OPERATING INSTRUCTIONS

Personal Computer

Model No. CF-W2 Series

1 2

For first-time and basic operation, refer to the Operating Instructions (this manual).

For more information on how to use this computer, refer to the onscreen Reference Manual. Î page 13

For your technical support office, refer to the Operating Instructions.

Contents Preparations

Read Me First ..............................................................

Usage Precautions/About Notations......................... 12

How to Use this Manual............................................ 13

Features.................................................................... 14

Names and Functions of Parts ................................. 15

Confirm the Status Using the LEDs .......................... 17

First-time Operation .................................................. 18

Page

Getting Started (Basic Operations)

Starting Up/Shutting Down ....................................... 24

Using the Touch Pad................................................. 26

Using the Fn key....................................................... 27

Expanding Memory................................................... 28

Setup Utility............................................................... 30

Useful Information

Usage / Handling / Maintenance............................... 37

Wireless LAN ............................................................ 39

Windows / Antivirus Measures.................................. 40

Use of Peripheral Devices / Internal Hard Disk......... 42

Using CD/DVD .......................................................... 43

Preparations

Getting Started

Useful Information

Troubleshooting

List of Error Codes.................................................... 44

How to Resolve the Problem .................................... 45

Dealing with Problems (Summary) ........................... 46

Information for Installed Applications........................ 53

Reinstalling Software ................................................ 54

Important Information

LIMITED USE LICENSE AGREEMENT ................... 59

Hard Disk Data Erase Utility ..................................... 60

Specifications............................................................ 62

LIMITED WARRANTY .............................................. 65

Index ............................................................. back cover

Troubleshooting

Important Information

Customer’s Record

Model No.*

Serial No.

or Code No.

Date of Purchase

For the Model No., insert the 12 digit number (for example, CF-W2DWB02KM) located on the bottom of the computer.

Dealer’s Name

Dealer’s Address

Introduction

Thank you for purchasing the Panasonic computer. Read this manual thoroughly for proper operation of your new computer.

This manual is copyrighted by Matsushita Electric Industrial Co., Ltd. with all rights reserved. No part of this manual may be reproduced in any form without the prior written permission of Matsushita Electric Industrial Co., Ltd. No patent liability is assumed with respect to the use of the information contained herein.

Disclaimer

Computer specifications and manuals are subject to change without notice. Matsushita Electric Industrial Co., Ltd. assumes no liability for damage incurred directly or indirectly from errors, omissions or discrepancies between the computer and the manuals.

Trademarks

Microsoft, Windows and the Windows logo are registered trademarks of Microsoft Corporation of the United States and/or other countries. Intel, Pentium and PROSet are either registered trademarks or trademarks of Intel Corporation. SD Logo is a trademark.

Adobe other countries.

WinDVD Panasonic is a registered trademark of Matsushita Electric Industrial Co., Ltd. Names of products, brands, etc., appearing in this manual are trademarks or registered trademarks of their respective owner companies.

and Acrobat® are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or

™ is a trademark of InterVideo, Inc.
