Panasonic camera systems for a wide range of locations
Panasonic camera systems for a wide range of locations
Panasonic's extensive lineup enables configuration of the
You can configure peripheral components around a high image quality 3CCD convertible camera to
achieve the ideal system for any application.
High resolution, high image quality
Original key benefits such as the 12-bit A/D converter enable sophisticated image processing.
Flexible system configuration
3CCD Convertible Cameras
2/3-inch
AW-E860
16:9/4:3 Switchable Wide Image
Shooting Camera
• 2/3” 3CCD high image quality
• Switchable 16:9/4:3 aspect ratios
• Horizontal resolution: 850 lines
• Signal to noise ratio: 65 dB (NTSC)/
63 dB (PAL) (DNR on)
• High sensitivity: 2 000 lx, F11
• Minimum illumination: 0.4 lx, (F1.7, Night Eye H)
• Wide dynamic range: 600 %
• Compact size, light weight and
low power consumption
Bayonet Mount
AW-E750
High Sensitivity, Wide Dynamic
Range Camera
• 2/3” 3CCD high image quality
• Horizontal resolution: 850 lines
• Signal to noise ratio: 67 dB (NTSC)/
65 dB (PAL) (DNR on)
• High sensitivity: 2 000 lx, F14
• Minimum illumination: 0.005 lx, 0.00005 lx
(2-second CCD charge accumulation)
• Wide dynamic range: 600 %
• Compact size, light weight and
low power consumption
Panasonic's extensive lineup lets you create a system boasting
Broad selection of peripherals
Enables optimum system configuration
Panasonic's cameras offer high quality images by advanced
1/2-inch
Bayonet Mount
AW-E655
Camera Equipped with
Motor-driven Optical Filter
• 1/2” 3CCD high sensitivity
• Horizontal resolution: 850 lines
• Signal to noise ratio: 67 dB (NTSC)/
65 dB (PAL) (DNR on)
• High sensitivity: 2 000 lx, F14
• Minimum illumination: 0.005 lx, 0.00005 lx
(2-second CCD charge accumulation)
• Motor-driven optical filter
(Normal, 1/16ND, 1/64ND, IR through)
The AW-E655's optical filter rotates to facilitate
its use as an infrared camera capable of shooting
completely dark scenes from a distance.
MIC
77 mm 18 mm
84 mm 84 mm
Power supply
Power consumption
Dimensions
(W x H x D)
Weight
2/3" Lenses
12 mm 170 mm 10 mm
10 mm
DC12 V
Approx. 15.4 W
84 mm x 95 mm x 192 mm
(3-5/16 " x 3-3/4 " x 7-9/16 ")
Approx. 1.15 kg (2.5 lbs)
for AW-E860/E750
Power supply
Power consumption
Dimensions
(W x H x D)
Weight
77 mm 18 mm
12 mm
10 mm
DC12 V
Approx. 12.6 W
84 mm x 95 mm x 192 mm
(3-5/16 " x 3-3/4 " x 7-9/16 ")
Approx. 1.1 kg (2.4 lbs)
Convertible Camera AW-
170 mm 10 mm
Power supply
Power consumption
Dimensions
(W x H x D)
Weight
1/2" Lenses
96 mm 18 mm
12 mm 10 mm160 mm84 mm
DC12 V
Approx. 12 W
84 mm x 114 mm x 182 mm
(3-5/16 " x 4-1/2 " x 7-3/16 ")
Approx. 1.2 kg (2.6 lbs)
for AW-E655/E650
AW-LZ17MD9A AW-LZ17ST9A AW-LZ16MD73
• 17x MD zoom lens
• Focal length: 9 mm-153 mm (F1.9-2.6)
2
• 17x studio zoom lens
• Focal length: 9 mm-153 mm (F1.9-2.6)
• 16x MD zoom lens
• Focal length: 7.3 mm-117 mm (F1.9-2.3)
Convertible Camera
optimum system for your needs.
Panasonic's exceptional reliability throughout.
for a wide range of applications including program production.
Digital Signal Processor (DSP) with clean Digital Noise Reduction (DNR) and 12 vector matrix masking.
AW-E650
High Sensitivity, High Image
Quality Camera
• 1/2” 3CCD high image quality
• Horizontal resolution: 850 lines
• Signal to noise ratio: 67 dB (NTSC)/
65 dB (PAL) (DNR on)
• High sensitivity: 2 000 lx, F14
• Minimum illumination: 0.005 lx, 0.00005 lx
(2-second CCD charge accumulation)
• Compact size, light weight and
low power consumption
Power supply
Power consumption
Dimensions
(W x H x D)
Weight
77 mm
10 mm
12 mm84 mm
DC12 V
Approx. 11.8 W
84 mm x 77 mm x177 mm
(3-5/16 " x 3-1/32 " x 7 ")
Approx. 0.92 kg (2.02 lbs)
Convertible Camera AW-
155 mm 10 mm
1/3-inch
C-Mount
AW-E350
Cost Effective C-Mount
Lens Camera
• 1/3" 3CCD C-mount lens camera
• Horizontal resolution: 850 lines
• Signal to noise ratio: 66 dB (NTSC)/
63 dB (PAL) (DNR on)
• High sensitivity: 2 000 lx, F9.5
• Minimum illumination: 0.015 lx, 0.00015 lx
(2-second CCD charge accumulation)
• Compact size, light weight and
low power consumption
FOCUS
LOCK
Power supply
Power consumption
Dimensions
(W x H x D)
Weight
1/3" Lenses
77 mm10 mm
1 mm84 mm
DC12 V
Approx. 11.3 W
84 mm x 77 mm x 156 mm
(3-5/16 " x 3-1/32 " x 6-1/8 ")
Approx. 0.8 kg (1.8 lbs)
Convertible Camera AW-
145 mm 10 mm
for AW-E350
Feature Cards
SDI Card
AW-PB504
Digital connecting card for video equipment with
SDI input jack
• Output: Serial digital interface
(SMPTE259M [4:2:2 SDI])
• Zoom/focus of the MD lens can be
controlled by contact closure type
pan-tilt head control or a controller
without a pan-tilt head.
Lens control is not servo type control.
*
Studio Card
AW-PB305A
Studio camera system card
• Output: RGB, Y/Pr/Pb, Y/C, VBS
• 4-inch EVF (Zebra, safety zone,
and center marker are included),
and intercom input and output,
and tally output compatible
• EVF interface bracket is included
SDI Studio Card
AW-PB506A
Studio and SDI Cards are
integrated into one.
• SDI Output: SMPTE259M
compatible
• View finder connector is mounted
• Intercom jack and intercom
audio volume mounted on the
EVF interface bracket
• EVF interface bracket is included
Lens Control kit
AW-LK30
• For MD (Motor Drive) Lenses
• Cable Length: 190 cm
AW-LZ17ST66 AW-LZ16MD55
• 17x studio zoom lens
• Focal length: 6.6 mm-114 mm (F1.5-1.9)
• 16x MD zoom lens
• Focal length:
5.5 mm-88 mm (F1.4-1.8)
AW-LZ16ST55
• 16x studio zoom lens
• Focal length:
5.5 mm-88 mm (F1.4-1.8)
WV-LK36
• For Studio Zoom Lens
AW-LZ17ST9A
AW-LZ17ST66
WV-LK35
• For Canon Zoom Lens
AW-LK50
• For Studio Zoom Lens
AW-LZ16ST55
3
Pan-tilt Heads
Multiple types of pan-tilt heads are available
for professional camera applications both indoors and outdoors.
