Panasonic CT-27E13-1, CT-32E13-1 User Manual
Color Television
Operating Instructions
Televisor a color
Instrucciones de Operación
Télé-couleur
Manuel d’utilisation
CT-27E13-1 CT-32E13-1
TQB2AA0484 30317
PRINTED IN USA
IMPRESO EN EE.UU
IMPRIMÉ AUX ÉTATS-UNIS
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: To reduce the risk of electric shock do not remove cover or back.
No user-serviceable parts inside. Refer servicing to qualified service personnel.
ENGLISH
WARNING: To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture and objects filled with liquids, such as vases,
should not be placed on this apparatus.
FCC CAUTION:
ENVIRONMENTAL NOTICE:
The lightning flash with arrow
head within a triangle is
intended to tell the user that
parts inside the product are a
risk of electric shock to persons.
The Class II insulation symbol (square within a square) indicates
that this product has been evaluated and tested to comply with
Class II insulation requirements.
The exclamation point within a
triangle is intended to tell the
user that important operating
and servicing instructions are in
the papers with the appliance.
ANY CHANGES OR MODIFICATIONS TO THIS TV
RECEIVER NOT EXPRESSLY APPROVED BY
MATSUSHITA ELECTRIC CORPORATION OF AMERICA
COULD CAUSE HARMFUL INTERFERENCE, WHICH
WOULD VOID THE USER’S AUTHORITY TO OPERATE
THIS EQUIPMENT.
THIS PRODUCT UTILIZES CATHODE RAY TUBES (CRT) AND OTHER
COMPONENTS THAT CONTAIN LEAD. DISPOSAL OF THESE MATERIALS
MAY BE REGULATED IN YOUR COMMUNITY DUE TO ENVIRONMENTAL
CONSIDERATIONS. FOR DISPOSAL OR RECYCLING INFORMATION
PLEASE CONTACT YOUR LOCAL AUTHORITIES, OR THE ELECTRONICS
INDUSTRIES ALLIANCE: <HTTP://WWW.EIAE.ORG.>
The Energy Star label, a symbol for energy efficiency, was created by the U.S.
Environmental Protection Agency (EPA) and the U.S. Department of Energy
(DOE) to help customers identify products that can save them money and protect
the environment by saving energy. Energy Star compliant products generally
consume less energy than similar standard products.
Read these instructions completely before operating television.
Contents are subject to change without notice or obligation.
Copyright 2003 by Matsushita Electric Corporation of America. All rights reserved.
Unauthorized copying and distribution is a violation of law.
Table of Contents
TABLE OF CONTENTS
Congratulations...............................................2
Customer Record........................................................ 2
Care and Cleaning...................................................... 2
Specifications .............................................................. 2
Feature Chart.............................................................. 2
Installation........................................................3
Television Location ..................................................... 3
Optional Cable Connections....................................... 3
AC Power Supply Cord............................................... 3
Cable / Antenna Connection....................................... 3
Important Information Regarding The Use Of Video
Games, Computers, Or Other Fixed Image Displays.. 3
Auto Set Up Menu............................................4
Optional Equipment Connections ..................5
VCR............................................................................. 5
Front Control Panel..................................................... 5
Digital TV - Set-Top Box (DTV-STB) or DVD Players. 5
Amplifier (TO AUDIO AMP) ......................................... 5
Remote Control Operation..............................6
Battery Installation...................................................... 6
Operating Components with Remote Control............. 7
Programming the Remote........................................... 8
Programming Without a Code .................................... 8
Component Codes..................................................... 8
Icon Menu Navigation................................... 10
Icon Menu Operation..................................... 11
Set Up..........................................................................11
Picture..........................................................................11
Timer............................................................................12
Channels......................................................................12
Audio............................................................................13
Lock .............................................................................13
V-Chip Menu Operation ................................ 14
Troubleshooting Chart.................................. 17
ENGLISH
Note: The warranty and service center information is located in the back of this manual.
1 l
CON GRATULATIONS
Congratulations
Your new TV Monitor/Receiver features a solid state
chassis that is designed to give you many years of
enjoyment. It was thoroughly tested and tuned at the
factory for best performance.
Customer Record
The model and serial number of this product are located on
the back of the TV. You should note the model and serial
number in the space provided and retain as a permanent
record of your purchase. This will aid in identification in the
event of theft or loss. Product registration for U.S. customers
is available at: www.prodreg.com/panasonic.
Model
ENGLISH
Number
Serial
Number
Care and Cleaning
Screen (Turn TV Off)
• Use a mild soap solution or window cleaner and a clean
cloth.
• DO NOT USE ABRASIVE CLEANERS.
• Avoid excessive moisture and wipe dry.
Note: Do not spray any type of cleaning fluid directly on the
screen.
Cabinet and Remote Control
• For cabinets and remote control, use a soft cloth
dampened with water or a mild detergent solution.
• Avoid excessive moisture and wipe dry.
• Do not use benzene, thinner or other petroleum based
products.
Specifications
Specifications are subject to change without notice or
obligation.
