R1509 ERJ1GEJ103 M.RESISTOR CH 1/20W 10K 1 R1510 ERJ1GEJ474 M.RESISTOR CH 1/20W 470K 1 R1511 ERJ1GEJ472 M.RESISTOR CH 1/20W 4.7K 1 R1512 ERJ1GEJ102 M.RESISTOR CH 1/20W 1K 1 R1513 ERJ2RKD154 M.RESISTOR CH 1/16W 150K 1 R1515 ERJ2RKD124 M.RESISTOR CH 1/16W 120K 1 R1516 ERJ1GEJ102 M.RESISTOR CH 1/20W 1K 1 R1517 ERJ1GEJ103 M.RESISTOR CH 1/20W 10K 1 R1518 ERJ1GEJ104 M.RESISTOR CH 1/20W 100K 1 R1522 ERJ2RKD124 M.RESISTOR CH 1/16W 120K 1 R1523 ERJ2RKD184 M.RESISTOR CH 1/16W 180K 1 R1524 ERJ1GEJ473 M.RESISTOR CH 1/20W 47K 1 R1525 ERJ2RHD223 M.RESISTOR CH 1/16W 22K 1 R1526 D1BDR100A111 RESISTOR 1 R1529 ERJ2GEJ101 M.RESISTOR CH 1/10W 100 1 R1535 ERJ2GEJ472 M.RESISTOR CH 1/10W 4.7K 1 R1602 D0YAR0000007 M.RESISTOR CH 1/10W 0 1 R1604 D0YAR0000007 M.RESISTOR CH 1/10W 0 1 R1606 D0YAR0000007 M.RESISTOR CH 1/10W 0 1 R2304 ERJ1GEJ102 M.RESISTOR CH 1/20W 1K 1 R2312 ERJ2GEJ472 M.RESISTOR CH 1/10W 4.7K 1 R3403 D0YAR0000007 M.RESISTOR CH 1/10W 0 1 R3408 ERJ1GE0R00C M.RESISTOR CH 1/20W 0 1 R3416 ERJ1GEJ472 M.RESISTOR CH 1/20W 4.7K 1 R3417 ERJ1GEJ472 M.RESISTOR CH 1/20W 4.7K 1 R3418 ERJ1GEJ472 M.RESISTOR CH 1/20W 4.7K 1 R3424 ERJ2RHD101 M.RESISTOR CH 1/16W 100 1

Model No. : HC-V700/V700M/V707/V707M Parts List

Safety

Ref.

No.

