Page 1
SPECIFICATION SHEET
PREMIER
Our Premier self-contained, portable, hot water,
handwashing sink is redefi ning what it means to be
that model citizen. NSF-certifi ed, code compliance
doesn’t need to be complicated and this out-of-thebox-ready, versatile sink keeps things simple without
sacrifi cing style. Its compact size is adaptable to all
industries, employing a minimal footprint in those highfootprint workspaces.
A one-piece, integrated ABS black countertop,
splashguard, and single sink basin with top-fi ll soap
dispenser is all you’ll need for point-of-contact
handwashing. Your quick-connect tanks are locked away
behind black, cherry, or maple woodgrain cabinets,
allowing you to mix and match this model to fi t your
specifi c work environment.
251/2" 171/2"
/2"
/2"
1
1
37
40
ADSTM-AB-AB1N
Model Name
NSF Certifi ed
LivingGreen Certifi ed
SACERS Rating
CARB 93120 Phase 2
Electrical Requirements
On-Demand Hot Water
GPM
Approx Handwashings
Product Dimensions
Product Weight
Basin
Basin Dimensions
Countertop Material
Cabinet Material
Cabinet Color
Fresh Water Tank
Waste Water Tank
Faucet Style
Door Lock
Soap Dispenser
Cabinet Wheels
Warranty
Minimum Operating Requirements
• Each sink must use a grounded, dedicated 110V,
20A circuit breaker
• Sinks must be used on a dry, level indoor surface
• Extension cord must be 12/3, rated at 20A or higher
• Water must meet EPA standards (PH between 7.0 and 9.0)
Premier
Yes
Yes
12, 3.4, 5.1, 5.2
Yes
110V, 20A Dedicated Outlet and Breaker
Approx. 40°F Above Water Temperature
0.50
45-60 (5 gallon tank)
25.5”W x 17.5”D x 37.5”H
88 lbs.
Single Integrated ABS Plastic
12” W x 10” L x 5.75” D
Black ABS Plastic
Phthalate, Lead Free Millwork
Black, Cherry, Maple, White
5 Gallon Capacity, FDA Approved
6 Gallon Capacity, FDA Approved
ADA Compliant Wrist Action Handles
Keyless
Liquid Only, Countertop Mount
5” Front Locking/Swivel Casters
2 Year (see warranty for details)
BEAUTY +
WELLNESS
EDUCATION +
CLASSROOM
FOOD SAFETY
HEALTHCARE
RETAIL
IMPORTANT!
Consult with your state and
local environmental health
offi cial to confi rm usage of
portable sinks in place of
plumbing.
GREATER
NASHVILLE AREA
call 1.866.663.1982
