AeGIS 7000 Series

Installation and Programming Manual

PACH & COMPANY

www.pach-co.com

941 Calle Negocio San Clemente, CA 92673

Phone: 888-678-7224 Fax: 949-498-6879

REV. 08.31.10

TABLE OF CONTENTS

Limitations of Liability

Chapter 1. Getting Started ............................................................................................. 1

1.1. Introduction .................................................................................................................................. 1

1.2. System Description, Specifications and Accessories .................................................................. 1

1.3 Unpacking the System ................................................................................................................. 2

1.4 Warranty ........................................................................................................................................3

Chapter 2. Installation .................................................................................................... 4

Chapter 3. Programming ................................................................................................ 7

3.1. Local Programming Via Built-in Keypad ...................................................................................... 7

3.2. Remote Programming Via a Touch Tone Phone ......................................................................... 7

Programming Function Codes .......................................................................................... 8

............................................................................................................................. 8

# ............................................................................................................................. 8

00 Replace System Master Code ................................................................. 8

01 Program a New Tenant ............................................................................ 9

02 Modify an Existing Tenant Directory .........................................................10

03 Delete an Existing Tenant Directory ......................................................... 11

04 Clear All Tenants Directory .......................................................................11

05 Manual Lock (open) or Unlock (Close) Door ............................................12

06 Selecting Directory Digits .........................................................................12

07 Single or Multi Systems ............................................................................13

08 System Number ........................................................................................13

10 Change the Welcome Screen ..................................................................13

46 System Information .................................................................................. 14

50 Clear the Memory to Factory Default .......................................................14

70 Change Talk Time .....................................................................................15

71 Change Door Open Interval .....................................................................15

72 Change Lock Out Count .......................................................................... 15

73 Select Tone or Pulse Dialing ................................................................... 16

74 Enable or Disable Auto Answer .............................................................. 16

75 Turn On or Off Key Press Beep .............................................................. 16

76 Turn On or Off Speaker Beep ................................................................. 17

77 Enable or Disable Remote Access ......................................................... 17

78 View Directory by Name ......................................................................... 17

91 Exit from Remote Programming ............................................................ 18

Chapter 4. System’s Operation ..................................................................................... 19

How to View the Tenant Name .......................................................................................................... 19

How to Initiate a Call and Unlock the Door for Visitor ....................................................................... 19

How to Extend the Talk Time ............................................................................................................. 19

How to Call into The System ............................................................................................................. 19

How to Provide Remote Access ........................................................................................................ 20

How to Disable Remote Access ........................................................................................................ 20

How to Call to a Voice Mail or Extension Number ............................................................................ 20

How to Use the 4-Digit Access Code to Unlock the Door ................................................................. 20

How to Adjust the Speaker and Microphone Volume ....................................................................... 20

How to Adjust the LCD Display ......................................................................................................... 20

How to Adjust the Pulse Sensitivity ................................................................................................... 20

How to Check the Number of Tenants Programmed in the System .................................................. 20

Chapter 5. Trouble Shooting Guide .............................................................................. 21

General FCC Requirements .......................................................................................... 24

Quick Guide ....................................................................................................................25

LIMITATIONS OF LIABILITY

This manual is subject to change without notice. Pach and Company is not liable for any errors that might occur from use of this document,

nor is any commitment to update the information herein implied. Pach and Company does not assume any liability for any damages, which may arise in

installation or use of the AeGIS 7000 Series. Pach and Company does not assume liability for any incompatibility between the AeGIS 7000 Series and users devices.

Pach & Company reserves the right to make changes without prior notice to any products in order to improve reliability, function or design.

Chapter 1 GETTING STARTED

1.1 Introduction

Pach & Company thanks and congratulates you on the purchase of your AeGIS 7000 Series (7025, 7050, 7100, 7150,7200 or 7250) Telephone Access Control Systems.

The manual is designed to guide you through the proper programming and use of the AeGIS 7000 Series. It is important for you to read and follow the manual completely.

The Aegis 7000 Series comes with two years warranty, see section 1.4 for more detail on warranty policy.

1.2 System Description, Specifications and Accessories

AeGIS 7000 Series utilizes microprocessor technology to provide security as well as convenience to you. It is designed for residential and commercial buildings, military and government sites, industrial facilities, or any location where access control is required. It uses a dedicated phone line and connects to the public telephone network. Authorization for access control is through the telephone line, or with the tenant's own access code, which is entered on the system keypad. The tenants MUST have a telephone to allow remote visitor access.

Also, as a standard feature, the tenant is allowed to "call" the Aegis unit and converse with the visitor and "remote programming" using a touch tone phone.

The system parameters and tenants data will be entered via the keypad and the LCD provides easy display. EEPROM technology is used for AeGIS 7000 series. The tenant database will not be lost during a power failure.

Standard features:

• Program and store the tenant's name, directory code, telephone number and personal access code.

• Unlocking door or gate remotely by the tenant using his or her telephone keypad.

• Unlocking door or gate by the tenant using his or her own private access code.

• Built-in back-light LCD directory, Postal Switch.

• Works behind a PBX to dial extensions (analog only).

• Keypad Activated to support Voice Mail.

• Programmable features:

• 2, 3 or 4 Digit Directory Code

• Lock Out Count

• Manual Unlock-Auto Countdown Re-lock.

• 4 Digit Unit master Code

• Open Interval

• Talk Time

Technical Specifications:

Power Input: 12 VAC 40 VA (supplied) or 12 VDC 40VAUL Listed Transformer Current Consumption: 500mA idle, 700mA operation Emergency Battery: 12Vdc, 4Ahr rechargeable (not supplied) Telephone Line: Standard voice grade RJ11 jack. Night Light: 14V 0.080A 15,000 Average life hours. Operating Environment: Temp. 32°F to +140°F Relative Humidity 0% to 95% non-condensing.

* Heater Pad (AHP5) is required if the ambient temperature is below 32°F.

Pach and Company Chapter 1 Page 1 AeGIS 7000 Series GETTING STARTED

Relay Output: Form C Dry Contact 120 VAC 10A/ 24VDC 10A/ 250VAC 7A Memory Type: EEPROM Tone Detection: Crystal controlled, capable of detecting short bursts 80 ms Ringer Equivalence: 0.6B Mounting: Surface or Full-Flush. Construction: 16-gauge stainless steel Shipping: 11 lbs. or 5 kg. Approximate Dimensions: 10.75" (27.3Cm) x 8.5" (21.6Cm) x 3.125" (7.9Cm) (HWD)

Specifications subject to change without prior notice

Accessories and Replacement Parts:

Visit our website www.pach-co.com or call 1-888-678-7224

1.3 Unpacking the System

After you unpacked the package, check the serial number on the printed circuit board, cabinet and warranty card, they must match. If they do not match, please contact Pach and Company toll free number at (888) 678-7224. All the items listed below come with the AeGIS 7000 Series. If you have missing items, please contact your distributor or Pach and Company at (888) 678-7224.

• AeGIS 7000 Series System (7050, 7150 or 7250).

• XMFR (Power Transformer, 12VAC 40VA).

• 2-pin terminal connector (inside the cabinet)

• 4-pin terminal connector (inside the cabinet).

• 5-pin terminal connector (inside the cabinet).

• Key sets (2 keys per set)

• RJ-11 adapter (inside the unit's cabinet).

• Owners Manual.

1.4 Limited Warranty

Pach and Company new products are warranted to be free of defects in material or workmanship for a period of two years, (24 months), from the date of purchase. This warranty extends only to wholesale customers who buy direct from Pach and Company or through Pach and Company’s normal distribution channels.

Pach and Company does not warrant this product in any way to the end user consumer. Consumers must obtain warranty information from the selling dealer and/or installer as to the nature of the dealer’s warranty, if any. All contact to Pach and Company from the end user consumer will be referred to the consumer’s selling dealer and/or installer.