Part No. Part Name & Description Q'ty Remarks

R3426 ERJ2RHD101 M.RESISTOR CH 1/16W 100 1 R3428 ERJ2RHD101 M.RESISTOR CH 1/16W 100 1 R3429 ERJ1GEJ273 M.RESISTOR CH 1/20W 27K 1 R3430 ERJ2RHD431 M.RESISTOR CH 1/16W 430 1 R3431 ERJ2RHD272 M.RESISTOR CH 1/16W 2.7K 1 R3432 ERJ2RHD512 M.RESISTOR CH 1/16W 5.1K 1 R3433 ERJ1GEJ472 M.RESISTOR CH 1/20W 4.7K 1 R3434 ERJ2RHD243 M.RESISTOR CH 1/16W 24K 1 R3435 ERJ2RHD183 M.RESISTOR CH 1/16W 18K 1 R3436 ERJ1GEJ472 M.RESISTOR CH 1/20W 4.7K 1 R3437 ERJ1GEJ182 M.RESISTOR CH 1/20W 1.8K 1 R3438 ERJ1GEJ182 M.RESISTOR CH 1/20W 1.8K 1 R3442 ERJ2GEJ470 M.RESISTOR CH 1/16W 47 1 R3443 ERJ2GEJ270 M.RESISTOR CH 1/10W 27 1 R3444 ERJ2RHD123X M.RESISTOR CH 1/16W 12K 1 R3445 ERJ2GEJ470 M.RESISTOR CH 1/16W 47 1 V700MP,MPC,MPU,MGK, V707MEG R3446 ERJ2GEJ560X M.RESISTOR CH 1/10W 56 1 V700MP,MPC,MPU,MGK, V707MEG R3447 D0YAR0000007 M.RESISTOR CH 1/10W 0 1 R3450 D0YAR0000007 M.RESISTOR CH 1/10W 0 1 R3453 ERJ2GEJ103 M.RESISTOR CH 1/10W 10K 1 R3456 ERJ1GEJ102 M.RESISTOR CH 1/20W 1K 1 R3458 ERJ1GEJ472 M.RESISTOR CH 1/20W 4.7K 1 R3460 ERJ1GEJ473 M.RESISTOR CH 1/20W 47K 1 R3461 ERJ1GEJ104 M.RESISTOR CH 1/20W 100K 1 R3463 ERJ1GEJ104 M.RESISTOR CH 1/20W 100K 1 R3464 ERJ1GEJ473 M.RESISTOR CH 1/20W 47K 1 R3466 ERJ1GEJ473 M.RESISTOR CH 1/20W 47K 1 R3467 ERJ2RKD184 M.RESISTOR CH 1/16W 180K 1 R3468 ERJ2RKD184 M.RESISTOR CH 1/16W 180K 1 R3470 ERJ1GEJ103 M.RESISTOR CH 1/20W 10K 1 R3475 ERJ1GEJ103 M.RESISTOR CH 1/20W 10K 1 R3476 ERJ1GEJ102 M.RESISTOR CH 1/20W 1K 1 R3477 ERJ2GEJ183 M.RESISTOR CH 1/10W 18K 1 R3478 ERJ1GEJ473 M.RESISTOR CH 1/20W 47K 1 R3481 ERJ1GEJ152 M.RESISTOR CH 1/20W 1.5K 1 R3486 ERJ2GEJ473Y M.RESISTOR CH 1/10W 47K 1 R3489 ERJ1GEJ101 M.RESISTOR CH 1/20W 100 1 R3490 ERJ1GEJ101 M.RESISTOR CH 1/20W 100 1 R3496 ERJ1GEJ103 M.RESISTOR CH 1/20W 10K 1 R3497 ERJ1GEJ103 M.RESISTOR CH 1/20W 10K 1 R3500 ERJ1GEJ473 M.RESISTOR CH 1/20W 47K 1 R3703 ERJ1GEJ102 M.RESISTOR CH 1/20W 1K 1 R3712 ERJ1GEJ102 M.RESISTOR CH 1/20W 1K 1 R3799 ERJ1GEJ473 M.RESISTOR CH 1/20W 47K 1 R3901 ERJ2GEJ470 M.RESISTOR CH 1/16W 47 1 R3902 ERJ2GEJ560X M.RESISTOR CH 1/10W 56 1 R3903 ERJ2GEJ103 M.RESISTOR CH 1/10W 10K 1 R3904 ERJ2GEJ271 M.RESISTOR CH 1/10W 270 1 R3905 ERJ2GEJ331 M.RESISTOR CH 1/16W 330 1 R3906 ERJ2GEJ102Y M.RESISTOR CH 1/10W 1K 1 R3907 ERJ2GEJ102Y M.RESISTOR CH 1/10W 1K 1 R3909 ERJ2GEJ333 M.RESISTOR CH 1/16W 33K 1 R3910 D0GB150JA057 M.RESISTOR CH 1/10W 15 1 R3951 ERJ2GEJ470 M.RESISTOR CH 1/16W 47 1 V700MP,MPC,MPU,MGK, V707MEG R3956 ERJ2GEJ103 M.RESISTOR CH 1/10W 10K 1 V700MP,MPC,MPU,MGK, V707MEG R4901 ERJ3RBD331 M.RESISTOR CH 1/10W 330 1 R4902 ERJ1GEJ472 M.RESISTOR CH 1/20W 4.7K 1 R4904 ERJ3RBD562 M.RESISTOR CH 1/10W 5.6K 1 R4905 ERJ1GEJ471 M.RESISTOR CH 1/20W 470 1 R4906 ERJ3RBD103 M.RESISTOR CH 1/10W 10K 1 R4907 D0HB154ZA002 M.RESISTOR CH 1/16W 150K 1 R4908 D0HB563ZA002 M.RESISTOR CH 1/10W 56K 1

Model No. : HC-V700/V700M/V707/V707M Parts List

Safety

Ref.

