Page 1

Operating Instructions

BL-C1A

BL-C20A

Network Camera

Model No. BL-C1A

BL-C20A

Indoor Use Only

Wired Type

Wireless/Wired Type

Please read this manual before using, and save this manual for future reference. Panasonic Network Camera Website: http://www.panasonic.com/netcam

for customers in the USA or Puerto Rico

Page 2

Operating Instructions

Main Features

[For BL-C20A] Wireless Communication

This Network Camera is compatible with a wireless system based on IEEE

802.11b/g. Wireless installation is playing an ever increasing role in flexible communication. The use of encryption ensures security on this kind of network. Communication via Ethernet cable is also available.

Digital zoom feature

This camera has a 10× digital zoom feature. This feature allows you to increase or decrease the size of objects on the Single Camera screen, the Multi Camera screen, and the Buffered Image screen. This makes it easy to view distant objects. A mouse wheel operation or clicking the right mouse button increase or decrease the size of the object.

Color Night View Mode

The color night view mode provides better image quality and low light performance

(4 lx

Multi-Camera Support

The Multi-Camera page displays the moving images from up to 4 cameras. This camera allows you to switch between 3 sets of 4 cameras. Additionally, static images from a maximum of 12 cameras can be displayed on a single page.

DynamicDNS Service Support

DynamicDNS service allows you to access the camera over the Internet with a domain name of your choice (e.g. bob.viewnetcam.com) instead of a global IP address.

Multi-Language Display

The Top page, Single Camera and Multi-Camera page can be displayed in English, French, German, Italian, Spanish, Russian, Simplified Chinese, Korean or Japanese. The Setup, Maintenance and Support pages are displayed only in English, Japanese, French or Simplified Chinese.

Motion Detection feature

The Camera has a Motion Detection feature that detects movement, such as people, based on the preset threshold and sensitivity of the Camera. You can buffer the camera images, transfer images to an FTP server or send E-mails using the Motion Detection function as a trigger.

This feature is not available when viewing on a cell phone.

As the magnification increases, the image quality decreases.

The brightness about 1 m (3 feet 3 inches) away under auxiliary fluorescent light. When the object darkens, color night view mode is automatically enabled. The frame rate and the image quality decrease in color night view mode. Also, images of moving people or animals may be blurred.

Page 3

Operating Instructions

Documentation

This manual is for both BL-C1A (Wired Type) and BL-C20A (Wireless/Wired Type). Available features and operations are different in part depending on the model. Read this manual carefully and use the Network Camera properly. (The model no. is indicated on the upper left of the front of the main unit.) The

illustrations and images used in this manual are of BL-C20A.

Trademarks

• Adobe, Acrobat and Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

• Microsoft, Windows, Hotmail and ActiveX are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

• Screen shots reprinted with permission from Microsoft Corporation.

• All other trademarks identified herein are the property of their respective owners.

• This software is based in part on the work of the Independent JPEG Group.

Abbreviations

• UPnP is the abbreviation for "Universal Plug and Play".

• "Network Camera" is called "Camera" in this manual.

• "Setup CD-ROM" is called "CD-ROM" in this manual.

[For assistance, please call: 1-800-272-7033] 3

Page 4

Operating Instructions

Camera Feature Locations

BL-C1A Front View

Indicator

The indicator color shows camera status. (See page 96)

Lens (Focus: 0.3 m [about 11 13/16 inches]— Unlimited)

Indicator Display

Powe r on

Normal Operation*

Automatic Setup

Using DHCP

Updating Firmware

FACTORY DEFAULT RESET

button pressed

UPnP Internal Failure Red blinking*

Not on LAN

On LAN

Setting

Finished setting

Getting IP address*

Got IP address

Failure Orange blinking (About a 2-second interval)

Orange

Orange blinking Turning off (about 5 seconds)

(The camera is reset to factory default status after 1 minute.)

Orange

Orange blinking GreenGreen blinking

Orange blinking

The status when turned on

Orange blinking

Green

Green blinking

Green

Green blinking

Green

Orange blinking

*1 The information below varies depending on the indicator settings (see page 96). *2 The indicator turns orange if the camera is not connected to the LAN. *3 The indicator blinks orange if the camera is not connected to the LAN. *4 See page 4 of the Troubleshooting on the CD-ROM.

Page 5

BL-C1A Rear View

Stand/Tripod

Mounting Hole

(See Getting

Started.)

Serial number

MAC Address

(See Getting

Started.)

Ethernet

(LAN) port

(See Getting

Started.)

Hook for AC

adaptor cord

Operating Instructions

DC IN jack

(See Getting Started.)

FACTORY DEFAULT RESET Button

[For assistance, please call: 1-800-272-7033] 5

Page 6

Operating Instructions

BL-C20A Front View

Antenna

FACTORY DEFAULT

RESET Button

Note

See page 4 for the indicator operations.

BL-C20A Rear View

Stand/Tripod

Mounting Hole

(See Getting

Started.)

Indicator

The indicator color shows camera status.

Lens

(0.3 m [about 11 13/16 inches]—Unlimited)

Serial number MAC Address

(See Getting Started.)

DC IN jack

(See Getting Started.)

Switch

(WIRED or

WIRELESS)

Ethernet

(LAN) port

(See Getting

Started.)

Hook for AC

adaptor cord

Page 7

Operating Instructions

1 Camera Monitoring......................................................10

1.1 Accessing the Camera ................................................................. 10

1.2 Viewing the Single Camera page ................................................. 12

1.2.1 Displaying the Banner ............................................................................. 16

1.2.2 Auto Centering the Image (Click to Center)............................................. 16

1.2.3 Zooming In and Out................................................................................. 17

1.2.4 Capturing a Still Image............................................................................ 18

1.2.5 Using the Operation Bar.......................................................................... 19

1.3 Viewing the Multi-Camera page ................................................... 20

1.4 Viewing the Buffered Image page ................................................ 22

1.4.1 Deleting Buffered Images........................................................................ 24

1.5 Viewing Still Images on Your Cell Phone ..................................... 25

1.5.1 Enabling or Disabling the Buffer/Transfer on Your Cell Phone................. 27

2 Using the Camera's Basic Features ..........................28

2.1 Setup Page of the Camera........................................................... 28

2.2 Connecting the Camera to Your Network..................................... 31

2.3 [For BL-C20A] Using Wireless LAN ............................................. 36

2.4 Using UPnP™ (Universal Plug and Play) .................................... 39

2.4.1 Connecting the Camera to a Router that Supports UPnP™ ................... 40

2.4.2 Connecting the Camera to a Router that does not Support UPnP™ ...... 41

2.5 Registering with the DynamicDNS service .................................. 42

2.5.1 DynamicDNS Service.............................................................................. 46

2.6 Setting the Date and Time ........................................................... 48

2.7 Changing Camera Settings.......................................................... 50

3 Registering Users........................................................52

3.1 Changing the Authentication Setting and Administrator User

Name and Password.................................................................... 52

3.2 Logging in to the Camera............................................................. 56

3.3 Creating, Modifying or Deleting General Users............................ 57

4 Buffering or Transferring Images...............................59

4.1 Procedures of Buffering or Transferring Images .......................... 59

4.2 Buffering or Transferring Images by Timer ................................... 60

[For assistance, please call: 1-800-272-7033] 7

Page 8

Operating Instructions

4.3 Buffering or Transferring Images by Motion Detection Signal ...... 70

4.4 Setting the Motion Detection........................................................ 83

4.5 Setting Sensor Log Notification.................................................... 86

5 Using Other Features..................................................89

5.1 Changing Initial Settings on the Single Camera page or

the Multi-Camera page ................................................................ 89

5.2 Configuring Multiple Cameras...................................................... 92

5.3 Specifying Operation Time........................................................... 94

5.4 Changing the Indicator Display .................................................... 96

6 Camera Maintenance ..................................................97

6.1 Maintenance page ....................................................................... 97

6.1.1 Confirming the Status.............................................................................. 98

6.1.2 [For BL-C20A] Confirming the Wireless Status ....................................... 98

6.1.3 Confirming Session Status ...................................................................... 98

6.1.4 Confirming Sensor Logs.......................................................................... 99

6.1.5 Restarting the Camera ............................................................................ 99

6.1.6 Updating the Camera Firmware............................................................. 100

6.1.7 Creating a Configuration File................................................................. 103

6.1.8 Loading Settings from a Configuration File............................................ 104

6.1.9 Resetting the Camera to Factory Default............................................... 105

6.2 Support page ............................................................................. 106

6.2.1 The Help page ....................................................................................... 106

6.2.2 [For BL-C20A] The Wireless Help page ................................................ 107

6.2.3 Product Information ............................................................................... 107

6.2.4 Support Information............................................................................... 107

6.3 FACTORY DEFAULT RESET Button.......................................... 108

7 Other Information......................................................109

7.1 Default Setting List..................................................................... 109

7.2 Cleaning..................................................................................... 118

7.2.1 Cleaning the Main Unit .......................................................................... 118

7.2.2 Cleaning the Lens.................................................................................. 118

7.3 Setting an IP Address on Your PC ............................................. 119

7.4 Using Setup Program................................................................. 120

7.5 Setting Your PC.......................................................................... 127

7.5.1 Setting Proxy Server Settings on a Web Browser ................................ 127

Page 9

Operating Instructions

7.5.2 Setting UPnP™ to Display Camera Shortcut in My Network Places..... 130

7.5.3 Setting the Internet Temporary File Setting on the Web Browser.......... 130

7.6 ASCII Character Table ............................................................... 131

7.7 File Size and Number of Buffered Images ................................. 132

7.8 Specifications ............................................................................. 135

Index..................................................................................138

[For assistance, please call: 1-800-272-7033] 9

Page 10

Operating Instructions

1 Camera Monitoring

1.1 Accessing the Camera

1. Start up the web browser on your PC.

2. Enter "http://IP Address (or URL):Port Number" on the address bar, and

press [Enter] on the keyboard.

• When the port number is 80 (default), you do not need to include the port number in the address. See page

• If the camera image is not displayed, see page 9 and page 10 of the Troubleshooting on the CD-ROM.

E.g. http://192.168.0.253:50000

http:// .viewnetcam.com:50000

3. The Enter Network Password window is displayed. Enter the user name and

password that you set previously, and click [OK].

Note

When [Permit access from guest users] is set on the Security: Administrator page (see page

52), the authentication window will not be displayed.

33 for details about the port number.

Page 11

Operating Instructions

4. Click the following tabs to display each page.

A B C D E F G

Select a language.

Version Number

A To Single Camera page (page 12) B To Multi-Camera page (page 20) C To Buffered Image page (page 22) D To Setup page (page 28) E To Maintenance page (page 97) F To Support page (page 106) G To log in to the camera (page 56)

Note

When users other than an administrator are accessing the camera, the [Setup] and [Maintenance] tabs are not displayed. Additionally, when [Do not permit access from guest users] or [Permit access from guest users (mobile only)] is set on the Security: Administrator page (see page be displayed.

52), the [Login] tab will not

[For assistance, please call: 1-800-272-7033] 11

Page 12

Operating Instructions

1.2 Viewing the Single Camera page

1. Access the camera (see page 10).

• The Top page is displayed.

2. Click the [Single] tab at the top of the page.

• When the Security Warning window is displayed, click [Yes] (see page 14).

• See page 15 for the Security Warning window when using Microsoft® Windows® XP Service Pack 2.

Capture Image

Button

(See page 18)

Operation Bar

(See page 19)

3. Close the web browser.

Note

• While viewing images under fluorescent lighting, the image may appear noisy or experience flicker if the incorrect AC power setting was selected. Select the frequency that is used in your area (see page

• When the camera image is not displayed immediately or correctly, click [Refresh] at the tool bar on the web browser. The image will be refreshed.