There are no obligations and/or liabilities on the part of Pach and Company for consequential damages arising out of or in connection with use or performance of Pach and Company products or other indirect damages with respect to loss of property, revenue, or profit, or cost of removal, installation, or reinstallation. Any use or change to Pach and Company products not expressly approved by the manufacturer, and performed by an authorized dealer/installer will immediately void the warranty. All implied warranties, including warranties for marketability as well as implied warranties for suitability, are valid only until the warranty expires or is voided, whichever comes first.

This Pach and Company Limited Warranty is in lieu of all other warranties express or implied and all Pach and

Pach and Company Chapter 1 Page 2 AeGIS 7000 Series GETTING STARTED

Company warranties are subject, but not limited, to the following conditions.

I. NEW PRODUCT POLICY

1. The products must be properly installed as specified; and maintained or used as intended.

2. Cause of product failure is not due to vandalism or malicious mischief, improper installation, abnormal physical or electrical stress, lightning, power surges, misuse, negligence, accidents, or Natural disasters.

3. Warranty is immediately null and void if the product has been altered, repaired, or modified without express

written authorization from Pach and Company Technical Department, with such authorization given only to manufacturer approved dealer/installers.

4. Under no circumstances will Pach and Company honor warranty any product found to have been altered, repaired, and/or modified by the end-user consumer.

5. Pach and Company reserves the right to repair the product, or replace a warranted product with a like product of equal value in the event original product cannot be repaired.

6. Distributors and/or Dealer-Installer must first obtain a Return Merchandise Authorization (RMA) number from Pach and Company Technical Department before returning any product to factory for repair, whether under warranty or not. No

returns accepted without RMA.

7. Return Merchandise Authorization (RMA) numbers will not be issued to the end-user consumers. Consumers must contact their selling dealer-installer for any/all warranty issues.

8. Distributor and/or Dealer-Installer are responsible for all shipping charges, incl. freight and insurance fees, for products shipped to Pach and Company repair center.

9. Pach and Company warranty does not guarantee any product to be free of operation error or service interruption in any way during the course of daily product operation.

10. Pach and Company is not responsible for time, travel, and/or labor costs of any distributor and/or dealer-installer, including but not limited to, any expenses to install, uninstall or reinstall hardware/software/firmware related to warranty issues, product enhancements, or product failures.

Pach and Company Chapter 1 Page 3 AeGIS 7000 Series GETTING STARTED

NEW PRODUCT WARRANTY EXCEPTION

WIEGAND CARD, KEYFOB AND TRANSMITTER

Pach and Company warrants the wiegand card, clam, and keyfob to be free of defects in material or workmanship for a period of three (3) months from the date of invoice. The above warranty is subject to the following conditions.

1. The products must be properly installed as specified; and maintained or used as intended.

3. Warranty is immediately null and void if the product has been altered, repaired, or modified without express written authorization from Pach and Company Technical Department, with such authorization given only to manufacturer approved dealer/installers.

4. Under no circumstances will Pach and Company honor warranty any product found to have been altered, repaired, and/or modified by the end-user consumer.

5. Pach and Company reserves the right to repair the product, or replace a warranted product with a like product of equal value in the event original product cannot be repaired.

7. Return Merchandise Authorization (RMA) numbers will not be issued to the end-user consumers. Consumers must contact their selling dealer-installer for any/all warranty issues.

8. Distributor and/or Dealer-Installer are responsible for all shipping charges, incl. freight and insurance fees, for products shipped to Pach and Company repair center.

9. Pach and Company warranty does not guarantee any product to be free of operation error or service interruption in any way during the course of daily product operation.

10. Pach and Company is not responsible for the time, travel, and/or labor costs of any distributor and/or dealer- installer, including but not limited to, any expenses to install, uninstall or reinstall hardware/software/firmware related to warranty issues, product enhancements, or product failures.

AeGIS PARTS LIMITED WARRANTY

II. NON-W

ARRANTY REPLACEMENT PARTS POLICY

Pach and Company parts are warranted to be free of defects in material or workmanship for a period of six (6) months), from the date of purchase or repair. This warranty extends only to wholesale customers who buy direct from Pach and

Company from the end user consumer will be referred to the consumer’s selling dealer and/or installer.

This Pach and Company Limited Warranty is in lieu of all other warranties express or implied and all Pach and

Company warranties are subject, but not limited, to the following conditions.

REPLACEMENT PARTS

1. The products must be properly installed as specified; and maintained or used as intended.

4. Under no circumstances will Pach and Company honor warranty any product found to have been altered, repaired, and/or modified by the end-user consumer.

5. Pach and Company reserves the right to replace a warranted product with a like product of equal value in the event original system cannot be repaired.

returns accepted without RMA.

7. Return Merchandise Authorization (RMA) numbers will not be issued to the end-user consumers. Consumers must contact their selling dealer-installer for any/all warranty issues.

8. Distributor and/or Dealer-Installer are responsible for all shipping charges, incl. freight and insurance fees, for products shipped to Pach and Company repair center.

9. Pach and Company warranty does not guarantee any product to be free of operation error or service interruption

in any way during the course of daily product operation.

AeGIS NON-WARRANTY REPAIR LIMITED WARRANTY

III. NON-W

ARRANTY REPAIR POLICY

Pach and Company warrants repairs to be free of defects in material or workmanship for a period of three (3) months from the date of repair and invoice. This warranty extends only to wholesale customers who buy direct from Pach and

Company or through Pach and Company’s normal distribution channels. Consumers must obtain warranty information from the selling dealer and/or installer as to the nature of the dealer’s warranty, if any. All contact to Pach and Company from the end user consumer will be referred to the consumer’s selling dealer and/or installer.

This Pach and Company Limited Warranty is in lieu of all other warranties express or implied and all Pach and

Company warranties are subject, but not limited, to the following conditions.

1. The products must be properly re-installed as specified; and maintained or used as intended.

2. Cause of repaired product failure is not due to vandalism or malicious mischief, improper installation, abnormal physical or electrical stress, lightning, power surges, misuse, negligence, accidents, or Natural disasters.

3. Warranty is immediately null and void if the product has been altered, repaired, or modified without express

written authorization from Pach and Company Technical Department, with such authorization given only to manufacturer approved dealer/installers.

4. Under no circumstances will Pach and Company honor warranty of any product found to have been altered, repaired, and/or modified by the end-user consumer.

5. Pach and Company reserves the right to replace a previously repaired product with a like product of equal value in the event of repair failure, provided repair failure occurs within the specified warranty period.

without RMA.

7. Return Merchandise Authorization (RMA) numbers will not be issued to the end-user consumers. Consumers must

contact their selling dealer-installer for any/all warranty issues.

8. Distributor and/or Dealer-Installer are responsible for all shipping charges, incl. freight and insurance fees, for products shipped to Pach and Company repair center.

9. Pach and Company warranty does not guarantee any product, new or repaired, to be free of operation error or

service interruption in any way during the course of daily product operation

IMPORT

ANT REP

AIR NOTE: Pach and Company will perform a factory physical evaluation of all products submitted for

repair at receipt of item, and reserves the right to decline repairs after said physical evaluation. In the event a returned product is deemed ineligible for repair; the product will be returned to sender via common carrier ground at Pach and Company expense.

Chapter 2 INSTALLATION

A proper installation of the AeGIS system is very essential. You MUST follow the installation procedures, block diagrams and installation requirements as specified in this chapter.

Figure 2.1

Pach and Company Chapter 2 Page 4 AeGIS 7000 Series INSTALLATION

GROUNDING

Grounding the AeGIS steel enclosure is essential. Please comply with all local ordinances and industry standard procedures to ensure a complete and safe ground. Recommended earth grounds are:

• Use 18-gauge solid wire for grounding.

• Installing a ground steel rod from the AeGIS steel enclosure to the earth ground.