No.

Part No. Part Name & Description Q'ty Remarks

R4909 ERJ1GEJ102 M.RESISTOR CH 1/20W 1K 1 R4910 ERJ1GEJ562 M.RESISTOR CH 1/20W 5.6K 1 R4911 ERJ1GEJ151 M.RESISTOR CH 1/20W 150 1 R4912 ERJ1GEJ471 M.RESISTOR CH 1/20W 470 1 R4913 ERJ3RBD103 M.RESISTOR CH 1/10W 10K 1 R4914 D0HB154ZA002 M.RESISTOR CH 1/16W 150K 1 R4915 D0HB563ZA002 M.RESISTOR CH 1/10W 56K 1 R4916 ERJ1GEJ102 M.RESISTOR CH 1/20W 1K 1 R4917 ERJ1GEJ562 M.RESISTOR CH 1/20W 5.6K 1 R4918 ERJ1GEJ151 M.RESISTOR CH 1/20W 150 1 R4920 ERJ3RBD562 M.RESISTOR CH 1/10W 5.6K 1 R4922 ERJ1GEJ223 M.RESISTOR CH 1/20W 22K 1 R4923 ERJ1GEJ683 M.RESISTOR CH 1/20W 68K 1 R4924 ERJ1GEJ473 M.RESISTOR CH 1/20W 47K 1 R6001 ERJ2GEJ471 M.RESISTOR CH 1/10W 470 1 R6006 ERJ1GEJ102 M.RESISTOR CH 1/20W 1K 1 R6027 ERJ2RKD750 M.RESISTOR CH 1/16W 75 1 R6028 ERJ2RKD750 M.RESISTOR CH 1/16W 75 1 R6029 ERJ2RKD750 M.RESISTOR CH 1/16W 75 1 R6030 ERJ2RKD750 M.RESISTOR CH 1/16W 75 1 R6401 ERJ2RKD100 M.RESISTOR CH 1/16W 10 1 R6402 ERJ2RKD100 M.RESISTOR CH 1/16W 10 1 (MAIN P.C.B.) R6402 ERJ2GEJ103 M.RESISTOR CH 1/10W 10K 1 (SD HOLDER P.C.B.) R6403 ERJ2GEJ102Y M.RESISTOR CH 1/10W 1K 1 R6404 ERJ2GEJ470 M.RESISTOR CH 1/16W 47 1 R6405 ERJ2GEJ432 M.RESISTOR CH 1/10W 4.3K 1 R6406 ERJ2RHD683 M.RESISTOR CH 1/16W 68K 1 R6407 ERJ2RHD183 M.RESISTOR CH 1/16W 18K 1 R6408 ERJ2RHD332X M.RESISTOR CH 1/16W 3.3K 1 R6409 D1JBR084A023 FUSE RESISTOR 1 R6411 ERJ3GEY0R00 M.RESISTOR CH 1/10W 0 1 R6421 ERJ3GEY0R00 M.RESISTOR CH 1/10W 0 1 RX901 D1H88204A024 RESISTOR NETWORKS 1 RX902 D1H88204A024 RESISTOR NETWORKS 1 RX903 D1H88204A024 RESISTOR NETWORKS 1 RX904 D1H88204A024 RESISTOR NETWORKS 1

