OWCdigital.com
Compatible
Power
Pass-Through
Charging
USB 3.1 Gen 1
Type-A ports
OWC
USB-C Travel Dock
USB-C | USB-A | SD Card | HDMI
Simplify your mobile life
Your oce is wherever your work takes you — that day. With a single cable
connection, the USB-C Travel Dock puts ve essential ports at your ngertips
wherever you are: on-set, on location, at the studio, or lounging at a coee
shop. It transfers up to 100W of pass-through charging from your USB-C
power adapter, ensuring you’re powered up and ready to deliver a client
presentation or download the day’s last shots.
Whether it’s time-lapse photography, live events, or urban exploring, the USB-C
Travel Dock helps lighten your load of adapters and dongles while expanding
your connectivity options. With minimal gear, you can nd inspiration anywhere,
download your SD card quickly, and keep capturing the moment.
HDMI portSD slotiPad Pro
Key Features
- USB 3.1 Gen 2 (Type-C) port
- Dual USB 3.1 Gen 1 (Type-A) port
- USB-C power pass-through
- SD Card Reader (UHS-II)
- HDMI 2.0
- Up to 100W pass-through power1
- Built-in cable storage
- Compatibility: Notebooks, Tablets, Mac,
PC, iOS, Android, Windows, and Chrome
1. With existing USB-C adapter
USB-C and
Thunderbolt 3
Compatible
Mac, PC,
iOS, Android,
and Chrome
OWC
USB-C Travel Dock
Tech Specs
Interface
- (1) USB 3.1 Gen 1 Type-C captive cable
- (2) USB 3.1 Gen 1 Type-A
- (1) USB 3.1 Gen 1 Type-C pass-through power port — up to 100W
- (1) SD card reader (UHS-II)
- (1) HDMI 2.0
Display Support
- 4K resolution: up to 4096 x 2160 @ 30Hz
- Color Depth: up to 24-bit
System Requirements
- OS Compatibility
- Mac: OS X 10.10 or later
macOS 10.12 or later
iOS 12 or later
- PC: Windows 10 or later
- Android, Chrome, and Linux versions with USB Type-C support
- Hardware
- Works with any computer or tablet with a USB Type-C or Thunderbolt 3 port.
Power Supply
2
- 5W — 15W bus powered3
- Up to 100W power delivery4
Operating Environment
- Environmental (Non-Operating)
- Temperature (°F): -4° to 158°
- Temperature (°C): -20° to 70°
- Environmental (Operating)
- Temperature (°F): 32° to 104°
- Temperature (°C): 0° to 40°
1
PART NUMBER COLOR UPC AVAILABLE
OWCTCDK5P2SG Space Gray 810586031509 now
OWCdigital.com
Includes
- OWC USB-C Travel Dock with USB-C captive cable
- Quick start guide
Warranty
- 2 Year OWC Limited Warranty
Dimensions
- 3.2 in (W) x 0.9 in (H) x 3.2 in (D)
- 8.0 cm (W) x 2.3 cm (H) x 8.0 cm (D)
Captive Cable Length
- 5.9 in (15.0 cm)
Weight
- 6.1 oz (172.0 g)
Box Dimensions
- 4.4 in (W) x 2.0 in (H) x 4.4 in (D)
- 11.1 cm (W) x 5.0 cm (H) x 11.1 cm (D)
Box Weight
- 8.5 oz (240.0 g)
Master Carton Dimensions — 60 pieces
- 20.7 in (W) x 13.9 in (H) x 10.2 in (D)
- 52.7 cm (W) x 35.2 cm (H) x 26.0 cm (D)
Master Carton Weight — 60 pieces
- 34.0 lb (15.4 kg)
1. SD Card reader is compatible with SD, SDHC, SDXC, SDUC cards. SD card reader is compatible with UHS-I, UHS-II, UHS-III (Ultra High Speed) and
SD Express cards. Up to 156MB/s (SDHC) or 312MB/s (SDXC). Speeds are dependent upon the type of SD card used, including its speed class.
2. The dock itself requires 1.5W of power to operate. The dock draws between 5W and 15W of power, depending on the devices connected. If the
connected devices require more power than is available, one or more of these devices may not function as expected while on bus power.
When connected to an AC power adapter, each USB Type-A port can deliver up to 12W of power. Any power not used by the dock, inserted cards,
and connected peripherals, is passed to the host computer for battery charging, if applicable.
3. Connected to host computer without AC adapter.
4. The dock is capable of supporting up to 100W of power delivery to the host computer from a USB Type-C AC power adapter connected to the
dock’s USB Type-C port.
owc-usb-c-travel-dock-2019 : 07.2019