Indoor
High Performance Pan-tilt Head
AW-PH400
A high performance, high speed, quiet pan-tilt head
• Pan range: 400 ° Tilt range: 300 °
• Maximum pan/tilt speed: 90 ° /sec (variable speed)
• Stop accuracy (
• Noise: Under NC30 (at 30 ° /sec)
• Maximum load: 8 kg (17.6 lbs)
• 10 tracing memories (Maximum time: 600 seconds)
• RS-232C controllable (Through AW-RP400)
• Tally lights are available
+
30 seconds) (0.008 ° )
-
• Maximum control distance: 500 m (1 640 ft.)
from AW-RP400 (Maximum 1 000 m (3 280 ft.)
using protocol converter AW-IF400)
• Last position can be stored.
• Diagonal motion is possible.
• Optional camera rolling unit (AW-RL400) is available
• Teleprompter output
• Both broadcast and industrial motor driven lenses are acceptable.
• Power Supply (standard accessory) can be installed in pan-tilt head.
With Camera
Rolling Unit
Camera Rolling Unit
AW-RL400
• Power is supplied from AW-PH400.
• Convertible cameras are mountable
• Controlled by AW-RP400.
Power supply
Power consumption
Maximum load
Rotation range
Maximum speed
Weight
Dimensions(W x H x D)
Indoor Pan-tilt Head
AW-PH405
A compact pan-tilt head for heavy load
• High pan-tilt speed: 45 ° /sec
• Quiet motion: Noise level under NC35 (at 30 ° /sec)
• Stop accuracy (
• Maximum load: 15 kg (33.1 lbs) (using with a camera,
a lens and a teleprompter)
• Pan range: 300 ° Tilt range: 300 °
• 50 preset positions and 10 tracing memories
(Maximum time: 300 sec) are available when using
the pan-tilt head controller AW-RP655.*
• Up to five camera systems can be controlled using
Panasonic controllers (AW-RP655/RP555/RP400**)
+
3 minutes) (0.05 ° )
-
• Maximum control distance:
1 500 m (4 920 ft.)...AW-RP400 + AW-IF400 (optional protocol converter)
1 000 m (3 280 ft.)...AW-RP655/RP555
• A removable tally light is available on the pan-tilt head.
• RS-232C controllable (through Panasonic controllers)
• Professional motor drive lenses and broadcast ENG lenses*** can be
connected.
You can't use tracing memories if you use the AW-RP400 in combination
*
with the AW-IF400.
Use together with the AW-IF400 if you use the AW-RP400.
**
Use an optional cable if you use a broadcast ENG lens.
***
Indoor Pan-tilt Head
AW-PH360
A compact pan-tilt head with a wide pan-tilt range
• Pan angle: 300 ° Tilt angle: 190 °
• High performance: Quiet (Under NC30)
Pan speed (30 ° /sec) / Tilt speed (25 ° /sec)
• Stop accuracy (
• Smooth starts and stops with soft landing function
+
3 minutes) (0.05 ° )
-
Power Supply
AW-PS300A
• 50 preset memories
• Maximum load: 4 kg (8.8 lbs)
• Maximum control distance 500 m (1 640 ft.) from AW-RP400*
1 000 m (3 280 ft.) from AW-RP655/RP555
• RS-232C interface
AW-PH360 requires Power Supply AW-PS300A.
*
Power supply
Dimensions(W x H x D)
Weight
DC24 V
Approx. 24 W
4 kg (8.8 lbs)
+
380 ° (
190 ° )
-
60 ° /s
Approx. 3.9 kg (8.8 lbs)
205 mm x 198 mm x 260 mm (8-1/16 " x 7-13/16 " x 10-1/4 ")
With AK-HC1500 and
AK-LZ20M85
AC120 V/4.9 A, AC220 V to 240 V*
210 mm x 51 mm x 275 mm (8-1/4 " x 2 " x 10-13/16 ")
Approx. 2.2 kg (4.8 lbs)
The values vary depending on the region.
*
Outdoor
4
Power Supply
Outdoor Pan-tilt Head
AW-PH650
Waterproof design for stable shooting despite the rain
• Pan angle: 320 ° (
• High performance: Quiet (Under NC40)
Pan speed (20 ° /sec) Tilt speed (20 ° /sec)
• In addition to zooming, panning and tilting functions,
heater, wiper and defroster functions for the
housing can also be controlled by the controller.
• 50 preset memories
• Maximum load: 10 kg (22 lbs)
• Maximum control distance: 1 000 m (3 280 ft.)
• Camera housing, power supply and cables are
included with the AW-PH650.
+
160 ° ) Tilt angle: +50 ° -90 °
-
• Accessories: power cable (approx. 30 m (98 ft.), control cable
(approx. 10 m (32.8 ft.), camera cable (approx. 0.4m (1.312 ft.)
for C-CAM/AK-HC910/HC1500)
Housing
Dimensions(W x H x D)
Weight
Power Supply
Dimensions(W x H x D)
Weight
246 mm x 314 mm x 685 mm (9-11/16 " x 12-3/8 " x 26-15/16 ")
Approx. 18 kg (39.7 lbs)
200 mm x 131 mm x 280 mm (7-7/8 " x 5-3/16 " x 11-1/16 ")
Approx. 4.2 kg (9.3 lbs)
Control Panels
Pan-tilt systems for multiple cameras ready
for a wide range of applications.
Multi-function Controller
High performance multi-function controller with
AW-RP655
(Rear view)
full camera control function
• Controls maximum five cameras and five pan-tilt heads without hub unit.
• Full camera control by LCD menu
• Control speed can be adjusted by the angle of the operation lever and
high speed and low speed mode can be switched.
• 50 pre-set memories per camera
• Ergonomically designed joystick controller
• 10 tracing memories (Maximum time: 300 sec)
• Maximum control distance from controller to pan-tilt head: 1 000 m (3 280 ft.)
(AW-PH360,AW-PH650) This controller can control an AW-PH400 by using a
protocol converter (AW-IF400).
• The motion direction of the operation lever can be reversed.
• Two additional controllers can be connected.
• This controller can be placed on a desk or mounted in a rack.
• Power Supply AW-PS505A is required.
Power supply
Power consumption
Dimensions(W x H x D)
Weight
Accessories
DC12 V
Approx. 9.0 W
420 mm x 52 mm x 220 mm (16-1/2 " x 2-1/16 " x 8-11/16 ")
Approx. 3.5 kg (7.7 lbs)
Rack mounting adapters (5U) x 2 Mounting screws (M4 x 8 mm) x 4
Compact Size Controller
AW-RP555
Pan-tilt Controller
AW-RP400
Joystick controller can be changed
for seesaw controller.
(Standard accessory)
Seesaw controller
(Rear view)
(Rear view)
Compact controller with
full camera control function
• Controls up to five cameras and five pan-tilt heads.
• Full camera control by camera menu
• Speed of controls can be adjusted by the angle of the operation lever.
• 10 pre-set memories per camera
• Maximum control distance from pan-tilt head to controller:
1 000 m (3 280 ft.) (AW-PH360,AW-PH650)
• With a protocol converter (AW-IF400), this controller can control the AW-PH400.
• The motion direction of the operation lever can be reversed or changed.
• This controller can be placed on a desk or mounted in a rack.
(The position of input and output connectors can be changed by 90 degrees)
• Power Supply AW-PS505A is required.
