Panasonic CF-18KDH77VM, CF-18KDQZXVM User Manual
Tablet PC
OPERATING INSTRUCTIONS
Personal Computer
Model No. CF-18 Series
Contents
Getting Started
Read Me First ................................................. 3
Names and Functions of Parts ........................ 9
First-time Operation ...................................... 13
• Read Me First
• Key Combinations
Operation
Starting Up/Shutting Down ............................ 17
Touch Pad (Basic Operation) ............................. 20
Digitizer (Basic Operation) ................................. 21
Operating in Tablet Mode .............................. 22
Reference Manual ......................................... 24
Useful Information ......................................... 25
Reference Manual
• LED Indicators
Getting Started
[Additional Manual]
Reference Manual
This manual can be accessed on your computer. Refer to page 24 on how to access the Reference Manual.
• Tablet Buttons
• Touch Pad
Digitizer
•
• Display Rotation
• Standby/Hibernation
Functions
• Security Measures
Computing on the Road
•
• Battery Power
• PC Cards
• SD Memory Card
• SD Memory Card
Security Function
(Advanced)
• RAM Module
• Port Replicator
• External Display
• USB Devices
• Modem
• LAN
• Wireless LAN
• Bluetooth
• Wireless Switch Utility
• Hard Disk Drive
• Setup Utility
• Icon Enlarger
• Loupe Utility
Troubleshooting
Reference Manual
List of Error Codes ........................................ 29
Dealing with Problems (Summary) .................. 30
Reinstalling Software .................................... 35
Reference Manual
• Technical Information
• DMI Viewer
• List of Error Codes
• Dealing with Problems
(Advanced)
Appendix
LIMITED USE LICENSE AGREEMENT ....... 37
Hard Disk Backup Function ............................. 39
Hard Disk Data Erase Utility.......................... 43
Specifications ................................................ 44
LIMITED WARRANTY................................... 46
Operation
Troubleshooting
Appendix
Please read these instructions carefully before using this product and save this manual for future use.
Customer's Record
Model No.*
Serial No.
or
Code No.
Date of Purchase
* For the Model No., insert the 12 digit number (for example, CF-18KDHZXVM) located on
the bottom of the computer.
Dealer's Name
Dealer's Address
Introduction
Thank you for purchasing the Panasonic computer. Read the operating instructions thoroughly for proper operation of your new
computer.
Illustrations and Terminology in this Manual
Getting Started
NOTE: NOTE provides a useful fact or helpful information.
CAUTION: CAUTION indicates a condition that may result in minor or moderate injury.
Enter : This illustration means to press the [Enter] key.
Fn + F5 : This illustration means to press and hold the [Fn] key, then press the [F5] key.
[start] - [Run]: This illustration means to click [start], then to click [Run]. For some applications, you may need to
double-click.
: Where to go for referred information.
: This illustration means to refer to the Reference Manual, which is available on your computer.
Refer to page 24 on how to access this manual.
Some of the illustrations in this manual may differ slightly in shape from the actual items in order to make the explanation
easier to understand.
The “CD/DVD drive” is a description about drives, such as DVD-ROM, CD-ROM, CD-R/RW, and DVD-ROM & CDR/RW drives.
In this manual, descriptions are given using illustrations not featuring the hand strap for convenience of explanation.
If the user has logged on without administrator authority, some functions may not be executable, and some screens may not
be displayed as shown in this manual. If this happens, log on with the administrator authority to enable these functions.
Confirm the latest information on optional products in catalogs, etc.
In this manual, “Microsoft® Windows® XP Tablet PC Edition 2005” is indicated as “Windows” or “Windows XP”.
Copyright
This manual is copyrighted by Matsushita Electric Industrial Co., Ltd. with all rights reserved. No part of this manual may be
reproduced in any form without the prior written permission of Matsushita Electric Industrial Co., Ltd.
No patent liability is assumed with respect to the use of the information contained herein.
© 2005 Matsushita Electric Industrial Co., Ltd. All Rights Reserved.
Disclaimer
Computer specifications and manuals are subject to change without notice. Matsushita Electric Industrial Co., Ltd. assumes no
liability for damage incurred directly or indirectly from errors, omissions or discrepancies between the computer and the manuals.
Trademarks
Microsoft, Windows, the Windows logo and IntelliMouse are registered trademarks of Microsoft Corporation of the United States
and/or other countries.
Intel, Pentium and PROSet are either registered trademarks or trademarks of Intel Corporation.
SD Logo is a trademark.
Adobe, the Adobe logo and Adobe Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the
United States and/or other countries.
Bluetooth is a trademark owned by Bluetooth SIG, Inc., U.S.A. and licensed to Matsushita Electric Industrial Co., Ltd.