RX3401 D1H82704A024 RESISTOR NETWORKS 1 RX3402 D1H85604A024 RESISTOR NETWORKS 1 V700MP,MPC,MPU,MGK, V707MEG RX3403 D1H84724A024 RESISTOR NETWORKS 1 RX3404 D1H84734A024 RESISTOR NETWORKS 1 RX3405 EXB28V103JX RESISTOR NETWORKS 1 RX3406 EXB28V103JX RESISTOR NETWORKS 1 RX3408 D1H84734A024 RESISTOR NETWORKS 1 RX3409 D1H84734A024 RESISTOR NETWORKS 1 RX3410 EXB28V103JX RESISTOR NETWORKS 1 RX3901 D1H85604A024 RESISTOR NETWORKS 1 RX3902 EXB28V103JX RESISTOR NETWORKS 1 RX3951 D1H86834A024 RESISTOR NETWORKS 1 V700MP,MPC,MPU,MGK, V707MEG

S6001 ESE18L62BXFD SWITCH 1 S6401 K0H1BA000580 SWITCH 1 S6404 K0H1BA000580 SWITCH 1 VA501 D4ED18R00008 VARISTOR 1 VA502 D4ED18R00008 VARISTOR 1 VA503 D4ED18R00008 VARISTOR 1 VA504 D4ED18R00008 VARISTOR 1

VA1501 D4ED1270A011 VARISTOR 1 VA1502 D4ED1270A011 VARISTOR 1 VA1503 D4ED18R00008 VARISTOR 1 VA1504 D4ED18R00008 VARISTOR 1 VA3902 D4EDY1310001 VARISTOR 1 VA6403 D4EDY1310001 VARISTOR 1 VA6404 D4EDY1310001 VARISTOR 1

Model No. : HC-V700/V700M/V707/V707M Parts List

Safety

Ref.

No.

Part No. Part Name & Description Q'ty Remarks

VA6405 D4EDY1310001 VARISTOR 1

X2303 H0J327200085 CRYSTAL OSCILLATOR 1 X3402 H1A5405B0027 CRYSTAL OSCILLATOR 1

Model No. : HC-V700/V700M/V707/V707M Frame and Casing Section

Model No. : HC-V700/V700M/V707/V707M LCD Section

Model No. : HC-V700/V700M/V707/V707M Packing Parts and Accessories Section

Model No. : HC-V700/V700M/V707/V707M Parts List

Safety

Ref.

No.

Part No. Part Name & Description Q'ty Remarks

1 VYK5L06 FRONT CA SE UNIT 1 (-K) 1 VYK5L17 FRONT CA SE UNIT 1 (-S) 2 VEP03J60C ESD P.C.B. UNIT(16GB) 1 V700MP,MPC,MPU,MGK, V707MEG 3 VWJ2327 ECM RELA Y FP C 1 4 VGQ1D43 LENS SHEET 1 5 VMP0C14 BATTER Y FR AME 1 6 VEP03J51A SD HOLDER P.C.B. UNIT 1 (RTL) E.S.D. 8 VYK5L05 LCD CASE(T) UNIT 1 V700MP,MPC,MPU,MGK 8 VYK5T16 LCD CASE (T ) UNIT 1 V707MEG 8 VYK5L10 LCD CASE(T) UNIT 1 V700P,PC,EG,EF,EC,EP,EB, GC,EE,GN,GK 8 VYK5L16 LCD CASE (T ) UNIT 1 V707EGK 8 VYK5L20 LCD CASE (T ) UNIT 1 V707EGS

9 VYK5J47 LCD PANE L UN IT 1 10 VEP26353A MONITOR P.C.B. UNIT 1 (RTL) E.S.D. 11 VYK5J45 SIDE CASE-R UNIT 1 V700MP,MPC,MPU, V700P,PC