Power supply
Power consumption
Dimensions(W x H x D)
Weight
Accessories
DC12 V
Approx. 9.0 W
210 mm x 58 mm x 177 mm (8-1/4 " x 2-5/16 " x 7 ")
1.4 kg (3.08 lbs)
Rack mounting adapters (5U) x 2 Mounting screws (M4 x 8 mm) x 4
High performance controller for
professional and broadcast use
• Changeable zoom/focus controller (joystick/seesaw)
• Joystick with camera roll control
• 50 preset positions
• 5 pan-tilt heads control
• Zoom/Focus/Pan/Tilt speed control
• Tally/Intercom function
• 10 minutes tracing memory (60 seconds x 10 positions)*
• RS232C interface
• Maximum control distance:500 m (1 640 ft.)**
• Cross control by two controllers
• Camera control inputs (AW-CB400)
• +DC12 V operation (Power Supply AW-PS505A is required.)
This function does not work for AW-PH405/PH650.
*
Maximum 1 000 m (3 280 ft.) by using the Protocol Converter AW-IF400.
**
Power supply
Power consumption
Weight
Dimensions(W x H x D)
Accessories
DC12 V
Approx. 13 W
Approx. 3.8 kg (8.4 lbs)
320 mm x 85 mm x 266 mm (12-5/8 " x 3-3/8 " x 10-1/2 ")
Zoom switch x 1, Plug (D-SUB 15pin) for tally/INCOM system x 1 set,
Rack-mounting adapters x 2, Mounting screws (M4 x 8 mm) x 4
Availability of the tracing
memory function
AW-RP655
AW-RP555
AW-RP400
AW-PH400 AW-PH405 AW-PH360 AW-PH650
•
-
•
•
-
-
•
-
•
*
•
-
-
When you use it with AW-IF400,
*
activating the extended distance
transmission function is required.
5
Camera Controller/Switcher
Remote Operation Panel
AW-CB400
(Rear view)
Remote Control Unit (RCU)
AW-RC600
(Rear view)
Remote control panel enabling full control of
up to five cameras
• Controls five cameras
• Full camera control
• +DC12 V operation*
• Tally/Intercom function**
Power is supplied from AW-RP400.
*
Power supply AW-PS505A is required for controlling cameras directly
(Maximum control distance: 1 000m (3 280 ft.)
Intercom function is not available if the AW-CB400 is connected directly to the camera.
**
Power supply
Power consumption
Weight
Dimensions(W x H x D)
Accessories
DC12 V
Approx. 3.8 W
Approx. 1.4 kg (3.08 lbs)
100 mm x 85 mm x 266 mm (4" x 3-3/8" x 10-7/16")
Pan-tilt controller connection cable (10 m (32.8 ft.))
Basic camera controls on the front panel and
full camera control by camera menu
• Composite, Y/C and component (Y/Pb/Pr, R/G/B) outputs
• By using RCU cable (AW-CA50A26) and extension cables (WV-CA26T26,
WV-CA26U/15/30/100), this unit can control a camera at a maximum distance
of approx. 100 m (328 ft.) (with viewfinder AW-VF64)
• Camera power can be supplied by this RCU.
• Equipped with tally/intercom, AUX (for line view) inputs, and contact-closure
type pan-tilt head control input terminal (15-pin D-sub)
Power supply
Power consumption
Dimensions(W x H x D)
Weight
Accessory
AC120 V/AC220 V to 240 V*
Approx. 67 W
420 mm x 88 mm x 250 mm (16-1/2 " x 3-7/16 " x 9-13/16 ")
Approx. 5.6 kg (13.2 lbs)
Power cable x 2, Rack angle handles x 2, Rack-mount angles x 2,
Rack angle handle fixing screws x 4, Mounting screws x 4
The values vary depending on the region.
*
Cable Compensation Unit
AW-RC400
Compact Live Switcher
Compact Live Switcher
AW-SW350
(Rear view)
(Rear view)
• Five channels compensation
• Composite, Y/C, Y/Pb/Pr, R/G/B (Composite, Y/C, Y/Pb/Pr, R/G/B video
signals can be compensated by maximum 500 m (1 640 ft.))
• +DC12 V operation (Power Supply AW-PS505A is required.)
Power supply
Power consumption
Weight
Dimensions(W x H x D)
Accessories
DC12 V
Approx. 9 W
Approx. 3.7 kg (8.2 lbs)
420 mm x 88 mm x 250 mm (16-1/2 " x 3-7/16 " x 9-13/16 ")
Rack-mount angles x 2, Mounting screws (M4 x 8 mm) x 4
High quality five input live switcher for multi use
• Five inputs (composite and Y/C) in compact body (half rack size)
• Three program outputs and one preview output
• Selectable bus switching system
• 10 bit, 5-channel frame synchronizer/genlock system are switchable
• Frame capture, soft wipe and linear key
• +DC12 V operation
• Tally and intercom function
• Power Supply AW-PS505A is required.
Power supply
Power consumption
Dimensions(W x H x D)
Weight
Accessories
DC12 V
Approx. 16 W
210 mm x 86 mm x 176 mm (8-1/4 " x 3-3/8 " x 6-15/16 ")
Approx. 2.2 kg (4.8 lbs)
Tally/Intercom connector x 5, Rack mounting clamp x 2,
Connection bracket, Screw kit, Image transfer setup CD
6
Cable/Other Peripheral
Cables
Name Number Connection apparatus Length Note
Cable joint adapter
Studio cable (26P-26P)
Lens extension cable
RCU cable
RGB cable
RS-232C pan-tilt cable
RS-232C camera control cable
Camera control cable
Pan-tilt cable kit
Pan-tilt cable
Lens cable for Fujinon ENG lens
Lens cable for Canon digital lens
Lens cable for Canon analog lens
Pan-tilt control extension cable
Other Peripherals
WV-CA26T26
WV-CA26U15 / 30 / 100
AW-CA12T12A
AW-CA50A26
AW-CA50T6
AW-CA28T9
AW-CA50T9
AW-CA50T8
AW-CAK4H1
AW-CA15H29
AW-CA4FLZ
AW-CA4DLZ
AW-CA4ALZ
AW-CA24T24
AW-E750 etc.
AW-E750 etc.
AW-E750 etc.
AW-E750 etc.
AW-E750 etc.
AW-PH360
AW-E750 etc.
AW-E750 etc.
AK-HC1500
AK-HC1500
Fujinon ENG (RD) lens
Canon ENG digital lens
Canon ENG analog lens
AW-PH650
WV-CA26U15 etc.
AW-RC600
AW-RC600
Moniotor, VTR etc.
PC.
PC.
AW-CB400
AW-PH400/PH405
AW-PH400/PH405
AW-PH400/PH405
AW-PH400/PH405
AW-PH400/PH405
AW-RP655/RP555/RP400
15 m, 30 m, 100 m
0.15 m
15 m
5 m
5 m
10 m
10 m
0.7 m/3 m
0.7 m
0.8 m
0.8 m
0.8 m
20 m
Connects AW-CA50A26 to longer lengths
12P-12P
BNCx5 + S terminal
A pan-tilt head is controlled by a PC.
A camera is controlled by a PC.
Pan-tilt cable: 0.7 m, Control cable: 3 m
for AK-HC1500/AW-E860
for AK-HC1500/AW-E860
for AK-HC1500/AW-E860
Protocol Converter
Protocol Converter
AW-IF400
Public Telephone Line
Connecting Adapter/
RS232C Distribution Adapter
AW-DU600
Enables remote control of camera and pan-tilt head
• High performance pan-tilt head (AW-PH400) can be controlled by controllers
(AW-RP555, AW-RP655) by using this protocol converter (AW-IF400).
