2SA0885
Power Transistors
2SA0885 (2SA885)
Silicon PNP epitaxial planar type
For low-frequency power amplification
Complementary to 2SC1846
■ Features
•Output of 3 W can be obtained by a complementary pair with 2SC1846
•TO-126B package which requires no insulation plate for installation to the heat sink
■ Absolute Maximum Ratings Ta = 25°C
Parameter |
Symbol |
Rating |
Unit |
|
|
|
|
Collector-base voltage (Emitter open) |
VCBO |
−45 |
V |
Collector-emitter voltage (Base open) |
VCEO |
−35 |
V |
Emitter-base voltage (Collector open) |
VEBO |
−5 |
V |
Collector current |
IC |
−1 |
A |
|
|
|
|
Peak collector current |
ICP |
−1.5 |
A |
Collector power dissipation |
PC |
1.2 |
W |
|
|
|
|
|
|
5.0 * |
|
Junction temperature |
Tj |
150 |
°C |
|
|
|
|
Storage temperature |
Tstg |
−55 to +150 |
°C |
Note) *: With a 100 × 100 × 2 mm Al heat sink
|
|
|
|
Unit: mm |
8.0–0.1+0.5 |
|
|
3.2±0.2 |
|
φ 3.16±0.1 |
|
|
|
|
|
|
3.8±0.3 |
11.0±0.5 |
3.05±0.1 |
|
|
1.9±0.1 |
1.0 |
|
|
|
|
16.0± |
|
0.75±0.1 |
|
0.5±0.1 |
|
|
4.6±0.2 |
|
0.5±0.1 |
1.76±0.1 |
|
2.3±0.2 |
|
|
||
|
|
|
1: Emitter |
|
|
|
|
|
|
1 |
2 |
3 |
|
2: Collector |
|
3: Base |
|||
|
|
|
|
|
|
|
|
TO-126B-A1 Package |
■ Electrical Characteristics Ta = 25°C ± 3°C
Parameter |
Symbol |
Conditions |
Min |
Typ |
Max |
Unit |
|
|
|
|
|
|
|
Collector-base voltage (Emitter open) |
VCBO |
IC = −10 µA, IE = 0 |
−45 |
|
|
V |
Collector-emitter voltage (Base open) |
VCEO |
IC = −2 mA, IB = 0 |
−35 |
|
|
V |
Collector-base cutoff current (Emitter open) |
ICBO |
VCB = −20 V, IE = 0 |
|
|
− 0.1 |
µA |
Collector-emitter cutoff current (Base open) |
ICEO |
VCE = −20 V, IB = 0 |
|
|
−100 |
µA |
Emitter-base cutoff current (Collector open) |
IEBO |
VEB = −5 V, IC = 0 |
|
|
−10 |
µA |
Forward current transfer ratio |
* |
VCE = −10 V, IC = −500 mA |
85 |
|
340 |
|
hFE1 |
|
|||||
|
hFE2 |
VCE = −5 V, IC = −1 A |
50 |
|
|
|
Collector-emitter saturation voltage |
VCE(sat) |
IC = −500 mA, IB = −50 mA |
|
|
− 0.5 |
V |
Transition frequency |
fT |
VCE = −10 V, IE = 50 mA, f = 200 MHz |
|
200 |
|
MHz |
|
|
|
|
|
|
|
Collector output capacitance |
Cob |
VCB = −10 V, IE = 0, f = 1 MHz |
|
20 |
30 |
pF |
(Common base, input open circuited) |
|
|
|
|
|
|
|
|
|
|
|
|
|
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
2. *: Rank classification
Rank |
Q |
R |
S |
|
|
|
|
hFE1 |
85 to 170 |
120 to 240 |
170 to 340 |
Note) The part number in the parenthesis shows conventional part number.
