OWC Mulit-Mount operation manual

MULTI-MOUNT

Assembly Manual

CONTENTS

Introduction

1.1 Hardware Requirements ................................................................. 1

1.1.1 Compatible Systems

1.1.2 Supported Drives

1.1.3 Required Tools

1.2 Package Contents .......................................................................... 1

1.3 About This Manual ......................................................................... 1

Bracket Assembly

2.1 Installing 3.5 Inch SATA Drives ....................................................... 2

2.2 Installing 2.5 Inch SATA Drives ....................................................... 3

2.3 Installing Two 2.5 Inch SATA drives ................................................ 3

2.4 Combining 2.5 and 3.5 Inch Drives ................................................ 3

Computer Installation

3.1 Apple Mac Pro Installation ............................................................. 4

3.2 PC Installation ................................................................................ 4

Support Resources

4.1 Formatting ...................................................................................... 5

4.2 Troubleshooting .............................................................................. 5

4.3 About Data Backup ........................................................................ 5

4.4 Contacting Technical Support ........................................................ 5

OWC MULTI-MOUNT

TABLE OF CONTENTS

INTRODUCTION

1.1 Hardware Requirements

1.1.1 Compatible Systems

• Apple Mac or PC with available 5.25 inch optical bay or 3.5 inch hard drive bay

1.1.2 Supported Drives

• Any 3.5 inch or 2.5 inch SATA drive, or 3.5 inch IDE drive

1.1.3 Required Tools

• Phillips PH1 or PH2 screwdriver *

* There may be additional tools required; please check the computer’s manual.

1.2 Package Contents

1. OWC Multi-Mount 3.5″ drive bracket (2 pieces)

2. OWC Multi-Mount 2.5″ drive bracket (2 pieces)

3. Coarse-threaded screws for 2.5″ brackets and 3.5″ drives (12 pieces)

4. Fine-threaded screws for 5.25″ PC bays (4 pieces) - not shown

1

2

3

1.3 About This Manual

The OWC Multi-Mount brackets are sold both individually and as sets. This manual
details both types of brackets. For this reason, the item you purchased may not include

all of the items shown in this manual (or the same quantity of items). In addition, the

images included in this manual may vary slightly in appearance from the items you
received. Please visit the product web page for the most recent product information.
OWC’s Limited Warranty is not transferable and subject to limitations.

1

OWC MULTI-MOUNT INTRODUCTION
