ADELPHI Vanity
H
W
Ext.
3-536-xx
FIXTURE TYPE LOCATION
PROJECT DATE
oxygen
-24 Satin Nickel
LIGHT SOURCE
LUMINAIRE POWER
RATED LIFE
OPTIONAL COLOR
TEMPERATURES
LUMEN OUTPUT
INPUT VOLTAGE
DRIVER OUTPUT
DIMMING
CONSTRUCTION
DIFFUSER
FINISHES
MOUNTING
STANDARDS
2 x 11.7W LED, 3000K, CRI 90
28.0W at 120V
60000 hr RL
2700K, 3500K, 4000K
Delivered: 2490 lm (LM-79)
1
20V to 277V AC, 50/60Hz
700mA, 29.4W max power
TRIAC and ELV dimming at 120V AC;
0-10V dimming, 100% to 1% current output
Plated Steel and Acrylic
- Matte White Acrylic
Oiled Bronze (-22), Satin Nickel (-24), Aged Brass (-40)
4” Octagonal J-Box
UL Dry/Damp listed, ADA Compliant, Conforms to
UL STD 1598, Certified CAN/CS
A STD C22.2 No 250.0.
-40 Aged Brass-22 Oiled Bronze
DIMENSIONS
W: 46.375”
H: 4.75”
Ext: 3.50”
M.C: 2.37” From top of fixture
Order example for standard fixture:
3-536-24 (x- Voltage - xxx-Sequence # - xx-Finish)
3: 120V to 277V
Order example for optional color temperatures: 3-536-2724
27: 2700K, 35: 3500K, 40: 4000K
201 Railhead Road, Fort Worth, TX 76106 - Tel. (877) 607-0202 - www.oxygenlighting.com
