Pablo Designs XPD1021 Specifications

LINK TABLE

DESCRIPTION

Link modernizes the classic pantograph task lamp,
incorporating the most advanced LED lighting technology
to date. Designed with a dual-purpose shade/handle, Link
seamlessly balances performance and style to satisfy
focused lighting needs in any environment. The wide range
of Link models include medium and small table, loor, clamp,
and wall mount options to accommodate all residential,
oice, and hospitality task lighting applications.

FIXTURE TYPE

Table

LIGHT SOURCE

(99x) High-output LED array

PRODUCT CODES

Link Medium Table (Silver): LINK MED TBL SLV
Link Medium Table (White): LINK MED TBL WHT
Link Medium Table (Black): LINK MED TBL BLK
Link Medium Table (Orange): LINK MED TBL ORG
Link Medium Table (Green): LINK MED TBL GRN
Link Small Table (Silver): LINK SML TBL SLV
Link Small Table (White): LINK SML TBL WHT
Link Small Table (Black): LINK SML TBL BLK
Link Small Table (Orange): LINK SML TBL ORG
Link Small Table (Green): LINK SML TBL GRN
Link USB (White) LINK USB
Link Small Surface Mount: Special order only
Link Medium Surface Mount: Special order only

FINISHES

LIGHT CONTROL

Rocker switch (high, low, o)

FEATURES

360° rotation at base
Full-range height adjustability
180° front to back head tilt
Advanced LED array eliminates multiple shadows
Ships lat-packed
OCC model available upon request

SPECIFICATIONS

Voltage: 120240V 5060Hz
Power Consumption: 7.5W

Color Temperature: 3000K
Luminosity: 350 Lumens
Luminaire eicacy: 47 Lumens/Watt
Color Rendition Index: 90 CRI
50K hour lifespan
Cable length: 8’ (244cm)
Global multi-plug adapter available
1 year warranty

CERTIFICATIONS

PACKAGING WEIGHT AND DIMENSIONS

Link Small: 3.05LBS 33’’ X 6.5’’ X 4.5’’

1.4KGS 84cm X 17cm X 11cm

Link Medium: 3.25LBS 33’’ X 6.5’’ X 4.5’’

1.5KGS 84cm X 17cm X 11cm

Link Table Base: 7.65LBS 12.5’’ X 12’’ X 4’’

3.5KGS 32cm X 30cm X 10cm

NOTES

Occupancy sensor model available upon request
Custom requests can be considered on volume orders
Link USB sold separately

WHITE SILVERBLACK

GREEN ORANGE

DIMENSIONS

13"

(33cm)

13"

(33cm)

7"

(18cm)

7.5"

(19cm)

LINK MEDIUM SURFACE MOUNT LINK SMALL SURFACE MOUNT

13"

(33cm)

13"

(33cm)

7"

(18cm)

SURFACE MOUNT AVAILABLE FOR .2-1.2” (.5-3cm)
AND 1.2-3” (3-7.6cm) WORKSURFACES

8.5"

(21.5cm)

(21.5cm)

8.5"

7"

(18cm)

7"

(18cm)

(48cm)

7.5"

(19cm)

19"

(48cm)

19"

8.5"

(21.5cm)

(21.5cm)

8.5"

1”

(2.5cm)

LINK USB PORT ADD-ONLINK MEDIUM TABLE LINK SMALL TABLE

2”

(5cm)

LINK CLAMP

DESCRIPTION

Link modernizes the classic pantograph task lamp,
incorporating the most advanced LED lighting technology
to date. Designed with a dual-purpose shade/handle, Link
seamlessly balances performance and style to satisfy
focused lighting needs in any environment. The wide range
of Link models include medium and small table, loor, clamp,
and wall mount options to accommodate all residential,
oice, and hospitality task lighting applications.