Panasonic is a registered trademark of Matsushita Electric Industrial Co., Ltd.
Names of products, brands, etc., appearing in this manual are trademarks or registered trademarks of the respective owner companies.
2
Read Me First
For U.S.A.
Federal Communications Commission Radio
Frequency Interference Statement
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the Panasonic Service Center or an experienced radio/TV technician for help.
Warning
To assure continued compliance, use only shielded interface
cables when connecting to a computer or peripheral. Also, any
changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate this equipment.
FCC RF Exposure Warning:
This equipment is provided with PC Card slot that could be
used with wireless transmitters, which will be specifically
recommended when they become available.
Other third-party wireless transmitters have not been RF exposure evaluated for use with this computer and may not comply with FCC RF exposure requirements.
<Only for models with wireless LAN and/or Bluetooth>
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment has been approved for portable operation,
and unless otherwise advised in separate supplemental instructions for individual wireless transmitter(s), requires minimum 1.5 cm spacing be provided between antenna(s) and all
person’s body (excluding extremities of hands, wrist and feet)
during wireless modes of operation.
This equipment may use multiple installed transmitters, which
may be capable of simultaneous transmission.
This equipment is provided with external antenna connector(s)
for connection to optional Car Mounter or Port Replicator for
mobile external mounted antenna(s). External antenna(s) must
be professionally installed and cannot exceed recommended
maximum antenna gain as described in individual provided
supplement instructions for wireless transmitters. Also, user
must maintain minimum 20 cm spacing between external
antenna(s) and all person’s body (excluding extremities of
hands, wrist and feet) during wireless modes of operation.
<Only for models with wireless LAN>
This product is restricted to indoor use due to its operation in
the 5.15 to 5.25 GHz frequency range.
FCC requires this product to be used indoors for the frequency
range 5.15 to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems.
High power radars are allocated as primary users of the 5.25 to
5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can
cause interference with and /or damage this product.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Responsible Party: Panasonic Corporation of North America
One Panasonic Way
Secaucus, NJ 07094
Tel No:1-800-LAPTOP5 (1-800-527-8675)
FCC Regulation Notice for modem
This equipment contains a FCC approved modem.
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
1. This equipment complies with CFR47 Part 68 rules. On the
computer is a label that contains, among other information,
the FCC registration number and ringer equivalence number
(REN) for this equipment. If required, this information must
be provided to the telephone company.
2. An FCC compliant telephone cord and modular plug is provided with this equipment. This equipment is designed to be
connected to the telephone network or premises wiring using a compatible modular jack which is Part 68 compliant.
See Installation Instructions for details.
3. The REN is used to determine the quantity of devices which
may be connected to the telephone line. Excessive RENs on the
telephone line may result in the devices not ringing in response
to an incoming call. In most, but not all area, the sum of RENs
should not exceed five (5.0). To be certain of the number of
devices that may be connected to a line, as determined by the
total RENs, contact the local telephone company.
4. If your telephone equipment cause harm to the telephone
network, the telephone company will notify you in advice
that temporary discontinuance of service may be required.
But if advice notice isn’t practical, the telephone company
will notify the customer as soon as possible. Also, you will
be advised of your right to file a complaint with the FCC if
you believe it is necessary.
5. The telephone company may take changes in its facilities,
equipment, operations or procedures that could affect the operation of the equipment. If this happens the telephone company will provide advance notice in order for you to make
necessary modifications to maintain uninterrupted service.
6. If trouble is experienced with this equipment, for repair or
warranty information, please contact Panasonic Corporation
of North America at DIAL TOLL FREE 1-800-LAPTOP5
(1-800-527-8675). If the equipment is causing harm to the
telephone network, the telephone company may request that
you disconnect the equipment until the problem is resolved.
7. There are no user serviceable parts contained in this equipment.
8. This equipment may not be used on coin service provided
by the telephone company. Connection to party lines is subject to state tariffs.
Getting Started
3
Read Me First
9. The Telephone Consumer Protection Act of 1991 makes it
unlawful for any person to use a computer or other electronic
device to send any message via a telephone fax machine unless such message clearly contains in a margin at the top or
bottom of each transmitted page or on the first page of the
transmission, the date and time it is sent and an identification
of the business or other entry, or other individual sending the
message and the telephone number of the sending machine or
such business, other entity, or individual. In order to program
this information into your fax software, you should refer to
the manual of the Fax software being used.
10.According to the FCC’s electrical safety advisory, we recommend that you may install an AC surge arrestor in the AC
outlet to which this equipment is connected. Telephone companies report that electrical surges, typically lightning transients, are very destructive to customer terminal equipment
connected to AC power sources and that this is a major nationwide problem.