• The digital zoom can be operated only when displaying video (Motion JPEG).

• The refresh interval is set to [Motion] by default. The setting can be changed on the operation bar (see page

• The refresh interval may change depending on the network condition, PC performance, what object you view and the number of simultaneous users.

• When displaying video (Motion JPEG), the camera allows up to 20 simultaneous accesses. The 21st user will see a gray screen. (Access to play buffered images is also included in the maximum number.)

• To reduce the data traffic, set up [Limit Continuous Motion JPEG] on the Image Display page (see page 89). The video (Motion JPEG) can be automatically changed to refreshing still images. Images of moving subject are blurred or not displayed.

19).

Features on the image

• Click to Center (See page

16)

• Digital Zoom (See page

The banner is displayed.

(See page 16)

50).

17)

Page 13

Operating Instructions

• When the camera transmits a dark scene, the camera image may become white, or horizontal lines may be displayed on the screen. This is one of the characteristics of a CMOS sensor. This is not a malfunction.

• To display the Single Camera page directly, add it to the [Favorites] on the web browser.

• To view dark images, select [Enable] (default) at Color Night View on the Camera Setup page. The image will be brighter, but the refresh interval may increase and image quality may decrease in a dark place. (See page

• [For BL-C20A] The video (Motion JPEG) may stop because the wireless communication may be disconnected depending on the environment. Click [Refresh] on the web browser when the communication is disconnected.

• If ActiveX® Controls (see page 14 or page 15) cannot be installed, download them from the Panasonic Network Camera support website at

http://panasonic.co.jp/pcc/products/en/netwkcam/

Error messages and screen color

When general or guest users access the Single Camera page outside the Operation Time, or when over 20 (the maximum number) users access the page simultaneously, a gray screen and error messages will be displayed on the page.

50)

Error Message Cause and Remedy

The operation time has ended.

When general or guest users access the Single Camera page outside the Operation Time, a gray screen will be displayed. Clicking [Refresh] on the web browser displays an error message. Consult your administrator about the Operation Time.

The maximum number of acce sses has been exceeded.

When [Motion] is selected for the Refresh Interval, up to 20 users can access the camera simultaneously. For the 21st user, a gray screen and an error message will be displayed on the Single Camera and Buffered Image pages. Wait for a moment, and click [Refresh] on the web browser, or change the value for the Refresh Interval.

[For assistance, please call: 1-800-272-7033] 13

An error message is displayed.

Page 14

Operating Instructions

Security Warning window

When trying to view a video (Motion JPEG) for the first time, a Security Warning for ActiveX Controls will be displayed. When using Windows 2000 or Windows XP, log in as an administrator to install ActiveX Controls and enable video (Motion JPEG) viewing.

If you cannot install ActiveX Controls or you cannot see the video (Motion JPEG) using Internet Explorer

• In Internet Explorer, click [Tools]→[Internet Options]→[Security] tab and click [Custom level]. (1) Check "Prompt" in "Download signed ActiveX Controls". (2) Check "Enable" in "Run ActiveX Controls and plug-ins".

• ActiveX Controls can be installed from the CD-ROM. (1) Restart the PC. (2) Confirm that Internet Explorer is closed. (3) Double-click "ocx\ActiveXInst.exe" on the CD-ROM.

Note

• When the IP address was changed for the camera, enter it on the address bar.

• Video (Motion JPEG) may not be displayed. Wait for a moment.

• If you use a proxy server, set the web browser not to access the proxy server (see page 127).

• In some corporate network environments, a firewall may be used for security purposes. This may prevent motion video (Motion JPEG) from being displayed. In this situation we recommend:

– Contacting your network administrator. – Using regularly refreshed images rather than video (Motion JPEG).

Page 15

Operating Instructions

Security Warning window on Microsoft Windows XP Service Pack 2

To view a video (Motion JPEG), ActiveX Controls must be installed. Follow the steps shown below to install ActiveX Controls.

1. Click the warning displayed above the tabs, and click [Install ActiveX

Control...].

2. Click [Install].

[For assistance, please call: 1-800-272-7033] 15

Page 16

Operating Instructions

1.2.1 Displaying the Banner

An image and its linked website can be specified for a banner. To display the banner, the Banner Display settings need to be set on the Image Display page (see page

89). Clicking the banner displays the website of the set URL Link. The Banner

Display is not enabled as the default.

1.2.2 Auto Centering the Image (Click to Center)

Using your mouse, click any portion of the camera image when using the digital zoom. The image will automatically move to place the selected point in the center of the screen.

1. Move the cursor to the desired point.

Cursor

2. Click it.

• The clicked point is centered.

Note

• A clicked position may deviate from the center depending on the position.

• Images can only be moved within the page when magnification is ×1.

Page 17

Operating Instructions

1.2.3 Zooming In and Out

This Camera has 10× digital zoom feature that uses ActiveX Controls. The digital zoom feature can be used while playing video (Motion JPEG) on the Single Camera, Multi-Camera and Buffered Image pages. The digital zoom feature can be operated by rotating the mouse wheel or clicking the right mouse button.

Note

• The Click to Center feature is available while zooming in or out. Images can only be moved within the page when magnification is ×1.

• As the magnification increases, the image quality decreases.

• This feature is not available when viewing on a cell phone.

• When camera images are buffered and transferred, the camera images are not zoomed in and out.

Clicking the right mouse button

Moving the mouse up or down while pressing the right mouse button zooms in and out.

Zoom in

Zoom out

Rotating the mouse wheel

On a screen, rotating the mouse wheel away from you zooms in, and rotating it towards you zooms out.

Note

The performance of the mouse varies according to your OS.

[For assistance, please call: 1-800-272-7033] 17

Zoom in Zoom out

Page 18

Operating Instructions

1.2.4 Capturing a Still Image

Still images can be saved on your PC.

1. Select an image resolution to display an image.

2. Click the Capture image button.

Capture Image Button

• The camera image opens in another window.

3. Right-click the image, and select [Save Picture As...].

• The Save as dialog box is displayed.

4. Specify a folder, enter the file name and click [Save].

• The camera image is saved in the folder.

5. Click [Close].

Page 19

1.2.5 Using the Operation Bar

Brightness: Adjusts image brightness in nine steps including

[STD] (Standard). Clicking [-] or [+] darkens or brightens the image respectively.

Operating Instructions

Refresh Interval:

Resolution: Selects [640 × 480] or [320 × 240] (default) pixels.

Image Quality:

Sets a refresh interval. (Motion—60-second interval)

Selects the image quality.

• [Favor Clarity] optimizes the image for good clarity.

• [Standard] keeps the standard quality. (default)

• [Favor Motion] optimizes the image for motion display.

[For assistance, please call: 1-800-272-7033] 19

Page 20

Operating Instructions

1.3 Viewing the Multi-Camera page

To view multiple cameras on the Multi-Camera page, you need to configure each camera on the Multi-Camera Setup page (see page 92).

1. Access the camera (see page 10).

• The Top page is displayed.

2. Click the [Multi] tab at the top of the page.

• The Multi-Camera page can display up to 12 camera images.

Capture Image Button (See page 18)

Switches displayed cameras. If you select [All] at the View Type, video (Motion JPEG) cannot be displayed.

Selects [320 × 240] (default) or [160 × 120] pixels resolution.

The Selfcamera is registered at No. 1. (default)

3. Close the web browser.

Selects the refresh interval (Motion—60second interval).

Clicking the camera name displays the Single Camera page in another window.

Page 21

Operating Instructions

Note

• The digital zoom feature and the Click to Center feature can be used for video (Motion JPEG) only.

• When selecting [All] for the View Type, all images are displayed in 160 × 120 pixels resolution.

• 640 × 480-pixel images cannot be displayed on the Multi-Camera page.

• When viewing video (Motion JPEG), we recommend using an Ethernet switching hub instead of a repeater hub to prevent degradation in video display.

• Due to network congestion or the number of accesses, the refresh interval may increase.

• If the refresh interval is too long, restrict the bandwidth on the Network page (see page

• To reduce the data traffic, set up [Limit Continuous Motion JPEG] on the Image Display page (see page automatically changed to refreshing still images. Images of moving subject are blurred or not displayed.

• When viewing 4 cameras on the Multi-Camera page, you may need 3 to 4 Mbps bandwidth. If sufficient bandwidth is not available, the refresh interval may increase.

• The Click to Center feature can be used while using the digital zoom.

34). The refresh interval should improve.

89). The video (Motion JPEG) can be

When an image is not displayed on the Multi-Camera page

• Confirm that the global IP address is specified correctly for each camera and that each camera is connected to the Internet. For Internet access, local IP

addresses (192.168. Troubleshooting on the CD-ROM)

• Confirm the settings on the Multi-Camera Setup page (see page 92).

• Confirm that the web browser is not accessing a proxy server (see page 127).

. ) cannot be used. (See page 11 of

When setting [Do not permit access from guest users] or [Permit access from guest users (mobile only)] on the Security: Administrator page

• An authentication window is displayed when accessing the camera. Enter the administrator's or the general user's user name and password.

• When you view images from several cameras on the Multi-Camera page, an authentication window is displayed for each camera that has security settings enabled. Enter the administrator's or general user's user name and password registered for each camera.

[For assistance, please call: 1-800-272-7033] 21

Page 22

Operating Instructions

1.4 Viewing the Buffered Image page

To buffer images in the camera's internal memory, you need to set up the image transfer settings (see page 60 or page 70). Buffered images can be viewed on this Buffered Image page.

1. Access the camera (see page 10).

• The Top page is displayed.

2. Click the [Buffered Image] tab at the top of the page.

3. Click the trigger number.

The trigger number is displayed (see page 60 or page 70).

The trigger is displayed (see page 60 or page 70).

Page 23

Operating Instructions

4. Display images by clicking buttons below.

The date and time when the images were buffered are displayed.

Month (Sep), day (20), hour (02), minute (58), second (15), millisecond (120), AM/PM (PM), the number and the total number of frames (1/10) are displayed.

[Play]:

The buffered images are displayed in sequence.

[<Prev] or [Next>]:

The previous or next image is displayed.

[<100], [<10] or [10>], [100>]:

The 10th or 100th image before or after the current image appears.

Note

• The buffered images are displayed chronologically.

• Still images (not being played) from the Buffered Image page can be saved. Put the cursor on the image, and right-click it. Then select [Save Picture As...].

• The maximum number of buffered images changes depending on resolution, image quality and the specific images the camera is buffering. At 320 × 240 pixels resolution and standard quality, the camera can buffer about 250 frames. (If 3 triggers are enabled [maximum 5 triggers], the internal memory capacity is divided into 3 sections. In this case, each trigger can buffer about 80 frames.) See page

132 for more details regarding the internal memory

capacity.

• The digital zoom can be used while viewing buffered images (while playing video [Motion JPEG]).

• The Click to Center feature can be used while using the digital zoom.

[For assistance, please call: 1-800-272-7033] 23

Page 24

Operating Instructions

1.4.1 Deleting Buffered Images

If you intend to delete images for each transfer method, click [Delete Buffered Images] on the Trigger page (see page

Note

• If you are buffering images to the internal memory, the following operations

also delete all buffered images. – Turning off the camera. – Saving the Date and Time page. – Restarting, updating firmware or resetting the camera to factory default. – Changing the Enable/Disable settings on the Image Buffer/Transfer page

(See page 60 or page 70).

60 or page 70).

Page 25

Operating Instructions

1.5 Viewing Still Images on Your Cell Phone

Still images can be viewed over the Internet from a compatible cell phone. Enter "http://IP address (or URL):Port Number/mobile" on a cell phone and

press [OK].