(Max.control distance: 1 500 m (4 920 ft.)
• Outdoor pan-tilt head (AW-PH650) can be controlled by a high performance
controller (AW-RP400) by using this protocol converter (AW-IF400).
(Max.control distance: 1 500 m (4 920 ft.)
• By using protocol converter AW-IF400, control distance between
AW-PH400 & AW-RP400 can be extended up to 1 000 m (3 280 ft.).
• Power Supply AW-PS505A is required.
(Rear view)
Power supply
Power consumption
Dimensions(W x H x D)
Weight
DC12 V
Approx. 1.5 W
145 mm x 30 mm x 85 mm (5-11/16 " x 1-3/16 " x 3-3/8 ")
Approx. 0.4 kg (0.88 lbs)
Power Supply
AW-PS505A
The unit can supply power to Convertible cameras,
Live switchers, the AW-RP655, AW-RP555, AW-DU600
and other units.
4" B/W Viewfinder
AW-VF64
• Power Supply AW-PS505A is required.
• Using a public telephone line enables remote control
of camera and pan-tilt head through the AW-RP555/
RP655 series models and a PC.
• Up to five sets of camera and pan-tilt heads can be
controlled with the distribution function.
• Directly controllable pan-tilt and zoom/focus.
The product is not available in some areas.
*
A modem is required.
**
Power supply
Power consumption
Dimensions
(W x H x D)
Weight
Accessories
AC120 V/AC220 V to 240 V*
Approx.76 W
132 mm x 51 mm x 275 mm
(5-3/16 " x 2 " x 10-13/16 ")
Approx. 1.6 kg (3.5 lbs)
DC cable with 4-pin Canon connector (for AW-RP400.etc.):
Approx. 2 m (6.5 ft.)
DC cable with ø5.5 plug (for AW-RC400.etc.):
Approx. 3 m (9.8 ft.)
DC cable with ø6.5 plug (for convertible cameras):
Approx. 3 m (9.8 ft.)
The value vary depending on the region.
*
Aspect ratio: 4:3 only
*
Power supply
Power consumption
Dimensions
(W x H x D)
Weight
Accessories
DC12 V (supplied from
camera head)
Approx. 9 W
128 mm x 158 mm x
330 mm (5-1/16 " x
6-1/4 " x 12-15/16 ")
Approx. 1.6 kg (3.5 lbs)
Mounting base x 1,
Mounting screw x 2
7
System Example
Indoor Event Shooting
Quiet, accurate and
high speed pan-tilt motion
Key points
• Compact size camera and pan-tilt head
• Quiet, accurate and high speed pan-tilt head
for event shooting
• Pre-set memory function
• Multi-function control
• Maximum control distance: 1 000 m (3 280 ft.)
Parliament/Hall
Many cameras and quiet pan/tilt-heads can be controlled from several control rooms.
Convertible cameras (AW-E750/E655/E650) can
shoot in dark settings such as parliament,
halls or theaters thanks to high sensitivity
(Minimum illumination: 0.005 lx).
By using the Multi-function Controller AW-RP655 and
five cameras, a total of 250 pre-set memories
(50 presets per camera) can memorize 250 seats
in a conference hall.
System example
Indoor
Pan-tilt Head
AW-PH360
No.1 Camera
16 x Zoom Lens
AW-LZ16MD73
No.5 Camera
Camera head
AW-E650
*
Accessory Cable
for AW-PH360
*
Power Supply
AW-PS300A
Cable
Compensation
Unit
AW-RC400
Power Supply
AW-PS505A
Monitor
Control Room Control Room
Video Output x 5
G/L IN
***
** **
*** ***
Intercom
headset
Multi-Function Controller
AW-RP655
Monitor
Power Supply
AW-PS505A
Power Supply
AW-PS505A
Intercom
headset
Multi-Function Controller
AW-RP655
Local procurement
*
10 BASE-T Straight cable x 1
**
Accessory Cable for AW-PS505A (2 m)
***
Camera Head AW-E650
16 x Zoom Lens AW-LZ16MD73
Pan-tilt Head AW-PH360
Power Supply AW-PS300A
Multi-function Controller AW-RP655
Power Supply AW-PS505A
Cable Compensation Unit AW-RC400
••••••••••••••5
•••••••5
•••••••••••••5
•••••••••••5
•••••••••••3
••••2
••1
Address/Sports Relay
Compact size camera and pan-tilt head can be controlled in small event shooting spaces.
Quiet indoor pan-tilt system with no disturbing noise.
The pan-tilt head and camera are compact,
as well as extremely quiet.
The videographer does not need to move around
the hall, and is able to shoot without disturbing
the scene.
Ideal for wedding or religious ceremonies
where the atmosphere and mood are very important.
8
System example
Power Supply
AW-PS300A
*
Indoor
Pan-tilt Head
AW-PH360
16 x Zoom Lens
AW-LZ16MD73
No.1 Camera
No.3 Camera
Camera head
AW-E650
Accessory Cable
for AW-PH360
*
Power Supply
AW-PS505A
**
Co-axial Cable
x 3
Cable Compensation Unit
AW-RC400
No.1 Camera
Monitor
***
Video Signal
Compact Size Controller
AW-RP555
No.2 Camera
No.3 Camera
Monitor
Monitor
Power Supply
AW-PS505A
***
Program
Monitor
Power Supply
AW-PS505A
Live Switcher
AW-SW350
DVCPRO VTR
AJ-SD755
Control Room
Local procurement
*
Accessory Cable for AW-PS505A (3 m)
**
Accessory Cable for AW-PS505A (2 m)
***
Camera Head AW-E650
16 x Zoom Lens AW-LZ16MD73
Pan-tilt Head AW-PH360
Power Supply AW-PS300A
Multi-function Controller AW-RP555
Power Supply AW-PS505A
Cable Compensation Unit AW-RC400
Compact Live Switcher AW-SW350
DVCPRO VTR AJ-SD755
••••••••••••••3
•••••••3
•••••••••••••3
•••••••••••3
•••••••••••3
••••••••••••1
••••1
••1
••••1
Remote Studios
Content production at small,
cost effective studios
Key points
• Many cameras can be used in a small studio.
• SDI video system by SDI card (AW-PB504)
• One operator can control many cameras and
pan-tilt heads.
• Quiet pan-tilt motion for shooting in a quiet studio
Remote Studio
A single camera operator can control three cameras in a quiet studio.
One control panel controls three cameras and pan-tilt
heads in the studio. By using compact pan-tilt heads,
many cameras can be controlled in a small studio.
Using the compact live AW-SW350 switcher
also enables an operator to produce independently
creative images with wipes and other special effects.