“Caution: To reduce the risk of fire, use only No.26 AWG or larger telecommunication line cord.”
“ATTENTION: Pour réduire le risque d’incendie, utiliser uniquement des
conducteurs de télécommunications 26 AWG ou de section supérieure.”
Getting Started
For Canada
Industry Canada (IC) Notice for modem
This equipment contains an Industry Canada approved modem unit.
The Industry Canada label is affixed on the modem unit.
EQUIPMENT ATTACHMENT LIMITATIONS
“NOTICE: The Industry Canada label identifies certified
equipment. This certification means that the equipment meets
telecommunications network protective, operational and
safety requirements as prescribed in the appropriate Terminal
Equipment Technical Requirements document(s). The
Department does not guarantee the equipment will operate
to the user’s satisfaction.
Before installing this equipment, users should ensure that it
is permissible to be connected to the facilities of the local
telecommunications company. The equipment must also be
installed using an acceptable method of connection. The
customer should be aware that compliance with the above
conditions may not prevent degradation of service in some
situations.
Repairs to certified equipment should be coordinated by a
representative designated by the supplier. Any repairs or
alterations made by the user to this equipment, or equipment
malfunctions, may give the telecommunications company
cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical
ground connections of the power utility, telephone lines and
internal metallic water pipe system, if present, are connected
together. This precaution may be particularly important in
rural areas. Caution: Users should not attempt to make such
connections themselves, but should contact the appropriate
electric inspection authority, or electrician, as appropriate.”
“NOTICE: The Ringer Equivalence Number (REN) assigned
to each terminal device provides an indication of the
maximum number of terminals allowed to be connected to a
telephone interface. The termination on an interface may
consist of any combination of devices subject only to the
requirement that the sum of the Ringer Equivalence Numbers
of all the devices does not exceed 5.”
REN: See bottom of the computer
4
Notice for the products using LCD
This product uses one or more fluorescent lamps containing a
small amount of mercury. It also contains lead in some components. Disposal of these materials may be regulated in your community due to environmental considerations. For disposal or
recycling information please contact your local authorities, or
the Electronics Industries Alliance: <http://www.eiae.org/>
UL1604-conforming model. (The model which has description of “UL1604” in the bottom of the computer.)
• THIS EQUIPMENT IS SUITABLE FOR USE IN CLASS I,
DIVISION 2, GROUPS A, B, C AND D OR NON-HAZARDOUS LOCATIONS ONLY.
• WARNING – EXPLOSION HAZARD – SUBSTITUTION
OF COMPONENTS MAY IMPAIR SUITABILITY FOR
CLASS I, DIVISION 2.
• When connecting and using a device manufactured by a third
party, enquire to the manufacturer as to whether the device
suits CLASS I, DIVISION 2.
RESTRICTIONS CONCERNANT LE RACCORDEMENT
DE MATÉRIEL
“AVIS: L’étiquette d’Industrie Canada identifie le matériel
homologué. Cette étiquette certifie que le matériel est
conforme aux normes de protection, d’exploitation et de
sécurité des réseaux de télécommunications, comme le
prescrivent les documents concernant les exigences techniques relatives au matériel terminal. Le Ministère n’assure
toutefois pas que le matériel fonctionnera à la satisfaction
de l’utilisateur.
Avant d’installer ce matériel, l’utilisateur doit s’assurer qu’il
est permis de le raccorder aux installations de l’entreprise
locale de télécommunication. Le matériel doit également être
installé en suivant une méthode acceptée de raccordement.
L’abonné ne doit pas oublier qu’il est possible que la
conformité aux conditions énoncées ci-dessus n’empêche pas
la dégradation du service dans certaines situations.
Les réparations de matériel homologué doivent être
coordonnées par un représentant désigné par le fournisseur.
L’entreprise de télécommunications peut demander à
l’utilisateur de débrancher un appareil à la suite de
réparations ou de modifications effectuées par l’utilisateur
ou à cause de mauvais fonctionnement.
Pour sa propre protection, l’utilisateur doit s’assurer que
tous les fils de mise à la terre de la source d’énergie
électrique, des lignes téléphoniques et des canalisations
d’eau métalliques, s’il y en a, sont raccordés ensemble. Cette
précaution est particulièrement importante dans les régions
rurales. Avertissement: L’utilisateur ne doit pas tenter de
faire ces raccordements lui-même; il doit avoir recours à un
service d’inspection des installations électriques, ou à un
électricien, selon le cas.”
