B I O - F U E L F I R E P L A C E S

User Information and Instruction Manual

www.ozflame.com.au

27 Rosalie Street, Springvale VIC 3171 Australia

t: [phone] f: [phone] e: sales@thermofilm.com.au

www.thermofilm.com.au www.ozflame.com.au

27 Rosalie Street, Springvale VIC 3171 Australia

t: [phone] f: [phone] e: sales@thermofilm.com.au
www.thermofilm.com.au www.ozflame.com.au

Model Codes and Descriptions

OZF 100 Series

OZF 100B / OZF 100W

Floor mount, free standing indoor with mantle and 5L fire box
830H x 830L x 390Dmm
Solid timber with gloss 2 pack paint finish, stainless steel side inserts,
tempered glass

OZF 105B / OZF 105W

Floor mount, free standing indoor with open top and 5L fire box
800 x 770L x 360Dmm
Solid timber with gloss 2 pack paint finish, stainless steel side inserts,
tempered glass

OZF 200 Series

OZF 200

Floor mount, free standing indoor and outdoor with 5L fire box
490H x 700L x 450Dmm
Stainless steel, tempered glass

OZF 210B / OZF 210W

Floor mount, free standing indoor and outdoor with 1.8L fire box
650H x 400L x 400Dmm
Powder coated steel, tempered glass

OZF 220B / OZF 220SS

Floor mount, free standing indoor and outdoor with 1.8L fire box
600H x 355L x 365Dmm
Powder coated steel, tempered glass (220B) / stainless steel,
tempered glass (220SS)

OZF 240B

Floor mount, free standing pedestal indoor and outdoor with

1.8L fire box
1160H x 440L x 440Dmm
Powder coated steel, tempered glass

OZF 250

Fireplace insert with 3L fire box
420H x 450L x 290Dmm
Powder coated steel, tempered glass

B I O - F U E L F I R E P L A C E S

OZF 400 Series

OZF 400

Wall / recess mount, indoor and outdoor with 1.8L fire box
550H x 1100L x 180Dmm
Stainless steel fascia, powder coated steel casing

OZF 450

Wall mount, indoor and outdoor with 3L fire box
400H x 780L x 290Dmm
Powder coated steel, tempered glass

OZF 500 Series

OZF 502

1.8L fire box, stainless steel

70H x 240L x 120Dmm

OZF 503

3L fire box, stainless steel, sqaure
80H x 205L x 205Dmm

OZF 503L

3L fire box, stainless steel, rectanglar

80H x 240L x 150Dmm

OZF 505

5L fire box, stainless steel
90H x 280L x 240Dmm

OZF 550

Stainless steel funnel to suit all fire boxes

27 Rosalie Street, Springvale VIC 3171 Australia

t: [phone] f: [phone] e: sales@thermofilm.com.au
www.thermofilm.com.au www.ozflame.com.au

Please read these instructions prior to
using your Ozflame™bio-fuel fireplace

Warnings

Bio-fuel (Methylated Spirits) is highly inflammable.

Handle the fuel with extreme caution and follow
all instructions carefully.

If possible, fill your burner in an outside location where
spillage will not be a hazard. Always use a funnel to
prevent spillage. An Ozflame™ model OZF 550 funnel
is recommended. In the event of spillage, wipe up all spilt
fuel and allow time for any excess fuel to evaporate before
lighting.

Only use bio-fuel (methylated spirits) in your burner. Store
your bio-fuel in a safe, ventilated, dry area away from the
fire and out of reach of children. Never smoke near burner
or fireplace. Do not put any foreign objects in the fireplace
particularly cigarette butts. Always store bio-fuel in a sealed
container designed for this purpose.

Do not ingest bio-fuel. If ingested or splashed in eyes, seek immediate medical attention. If fuel is spilt
on skin, wash off with soapy water.

First aid – For advice contact a doctor or Poisons information centre ­Australia phone [phone]

Do not add fuel while the fire is lit or the fire box is hot
and allow

at least 30 minutes

before adding fuel. Never
move the fire box or fireplace while the fire is lit. Do not
smoke while handling the fuel.