• When the port number is set to 80 (default), it is not required.

E.g.

http:// . . . :50000/mobile

(or .viewnetcam.com:50000/mobile)

• Allow access from the Internet to access the camera from cell phones.

• When an authentication window is displayed, enter the administrator's or general user's user name and password.

• A still image is displayed. (Video [Motion JPEG] cannot be displayed.)

Pressing 5 will refresh the image.

160 × 120 resolution is displayed on the first access. Pressing 0 switches the resolution to 320 × 240.

An administrator can enable or disable the Image Buffer/Transfer setting from your cell phone. (See page

27)

[For assistance, please call: 1-800-272-7033] 25

Displays up to 50 Logs in order of time. (Only for an administrator)

Goes to the control page. Displays the number of

new logs.

MD: Motion Detection Displays the date and

time.

Goes to the control page.

Page 26

Operating Instructions

Note

• If the image is not displayed properly, try the following 2 URLs.

1. http:// IP address(or URL):Port Number/MobileH for HTML.

(or .viewnetcam.com:50000/MobileH)

2. http:// IP address(or URL):Port Number/MobileX for XHTML.

(or .viewnetcam.com:50000/MobileX)

• Some cell phones are not compatible with Panasonic Network Cameras.

Some phones may allow viewing only on port 80, and some may not support password authentication. See the Panasonic Network Camera support website below for a list of cell phones, and their level of compatibility with the Panasonic Network Camera.

• Some cell phones display images at a decreased size.

• If [Permit access from guest users] or [Permit access from guest users (mobile

only)] is selected, users can access cell phone-specific screens via a cell phone or PC without the need for authentication.

• Only administrators can operate the Sensor log and Buffer/Transfer.

Panasonic Network Camera support website: http://panasonic.co.jp/pcc/products/en/netwkcam/

Page 27

Operating Instructions

1.5.1 Enabling or Disabling the Buffer/Transfer on Your Cell Phone

1. Access camera images from your cell phone, and log in as an administrator

(see page 25).

2. Select [Buffer/Transfer].

3. Select a trigger number that you want to enable or disable.

Example: Enabling the Buffer/Transfer setting (No.1).

• Selecting [Control Page] changes to the previous page.

4. Select [Save].

• Selecting [Save] enables or disables the buffer/transfer settings, and all buffered images will be deleted.

• Selecting [Cancel] takes you back to the previous page without saving changes.

[For assistance, please call: 1-800-272-7033] 27

Page 28

Operating Instructions

2 Using the Camera's Basic Features

2.1 Setup Page of the Camera

1. Access the camera (see page 10).

• The Top page is displayed.

Note

• When [Permit access from guest users] is set on the Security:

Administrator page, click the [Login] tab (see page administrator.

• When users other than an administrator are accessing the camera, the

[Setup] and [Maintenance] tabs are not displayed.

2. Click the [Setup] tab at the top of the page.

The feature is for only BL-C20A.

(1)

(2) (3) (4) (5) (6)

56) and log in as an

(7) (8)

(9) (10) (11)

(12)

(13)

(14) (15)

Page 29

Operating Instructions

Basic

(1) Network Configures network settings to connect the camera to the

network (see page

31).

(2) [For BL-C20A]

Configure a wireless network (see page 36).

Wireless

(3) UPnP Enables automatic port forwarding and creates a shortcut

to the camera (see page

39).

(4) DynamicDNS Registers with the DynamicDNS service (see page 42).

(5) Date and Time Sets the date and time, automatic time adjustment and

daylight saving time settings (see page

48).

(6) Camera Sets camera name, white balance, AC power source

frequency and color night view (see page 50).

Account

(7) Administrator*1Sets authentication and administrator security (user name

and password) (see page

52).

(8) General User*1Sets general user security (user name and password) and

access levels (see page

57).

Buffer/Transfer

(9) Tri gger Sets image buffer or transfer by timer or motion detection.

(See page 60 or page 70)

(10) Motion

Detection

Sets the threshold and sensitivity for motion detection (see page

83).

(11) Sensor Log Sets the information required to send log notifications by e-

mail (see page

86).

[For assistance, please call: 1-800-272-7033] 29

Page 30

Operating Instructions

Advanced

(12) Image Display Sets the resolution, image quality and refresh interval of the

Single Camera and Multi-Camera page, Limit Continuous Motion JPEG setting

, language and banner display (see

page 89).

(13) Multi-Camera*1Sets the camera IP address or host name, and camera

name on the Multi-Camera page (maximum 12 cameras) (see page

92).

(14) Operation

Time

(15) Indicator

Sets the time period to display camera images (see page

94).

Sets the indicator display (see page 96).

Control

If you change the [Administrator], [General User], [Multi-Camera] page settings or Limit Continuous Motion JPEG setting, changes will not be applied to video (Motion JPEG) viewers. Restart the camera to apply changes to all video viewers.

Page 31

Operating Instructions

2.2 Connecting the Camera to Your Network

The Network page offers three options to configure the camera.

• [Automatic Setup] automatically assigns an unused IP address to the camera, and uses UPnP

• [Static] allows the user to use a specific IP address.

• [DHCP] is offered for ISPs that require this option.

1. Click [Network] on the Setup page.

2. Click a connection mode.

• See below for details of each connection mode.

3. Enter each parameter in the relevant data field.

Automatic Setup

The camera automatically obtains the network settings (subnet mask, default gateway and DNS server address) using the router's DHCP feature. The camera also automatically searches for an unused IP address on your network. If you select [Yes] for Allow Access from the Internet, the camera automatically enables port forwarding using UPnP automatically searches for an unused port number on your network in order from 50000 to 50050.

(Universal Plug and Play) to configure your router.

Most common mode of setup.

Uses a static IP address.

Uses ISP DHCP server function.

. In this case, the camera

• Clicking [Cancel] takes you back to the previous page without saving

changes.

[For assistance, please call: 1-800-272-7033] 31

Page 32

Operating Instructions

DHCP Setup Static Setup

• Clicking [Cancel] takes you back to the previous page without saving changes.

4. Click [Save] when finished.

• The new settings are saved.

• When finished, the following page is displayed.

Note

The current network settings are shown on the Status page in the Maintenance section (see page

98).

5. Click [Restart].

• The camera restarts, and the Top page is displayed.

• When the camera is restarted, all buffered images in the internal memory are deleted.

• Checking [Yes] for [Allow Access from the Internet] on [Automatic Setup] may not display the Top page, because the port number may change. Use the Setup Program to access the camera.

Page 33

Operating Instructions

Note

If you do not know the camera IP address when setting [Automatic Setup] or [DHCP Setup], it can be searched for by using the Setup Program (see page

120).

Setting Description

Allow Access from the Internet (Automatic Setup Only)

Network Configuration from Setup Program (Static/DHCP Only)

Port Number (Static/DHCP Only)

• The Allow Access from the Internet setting automatically configures the router's Port Forwarding setting (some routers call it "Address Translation", "Static IP Masquerade", "Virtual Server" or "Port Mapping"). To enable Internet access to the camera, check [Yes]. In this case, the camera automatically searches for an unused port number on your network in order from 50000 to

50050. To disable Internet access to the camera, check [No].

• To prohibit the Setup Program from changing the network settings, uncheck the box.

• The default port number is 80. When you use multiple cameras with a router on your network, each camera must be assigned its own port number (see page

41 "2.4.2 Connecting the Camera to a Router that does not Support UPnP™").

– Do not set the following port numbers.

FTP: 20 and 21, Telnet: 23, SMTP: 25, DNS: 53, POP3: 110, HTTPS: 443, ICQ: 4000 and IRC: 6661—

6667.

• Enter a number between 1—65535.

• Some ISPs do not allow you to use port 80. Ask your ISP or network administrator about which port numbers are accessible over the Internet.

• IP address

• Subnet Mask (Static Only)

• If your ISP or network administrator specifies an IP address and subnet mask, enter them in each data field.

• If you use the camera on a LAN, set an IP address with the same class as your PC (see page 119).

• Set 4 numbers (0—255) and 3 periods, such as "192.168.0.253". Note that "0.0.0.0" and "255.255.255.255" are not available.

[For assistance, please call: 1-800-272-7033] 33

Page 34

Operating Instructions

Setting Description

Host Name (DHCP Only)

Default Gateway

(Static/DHCP Only)

DNS Server Address

(Static/DHCP Only)

Max. Bandwidth Usage

• If your ISP uses the DHCP function, which automatically

assigns an IP address to the camera, enter the ISPassigned host name. (The host name may be used as an authentication.)

• Enter ASCII characters for the host name (see page 131).

Note that [Space], ["], ['], [&], [<] and [>] are not available.

• If you have been assigned a Default Gateway address by

your ISP or network administrator, enter it in this data field.

• Set 4 numbers (0—255) and 3 periods, such as

"192.168.0.253". Note that "0.0.0.0" and "255.255.255.255" are not available.

• The DNS server address is required in the following

situations: – Transferring camera images by E-mail or FTP – Setting cameras by their host names on the Multi-

Camera Setup page – Using the DynamicDNS service – Using the sensor log notification

• If you have been assigned a DNS server addresses by your ISP or network administrator, enter them in this data field. There are usually two addresses.

• Set 4 numbers (0—255) and 3 periods, such as "192.168.0.253". Note that "0.0.0.0" and "255.255.255.255" are not available.

• The bandwidth can be restricted.

• Select a maximum bandwidth from [Unlimited] to [0.1 Mbps].

Note

Set a maximum bandwidth referring to the following file sizes. These are examples for a JPEG file of standard image quality. File sizes may change depending on the image quality or the brightness of the object.

160 × 120 pixels: About 3 KB (24 Kbit) 320 × 240 pixels: About 10 KB (80 Kbit) 640 × 480 pixels: About 18 KB (144 Kbit)

Page 35

Operating Instructions

Setting Description

Connection Type • Select [Auto Negotiation] normally. For wireless

connection (BL-C20A only), [Auto Negotiation] must be selected. If the camera cannot be accessed, see page Troubleshooting on the CD-ROM.

If the IP address is automatically obtained from a DHCP server, this field does not need to be set.

9 of

[For assistance, please call: 1-800-272-7033] 35

Page 36

Operating Instructions

2.3 [For BL-C20A] Using Wireless LAN

Wireless communication is possible by adjusting the settings of the wireless LAN to those of the wireless router. Take a note of the settings and save them for reference. For more information about wireless settings, please refer to

panasonic.co.jp/pcc/products/en/netwkcam/.

1. Click [Wireless] on the Setup page.

2. Set each parameter for Wireless Configuration.

Setting Description

SSID • The SSID must be set to match the SSID your wireless

router or wireless LAN uses. The SSID is limited to 32 characters (alpha numeric) and is case sensitive.

http://

Communication mode

• 802.11b: There are a lot of 802.11b-compliant products and they are inexpensive. They are widely prevalent, so it is likely that 802.11b will match your existing wireless devices.

• 802.11b/g (default): This mode supports both the 802.11b and 802.11g wireless LAN standards. It is the communication mode that is easiest to install on your existing wireless LAN.

• 802.11g exclusive: This mode communicates using

802.11g only. It does not support the mixed standard mode of 802.11b/g, so it allows the use of original features of

802.11g.

Even if "802.11g exclusive" is in use, the existence of other wireless devices using a 2.4 GHz bandwidth —including 802.11b wireless devices— may make the baud rate on the

802.11g slower.

Page 37

3. Set each parameter for Encryption.

Setting Description

Cipher • Select to encrypt or not encrypt.

• To prevent unauthorized users from reading data, selecting [WEP] is recommended.

