Page 1
Technical Description
Specification of KEY for DTCP-IP, CI Plus, DIMORA, HDCP2, Netflix, Widevine
General information:
1. NAND FLASH (IC8900) for spare parts has the seed of KEY for each.
2. The final KEY data will be generated by sLD8A IC (IC8000) when SELF CHECK was done and are stored in both
sLD8A IC (IC8000) and NAND FLASH (IC8900).
All KEYs are not generated for all models.
The necessary KEY are only generated and stored depend on the feature of models.
Replacement of ICs:
When sLD8A IC (IC8000) is replaced, NAND FLASH (IC8900) should be also replaced with new one the same time.
When NAND FLASH (IC8900) is replaced, sLD8A IC (IC8000) is not necessary to be replaced the same time.
After the replacement of IC, SELF CHECK should be done to generate the final KEY data.
How to SELF CHECK: While pressing [VOLUME ( - )] button on the main unit, press the MENU button on the remote
control for more than 3 seconds.
TV will be forced to the factory shipment setting after this SELF CHECK.
Model and Keys:
Keys
Model No.
TX-42AS500E Yes Yes Yes Yes Yes
DTCP-IP CI PLUS DIMORA HDCP2
Netflix
Widevine
Page 2
Setting Inspection
V
V
V
Voltage Confirmation
A board
Description Test point
PNL12V TP4097 12.1V ± 0.8V
SUB3.3V TP5400 3.32V ± 0.165V
SUB1.1V TP8100 1.2V ± 0.06V
SUB 1.5 V TP8101 1.52V ± 0.05V
SUB5V TP5420 5.0V ± 0.25V
HDMI3.3V TP8000 3.3V ± 0.16V
STB3.3V TP5002 3.14V - 3.46V
SUB9V TP5004 9.0V ± 0.25V
TU_1.8V TP5705 1.8V ± 0.16V
P board
Description Test point
32V (PANEL) TP7407 and GND TP7413
16V TP7410 and GND TP7413
5.3VS TP7501 and GND TP7413 5.2V ± 0.2V 5.2V ± 0.2V
PFC TP7201 and GND TP7203
* Connect AC 230V to JK7101 connector (Main switch is “OFF”).
** Connect DC 3.3V to TV_SUB_ON P2 connector – pin 9 /TP7415/ (Main switch is “ON”).
oltage
oltage*
<1V
<1V
<340V
oltage**
32V ± 1.6V
15.7V ± 0.8V
390 ± 15V