Power Source
Component Input (Y / PB / PR)
CT-27E13-1 (2.0A)
CT-27E13-1U (2.0A)
CT-32E13-1 (2.2A)
CT-32E13-1U (2.2A)
Channel Capability - 181 VHF- 12; UHF-56; Cable-113
Video Input Jacks 1Vp-p, 75 Ohm, Phono Jack Type
Audio Input Jacks 500mV RMS 47K Ohm
Audio Output Jacks 0-2.0V RMS 4.7K Ohm
S-Video Input Jacks S-Video (Y-C) Connector
120V AC, 60Hz
75 Ohm, Phono Jack Type
Feature Chart
MODELS
FEATURES
MENU LANGUAGE ENG/SPAN/FR
CHANNEL INFO BANNER
VIDEO PICTURE MEMORY
VIDEO INPUT SKIP
CLOSED CAPTIONING
CT-27E13-1
• •
• •
• •
• •
• •
CT-32E13-1
V-CHIP CAPABILITY
VIDEO NORM
AUDIO NORM
STEREO
AI SOUND
BASS/BALANCE/TREBLE
SURROUND
A/V IN (REAR/FRONT)
AUDIO OUT
S-VHS INPUT
COMPONENT INPUT
HEADPHONE JACK
• •
• •
• •
• •
• •
• •
• •
3
(2/1) 3 (2/1)
• •
• •
• •
• •
2 l
Installation
INSTALLATION
Television Location
Follow these recommendations before deciding the
location of your television.
• Avoid excessive sunlight or bright lights, including
reflections.
• Keep away from excessive heat or moisture. Inadequate
ventilation may cause internal component failure.
• Fluorescent lighting may reduce remote control
transmitting range.
• Keep away from magnetic equipment, including motors,
fans and external speakers.
WARNING: Use this television receiver only with the
cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
In order to avoid injury to children, never place your television
receiver on a piece of furniture that is capable of being tilted by a
child leaning on it, pulling on it, standing on it, or climbing on it. A
falling television can cause serious injury or even death.
CT-27E13-1, CT-27E13-1U:
CAUTION: These television receivers for use only with
PANASONIC TY27E33T stand. Use with other carts (or
stands) is capable of resulting in instability causing
possible injury.
Cable / Antenna Connection
For proper reception, either a cable or antenna connection
is required.
Cable Connection
Connect the cable supplied by your local
cablecompany.
Note: A cable converter box may be
required for proper reception.
Check with your local cable
companyforcompatibility
requirements.
Incoming Cable from
Cable Company
75 Ohm VHF/UHF
on back of TV
Antenna Connections
• For proper reception of VHF/
UHF channels, an external
antenna is required. For best
reception an outdoor antenna
is recommended.
Note: Cable Mode is preset at the
factory. Antenna users must
change to TV Mode in the Set Upmenu under Prog
Chan .
Incoming Cable from
Home Antenna
Important Information Regarding The Use Of
Video Games, Computers, Or Other Fixed
Image Displays.
ENGLISH
CT-32E13-1, CT-32E13-1U:
CAUTION: These television receivers for use only with
PANASONIC TY-32E33T stand. Use with other carts (or
stands) is capable of resulting in instability causing
possible injury.
Optional Cable Connections
Shielded audio and video cables should be used between
components. For best results:
• Use 75-ohm coaxial shielded cables.
• Use appropriate input and output connectors, that match
your component connectors.
• Avoid long cables to minimize interference.
AC Power Supply Cord
CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE SLOT
OF AC OUTLET AND FULLY INSERT. DO NOT
USE A PLUG WITH A RECEPTACLE OR OTHER
OUTLET UNLESS THE BLADE CAN BE FULLY INSERTED TO
PREVENT BLADE EXPOSURE.
PROTECT POWER CORDS FROM BEING WALKED ON, ROLLED
OVER, CRIMPED, BENT, OR PINCHED, PARTICULARLY AT PLUGS,
CONVENIENCE RECEPTACLES, AND THE POINT WHERE THEY EXIT
FROM THE APPARATUS.
Polarized plug
WARNING: The marking or retained image on the
picture tube resulting from viewing fixed image is
not an operating defect and as such is not covered
by Warranty.
This television is designed to display constantly
moving images on the screen. Continuous viewing of
stationary images such as letterbox pictures on
standard screen TVs (with top/bottom bars), nonexpanded standard (4:3) pictures on wide screen TVs
(with side bars shown on each side of an image), stock
market report bars (ticker running at the bottom of the
screen), video game patterns, fixed scoreboards,
bright station logos, on-line (Internet) or repetitive
computer style patterns should be limited.
The extended use of fixed image program material can
cause a permanent picture tube damage, shown as a
“shadow image” viewable on normal programs. This
type of irreversible picture tube deterioration can be
limited by performing the following steps:
• Do not display the fixed image for extended periods
of time.
• Turn the power off when not in use.
3 l
AUTO SET UP MENU
Auto Set Up Menu
For your convenience, Auto Set up menu will be displayed
on screen when the set is turned on for the first time. If
needed, follow the menus and procedures for setting up the
features.
IDIOMA/LANGUE
To change menu language to ENGLISH, SPANISH or
FRENCH.
Procedure
• Press VOL u to select English, Spanish or French.
ENGLISH
MODE
To select TV (antenna) or CABLE mode depending on the
signal source.
Procedure
• Press VOL u to select TV or CABLE.
AUTO PROGRAM
To automatically program all channels with a signal.
Procedure
• Press VOL u to start Auto Programming.
4 l
Optional Equipment Connections
Note: The remote control must be programmed with supplied
codes to operate the optional equipment.
VCR Connection
VCRs, video disc players, video game equipment, and
DSS equipment can also be connected to the video inputs.