FIXTURE TYPE

Table

LIGHT SOURCE

(99x) High-output LED array

PRODUCT CODES

Link Medium Clamp (Silver): LINK MED CLP SLV
Link Medium Clamp (White): LINK MED CLP WHT
Link Medium Clamp (Black): LINK MED CLP BLK
Link Medium Clamp (Orange): LINK MED CLP ORG
Link Medium Clamp (Green): LINK MED CLP GRN
Link Small Clamp (Silver): LINK SML CLP SLV
Link Small Clamp (White): LINK SML CLP WHT
Link Small Clamp (Black): LINK SML CLP BLK
Link Small Clamp (Orange): LINK SML CLP ORG
Link Small Clamp (Green): LINK SML CLP GRN
Link USB (White) LINK USB
Link Small Surface Mount: Special order only
Link Medium Surface Mount: Special order only

FINISHES

LIGHT CONTROL

Rocker switch (high, low, o)

FEATURES

360° rotation at base
Full-range height adjustability
180° front to back head tilt
Advanced LED array eliminates multiple shadows
Hi-low dim control
Ships lat-packed
OCC model available upon request

SPECIFICATIONS

Voltage: 120240V 5060Hz
Power Consumption: 7.5W
Color Temperature: 3000K
Luminosity: 350 Lumens
Luminaire eicacy: 47 Lumens/Watt
Color Rendition Index: 90 CRI
50K hour lifespan
Cable length: 8’ (244cm)
Global multi-plug adapter available
1 year warranty

CERTIFICATIONS

PACKAGING WEIGHT AND DIMENSIONS

Link Clamp Small: 3.4LBS 33.5’’ X 7’’ X 4.5’’

1.5KGS 85cm X 18cm X 11cm

Link Clamp Medium: 3.6LBS 33’’ X 6.5’’ X 4.5’’

1.6KGS 84cm X 17cm X 11cm

DIMENSIONS

LINK MEDIUM CLAMP

13"

(33cm)

13"

(33cm)

7"

(18cm)

.5”-2.25”

(1.25-5.7cm)

3"

(8cm)

LINK MEDIUM SURFACE MOUNT

(33cm)

13"

(33cm)

(21.5cm)

13"

8.5"

(21.5cm)

8.5"

GREEN ORANGEWHITE SILVERBLACK

LINK SMALL CLAMP

19"

(48cm)

7"

(18cm)

.5”-2.25”

(1.25-5.7cm)

3"

(8cm)

LINK SMALL SURFACE MOUNT

19"

(48cm)

8.5"

(21.5cm)

(21.5cm)

8.5"

LINK USB PORT ADDON

1”

(2.5cm)

2”

(5cm)

NOTES

Occupancy sensor model available upon request
Custom requests can be considered on volume orders
Link USB sold separately

7"

(18cm)

SURFACE MOUNT AVAILABLE FOR .21.2” (.53cm)
AND 1.23” (37.6cm) WORKSURFACES

(18cm)

7"

LINK FLOOR

DESCRIPTION

Link modernizes the classic pantograph task lamp,
incorporating the most advanced LED lighting technology
to date. Designed with a dual-purpose shade/handle, Link
seamlessly balances performance and style to satisfy
focused lighting needs in any environment. The wide range
of Link models include medium and small table, loor, clamp,
and wall mount options to accommodate all residential,
oice, and hospitality task lighting applications.

FIXTURE TYPE

Floor

LIGHT SOURCE

(99x) High-output LED array

PRODUCT CODES

Link Medium Floor (Silver): LINK MED FLR SLV
Link Medium Floor (White): LINK MED FLR WHT
Link Medium Floor (Black): LINK MED FLR BLK
Link Medium Floor (Orange): LINK MED FLR ORG
Link Medium Floor (Green): LINK MED FLR GRN
Link Small Floor (Silver): LINK SML FLR SLV
Link Small Floor (White): LINK SML FLR WHT
Link Small Floor (Black): LINK SML FLR BLK
Link Small Floor (Orange): LINK SML FLR ORG
Link Small Floor (Green): LINK SML FLR GRN
Link USB (White) LINK USB

LIGHT CONTROL

Rocker switch (high, low, o)

FEATURES

360° rotation at base
Full-range height adjustability
180° front to back head tilt
Advanced LED array eliminates multiple shadows
Ships lat-packed
OCC model available upon request