When lit, the fire box and surrounding area of the fireplace
will be hot. Do not touch these areas while fire is lit or for 30
minutes or more after the fire is extinguished. Also note that
when first lit or the fuel is running low the flame may not be
easily visible and caution is required.

5L1.8/3L

Wall

Ceiling

Fabric/Curtains

40cm1m

1.5m

5L1.8/3L

Never move a lit

fireplace or burner

No smoking near

the burner or fireplace

Wall

Ceiling

1.5m

FUEL

Always use a funnel

to fill the burner

B I O - F U E L F I R E P L A C E S

Children, animals and infirm persons should not be left
unattended near the fireplace when lit. Only adults who
have read instructions and are familiar with procedures
should add fuel or light or extinguish the fire.

Never place the burner or fireplace near flammable
objects such as clothing, curtains etc, or other flammable
materials etc. The following clearances are recommended
– 1 metre from any fabric (curtains etc) or flammable
material, 1.5 metres from ceilings, 40 cm from walls
(unless fireplace is designed to go against a wall or is wall
mounted). Models OZF100 & OZF105 are designed
for free-standing, indoor applications and can be located
against a wall.

As the fireplace consumes oxygen, there is a danger of suffocation, so the fireplace should be located
in a suitably sized room with adequate oxygen supply and fresh air. The first signs of lack of oxygen are
sudden fatigue and an impaired ability to concentrate.

Wall

Ceiling

Fabric/Curtains

40cm1m

1.5m

Recommended

clearance

For burners up to 3 litres in

size, room size should be a minimum of 35m

3

.

For burners over 3 litres in size,

the room size should be a minimum of 70m

3

.

Wall

Ceiling

40cm1m

1.5m

5L

MINIMUM 70m

3

Wall

Ceiling

Fabric/Curtains

40cm1m

1.5m

5L

1.8/3L

MINIMUM 35m

3

27 Rosalie Street, Springvale VIC 3171 Australia

t: [phone] f: [phone] e: sales@thermofilm.com.au
www.thermofilm.com.au www.ozflame.com.au

It is important that there is adequate ventilation
while the fireplace is in operation. It is
recommended that either an outside window is left
slightly open or a door to an adjacent area is left
ajar whilst the fireplace is operating.

When used in outdoor or high draft locations, the
flame will become more erratic and extra caution
should be taken. Under these circumstances a
greater clearance area may be required. Also note
fuel consumption will be higher. Never blow onto
the naked flames.

A fire extinguisher and safety fire blanket should be kept close at hand for emergency use,
if required. In the event a fire occurs, alcohol resistant foam or carbon dioxide are suitable
extinguishing agents. Do not use water to put out the flames.

Fireplace location

Depending on your Ozflame™ model, the fireplace should be located in an appropriate position
where the fire will operate safely. Do not locate the fireplace near flammable materials such as
curtains. Read the warning section and allow the appropriate recommended clearances. Indoor
models can be operated in undercover outdoor locations but should not be left outdoors.
Outdoor models should be kept undercover when not in use. Your fireplace should be operated
in a well ventilated space at all times. Do not leave your fireplace unattended at any time.

FIRE

BLANKET

FIRE

EXTINGUISHER

In an emergency extinguish flames

with fire extinguisher or fire blancket

Do not extinguish
flames with water

Do not blow

on naked flames

B I O - F U E L F I R E P L A C E S

Fuel

Only Bio ethanol (methylated spirits) with at least 95% alcohol content should be used.
The container should be marked with the international standard “Ethanol Solution UN 1170”.
This can be purchased from hardware stores, supermarkets etc in one, four and twenty litre
containers. The one litre containers are the easiest to use.

FIRST AID

– For advice, contact a doctor or poisons information centre

(Australia phone [phone]).

Filling the burner

We recommend that you remove the burner from the fireplace and fill it outdoors, to reduce
any spillage hazard. Fill the burner in the fireplace using a funnel. We recommend you use an
Ozflame™ funnel which is purpose designed to fit in all burner models and will make filling much
easier and safer. The funnel can be purchased as an accessory code OZF 550

Important:

• Fill the burner to a minimum of 1/3 capacity and a maximum of 2/3 full.