• Installing a solid heavy gauge wire from the AeGIS steel enclosure to a water pipe.

• Connecting the AeGIS steel enclosure to any earth grounded steel metal.

TELEPHONE LINE

Always use AeGIS AC/Telephone Surge Protector (ASP1) to protect your investment. One surge protector must be used for each AeGIS 7000 system.

• Twisted pair category 5 is the minimum requirement if the distance less than 200 feet. Shielded wires are recommended to avoid radio reception or any other noise problems. If the distance is more than 200 feet, 2-conductors, 18-gauge shielded stranded is recommended. Ground one end of the shielded to earth ground.

See installation instruction if ASP1 Surge Protector is used.

• If a PBX line is used connect the AeGIS to the analog PBX's extension to dial the extensions within the PBX.

Do not connect to a PBX's Digital Port.

NOTE: The AeGIS 7000 Series only works behind the PBX to dial extensions, no pause can be programmed on

the AeGIS 7000 to dial the outside line.

DOOR STRIKE OR ELECTRICAL STRIKE

The AeGIS 7000 series provides a single relay form "C" dry contact: Normally Open (NO) and Normally Closed (NC).

• 10 Ampere 120 VAC or

• 10 Ampere 24 VDC or

• 7 Ampere 250 VAC See figure 2.1 for door strike wiring diagram. You MUST use two conductors 18 gauge stranded wire minimum. Note: Some door strikes are creating electrical or magnetic noise or spikes and could create problem to the system's

memory. Although the system's relay has built-in filtration circuit, installing an isolation relay is recommended if the system is experiencing with looses memory.

POSTAL LOCK

The AeGIS system comes with pre-wired "Normally Open" postal switch as shown on figure 2.2(a). If the postal switch is pressed, the gate will open. If you need "Normally Closed" postal switch, see figure 2.2(b). The postal lock is not included. You have to purchase the postal lock from your local post office. See figure 2.2 to alter the postal switch to normally closed.

POWER

Pach and Company Chapter 2 Page 5 AeGIS 7000 Series INSTALLATION

Figure 2.2 (a)

Figure 2.2 (b)

LCOM

POST

LCOM

POST

A 12 VAC 40VA transformer is supplied by Pach and Company. However, 12 VDC 40VApower supply or 12VDC

power

supply with battery backup can be used to power the AeGIS 7000 Series, use the same connection as shown on figure 2.1.

• Two conductors, 18-gauge shielded stranded wires must be used. Ground one end of the shielded to earth ground. See installation instruction if ASP1 Surge Protector is used.

• Do not share power transformer or power supply between the AeGIS and other electronic equipment.

• Turn the power "ON" (left position). The Power Light Emitting Diode (LED2) should be "ON". You should see “Welcome to Pach's Telephone Access Systems" on the Liquid Crystal Display (LCD). If the display is blank, turn the system off and see Chapter 4.0 Operations and Chapter 6.0 Trouble Shooting Guides.

BATTERY BACKUP

The AeGIS 7000 Series have built-in charging circuit for battery backup. The battery will keep the system in full operation during power failure. Recommended battery is 12 VDC, 4.5 Ahr rechargeable (customer supply). The life of the battery is approximately 8 hours in idle mode.

• Use two conductors 18-gauge shielded stranded wires.

WARNING: The connection is polarity sensitive. Connect the battery (+) terminal to the connector labeled (BAT) on the

AeGIS and the battery (-) terminal to the connector labeled LCOM on the AeGIS. See figure 2.1 for wiring diagram.

NIGHT LIGHT

14V 0.080A 15,000 Average life hours light bulbs. Use the same rating of replacement light bulb.

Pach and Company Chapter 2 Page 6 AeGIS 7000 Series INSTALLATION

Chapter 3 PROGRAMMING

The AeGIS 7000 Series can be programmed locally using the built-in keypad or remotely via a touch tone phone.

3.1 LOCAL PROGRAMMING VIA BUILT-IN KEYPAD

Log on to programming mode

Two ways to log on to programming mode:

1) PRESS 0 AND # SIMULTANEOUSLY THEN RELEASE, the display screen stops scrolling (If the display screen is still

scrolling repeat this step again) then enter the valid 4-digit Master Code (default Master Code: 0000). Now, you are in programming mode, the display shows:

and proceed to Local Programming Table 3.1. If the system idles in 30 seconds, the display will return to a scrolling mode.

2) IF YOU DO NOT HAVE A VALID MASTER CODE, open the panel (key must be used) then press and release the “RED

BUTTON” on the board and the display shows:

x x x x: 4-digit Master Code.

then press #. Now, you are in programming mode and proceed to Local Programming Table 3.1. If the system idles in 30 seconds, the display will return to a scrolling mode.

3.2 REMOTE PROGRAMMING VIA A TOUCH TONE PHONE

You may use Telephone Remote programming to add a tenant, delete or modify the system's parameter. The rules below must be followed:

• Enable the system Auto Answer (see table 3.1 Function Code 74-Enable or Disable Auto Answer), the AeGIS 7000 Series will answer on the first ring.

• Do not share the AeGIS 7000 phone line with any answering devices such as a fax machine, alarm device or modem.

• Atouch-tone phone must be used.

• Only letter A-Z can be entered using a touch-tone phone for a person name. No punctuation or number can be entered.

• Aperson name only in upper case.

Log on to programming mode

1) SINGLE SYSTEM

Step 1 Call the AeGIS 7000. When the system answer you will hear:

One Short Beep: Door is opened. Two Short Beeps: Door is closed.

Press # key

Step 2 Press your valid Master Code.

• If your Master Code is accepted, you will hear Two Short Beeps and now, you are in the programming mode and proceed to Touch Tone Programming Table 3.1. Note: If the system idles in 30 seconds, the display will return to a scrolling mode.

• If your Master Code is rejected, the system will disconnect.

Pach and Company Chapter 3 Page 7 AeGIS 7000 Series PROGRAMMING

Select Func: _ _

Master Code: x x x x

2) MULTI-SYSTEM IN SINGLE TELEPHONE LINE

Step 1 Call into the AeGIS 7000 using a touch tone phone. When the system answer you will hear:

• One Short Beep: Door is opened.

• Two Short Beeps: Door is closed.

• One Long Beep: Combination of Closed and open.

Step 2 Press the System Number you want to log in (1-8) then press # key. Step 3 Press your valid Master Code.

• If your Master Code is accepted, you will hear Two Short Beeps and you are in the programming mode, then proceed to Touch Tone Programming Table 3.1. Note: If the system idles in 30 seconds, the display will return to a scrolling mode.

• If your Master Code is rejected, the system will disconnect.

Step 4 Follow the next programming sections below to program the tenant database and parameters.

TABLE 3.1 PROGRAMMING FUNCTION CODES

REPLACE SYSTEM

MASTER CODE

(Default setting is

0000)

Master Code is used to log

on to programming mode,

not to unlock door or gate.

1. Exit the programming mode by pressing * once or twice.

2. Clear the programmed name, phone number or access code by pressing

3. Press * then the 4-digit access code to unlock the door

or gate via the system keypad. Press # to accept program. Step 1 Log on to programming mode (see section 3.1).

The display shows

Step 2 Enter Function code 00, then press #, the display

shows

Step 3 Enter the new 4-digit Master Code then press #

the display shows

If you press * the display shows

Ignore the message, and your existing Master Code will remain in the system.

Step 4 Select another Function Code to program

different field from the table or press *to exit the programming mode and you hear “Three

Short Beeps”.

NOT APPLICABLE. IF PURCHASE 2004 AND AFTER.

Press # to accept program. Step 1 Log on to programming mode,

see section 3.2. If you have logged on. Proceed to step

Step 2 Enter Function Code 00 and

press #, you will hear “One

Short Beep”.

Step 3 Enter the new Master Code and

press #, and you will hear “Two Short Beeps”.