See the optional equipment manual for more information.
Note: VIDEO 1 input is a dual-purpose input. It is primarily
intended for connection with 480i devices such as a DVD
player using the Y PB PR component video jacks and
Audio L & R jacks. However, it can also be connected to
conventional composite video sources such as a VCR,
using only the Y/Video jack and Audio L & R jacks. The
on-screen label will display Component or Video 1
depending on which source is connected.
CONNECTION ON BACK OF TV
COMPONENT
R AUDIO L
VIDEO INPUT
TO AUDIO
AMP
INPUT 1
L
R
S-VIDEO
R
R AUDIO
PBP
Y/VIDEO
VIDEO
LINPUT 2
Jack used for 1/8"
headpone plug
CABLES NOT SUPPLIED
Procedure
• Connect equipment as shown to front or rear Audio/
Video input jacks.
• Select the Video mode by pressing TV/VIDEO button.
• Operate optional equipment as instructed in equipment
manual.
Front Control Panel
Use the front panel of the television to use the TV without
remote or to use the Audio/Video input jacks for optional
equipment.
Procedure
• Press TV/VIDEO to select VIDEO 3 input mode.
Note: The front control panel can be used to access menus
and switch video mode when the remote control is not
available.
VCR
VIDEO OUT
L
AUDIO OUT
R
ANT IN
ANT OUT
HPJ VIDEO 3 L AUDIO IN R
FRONT OF TV
OPTIONAL EQUIPMENT CONNECTIONS
Digital TV - Set-Top Box (DTV-STB) or DVD
Player Connection
Use this diagram to connect the Panasonic DTV-STB
(Digital TV-Set-Top Box) to the back of your TV.
TERMINALS ON BACK OF DTV-STB OR DVD PLAYER
CABLES NOT SUPPLIED
R-AUDIO-L
Notes:
COMPONENT
VIDEO INPUT
TO AUDIO
PBP
Y
R-AUDIO-L VIDEO
NTSC OUTPUT
DIGITAL OUTPUT
R
S-VIDEO
AMP
INPUT 1
L
R
COMPONENT VIDEO INPUT TERMINALS ON BACK OF TV
• There are three video inputs, Y, PB, and PR.
Separate component color inputs provide
luminance and color separation. Use the L (left)
and R (right) audio inputs.
• Select DTV-STB to 480i output mode. TV set can
receive 480i signal only.
S-VIDEO
R AUDIO L
R
R AUDIO
PBP
Y/VIDEO
VIDEO
LINPUT 2
Amplifier Connection (TO AUDIO AMP)
Connect to an external audio amplifier input for listening to
a stereo system.
Note: TO AUDIO AMP terminals can not be connected directly
to externalspeakers.
External Amplifier
CABLES NOT SUPPLIED
TO AUDIO
Audio Adjustments
• Select TV SPEAKERS ON from AUDIO menu.
• Set amplifier volume to minimum.
• Adjust television volume to desired level.
• Adjust amplifier volume to match the television.
• Select SPEAKERS OFF & VARIABLE AUDIO OUT from
AUDIO menu.
• Volume, mute, bass, treble and balance are now
controlled through the television.
Note: Select SPEAKERS OFF & FIXED AUDIO OUT to control
audio functions through the external amplifier.
CONNECTIONS ON BACK OF TV
COMPONENT
VIDEO INPUT
AMP
L
INPUT 1
R
S-VIDEO
R AUDIO
R
R AUDIO
L
PBP
Y/VIDEO
VIDEO
LINPUT 2
ENGLISH
5 l
REMOTE CONTROL OPERATION
C
R
Remote Control Operation
POWER
POWER
Press to turn ON and OFF.
D
B
S
/
V
V
T
Press to select remote operation.
C
B
L
D
V
D
SAP
Press to access second audio program.
VOL VOL
Press to adjust TV sound and navigate in
menus.
ACTION
ENGLISH
Press to access menus.
MUTE
Press to mute sound. Press to display and
cancel CC (Closed Caption).
TV/VIDEO
Press to select TV or Video mode.
MENU
Press to access DBS or DVD menus.
1 2
4
7
Press numeric keypad to select any channel.
R-TUNE
CH
CH
Press to select next or previous channel and
navigate in menus.
RECALL
Press to display time, channel, sleep timer,
and other options.
GUIDE
DBS functions button.
EXIT
DBS functions button.
3
5
6
8
9
Press to enter the minor number in a
compound channel number (DBS mode only).
PROG
0
EUR7613Z60
REW
PAUSE
PLAY
u
STOP
FF
REC
VCR /DBS CH
Press to switch to previously viewed
channel or video mode.
Battery Installation
Use two AA batteries:
Remove battery cover by pushing in and up neararrow.
Install batteries matching (+) and (-) polarity signs.
Replace the battery cover.
TV/VCR
Component function buttons
Precautions
• Replace batteries in pairs.
• Do not mix battery types (zinc carbon
with alkaline).
• Do not recharge, heat, short-circuit,
disassemble, or burn batteries.
Note: Incorrect installation can cause battery leakage and
corrosion that will damage the Remote Control.
6 l
Operating Components with Remote Control
EXIT
PROG
Note: Refer to page 8 for programming Remote Control
procedure.
Operating a VCR
Program the remote control to use with VCR.