Operating Instructions

WEPKey Selection

• The checked WEPKey is used as the standard WEPKey. Check the same WEPKey as the one selected for the router.

WEPKey1—4 • Select one from [HEX, 10 characters 64 bit], [HEX, 26

characters 128 bit], [HEX, 32 characters 152 bit], [ASCII 5 characters 64 bit], [ASCII 13 characters 128 bit] or [ASCII 16 characters 152 bit].

• Selecting [WEP] at Cipher enables you to set WEPKey1—

4. One or all of the four keys can be set. Check the same key number as set to the wireless router, and set the same encryption as at the wireless router.

<Example> HEX, 10 characters 64 bit : 012345abcd

HEX, 26 characters 128 bit : 0123456789abcdef012

345abcd

HEX, 32 characters 152 bit : 0123456789abcdef012

3456789abcdef

ASCII 5 characters 64 bit : 012yz

ASCII 13 characters 128 bit : 0123456uvwxyz

ASCII 16 characters 152 bit : 0123456789uvwxyz

[For assistance, please call: 1-800-272-7033] 37

Page 38

Operating Instructions

Note

• Some wireless devices do not support the WEP 152 bit encryption.

• The camera supports only open system authentication. If the wireless router or access point is set to shared key authentication, set it to auto or open system.

4. Click [Save] when finished.

• The new settings are saved.

• When finished, "Success!" is displayed.

5. Click [Go to Wireless configuration page].

• The Wireless page is displayed.

6. Set the switch to WIRELESS.

Note

• Encryption helps protect data within wireless LAN from third parties.

• Enter both the MAC addresses for the camera itself and the camera's wireless module to enable the MAC address filtering feature on the wireless router. The wireless module MAC address is one value higher than the camera MAC address.

• It takes about 1 minute for the new settings to become effective.

• It is not possible to access the camera simultaneously by both wired and wireless connection.

• To communicate using wireless connection, set up the camera using wired connection and flip the switch from WIRED to WIRELESS as shown below.

• Even if the camera is set to wired connection, it emits electrical waves for about 5 minutes after the power has been on. During this time, the router's wireless indicator is on or blinking. Electrical waves will stop being transmitted after about 5 minutes.

< Side >

Switch

• When you switch from WIRED to WIRELESS or vice versa, restart the camera. Some routers may also need to be restarted after switching.

Page 39

Operating Instructions

2.4 Using UPnP™ (Universal Plug and Play)

UPnPTM can automatically configure your router to make it accessible from the Internet. In order to use this feature, your router needs to support UPnPTM, and it must be enabled. UPnP panasonic.co.jp/pcc/products/en/netwkcam/ and your router's manual for details of how to enable UPnPTM. After UPnPTM is enabled on the router, set [Enable] for auto port forwarding.

1. Click [UPnP] on the Setup page.

2. Set up UPnP.

Setting Description

is disabled on most routers by default. See http://

Auto Port Forwarding

Display Short cut Icon in My Network Places

• If the network setting is [Static] or [DHCP], enabling auto port forwarding allows you to access the camera from the Internet.

Note

If the network setting is [Automatic Setup], also enable [Allow Access from the Internet] on the Network page (see page 33).

• Enabling this creates a shortcut to the camera in the My Network Places folder.

Note

To enable this feature when using Windows XP or Windows Me, enable the UPnP beforehand (see page

130).

[For assistance, please call: 1-800-272-7033] 39

Windows component

Page 40

Operating Instructions

3. Click [Save] when finished.

• The new settings are saved.

• When finished, "Success!" is displayed.

4. Click [Go to UPnP page].

• The UPnP page is displayed.

2.4.1 Connecting the Camera to a Router that Supports UPnP™

To allow access from the Internet with a router supporting UPnPTM, follow the procedures shown in Getting Started.

Note

• On some routers, the UPnPTM feature is disabled by default. Enable your router's UPnP camera. See the Panasonic Network Camera support website at panasonic.co.jp/pcc/products/en/netwkcam/ for details.

• If a maximum idle time is set in PPPoE or PPTP connection with your ISP, disable it on the router. See the router manual for details.

feature following the router manual before you set up the

http://

Page 41

Operating Instructions

2.4.2 Connecting the Camera to a Router that does not Support UPnP™

To allow access from the Internet with a router that does not support UPnPTM, follow the procedures below.

1. Select [Static] on the Network page.

(1) Access the camera (see page 10). (2) Click the [Setup] tab at the top of the page. (3) Select [Static] on the Network page.

• The Static IP Address Configuration page is displayed. Make a note of the IP address and port number, since they are required to enable port forwarding on the router.

(4) Click [Save] without changing the settings. (5) Click [Restart].

2. Enable port forwarding

on the router.

Using the IP address and port number noted on step 1-(3), enable port forwarding on the router. See the router manual for how to enable port forwarding.

3. Register with the DynamicDNS service.

Port Forwarding feature

The port forwarding feature is required to allow camera access from the Internet with a router that does not support UPnP global one. Each camera must be assigned a unique port number.

Global IP address or URL

Port No.

Port Forwarding feature

vvv.xxx.yyy.zzz:80 vvv.xxx.yyy.zzz:81

Internet

192.168.0.254

Router

Note

The IP addresses shown above may differ from those offered on your home network.

. It exchanges a local IP address for a

vvv.xxx.yyy.zzz:80 192.168.0.253:80 vvv.xxx.yyy.zzz:81 192.168.0.252:81

192.168.0.1

192.168.0.252 Por t N o.

192.168.0.253 Por t N o.

"Port forwarding" may be called "Address translation", "Static IP Masquerade", "Virtual server" or "Port mapping" in other products.

[For assistance, please call: 1-800-272-7033] 41

Page 42

Operating Instructions

2.5 Registering with the DynamicDNS service

DynamicDNS is a service that allows you to assign an easy-to-remember name to the camera, for example, similar to your favorite web site. It also allows you to easily access the camera, even when your ISP changes the IP address. Panasonic Communications recommends that you register with a DynamicDNS to access the camera from the Internet. See Viewnetcam.com service.

1. Click [DynamicDNS] on the Setup page.

• When you select [Disable] or [Viewnetcam.com] (see page 42)

• When you select [User-specified DynamicDNS] (see page 44)

When you select [Disable]

2. Click [Save].

• The DynamicDNS service is disabled.

• Clicking [Cancel] cancels your settings without saving changes.

When you select [Viewnetcam.com]

2. Click [Next].

http://www.viewnetcam.com for details about the

• Clicking [Cancel] cancels your settings without saving changes.

Page 43

Operating Instructions

3. Click [Save].

• Clicking [Cancel] cancels your settings without saving changes, and the DynamicDNS window is displayed.

Setting Description

Personal (Camera) URL

Your Account Link

• The camera's personal URL will be displayed after you register with the Viewnetcam.com service.

• The URL required to register with the Viewnetcam.com service is displayed. Clicking [Your Account Link] item name displays the Viewnetcam.com registration website.

4. Click [OK].

• When finished, "Success!" is displayed.

• The new settings are saved.

5. Click [Go to Viewnetcam.com page].

• The Viewnetcam.com page is displayed.

6. Click Your Account Link.

• The Viewnetcam.com registration website is displayed.

Note

• When the Viewnetcam.com registration website is not displayed, confirm that the URL is displayed in the right column next to Your Account Link. If the URL is not displayed, follow the procedures below.

1. Wait for a moment, then click [Refresh] on the web browser.

2. Confirm that your network (your PC and camera) is connected to the Internet.

• Personal (Camera) URL is available after registering with the Viewnetcam.com service.

• If port forwarding is not enabled or your network is not connected to the Internet, the Viewnetcam.com service is not available.

7. Register with the Viewnetcam.com service following the instructions on the

website.

• The Viewnetcam.com page is displayed.

[For assistance, please call: 1-800-272-7033] 43

Page 44

Operating Instructions

8. Access your camera with the registered URL from the Internet (see page 10).

• When the Top page is displayed, Viewnetcam.com registration is

complete.

Note

• It may take a maximum of 30 minutes for the registered URL to work.

• If "Expired" is displayed for the Personal (Camera) URL on the

Viewnetcam.com page or for the Camera URL at Viewnetcam.com on the Status page, restart the camera. After that, confirm that your registered URL is displayed on the pages.

Confirming Internet access

Due to the router's specifications, the image may not be displayed even if you access the camera from your PC on the same LAN as the camera. In this case, try:

• Accessing from a PC on another network (see page 10)

• Accessing from your cell phone (see page 25)

When you select [User-specified DynamicDNS]

2. Click [Next].

• Clicking [Cancel] cancels your settings without saving changes.

Page 45

3. Set each parameter.

• Clicking [Cancel] cancels your settings without saving changes.

• DynamicDNS information can be obtained from companies in the DynamicDNS service industry.

Setting Description

Operating Instructions

DynamicDNS Server URL

Input URL acquired from the DynamicDNS service industry

company. Enter 1—255 characters. The URL must be started with "http://".

Updating time Specify the updating time.

User Name

Input User Name acquired from the DynamicDNS service industry company. Enter up to 63 characters.

Password

Input Password acquired from the DynamicDNS service industry company. Enter up to 63 characters.

Note that [Space] and ["] are not available.

Note that ["] and [:] are not available.

4. Click [Save] after finished.

• The new settings are saved.

• When finished, "Success!" is displayed.

5. Click [Go to DynamicDNS page].

• The DynamicDNS page is displayed.

[For assistance, please call: 1-800-272-7033] 45

Page 46

Operating Instructions

Note

• It may take several minutes for the registered URL to connect.

• Some DynamicDNS services may not connect.

Confirming Internet access

Due to the router's specifications, the image may not be displayed even if you access the camera from your PC on the same LAN as the camera. In this case, try:

• Accessing from a PC on another network (see page 10)

• Accessing from your cell phone (see page 25)

2.5.1 DynamicDNS Service

DynamicDNS allows you to choose an easy-to-remember address (such as "bob.viewnetcam.com") that can be used to view images from your camera over the Internet.

What are the advantages of DynamicDNS service?

In order to view camera images over the Internet, you need to know your camera's global IP address. However, many Internet Service Providers (ISPs) assign their customers a "dynamic" IP address that changes monthly, weekly, or each time they log on. Unless you have been assigned a static IP address (an IP address that does not change periodically) by your ISP, you may find it difficult to access your camera over the Internet. The Viewnetcam.com service allows you to access your camera even if your assigned global IP address changes.

Page 47

How the DynamicDNS service works

DynamicDNS service server

Operating Instructions

DNS

server

DNS looks up current address

New address registered with DNS server

Internet

Off-site PC

Camera connection established

Camera reports new address

ISP

Global IP address changes

On-site Network Camera

1. Your ISP assigns a global IP address to your Internet access account that

changes periodically. This is the address needed to access the camera over the Internet.

2. When your ISP-assigned global IP address changes, your camera

automatically notifies the DynamicDNS service server of the new address in the DynamicDNS. The camera notifies the DynamicDNS service server of the new address in DynamicDNS in the following cases.

– When starting the camera – When an update interval time has been set. – When clicking the [Save] button

3. The DynamicDNS server contacts the Domain Name System (DNS) server

and registers your new global IP address to your chosen DynamicDNS address (such as "bob.viewnetcam.com").

4. When you enter your DynamicDNS address in your web browser while away

from home or the office, the DNS server looks up the global IP address assigned to your DynamicDNS address.

5. The DNS server finds your current global IP address and allows you to connect

to your camera.

Note

• Ask your ISP about what type of IP address you are using.

• Some ISPs assign you a local IP address. In this case, the DynamicDNS service cannot be used.