Step 4 Select another Function Code to

program another parameter or press 91 then press # to disconnect the call, you will hear

“Three Short Beeps”.

FUNCTION CODE LOCAL PROGRAMMING TOUCH TONE PROGRAMMING

Pach and Company Chapter 3 Page 8 AeGIS 7000 Series PROGRAMMING

Select Func: _ _

Master Code: 0

000

Select Func: _ _

ERROR DATA

* * * *

PROGRAM A NEW

TENANT

There are four different fields that need to be programmed: Directory Code (DIR), Name, Phone Number (PH #), and Access Code.

Directory Code (DIR): A

unique (non-duplicating) 2, 3 (factory default) or 4 digit code assigned for each tenant for identification (Used Function Code 06 to Change Directory Digits). It links to tenant name, phone number and access code. The same number of digit must be used on every tenant's directory.

Name: up to 16

characters.

Phone Number: up to

11-digit.

Access Code: A 4-digits

personal code is assigned to individuals for the purpose of granting entry using the Telephone Entry Systems keypad.

Please note the following criteria before entering the tenant Directory Code, Name, Phone Number and Access Code.

1. The Directory Codes can NOT be duplicated.

2. Each Directory Code is considered as one tenant.

3. The existing Directory Codes cannot be changed by another directory code. They can be deleted using Function Code "03".

4. Delete the unused directory code to avoid running out of memory.

5. The Tenant Directory database must contain name. Tenant Directory cannot be deleted if the directory code is forgotten and no name is programmed.

6. The tenant names may be entered in any order. The system will automatically arrange them it alphabetical order.

7. The same Name, Telephone Number and Access Code can be assigned into different directory code number.

Step 1 Log on to programming mode (see section 3.1),

the display shows

Step 2 Enter Function Code 01 then press #, the

display shows:

Step 3 Enter the directory code (see setting on

function code 06) 2, 3 (default) or 4-digit. The

display shows:

The display goes blank about one second then the display shows:

Proceed to Step 4.

If the directory code has already used, the display shows:

Return to Step 2. If the memory is full, the display shows:

You cannot program more tenant unless if you delete the existing one or call Pach and Company to purchase memory upgrade EPROM.

Step 4 Enter the tenant name (up to 16 characters )

using the keypad (see keypad layout) then

• Press # after entering each letter then

• Press # # after entering the last letter

the display shows:

Press 0 for space ( move

cursor to the right).

Press 8 then 0 for back

space ( move cursor to the left.

Press

to clear all letters

or numbers entered.

Step 1 Log on to programming mode,

see section 3.2 If you have logged on proceed to step 2.

Step 2 Enter Function Code 01 then

press #, you hear “One

Short Beep”.

Step 3 Enter a tenant directory code (2,

3 or 4 digits) then press # and you hear “One Short Beep”. If the directory has already existed, you hear “Two Long Beeps” , return to step 2.

Step 4 Enter tenant name up to 16

characters then

• Press # after entering each letter then

• Press # # after entering the last letter

then you hear “One Short Beep”.

Step 5 Enter tenant's telephone number

up to 11-digit and press #, you hear “One Short Beep”.

Step 6 Enter tenant's 4-digits access

code number then press #, you will “One Short Beep”.

Step 7 Select another Function Code to

program another parameter or tenant's directory, otherwise enter 91 then press # to disconnect the call, you hear “Three Short Beeps”.

Pach and Company Chapter 3 Page 9 AeGIS 7000 Series PROGRAMMING

FUNCTION CODE LOCAL PROGRAMMING TOUCH TONE PROGRAMMING

Select Func: _ _

Enter Dir: _ _ _

Enter the NAME:

Dir # is used !

ERROR DATA

* * * *

PH #:

_ _ _ _ _ _ _ _ _ _ _

Pach and Company Chapter 3 Page 10 AeGIS 7000 Series PROGRAMMING

MODIFY AN

EXISTING TENANT

DIRECTORY

Step 5 • To change phone number: press * to erase

and program a new one then press #.

• To keep the phone number: press #.

The display shows:

X is existing access code.

• To change access number: enter a new one

then press #.

• To keep the access code: press #.

Step 6 Proceed to step 2 and select the same Function

Code or different Function Code to continue programming or press *to exit the programming

mode and you will “Three Short Beeps”.

Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 03 then press #, the

display shows:

Step 3 Enter a tenant directory code you want to delete

the press #. The display shows:

If the directory does not exist, the display shows:

Proceed to step 2.

Step 4 Proceed to step 2 and select the same Function

Code or different Function Code to continue programming or press *to exit the programming

mode and you will hear “Three Short Beeps”.

Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 04 then press #, the

display shows:

Step 3 • Press 13 then # the display shows:

then proceed to step 4 or

Step 1 Log on to programming mode,

see section 3.2 If you have logged on proceed to step 2.

Step 2 Enter Function Code 03 then

press #, you hear “One Short

Beep”.

Step 3 Enter the tenant directory code

(2, 3 or 4 digits) you want to delete then press # and you hear “Two Short Beeps” means directory is deleted or “One Long Beep” then “Two Short Beeps” means vice versa.

Step 4 Select another Function Code to

program another parameter or tenant's directory, otherwise enter 91 then press # to disconnect the call, you hear “Three Short Beeps”.

NOT AVAILABLE.

FUNCTION CODE LOCAL PROGRAMMING TOUCH TONE PROGRAMMING

Access Code: XXXX

Select Func: _ _

Delete Dir: _ _ _

(Dir Code) is deleted !

Error on Delete !

Select Func: _ _

Delete all? 13

Are you sure ? 5

MANUAL LOCK

(OPEN) OR

UNLOCK (CLOSE)

DOOR

SELECTING

DIRECTORY DIGITS

Factory default setting is 3-digit.

• Press* to cancel deletion and you hear “One

Long Beep” and proceed to step 5.

Step 4 Press 5 then # to delete or

Press

to cancel deletion.

Step 5 Proceed to step 2 and select the same Function

Code or different Function Code to continue programming or press *to exit the programming

mode and you will hear “Three Short Beeps”.

Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 05 then press #, the

display shows:

Step 3 Enter • 01-98 hours to unlock door or

• 99 hours to to unlock door for indefinite time or

• 00 hours to lock door

then press # or press

to cancel.

Step 5 Proceed to step 2 and select the same Function

Code or different Function Code to continue programming or press

to exit the programming

mode and you will hear “Three Short Beeps”.

Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 06 then press #, the

display shows:

Step 3 Enter the Directory Digits 2, 3 or 4 then press #

or press

to keep the existing one.

Step 4 Proceed to step 2 and select the same Function

Code or different Function Code to continue programming or press *to exit the programming

mode and you will hear “Three Short Beeps”.

Step 1 Log on to programming mode,

see section 3.2 If you have logged on proceed to step 2.

Step 2 Enter Function Code 05 then

press #, you hear “One Short

Beep”.

Step 3 Enter • 01-98 hours to unlock

door or

• 99 hours to to unlock door for indefinite time or

• 00 hours to lock door

then press # you will hear “Two

Long Beeps” and “Two Short Beeps”.

Step 4 Select another Function Code to

program another parameter or tenant's directory, otherwise enter 91 then press # to disconnect the call, you hear “Three Short Beeps”.

NOT AVAILABLE.

FUNCTION CODE LOCAL PROGRAMMING TOUCH TONE PROGRAMMING

Pach and Company Chapter 3 Page 12 AeGIS 7000 Series PROGRAMMING

Select Func: _ _

OPEN: 00 HOURS

Select Func: _ _

DIR DIGITS: 3 _

SINGLE OR MULTI SYSTEMS

(Default setting is Single)

You must set the system to multi if more than one systems are installed using a single phone line. You can connect up to eight system on a single phone line.

It is not necessary to set the system to multi if separate phone is used for each system.

If system is set for multi, Function Code 75 (Key Press Beep) is disabled.

