OWC Mercury Elite Pro mini
USER GUIDE
TABLE OF CONTENTS
1. INTRODUCTION ...................................................................................... 1
1.1 MINIMUM SYSTEM REQUIREMENTS
1.1.1 Apple® Mac Requirements
1.1.2 PC Requirements
1.2 PACKAGE CONTENTS
1.3 ABOUT THIS MANUAL
1.4 REAR VIEW
1.4.1 Rear Features
1.5 LED INDICATOR
2. SYSTEM SETUP ........................................................................................ 3
2.1 QUICK START
3. APPENDIX ................................................................................................. 4
3.1 FORMATTING
3.2 UNMOUNTING DRIVES
3.3 TROUBLESHOOTING
3.4 ABOUT DATA BACKUP
3.5 ONLINE RESOURCES
3.6 TECHNICAL SUPPORT HOURS AND CONTACT INFORMATION
OWC MERCURY ELITE PRO MINI
TABLE OF CONTENTS
INTRODUCTION
1.1 MINIMUM SYSTEM REQUIREMENTS
1.1.1 Apple® Mac Requirements
•PowerPC G4 CPU, 128MB RAM
•USB 3.0 (backwards compatible to
USB 2.0): OS X 10.2 or later
1.2 PACKAGE CONTENTS
1.1.2 PC Requirements
•500MHz Intel® Pentium® 3 CPU, 128MB RAM
•USB 3.0 (backwards compatible to USB 2.0):
Windows® XP or later
Mercury Elite Pro mini USB 3.0 cable
1.3 ABOUT THIS MANUAL
Firmware, images, and descriptions may vary slightly between this manual and the unit
shipped. Functions and features may change depending on the firmware version. Please
visit the product webpage for the most recent product specifications.
1.4 REAR VIEW
(Standard-A to Micro-B)
1
3
2
1
OWC MERCURY ELITE PRO MINI
INTRODUCTION
1.4.1 Rear Features
1. USB 3.0 port — Attach the included USB 3.0 (Standard-A to Micro-B) cable here.
2. On/o switch — Turn on and off the Mercury Elite Pro mini here.
3. Power input — Connect the optional 5V power adapter here (sold separately).
NOTE:
•The Mercury Elite Pro mini is designed to receive all needed power through the
USB cable, therefore a separate power adapter is not necessary and not included.
For the few situations in which external power may be necessary, an optional 5V
power adapter is available at: http://eshop.macsales.com/item/OWC/
MOTGPWR/
•Even when the optional 5V power adapter is not connected, the on/off switch must
be in the ‘on’ position in order to use the Mercury Elite Pro mini.
•For the safe removal of your drive and to ensure that no data is lost, always eject or
unmount the drive from your operating system before powering off.
1.5 LE D IN DIC ATOR
The Mercury Elite Pro mini has a blue LED behind the front grill. The LED emits a solid
blue light when the unit is powered on and flashes during drive activity.
OWC MERCURY ELITE PRO MINI
2
INTRODUCTION
SYSTEM SETUP
2.1 Q UICK S TART
Before your Mercury Elite Pro mini can be put to use, it needs to be formatted. To help
with the formatting process, the OWC Drive Guide formatting utility has been installed
on your Mercury Elite Pro mini. Follow these steps to use the OWC Drive Guide to format
your Mercury Elite Pro mini for OS X (10.4 and later) or Windows (XP and later).
1. Connect your drive to your computer using the proper cable, then turn on your drive.
If you prefer to use a different formatting utility, do so at this time and skip the rest of
these instructions.
2. Your drive will show up as “OWC HD”. Open your drive to view its contents.
3. Open the “Macintosh Setup” or “Windows Setup” folder, depending on the computer’s
operating system, then double-click the OWC Drive Guide application.
4. Follow the simple on-screen instructions to complete the formatting process.
5. Once the formatting is finished the drive is ready to use.
OWC MERCURY ELITE PRO MINI
3
SYSTEM SETUP
APPENDIX
3.1 FORMATTING
For formatting information, including instructions on how to format your Mercury Elite
Pro mini for Mac or Windows, go to: h t t p: // www.macsales.com/format
3.2 UNMOUNTING DRIVES
To properly unmount any connected drives from your computer, you need to follow a
few simple steps.
For OS X systems:
There are two main methods to umount disks with OS X systems. Either drag the icon
for the disk you wish to unmount to the trash can, or right-click the disk icon on the
desktop, then click “Eject”.
For Windows systems:
1. Go to the System Tray (located in the lower right corner of your screen). Click on the
“Eject” icon (a small green arrow over a hardware image).
2. A message will appear, detailing the devices that the “Eject” icon controls, i.e., “Safely remove...” Click on this prompt.
3. You will then see a message that says, “Safe to Remove Hardware.” It is now safe to
disconnect the Mercury Elite Pro mini from the computer.
3.3 TROUBLESHOOTING
Begin your troubleshooting by verifying that both ends of your cables are properly
plugged into the computer and the Mercury Elite Pro mini. If the Mercury Elite Pro mini is
still not working properly, try connecting it to a different computer.