• If the camera is using a port number other than 80, the port number must be specified at the end of the DynamicDNS URL. For example: Using port 80: http://(Cameraname).viewnetcam.com Using any other port: http://(Cameraname).viewnetcam.com:Port

Number

[For assistance, please call: 1-800-272-7033] 47

Page 48

Operating Instructions

2.6 Setting the Date and Time

The Date and Time page allows you to set and confirm the date and time. The date and time are used for the settings of the trigger setting, sensor log, operation time and Buffered Image page.

Note

Saving a new date and time deletes all buffered images on the internal memory.

1. Click [Date and Time] on the Setup page.

2. Set each parameter.

• Set [Automatic Time Adjustment] to synchronize the time automatically

with an NTP server.

• Clicking [Cancel] cancels your settings without saving changes.

Page 49

Setting Description

Operating Instructions

Time Setting

Automatic Time Adjustment

Adjust Clock for Daylight Saving Time

• Set the date and format (AM/PM or 24 H). The interface and available values depend on the format. The date and time are used for the settings of the trigger setting, sensor log, operation time and Buffered Image page. Note that the format for the subject and file name of Emails by E-mail or FTP transfer can only be 24 h.

• NTP (Network Time Protocol) server synchronizes the camera's internal clock automatically every day. Check the box to enable it.

• Set the NTP server IP address. Set 4 numbers (0—255) and 3 periods, such as "192.168.0.253". Note that "0.0.0.0" and "255.255.255.255" are not available. Set a host name (1—255 characters). Note that [Space], ["], ['], [&], [<] and [>] are not available.

• Select your time zone.

Note

The camera will not synchronize to the NTP server if there is more than a 1 hour difference between the NTP server time and the camera's current time. This is to protect the camera's time setting from fraudulent NTP server tampering, incorrect time information, etc.

• During daylight saving time, the internal clock is turned forward an hour. The clock will shift one hour forward at the set time on the Start Day, and move back one hour at the set time on the End Day. Check the box to enable it.

Note

An "s" is inserted between the date and time of the time stamp when this feature is enabled. The time stamp is printed on images transferred by the Image Transfer feature.

3. Click [Save] when finished.

• The new settings are saved.

• When finished, "Success!" is displayed.

4. Click [Go to Date and Time page].

• The Date and Time page is displayed.

Note

Date and time settings become incorrect depending on the length of time the camera is turned on and its internal temperature. Using the Automatic Time Adjustment is recommended.

[For assistance, please call: 1-800-272-7033] 49

Page 50

Operating Instructions

2.7 Changing Camera Settings

The Camera page allows you to set the camera name, white balance, AC power source frequency and color night view.

1. Click [Camera] on the Setup page.

2. Set each parameter.

• Clicking [Cancel] cancels your settings without saving changes.

Setting Description

Camera Name

• The camera name is displayed on the Single Camera page.

• Enter ASCII characters (see page 131) or characters from

other languages (1—15 characters for a 1-byte character and 1—7 characters for a 2-byte character). Note that [Space], ["], ['], [&], [<], and [>] are not available.

Page 51

Setting Description

White Balance Select from the following options.

• Auto (default) — Automatic adjustment

• Fixed Indoor — Electric bulb (2800 K)

Operating Instructions

AC Power Source Frequency

Color Night View

• Fixed Fluorescent (White)

• Fixed Fluorescent (Daylight)

• Fixed Outdoor — Solar light (6000 K)

— White (3600 K)

— Daylight (4000 K)

Note

The kelvin (symbol: K) is the standard unit for color temperature.

• This setting may correct flickering caused by power line frequency.

– 60 Hz (default) –50 Hz

Select 60 Hz in the United States.

• In the color night view mode, the camera image becomes brighter in a low illuminance. The camera image returns to normal operation in a bright location.

• If you enable the color night view mode, refresh interval may increase.

• Subjects that are moving in low illumination may be blurred, not distinguished, or not displayed.

Note

When the camera transmits a dark scene, the camera image may become white, or horizontal lines may be displayed on the screen. This is one of the characteristics of a CMOS sensor. This is not a malfunction.

3. Click [Save] when finished.

• The new settings are saved.

• When finished, "Success!" is displayed.

4. Click [Go to Camera page].

• The Camera page is displayed.

[For assistance, please call: 1-800-272-7033] 51

Page 52

Operating Instructions

3 Registering Users

3.1 Changing the Authentication Setting and Administrator User Name and Password

The Security: Administrator page allows you to change authentication, and the administrator's user name and password. An authentication window allows registered users to access the camera.

Note

• If you access the camera for the first time, the window for setting the administrator's user name and password is displayed. Make a note of the user name and password so that you will not forget them.

• The user name and password should be secured at your own responsibility. Pay attention to the following points.

– Set a user name and password with as many characters as possible. – Change the password regularly.

• Setting [Permit access from guest users] (permitting access without a User Name or Password) or [Permit access from guest users (mobile only)] (permitting access without a User Name or Password) at General Authentication risks the images being viewed by third parties. Control the contents of the images accordingly.

IMPORTANT

• It is important to limit access to the camera by use of a unique User Name and a secret Password. Because the camera is accessed through the Internet it is possible that the camera could be accessed by unknown individuals, including those who are commonly known as "crackers" to whom you do not want to allow access. The use of a unique User Name and a Password known only to you will help insure that only authorized individuals are given access to the camera. You have the option of proceeding without a User Name and Password, but it is strongly recommended that you utilize these protections.

1. Click [Administrator] on the Setup page.

Page 53

2. Set each parameter.

• Clicking [Cancel] cancels your settings without saving changes.

Setting Description

Operating Instructions

General Authentication

Authentication has 3 phases.

• If you set [Permit access from guest users], the camera does not display the authentication window in camera access. All guest users can view images without a user name and password.

Note

If you set [Permit access from guest users], [Login] tab is displayed at the top of the page. After you log in as an administrator (see page 56), the Setup page and the Maintenance page can be accessed.

• If you set [Permit access from guest users (mobile only)], an authentication window is not displayed even if you access the cell phone page. All guest users can view images without a user name and password.

• If you set [Do not permit access from guest users], an authentication window is displayed to access the camera. Users must enter the user name and password.

[For assistance, please call: 1-800-272-7033] 53

Page 54

Operating Instructions

Setting Description

User Name/ Password

• User Name (6 to 15 characters): Enter the user name.

• Password (6 to 15 characters): Enter the password.

Note

The password must be different from the user name.

• Retype Password: Reenter the password.

• Enter ASCII characters (see page 131). Note that [Space],

["], ['], [&], [<], [>] and [:] are not available.

Note

• When setting authentication, set the user name and password, and save them.

• When users other than an administrator are accessing the camera, the [Setup] and [Maintenance] tabs will not be displayed.

• The user name and password are case sensitive.

3. Click [Save] when finished.

• The new settings are saved.

• When finished, "Success!" is displayed.

4. Click [Go to Security: Administrator page].

• The Security: Administrator page is displayed.

Note

When the user name and password have been changed, the camera displays an authentication window. Enter the user name and password, and click [OK].

Page 55

Operating Instructions

Administrator/General Users/Guest Users

The camera has 3 user levels (administrator, general users and guest users).

Items Administrator General Users Guest Users

User Name and Password

Number of Users 1 50 —

Accessible Pages All Pages Pages Except For

Access Level All Operations Access level can

Required Required Not Required

Pages Except For

Setup and

Maintenance page

be set for each

general user (see

page

57).

Setup and

Maintenance page

Access level can

be set for guest

users (see page

57).

Note

Guest users mean unregistered users. Set [Permit access from guest users] or [Permit access from guest users (mobile only)] on the Security: Administrator page (see page 52) to allow access from guest users.

[For assistance, please call: 1-800-272-7033] 55

Page 56

Operating Instructions

3.2 Logging in to the Camera

If you set [Permit access from guest users] on the Security: Administrator page, [Login] tab is displayed at the top of the page. After you log in as an administrator, the Setup page and the Maintenance page can be accessed.

1. Click [Login] tab at the top of the page.

2. Check a login mode, and click [Login].

Note

The authentication window is displayed. Enter the user name and password set for General Users or Administrator.

3. Enter a valid user name and password according to the Login mode selected

in step 2, and click [OK].

Page 57

Operating Instructions

3.3 Creating, Modifying or Deleting General Users

The General User page allows you to create, modify or delete general users. Up to 50 general users can be registered. The access level is set for each general user. If you set [Permit access from guest users] or [Permit access from guest users (mobile only)] on the Security: Administrator page, the access level can be set for guest users.

Note

For general users, the Setup and Maintenance tabs are not displayed.

1. Click [General User] on the Setup page.

2. To create a general user, click [Create].

• When setting [Do not permit access from guest users]

• To change the settings of general users or guest users, select their name and click [Modify]. The modification page is displayed.

• To delete a general user, select the name and click [Delete]. The confirmation page is displayed.

• When setting [Permit access from guest users] or [Permit access from guest users (mobile only)]

[For assistance, please call: 1-800-272-7033] 57

Page 58

Operating Instructions

3. Set each parameter.

• Settings for general users • Settings for guest users

• Clicking [Cancel] takes you back to the previous page without saving changes.

Setting Description

User ID List • Up to 50 general users can be registered.

• The list is used to modify or delete general user settings.

User Name/ Password

• User Name (6 to 15 characters): Enter the user name.

• Password (6 to 15 characters): Enter the password.

Note

The password must be different from the user name.

• Retype Password: Reenter the password.

• Enter ASCII characters (see page 131). Note that [Space], ["], ['], [&], [<], [>] and [:] are not available.

Access Level An access level is set for each general user.

• Level 1 : Only the camera images can be viewed.

• Level 2 : The camera images can be viewed and the brightness can be adjusted.

4. Click [Save] when finished.

• The new settings are saved.

• When finished, "Success!" is displayed.

5. Click [Go to General User page].

• The General User page is displayed.

Page 59

Operating Instructions

4 Buffering or Transferring Images

4.1 Procedures of Buffering or Transferring Images

The procedures from this page to page 70 are described about settings of the image buffer or transfer. See the procedures below to understand the general outline of the settings.

Buffer/Transfer by Timer (Page 60)

Time Setting

Image Setting

Image Buffer Frequency Setting

Transfer Method (Select one from the lists.)

• No Transfer, No Memory Overwrite

• No Transfer, Memory Overwrite

• FTP

• E-mail

Save the settings to complete.

Buffer/Transfer by Motion Detection Signal (Page 70)

Time Setting

Image Setting

Image Buffer Frequency Setting

Transfer Method (Select one from the lists.)

• No Transfer, No Memory Overwrite

• No Transfer, Memory Overwrite

• FTP

• E-mail

E-mail Notification

When Triggered Setting

Save the settings to complete.

Changing Motion Detection Sensitivity

(Page 83)

Notifying the Sensor Log

(Page 86)

[For assistance, please call: 1-800-272-7033] 59

Page 60

Operating Instructions

4.2 Buffering or Transferring Images by Timer

The Trigger page allows you to enable image buffer/transfer by E-mail or FTP.

1. Click [Trigger] on the Setup page.

2. Click a No. to enable buffer/transfer.

3. Check [Enable Image Buffer/Transfer], and select [Timer] for the trigger, and

click [Next>].

Note

• Click [Delete Buffered Images] to delete images already buffered.

• Click [Save] to save the settings. The buffered images will be deleted.

• Clicking [Cancel] takes you back to the Trigger page without saving changes.

Setting Description

Enable Image Buffer/Transfer

• Check the box to enable the Trigger setting. Uncheck the box to disable it.

Page 61

Operating Instructions

Setting Description

Trigger • Selecting [Timer] enables the camera to buffer/transfer

images during the specified date and time by timer.