SYSTEM NUMBER

(Default Setting is

It is not necessary to set the system number if :

1. Remote touch-tone programming is not used.

2. Separate phone line is used for each system.

CHANGE THE

WELCOME

SCREEN

Welcome screen is divided into three segments. Each segment consists of 16 characters. The welcome screen can be a combination of letter and number.

Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 07 then press #, the

display shows:

Step 3 Enter • 1 for Single system or

• 0 for multi systems

then press # or press

to keep the existing one.

Step 4 Proceed to step 2 and select the same Function

Code or different Function Code to continue programming or press

to exit the programming

mode and you will hear “Three Short Beeps”.

Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 08 then press #, the

display shows:

Step 3 Enter the system number 1-8 then press # or

press

to keep the existing one.

Step 4 Proceed to step 2 and select the same Function

Code or different Function Code to continue programming or press

to exit the programming

mode and you will hear “Three Short Beeps”.

Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 10 then press #, the

display shows:

Step 3 Press

to erase the 1stsegment then enter the

welcome message then press # # to proceed to the 2ndsegment, the display shows:

NOT AVAILABLE.

FUNCTION CODE LOCAL PROGRAMMING TOUCH TONE PROGRAMMING

Pach and Company Chapter 3 Page 13 AeGIS 7000 Series PROGRAMMING

Select Func: _ _

SING=1, MULT=0: 1

Select Func: _ _

SYSTEM #

[1-8] 1

Select Func: _ _

Welcome to Pach’

1st segment

s Telephone Acce

SYSTEM

INFORMATION

Display the model number and the firmware released date.

CLEAR THE

MEMORY TO

FACTORY

DEFAULT

Use this Function Code will erase the whole database and and reset the system to factory default.

Step 4 Press *to erase the 2ndsegment then enter

the welcome message then press # # to proceed to the 3rdsegment, the display shows:

Step 5 Press

to erase the 3rdsegment then enter

the welcome message then press # #.

Step 6 Proceed to step 2 and select the same Function

Code or different Function Code to continue programming or press

to exit the programming

mode and you will hear “Three Short Beeps”.

Note: See keypad correlation on page 3.

Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 46 then press #, the

display shows:

XXX: the model number. MM/DD/YY: month, date, and year firmware

released.

Step3 Press

then proceed to step 2 and select the

same Function Code or different Function Code to continue programming or press *to exit the

programming mode and you will hear “Three

Short Beeps”.

Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 50 then press #, the

display shows:

Step 3 Press 1 to confirm the display shows:

and the system returns to Welcome Screen, or

to cancel and proceed to step 3.

Step4 Press

then proceed to step 2 and select the

same Function Code or different Function Code

NOT AVAILABLE.

FUNCTION CODE LOCAL PROGRAMMING TOUCH TONE PROGRAMMING

Pach and Company Chapter 3 Page 14 AeGIS 7000 Series PROGRAMMING

ss System . . . * *

Select Func: _ _

V7XXX MM/DD/YY

Select Func: _ _

1 to confirm: _

DB Init. Wait . . . _

CHANGE TALK

TIME

(Default setting is

seconds)

The talk time is the length of time the visitor can talk to the tenant. The talk time timer starts as soon as the system initiates the call.

CHANGE DOOR

OPEN INTERVAL

(Default setting is

12 seconds)

The Door Open Interval is the length of time the relay turns on.

CHANGE LOCK

OUT COUNT

(Default setting is

The system is disabled if invalid access code has been entered according to the lock out count sets on Function Code 72. The system will ignore further access code entries for 90 seconds.

to continue programming or press *to exit the programming mode and you will hear “Three

Short Beeps”. Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 70 then press #, the

display shows:

Step 3 Enter Talk Time Value in 3-digit mode (010 -

180) seconds the press #.

Step4 Press

then proceed to step 2 and select the

same Function Code or different Function Code to continue programming or press *to exit the

programming mode and you will hear “Three

Short Beeps”.

Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 71 then press #, the

display shows:

Step 3 Enter the Open Time value in 2-digit mode (04-

99) seconds then press #.

Step4 Press

then proceed to step 2 and select the

same Function Code or different Function Code to continue programming or press *to exit the

programming mode and you will hear “Three

Short Beeps”.

Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 72 then press #, the

display shows:

Step 3 Enter the lock out count in one-digit mode (1-9).

Step4 Press

then proceed to step 2 and select the

Step 1 Log on to programming mode,

see section 3.2 If you have logged on proceed to step 2.

Step 2 Enter Function Code 70 then

press #, you hear “One Short

Beep”.

Step 3 Enter the talk time in 3-digit mode

(10-180 seconds) and press # and you will hear “ Two Short

Beeps”.

Step 4 Select another Function Code to

program another parameter or tenant's directory, otherwise enter 91 then press # to disconnect the call, you hear “Three Short Beeps”.

Step 1 Log on to programming mode,

see section 3.2 If you have logged on proceed to step 2.

Step 2 Enter Function Code 71 then

press #, you hear “One Short

Beep”.

Step 3 Enter the Open Time value in 2-

digit mode (04-99) seconds then press # and you will hear “ Two

Short Beeps”.

Step 4 Select another Function Code to

program another parameter or tenant's directory, otherwise enter 91 then press # to disconnect the call, you hear “Three Short Beeps”.

Step 1 Log on to programming mode,

see section 3.2 If you have logged on proceed to step 2.

Step 2 Enter Function Code 72 then

press #, you hear “One Short

Beep”.

Step 3 Enter the Lock Out Count value in

one-digit (04-99) seconds then press # and you will hear “ Two

Short Beeps”.

Step 4 Select another Function Code to

FUNCTION CODE LOCAL PROGRAMMING TOUCH TONE PROGRAMMING

Pach and Company Chapter 3 Page 15 AeGIS 7000 Series PROGRAMMING

Select Func: _ _

TALK TIME: 060

Select Func: _ _

OPEN TIME: 12

Select Func: _ _

LOCK-OUT CNT: 3

SELECT TONE OR

PULSE DIALING

(Default setting is

tone)

If set to Tone: pulse phone can’t unlock the door by pressing 9.

If set to pulse: both tone and pulse phone can unlock the door by pressing 9.

ENABLE OR

DISABLE AUTO

ANSWER

(Default setting is

Enable)

If Enable, the system will answer an incoming call.

If disable, the system will not answer an incoming call.

This feature is useful if:

• Remote touch-tone

programming is used or

• For the tenant to call

the system in case the tenant is not available at the time the visitor call.

TURN ON OR OFF KEY PRESS BEEP

(Default setting is

ON)

If ON, the system beep if key is pressed.

If OFF, the system does not beep if the key is pressed.

If the system is set for Multi (see Function Code

07),

same Function Code or different Function Code to continue programming or press

to exit the

programming mode and you will hear “Three

Short Beeps”. Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 73 then press #, the

display shows:

Step 3 Enter 1 for Tone or 0 for Pulse then press #.

Step4 Press

then proceed to step 2 and select the

same Function Code or different Function Code to continue programming or press *to exit the

programming mode and you will hear “Three

Short Beeps”.

Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 74 then press #, the

display shows:

Step 3 Enter 1 to Enable or 0 to Disable, then press #.

Step4 Press

then proceed to step 2 and select the

same Function Code or different Function Code to continue programming or press *to exit the

programming mode and you will hear “Three

Short Beeps”.

Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 75 then press #, the

display shows:

Step 3 Enter 1 to turn ON key press beep or 0

turn OFF key press beep, then press #.

program another parameter or tenant's directory, otherwise enter 91 then press # to disconnect the call, you hear “Three Short Beeps”.

Step 1 Log on to programming mode,

see section 3.2 If you have logged on proceed to step 2.

Step 2 Enter Function Code 73 then

press #, you hear “One Short

Beep”.

Step 3 Enter 1 for Tone or 0 for Pulse

then press #, then press # and you will hear “ Two Short

Beeps”.