TO DO THIS... PRESS
Turn on/off
POWER
REMOTE CONTROL OPERATION
Operating a DBS
Program the remote control to use with DBS.
TO DO THIS... PRESS
Turn on/off
Display DBS menu
POWER
ACTION
Select TV Input mode for VCR
Change Channels up/down
TV/VIDEO
VCR/DBS CH
REC
Record
Play
Stop
Fast Forward
Rewind the Tape
Pause
PLAY
u
STOP
FF
REW
PAUSE
TV/VCR
Change to TV or VCR Mode
On screen VCR Display
RECALL
Operating a CABLE BOX
Program the remote control to use with Cable Box.
TO DO THIS... PRESS
Turn on/off
POWER
CH
Menu Navigation
CH
1
2
4
Select a Channel
Program Infomation
Back to previous channel
Select next page up/down
5
7
809
RECALL
R-TUNE
VCR DBS CH
Exit menus
Display program Guide
GUIDE
Minor channel numbers
Operating a DVD
Program the remote control to use with DVD
TO DO THIS... PRESS
Turn on/off
POWER
VOL VOL
3
6
ENGLISH
Select a Channel
Change Channels Up/Down
Back to previous channel
1 2
4
7
R-TUNE
3
5
6
8
9
0
CH
CH
Next/Previous Chapter
DVD Display
Skip Search Reverse
Skip Search Fast Forward
Play
Open/Close
Stop
Still
Slow +/-
CH
CH
RECALL
REW
FF
PLAY
u
TV/VCR
STOP
PAUSE
VCR/DBS CH
7 l
REMOTE CONTROL OPERATION
ACTION
ACTION
Programming The Remote
The Universal Remote Control can be programmed to
operate many manufacturers’ components, using the
component function buttons for VCR, DVD, CABLE or
DBS. Follow the procedures for programming your Remote
Control with or without a code for the component.
Device Operates Default
TV TV (Panasonic Only) Panasonic Code
DBS/CBL DBS\CBL (Preset) Panasonic DBS Code
VCR VCR (Preset) Panasonic Code
DVD DVD (Preset) Panasonic Code
Note: Determine the manufacturer of the component and look
in the table for the code (found on page 9).
Procedure
ENGLISH
• Confirm that the external component is plugged and
operating.
• Turn the component off.
• Press and together, for at least 5
seconds.
• Press appropriate component button on the Remote
Control VCR, DVD, CABLE or DBS.
• Enter the 3-digit component code using the Remote
Control numeric keypad (0 ~ 9 buttons).
• Press the Remote Control to test the
component. If the procedure was successful, the
component will turnon.
Note: If the component does not operate with the Remote
Control, repeat the procedure using another code.
(Some brands have multiple codes). If an incorrect code
is entered, or if the procedure takes longer than 30
seconds, the programming will fail.
POWER
POWER
Programming Without A Code
This procedure searches all codes and is called the
“sequence method.”
• Confirm that the external component is plugged in
and on.
• Turn the component off.
• Press and together, for at least 5
seconds.
• Press appropriate component button on the
Remote Control.
• Press VOL u to move forward to the next code.
Press t VOL to move backward.
• Press the Remote Control to test the
component. If the procedure was successful, the
component will turn on.
Note: Repeat the above steps until the component code is
found. It may take many attempts before the correct
code isfound.
• After the code is found, press to store the
code.
POWER
POWER
ACTION
Component Codes
The Universal Remote Control is capable of operating
many component brands after entering a code. Some
components may not operate because the codes are not
available due to limited memory. The Universal Remote
Control does not control all features found in each model.
Write the code numbers from tables in this space.
This will serve as a reference if you need to program
your Remote Control.
VCR CABLE DVD
DBS
8 l
Component Codes (cont.)
Codes For VCR
Brand Code
Admiral
Aiwa 332
Akai 314, 315, 316, 329
Audio
Dynamic
Bell & Howell 305, 313
Broksonic 320, 326
Canon 323, 325
CCE 343
Citizen 306
Craig 305, 306, 329
Curtis Mathes 324, 345
Daewoo 301, 324, 343
DBX 310, 311, 339
Dimensia 345
Emerson
Fisher
Funai 320, 326, 334
GE 324, 333, 345
Goldstar 306
Gradiente 334
Hitachi 300, 323, 345
Instant Replay 323, 324
Jensen 339
JVC 310, 311, 334,339
Kenwood 306, 310, 311, 339
LXI
Magnavox 323, 324, 331
Marantz 310, 311, 339
Marta 306
Memorex 309, 324
MGA
Minolta 300, 345
Mitsubishi
Multitech 304, 347
NEC 310,311, 334, 339
Olympic 323, 324
Optimus 306, 321, 328, 335
Orion 320, 326
Panasonic 321,322, 323, 324
335
311, 339
303, 319, 320, 325,
326, 343
305, 307, 308, 309,
313
300, 305, 306,307,
308, 309
338, 340, 341,
347,348
338, 340, 341, 347,
348
J.C. Penney
Pentax 300,311, 345
Philco
Philips 323, 324, 331
Pioneer 323
Proscan
Quasar 321, 322, 323, 324
Radio Shack
RCA
Realistic
Samsung 302, 304, 333
Sansui 320, 326, 339, 352
Sanyo 305, 309, 313
Scott
Sears
Sharp 335, 336
Shintom 317
Signature
2000
Singer 337
Sony 328, 329, 330
Sylvania 331, 324, 331
Tashiro 306
Tatung 310, 311, 339
Teac 310, 311, 339
Technics 321, 322, 323, 324
Teknika 324
Toshiba 301, 346
Vector
Research
Wards
Yamaha 305, 310, 311, 339
Zenith 306,344
Codes For VCR (cont.)