“AVIS: L’indice d’équivalence de la sonnerie (IES) assigné
à chaque dispositif terminal indique le nombre maximal de
terminaux qui peuvent être raccordés à une interface. La
terminaison d’une interface téléphonique peut consister en
une combinaison de quelques dispositifs, à la seule condition que la somme d’indices d’équivalence de la sonnerie
de touts les dispositifs n’excède pas 5.”
IES: Voir sous le fond de l’ordinateur
<Only for models with wireless LAN/GPS>
Industry Canada
This product complies with RSS210 Industry Canada.
Operation is subject to the following two conditions;
(1) this device may not cause interference, and
(2) this device must accept any interference, including interfer-
ence that may cause undesired operation of the device.
<Only for models with wireless LAN>
This product (local network devices) for the band 5150-5250
MHz is only for indoor usage to reduce potential for harmful
interference to co-channel Mobile Satellite systems.
High power radars are allocated as primary users (meaning they
have priority) of 5250-5350 MHz and 5650-5850 MHz and these
radars could cause interference and/or damage to LELAN devices.
CSA C22 2 NO.213-conforming model. (The model
which has description of “CSA C22 2 NO.213” in the
bottom of the computer.)
• THIS EQUIPMENT IS SUITABLE FOR USE IN CLASS I,
DIVISION 2, GROUPS A, B, C AND D OR NON-HAZARDOUS LOCATIONS ONLY.
• WARNING – EXPLOSION HAZARD – SUBSTITUTION
OF COMPONENTS MAY IMPAIR SUITABILITY FOR
CLASS I, DIVISION 2.
• When connecting and using a device manufactured by a third
party, enquire to the manufacturer as to whether the device
suits CLASS I, DIVISION 2.
<Only for models with Bluetooth>
This Class B digital apparatus complies with Canadian ICES-
003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
For Europe
(For models with a “CE” mark on the bottom of the computer)
Declaration of Conformity (DoC)
“Hereby, we declare that this Personal Computer is in compliance with the essential requirements and other
relevant provisions of the Directive 1999/5/EC.”
Hint:
If you want to get a copy of the original DoC of our products which relates to the R&TTE, please contact our web
address: http://www.doc.panasonic.de
Contact:
Panasonic Services Europe
A Division of Panasonic Marketing Europe GmbH
Panasonic Testing Centre
Getting Started
Network connection.
The terminal equipment is intended for connection to the following public network;
In all the countries of European Economical Area;
- Public Switched Telephony Networks
Technical Features.
The terminal equipment includes the following features;
- DTMF dialing
- Maximum bitrate receiving mode: 56 kbit/s
- Maximum bitrate sending mode: 33.6 kbit/s
This product is designed to interwork with the Public Switched Telecommunication Networks in UK, Ireland, Netherlands, Sweden,
Denmark, Finland, Switzerland, Luxembourg, Belgium, France, Germany, Spain, Portugal, Iceland, Greece, Italy, Norway and
Austria.
--------------------------------------------------------------------------------------------------------------------------------------------
Compliance Notice - CE Mark
This equipment is in conformance with the requirements of the European Council Directive listed below:
73/23/EEC Low Voltage Directive with amendment 93/68/EEC
89/336/EEC EMC Directive with amendments 92/31/EEC and 93/68/EEC
1999/5/EC R&TTE
--------------------------------------------------------------------------------------------------------------------------------------------
5
Read Me First
For France and Italy
<Only for models with Bluetooth>
Communication using Bluetooth outdoor is against the law.
Do not use Bluetooth outdoors.
Important Safety Instructions / Importantes Mesures De Sécurité
When using your telephone equipment, basic safety precautions
should always be followed to reduce the risk of fire, electric shock
and injury to persons, including the following:
1.Do not use this product near water, for example, near a bath
tub, washbowl, kitchen sink or laundry tub, in a wet basement
or near a swimming pool.
2.Avoid using a telephone (other than a cordless type) during an
electrical storm. There may be a remote risk of electric shock
from lightning.
3.
Do not use the telephone to report a gas leak in the vicinity of the leak.
4.Use only the power cord and batteries indicated in this manual.
Getting Started
Do not dispose of batteries in a fire. They may explode. Check
with local codes for possible special disposal instructions.
SAVE THESE INSTRUCTIONS
Information to the User
<Only for models with wireless LAN and/or Bluetooth>
This product and your Health
This product, like other radio devices, emits radio frequency electromagnetic energy. The level of energy emitted by this product
however is far much less than the electromagnetic energy emitted by wireless devices like for example mobile phones.
Because this product operates within the guidelines found in radio frequency safety standards and recommendations, we believe
this product is safe for use by consumers. These standards and
recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of
scientists who continually review and interpret the extensive research literature.