Step 4 Select another Function Code

to program another parameter or tenant's directory, otherwise enter 91 then press # to disconnect the call, you hear “Three Short Beeps”.

NOT AVAILABLE.

Step 1 Log on to programming mode,

see section 3.2 If you have logged on proceed to step 2.

Step 2 Enter Function Code 75 then

press #, you hear “One Short

Beep”.

Step 3 Enter 1 to turn ON key press

beep or 0 to turn OFF key press

beep then press #, then

press #and you will hear “Two Short Beeps”.

FUNCTION CODE LOCAL PROGRAMMING TOUCH TONE PROGRAMMING

Pach and Company Chapter 3 Page 16 AeGIS 7000 Series PROGRAMMING

Select Func: _ _

TONE=1 PULSE=0: 1

Select Func: _ _

Auto Answer=1 : 1

Select Func: _ _

BEEP On=1 OFF=0: 1

this function will be disabled

TURN ON OR OFF

SPEAKER BEEP

(Default setting is

ON)

If ON, the system beep if the door is unlocked.

If OFF, the system does not beep if the door is unlocked.

ENABLE REMOTE

ACCESS

(NOT APPLICABLE ON

NEWER SYSTEM)

(Default setting is

Enabled)

If Enable, the system will unlock the door if 9 is pressed.

If Disable, the system will not unlock the door if 9 is pressed.

VIEW DIRECTORY

BY NAME

This Function Code is very useful to find the tenant directory.

Step4 Press * then proceed to step 2 and select the

same Function Code or different Function Code to continue programming or press

to exit the

programming mode and you will hear “Three

Short Beeps”.

Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 76 then press #, the

display shows:

Step 3 Enter 1 to turn ON unlock beep or 0 to turn

OFF unlock beep, then press #.

Step4 Press

then proceed to step 2 and select the

same Function Code or different Function Code to continue programming or press *to exit the

programming mode and you will hear “Three

Short Beeps”.

Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 77 then press #, the

display shows:

Step 3 Enter 1 to Enable remote access or 0 to dis

able remote access, then press #.

Step4 Press

then proceed to step 2 and select the

same Function Code or different Function Code to continue programming or press *to exit the

programming mode and you will hear “Three

Short Beeps”.

Step 1 Log on to programming mode (see section 3.1),

the display shows:

Step 2 Enter Function Code 78 then press #, and the

name in alphabetical order shows on the display (press 3 to scroll A-Z or 6 to scroll Z-A).

Step 3 Press # to display the directory code.

Step 4 Select another Function Code to

program another parameter or tenant's directory, otherwise enter 91 then press # to disconnect the call, you hear “Three Short Beeps”.

Step 1 Log on to programming mode,

see section 3.2 If you have logged on proceed to step 2.

Step 2 Enter Function Code 76 then

press #, you hear “One Short

Beep”.

Step 3 Enter 1 to turn ON unlock beep

or 0 to turn OFF unlock beep, then press # and you will hear “

Two Short Beeps”.

Step 4 Select another Function Code

to program another parameter or tenant's directory, otherwise enter 91 then press # to disconnect the call, you hear “Three Short Beeps”.

NOT AVAILABLE ON NEWER

SYSTEM

NOT AVAILABLE.

FUNCTION CODE LOCAL PROGRAMMING TOUCH TONE PROGRAMMING

Pach and Company Chapter 3 Page 17 AeGIS 7000 Series PROGRAMMING

Select Func: _ _

UnlockBeep (1,0): 1

Select Func: _ _

ENA=1 DISA=0: 1

Select Func: _ _

EXIT FROM

REMOTE

PROGRAMMING

Step4 Press * then proceed to step 2 and select the

same Function Code or different Function Code to continue programming or press

to exit the

programming mode and you will hear “Three

Short Beeps”.

NOT AVAILABLE.

Press 91 then press # to disconnect the call, you hear “Three Short Beeps”.

FUNCTION CODE LOCAL PROGRAMMING TOUCH TONE PROGRAMMING

Pach and Company Chapter 3 Page 18 AeGIS 7000 Series PROGRAMMING

Chapter 4 SYSTEM’S OPERATION

Pach and Company Chapter 4 Page 19 AeGIS 7000 Series SYSTEM’S OPERATION

HOW TO VIEW THE TENANT NAME.

HOW TO INITIATE A CALL AND UNLOCK THE DOOR FOR VISITOR.

HOW TO EXTEND THE TALK TIME

HOW TO CALL INTO THE SYSTEM.

Two ways to view the tenant name:

1. Press 3 to scroll the tenant name from Ato Z.

2. Press 6 to scroll the tenant name from Z to A.

Two way to initiate a call:

1. USING THE SCROLLING ELECTRONIC DIRECTORY Step 1 Press 3 or 6 to scroll the tenant name, when the tenant name you are

intended to call is visible on the display, then press # to initiate the call. The display shows:

then it shows:

Step 2 Press

to cancel the call, otherwise wait for the tenant to answer your call.

Step 3 Tenant must press 9 to unlock the door.

2. A DIRECT CALL

You must know the tenant directory number to use a direct call. The tenant directory number can be associated with apartment number, suite number, etc..

Step 1 Press # and wait for a dial tone, the display shows:

Step 2 Press the 2, 3 or 4 digit directory number, the system will initiate the call.

Step 3 Press

to cancel the call, otherwise wait for the tenant to answer your call.

Step 4 Tenant must press 9 to unlock the door.

The talk time can be programmed from 10 - 180 seconds. You will hear “ One Long Beep” ten seconds before the talk time expires. The tenant must press #

immediately to extend the talk time to another cycle. For example: if the talk time is set for 30 seconds, pressing # will extend for another 30 seconds. You can continue pressing the # to extend the talk time after the “ One Long Beep”.

The AeGIS 7000 will accept an incoming call from tenant and tenant can talk to his or her visitor. Function Code 74 (Enable or Disable Auto Answer) must be set to 1. The feature is very useful if for some reason you are not available to answer the visitor call and you can call into the system later on. This feature is not available if multi systems are installed on a single phone line.

Step 1 Call the system ( you must know the phone number) then you hear “One Short

Beep” if the call is connected.

Step 2 Press

to talk to the visitor then press 9 to unlock the door or hang up.

WAIT . . . DIALING

Wait for Answer

DIR CODE:

HOW TO PROVIDE REMOTE ACCESS HOW TO DISABLE REMOTE ACCESS

HOW TO CALL TO A VOICE MAIL OR EXTENSION NUMBER

HOW TO USE THE 4DIGIT ACCESS CODE TO UNLOCK THE DOOR.

HOW TO ADJUST THE SPEAKER AND MICROPHONE VOLUME

HOW TO ADJUST THE LCD DISPLAY

HOW TO ADJUST THE PULSE SENSITIVITY

HOW TO CHECK THE NUMBER OF THE TENANTS PROGRAMMED IN THE SYSTEM.

Press 9 to unlock the door.

Function Code 77 is to disable remote access. Disabling remote access means disable number 9 from unlocking the door.

Press the voice mail or extension number after the call is connected.

The personal Access Code is used to unlock the door without using the key. It is not mandatory for the manager to provide a personal access code for each tenant. If you decide not to provide a personal access code to each tenants, all you have to do is to leave the Access Code Field blank when you program the tenant directory. See Function code 01.

Step 1 Press

and the screen stops scrolling then press the 4-digit access code.

The speaker volume and microphone are factory preset. The adjustment pot is VR2, see figure 2.1. Turn the speaker volume adjustment pot counter-clockwise to increase or clockwise to decrease the speaker volume. If you hear a "feedback" when you closed the panel door, decrease the speaker and microphone volume.

Turn the LCD Adjustment Pot ( VR3) clockwise to increase or counter-clockwise to decrease the intensity. See figure 2.1 to locate the LCD adjustment pot.