System example
Power Supply
Indoor
Pan-tilt Head
AW-PH360
16 x Zoom Lens
AW-LZ16MD73
No.1 Camera
No.3 Camera
AW-PS300A
*
Accessory Cable
for AW-PH360
Camera head AW-E650
Microphone
*
Power Supply
AW-PS505A
***
Co-axial Cable
x 3
Cable Compensation Unit
AW-RC400
No.1 Camera
Monitor
Audio Mixer
**
Power Supply
AW-PS505A
Compact Size Controller
AW-RP555
No.2 Camera
No.3 Camera
Monitor
Monitor
Equalizer Audio Amplifier
**
Program
Monitor
Power Supply
AW-PS505A
Live Switcher
AW-SW350
Video Output
DVCPRO VTR
AJ-SD755
Speaker
Control Room
Video Output
Local procurement
*
Accessory Cable for AW-PS505A (3 m)
**
Accessory Cable for AW-PS505A (2 m)
***
Camera Head AW-E650
16 x Zoom Lens AW-LZ16MD73
Pan-tilt Head AW-PH360
Power Supply AW-PS300
Multi-function Controller AW-RP555
Power Supply AW-PS505A
Cable Compensation Unit AW-RC400
Compact Live Switcher AW-SW350
DVCPRO VTR AJ-SD755
••••••••••••••3
•••••••3
•••••••••••••3
••••••••••••3
•••••••••••3
••••••••••••1
••••1
••1
••••1
CATV Studio
High quality image SDI recording system for minimizing deterioration of video images.
When equipped with the AW-PB504 SDI card,
Panasonic convertible cameras can be easily
integrated into a SDI broadcast system to record
high quality video with little degradation.
Panasonic cameras are an ideal choice
for professional studio use.
System example
17 x Zoom Lens
AW-LZ17MD9A
Camera Head
AW-E860
Teleprompter
Indoor
Pan-tilt Head
AW-PH405
No.1 Camera
Teleprompter
No.2 Camera
Insert
SDI Card
*
Insert
SDI Card
*
SDI Card
AW-PB504
Sync Generator Video Distribution Amp
Control Room
Digital Switcher
SDI
SDI
**
***
For Cameras
VDA
For Digital Switcher
AJ-SD755
+
AJ-YA455P(SDI Input/Output Unit)
SDI
DVCPRO VTR
Cable Compensation Unit
AW-RC400
Monitor
Control Panel
AW-RP555
***
Power Supply
AW-PS505A
Output
SDI
SDI Monitor
Power Supply
AW-PS505A
Camera Connection Cable included with the AW-PH405.
*
Coaxial cable x 3, 10BASE-T Straight Cable x 1
**
Accessory Cable for AW-PS505A (3m)
***
Camera Head AW-E860
SDI Card AW-PB504
16 x Zoom Lens AW-LZ17MD9A
Pan-tilt Head AW-PH405
Multi-function Controller AW-RP555
Power Supply AW-PS505A
Cable Compensation Unit AW-RC400
SDI Input Unit for DVCPRO VTRAJ-YA455
DVCPRO VTR AJ-SD755
Teleprompter
••••••••••••••2
••••••••••••••••2
•••••••2
•••••••••••••2
••••2
•••••••••••3
••1
••1
•••••••••••••••••••••••2
••••••••••••1
9
System Example
Production systems
Studio systems can be
configured using
Key points
• 3CCD (2/3", 1/2" or 1/3") high quality camera
Resolution: 850 lines, S/N 67 dB (NTSC)/
optional studio cards.
65 dB (PAL)(DNR ON)
: 860 lines, S/N 65 dB (NTSC)/
63 dB (PAL)(DNR ON)
• Two types of studio card: Analog (Composite,
Component) output card/SDI output card
• Intercom, viewfinder, lens control kit and RCU
(remote control kit) can be used for studio system.
Production Studio
A convertible camera can be used as a production studio camera by inserting an SDI studio card.
System example
DVCPRO VTR
AJ-SD755
AJ-YA455P
(SDI Input Unit)
D1
Control Room
+
Output
SDI
SDI Monitor
No.1 Camera
VF Mounting Bracket
(included with the
AW-PB506A)
Camera Head
AW-E750
17 x Studio Zoom
Lens
AW-LZ17ST9A
4 " B/W Viewfinder
AW-VF64
Zoom/Focus
Control Kit
WV-LK36
Insert
SDI Card
RCU Cable
AW-CA50A26
SDI Studio Card
AW-PB506A
Remote Control Unit
AW-RC600
SDI
SDI
Digital Switcher
The 2/3" high quality camera AW-E860 or AW-E750
with the SDI studio card AW-PB506A
(with two SDI outputs) can be used as
high quality studio cameras in
production houses or community stations.
No.2 Camera
No.1 Camera
No.2 Camera
Monitor
Camera Head AW-E750
17 x Studio Zoom Lens AW-LZ17ST9A
Studio SDI Card AW-PB506A
4 " B/W Viewfinder AW-VF64
Lens Control Kit WV-LK36
Remote Control Unit AW-RC600
RCU Cable AW-CA50A26
DVCPRO VTR AJ-SD755
SDI Input Unit for DVCPRO VTR
••••••••••••••2
•••••••••2
••••••••••2
••••••••••••2
•••••••2
••••••••••••2
••••••••••••1
•••••••1
••2
College Studio
A simple, cost effective studio system can be configured by inserting a studio card.
A compact, easy to operate, low-cost system can be
set up by inserting a Studio card into the camera,
which is ideal for small size studios in schools,
companies, etc.
System example
4 " B/W Viewfinder
AW-VF64
Camera Head
AW-E350
16 x MD Lens
AW-LZ16MD55
VF Mounting
Bracket
(included with
the AW-PB305A)
Lens control kit
AW-LK30
Intercom
(Local
procurement)
RCU Cable
Remote Control Unit
AW-CA50A26
AW-RC600
No.1 Camera
IN
Studio Card
AW-PB305A
No.2
Camera
No.1 Camera
No.2 Camera
Monitor
G/L
G/L
Video Signal
Preview
Power Supply
AW-PS505A
Video Signal
*
Panasonic
Live Switcher
AW-SW350
DVCPRO VTR
AJ-SD755
Control Room
LIve Switcher AW-SW350
Intercom
(Local
procurement)
Accessory Cable for AW-PS505A (3 m)
*
Camera Head AW-E350
16 x MD Zoom Lens AW-LZ16MD55
Studio Card AW-PB305A
4 " B/W Viewfinder AW-VF64
Lens Control Kit AW-LK30
Remote Control Unit AW-RC600
RCU Cable AW-CA50A26
DVCPRO VTR AJ-SD755
Live Switcher AW-SW350
Power Supply AW-PS505A
••••••••••••••2
•••••••••••••2
••••••••••2
••••••••••••2
•••••••2
••••••••••••2
••••••••••••1
••••••••••••1
•••••••••••1
••••2
10
Multi-purpose systems
High quality images indoors and
out make them ideal for everything
from live sports coverage to use as
ceiling cameras.
High speed pan-tilt system
High speed and accurate camera operation can be achieved.
By using the high speed (90 ° /s) pan-tilt head
System example
Camera Head
AW-E860
17 x MD Zoom Lens
AW-LZ17MD9A
No.1 Camera
Indoor
Pan-tilt Head
AW-PH400
Camera Connection Cable
(included with the AW-PH400)
Cable Compensation Unit
AW-RC400
**
Intercom
(Local
procurement)
Monitor 1
Monitor 2
*
Monitor Selection Switch
(A control cable is included
with the AW-CB400.)
***
Co-axial Cable x 2 (Max.1 000 m)
*
10BASE-T Cable (Max.1 000 m)
**
Accessory Cable for AW-PS505A (3 m)
***
Accessory Cable for AW-PS505A (2 m)
****
Power Supply
AW-PS505A
For switcher/
monitor
Intercom
(Local procurement)
AW-PH400 and high quality controller AW-RP400,
high-level camera operation for sports relays or
music video production can be achieved.