11 VYK5L08 SIDE CASE-R UNIT 1

V700MGK, V707MEG, V700EG,EF,EC,EP,EB,GC,

EE,GN,GK, V707EGK 11 VYK5L19 SIDE CASE-R UNIT 1 V707EGS 12 VMP0C16 LCD FRAME A 1 13 VMP0C17 LCD FRAME B 1 14 VKM9802 LCD CASE(B) 1 15 VGQ1B39 TP SPACER 1 17 VGQ1B04 LGP HOLDER 1 18 VGL1416 PRISM SHEET(A) 1 19 VGL1417 PRISM SHEET(B) 1 20 VGL1384 DIFFUSION SHEET 1 21 VKW3518 LIGHT GUIDE PLATE 1 22 VGL1418 REFLECTION SHEET 1 23 VXK2003 HEAT RADIATION PLATE UNIT 1

24 VEP03J48B MAIN P.C.B. UNIT 1

(RTL) E.S.D. V700MP,MPC,MPU,MGK, V707

MEG 24 VEP03J48C MAIN P.C.B. UNIT 1

(RTL) E.S.D. V700P,PC,EG,EF,EC,EP,EB, G

C,EE,GN,GK, V707EGK,EGS 25 VXK1993 LENS FRAME UNIT 1 26 VYK5J50 TOP CASE UNIT 1 (-K) 26 VYK5K83 TOP CASE UNIT 1 (-S) 27 VYK5J49 SIDE CASE-L UNIT 1 28 VWJ2172 ESD FPC 1 V700MP,MPC,MPU,MGK, V707MEG

201 VMX3811 MOS CUSHIO N 1 202 VDL2467 IR FILTER 1 203 L6HAYYYB0004 4TH LENS FRAME UNIT STEP PING MOTOR 1 204 L6HAYYYB0007 2ND LENS FRAME UNIT STEP PING MOTOR 1 205 VXW1402 LENS UNIT 1 206 VXQ2208 MOS UNIT 1 207 VXK2009 MOS SHIELD CAS E UNIT 1 301 K1HY12YY0016 MULTI D/RCA CABLE 1 302 K2KYYYY00201 USB CABLE 1 303 K2CA2CA00025 AC CORD W/PLUG 1 V700MP,MPC,MPU, V700P,PC 304 VSK0780 AC ADAPTOR 1 V700MP,MPC, V700P,PC

304 VSK0781 AC ADAPTOR 1

V700MPU,MGK, V707MEG, V700EG,EF,EC,EP,EB

,GC,EE,GN,GK, V707EGK,EGS

305 VYC1055 ATTACHMENT SHOE UNIT 1 306 VFF0929 CD-ROM(O/I) 1 V707MEG, V700EG,EF,EC,EP, V707EGK,EGS 306 VFF0930 CD-ROM(O/I) 1 V700GC,EE,GN

307 VFF0890-S CD-ROM 1

V700MP,MPC,MPU, V707MEG, V7 00 P, PC,EG,EF,

EC, EP,EB,GC,EE,GN, V707EGK ,E GS

307 VFF0891-S CD-ROM 1 V700MGK, V700GK 308 VPF1294 BAG, POLYETHYLENE 1 309 VQT3Y41 OPERATIN G IN STRUCTIONS (ENGLISH) 1 P,PC,PU 309 VQT3Y42 OPERATIN G IN STRUCTIONS (CANADIAN FRENC H) 1 PC 309 VQT3Y43 OPERATIN G IN STRUCTIONS (SPANISH) 1 V700MPU

Model No. : HC-V700/V700M/V707/V707M Parts List

Safety

Ref.

No.