Brand Code
300,305, 310, 311,
324, 339, 345
320, 323, 324, 326,
331, 343
300, 301, 302, 323,
324, 331, 333, 345,
346
305, 309, 324, 333,
336, 340
300, 301,302, 323,
324, 331, 333, 345,
346
305, 309, 324, 336,
340
301, 302, 304, 309,
320, 326, 338, 340,
347, 348
300, 305, 306, 307,
308
335
311
306, 309, 335, 336,
344
Codes For Cable Box
Brand Code
ABC 224
Archer 225, 232
Cableview 205, 232
Citizen 205, 222
Curtis 212, 213
Diamond 224, 225, 232
Eagle 229
Eastern 234
GC Brand 205,232
Gemini 222
General
Instrument/
Jerrold
Hamlin
Hitachi 203, 224
Macom 203, 204, 205
Magnavox 233
Memorex 230
Movietime 205, 232
Oak 202, 237,239
Panasonic 209, 210, 214
Philips
Pioneer 201, 216
Pulsar 205, 232
Puser
RCA 215
Realistic 232
Regal
Regency 234
Rembrandt 205, 232, 237
Samsung 205
Scientific Atlanta 211, 212, 213
Slmark 201, 205
Sprucer 205, 210
Stargate 205, 232
Teleview 201, 205
Texscan 244
Tocom 235
Toshiba 204
Unika 225, 232
Universal 222, 232
Videoway 206
Viewstar 229, 230
Zenith 200, 217
211, 219,
220, 221,
222, 223,
224, 225,
226, 227
212, 218,
240, 241,
242, 245
206, 207,
228, 229, 230
232
212, 218,
240, 241,
242, 245
REMOTE CONTROL OPERATION
Zenith / Drake
Satellite
Codes For DBS
Brand Code
Dish Network
(Echostar)
Echo Star 105
Express VU 105, 115
G.E. 106
G.I. (General
Instrument)
Gradiente 114
Hitachi 103, 111, 112
HNS (Hughes) 103
Magnavox 101, 102
Panasonic
Philips 101, 102
Primestar 108
Proscan
RCA
Sony 107
Star Choice 103, 108
Toshiba 100
Uniden 101, 102
Codes For DVD
Brand Code
Denon 100
Ferguson 101
JVC 109
Mitsubishi 105
Nordmende 101
Panasonic 100
Philips 103
Pioneer 102
RCA 101
Saba
Samsung 110
Sharp 108
Sony 104
Technics 100
Thomson 101
Toshiba 103
Yamaha 100
Zenith 107
200
105, 115, 116
108
104
106, 109,
110, 113
106, 109,
110, 113
101
ENGLISH
9 l
IC ON MENU NAVIGATION
Icon Menu Navigation
Press to display the Icons.
Press to select desired icon.
EXIT
ENGLISH
EXIT
Press to display selected
Icon features.
Press to select feature.
10 l
Press
Press repeatedly to exit menus.
to adjust or activate feature.
BRIGHTNESS 32 -- -- -- I -- -- --
NORMAL PICTURE
Icon Menu Operation
Note: Refer to page 10 for Icon Menu Navigation procedures.
SET UP
IDIOMA/LANGUE (Menu Languages)
r MODE - Select IDIOMA/LANGUE to change menu
language to ENGLISH, ESPAÑOL (Spanish) or
FRANÇAIS (French).
Note: While highlighted, press VOL u to select English,
Spanish or French.
PROG CHAN (Program Channels)
Note: While highlighted, press VOL u to select or activate
features.
r MODE - To select TV (antenna) or CABLE mode
depending on the signal source.
r AUTO PROGRAM - To automatically program all
channels with a signal.
r MANUAL PROGRAM - To manually add or delete
channels.
Note: Use Remote numeric keypad to enter channel numbers
in Manual Program sub menu.
(CLOSED CAPTIONING)
CC
This television contains a built-in decoder that displays
CC
(Closed Captioned) text across the screen (white or
colored letters on black background). It allows the viewer to
read the dialogue of a television program or other
information. The program viewed must include Closed
Captioning for the feature to work.
Note: While highlighted, press VOL u to select modes.
r ON MUTE - Activates the onscreen Closed
CC
Caption feature when the MUTE button on the remote
control is pressed. To deactivate press MUTE button
again.
ICON MENU OPERATION
r MODE - Activates the onscreen Closed Caption
CC
feature by selecting one of the following modes.
• OFF - When Closed Caption is not desired.
• C1 - For video related information to be displayed, up to
4 lines onscreen at a time. (It does not block relevant
parts of the picture). Text may be in any language.
• C2 - For other modes of video related information.
Note: C1 mode is recommended for viewing Closed Caption.
Other Adjustments
Note: While highlighted, press VOL u to select or activate
features.
r AUTO POWER ON - Select SET to power up the TV at
the same time as the Cable box or other components
or select OFF.
r CHAN BANNER - Select ON to display onscreen
banner when changing channels.
Note: While highlighted, press VOL u to select or adjust
features.