Publication date: February 2003 |
SJD00002BED |
1 |
2SA0885 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
PC Ta |
|
|
|
|
|
|
IC VCE |
|
|
|
|
|
IC IB |
|
|
|
|||
|
6 |
|
(1)With a 100 |
× 100 × 2 mm |
|
−1.50 |
|
|
|
TC=25˚C |
|
–1.2 |
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
VCE=–10V |
|
|
|
|
||||||||
|
|
|
Al heat sink |
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
TC=25˚C |
|
|
|
|
|
||||
(W) |
|
|
(2)Without heat sink |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
5 |
|
|
|
−1.25 |
|
|
|
|
|
|
–1.0 |
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
–9mA |
IB=–10mA |
|
|
|
|
|
|
|
||||||
C |
|
|
|
|
|
|
(A) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
P |
|
|
|
|
|
|
|
|
|
|
–8mA |
|
|
(A) |
|
|
|
|
|
|
|
|
4 |
|
|
|
|
|
−1.00 |
|
–7mA |
|
|
–0.8 |
|
|
|
|
|
|
|||||
Collector power dissipation |
|
|
|
|
|
|
|
|
|
|
|
C |
|
|
|
|
|
|
||||
|
|
(1) |
|
|
|
C |
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
Collector current I |
|
|
|
|
|
|
|
Collector current I |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
–6mA |
|
|
|
|
|
|
|
|||
3 |
|
|
|
|
|
−0.75 |
|
|
|
|
|
–0.6 |
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
–5mA |
|
|
|
|
|
|
|
|||
2 |
|
|
|
|
|
−0.50 |
|
|
|
|
–4mA |
–0.4 |
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
–3mA |
|
|
|
|
|
|
|
|||
1 |
|
(2) |
|
|
|
−0.25 |
|
|
|
|
–2mA |
–0.2 |
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
–1mA |
|
|
|
|
|
|
|
|
|
0 |
|
|
|
|
|
|
|
0 |
−2 |
−4 |
−6 |
−8 |
−10 |
|
0 |
|
|
|
|
|
|
|
0 |
40 |
80 |
120 |
160 |
200 |
|
|
0 |
|
0 |
–2 |
–4 |
–6 |
–8 |
–10 |
–12 |
|||||
|
|
Ambient temperature Ta (°C) |
|
|
|
Collector-emitter voltage |
VCE (V) |
|
|
Base current IB (mA) |
|
|||||||||||
|
|
VCE(sat) IC |
|
|
|
|
|
VBE(sat) IC |
|
|
|
|
|
hFE IC |
|
|
||||||
(V) |
–10 |
|
|
|
IC/IB=10 |
|
|
–10 |
|
|
|
IC/IB=10 |
|
1 000 |
|
|
|
|
VCE=–10V |
|||
|
|
|
|
(V) |
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
TC=100˚C |
|
|
|
|||
CE(sat) |
|
|
|
|
|
|
BE(sat) |
|
|
|
|
|
|
FE |
|
|
25˚C |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
Collector-emitter saturation voltageV |
–1 |
|
|
|
|
|
Base-emitter saturation voltage V |
|
–1 |
|
TC=–25˚C |
|
|
Forward current transferratioh |
100 |
|
|
–25˚C |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
100˚C |
|
|
|
|
|
|
|
|
|
|||
|
|
TC=100˚C |
|
|
|
|
|
|
25˚C |
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
25˚C |
|
–25˚C |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
–0.1 |
|
|
|
|
|
–0.1 |
|
|
|
|
|
10 |
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
–0.01 |
|
|
|
|
|
–0.01 |
|
|
|
|
|
1 |
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
–0.01 |
|
–0.1 |
|
–1 |
|
|
|
–0.01 |
|
–0.1 |
|
–1 |
|
–0.01 |
|
|
–0.1 |
|
–1 |
|
|
|
|
Collector current |
IC (A) |
|
|
|
|
Collector current IC (A) |
|
|
Collector current |
IC (A) |
|
|||||||||
|
|
|
fT IE |
|
|
|
|
|
|
Cob VCB |
|
|
|
|
|
VCER RBE |
|
|||||
|
200 |
|
|
|
|
|
(pF) |
|
50 |
|
|
|
|
|
|
–100 |
|
|
|
|
IC=–10mA |
|
|
VCB=–10V |
|
|
|
|
|
|
|
|
|
IE=0 |
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
TC=25˚C |
|
|||||
|
f=200MHz |
|
|
|
|
ob |
|
|
|
|
|
f=1MHz |
(V) |
|
|
|
|
|
|
|
||
|
TC=25˚C |
|
|
|
|
|
|
|
|
|
TC=25˚C |
|
|
|
|
|
|
|
||||
(MHz) |
160 |
|
|
|
|
|
C |
|
40 |
|
|
|
|
|
CER |
–80 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
V |
|
|
|
|
|
|
|
||
T |
|
|
|
|
|
|
Collectoroutput capacitance (Commonbase, input opencircuited) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Transition frequency f |
120 |
|
|
|
|
|
30 |
|
|
|
|
|
|
–60 |
|
|
|
|
|
|
||
80 |
|
|
|
|
|
20 |
|
|
|
|
|
|
–40 |
|
|
|
|
|
|
|||
40 |
|
|
|
|
|
10 |
|
|
|
|
|
|
–20 |
|
|
|
|
|
|
|||
0 |
|
|
|
|
|
0 |
|
|
|
|
|
voltageemitterCollectorbetween(ResistorandE)B |
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
0 |
|
|
|
|
|
|
||
|
1 |
|
10 |
|
|
100 |
|
|
–1 |
|
|
–10 |
|
–100 |
|
0.1 |
|
1 |
|
10 |
|
100 |
|
|
Emitter current IE (mA) |
|
|
|
Collector-base voltage VCB (V) |
|
Base-emitter resistance |
RBE (kΩ) |
|||||||||||||
2 |
|
|
|
|
|
|
|
|
|
SJD00002BED |
|
|
|
|
|
|
|
|
|
|