In some situations or environments, the use of this product may
be restricted by the proprietor of the building or responsible representatives of the organization. These situations may for example
include:
Using this product on board of airplanes, or
In any other environment where the risk of interference to other
devices or services is perceived or identified as harmful.
If you are uncertain of the policy that applies on the use of wireless devices in a specific organization or environment (e.g. airports), you are encouraged to ask for authorization to use this
product prior to turning on the product.
Certaines mesures de sécurité doivent être prises pendant l’utilisation
de matérial téléphonique afin de réduire les risques d’incendie, de
choc électrique et de blessures. En voici quelquesunes:
1.Ne pas utiliser l’appareil près de l’eau, p.ex., près d’une
baignoire, d’un lavabo, d’un évier de cuisine, d’un bac à laver,
dans un sous-sol humide ou près d’une piscine.
2.Éviter d’utiliser le téléphone (sauf s’il s’agit d’un appareil sans
fil) pendant un orage électrique. Ceci peut présenter un risque
de choc électrique causé par la foudre.
3.Ne pas utiliser l’appareil téléphonique pour signaler une fuite
de gaz s’il est situé près de la fuite.
4.Utiliser seulement le cordon d’alimentation et le type de piles
indiqués dans ce manual. Ne pas jeter les piles dans le feu:
elles peuvent exploser. Se conformer aux règlements pertinents
quant à l’élimination des piles.
CONSERVER CES INSTRUCTIONS
Lithium Battery
Lithium Battery!
This computer contains a lithium battery to enable the date, time,
and other data to be stored. The battery should only be exchanged
by authorized service personnel.
Warning! A risk of explosion from incorrect installation or misapplication may possibly occur.
Pile au lithium!
Le micro-ordinateur renferme une pile au lithium qui permet de
sauvegarder certaines données, notamment la date et l'heure. La
pile ne doit être remplacée que par un technicien qualifié.
Danger! Risque d'explosion en cas de non respect de cette mise
en garde!
Regulatory Information
We are not responsible for any radio or television interference
caused by unauthorized modification of this product. The correction of interference caused by such unauthorized modification will be the responsibility of the user. We and its authorized
resellers or distributors are not liable for damage or violation of
government regulations that may arise from failing to comply
with these guidelines.
6
Precautions
Precautions (Battery Pack)
The CF-18 was developed based on thorough research into the
real-world portable computing environments. Exhaustive pursuit
of usability and reliability under harsh conditions led to innovations such has the magnesium alloy exterior, vibration damped
hard disk drive and floppy disk drive, flexible internal connections. The CF-18’s outstanding engineering has been tested using the strict MIL-STD- 810F (for vibration and shock) and IP
(for dust and water) based procedures.
As with any portable computer device precautions should be taken
to avoid any damage. The following usage and handling procedures are recommended.
Before putting the computer away, be sure to wipe off any moisture.
Avoid Radio Frequency Interference
Do not place the computer near a television or
radio receiver.
Avoid Magnetic Fields
Keep the computer away from magnets.
Data stored on the hard disk may be lost.
Keep Small Objects Away
Do not insert paper clips or other small objects
into the computer.
Do Not Disassemble the Computer
Do not attempt to disassemble your computer.
Avoid Excessive Force on the Display
Do not apply excessive downward force on the
display when it is completely opened, especially
when plugs and/or cables are connected to the
rear of the computer.
Avoiding Low-temperature Burns
Avoid more than casual contact with any heat producing area of the notebook computer, AC adaptor, and any option or accessory you use with it.
Even low heat (warmer than body temperature),
can cause a burn if the skin is exposed to the heat
source for a long period of time.
Do not touch the computer and cable when it
starts thundering
Do not connect a telephone line, or a network
cable other than the one specified, into the
LAN port
If the LAN port is connected to a network such
as the ones listed below, a fire or electric shock
may result.
• Networks other than 100BASE-TX or
10BASE-T
• Phone lines (Telephone lines, internal phone
lines (on-premise switches), digital public
phones, etc.)
Care should be exercised with regard to the following in order to avoid the possibility of overheating, fire or damage.
Avoid Heat
Do not throw the battery pack into a fire or
expose it to excessive heat.
Keep Articles Away
Do not place the battery pack together with articles such as necklaces or hairpins when carrying or storing.
Do Not Disassemble
Do not insert sharp objects into the battery pack,
expose it to bumps or shocks, deform, disassemble, or modify it.
Do Not Short
Do not short the positive (+) and negative (-)
contacts.
Avoid Extreme Heat, Cold and Direct Sunlight
Do not charge, use or leave the battery pack for
extended periods where it will be exposed to direct sunlight, in a hot place (in a car on a sunny
day, for example), or in a cold place.