Part No. Part Name & Description Q'ty Remarks

309 VQT3Y53

OPERATING INSTRUCTIONS (CHI NE SE (SIMPLIFI ED))

1GK

309 VQT3Y44

OPERATING INSTRUCTIONS (GER MA N/ TURKISH/I TALIAN/DUTCH)

1EG 309 VQT3Y45 OPERATIN G IN STRUCTIONS (FRENCH) 1 EG,EF 309 VQT3Y46

OPERATING INSTRUCTIONS (SPA NI SH /PORTUGUE SE/SWEDISH/ DANISH/FINNIS H)

1EC

309 VQT3Y47

OPERATING INSTRUCTIONS (ENG LI SH /POLISH/C ZECH/HUNGARIAN)

1EP 309 VQT3Y48 OPERATIN G IN STRUCTIONS (ENGLISH) 1 EB

309 VQT3Y50 OPERATIN G IN STRUCTIONS (ENGLISH) 1 GC,GN 309 VQT3Y51 OPERATIN G IN STRUCTIONS (ARABIC/PERSI AN ) 1 GC

309 VQT3Y52

OPERATING INSTRUCTIONS (THA I/ CH INESE(TRA DITIONAL)/HINDI)

1GC

309 VQT3Y49

OPERATING INSTRUCTIONS (RUS SI AN /UKRAINIA N)

1EE 310 VPG3E04 PACKING CA SE 1 V700MP,MPC

310 VYQ7603 PACKING CASE UNIT 1 V700MPU 310 VYQ7604 PACKING CASE UNIT 1 V700MGK 310 VPG3F64 PACKING CA SE 1 V707MEG 310 VPG3E06 PACKING CA SE 1 V700P,PC 310 VPG3E07 PACKING CASE 1 V700EG,EF,EC,EP,EB,GC,EE,GN 310 VYQ7605 PACKING CA SE UNIT 1 V700GK 310 VPG3E08 PACKING CA SE 1 V707EGK 310 VYQ7606 PACKING CASE UNIT 1 V707EGS 311 VPN7349 PAD 1 312 VPF1447 PROTECT BA G 1 313 K2CA2YY00130 AC CORD W/PLUG 1 V700MGK, V700GK

314 K2CQ2YY00082 AC CORD W/PLUG 1

V707MEG, V700EG,EF,EC,EP,GC,EE, V707EGK,

EGS 315 K2CT3YY00034 AC CORD W/PLUG 1 V700EB,GC 316 K2CJ2YY00052 AC CORD W/PLUG 1 V700GN 317 --- BATTERY PACK 1

B1 XQN16+B5FJK SCREW 1 B2 XQN16+BJ7FJK SCREW 1 B3 XQN16+BJ7FJK SCREW 1 B4 XQN16+BJ4FJK SCREW 1 B5 XQN16+BJ4FJK SCREW 1 B6 XQN16+BJ6FJK SCREW 1 B7 XQN16+BJ6FJK SCREW 1 B8 XQN16+B6FJK SCREW 1

B9 XQN16+B6FJK SCREW 1 B10 XQN16+BJ5FJK SCREW 1 B11 XQN16+B4FJK SCREW 1 B12 XQN16+B4FJK SCREW 1 B13 XQN16+B3FN SCREW 1 B14 XQN16+B3FN SCREW 1 B15 XQN16+B3FN SCREW 1 B16 XQN16+B3FN SCREW 1 B17 VHD1907 SCREW 1 B18 VHD1907 SCREW 1 B19 VHD1907 SCREW 1 B20 VHD1919 SCREW 1 B21 VHD1919 SCREW 1 B22 VHD1919 SCREW 1 B23 VHD1919 SCREW 1 B26 VHD1688 SCREW 1 B27 VHD1688 SCREW 1 B28 XQN14+BJ4FJK SCREW 1 B29 XQN14+BJ4FJK SCREW 1 B30 XQN16+BJ4FN SCREW 1

B201 VHD2072 SCREW 1

Model No. : HC-V700/V700M/V707/V707M Parts List

Safety

Ref.

No.

Part No. Part Name & Description Q'ty Remarks

B202 VHD2072 SCREW 1 B203 VHD2072 SCREW 1 B204 VHD2072 SCREW 1 B205 VHD2072 SCREW 1 B206 VHD2072 SCREW 1 B207 VHD2072 SCREW 1 B208 VHD2072 SCREW 1

Panasonic HC-V700PC, HC-V700P, HC-V700EB, HC-V700EC, HC-V700EF Service Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