• Selecting [Motion Detection] enables the camera to buffer/ transfer images when the motion is detected during the specified date and time.

4. Set the time, and click [Next>].

Note

The timer works by an internal clock. Set the date and time before using timer buffer/transfer (see page

• Clicking [<Back] takes you back to the previous page.

• Clicking [Cancel] takes you back to the Trigger page without saving changes.

Setting Description

48).

Day of the week • Check the box to enable the day. Uncheck the box to

disable it.

Active Time of Trigger

• To set a trigger time, check the time option and set a time period. Check the [Always] option if you are not specifying a time period.

5. Set the image settings, and click [Next>].

• Clicking [<Back] takes you back to the previous page.

• Clicking [Cancel] takes you back to the Trigger page without saving changes.

[For assistance, please call: 1-800-272-7033] 61

Page 62

Operating Instructions

Setting Description

Image Resolution

Image Quality • Select the image quality.

• Select an image resolution (640 × 480, 320 × 240 (default) or 160 × 120 pixels) for the buffer/transfer.

[Favor Clarity] optimizes for good quality. [Standard] offers standard quality. (default) [Favor Motion] optimizes for enhanced motion. [Mobile Phone] is for a transfer to a cell phone.

Note

640 × 480 pixels cannot be set for a transfer to a cell phone.

6. Set the image buffer frequency, and click [Next>].

Note

Due to the network environment, object and the number of simultaneous accesses, the camera may not record the number of images that you set. In this case, set the image buffer frequency longer.

• Clicking [<Back] takes you back to the previous page.

• Clicking [Cancel] takes you back to the Trigger page without saving changes.

Setting Description

Image Buffer Frequency

• Select an image buffer frequency to buffer or transfer the image. (1 image per hour—15 images per second)

Page 63

Operating Instructions

7. Select the transfer method, and click [Next>].

• Clicking [<Back] takes you back to the previous page.

• Clicking [Cancel] takes you back to the Trigger page without saving changes.

Note

If you transfer images by E-mail or FTP, confirm that the default gateway and DNS server addresses are assigned correctly (see page

Setting Description

31).

No Transfer, No Memory Overwrite

No Transfer, Memory Overwrite

FTP • The camera transfers the image to an FTP server (see

E-mail • The camera transfers the image by E-mail (see page 66).

• If the internal memory is full, the camera stops buffering.

• If the internal memory is full, the camera deletes the old images, and continues to buffer the image.

page 64).

[For assistance, please call: 1-800-272-7033] 63

Page 64

Operating Instructions

When you set [FTP] for Transfer Method

Select [FTP], and click [Next>]. The following page is displayed.

• Clicking [<Back] takes you back to the previous page.

• Clicking [Cancel] takes you back to the Trigger page without saving changes.

Page 65

Setting Description

Operating Instructions

Server IP Address or Host Name

• If you set a server IP address, set 4 numbers (0—255) and 3 periods, such as "192.168.0.253". Note that "0.0.0.0" and

"255.255.255.255" are not available. Or set a host name (1— 255 characters).

Por t No. • Enter a number (1—65535). Usually set to 21.

• If your ISP requires a login ID, set it (0—63 characters).

Password*2• If your ISP requires a password, set it (0—63 characters).

Time] and the image buffer frequency value is set within 1 minute, the camera logs in to the server only once. This can reduce transfer time.

Upload File

Name

• Set a file name on the FTP server to receive the transferred files. Enter 1—234 characters. Entering "\" creates directories for a file. (E.g. NetworkCamera\image.jpg)

Overwrite Setting

• Selecting [Overwrite File] overwrites the image on the server with a newer image. Selecting [Save as New File with Time Stamp] saves the image attaching time stamps on the file name, and the images are not overwritten.

(E.g. image20050101093020500.jpg) The underlined numbers mean "9h30min20s500ms on January 1, 2005". The letter "s" is inserted after the day when referring to a daylight saving time zone.

Data Tr an s fe r

• Select [Passive Mode] normally. If the transfer does not work, select [Active Mode] and check the operation.

Method

Note that [Space], ["], ['], [&], [<] and [>] are not available.

Note that ["] is not available.

[For assistance, please call: 1-800-272-7033] 65

Page 66

Operating Instructions

When you set [E-mail] for Transfer Method

Select [E-mail], and click [Next>]. The following page is displayed.

• Clicking [<Back] takes you back to the previous page.

• Clicking [Cancel] takes you back to the Trigger page without saving changes.

Note

• The camera works only with an SMTP (Simple Mail Transfer Protocol) server. It does not work with mail servers like "Hotmail browser.

• The subject name by E-mail transfer uses only 24 h format. The file name is "image.jpg". E.g. "image:20050101093020500". The underlined numbers mean "9h30min20s500ms on January 1, 2005". The letter "s" is inserted after the day when referring to a daylight saving time zone.

" that use a web

Page 67

Setting Description

Operating Instructions

SMTP Server IP Address or Host

Name

• If you set a server IP address, set 4 numbers (0—255) and 3 periods, such as "192.168.0.253". Note that "0.0.0.0" and "255.255.255.255" are not available. Or set a host name (1—255 characters).

Por t No. • Enter a number (1—65535). Usually set to 25.

Reply E-mail Address

Destination Email Address

• Set the sender's E-mail address. We recommend you to set the administrator's E-mail address.

• Set the destination E-mail address (up to 3).

1—3

Subject

• Enter a subject with ASCII characters (see page 131) or characters from other languages (0—44 characters for a 1-byte character and 0—22 characters for a 2-byte character).

Tex t

• Enter text with ASCII characters (see page 131) or characters from other languages (0—63 characters for a 1-byte character and 0—31 characters for a 2-byte character). Note that [end-of-line] key is not available.

[For assistance, please call: 1-800-272-7033] 67

Page 68

Operating Instructions

Setting Description

How to authenticate

You can select the authentication method: [No authentication], [POP before SMTP authentication] and [SMTP authentication].

POP server authentication may be required by your ISP. In that case, set POP before SMTP authentication.

• No authentication: No authentication when sending an e-

mail.

• POP before SMTP authentication: Some SMTP servers

that send e-mails do not have an authentication feature. Therefore, the camera uses the authentication of a POP server that receives e-mails, before sending e-mails.

– POP3 Server

IP Address or Host Name

If you set a server IP address, set 4 numbers (0—255) and 3 periods, such as

"192.168.0.253". Note that "0.0.0.0" and

"255.255.255.255" are not available. Or set a host name (1—255 characters).

– Port No.: Enter a number (1—65535). Usually set

to 110.

– Login ID*2: If your ISP requires a login ID to log in to

a POP3 server, set it (1—63 characters).

– Password*2: If your ISP requires a password to log in

to a POP3 server, set it (0—63 characters).

• SMTP authentication: Users are authenticated by user

name and password on the SMTP server. Your ISP must support the SMTP authentication. Only the LOGIN and PLAIN authentication mechanisms are supported.

– Login ID*2: If your ISP requires a login ID to log in to

an SMTP server, set it (1—63 characters).

– Password*2: If your ISP requires a password to log in

to an SMTP server, set it (0—63 characters).

Note that [Space], ["], ['], [&], [<] and [>] are not available.

Note that ["] is not available.

Page 69

8. Confirm the settings, and click [Save].

• The new settings are saved.

• When finished, "Success!" is displayed.

9. Click [Go to Trigger page].

• The Trigger page is displayed.

Note

• If you are buffering images to the internal memory, the following operations also delete all buffered images.

– Turning off the camera. – Saving the Date and Time page. – Restarting, updating firmware or resetting the camera to factory

default.

Operating Instructions

[For assistance, please call: 1-800-272-7033] 69

Page 70

Operating Instructions

4.3 Buffering or Transferring Images by Motion Detection Signal

The Trigger page allows you to enable image buffer/transfer by E-mail or FTP.

Note

• The level of motion detection depends on resolution, image quality, and the object being viewed. Check the level by performing motion detection recording. (See page 83)

• Enabling Motion Detection delays the frame rate of the camera.

• A change to light or wind conditions may detect motions accidentally.

• Motion Detection may not work in dark areas.

• Objects moving fast may not be detected.

1. Click [Trigger] on the Setup page.

2. Click a No. to enable buffer/transfer.

3. Check [Enable Image Buffer/Transfer], select [Motion Detection] for the trigger,

and click [Next>].

Page 71

Operating Instructions

Note

• Click [Delete Buffered Images] to delete images already buffered.

• Click [Save] to save the settings. The buffered images will be deleted.

• Clicking [Cancel] takes you back to the Trigger page without saving changes.

Setting Description

Enable Image Buffer/Transfer

Trigger • Selecting [Timer] enables the camera to buffer/transfer

• Check the box to enable the Trigger setting. Uncheck the box to disable it.

images during the specified date and time by timer.

• Selecting [Motion Detection] enables the camera to buffer/ transfer images when the motion is detected during the specified date and time.

4. Set the time, and click [Next>].

Note

The timer works by an internal clock. Set the date and time before using timer buffer/transfer (see page

• Clicking [<Back] takes you back to the previous page.

• Clicking [Cancel] takes you back to the Trigger page without saving changes.

Setting Description

Day of the week • Check the box to enable the day. Uncheck the box to

48).

disable it.

Active Time of Trigger

• To set a trigger time, check the time option and set a time period. Check [Always] if you are not specifying a time period.

[For assistance, please call: 1-800-272-7033] 71

Page 72

Operating Instructions

5. Set the image settings, and click [Next>].

• Clicking [<Back] takes you back to the previous page.

• Clicking [Cancel] takes you back to the Trigger page without saving changes.

Setting Description

Image Resolution

Image Quality • Select the image quality.

• Select an image resolution (640 × 480, 320 × 240 (default) or 160 × 120 pixels) for the buffer/transfer.

[Favor Clarity] optimizes for good quality. [Standard] offers standard quality. (Default) [Favor Motion] optimizes for enhanced motion. [Mobile Phone] is for a transfer to a cell phone.

Note

640 × 480 pixels cannot be set for a transfer to a cell phone.

Page 73

Operating Instructions

6. Set the image buffer frequency and the Motion deactivation time, and click

[Next>].

Note

Due to the network environment, object and the number of simultaneous accesses, the camera may not record the number of images that you set. In this case, set the image buffer frequency longer.

• Clicking [<Back] takes you back to the previous page.

• Clicking [Cancel] takes you back to the Trigger page without saving changes.

Setting Description

Enable Pretrigger Image Buffer

Enable Posttrigger Image Buffer

• Check the box to enable the setting. The camera buffers or transfers the image right before the motion detection signal is detected.

• Set an interval, number of images to buffer and total number (see page may not match the total number due to memory capacity, image resolution, image quality or what object you view.

• Check the box to enable the setting. The camera buffers or transfers the image right after the motion detection signal is detected.

• Set an interval, number of images to buffer and total number (see page may not match the total number due to memory capacity, image resolution, image quality or what object you view.

[For assistance, please call: 1-800-272-7033] 73

132). The number of buffered images

Page 74

Operating Instructions

Setting Description

Motion deactivation time

• Set the length of time during which the Motion Detection

cannot be triggered after saving images temporarily or transmitting them. This function is recommended to prevent sending too many E-mails to a cell phone.

• After detecting motions, the camera does not detect

motions during motion deactivation time, so some images may not be captured.

Note

The internal memory cannot buffer images during motion deactivation time. Because of this, images taken before detection are not saved in internal memory, and so cannot be received. Depending on the settings for image buffer/ transfer, even if it is set to, for example, take "1 image per second, and store 10 images, before detection", because the images are not stored in internal memory, if the Motion Detection detects something directly after the end of motion deactivation time, the images may not be saved. Ten seconds after the end of motion deactivation time, images can be received as specified in the settings (see

82).

page

Page 75

Operating Instructions

7. Select the transfer method, and click [Next>].

• Clicking [<Back] takes you back to the previous page.