SPECIFICATIONS

Voltage: 120240V 5060Hz
Power Consumption: 7.5W
Color Temperature: 3000K
Luminosity: 350 Lumens
Luminaire eicacy:47 Lumens/Watt
Color Rendition Index: 90 CRI
50K hour lifespan
Cable length: 8’ (244cm)
Global multi-plug adapter available
1 year warranty

CERTIFICATIONS

PACKAGING WEIGHT AND DIMENSIONS

Link Small: 3.05LBS 33’’ X 6.5’’ X 4.5’’

1.4KGS 84cm X 17cm X 11cm

Link Medium: 3.25LBS 33’’ X 6.5’’ X 4.5’’

1.5KGS 84cm X 17cm X 11cm

Link Floor Base: 10.1LBS 12.5’’ X 12’’ X 1.5’’

4.6KGS 32cm X 30cm X 4cm

FINISHES

GREEN ORANGEWHITE SILVERBLACK

DIMENSIONS

LINK MEDIUM FLOOR LINK SMALL FLOOR

13"

(33cm)

38"

(96.5cm)

13"

(33cm)

8.5"

(21.5cm)

38"

(96.5cm)

19"

(48cm)

8.5"

(21.5cm)

LINK USB PORT ADD-ON

1”

(2.5cm)

2”

(5cm)

NOTES

Occupancy sensor model available upon request
Custom requests can be considered on volume orders

Link USB sold separately

9.5"

(24.5cm)

9.5"

(24.5cm)

LINK WALL

DESCRIPTION

Link modernizes the classic pantograph task lamp,
incorporating the most advanced LED lighting technology
to date. Designed with a dual-purpose shade/handle, Link
seamlessly balances performance and style to satisfy
focused lighting needs in any environment. The wide range
of Link models include medium and small table, loor, clamp,
and wall mount options to accommodate all residential,
oice, and hospitality task lighting applications.

FIXTURE TYPE

Wall

LIGHT SOURCE

(99x) High-output LED array

PRODUCT CODES

Link Medium Wall (Silver): LINK MED WAL SLV
Link Medium Wall (White): LINK MED WAL WHT
Link Medium Wall (Black): LINK MED WAL BLK
Link Medium Wall (Orange): LINK MED WAL ORG
Link Medium Wall (Green): LINK MED WAL GRN
Link Small Wall (Silver): LINK SML WAL SLV
Link Small Wall (White): LINK SML WAL WHT
Link Small Wall (Black): LINK SML WAL BLK
Link Small Wall (Orange): LINK SML WAL ORG
Link Small Wall (Green): LINK SML WAL GRN
Link USB (White) LINK USB

LIGHT CONTROL

Rocker switch (high, low, o)

FEATURES

180° rotation at base
Full-range height adjustability
180° front to back head tilt
Advanced LED array eliminates multiple shadows
Ships lat-packed
OCC model available upon request

SPECIFICATIONS

Voltage: 120240V 5060Hz
Power Consumption: 7.5W
Color Temperature: 3000K
Luminosity: 350 Lumens
Luminaire eicacy: 47 Lumens/Watt
Color Rendition Index: 90 CRI
50K hour lifespan
Cable length: 8’ (244cm)
Global multi-plug adapter available
1 year warranty

CERTIFICATIONS

PACKAGING WEIGHT AND DIMENSIONS

Link Wall Small: 3.4LBS 33.5’’ X 7’’ X 4.5’’

1.5KGS 85cm X 18cm X 11cm

Link Wall Medium: 3.6LBS 33’’ X 6.5’’ X 4.5’’

1.6KGS 84cm X 17cm X 11cm

FINISHES

GREEN ORANGEWHITE SILVERBLACK

DIMENSIONS

LINK MEDIUM WALL LINK SMALL WALL

13”

(33cm)

13"

(33cm)

7"

(18cm)

2"

(4cm)

LINK USB PORT ADD-ON

8.5"

(21.5cm)

7"

(18cm)

2"

(4cm)

19"

(48cm)

8.5"

(21.5cm)

NOTES

Occupancy sensor model available upon request
Custom requests can be considered on volume orders

Link USB sold separately

1”

(2.5cm)

2”

(5cm)
