The AC.TOP is a ceiling mount wireless multi-function AP based on 1200Mbps 2T2R
Wireless AC+ b/g/n MIMO standard radio technologies. It is 2.4G/5G dual band concurrent.
The Wireless Access Point is equipped with one Gigabit Auto-sensing Ethernet ports for
connecting to LAN and also for cascading to next Wireless Access Point. It has built-in
802.3af PoE port for installation up to 100 meter away from the power source.
1.2 Firmware Upgrade and Tech Support
If you encounter a technical issue that can not be resolved by information on this guide, we
recommend that you visit our comprehens ive website support at www.airlive.com. The tech
support FAQ are frequently updated with latest information.
In addition, you might find new firmware that either increase software functions or provide
bug fixes for AC.TOP in our website.
1 AirLive AC.TOP User’s Manual
1.3 Features
AC.TOP Wireless Operation Mode
Wireless Mode
Radio 5G
Radio 2.4G
Application
Access Point
AP
AP
Hotspot (Indoor and Outdoor)
WDS Repeater
WDS
WDS
Extend distance of another WDS
1200Mbps 802.11AC+b/g/n Standard
Up to 23dBm output power (limited to 20dBm in EU)
Built-in MIMO Antennas
8MB Flash and 64MB SDRAM
2 wireless multi-function modes: AP, WDS repeater
1 x 10/100/1000 Mbps Ethernet Port with IEEE 802.3af PoE support
Web management
Easy Setup Wizard
Wireless Access Control ,Multiple SSID up to 32 and Virtual AP
Wireless Client Limit, C li ent Isol ation and Watchdog
1. Introduction
IP Finder Management Utility
AirLive Central Wireless Management
Green WLAN for Power Saving
1.4 Wireless Operation Modes
The AC.TOP can perform as a Multi-Functi o n wireless device. Through the wizard web
interface, users can easily select which wireless mode they wish the AC.TOP to perform.
AP/Router
AC.TOP are dual radio device, you also can change the operation mode for each radio.
Each radio can be set to difference Operation Mode such as AP mode in 2.4G and WDS
repeater mode in 5G
1.4.1 Access Point Mode
When operating in the Access Point mode, the AC.TOP becomes the center hub of the
wireless networ k. All wirel ess car ds and c lient s connect and communicate t hr ough AC.TOP.
This type of network is known as “Infrastructure Network”. Other AC.TOP or 802.11b/g/n
device can connect to AP mode through “Client Mode”.
AirLive AC.TOP User’s Manual 2
1. Introduction
1.4.2 WDS Repeater Mode
In WDS Repeater mode, the AC.TOP functions as a repeater that extends the range of
remote wireless LAN. In this mode, the remote Access Point must have WDS (Wireless
Distribution System) capab ility. If you require the PC’s MAC addresses to be preserved
when the data pass through the Repeater, it is necessary to use the WDS Repeater mode.
Because the radio is divided into WDS + AP mode, the Repeater mode will have less
performance and dista nce.
3 AirLive AC.TOP User’s Manual
2. Installing the AC.TOP
2
Installing the AC.TOP
Ethernet Port/ PoE In
Power Jack (DC IN)
2.
This section describes the installation procedure for the AC.TOP. It starts with a summary
of the content of the package you have purchased, followed by steps of how to power up
and connect the AC.TOP. Finally, this section explains how to configure a Windows PC to
communicate with the AC.TOP.
2.1 Package Content
The AC.TOP package contains the fol l owing items:
One AC.TOP main unit
One 12V DC power adapter
One CD of the AC.TOP
Quick Installation Guide
2.2 Knowing your AC.TOP
Below are descriptions and diagrams of the product:
AirLive AC.TOP User’s Manual 4
2. Installing the AC.TOP
※
Note
Before you starting hardware connection, you are advised to find an
2.3 Hardware Installation
appropriate location to place the Access Point. Usually, the best place for the
Access Point is at the center of your wireless network, with line of straight to all
your wireless stations.
There are two methods to mound the AC.TOP. Ceiling mount and T-rail Mount
2.3.1 Ceiling Mount
If you want to mount the AC.TOP into wood ceiling
1. Place the ceiling mount bracket to a ceiling in your desired location and insert screw
through hole (x 2) and tighten to fix the bracket in place.
2. When the ceiling bracket is in place, inset screw into hole (x 2) on the access point.
3. Fix the access point to the ceiling bracket by inserting the attached screws into hole
and twisting the access point.
4. Lock the access point firmly into place when by twisting it to align screws with the
grooves in the ceiling mount.
