Page 1
IN
IN
4 1
4 1
CAMERA
CAMERA
FEATURES:
FEATURES:
• Up to 8 Megapixel high resolution
• 2.8mm 4K lens
• 25-30m IR Distance
• DC12V
• 36pcs IR LED
• IP66 weather-proof protecion
15/08/19
2.8MM 4K LENS TURRET CAMERA
2.8MM 4K LENS TURRET CAMERA
Model No. 4K-TUR-FG36 / 4K-TUR-FW36
Image Sensor 1/2.3” colour CMOS 4K image sensor
Signal System PAL/NTSC
Active Pixels 3840(H)x2160(V)
Lens 2.8mm 4K lens
Angle of View H:105°
Horizontal Resolution 4K (8MP)
Backlight BLC/Off
Sharpness Low/Middle/High
Min Illumination 0 Lux (IR ON - IR-cut technology)
Menu UTC Control (or OSD cable)
Language
Shutter FLK/Auto
Day/Night Ext/Auto/Colour/B&W
White Balance ATW/ATW->SET
3DNR Low/Middle/High
Mirror Mirror/V-Flip/Rotate/Off
Brightness 0-100 (LSC: On/Off)
Video Output TVI / AHD / CVI / CVBS ** Factory Default is TVI
Power Supply DC12V ±10%
Current Consumption 130 mA(IR OFF), 370 mA(IR ON)
IR Led 36 pcs
IR Distance in Effect 25-30M
IP Rating IP66
Storage Temperature -50
Operating Temperature -30
Dimension Φ120*86mm
Weight 800g
ENG/CHN/GER/FRA/ITA/SPA/POL/RUS/POR/
NED/TUR/JPN
0
C ~ +900C
0
C ~ +700C
DIAGRAM:
DIAGRAM:
For further information on our products visit our website www.oyn-x.com, email: [email protected], sales Line: (023 92 488366).
///