Do Not Put into a Microwave
Do not put the battery pack into a microwave
oven or a pressurized chamber.
Stop Using
Should the battery emit an abnormal odor, become hot to the touch, become discolored,
change shape, or become in any way different
from normal, remove it from the computer or
charger and stop using it.
Do Not Use With Any Other Computer
The battery pack is rechargeable and was intended for the specified computer or charger. Do
not use it with a computer other than the one for
which it was designed.
Do not use this computer with a battery pack
other than the one specified (the one included
with the computer or the specified battery
pack sold separately)
Do not touch the terminals on the battery pack. The battery pack may no longer function properly if the contacts
are dirty or damaged.
Do not expose the battery pack to water, or allow it to become wet.
Getting Started
Keep SD Memory Cards away from infants
and small children
Accidental swallowing will result in bodily injury.
In the event of accidental swallowing, see a doctor
immediately.
7
Read Me First
Precautions (Battery Pack)
If the battery pack will not be used for a long period of time
(a month or more), charge or discharge (use) the battery pack
until the remaining battery level becomes 30% to 40% and
store it in a cool, dry place.
This computer prevents overcharging of the battery by recharging only when the remaining power is less than approx.
95% of capacity.
The battery pack is not charged when the computer is first
purchased. Be sure to charge it before using it for the first
time. When the AC adaptor is connected to the computer,
charging begins automatically.
Should the battery leak and the fluid get into your eyes, do not
rub your eyes. Immediately flush your eyes with clear water
and see a doctor for medical treatment as soon as possible.
NOTE
Getting Started
The battery pack may become warm during recharging or
normal use. This is completely normal.
Recharging will not commence if internal temperature of
the battery pack is outside of the allowable temperature
range (0 °C to 50 °C {32°F to 122 °F})
tery Power”. Once the allowable range requirement is
satisfied, charging begins automatically. Note that the recharging time varies based on the usage conditions. (Recharging takes longer than usual when the temperature is
10 °C {50 °F} or below.)
If the temperature is low, the operating time is shortened. Only
use the computer within the allowable temperature range.
This computer has a high temperature mode function that
prevents the degradation of the battery in high temperature environments. (
corresponding to a 100% charge for high temperature mode
is approximately equivalent to an 80% charge level for
normal temperature mode.
The battery pack is a consumable item. If the amount of
time the computer can be run by using a particular battery
pack becomes dramatically shorter and repeated
recharging does not restore its performance, the battery
pack should be replaced with a new one.
When transporting a spare battery inside a package,
briefcase, etc., it is recommended that it be placed in a
plastic bag so that its contacts are protected.
Always power off the computer when it is not in use.
Leaving the computer on when the AC adaptor is not
connected will exhaust the remaining battery capacity.
“Battery Power”) A level
“Bat-
For Used in Motor Vehicle /
Pour L’utilisation Dans Un Véhicule
Motorisé
Warning: Notebook Computer may be installed in a motor vehicle and visible to the driver only if used to support vehicle
related functions such as vehicle information, system control,
rear or side observation and navigation. If used for entertainment purpose, such as television reception or video play, it must
be installed to the rear of the driver’s seat where it will not be
visible, directly or indirectly, to the operator of the motor vehicle. Check with individual state/provincial laws to determine
lawful use of this product while operating within a motor vehicle.
Avertissement: L’ordinateur bloc-notes peut être installé dans un
véhicule motorisé et dans le champ de vision du conducteur
uniquement en tant que dispositif d’aide aux fonctions du
véhicule, comme par exemple pour fournir des informations sur
le véhicule, comme dispositif de contrôle de système, pour
l’observation à l’arrière ou sur les côtés du véhicule, ainsi que
pour fournir de l’information routière. Pour toute utilisation à fin
de divertissement, comme par exemple pour regarder la télévision
ou jouer à des jeux vidéo, il doit être installé à l’arrière du siège
du conducteur, en un emplacement où il ne sera pas visible, ni
directement ni indirectement, pour le conducteur du véhicule
motorisé. Vérifiez les lois fédérales et nationales qui régissent
l’utilisation légale de cet appareil à l’intérieur d’un véhicule
motorisé.
8
Names and Functions of Parts
The illustrations shown may differ from the actual physical appearances.
<Only for models with Bluetooth>
Bluetooth Antenna
“Bluetooth”)
(
( page 21)
Pen
Keyboard
LED Indicators
( “LED Indicators”)
Caps Lock
Numeric Key (NumLk)
Scroll Lock (ScrLk)
Hard disk drive status
Battery pack status
Power status
Power Switch
Touch Pad
( page 20)
<Only for models with
wireless LAN>
Wireless LAN Antenna
( “Wireless LAN”)
( page 21)
LCD
Function Keys
For information on the key combinations available.
