This product complies with the RoHS Directive (EU 2002/95/EC).
Transistors
2SC5950G
Silicon NPN epitaxial planar type
For general amplification
Complementary to 2SA2122G
Features
High forward current transfer ratio h
Smini typ package, allowing downsizing of the equipment and automatic
insertion through the tape packing
FE
Package
Code
SMini3-F2
Marking Symbol: 7M
Pin Name
Absolute Maximum Ratings Ta = 25°C
Parameter Symbol Rating Unit
Collector-base voltage (Emitter open) V
Collector-emitter voltage (Base open) V
Emitter-base voltage (Collector open) V
Collector current I
Peak collector current I
Collector power dissipation P
Junction temperature T
Storage temperature T
CBO
CEO
EBO
C
CP
C
j
-55 to +150 °C
stg
60 V
50 V
7 V
100 mA
200 mA
150 mW
150
°C
1: Base
2: Emitter
3: Collector
Electrical Characteristics Ta = 25°C±3°C
Parameter Symbol Conditions Min Typ Max Unit
Collector-base voltage (Emitter open) V
Collector-emitter voltage (Base open) V
Emitter-base voltage (Collector open) V
Collector-base cutoff current (Emitter open) I
Collector-emitter cutoff current (Base open) I
Forward current transfer ratio h
Collector-emitter saturation voltage V
CBOIC
CEOIC
EBOIE
CBO
CEO
FE
CE(sat)IC
Transition frequency f
Collector output capacitance
(Common base, input open circuited)
Note) Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
C
= 10 mA, IE = 0 60 V
= 2 mA, IB = 0 50 V
= 10 mA, IC = 0 7 V
VCB = 20 V, IE = 0 0.1
VCE = 10 V, IB = 0 100
VCE = 10 V, IC = 2 mA 160 460
= 100 mA, IB = 10 mA 0.1 0.3 V
VCB = 10 V, IE = -2 mA, f = 200 MHz 100 MHz
T
VCB = 10 V, IE = 0, f = 1 MHz 2.2 pF
ob
mA
mA
Publication date: June 2007 SJC00371AED 1
This product complies with the RoHS Directive (EU 2002/95/EC).
0 16040 12080
0
240
200
160
120
80
40
࿐ᐲ Ta (°C
)
ࠦࠢ࠲៊ᄬ P
C
(m
W
)
2SC5632_PC-T
a
0
4 8 12
0
20
40
2SC5950_ IC-V
CE
Collector current I
C
(m
A
)
Collector-emitter voltage VCE (V)
IB = 160 µA
20 µA
40 µA
60 µA
80 µA
100 µA
120 µA
140 µA
Ta = 25°C
0
0.4 0.8 1.2
0
40
80
2SC5950_ IC-V
BE
Collector current I
C
(m
A
)
Base-emitter voltage VBE (V)
Ta = 85°C
25°C
−25°C
V
CE
= 10 V
1 10 100 1 000
0.001
0.01
0.1
1
10
IC / IB = 5
Ta = 75°C
25°C
−25°C
ࠦࠢ࠲ࠛࡒ࠶࠲㑆㘻㔚 V
CE(sat)
(V)
ࠦࠢ࠲㔚ᵹ IC (mA)
2SC5632_V
CE(sat)-IC
0.1 1 10 100
0
300
250
200
150
100
50
VCE = 4 V
Ta = 75°C
25°C
−25°C
⋥ᵹ㔚ᵹჇ₸ h
FE
ࠦࠢ࠲㔚ᵹ IC (mA)
2SC5632_hFE-I
C
2SC5950G
PC Ta IC VCE IC V
V
IC hFE I
CE(sat)
C
BE
2 SJC00371AED
This product complies with the RoHS Directive (EU 2002/95/EC).
SMini3-F2 Unit: mm
2.00 ±0.20
+0.05
0.30
−0.02
0.425 ±0.050
3
12
(0.65)(0.65)
1.30
±0.10
(5°)
1.25 ±0.10
(0.89)
2.10 ±0.10
±0.10
0.90
(5°)
+0.05
0.13
−0.02
(0.49)
0 to 0.10