The Pulse sensitivity is factory preset. An adjustment is necessary if the system is in a dial tone mode (press # to get a dial tone) and the PULSE SENSITIVITY LED1 flashes or ON (see figure 2.1). If the PULSE SENSITIVITY IS TOO SENSITIVE, the system may unlock the door by itself without pressing 9. Follow the instruction below to adjust the pulse sensitivity:

Step 1 Apply power to the system and connect the phone line. Step 2 If the Pulse Sensitivity LED1 flashes or ON when the system is in dial tone

mode (press #), decrease the pulse sensitivity by turning the Pot adjustment (VR1) clockwise, otherwise proceed to step 3.

Step 3 If the Pulse Sensitivity LED1 does not flash or ON, press the keypad number

0-9 and the LED should be flashed every time the key number is pressed. If it does not flash, increase the sensitivity by turning the pot counter-clockwise.

You cannot program the tenant's directory more than the system capacity. An accurate tenant's record is essential. You must delete any unused tenant's directory to free the system's memory. If you program a tenant database without programming the tenant’s name, the system will not record it in the memory and you will not get an accurate number of tenant in the memory. You may check the total number of tenant in the system as follow:

Step 1 Log on to programming mode (see section 3.1), the display shows:

Step 2 Press * to exit, then the display shows:

XXX is the total number of tenant in the system.

Pach and Company Chapter 4 Page 20 AeGIS 7000 Series SYSTEM’S OPERATION

Select Func: _ _

Total Tnt: XXX

Chapter 5 TROUBLE SHOOTING GUIDE

NO AUDIO WHEN KEY(S) IS PRESSED

NO DIAL TONE WHEN THE # KEY IS PRESSED

THE VISITOR CAN'T HEAR THE TENANT FROM THE SYSTEM BUT THE TENANT CAN HEAR THE VISITOR

THE TENANT CAN'T HEAR THE VISITOR TALKING BUT THE VISITOR CAN HEAR THE TENANT

THE LIQUID CRYSTAL DISPLAY (LCD) SHOWS QUESTION MARKS (????)

THE LIQUID CRYSTAL DISPLAY (LCD) IS BLANK, NO DISPLAY AT ALL

• Check the speaker and microphone connection on the board. The snap on clip connector on the speaker and microphone connector must be facing inside the board.

• Check the red and orange wires, make sure they are soldered into the speaker.

• Turn the power "OFF" and disconnect the speaker connector from the board. Set your meter to Ohm and use 50 Ohm scale or higher. Put the two probes into the speaker (+) and (-) (polarity not important) and the meter should read between 19 - 24 Ohms.

• Check the phone line using a standard phone, make sure you get dial tone.

• Check the speaker and microphone connection. The snap on clip connector on the speaker and microphone connector must be facing inside the board.

• Check the red and orange wires, make sure they are soldered into the speaker.

• Turn the system's power "OFF" and disconnect the speaker connector from the board. Set your meter to Ohm and use 50 Ohm scale or higher. Put the two probes into the speaker (+) and (-) (polarity not important) and the meter should read between 19 - 24 Ohms.

• Check the speaker and microphone connection. The snap on clip connector on the speaker and microphone connector must be facing inside the board.

• Check the red and orange wires, make sure they are soldered into the speaker.

• Press the # key as soon as you hear a dial tone, tap your finger into the microphone and you should hear a finger tap sound from the speaker.

• Check the speaker and microphone connection. The snap on clip connector on the speaker and microphone connector must be facing inside the board.

• Check the brown and black wires, make sure they are soldered into the microphone.

• Turn the unit power "OFF" and "ON".

• Erase the memory chip (EEPROM) using Function Code 50. If you have trouble to log on to programming mode, press and release the square red button then press #.

• The power LED must be "ON" (LED2 marked on the board).

• The Power Switch's toggle must be on the left position ("ON").

• Check the fuse (3 Amp 250 Volt).

• Measure the voltage on AC1 and AC2 (set your voltmeter to AC and put the probes on AC1 and AC2), it should read within 12VAC-13.8VAC or if you use 12 VDC, the meter must read 13.5 - 14.0 VDC.

• The LCD's ribbon cable has red dots along the side. The red dots must be facing up. It must be connected to the terminal marked number 1.

Pach and Company Chapter 5 Page 21 AeGIS 7000 Series TROUBLE SHOOTING GUIDE

AUDIO PROBLEM S SOLUTIONS AND SUGGESTIONS

DISPLAY PROBLEM S SOLUTIONS AND SUGGESTIONS

THE LCD SHOWS EIGHT SQUARES OR UNDERLINES

THE VISITOR CAN'T PLACE A CALL TO A TENANT OR TENANTS

THE VISITOR HEARS A RADIO STATION ON THE AEGIS SYSTEM WHILE TALKING TO A TENANT

BOTH THE VISITOR AND TENANT HEAR STATIC WHILE THEY ARE TALKING

THE SOUND KEEPS GOING OUT WHILE THE TENANT AND VISITOR ARE TALKING

• The LCD's ribbon cable sits tight on the terminal pins marked LCD on the

board.

• The LCD's ribbon cable is connected into the LCD's terminal pins connector and the red dots along the side of the ribbon should be connected on pin 1.

• Adjust the LCD's intensity.

• Turn the system's power "OFF", wait for 15 seconds and turn it "ON".

• If the sunlight hits directly into the the LCD, block the sunlight. If the LCD is readable after you block the sunlight, you may have to move the system to a different location otherwise the system will collect heat and it may get damaged if the inside temperature reaches above 140 °F.

• If the display only fails when the outside temperature is below 32°F or 0°C, you may need to install a heater (AHP-5).

• If the system beep when the keypad is pressed, try to adjust the LCD’s intensity, if the LCD display is still blank. possibility the LCD is bad.

• The LCD's ribbon cable has red dots along the side. The red dots must be facing up and connected to pin 1.

• It must be connected to the terminal marked LCD on the board.

• The LCD's ribbon cable sits tight on the terminal pins marked LCD on the board.

• The LCD's ribbon cable is connected into the LCD's terminal pin connector and the red dots along the side of the ribbon should be connected on pin 1.

• Turn the system's power "OFF", wait for 15 seconds and turn it "ON".

• The input voltage to AC1 and AC2 should read within 12VAC-13.8VAC or if you use 12 VDC, the meter must read 13.5 - 14.0 VDC.

• If the display only fails when the outside temperature is below 32°F or 0°C, you may need to install a heater (AHP-5).

• Check if the problem occurs on all tenants.

• Disconnect the phone line from the AeGIS system and connect a standard phone into the phone line and try to place a call.

• Check the phone number on the system programming.

• Check the phone line and make sure the telephone terminal box is grounded.

• Check if the problem occurs on all tenants.

• Disconnect the phone line from the AeGIS system and connect a standard phone into the phone line and try to place a call.

• Check the grounding on the AeGIS system and telephone line. The Aegis's cabinet must be grounded to an earth ground. The telephone line shield must be grounded at the telephone terminal block, not on the AeGIS cabinet.

• Disconnect the ground wire (marked GND at the 5 pins terminal) from the board. If the problem still exists, install a Modular RFI Filter.

• Check if the problem occurs on all tenants.

• Disconnect the phone line from the AeGIS system and connect a standard phone into the phone line and try to place a call.

• The AeGIS 7000 does not have full-duplex speakerphone. If the AeGIS is installed in a noisy environment, you may experience with this problem.

• Both the visitor and tenant can't talk simultaneously.

• Try to speak a little further from the system

DISPLAY PROBLEMS SOLUTIONS AND SUGGESTIONS

Pach and Company Chapter 5 Page 22 AeGIS 7000 Series TROUBLE SHOOTING GUIDE

COMMUNICATION PROBLEMS SOLUTIONS AND SUGGESTIONS

The technical support team at Pach and Company are highly trained and committed to providing you with the best in support and repair services. Our Services are available between 7:30 AM - 4:30 PM Pacific Standard Time.