In some rare instances, the power being provided through the interface cable may not
be sufficient to power the Mercury Elite Pro mini, depending on the computer you are
using and the hard drive or SSD inside the Mercury Elite Pro mini. If you suspect this is the
case, an optional 5V power adapter is available at: http://eshop.macsales.com/
ite m /OWC/ MOTGP WR /
If problems persist, consult our online collection of frequently asked questions (ht t p://
www.macsales.com/FAQ) or see section 3.6 for information on contacting OWC
technical support.
4
OWC MERCURY ELITE PRO MINI
APPENDIx
3.4 ABOUT DATA BACKUP
To ensure that your files are protected and to prevent data loss, we strongly suggest that
you keep two copies of your data: one copy on your Mercury Elite Pro mini and a second
copy on either your internal drive or another storage medium, such as an optical backup,
or on another external storage unit. Any data loss or corruption while using the Mercury
Elite Pro mini is the sole responsibility of the user, and under no circumstances will Other
World Computing be held liable for compensation or the recovery of any lost data.
3.5 ONLINE RESOURCES
Formatting:
For formatting information, including instructions on how to format your Mercury
Elite Pro mini for Mac or Windows, go to:
h t t p: // www.macsales.com/format
Data Migration:
For a step-by-step walkthrough of our recommended method for migrating your
data from an old drive to a new one, go to:
h t t p: // www.macsales.com/migration
FAQs :
Access our online collection of frequently asked questions for this and other products
at: http://www.macsales.com/FAQ
3.6 TECHNICAL SUPPORT HOURS AND CONTACT INFORMATION
8AM - 8PM (CT) Monday - Friday
9AM - 4PM (CT) Saturday
By telephone: (800) 275-4576 (North America only)
International customers please call: (815) 338-8685
Live chat is available during normal business hours as well.
For more information, visit: http://w ww.macsales.com/livechat
Or you can email us. Submit your email at:
http://www.macsales.com/ts_email
OWC MERCURY ELITE PRO MINI
5
APPENDIx
Changes:
The material in this document is for information only and subject to change without notice. While reasonable efforts
have been made in the preparation of this document to assure its accuracy, Other World Computing assumes no
liability resulting from errors or omissions in this document, or from the use of the information contained herein.
Other World Computing reserves the right to make changes or revisions in the product design or the product manual
without reservation and without obligation to notify any person of such revisions and changes.
FCC Statement:
Warning! Modications not authorized by the manufacturer may void the user’s authority to operate this
device.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at his own expense.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference with radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
Health And Safety Precautions:
• Read this user guide carefully and follow the correct procedures when setting up the device.
• Do not attempt to disassemble or modify the device. To avoid any risk of electrical shock, fire, short-circuiting or
dangerous emissions, never insert any metallic object into the device. If it appears to be malfunctioning, contact
Other World Computing technical support.
• Never expose your device to rain, or use it near water or in damp or wet conditions. Never place objects containing
liquids on the drive, as they may spill into its openings. Doing so increases the risk of electrical shock, short-circuiting,
fire or personal injury.
General Use Precautions:
• To avoid damage, do not expose the device to temperatures outside the range of 5° C to 40° C (41° F to 104° F).
• Always unplug the device from the electrical outlet if there is a risk of lightning or if it will be unused for an extended
period of time. Otherwise, there is an increased risk of electrical shock, short-circuiting or fire.
• Do not use the device near other electrical appliances such as televisions, radios or speakers. Doing so may cause
interference which will adversely affect the operation of the other products.
• Do not place the device near sources of magnetic interference, such as computer displays, televisions or speakers.
Magnetic interference can affect the operation and stability of hard drives.
• Do not place heavy objects on top of the device.
• Protect your device from excessive exposure to dust during use or storage. Dust can build up inside the device,
increasing the risk of damage or malfunction.
• Do not block any ventilation openings on the device. These help to keep the device cool during operation. Blocking
the ventilation openings may cause damage to the device and cause an increased risk of short-circuiting or fire.
• For up-to-date product and warranty information, please visit the product webpage.
Copyrights and Trademarks:
© 2014 Other World Computing. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written consent of Other World Computing. Mercury Elite, OWC, the OWC logo and the Other
World Computing logo are trademarks of New Concepts Development Corporation, registered in the U.S. Patent and
Trademark Office and in Canada. Apple, Mac, and Macintosh are trademarks of Apple Inc., registered in the U.S. and
other countries. Intel and Pentium are trademarks of Intel Corporation in the U.S. and/or other countries. Windows is
a registered trademark of Microsoft Corporation in the U.S. and other countries. Other marks may be the trademark or
registered trademark property of their owners.
®
OWCMANMEPMU3UGR3 01/16/14 SL
Copyright ©2013 Other World Computing, all rights reserved. Other World Computing’s
Limited Warranty is not transferable and is subject to limitations.