(
Hard Disk Drive
( “Hard Disk Drive”)
Battery Pack
( “Battery Power”)
“Key Combinations”
Getting Started
)
CAUTION
Do not cover the computer with a thick cloth, such as a blanket.
A lithium ion battery that is recyclable powers the product you have purchased. Please call 1-800-8BATTERY for information on how to recycle this battery.
Tablet Buttons
( “Tablet Buttons”)
LCD brightness control
Input Panel
Enter
Rotation
Security
L’appareil que vous vous êtes procuré est alimenté par une batterie au lithium-ion. Pour des
renseignements sur le recyclage de la batterie, veuillez composer le 1-800-8-BATTERY.
9
Names and Functions of Parts
Security Lock
A cable can be connected. For more information, read the manual provided
with the cable.
Microphone Jack
Use only a monaural condenser microphone (miniature jack). Using an input
source other than a monaural condenser
microphone may not allow audio to be
input or may damage the equipment.
Headphone Jack
Use this jack to connect headphones or
amplifier-equipped speakers. Audio out-
Getting Started
put from the internal speaker is disabled
when headphones or external speakers
are connected.
LOCK
DC-IN Jack
DC IN 16 V
USB Ports
“USB Devices”)
(
External Display Port
( “External Display”)
Modem
( “Modem”)
LAN
( “LAN”)
CAUTION
Do not connect the modem telephone cable into
the LAN port.
PC Card Slots
( “PC Cards”)
SD Memory Card Slot
“SD Memory Card”
(
and “SD Memory Card Security
Function”)
SD Memory Card Indicator
“LED Indicators”)
(
(The above illustration shows the position
where the hand strap is attached at the factory.)
Shoulder Strap
The shoulder strap can be connected to the hand
strap to make it longer.
Hand Strap
The hand strap can be attached to any two of the four corners using
screws (A) which were used to attach the hand strap.
Adjust the length of the belt so that the computer does not fall by mistake, and firmly hold the computer when using it.
CAUTION
The strap has been designed to carry only the weight of the computer. Therefore, be sure that the strap does not carry a weight
that exceeds the weight of the computer. The strap may accidentally come loose from the computer.
Do not use a strap that is damaged or about to tear.
10
CAUTION
Do not allow metallic objects or magnetic media to come near these areas.
Expansion Bus Connector
( “Port Replicator”)
RAM Module Slot
( “RAM Module”)
Getting Started
Speaker
To adjust the volume:
Fn + F5 / Fn + F6
Speaker on/off : Fn + F4
CAUTION
Do not allow metallic objects or magnetic media to come near the speaker on the bottom surface of the computer.
• Because the speaker contains a magnet, metal
objects may become attached to the bottom
surface of the computer. This may cause the
computer to be unstable, or may mark the surface of the desk on which it is sitting.
• If floppy disks, magnetic memory cards, or
other magnetic media approach the speaker,
there is a risk that data will be destroyed.
11
Names and Functions of Parts
Using the Tether
The tether can be attached to the bottom right or bottom left corner of the display. It prevents the
pen (included) from falling accidentally.
Attaching the Tether
Getting Started
1
Tether
2
CAUTION
When closing the display, be careful not to catch the tether between the display and main
part of the computer. (See the figure below.)
3
4
12
First-time Operation
Read the steps below to help you learn what parts are included, and to gain an understanding of
some basic computer-related operations.
Confirm the inclusion of all parts.
1
Make sure the parts shown in the figure have been supplied. If any of these items are
missing or are not working properly, contact Panasonic Technical Support.
Latch
AC adaptor ..........1
Model No : CF-AA1623A
Modem Telephone
Cable ......................1
Tether ...................... 1 Shoulder Strap ........ 1
*1If additional instructions are included with the computer, be sure to read them. It may be
necessary to perform additional operations during the following procedures.
AC Cord ...............1
Soft Cloth ............... 1
( page 10)( page 12)
Battery Pack ........1
Model No : CF-VZSU30B
Pen.......................... 1
( “Digitizer (Advanced)”)
Operating Instructions
(This book)
Windows
Product Recovery
CD-ROM................. 4
*1................. 1
®
Book .... 1
Getting Started
Read the LIMITED USE LICENSE AGREEMENT. ( page 37)
2
Be sure to read the LIMITED USE LICENSE AGREEMENT before breaking the seal
1
2
Cover
4
3
on the computer’s packaging.
Insert the battery pack.
3
1
Unlock the cover by sliding the latch to the right.