VIDEO ADJ.
r COLOR - Adjusts desired color intensity.
r TINT - Adjusts natural flesh tones.
r BRIGHTNESS - Adjusts dark areas of picture.
r PICTURE - Adjusts white areas of picture.
r SHARPNESS - Adjusts clarity of outline detail.
r NORMAL - Reset adjustments to factory default
settings.
Note: Video adjustments can be individually set for each video
input mode.
OTHER ADJ.
Note: While highlighted, press VOL u to select or activate
feature.
r COLOR TEMP (temperature) - To increase or
decrease WARM (red) and COOL (blue) colors to suit
personal preferences.
ENGLISH
11 l
IC ON MENU OPERATION
TIMER
CLOCK SET
r TIME - Set the time of the day.
r Day - Set the day of the week.
Procedure
Note: Use t VOL , VOL u and CH q to set time and day.
SLEEP
r How Long? - Select 30, 60 or 90 minutes for TV to turn
ENGLISH
off. Select NO to turn off Sleep timer.
TIMER 1 AND TIMER 2
Select one or both timers to turn the television on and off at
selected times, on selected channels, and on selected
days. Time must be entered in CLOCK SET to operate the
TIMER features.
Procedure
• Use the VOL u and CH q to set day, On Time, Off
Time and Channel number, then use the VOL u to
activate.
CHANNELS
FAVORITES
r CHANNEL SCAN FAV - To enter up to 16 favorite
channels.
Note: Use remote numeric keypad to select desired FAV
channels.
r CHANNEL SCAN ALL - To scan all channels when
using the CH up/down buttons.
CAPTION
r MANUAL CAPTION - To enter numbers and captions
manually.
Note: Use the remote numeric keypad to select desired
channel (refer to your local TV guide).
r INPUT LABEL - To label video input connections for
onscreen display.
Notes:
• The television automatically turns OFF after 90 minutes
when turned ON by the TIMER. If the OFF time is
selected or if a key is pressed, the automatic OFF after
90 minutes will becancelled.
• The TIMER is active when the television is OFF or ON.
The television will switch to the selected channel at the
selected time set in the TIMER.
Procedure
• Press CH p or CH q to select the desired Video input.
• Press t VOL or VOL u to select the first character.
• Press CH q to enter the next position and repeat the
step above to enter the next character.
• Repeat above steps until all characters are entered.
VIDEO INPUT SKIP FEATURE
This receiver has a Video Input Skip Feature, which will
allow the user to skip desired input modes when pressing
TV/VIDEO button.
Procedure
• Press t VOL while the first character is highlighed to
skip selected video input.
r To delete skip feature, press the VOL u button while the
desired video input mode is highlighted.
12 l
ICON MENU OPERATION
AUDIO
AUDIO ADJ.
r MODE - Select STEREO, SAP (Second Audio
Program) or MONO. (Use MONO when stereo signal is
weak).
r BASS - Increase or decrease the bass response.
r TREBLE - Increase or decrease the treble response.
r BALANCE - Emphasize the left/right speaker volume.
r NORMAL - Reset BASS, TREBLE and BALANCE
adjustments to factory default settings.
OTHER ADJ.
r AI SOUND - Equalize overall volume levels across all
channels. (AI sound is not available in VIDEO mode).
Procedure
• Press VOL u to select On or OFF.
LOCK
MODE
r LOCK SET - To prevent video games, VCR tapes and
all channels and video modes from being viewed.
Notes:
• Use the remote numeric keypad to enter a four-digit
secret code (Use a code that is easy to remember and
record it in a safe place).
• If you do not remember your code, LOCK will unlock in
12, 24, or 48 hours, depending on the current setup. Be
cautious when selecting ALWAYS. If ALWAYS is
selected, and you forget your secret code, the TV must
be serviced by a qualified technician to clear the LOCK
setup.
• If you select CHANGE CODE, and you change your
code from the one used in the LOCK menu, your new
code becomes the controlling code.
Procedure
• Press VOL u to select.
• OFF - Turns Lock function off.
• GAME - Lock CH 3, 4 and Video inputs.
• CHANNEL - Lock up to four channels.
• ALL - Locks all channels and video inputs.
ENGLISH
SURROUND
r MODE - Enhances audio response when listening to
stereo.
Procedure
• Press VOL u to select On or OFF.
SPEAKERS
r SPEAKERS - This feature is used when connecting to
an external amplifier.
Procedure
• Press VOL u to select.
• ON - TV speakers operate normally.
• OFF & Variable Audio Out - TV speakers off - audio
adjustable by television.
• OFF & Fixed Audio Out - TV speakers off - audio
adjustable by the external amplifier only.
• Press twice.
ACTION
• Press CH q to highlight HOW LONG?
• Press VOL u to select 12 Hours, 24 Hours, 48 Hours or
ALWAYS.
Note: If GAME, CHANNEL or ALL is selected, and if a blocked
channel or video input is selected, the message
LOCKED displays in the upper left corner of the TV
screen.
13 l
V-CHIP MENU OPERATION
V-Chip Menu Operation
Procedure
• Use the numeric keypad to enter your four digit code.
(Use a code that is easy to remember and record it in
a safe place.)
• Press CH q to enter the BLOCK PROGRAMS field.
• Press t VOL or VOL u to select desired option: U.S.
TV Programs, U.S. Movies, Canadian English or
Canadian French.