No.5 Camera
Power Supply
AW-PS505A
****
Pan-tilt Controller
AW-RP400
Remote Operation
Panel
AW-CB400
Camera Head AW-E860
17 x MD Zoom Lens AW-LZ17MD9A
Pan-tilt Head AW-PH400
Remote Control Unit AW-RP400
Remote Operation Panel AW-CB400
Power Supply AW-PS505A
Cable Compensation Unit AW-RC400
Weather/traffic information camera
High quality images can be supplied in any weather conditions.
Weather/traffic camera system with a waterproof,
outdoor pan-tilt head.
The camera can be operated by remote control
via a PC connection to enable projection of
faraway situations on the monitor.
System example
Camera Connection Cable
Camera Housing
(included with the AW-PH650)
Outdoor Pan-tilt
Head
AW-PH650
Camera Head
AW-E650
16X MD Zoom Lens
AW-LZ16MD73
Inside of Camera Housing
(included with the AW-PH650)
Video Signal
Camera/Pan-tilt
Control
Note: Camera housing, power supply,
power cable, control cable and
camera connection cable are included
with the AW-PH650.
Cable Compensation Unit
AW-RC400
Control Panel
AW-RP555
Control Room
Accessory Cable for AW-PS505A (3 m)
*
Monitor
*
Power Supply
AW-PS505A
*
Power Supply
AW-PS505A
Camera Head AW-E650
16 x MD Zoom Lens AW-LZ16MD73
Outdoor Pan-tilt Head AW-PH650
Remote Control Unit AW-RP555
Power Supply AW-PS505A
Cable Compensation Unit AW-RC400
••••••••••••••5
••••5
•••••••••••••5
•••••••1
•••1
•••••••••••2
••1
••••••••••••••1
••••1
••••••1
•••••••1
•••••••••••2
••1
11
Product configuration diagram
Shooting section
Lens
Controller
Lens Control Kit
WV-LK36
Lens Viewfinder
4 " Electronic Viewfinder
AW-VF64
17x Motor Drive Zoom Lens
AW-LZ17MD9A
17x Studio Zoom Lens
AW-LZ17ST9A
Camera/
Card
Studio Card
AW-PB305A
Studio Card includes a
*
Viewfinder Mounting Bracket.
SDI Studio Card
AW-PB506A
Studio Card includes a
*
Viewfinder Mounting Bracket.
SDI Card
AW-PB504
Slot In
2/3 " 3CCD
Convertible Camera
AW-E860
(SDI)
Outdoor Pan-tilt Head
AW-PH650
Power Supply, control cables
*
and a camera housing
are included.
Indoor
Pan-tilt Head
AW-PH405
Indoor Pan-tilt Head
AW-PH360
Pan-tilt
Head
(Analog signal only)
Lens Control Kit
WV-LK35
Lens Control Kit
AW-LK50
16x Motor Drive Zoom Lens
AW-LZ16MD73
17x Studio Zoom Lens
AW-LZ17ST66
Canon ENG/Studio Zoom Lens
For 1/2 "&2.3 "Lens
Lens Extension
*
Cable AW-CA12T12A
is required.
16x Motor Drive Zoom Lens
AW-LZ16MD55
16x Studio Zoom Lens
AW-LZ16ST55
AW-E750
1/2 " 3CCD
Convertible Camera
AW-E655
AW-E650
1/3 " 3CCD
Convertible Camera
AW-E350
Power Supply AW-PS300A
*
is required.
Indoor Pan-tilt Head
AW-PH400
Camera Rolling Unit
AW-RL400
Power Supply is included.
*
(Composite,
Y/C, Component)
10 m (32.8 ft.)
10 m (32.8 ft.)
12
Lens Control Kit
AW-LK30
C-Mount Manual Lens
C-Mount Microscope
Power Supply AW-PS505A is
*
required for stand-alone operation.
(Composite)
10 m (32.8 ft.)
Control section
Control Unit Live Switcher
RCU Cable
AW-CA50A26 (15 m (49 ft.))
RCU Cable Joint Adapter
WV-CA26T26
Studio Extension Cable
WV-CA26U15 (15 m (49 ft.))
WV-CA26U30 (30 m (98 ft.))
WV-CA26U100 (100 m (328 ft.))
Video Cable
Coaxial Cable (Max. 500 m (1 640 ft.))
Studio System
**
Pan-tilt Control System
Max. 1 000 m (3 280 ft.)
Max. 1 000 m (3 280 ft.)
Max. 1 000 m (3 280 ft.)
Max. 500 m (1 640 ft.)
Max. 500 m (1 640 ft.) Max. 500 m (1 640 ft.)
AW-IF400
AW-IF400
Max. 500 m (1 640 ft.)
Remote Control Unit
AW-RC600
Cable Compensation Unit
AW-RC400
Power Supply AW-PS505A is required.
*
Compact Size Control Panel
AW-RP555
Power Supply
*
AW-PS505A
is required.
Multi-Function Control Panel
AW-RP655
Power Supply
*
AW-PS505A
is required.
Pan-tilt Control Panel
AW-RP400
Power Supply
*
AW-PS505A
is required.
(Composite, Y/C)
(Composite, Y/C,
Component)
(Composite, Y/C,
Component)
10 m (32.8 ft.)
Live Switcher
AW-SW350
Power Supply AW-PS505A is required.
*
Other Peripherals
Power Supply
AW-PS505A
Power cables are included.
*
Protocol Converter
AW-IF400
Max. 500 m (1 640 ft.) Max. 1 000 m (3 280 ft.)
Max. 500 m (1 640 ft.)
Max. 500 m (1 640 ft.)
RS-232C Control Cable
AW-CA28T9
AW-IF400
AW-IF400
Max. 500 m (1 640 ft.)
Dial-up Adapter
(Public Telephone Line Connecting Box/
RS232C Distribution Box)
AW-DU600
Power Supply
*
AW-PS505A
is required.
Modem
Use a factory-approved
*
modem.
(Telephone Line)
Modem
Use a factory-approved
*
modem.
RS232C Cable (For extension: RS-422 conversion)
RS-232C Camera Control Cable
AW-CA50T9 (D-Sub 9pin 10 m (32.8 ft.))
RS232C Cable (For extension: RS-422 conversion)
Camera Control System
Camera Control Cable
AW-CA50T8 (10 m (32.8 ft.))
(Composite, Y/C, Component)
10BASE-T Cable (Max. 1 000 m (3 280 ft.))
Remote Operation Panel
AW-CB400
Power Supply AW-PS505A
*
is required for connecting
cameras directly.
(Direct Control)
Compact Size Control Panel
AW-RP555
Power Supply AW-PS505A is required.
*
Multi-Function Control Panel
AW-RP655
Power Supply AW-PS505A is required.
*
Dial-up Adapter
Control
**
Dial-up Adapter
(Public Telephone Line Connecting
Box/RS232C Distribution Box)
AW-DU600
Power Supply
*
AW-PS505A
is required.
Personal Conputer
Remote Operation Panel
AW-CB400
Power Supply AW-PS505A
*
is required for connecting
cameras directly.
By turning on the compensation switch of pan-tilt head, it can be extended up to 1 000 m (3 280 ft.)
***
PC Control Cable
AW-CA50T9
Power Supply AW-PS505A is required.
*
RS232C Cable (For extension: RS-422 conversion)
RS232C Cable
10BASE-T cable
Control cable etc.
Video cable
The control cable is included in the AW-CB400.
***
13
HD camera system
Panasonic also makes it easy to switch from conventional
As the demand for HD production systems continues to grow,
Panasonic is there to support you.
Panasonic's HD models offer the flexibility for use with
conventional SD systems, while making you more familiar
with the HD production environment.
