Ozmo OZMO2000WM014B User Manual

User Guide

OZMO2000WM014B Wireless Module

APP-AN-V1.1 – July 2012

User guide

1 General Description

The OZMO2000WM014 Wireless Module is a fully assembled and tested generalpurpose module using the OZMO2000 wireless System-on-Chip (SoC). The module contains the OZMO2000 chip, memory, antenna, and all other necessary components to operate the OZMO2000.

The memory is preloaded with firmware that is compatible with Windows 7 SoftAP or WiFi CERTIFIED™ Wi-Fi Direct host systems.

With modified firmware, the OZMO2000 can support other interfaces, such as I2C and GPIO. Contact your Ozmo FAE for assistance with these interfaces.

For detailed information on the OZMO2000 component itself, refer to the OZMO2000 datasheet.

2 Features

Small, self-contained SMT module On-board memory stores OZMO2000

program image, MAC address and security credentials

On-chip regulators allow direct connection to battery or unregulated supply between 1.8V and 3.6V. ( certain limitations may apply depending on module version )

Total module height is 4mm

3 Benefits

On-board 8051 processor eliminates need for external micro-controller.

Flexible application interfaces included: I2C, PCM/I2S, GPIOs, LED drivers with PWM.

Great battery life thanks to low power radio and systems design.

Low latency thanks to agile systems architecture and fast wake up algorithms.

Page 1 of 11

OZMO2000WM014 Module User Guide

4 Table of Contents

OZMO2000WM014 Wireless Module .............................................................................................. 1

User guide ....................................................................................................................................... 1

1 General Description ................................................................................................................ 1

2 Features .................................................................................................................................. 1

3 Benefits ................................................................................................................................... 1

4 Table of Contents .................................................................................................................... 2

5 Applications information .......................................................................................................... 3

5.1 Application Diagram......................................................................................................... 3

5.2 Using the module ............................................................................................................. 3

6 Pinout / Pin Description ........................................................................................................... 4

6.1 Module Pinout .................................................................................................................. 4

7 Electrical Characteristics ......................................................................................................... 6

7.1 Absolute Maximum Ratings ............................................................................................. 6

7.2 Recommended Operating Conditions ............................................................................. 6

7.3 Terminal Characteristics .................................................................................................. 7

7.4 Radio Characteristics....................................................................................................... 7

7.4.1 Radio Frequencies ................................................................................................... 7

7.4.2 Transmitter ............................................................................................................... 7

7.5 ESD Caution Notice ......................................................................................................... 8

8 Module Floorplan .................................................................................................................... 8

9 Ordering Information ............................................................................................................... 8

10 Regulatory notes ..................................................................................................................... 9

10.1 FCC ID ........................................................................................................................... 10

Page 2 of 11

OZMO2000WM014 Module User Guide

5 Applications information

5.1 Application Diagram

Figure 1 Application Diagram

5.2 Using the module

The WM014 module is designed to operate with customized embedded firmware programmed into the module by Ozmo Devices which controls the functioning of the radio and the various interfaces.

The General Purpose Input-Output pins (referred to as AIO or GPIO pins) are configured and monitored by the firmware.

Depending on the programmed functionality, the module will send data over the wireless link corresponding to the inputs received on the AIO pins, or will output digital signals from the AIO pins based on data received over the wireless link.

Ozmo application engineers will work with customers to define the desired Input-Output behavior and develop the customized firmware to achieve the desired digital input-output behavior. This has no effect on the radio operation which is defined by low-level firmware and hardware and always operates in accordance with FCC and Wi-Fi standards. The custom aspects of the firmware only affect the formatting and timing of the back-end digital I/O functions.