• Press CH q to highlight STATUS.
• Press t VOL or VOL u to display desired rating chart:
U.S. TV Programs, U.S. Movies, Canadian English or
Canadian French.
• Press VOL u to select ON or OFF.
• Press CH q to select VIEW NR PROGRAMS? for U.S.
ENGLISH
TV Programs and U.S. Movies or VIEW E PROGRAMS
for Canadian English and Canadian French.
• Press VOL u to select YES or NO.
U.S. TV PROGRAMS
This TV model features the “V-Chip technology” which
allows you to use U.S. TV PROGRAMS Guide ratings to
block various types of TV programs.
Note: Selecting “Yes”, NR programs will be received. Selecting
“NO”, NR programs will be blocked (See Customer
Caution below). .
Procedure
• Press CH q to select SETTING.
• Press VOL u to select BASIC or DETAILED.
BASIC - Allows you to select only general ratings such
as TV-Y, TV-PG, etc.
DETAILED - Allows you to select both general ratings
and content such as V, L, etc.
• Press CH q or CH p to move between different ratings.
• Use t VOL or VOL u to select ratings you want to
block (RED) and unblock (GREEN).
• Press twice to return to MODE in Lock menu.
• Press CH q to select HOW LONG?.
• Press t VOL or VOL u to select 12, 24, 48 hours or
ACTION
ALWAYS.
Customer Caution
The V-Chip system that is used in this set is capable of
blocking “NR” programs (non rated, not applicable and none)
per FCC Rules Section 15.120(e)(2). If the option of blocking
“NR” programs is chosen “unexpected and possibly confusing
results may occur, and you may not receive emergency
bulletins or any of the following types of programming: ”
• Emergency Bulletins (Such as EAS messages,
weather warnings and others)
• Locally originated programming
• News
• Political
• Public Service Announcements
• Religious
• Sports
• Weather
U.S. TV Programs Rating Chart Description
NR
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
FV FANTASY/CARTOON VIOLENCE
V VIOLENCE
S SEX
L OFFENSIVE LANGUAGE
D DIALOGUE WITH SEXUAL CONTENT
Not Rated. SEE CUSTOMER CAUTION on
previous page.
All children. The themes and elements in this
program are specifically designed for a very young
audience, including children from ages 2-6.
Directed to older children. Themes and elements
in this program may include mild physical or
comedic violence, or may frighten children under
the age of 7.
General audience. It contains little or no violence,
no strong language, and little or no sexual dialogue
or situations.
Parental guidance suggested. The program may
contain infrequent coarse language, limited
violence, some suggestive sexual dialogue and
situations.
Parents strongly cautioned. This program may
contain sophisticated themes, sexual content,
strong language and more intense violence.
Mature audiences only. This program may
contain mature themes, profane language, graphic
violence, and explicit sexual content.
U.S. MOVIES
This TV model features the “V-Chip technology” which
allows you to use Motion Picture Ratings when viewing
movies or video tapes. This innovation allows parents to
block various types of movies and video tapes at their
discretion.
14 l
V-Chip Menu Operation (cont.)
U.S. MOVIES (cont.)
Note: Some movies are not rated for a variety of reasons. Old
movies and foreign films are usually not rated.
Procedure
• Press CH q or CH p to move between different ratings.
• Use t VOL or VOL u to select ratings you want to
block (RED) and unblock (GREEN).
• Press twice to return to MODE in Lock menu.
• Press t VOL or VOL u to select 12, 24, 48 hours or
PG-13
NC-17 NO ONE 17 AND UNDER ADMITTED.
CANADIAN ENGLISH
The V-CHIP used in this TV model allows you to block
various types of movies and television programs based on
the two rating systems used in Canada.
ACTION
ALWAYS.
U.S. Movies Rating Chart Description
NR
G GENERAL AUDIENCES. All ages admitted.
PG
R
X ADULTS ONLY.
CONTAINS NO RATING (NOT RATED) AND NA
(NOT APPLICABLE) PROGRAMS . Movie has
not been rated or rating does not apply.
PARENTAL GUIDANCE SUGGESTED. Some
material may not be suitable for children.
PARENTS STRONGLY CAUTIONED. Some
material may be inappropriate for children under
13.
RESTRICTED. Under 17 requires accompanying
parent or adult guardian.
V-CHIP MENU OPERATION
Note: E (Exempt) programming includes: news, sports,
documentaries and other information programming, talk
shows, music videos, and variety programming.
Procedure
• Press CH q or CH p to move between different
ratings.
• Use t VOL or VOL u to select ratings you want to
block (RED) and unblock (GREEN).
• Press twice to return to MODE in Lock menu.
• Press t VOL or VOL u to select 12, 24, 48 hours or
.
C8+
CANADIAN FRENCH
The V-CHIP used in this TV model also lets you block or
unblock Canadian French programs according to various
ratings categories.
ACTION
ALWAYS.
Canadian English Rating Description
Exempt - Exempt programming includes:
E
C
G
PG
14+
18 ADULTS ONLY
news, sports, documentaries and other
information programming, talk shows, music
videos, and variety programming.
Programming intended for children under age
8. No offensive language, nudity or sexual
content.
Programming generally considered
acceptable for children 8 years and over. No
profanity, nudity or sexual content.
General programming, suitable for all
audiences.
Parental Guidance suggested. Some material
may not be suitable for children.