2/3-inch
Bayonet Mount
Multi-purpose HD Box Camera
AK-HC1500
2/3-inch Lens
AK-LZ20M85
• 20x Zoom Lens
• Focal length:
8.5 mm-170 mm (F1.8-2.7)
Multi-format Live Switcher
AV-HS400
Global multi-format HD/SD compatibility in a
compact unit designed for a wide range
of applications.
The camera is compatible with multiple formats at worldwide.
What's more, original Panasonic devices such as the 14-bit A/D converter,
newly developed DSP and 2/3-inch IT-3CCD assure exceptional image quality
and reliability. As well as being ideal for a wide range of applications,
this high cost performance HD camera helps assure an easy transition
from an SD system to an HD system.
* This camera can be mounted with Fujinon HD 2/3" bayonet mount lenses or
Canon HD 2/3" bayonet mount lenses.
117 mm
13.2 mm
160 mm 12 mm90 mm
For more details please consult a separate brochure.
HD/SD format compatible, compact live switcher
with a built-in multiviewer display function.
Multi-format HD/SD compatibility lets you meet changing needs as production
switches to HD worldwide. It also helps assure a trouble-free transition from
conventional SD operation to HD operation. Better still, it comes standardly
equipped with a wide range of effect functions and a multiviewer display function
allowing you to output up to 10 images on to a single monitor.
It flexibly responds to a variety of environments from live operation to full-scale
studio production.
Option Boards
SDI INPUTS
AV-HS04M1
• INPUTS:HD/SD-SDI x2
(BNC)(Built-in Up-converter)
ANALOG INPUTS
AV-HS04M2
• INPUTS:HD/SD Analog Component x2
(Y/Pb/Pr)(Built-in Up-converter)
DVI INPUTS
AV-HS04M3
• INPUTS:DVI-I x2(Built-in Scaler)
14
ANALOG OUTPUTS
AV-HS04M4
• OUTPUTS:Analog Component x2
(Y/Pb/Pr)
DVI/ANALOG OUTPUTS
AV-HS04M5
• OUTPUTS:DVI-I x1, Analog x1
408 mm
132 mm
420 mm
For more details please consult a separate brochure.
SD systems to an HD production environment.
System example
HD camera ideal for live sports coverage and other broadcast applications.
System example
Combining the AK-HC1500 HD Multi-Format Camera
with the high-speed, exceptionally quite AW-PH400
Pan-Tilt System lets you shoot and record
high-definition, broadcast-quality images.
And with the AV-HS400 Live Switcher,
you can use transitions and versatile titling effects
for results with incredible presence.
AK-HC1500 specifications
CCD
Image sensing method
Total number of pixels
Effective number of pixels
Optical prism
Optical filter
Lens mount
Output format
Sensitivity
Minimum Illumination
Gain
S/N
Smear
M.T.F.
Synchronize System
Input
Output
Input/output
Storage temperature
Operating temperature
Power supply
Power consumption
Dimensions(WxHxD)
Weight
2/3 " 1.0-megapixel IT-3CCD
GBR Image sensing method
1 370(H)x744(V)
1 280(H)x720(V)
F1.4 Prism
(ND) 100 %, 25 %, 6.3 %, 1.6 %
2/3" Bayonet type
1080: 60i/59.94i/50i/30psF/29.97psF/25psF/24psF/23.98psF
720: 60p/59.94p/50p
F10.0 at 2 000 lx, 3 200 K, white reflection rate 89.9 %
0.015 lx (F1.4 / 68 dB)
72 dB
54 dB
Less than -130 dB
45 % (27.5 MHz, 720 p / 60 p)
Internal and external synchronization (Tri-level SYNC/Black Burst)
GENLOCK: BNC x 1, Interface: Mini D-sub 15pin terminal
HD-SDI: BNC x 1
Lens aperture connector, lens zoom focus connector
-20 ˚C to 60 ˚C (-4 ˚F to 140 ˚F)
0 ˚C to 40 ˚C (32 ˚F to 104 ˚F)
DC12 V
Approx. 17 W
Approx. 90 mm x 117 mm x 160 mm (3-9/16 " x 4-5/8 " x 6-5/16 ")
Approx. 1.5 kg (3.3 lbs)
Multi format
HD Multi-purpose Camera
AK-HC1500
20x Zoom Lens
AK-LZ20M85
Pan-tilt Head
AW-PH400
A control cable (3 m) is included with the AW-CAK4H1.
Power Supply
AW-PS505A
AV-HS400 specifications
Video processing
Input
Output
WIPE/DVE
Transition
KEYER
PIP
Interface
Removable media
Operating temperature / Humidity
Power / Power consumption
Dimensions(W x H x D)
Weight
Features and specifications in this document are subject to change without notice due to continual improvements.
*
Pan-tilt Cable
AW-CAK4H1
Co-axial Cable(HD-SDI)
10BASE-T
Pan-tilt Control Panel
AW-RP400
Video format
Video processing
Video
Key
DSK
Reference
Video
Reference
Pattern
Transition method
Transition type
Key source
Key fill
Key mode
Transition method
Transition type
Serial (EDITOR)
Tally output
GPI
LAN
SD memory card slot
PC
Multi-format
Live Switcher
AV-HS400
Power Supply
AW-PS505A
Camera Head AK-HC1500
20x Zoom Lens AK-LZ20M85
Indoor Pan-tilt Head AW-PH400
Pan-tilt Control Unit AW-RP400
Camera Control Unit AK-HRP150
Camera Control Panel
AK-HRP150
SD (480/59.94i, 576/50i) HD (1080/59.94i, 1080/50i, 720/59.94p, 720/50p)
<Y:Cb:Cr>4:2:2 10 bit, <RGB>4:4:4 8 bit
<Standard>4 inputs, <Option>A maximum of 4 inputs
Assign one out of video inputs
Assign one out of video inputs
Black burst/TRI (loop through) x1
<Standard>4 outputs, <Option>A maximum of 4 outputs
Loop through x1 (Genlock), or Black burst x2 (internal synchronization)
WIPE x12, Squeeze x11, SLIDE x8, 3D DVE x12(3 directions)
FADER, AUTO
Cut, mix, wipe (including DVE), background and key can be selected.
BUS
BUS, MATTE
Linear key, Lum key, Chroma key (key only)
AUTO (PIP only)
MIX
Dsub9pin x1:RS-422 (GVG protocol compatible)
Dsub15pin x1, open collector output
ø 3.5 Stereo mini jack
10 Mbps x1 (Service purpose)
1 (for transferring still image files and providing an upgrade capability)
0 ˚C to +40 ˚C (32 ˚F to 104 ˚F ) /10 % to 90 % (no condensation)
AC 120 V / Approx. 98 W
420 mm (16-1/2") x 132 mm (5-3/16") x 408 mm (16-1/8") (*excluding protrusions)
Approx. 6.4 Kg (14.1 lbs): without options Approx. 7.2 Kg (15.9 lbs): with options
Power Supply AW-PS505A
Pan-tilt control cable AW-CAK4H1
Multi-format Live Switcher AV-HS400
Monitor
••••••••••••1
•••••••••1
•••••••1
••••••••1
••••••1
•••••••••••2
•••••1
•••1
15
Camera specifications (NTSC
<
PAL>)
AW-E860 AW-E750 AW-E655 AW-E650 AW-E350
Image elements
Total elements
Pixels
Effective elements
Imaging area (H x V)
Scanning system
Scanning frequency
Lens mount
Optical filter
Synchronize system
Standard illumination
Minimum illumination
Signal-to-noise ratio
Horizontal resolution
Registration
Image enhancer
White balance
Black balance
Color bar
Shutter speed
Gain
Iris
Video output
Power supply
Power consumption
Operating temperature
Weight
Dimensions (W x H x D)
The lens should be within 4.3 mm from the lens mount face. Otherwise, there is a risk of damaging the camera unit.