TOLL FREE (888) 678-7224.

THE GATE OR DOOR DOES NOT OPEN WHEN THE TENANT PRESSES NUMBER "9"

THE GATE OR DOOR DOES NOT OPEN WHEN THE TENANT PRESSES NUMBER "9"BUT IT OPENS USING THE PERSONAL ACCESS CODE

ALL OR SOME OF THE KEYPAD'S KEYS DO NOT WORK

• Check power on the gate operator or door strike.

• Check Function 77, it must be enabled.

• Check for loose connection on gate or door strike wires on RC1 and NO1 (if you use "Normally Open" gate or door strike) or RC1 and NC1 (if you use "Normally Close" gate or door strike) on the AeGIS system.

• Remove the two wires on RC1 and NO1 and short the two wires, the door or gate should open or remove the two wires on RC1 and NC1, the gate or door should open. If the door or gate does not open, you may have a problem with the gate or door strike.

• Test the relay and follow the steps below:

1. Set your multi-meter to Ohm (touch the two probes, the meter will read about 0 (zero value)

2. Connect the meter's probes to RC1 and NO1 (if "Normally Open" strike is used, the meter will read as an open circuit) or RC1 and NC1 (if "Normally Close" strike is used your meter will read about 0 value).

3. Place a call from the system to one of the tenants and tell the tenant to press "9" and you should get the following results:

• Your meter should read to about 0 value if RC1 and NO1 contacts are used, otherwise the system's relay is bad.

• Your meter should read as an open-circuit if RC1 and NC1contacts are used, otherwise the system's relay is bad.

• Try to call a few different tenants. If the problem precists, erase the system's memory to default (use function code 50).

• Call the Technical Support, you may have a bad board.

• The keypad's ribbon cable has red dots along the side, the red dots must be facing upward and connected to pin 1.

• Turn the power "OFF" and disconnect the keypad's ribbon cable from the board and reconnect it and turn the power "ON".

GATE PROBLEMS SOLUTIONS AND SUGGESTIONS

KEYPAD PROBLEMS SOLUTIONS AND SUGGESTIONS

Pach and Company Chapter 5 Page 23 AeGIS 7000 Series TROUBLE SHOOTING GUIDE

GENERAL FCC REQUIREMENTS

This equipment complies with Part 68 of the FCC rules. Located on the back of your AeGIS system is a label that contains, among other information, the FCC registration and ringer equivalence number (REN) for the system. Prior to installing your AeGIS system, please call your telephone company and provide them the FCC registration and REN numbers as well as the telephone number of the line to which you will connect the system.

Your AeGIS system connects to the telephone line by means of a standard jack called the USOC RJ11C. If this type of jack is not available at the location you want to install your AeGIS system, you will need to call your telephone company and order one.

Your AeGIS system connects to the Public Switching Telephone Network via standard-device telephone lines. IT SHOULD NOT BE CONNECTED TO "PARTY" OR "COIN SERVICE" LINES.

Should you have any questions about the telephone line you intend to connect your AeGIS system to, or other questions such as how many other devices you can connect to your telephone line, your telephone company will provide you upon request.

In the unlikely event your AeGIS system develops a problem, IMMEDIATELY DISCONNECT IT FROM YOUR TELEPHONE LINE to avoid harmful causes to the telephone network.

If repairs are ever needed on your AeGIS system, ONLY Pach and Company technician should perform them. Please contact our Toll Free Technical Service Department at 888-678-7224 for immediate assistance.

Should your telephone company determine that your AeGIS system developed a problem, they may notify you in advance that temporary discontinuance of service may be required. In some cases advance notice isn't practical, so your telephone company will notify you as soon as possible. You will also be advised by your telephone company of your right to file complaint with the FCC if you believe it necessary.

From time to time the Telephone Company may make changes to it's facilities equipment, operations, or procedures that could affect the operation of your AeGIS system. If this happens, the Telephone Company will provide advanced notice in order for you to make the necessary modifications to your AeGIS system to maintain uninterrupted service.

AeGIS 7000 SERIES QUICK REFERENCE GUIDE

1) PRESS 0 AND # SIMULTANEOUSLY THEN RELEASE, the display screen stops scrolling (If the display screen is still scrolling repeat this step again) then

enter the valid 4-digit Master Code (default Master Code: 0000). Now, you are in programming mode and see table below to continue.

2) IF YOU DO NOT HAVE A VALID MASTER CODE, open the panel (key must be used) then press and release the “RED BUTTON” on the board and the

display shows: x x x x: 4-digit Master Code, then press #. Now, you are in programming mode and see table below to continue.

1) SINGLE SYSTEM

Step 1 Call the AeGIS 7000. When the system answer you will hear: • One Short Beep: Door is opened; • Two Short Beeps: Door is closed.

Then Press # key

Step 2 Press your valid Master Code.

• If your Master Code is accepted, you will hear Two Short Beeps and now, you are in the programming mode and see table below to continue

• If your Master Code is rejected, the system will disconnect.

2) MULTI-SYSTEM IN SINGLE TELEPHONE LINE

Step 1 Call into the AeGIS 7000 using a touch tone phone. When the system answer

you will hear: • One Short Beep: Door is opened; • Two Short Beeps: Door is closed; • One Long Beep: Combination of Closed and open. Step 2 Press the System Number you want to log in (1-8) then press # key. Step 3 Press your valid Master Code.

• If your Master Code is accepted, you will hear Two Short Beeps and you are in the programming mode and see table below to continue.

• If your Master Code is rejected, the system will disconnect.

Step 4 Follow the next programming sections below to program the tenant database and parameter.

LOCAL PROGRAMMING

REMOTE TOUCH-TONE PROGRAMMING

SYSTEM’S OPERATION KEYPAD LAYOUT

TO PLACE A CALL FROM THE AeGIS 7000 SERIES: • Press 3 to scroll the tenant name from

A to Z. o r Press 6 to scroll the tenant name from Z to A, then press #. TO PLACE A DIRECT CALL: Press # , wait for a dial tone then press the 2, 3 or 4 digit directory number.

TO GRANT ACCESS TO VISITOR: Press 9 TO DISABLE REMOTE ACCESS: See Function Code 77. TO USE THE 4-DIGIT ACCESS CODE: Press*then the 4-digit code.

TO EXTEND THE TALK TIME: Tenant must press the # after the time-out warning beep, the talk

time will be extended to another cycle. TO CALL INTO THE AeGIS 7000 SERIES: Dial the AeGIS phone number, you hear “ONE SHORT BEEP” if you are connected then press*to communicate with the visitor and press 9 to

unlock the door.

See manual for more detail

FUNCTION CODE TABLE

CODE DESCRIPTION CODE DESCRIPTION

02 03 04

07 08

Exit the programming (local programming) or clear the existing field

To accept program. Replace System Master Code. Program a New Tenant.

Modify an Existing Tenant Directory. Delete an Existing Tenant Directory.

Clear All Tenant s Directory. Manual Lock (open) or Unlock (close) Door.

Selecting Directory Digits (2, 3, or 4-digit, default is 3-digit).

Single or Multi Systems (default is single). System Number (default is 1).

Edit Welcome Screen.

System Information.

Clear the Memory to Factory default. Change Talk Time (default is 60 seconds). Change Door Open Interval (default is 12 sec). Change Lock Out Count (default is 3 times). Select Tone and Pulse Dialing (default is tone). Enable or DIsable Auto Answer (default is enabled) Turn On or Off Key Press Beep (default is On). Turn On or Off Speaker Beep. (default is On). NO APPLICABLE ON NEWER SYSTEM

View Directory by Name. Exit from Remote Programming.

PACH & COMPANY AeGIS 7000, Aegis 7025, Aegis 7050, Aegis 7100, Aegis 7150 Installation And Programming Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