2
Slide the latch down, and then without releasing it, open the cover as illustrated.
3
Slide the battery pack inward until it is firmly in place.
CAUTION
Do not touch the terminals on the battery pack and the computer. The battery pack may no longer function properly if the contacts are dirty or damaged. Also, the computer may not operate properly.
Be sure to insert the battery pack as illustrated.
4
Close the cover until it clicks into place.
5
Lock the cover by sliding the latch to the left.
CAUTION
Confirm that the latch lock is correctly in place. If you carry your computer without the latch lock in place, the battery pack may fall out.
Before using the battery pack, carefully read “Precautions (Battery Pack)”
page 7-8).
5
(
13
First-time Operation
Getting Started
DC-IN Jack
DC IN 16 V
Latch B
2
Connect your computer to a power outlet.
4
CAUTION
Be sure the AC adaptor is connected until completing the first-time use operation.
When using the computer for the first time, do not connect any peripheral device except the battery pack and AC adaptor to the computer.
Handling the AC adaptor
Do not twist or pull the AC power cord forcefully. Doing so may damage the
connections.
Use only the specified AC adaptor with your computer. Using an AC adaptor
other than the one supplied might damage the battery and/or the computer.
When the DC plug is not connected to the computer, disconnect the AC cord
from your AC wall outlet.
Problems such as sudden voltage drops may arise during periods of thunder and
lightning. Since this could adversely affect your computer, an uninterruptible
power source (UPS) is highly recommended unless the battery pack is installed.
Open the display.
5
1 Pull up latch A and release latch B.
1
2 Lift open the display.
Latch A
Power Switch
Power Indicator
Turn your computer on.
6
Slide the power switch and hold it for approximately one second until the power indicator turns on before releasing it.
CAUTION
Do not slide the power switch and hold it for more than four seconds; this will
cause the power to be turned off forcibly.
Do not slide the power switch repeatedly.
Once the computer is powered off, you must wait at least ten seconds before
powering it on again.
Setup Windows.
7
Moving the cursor or clicking buttons can be performed with the touch pad (
page 20).
CAUTION
Do not press any keys or touch the touch pad until [Windows XP Professional
Setup] is displayed.
1 At [Welcome to the Windows XP Setup Wizard], select [Next].
2 After reading the agreement, select [I accept this agreement] or [I don’t accept this
agreement], then select [Next].
14
NOTE
If [I don’t accept this agreement] is selected, the Windows setup will be aborted.
3 Select settings for your region, then select [Next].
4 Enter your name and organization and then select [Next].
5 Enter your computer name and administrator password and then select [Next].
CAUTION
Remember this password! If the password is forgotten, Windows cannot be
operated.
6 Enter the correct date, time and time zone, then select [Next].
NOTE
It may take some time before the computer restarts and the screen of step
7 is displayed. Wait, and do not press any keys, or touch the touch pad, etc.
The computer will restart.
7 Enter your administrator password and select .
NOTE
If the message “Wait several minutes while the optimal configuration is
being set. Do not shutdown the computer during this process.” is displayed,
wait and do not press any keys, or touch the touchpad, etc.
When Windows setup is completed, the following message will be displayed
at the bottom right of the screen: “Your computer might be at risk.” Continue to the next step.
The message is generated by the [Security Center] function in [Control Panel],
and does not indicate an error or malfunction. For more information about
“Security Center”,
page 26.
Getting Started
If the cursor can not be pointed correctly with the pen, perform [Calibration] in [start]
- [Control Panel] - [Printers and Other Hardware] - [Tablet and Pen Settings].
When you perform the calibration, hold the pen at the same angle as you would
when actually using it.
Perform the calibration separately for [Landscape] and [Portrait].
8
Create a new account.
1 Select [start] - [Control Panel] - [User Accounts] - [Create a new account].
NOTE
When creating a new user account:
• If you make mail settings, create password reset disks ( page 16), or
conduct other related operations before creating the user account, you
will be unable to use any previous mail history or settings.
• When you create the first new account, you can only select [Computer
administrator].
Once a “Computer Administrator” account has been created, you can create additional limited user accounts.
Note also that only the added user account will be displayed in the Welcome screen. The account for the administrator created during Windows
setup will not be displayed.
2 Enter a name for the new account, then select [Next].
3 Select [Computer administrator], then select [Create Account].
4 <When you want to create a password for the new account>
Select the new account you have created and select [Create a password].
Follow the instructions on the screen to create a password.
CAUTION
Remember this password! If the password is forgotten, Windows cannot be
operated.
5 Select [start] - [Turn Off Computer] - [Restart] to restart the computer.
You can create a password reset disk beforehand.
( page 16)
15
Loading...
