IN WALL SPEAKER:
T
0
T
4
®
8" 3-WAY, 8 OHMS
ARCHITECTS AND ENGINEERS
SPECIFICATIONS / TECHNICAL DATA
GENERAL SPECIFICATIONS
MODEL NUMBER: IWT-83A
DESCRIPTION: 8" 3-Way, Aluminum Woofer
Swivel Midrange and Tweeter
COVERED OUTDOOR: Yes
IMPEDANCE: 8 Ohms
SENSITIVITY (1W/1M): 88 dB
MAX POWER: 200 Watts
NOMINAL POWER: 125 Watts
FREQUENCY RESPONSE: 55 Hz - 20 kHz
CROSSOVER: 900 & 4.5 kHz
WOOFER SIZE: 8"
WOOFER MATERIAL: Aluminum
MIDRANGE SIZE: 1"
MIDRANGE MATERIAL: Ceramic Soft Dome
TWEETER SIZE: 1"
TWEETER MATERIAL: Polypropylene
GRILL MATERIAL: Aluminum
DIMENSIONS
WEIGHT: 4.10 lbs.
MOUNTING HARDWARE: Kwik Klamps
PAINTABLE: Yes
(LxWxH): 10" x 3 5/8" x 14"
OWI Incorporated
17141 Kingsview Avenue, Carson, CA 90746 USA
el: 310.515.190
oll Free: 800.638.169
Fax: 310.515.1606
Web: www.owi-inc.com
E-mail: [email protected]
