Chapter 1
Overview
This chapter describes the front and back panels of the PA-200 firewall. For more information,
refer to the following topics:
• “Front Panel” in the next section
• “Back Panel” on page 7
Palo Alto Networks Overview • 5
Front Panel
Front Panel
Figure 1 shows the front panel of the PA-200 firewall.
Ethernet
ports
LEDs
Management
port
USB
port
Console
port
Figure 1. Front Panel
Table 1 describes the front panel features.
Table 1. Front Panel Features
Item Description
Ethernet ports 4 RJ-45 10/100/1000 ports for network traffic.
Management port 1 RJ-45 10/100 port used to access the device management interface.
Console port 1 RJ-45 port for connecting a serial console.
USB port 1 USB port for future use.
LED dashboard 6 LEDs indicating system status. Refer to “Interpreting the Device
LEDs” on page 12 for LED definitions.
6 • Overview Palo Alto Networks
Back Panel
Figure 2 shows the back panel of the PA-200 and Table 2 describes the back panel features.
Figure 2. Back Panel
Table 2. Back Panel Features
Item Description
Back Panel
DC power
Power inlet DC power inlet for powering the device.
Palo Alto Networks Overview • 7
Back Panel
8 • Overview Palo Alto Networks
May 20, 2015 - Palo Alto Networks COMPANY CONFIDENTIAL
Chapter 2
Installing the Hardware
This chapter describes how to install the PA-200 firewall. For more information, refer to the
following topics:
• “Tamper Proof Statement” on page 9
• “Before You Begin” in the next section
• “Connecting Cables to the Device” on page 10
• “Connecting Power” on page 10
Tamper Proof Statement
To ensure that products purchased from Palo Alto Networks have not been tampered with
during shipping, verify the following upon receipt of each product:
• The tracking number provided to you electronically when ordering the product matches
the tracking number that is physically labelled on the box or crate.
• The integrity of the tamper-proof tape used to seal the box or crate has not been
compromised.
• The warranty seals on the device itself do not show evidence of tampering. Being a
modular system, please note that the PA-7050 does not have a warranty seal.
Before You Begin
• Verify that the intended location has adequate air circulation and meets the temperature
requirements. Refer to
“Environmental Specifications” on page 14.
• Unpack the device.
• Verify that power is not connected to the firewall.
• Allow clear space on all sides, back, and top of the firewall to allow for proper cooling. Do
not stack PA-200 firewalls.
Palo Alto Networks Installing the Hardware • 9
Connecting Cables to the Device
Network Management Console
Note: The PA-200 firewall uses a combination of passive and active cooling and
needs proper airflow on all surfaces to ensure proper operation. Do not install the
PA-200 firewall in a small, confined space such as a closed shelf or drawer, as this
could lead to insufficient cooling of the device.
Connecting Cables to the Device
Figure 3 shows the PA-200 cable connections. Refer to Table 1 for descriptions of the front
panel interfaces.
Figure 3. Cable Connections for the PA-200 Firewall
Connecting Power
To power the PA-200 firewall:
1. Attach a power cable to the external power supply.
2. Plug the power supply into the PA-200 firewall.
3. Plug the cable into a grounded wall outlet.
10 • Installing the Hardware Palo Alto Networks
May 20, 2015 - Palo Alto Networks COMPANY CONFIDENTIAL
Chapter 3
Maintaining the Hardware
This chapter provides maintenance information for the PA-200 hardware. For more
information, refer to the following topics:
• “Cautions and Warnings” in the next section
• “Interpreting the Device LEDs” on page 12
• “Interpreting the Port LEDs” on page 13
Cautions and Warnings
This section describes the cautions and warnings that you must be familiar with before
working with the hardware:
• “Hardware Cautions” on page 11
• “Hardware Warnings” on page 11
Hardware Cautions
• Disconnect the power cord before servicing the PA-200 firewall.
• Shielded Ethernet interface cables should be used to ensure agency compliance with
electromagnetic emissions (EMC). Connecting a PoE enabled port to the firewall is not
recommended because the system does not support the PoE operating mode.
• To prevent damage from electrical surges, use a Uninterruptible Power Supply (UPS) and
implement the facilities lightning protection requirements outlined in the National Fire
Protection Association (NFPA) 780: Standard for the Installation of Lightning Protection
Systems (or similar effective measures per local regulations).
Hardware Warnings
• Risk of explosion if the battery is replaced with an incorrect type. Dispose of used
batteries in accordance with government regulations.
Palo Alto Networks Maintaining the Hardware • 11
Interpreting the Device LEDs
• Removal of equipment top cover is to be performed only by trained service person(s).