*
2-sec.CCD charge accumulation.
**
Approx.510 000 <595 728>
Approx.460 000 <538 200>
9.6 mm x 5.4 mm (2/3" 16:9)
(16:9/4:3 switchable)
2 000 lx, F11
0.4 lx (F1.7, Night Eye H)
65 dB (DNR on) <63 dB (DNR on)>
Manual: max. 42 dB (0 to 30 dB
in steps, Night Eye H/L)
Auto: max. 42 dB
(AGC 0 to 30 dB, Night Eye/H)
<Composite> 1.0 Vp-p/75 Ω (BNC,D-sub 50p), <Y/C> Y: 1.0 V p-p/75 Ω ; C: 0.286 Vp-p<0.3 Vp-p>/75 Ω (burst)(D-sub 50p),
<Y/Pr/Pb> Y: 1.0 Vp-p/75 Ω ; Pr,Pb: 0.7 Vp-p<0.525 Vp-p>/75 Ω (D-sub 50p), <RGB> G: 1.0 Vp-p/75 Ω ; RB: 0.7 Vp-p/75 Ω (D-sub 50p)
Approx. 15.4 W Approx. 12.6 W Approx. 12 W Approx. 11.8 W Approx. 11.3 W
Approx. 1.15 kg (2.5 lbs) Approx. 1.1 kg (2.4 lbs) Approx. 1.2 kg (2.6 lbs) Approx. 0.92 kg (2.02 lbs) Approx. 0.8 kg (1.8 lbs)
84 mm x 95 mm x 192 mm
(3-5/16 " x 3-3/4 " x 7-9/16 ")
Pan-tilt head specifications
2/3 " IT-3CCD
8.8 mm x 6.6 mm
(equivalent to 2/3 ")
2:1 interlaced NTSC system <2:1 interlaced PAL system>
Horizontal=15.734 kHz,Vertical=59.94 Hz <Horizontal=15.625 kHz, Vertical=50 Hz>
2/3 " Bayonet Mount 1/2 " Bayonet Mount 1/3 " C Mount *
1/16ND,1/64ND,Normal, IR Through
Internal/external synchronization
0.005 lx (F1.4) 0.00005 lx (F1.4) (2-sec. CCD accumulation)
67 dB (DNR on) <65 dB (DNR on)>
850 lines (high-band DTL ON, centre area)
0.05 % (entire screen, excluding effects of lens)
Horizontal/vertical
AWC A,AWC B(R/B gain,painting),AT W,3 200 K,5 600 K preset
Auto (R/B pedestal, painting function)
SMPTE color bar (setup 0/7.5IRE) <full>
OFF,1/100 <1/120>,1/250,1/500,1/1 000,1/2 000,1/4 000,1/10 000 Synchro-scan ELC
Manual: max. 72 dB (0 to 30 dB in steps, Night Eye/H, Digital Gain 0 to 30 dB in 6 dB steps)
84 mm x 95 mm x 192 mm
(3-5/16 " x 3-3/4 " x 7-9/16 ")
Auto: max. 42 dB (AGC 0 to 30 dB, Night Eye/H)
Auto (Manual by RCU control)
-10 °C to 45 °C (14 °F to 113 °F)
84 mm x 114 mm x 182 mm
(3-5/16 " x 4-1/2 " x 7-3/16 ")
Indoor pan-tilt head Outdoor pan-tilt head
1/2 " IT-3CCD 1/3 " IT-3CCD
Approx.410 000 <470 000>
Approx.380 000 <440 000>
6.4 mm x 4.8 mm (equivalent to 1/2 ")
2 000 lx, F14
DC 12 V
84 mm x 77 mm x 177 mm
(3-5/16 " x 3-1/32 " x 7 ")
4.8 mm x 3.6 mm
(equivalent to 1/3 ")
NoneNone
2 000 lx, F9.5
0.015 lx (F1.4)
0.00015 lx (F1.4) **
66 dB (DNR on) <63 dB (DNR on)>
84 mm x 77 mm x 156 mm
(3-5/16 " x 3-1/32 " x 6-1/8 ")
AW-PH400 AW-PH405 AW-PH360 AW-PH650
Pan-tilt range/speed
Repeatability
Noise level
Maximum load
Maximum control
distance
Power supply
Power consumption
Operating temperature
Dimensions(W x H x D)
Weight
The values vary depending on the region.
*
Features and specifications are subject to change without notice due to continual improvements.
*
Weight and dimensions shown are approximate.
*
Matsushita Electric Industrial Co., Ltd.
Panasonic System Solutions Company
Corporate Broadcast and Multimedia Business Unit
4-3-1 Tsunashima-Higashi,
Kohoku-ku, Yokohama City 223-8639, Japan
http://panasonic.biz/broad/
Pan: 400 °(90 °/s), Tilt: 300 °(90 °/s)
+
30 seconds (0.008 °)
-
Under NC30 (at 30 °/s)
8 kg (17.6 lbs)
1.5 km(AW-RP655/RP555 with AW-IF400),
1 km(AW-RP400 with AW-IF400),
500 m(AW-RP400)
AC120 V/AC220 V to 240 V *
Approx. 145 W
0 °C to 45 °C (32 °F to 113 °F)
315 mm x 534 mm x 188 mm
(12-3/8 " x 21 " x 7-3/8 ")
10.2 kg (22.5 lbs)
Pan: 300 °(45 °/s), Tilt: 300 °(45 °/s)
Under NC35 (at 30 °/s)
1.5 km(AW-RP400 with AW-IF400),
1 km(AW-RP655/RP555)
AC120 V/AC220 V to 240 V *
-5 °C to 45 °C (23 °F to 113 °F)
319 mm x 416 mm x 168 mm
(12-9/16 " x 16-3/8 " x 6-5/8 ")
+
3 minutes (0.05 °)
-
15 kg (33.1 lbs)
Approx. 120 W
10.0 kg (20.0 lbs)
Pan: 300 °(30 °/s), Tilt: 190 °(25 °/s)
+
3 minutes (0.05 °)
Under NC30
4 kg (8.8 lbs)
1 km(AW-RP655/RP555),
500 m(AW-RP400),
1km(AW-RP400 with AW-IF400)
DC12 V
1.3 A(pan-tilt head only)
-10 °C to 45 °C (14 °F to 113 °F)
130 mm x 244 mm x 192 mm
(5-1/8 " x 9-5/8 " x 7-9/16 ")
3.5 kg (7.7 lbs)
Pan: 320 °(20 °/s), Tilt: 145 °(20 °/s)
Less than
Less than NC40
10 kg (22 lbs)
1.5 km(AW-RP400 with AW-IF400),
1 km(AW-RP655/RP555)
AC120 V/AC220 V to 240 V * (Power supply)
Approx. 120 W
-20 °C to 45 °C (-4 °F to 113 °F)
Head: 237 mm x 511 mm x 213 mm
(9-5/16 " x 20-1/8 " x 8-3/8 ")
Head: 19 kg (41.9 lbs)
+
5 °
-
AW-JECCONSOL08
Printed in Japan
Loading...