Page 3 of 11

OZMO2000WM014 Module User Guide

Pin #

MD Module Pin

name

MD Pin

Description

PD Module Pin

name

PD Pin

Description

VBATT

Power supply

VBATT

Power supply

GND

NC 4 NC

NC 5 NC

NC 6 NC

/RESET

Ozmo chip

reset

/RESET

Ozmo chip

reset 8 NC

NC 9 NC

6 Pinout / Pin Description

6.1 Module Pinout

The table below described the pinout and pin descriptions of the module in the default configuration. Pins are numbered 1 to 25 beginning on the left looking at the module from above with the antenna end oriented upward and the row of pins at the bottom

Figure 2 Module Pinout (Top View)

Page 4 of 11

OZMO2000WM014 Module User Guide

Pin #

MD Module Pin

name

MD Pin

Description

PD Module Pin

name

PD Pin

Description

AIO04 (SDA)

I2C Data

AIO4 (SDA)

I2C Data

AIO03 (SCL)

I2C Clock

AIO3 (SCL)

I2C Clock

AIO0 (LED1)

GPIO 16mA

AIO0 (LED1)

GPIO 16mA

AIO01 (LED2)

GPIO 16mA

AIO1 (LED2)

GPIO 16mA

AIO07 (I:Pair)

Input from

pairing button

on Master

system, initiates

pairing

procedure.

AIO14 (O:DAC

Reset)

Output to

control

peripheral

function such

as Reset the

DAC

AIO13

GPIO

AIO13

GPIO

AUDIOCLK

Audio clock

output

AUDIOCLK

Audio clock

output

AIO07 (O:MUTE)

Output to control a

Peripheral

function (such

as mute the

amplifier)

AIO15 (I:GPIO)

GPIO

AIO15 (O:/STBY)

Output to

control a

Peripheral

function (such

as place codec

in standby)

AIO12 (FSYNC)

Audio In Frame

Sync (I2S

Slave)

AIO9 (FSYNC)

Audio Out Frame Sync (I2S Master)

AIO14

(I:/ADCSTBY)

Input indicating

system status

such as power

state

GND

AIO11 (I:PCMIN)

Audio data

input

AIO10

(O:PCMOUT)

Audio data

output

AIO8 (I:PCMCLK)

Audio clock

AIO8 (I:PCMCLK)

Audio clock

Page 5 of 11

OZMO2000WM014 Module User Guide

Pin #

MD Module Pin

name

MD Pin

Description

PD Module Pin

name

PD Pin

Description

GND

AIO12 (I:PAIRING/)

Input from

pairing button on Peripheral

Parameter

Min

Max

Units

Storage temperature

-40

+125

°C

Supply voltage: V

BATT

-0.3

3.6 V GND

-0.3

0.3 V Supply voltage: Digital I/O pins

-0.3

VBATT + 0.3

RF Input Power

+10

dBm

Parameter

Min

Typ

Max

Units

Operating temperature

0 +70

°C

Supply voltage: V

BATT

(1)

2.7 3.6

GND

Figure 3 Module Pinout and Pin Descriptions

7 Electrical Characteristics

7.1 Absolute Maximum Ratings

Note: Supply voltage is dependent on ordering option. The on-module flash memory chip can be either a low-voltage or high-voltage type. The default option is for the high voltage type, supply voltage 2.7 to 3.6V.

7.2 Recommended Operating Conditions

(1)

Additional limitations may apply. See ordering information for more detail.

Page 6 of 11

OZMO2000WM014 Module User Guide

Parameter

Conditions

Min

Typ

Max

Units

VIL, input logic low

1.8 < V

BATT

< 1.95

- 0.3V

BATT

VIH, input logic high

1.8 < V

BATT

< 1.95

0.7V

BATT

- V

ΔV, input hysteresis

0.4 V

II, input resistance

Pull-up resistor to V

BATT

42 KΩ

VOL, output logic low

= 8 mA (AIO[15:3],

TDO, TSTSEL1, AUXO

0.2 V

BATT

VOL, output logic low

=16 mA (AIO[2:0])

0.2 V

BATT

VOH, output logic high

= 8 mA (AIO[15:03,

TDO, AUX0)

0.8 V

BATT

VOH, output logic high

= 16 mA (AIO[2:0])

0.8 V

BATT

IOZ, output tri-state current

0.0 V < V0 < 3.6 V

-10 10

μA

CI, input capacitance

5 pF

CIO, input / output capacitance

5 pF

7.3 Terminal Characteristics

7.4 Radio Characteristics

7.4.1 Radio Frequencies

This module operates on standard Wi-Fi channels within the 5.15GHz to 5.825GHz bands (limited to 5180-5240MHz and 5745-5825MHz for operation in the US). Ozmo Devices will program the module with firmware which automatically selects the channel according to the designated application requirements established with the customer.