Interpreting the Device LEDs
Figure 4 shows the LEDs on the front panel of the PA-200 firewall.
Figure 4. Front Panel LEDs
Table 3 describes the LED functions and states.
Table 3. LED Functions and States
Interface State Description
POWER Green The device is powered.
Off Power is off.
STATUS Green The device is operating normally.
Yellow The device is booting up.
FAN Green The fan is operating normally.
Note: The fan is under the control of the firewall processor and may not
run all the time. This is normal.
Red The fan has failed.
HA Green This device is the current active device.
Yellow This device is the current passive device.
Off High availability is not enabled on this device.
ALARM Red There is a hardware failure, which may include power supply
detected but not working, fan failure, HA failover, or temperature
above high temperature threshold.
Off The device is operating normally.
TEMP Green The temperature is normal.
Yellow The temperature is outside the normal tolerance.
12 • Maintaining the Hardware Palo Alto Networks
Interpreting the Port LEDs
Each Ethernet port on the PA-200 firewall has two LEDs. Table 4 describes the LEDs.
Table 4. Port LEDs
LED Description
Left Shows green if there is a network link.
Right Blinks if there is network activity.
Interpreting the Port LEDs
Palo Alto Networks Maintaining the Hardware • 13
Interpreting the Port LEDs
14 • Maintaining the Hardware Palo Alto Networks
May 20, 2015 - Palo Alto Networks COMPANY CONFIDENTIAL
Chapter 4
Specifications
This chapter provides specifications for the PA-200 firewall. For more information, refer to the
following topics:
• “Physical Specifications” in the next section
• “Interface Specifications” on page 14
• “Electrical Specifications” on page 14
• “Environmental Specifications” on page 14
Physical Specifications
Table 5 lists the physical specifications for the PA-200 firewall.
Table 5. Physical Specifications
Specification Description
Height 1.75 inches (4.5 cm) (1 RU).
Depth 6.5 inches (16.5 cm).
Width 9 inches (23 cm).
Weight Firewall only: 2.8 lbs (1.3kg).
Fan Single fan.
As shipped: 5.1 lbs (2.3kg).
Note: The fan is under control of the firewall’s processor and may not run
all of the time. This is normal.
Palo Alto Networks Specifications • 13
Interface Specifications
Interface Specifications
Table 6 describes the interfaces for the PA-200 firewall.
Table 6. Interface Specifications
Specification Description
Ethernet ports 4 RJ-45 10/100/1000 ports for network traffic.
Management port 1 RJ-45 port to access the device management interfaces through an
Console port 1 RJ-45 port for connecting a serial console. Use these settings:
USB port One USB port for future use.
Ethernet interface.
• Data rate: 9600
• Data bits: 8
• Parity: none
• Stop bits: 1
• Flow control: none
Electrical Specifications
Table 7 lists the electrical specifications for the PA-200 firewall.
Table 7. Electrical Specifications
Specification Description
Input frequency 50-60 Hz
Average/maximum power consumption 20W/30W
AC voltage 100-240 VAC
Environmental Specifications
Table 8 lists the environmental specifications for the PA-200 firewall.
Table 8. Environmental Specifications
Specification Description
Operating temperature range 0° to 40° C
Storage temperature range -20° to 70° C
System air flow Side to side
14 • Specifications Palo Alto Networks
May 20, 2015 - Palo Alto Networks COMPANY CONFIDENTIAL
Chapter 5
Compliance Statements
CE
European Union (EU) Electromagnetic Compatibility Directive
This device is herewith confirmed to comply with the requirements set out in the Council
Directive on the Approximation of the Laws of the Member States relating to Electromagnetic
Compatibility Directive (2004/108/EC).
The above product conforms with Low Voltage Directive 2006/95/EC and complies with the
requirements in the Council Directive 2006/95/EC relating to electrical equipment designed
for use within certain voltage limits and the Amendment Directive 93/68/EEC.
KCC
TUV
Product Ambient Temperature: 0~40 degree C
Palo Alto Networks Compliance Statements • 15
FCC
VCCI
Federal Communications Commission (FCC) Statement:
For a Class B digital device or peripheral
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Japan Compliance Statement:
This is a Class B product based on the standard of the VCCI Council. If this is used near a
radio or television receiver in a domestic environment, it may cause radio Interference. Install
and use the equipment according to the instruction manual.
ICES
Canadian Department Compliance Statement:
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de
la classe B est conforme à la norme NMB-003 du Canada.
16 • Compliance Statements Palo Alto Networks
Loading...
