SP-3427WM RECHARGEABLE SPEAKER
User’s Guide

Thank you for purchasing SP-3427WM Panacom’s Rechargeable Speaker.
Please read the manual carefully before operating.

I. FEATURES & SPECIFICATIONS

USB/TF function
Wireless BT connection
Stand holder for phone/tablet
Colorful light
Rechargeable battery
Karaoke function
Wheels and handle
Microphone input
Wireless microphone
Treble:3”x 2
Subwoofer: 8” x 2
Lead Acid battery: 4500mAh
Output power: 50W RMS(40W+2x5W)

II.RECORDING:

Recording in AUX Mode:
Connect a storage device (USB/TF card) and press Mode key to enter AUX mode.
Short press Record key to start recording for a time depending on the storage capacity.
During recording, the input signal should be in proper strength as you like.

III. THE WIRELESS BT CONNECTION PAIRING OPERATION
AND RELATED PARAMETERS:

1. ON/OFF: switch the power to ON, press the key “MODE” to enter the mode of
Wireless BT connection, the display screen will show “BLUE”.

2. Switch on the Wireless BT connection function of Mobile phone and searching
, while the Mobile phone shows “SP-3427”, click the connect directly .
mobile phone connection do not need password, if need password , please
input”0000” to go on pairing. After success pairing, the speaker will send out a
voice of prompt. it is success pairing between mobile phone and Wireless BT
connection speaker.

3. Play the music of your mobile bphone directly and will give out beautiful voice
from speaker.

Pg. 4

IV. FUNCTIONAL OPERATIONS AND FEATURES

1. LED Screen

2. Master Volume: In MP3/AUX mode, use it to regulate volume output from the
speaker.

3. TF Port: Read audio les in MP3 format in TF card in capacity up to 32G
(FAT32).

4. USB Port: Read audio les in MP3 format in USB storage device in capacity
up to 32G (FAT32).

5. : Short press it to select the previous tack.

6. :In USB/TF card reading status, short press it to play/pause, or long press
it to select one of four playback sequencing modes (All - play all tracks in
sequence; ONE - repeat one track).

7. : In USB/TF card reading status, short press it to go to the previous track.

8. Mode/SHIFT: short press it to toggle between USB/TF. Long press it to toggle
between recording folder and MP3 folder.

9. Recording/DEL: Short press it to enable recording (USB/TF storage device
need be connected rst). During recording, reverberation should be tuned to
the minimum. Long press it to delete a recording le. Recording in AUX

10. EAR MIC: headphone/MIC Port

23

Pg. 5

11. EQ: Environment Switching: In USB/TF reading status, short press it to select
an environment mode (from Square, Meeting, Home, Hall and Personal).

12. MIC PRIORITY: Connect the microphone, short press the key, into the
microphone priority mode

13. LINE IN: External sound source input port (plug-and-play).

14. Microphone volume: Microphone volume regulating knob.

15. Reverberation: Microphone reverberation regulating knob.

16. Microphone input: Microphone input jack

17. DC 12V recharging: DC 12V recharging port.

18.

: it to control the ash light switch.

19. Recharging indicator light: When recharger is connected, the red light turns
on. When the device is fully recharged, the green light turns on.

20. Power switch: “ ” - ON; “ ” - OFF.

21. TREBLE: The control knob of treble

22. BASS: The control knob of bass

23. Stand holder for phone/tablet.

CAUTION:
Please Be sure to charge while music distorted.