• Clicking [Cancel] takes you back to the Trigger page without saving changes.

Note

If you transfer images by E-mail or FTP, confirm that the default gateway and DNS server addresses are assigned correctly (see page

Setting Description

31).

No Transfer, No Memory Overwrite

No Transfer, Memory Overwrite

FTP • The camera transfers the image to an FTP server (see

E-mail • The camera transfers the image by E-mail (see page 78).

• If the internal memory is full, the camera stops buffering.

• If the internal memory is full, the camera deletes the old images, and continues to buffer the image.

page 76).

[For assistance, please call: 1-800-272-7033] 75

Page 76

Operating Instructions

When you set [FTP] for Transfer Method

Select [FTP], and click [Next>]. The following page is displayed.

• Clicking [<Back] takes you back to the previous page.

• Clicking [Cancel] takes you back to the Trigger page without saving changes.

Page 77

Setting Description

Operating Instructions

Server IP Address or Host Name

• If you set a server IP address, set 4 numbers (0—255) and 3 periods, such as "192.168.0.253". Note that "0.0.0.0" and

"255.255.255.255" are not available. Or set a host name (1— 255 characters).

Por t No. • Enter a number (1—65535). Usually set to 21.

• If your ISP requires a login ID, set it (0—63 characters).

Password*2• If your ISP requires a password, set it (0—63 characters).

Time] and the image buffer frequency value is set within 1 minute, the camera logs in to the server only once. This can reduce transfer time.

Upload File

Name

• Set a file name on the FTP server to receive the transferred files. Enter 1—234 characters. Entering "\" creates directories for a file. (E.g. NetworkCamera\image.jpg)

Overwrite Setting

(E.g. image20050101093020500.jpg) The underlined numbers mean "9h30min20s500ms on January 1, 2005". The letter "s" is inserted after the day when referring to a daylight saving time zone.

Data Tr an s fe r

• Select [Passive Mode] normally. If the transfer does not work, select [Active Mode] and check the operation.

Method

Note that [Space], ["], ['], [&], [<] and [>] are not available.

Note that ["] is not available.

[For assistance, please call: 1-800-272-7033] 77

Page 78

Operating Instructions

When you set [E-mail] for Transfer Method

Select [E-mail], and click [Next>]. The following page is displayed.

• Clicking [<Back] takes you back to the previous page.

• Clicking [Cancel] takes you back to the Trigger page without saving changes.

Page 79

Operating Instructions

Note

• The camera works only with an SMTP (Simple Mail Transfer Protocol) server. It does not work with mail servers like "Hotmail" that use a web browser.

Setting Description

SMTP Server IP Address or Host

Name

Por t No. • Enter a number (1—65535). Usually set to 25.

Reply E-mail Address

Destination E-

• Set the sender's E-mail address. We recommend you to set the administrator's E-mail address.

• Set the destination E-mail address (up to 3).

mail Address*2 1—3

Subject

• Enter a subject with ASCII characters (see page 131) or characters from other languages (0—44 characters for a 1byte character and 0—22 characters for a 2-byte character).

Tex t*2 • Enter text with ASCII characters (see page 131) or

characters from other languages (0—63 characters for a 1byte character and 0—31 characters for a 2-byte character). Note that [end-of-line] key is not available.

[For assistance, please call: 1-800-272-7033] 79

Page 80

Operating Instructions

Setting Description

How to authenticate

You can select the authentication method: [No authentication], [POP before SMTP authentication] and [SMTP authentication].

POP server authentication may be required by your ISP. In that case, set POP before SMTP authentication.

• No authentication: No authentication when sending an e-

mail.

• POP before SMTP authentication: Some SMTP servers

that send e-mails do not have an authentication feature. Therefore, the camera uses the authentication of a POP server that receives e-mails, before sending e-mails.

– POP3 Server

IP Address or Host Name

If you set a server IP address, set 4 numbers (0—255) and 3 periods, such as

"192.168.0.253". Note that "0.0.0.0" and

"255.255.255.255" are not available. Or set a host name (0—255 characters).

– Port No.: Enter a number (1—65535). Usually set

to 110.

– Login ID*2: If your ISP requires a login ID to log in to

a POP3 server, set it (1—63 characters).

– Password*2: If your ISP requires a password to log in

to a POP3 server, set it (0—63 characters).

• SMTP authentication: Users are authenticated by user

name and password on the SMTP server. Your ISP must support the SMTP authentication. Only the LOGIN and PLAIN authentication mechanisms are supported.

– Login ID*2: If your ISP requires a login ID to log in to

an SMTP server, set it (1—63 characters).

– Password*2: If your ISP requires a password to log in

to an SMTP server, set it (0—63 characters).

Note that [Space], ["], ['], [&], [<] and [>] are not available.

Note that ["] is not available.

Page 81

Operating Instructions

8. After you confirm the settings and click [Next>], set E-mail notification and click

[Next>].

• If you select [Enable], the E-mail Notification When Triggered page is displayed. Enter the settings referring to page

Setting Description

Disable • The camera does not send an E-mail notification when

buffering or transferring images.

Enable • The camera sends an E-mail notification (up to 3

destinations) when buffering or transferring images.

78 — page 80.

9. Click [Save] after confirming the settings.

• The new settings are saved.

• When finished, "Success!" is displayed.

[For assistance, please call: 1-800-272-7033] 81

Page 82

Operating Instructions

10. Click [Go to Trigger page].

• The Trigger page is displayed. Note

• If you set a short interval when transferring to a cell phone, many E-mails

will be sent, which may lead to a large phone bill. Therefore, we recommend you to set a long interval. 1 image per minute frequency is recommended.

• Motion Detection transfer stops operating until after the camera finishes

all transfers. For example, if the camera transfers 3 images per minute and 6 images in total by setting 1 minute for motion deactivation time, the sensor will follow the pattern below.

120 seconds

1 minute

1st 2nd 3rd 4th 5th 6th

Detectable Undetectable

Undetectable

Motion

deactivation time

A Motion Detection signal is detected.

• If you are buffering images to the internal memory, the following

operations also delete all buffered images. – Turning off the camera. – Saving the Date and Time page. – Restarting, updating firmware or resetting the camera to factory

default.

Detectable

Page 83

Operating Instructions

4.4 Setting the Motion Detection

The Motion Detection page allows you to adjust the sensitivity of Motion Detection. Threshold: If the threshold is set low, this function detects nearly all movements. Sensitivity: If you set sensitivity high, the amplitude of the motion detection bar gets

jumpy.

1. Click [Motion Detection] on the Setup page.

2. Click the Motion Detection bar in Threshold to set the threshold level.

3. Click the Motion Detection bar in Sensitivity to set the sensitivity level.

4. Click [Save] to save the settings.

• Clicking [Cancel] cancels your settings without saving changes.

5. Click [Go to Motion Detection page].

• The Motion Detection page is displayed.

Setting Description

Threshold • Adjusts the threshold for Motion Detection. As the value is

set lower, the sensor will detect motions of smaller changes.

Sensitivity • Adjusts the sensitivity for Motion Detection. As the value is

set higher, the amplitude of the Motion Detection bar will become greater.

Preview

Display the current threshold and detection level.

• The threshold is the line between the green and red bar.

• The detection level is the line between the dark red and light red color.

Note

The Threshold and Sensitivity settings are enabled after saving, and reflected in preview.

[For assistance, please call: 1-800-272-7033] 83

Page 84

Operating Instructions

Threshold

Note

No responsibility will be taken by our company with respect to consequences resulting from the use of the Motion Detection feature. The Motion Detection feature is not suitable and not recommended for uses that require a high reliability constantly such as surveillance, etc.

What is the threshold?

The threshold is the minimum value for the camera to detect motions on the image during the motion detection buffering. Setting the threshold lower allows subtler changes to be detected. Setting the threshold higher allows only bigger changes that might occupy half the image to be detected.

Page 85

Operating Instructions

What is the sensitivity?

The sensitivity is the level of brightness detected as motion by the camera. A high sensitivity setting enables the camera to detect slight brightness changes. Lower the sensitivity to make the camera detect only big brightness changes.

Threshold setting is displayed.

The detection level exceeds the threshold when motions are detected.

Note

Lowering the threshold and increasing sensitivity enable the camera to easily detect slight movements on parts of the image.

Note

• Motion Detection is activated by changes in the outline of objects and brightness changes. This feature is designed to alleviate false detections due to overall brightness changes caused by sunlight. But in some cases, the camera may falsely detect rapid brightness changes by artificial light such as fluorescent light. In other cases, the motion detection function on the Network Camera Recorder may detect objects and brightness changes. The way to detect motion differs between the camera and the Network Camera Recorder. Additionally, if the object's color is similar to the color of the background, motion can be hard to detect.

• The detection level depends on the object, resolution, or image quality. Confirm the condition on the Preview window following the procedure above.

[For assistance, please call: 1-800-272-7033] 85

Page 86

Operating Instructions

4.5 Setting Sensor Log Notification

A sensor log sent once a day at a specified time can be checked. To enable Sensor Log, set Motion Detection for Trigger Setting and check [Enable].

1. Click [Sensor Log] on the Setup page.

When enabling the image/buffer transfer setting and selecting Motion Detection in the Trigger page, the Sensor log window is displayed.

2. Set each parameter.

Note

• Click [Save] to save the settings.

• Clicking [Cancel] cancels your settings without saving changes.

• Clicking [Save] deletes new-arrival sensor logs.

Page 87

Setting Description

Operating Instructions

A setup of

• Sensor log operation can be set here.

operation

Time • Set the day of the week and time to send sensor logs via

E-mail.

SMTP Server IP Address or Host

Name

Por t No. • Enter a number (1—65535). Usually set to 25.

Reply E-mail Address

Destination E-

• Set the sender's E-mail address. We recommend you to set the administrator's E-mail address.

• Set the destination E-mail address (up to 3).

mail Address 1-

Subject

• Enter a subject with ASCII characters (see page 131) or characters from other languages (0—44 characters for a 1byte character and 0—22 characters for a 2-byte character).

[For assistance, please call: 1-800-272-7033] 87

Page 88

Operating Instructions

Setting Description

How to authenticate

You can select the authentication method: [No authentication], [POP before SMTP authentication] and [SMTP authentication].

POP server authentication may be required by your ISP. In that case, set POP before SMTP authentication.

• No authentication: No authentication when sending an e-

mail.

• POP before SMTP authentication: Some SMTP servers

that send e-mails do not have an authentication feature. Therefore, the camera uses the authentication of a POP server that receives e-mails, before sending e-mails.

– POP3 Server

IP Address or Host Name

If you set a server IP address, set 4 numbers (0—255) and 3 periods, such as

"192.168.0.253". Note that "0.0.0.0" and

"255.255.255.255" are not available. Or set a host name (0—255 characters).

– Port No.: Enter a number (1—65535). Usually set

to 110.

– Login ID*2: If your ISP requires a login ID to log in to

a POP3 server, set it (1—63 characters).

– Password*2: If your ISP requires a password to log in

to a POP3 server, set it (0—63 characters).

• SMTP authentication: Users are authenticated by user

name and password on the SMTP server. Your ISP must support the SMTP authentication. Only the LOGIN and PLAIN authentication mechanisms are supported.

– Login ID*2: If your ISP requires a login ID to log in to

an SMTP server, set it (1—63 characters).

– Password*2: If your ISP requires a password to log in

to an SMTP server, set it (0—63 characters).