7.4.2 Transmitter

The WM014 module is designed to operate at firmware-controlled transmit power power levels. The module has been FCC certified at the maximum transmit power settings of +5dBm (5.150GHz band) and +1 dBm (5.8GHz band). Firmware may be provided to customers which configures the device at lower transmit power levels to achieve longer battery life, but it is not possible to operate this module at any higher power levels than those used during the certification testing.

Page 7 of 11

OZMO2000WM014 Module User Guide

36.3 mm

7.5 ESD Caution Notice

ESD (Electrostatic Discharge) can damage this device. Ozmo, Inc. recommends that all integrated circuits be handled and stored using appropriate ESD precautions. Failure to observe proper procedures can cause ESD damage ranging from performance degradation to complete device failure.

8 Module Floorplan

The diagram below shows the floorplan and dimensions of the OZMO2000WM014 Wireless Module.

Figure 4 Floorplan of the OZMO2000WM014 Wireless Module

The WM014 module is designed to be mounted to the end-equipment printed circuit board (pcb) either as a card inserted in a slot or laid flat and soldered as a surface mount component. In the latter case standard surface-mount technology (SMT) circuit construction procedures should be followed. For inserting in a slot the pcb is 0.045” thick so the slot should be sized accordingly.

9 Ordering Information

The OZMO2000WM014 wireless module is made available in the following options:

Page 8 of 11

OZMO2000WM014 Module User Guide

Order number

Description

OZMO2000WM014-BMH-1321

WM014 Master Device(MD) module: (intended for the master device such as audio base station or TV Soundbar).

Single cabled FPC antenna soldered to the module pcb, referred to as “WM014B1”

OZMO2000WM014-BPH-2321

WM014 Peripheral Device(PD) module: (intended for the peripheral device such as cordless headphones or wireless sub-woofer)

Dual antenna, one cabled FPC soldered to the pcb and one a pcb trace antenna, referred to as “WM014B2”

Contact your Ozmo sales representative or FAE with further questions or to confirm availability.

10 Regulatory notes

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:

- Reorient or relocate the receiving antenna by moving the end equipment.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help. FCC Caution: To assure continued compliance, (example - use only shielded interface cables

when connecting to computer or peripheral devices). Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

IMPORTANT NOTE: FCC & IC Radiation Exposure Statement:

Page 9 of 11

OZMO2000WM014 Module User Guide

This equipment complies with FCC & IC radiation exposure limits set forth for an uncontrolled environment.

This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This device is intended only for OEM integrators under the following conditions:

- The transmitter module may not be co-located with any other transmitter or antenna. As long as the condition above is met, further transmitter test will not be required. However, The

OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.).

IMPORTANT NOTE: In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the FCC & IC authorizations are no longer considered valid and the FCC & IC IDs cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining separate FCC & IC authorizations.

Indoor usage for 5.2GHz Important note:

Section 15.407(e) of the FCC Rules states that 5.15 – 5.25 GHZ band UNII devices are restricted to indoor operations.

If the device is configured for those frequencies, the usage of the device must be restricted to indoor applications.

End Product Labeling

The final end product must be labeled in a visible area with the corresponding FCC ID number. Similar to: “Contains Transmitter Module FCC ID: EFU-OZMO-WM014-B1”

Manual Information That Must be Included

The user’s manual for end users must include the following information in a prominent location.

Warning: modifications of the product not approved by the manufacturer can void the user’s authority to operate the device

The end product using this module must be labeled with the FCC 2part statement

“This device complies with FCC Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause

undesired operation.” This statement can be placed in the user’s manual if the product is too small.

10.1 FCC ID

This module product has been tested to meet FCC requirements for unlicensed devices and the FCC ID is: EFU-OZMO-WM014-B1

Page 10 of 11

OZMO2000WM014 Module User Guide

Example label:

Since this module will be embedded inside other equipment such as consumer audio products, or peripherals like game controllers, that equipment should be marked with a label as follows:

“Contains Transmitter Module FCC ID: EFU-OZMO-WM014-B1”

Document revision history:

1.0 7/2/2012 Initial release

1.1 7/30/2012 Modified part number section

Page 11 of 11