• Do not completely fill the burner.

• Do not fill the burner while it is still hot.

• Clean up all spillage before lighting.

27 Rosalie Street, Springvale VIC 3171 Australia

t: [phone] f: [phone] e: sales@thermofilm.com.au
www.thermofilm.com.au www.ozflame.com.au

Lighting the burner

Dip the slider handle into the fuel in the burner, remove it from the burner and holding it at arms
length, light the fuel on the handle, then lower it into the burner.

Do not position your face or

body above the burner when lighting. Do not light the burner directly with a cigarette lighter or

equivalent device.

We recommend you burn all the fuel in the burner rather than close the slider before all fuel is
used. Fuel level must be a minimum of 1/3 full before lighting.

For models with glass fitted on 4 sides, we recommend removing the front piece of glass while lighting
the flame to make it an easier and safer process. Add the piece of glass to the front of the fireplace
immediately after lighting the burner. After initial lighting of the burner, the flame may start as a small,
blue flame, however within several minutes it will increase to normal size and colour.

Dip slider handle into
the fuel in the burner

dip slider handle into the

fuel in the burner

holding at arms length, facing

downwards, light the fuel slider handle

do not position face or body

above burner when lighting

B I O - F U E L F I R E P L A C E S

Flame regulation and turning off

All models have a slide on the burner which can be opened or closed with the handle provided. The
slide will allow you to regulate the flame height which will also regulate fuel consumption. As with
lighting the fire, always operate the slide at arms length and do not position your head or body over
the burner.

Once the flame is out, do not open the burner for at least 30 minutes and do not
attempt to refill the burner until it has cooled down to room temperature.

Ideally allow the fuel to completely burn out and in this case it is not necessary to close the burner
when the flame is out. After several hours of burning, the burner slide may expand and become
slightly stiff to close. In this case, push the slide firmly and quickly and it will extinguish the flame. Make
sure there are no flames around the edges of the slide. If this occurs, push the slide firmly and quickly
closed again to extinguish all flames.

Maintenance

A small amount of carbon may form on the burner and this can be wiped off with a damp cloth. The
stainless steel burner and other stainless steel components should be cleaned with a good quality
stainless steel cleaning product such as 3M spray-on stainless steel cleaner. Note: after some use, the
heat generated by the flame may cause some discolouration of the stainless steel burner. If your
fireplace includes glass use a glass cleaner such as Windex. For the OZF 100 series fireplaces that have
a gloss enamel paint finish, use a good quality furniture polish such as Mr Sheen.

To turn off the flame, close the slide completely using the handle provided.

27 Rosalie Street, Springvale VIC 3171 Australia

t: [phone] f: [phone] e: sales@thermofilm.com.au
www.thermofilm.com.au www.ozflame.com.au

Warranty

Ozflame™ models have a ONE YEAR WARRANTY*.

Thermofilm warrants that OzflameTM products will be free from defects in materials and
workmanship for a period of 12 months from the date of purchase.

To claim for Warranty, please retain your receipt as proof of purchase and return the fireplace to
the place of purchase.

Warranty does not apply to products which have been misused or used in conditions other than
those for which they were intended for. Nor will it apply in the event of damage or accident
resulting from negligence, lack of care or maintenance, or if the fireplace has been modified in
any way.

Glass breakage is not included in the warranty. Due to the high temparatures generated by the
fireplace, discoloration of the stainless steel, glass and metal components may be expected. This is
not covered by warranty.

Thermofilm Australia Pty Ltd reserve the right to reject any Warranty claim deemed to be false.

Retailers must have Warranty claims authorised by Thermofilm Australia. Ph 03 9562 3455

*

Conditions apply. Please refer the Thermofilm standard terms of sale and warranty for details.

Thermofilm Australia

THERMOFILM AUSTRALIA is an Australian owned company specialising in innovative and energy
efficient heating and alfresco products.
Please visit www.thermofilm.com.au for more information.

B i o - F u e l F i r e p l a c e s

27 Rosalie Street, Springvale VIC 3171 Australia

t: [phone] f: [phone] e: sales@thermofilm.com.au

www.thermofilm.com.au www.ozflame.com.au