Note that [Space], ["], ['], [&], [<] and [>] are not available.

Note that ["] is not available.

Page 89

Operating Instructions

5 Using Other Features

5.1 Changing Initial Settings on the Single Camera page or the Multi-Camera page

The Image Display page allows you to change the initial settings (display settings when a user accesses the camera) for the Single Camera, Multi-Camera, Limit Continuous Motion JPEG, Language and Banner Display.

1. Click [Image Display] on the Setup page.

2. Set each parameter.

• Clicking [Cancel] cancels your settings without saving changes.

[For assistance, please call: 1-800-272-7033] 89

Page 90

Operating Instructions

Setting Description

Image Resolution • Select the image resolution.

640 × 480 pixels (Only for the Single Camera page) 320 × 240 pixels (default) 160 × 120 pixels (Only for the Multi-Camera page)

Image Quality • Select the image quality.

[Favor Clarity] optimizes for good quality. [Standard] offers standard quality. (default) [Favor Motion] optimizes for enhanced motion.

Refresh Interval • Select a refresh interval.

(Motion, 3 s, 5 s, 10 s, 30 s, and 60 s)

Limit Continuous Motion JPEG

• Limit time of

Continuous

• Set the time to change the video (Motion JPEG) to still images. (10 seconds—Unlimited)

Motion JPEG

•Refresh Interval

• Set a refresh interval after the image is changed to still images. (3-second interval—60-second interval)

Language • Select the initial language from English, Japanese,

French, German, Italian, Spanish, Simplified Chinese, Russian or Korean. The selected language is displayed as the initial language on the Top, Single Camera, Multi-Camera and Buffered Image pages. If you select English, Japanese, French or Simplified Chinese, all pages can be changed. But if you select another language, the Setup, Maintenance and Support pages are displayed in English.

Page 91

Operating Instructions

Setting Description

Banner Display When checked to [Enable], the setting will be enabled.

When unchecked, the setting will be disabled.

Note

• When the Banner Display is enabled, the camera accesses the Image URL every time the Single Camera page is displayed. The intermittent and continuous switching of the Single page burdens the PC that stores the image linked with the URL.

• If the image URL linked with an image stored in a PC that requires an authentication is set, the authentication window will be displayed when displaying the Single page.

• Banner user • All users : The banner can be displayed for all users.

Administrator only : The banner can be displayed for

the administrator.

General user only : The banner can be displayed for

the general user.

• Image URL

• Link URL

• Enter the image URL you want to display as a banner. When [Enable] is checked, enter the image URL. (1— 127 characters)

• Enter the target URL you want to display when clicking the banner. (0—127 characters)

Note that [Space], ["], ['], [&], [<], and [>] are not available.

3. Click [Save] when finished.

• The new settings are saved.

• When finished, "Success!" is displayed.

4. Click [Go to Image Display page].

• The Image Display page is displayed.

[For assistance, please call: 1-800-272-7033] 91

Page 92

Operating Instructions

5.2 Configuring Multiple Cameras

The Multi-Camera Setup page allows you to configure camera IP addresses and camera names to view multiple images on the Multi-Camera page. These configurations are required to use the Multi-Camera page. Up to 12 cameras can be configured. The Selfcamera is registered at No. 1 by default.

1. Click [Multi-Camera] on the Setup page.

2. Click Add.

Note

• If you click the camera number, the modification page is displayed. Camera settings can be modified or deleted here.

• If you configured multiple cameras, you can change the camera number. Select the number, and click [Move].

3. Set each parameter.

• Clicking [Cancel] cancels your settings without saving changes.

• By clicking [Clicking this link, enters this camera's settings.], the settings of the Selfcamera are entered automatically. "--" is displayed for the Port No, and the model no. is displayed for the Camera Name.

Page 93

Setting Description

Display • Check this box to enable the camera.

Operating Instructions

IP Address*1 or Host Name

• Set an IP address or host name to enable the camera.

Por t No. • Set a port number (1—65535).

Camera Name*3• This camera name is displayed only on the Multi-Camera

page.

Set 4 numbers (0—255) and 3 periods, such as "192.168.0.253". Note that "0.0.0.0" and "255.255.255.255" are not available.

Enter ASCII characters for the host name (see page 131). Note that [Space], ["], ['], [#], [&], [%], [=], [+], [?], [<] and [>] are not available.

Enter 1—255 characters.

You can enter ASCII characters (see page 131) or characters from other languages (1—15 characters for a 1-byte character and 1—7 characters for a 2-byte character). Note that [Space], ["], ['], [#], [&], [%], [=], [+], [?], [:], [<], and [>] are not available.

Note

• If your camera will only be accessed on your local network, use each camera's local IP address and port number.

• If you intend to access your camera from the Internet, you must use each camera's host name (global IP address) and the port number.

4. Click [Save] when finished.

• The new settings are saved.

• The Multi-Camera Setup page is displayed.

[For assistance, please call: 1-800-272-7033] 93

Page 94

Operating Instructions

5.3 Specifying Operation Time

The Operation Time page allows you to limit the time that the camera is in use. The camera image turns to a gray screen outside operation time.

Note

• Your privacy may be compromised if the time period is set incorrectly.

Confirm the time period after the setup.

• If you access the camera as an administrator, you can view the image

outside the time period.

1. Click [Operation Time] on the Setup page.

2. Click a No. to set the operation time.

Note

If No. 1—7 are disabled, the camera can always be operated.

3. Check [Enable], set the time, and click [Save]

• Clicking [Cancel] takes you back to the previous page without saving

changes.

Page 95

Operating Instructions

Setting Description

Enable • Check the box to enable the setting. Uncheck the box to

disable it.

Day of the week • Check the box to enable the day. Uncheck the box to

disable it.

Operation Time • To set an operation time, check the time option and set a

time period. Check the [Always] option if you are not specifying a time period.

4. Click [Save] when finished.

• The new settings are saved.

• The Operation Time page is displayed.

About Operation Time

In the operation time settings, the enabled settings take priority over the disabled settings. Therefore, if Monday or Tuesday is disabled in a setting but enabled in other settings, the camera can be operated on both Monday and Tuesday.

[For assistance, please call: 1-800-272-7033] 95

Page 96

Operating Instructions

5.4 Changing the Indicator Display

The Indicator Control page allows you to select an operation for the indicator. There are three options.

• Turn indicator on when camera is on.

• Turn indicator on during camera access.

• Never turn indicator on.

1. Click [Indicator Control] on the Setup page.

2. Select an option.

Setting Description

Turn indicator on when camera is on.

Turn indicator on during camera access.

Never turn indicator on.

• Clicking [Cancel] cancels your settings without saving changes.

• The indicator always turns on or blinks. See page 3 and page 4 of Troubleshooting on the CD-ROM.

• The indicator turns green when the camera is being accessed.

• The indicator always turns off.

Note

• See page 4 for the Indicator Display table.

• Selecting [Never turn indicator on] keeps indicator always off.

3. Click [Save] when finished.

• The new settings are saved.

• When finished, "Success!" is displayed.

4. Click [Go to Indicator Control page].

• The Indicator Control page is displayed.

Page 97

Operating Instructions

6 Camera Maintenance

6.1 Maintenance page

(1)

(2)

(3)

(4)

(5)

(6)

(7)

(8)

(9)

Maintenance

(1) Status Displays the camera settings and status (see page 98).

(2) [For BL-C20A]

Wireless Status

(3) Session Status Displays information on access to the camera (see page

(4) Sensor Log Displays sensor logs (see page 99).

(5) Restart Restarts the camera (see page 99).

(6) Update Firmware Updates the camera firmware (see page 100).

(7) Save Settings Creates a configuration file (see page 103).

(8) Load Settings Loads settings from a configuration file (see page 104).

(9) Reset to Factory

Default

Displays wireless information (see page 98).

98).

Resets the camera to its default settings (see page 105).

[For assistance, please call: 1-800-272-7033] 97

Page 98

Operating Instructions

6.1.1 Confirming the Status

The Status page allows you to check the status of the camera. The status information provides support for troubleshooting.

Clicking [Status] displays the following page.

Note

See the Panasonic Network Camera support website at http:// panasonic.co.jp/pcc/products/en/netwkcam/ for details about status

information.

6.1.2 [For BL-C20A] Confirming the Wireless Status

The Wireless Status page allows you to check the status of the wireless connection. The wireless status information provides support for troubleshooting regarding wireless connection.

Clicking [Wireless Status] displays the following page.

6.1.3 Confirming Session Status

Displays the information of clients connected to the camera. Clicking [Session Status] displays the following page.

Page 99

Operating Instructions

6.1.4 Confirming Sensor Logs

Displays up to 50 Sensor Logs in chronological order. Old logs will be overwritten by new ones.

1. Click [Sensor Log] on the Maintenance page.

2. Sensor Logs are displayed.

Note

If the camera is restarted, all sensor logs are deleted.

Item Description

New Sensor Logs • Displays the number of new sensor logs.

Date • Displays the date and time when the Motion Detection is

activated.

Sensor Type • Displays the Trigger Setting (Motion Detection) on the

Trigger page.

6.1.5 Restarting the Camera

It is possible to restart the camera by disconnecting the AC adaptor from the outlet and reconnecting it again. The camera can also be restarted on the Restart page.

Note

When the camera is restarted, the buffered images and sensor logs will be deleted.

1. Click [Restart] on the Maintenance page.

2. Click [Restart].

• Restarting takes about 1 minute for BL-C1A or about 90 seconds for BLC20A. The Top page is displayed when finished.

[For assistance, please call: 1-800-272-7033] 99

Page 100

Operating Instructions

6.1.6 Updating the Camera Firmware

The Update Firmware page allows you to update the camera's firmware. If new firmware is available, install it into the camera.

Note

• Do not turn off the power during a firmware update.

• All buffered images and sensor logs on the internal memory will be

deleted after the firmware update.

• The firmware version is displayed on the Top page and the Status page.

1. Download the new firmware from the Panasonic Network Camera support

website at http://panasonic.co.jp/pcc/products/en/netwkcam/, and save it on your PC.

2. Click [Update Firmware] on the Maintenance page.

3. Click [Update Firmware].

• The procedure can take up to 7 minutes for BL-C1A or 8 minutes for BL-

C20A.

• The camera restarts. Restart operation takes up to 1 minute for BL-C1A

or 90 seconds for BL-C20A.

100

Panasonic BL-C1A, BL-C20A User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Main Features

Camera Feature Locations

Table of Contents

1 Camera Monitoring

1.1 Accessing the Camera

1.2 Viewing the Single Camera page

1.3 Viewing the Multi-Camera page

1.4 Viewing the Buffered Image page

1.5 Viewing Still Images on Your Cell Phone

2 Using the Camera's Basic Features

2.1 Setup Page of the Camera

2.2 Connecting the Camera to Your Network

2.3 [For BL-C20A] Using Wireless LAN

2.5 Registering with the DynamicDNS service

2.6 Setting the Date and Time

2.7 Changing Camera Settings

3 Registering Users

3.1 Changing the Authentication Setting and Administrator User Name and Password

3.2 Logging in to the Camera

3.3 Creating, Modifying or Deleting General Users

4 Buffering or Transferring Images

4.1 Procedures of Buffering or Transferring Images

4.2 Buffering or Transferring Images by Timer

4.3 Buffering or Transferring Images by Motion Detection Signal

4.4 Setting the Motion Detection

4.5 Setting Sensor Log Notification

5 Using Other Features

5.1 Changing Initial Settings on the Single Camera page or the Multi-Camera page

5.2 Configuring Multiple Cameras

5.3 Specifying Operation Time

5.4 Changing the Indicator Display

6 Camera Maintenance

6.1 Maintenance page