Programming contains themes or content
which may not be suitable for viewers under
the age of 14. Parents are strongly cautioned
to exercise discretion in permitting viewing
by pre-teens and early teens.
ENGLISH
Note: E (Exempt) programming includes: news, sports,
documentaries and other information programming, talk
shows, music videos, and variety programming.
15 l
V-CHIP MENU OPERATION
V-Chip Menu Operation (cont.)
CANADIAN FRENCH (cont.)
Procedure
• Press CH q or CH p to move between different ratings.
• Use t VOL or VOL u to select ratings you want to
block (RED) and unblock (GREEN).
ACTION
ALWAYS.
Canadian English Rating Description
E Exempt - Exempt programming.
General - Programming intended
G
8 ans +
13 ans +
16 ans +
18 ans +
for audience of all ages. Contains
no violence, or the violence
content is minimal or is depicted
appropriately.
8+ General - Not recommended for
young children. Programming
intended for a broad audience but
contains light or occasional
violence. Adult supervision
recommended.
Programming may not be suitable
for children under the age of 13 Contains either a few violent
scenes or one or more sufficiently
violent scenes to affect them.
Adult supervision strongly
suggested.
Programming may not be suitable
for children under the age of 16 Contains frequent scenes of
violence or intense violence.
Programming restricted to adults.
Contains constant violence or
scenes of extreme violence.
ENGLISH
• Press twice to return to MODE in Lock menu.
• Press t VOL or VOL u to select 12, 24, 48 hours or
BLOCKING MESSAGE
If V-Chip is enabled and the program exceeds the rating
limit set by you, the blocking message will appear and the
audio will be muted. Enter your four-digit secret code if you
wish to continue viewing the program. After entering your
code, all locks and rating blocks are disabled until the TV is
turned off or until all settings are off.
Note: If you enter your four-digit secret code to override rating
blocks, you must reset all rating blocks by either
reprogramming or turning the TV off.
16 l
Troubleshooting Chart
Before calling for service, determine the symptoms and follow suggested solutions.
AUDIO VIDEO Solutions
Noisy Audio
Noisy Audio
Noisy Audio
No Audio
Noisy Audio
No Audio
Snowy Video
Multiple Image
Interference
Normal Video
No Video with
Snow
?
No Video
TROUBLESHOOTING CHART
Adjust Antenna Location and Connection
Check Cable Connection
Adjust Antenna Location and Connection
Check Antenna Lead-in Wire
Check Cable Connection
Move television from Electrical Appliances, Lights,
Vehicles and Medical Equipment
Increase Volume
Check Mute
Check television SPEAKERS on/off
Change Channel
Set TV or Cable Mode Properly
Check Antenna Cables
Check Power Cord is Plugged into Active Outlet
Adjust Brightness and Audio Controls
Change Channel
Check Cable Connections
Program the Remote Control Again
Check Second Video Source Operation
ENGLISH
Normal Audio
Wrong Audio
Normal Audio Normal Video
Intermittent Remote Control Operation
No Color
Normal Video
Adjust Color Settings
Change Channel
Check Audio Is Set To Stereo or Mono, Not SAP
Replace Remote Control Batteries
17 l
IN DEX
Index
A
AC Power Supply Cord 3
Amplifier Connection
(To Audio Amp) 5
Antenna Connections 3
Audio 13
Audio ADJ. 13
Auto Power On 11
Auto Program 4
Auto Set Up Menu 4
B
Balance 13
Bass 13
ENGLISH
Battery Installation 6
Blocking Message 16
Brightness 11
C
Cabinet and Remote Control 2
Cable / Antenna Connection 3
Cable Connection 3
Canadian English 15
Canadian French 15
Caption 12
Care and Cleaning 2
Chan Banner 11
Channel Scan All 12
Channel Scan Fav 12
Channels 12
Clock Set 12
Closed Captioning 11
Codes For Cable Box 9
Codes For DBS 9
Codes For DVD 9
Codes For VCR 8
Color 11
Color Temp 11
Component Codes 8, 9
Congratulations 2
Convergence 4
Customer Record 2
D
Digital TV - Set-Top Box
(DTV-STB) or DVD Player
Connection 5
F
Favorites 12
Feature Chart 2
Front Control Panel 5
G
Game 13
I
Icon Menu Navigation 10
Icon Menu Operation 11
Idioma/langue 4
Input Label 12
Installation 3
L
Lock 13
M
Manual Caption 12
Menu Languages 11
Mono 13
N
Normal 11
O
On Mute 11
Operating a Cable Box 7
Operating a DBS 7
Operating a DVD 7
Operating a VCR 7
Operating Components with
Remote Control 7
Optional Cable Connections 3
Optional Equipment
Connections 5
Other Adj. 13
Other Adj. 11
Other Adjustments 11
P
Picture 11
Program Channels 11
Programming The Remote 8
Programming Without A Code 8
R
Regarding The Use Of Video
Games 3
Remote Control Operation 6
S
Set Up 11
Sharpness 11
Sleep 12
Speakers 13
Specifications 2
Surround 13
T
Television Location 3
Timer 11, 12
Timer 1 and Timer 2 12
Tint 11
Treble 13
Troubleshooting Chart 17
U
U.S. Movies 14
U.S. TV Programs 14
V
V-Chip Menu Operation 14
VCR Connection 5
Video Adj. 11
Video Input Skip Feature 12
18 l
Loading...