If you want to mount the AC.TOP into other ceilings
1. Place the ceiling mount bracket to a ceiling in your desired location and insert screw
through hole (x 2) and tighten to fix the bracket in place, as shown in A.
2. Insert screw through hole and into the rear of screw and tighten to provide additional
strength.
3. When the ceiling bracket is in place, insert screw into hole (x 2) on the access point.
4. Fix the access point to the ceiling bracket by inserting the attached screws into hole
and twisting the access point.
5. Lock the access point firmly into place by twisting it to align screws with the grooves in
the ceiling mount.
5 AirLive AC.TOP User’s Manual
2. Installing the AC.TOP
B
A
2.3.2 Install in T-Rail Mount
To mount the access point to a T-Rail, please follow the instructions below and refer to
diagram C, D & E.
1. Select the correct size T-Rail bracket from the two sizes which are included in the
package contents.
2. Attach the T -Rail bracket to hole using screw (x 2) as shown in C.
If you need more space between the access point and the T-Rail,
then additionally use bracket between bracket and hole (x 2), and
use the longer screws (x 2) included in the package contents.
3. Clip the access point onto your T-Rail using the now attached T-Rail bracket.
AirLive AC.TOP User’s Manual 6
2. Installing the AC.TOP
C
D
E
7 AirLive AC.TOP User’s Manual
2.3.3 P ow er up t he AC.TO P
There are two way to power up the AC.TOP
1. Power by PoE
AC.TOP is equipped with 802.3at compliant PoE port. You can select AirLive
PoE-48PB v2 or PoE switch such as POE-GSH2004L-370 for the deployment of
the PoE network environment. The POE-48PB v2 and POE-GSH2004L-370 is an
optional accessory that must be purchased separately. You must use Cat.5E or
better graded Ethernet Cable for PoE Installation.
2. Installing the AC.TOP
2. Power by Power Adapter
Connect 12V adaptor to Power up the AC.TOP
Do not use the power adapter if you are using a PoE
switch.
AirLive AC.TOP User’s Manual 8
2.4 LED Indicators
LED Color
LED Status
Description
This section describes the LED behavior of AC.TOP.
You can find the LED in front of the AC.TOP.
2. Installing the AC.TOP
Blue OnThe access point is starting up.
Purple OnThe access point is on.
Amber FlashingError.
Off Off The access point is off.
9 AirLive AC.TOP User’s Manual
3. Configuring the AC.TOP
3
Configuri ng the AC.TOP
3.
The AC.TOP offers web browser (http) as management interface.In this chapter, we will
explain AC.TOP’s web management interface and how to get into them.
3.1 Important Information
The following information will help you to get start quickly. However, we recommend you to
read through the entire manual before you start. Please note the password and SSID are
case sensitive.
The defaul t IP address is: 192.168.1.254 Subnet Mask: 255.255.255.0
The defaul t user’s name is: admin
The defaul t password is: airlive
The defaul t SSID for 2.4G is: airlive
The defaul t SSID for 5G is: airlive 5g
The default wireless mode is : AP mode
After power on, please wait for 1 minutes for AC.TOP to finish boot up
Please remember to click on “Apply” for new settings to take effect
You must reboot the AC.TOP after you finish all the settings for changes to
take effect
By Default, the DHCP server is turned off, please to configure your PC’s IP
address manually.
3.2 Prepare your PC
The AC.TOP can be managed remotely by a PC through either the wired or wireless
network. The default IP address of the AC.TOP is 192.168.1.254 with a subnet mask of
255.255.255.0. This means the IP address of the PC should be in the same subnet of the
AC.TOP.
AirLive AC.TOP User’s Manual 10
3. Configuring the AC.TOP
To prepare your PC for management with the AC.TOP, please do the following:
1. Connect your PC directly to the LAN port of AC.TOP
2. Set your PC’s IP address manually to 192.168.1.100 (or other address in the same
subnet)
You are ready now to configure the AC.TOP using your PC.
3.3 Introduction to IP Finder
The AC.TOP provides IP Finder utility and you can get into web management easily. IP
Finder is included in the CD. Just click and follow the step by step instruction to install.
While entering the IP Finder utility, the IP Finder will automatically search the AP available
on the network. IP Fi nder wil l show t he Dev ice Name, I P Addr ess, HT TP Port, and Et hern e t
MAC Address.
Before start using IP Finder, make sure you disable personal firewall installed in your PC.
(Ex. Windows XP personal firewall)
11 AirLive AC.TOP User’s Manual
3. Configuring the AC.TOP
Search: By clicking Search, IP Finder will try to discover the AC.TOP on the network.
View: The function is for IP Camera only. It does not work for AC.TOP.
Exit: Click to close IP Finder.
3.4 Introduction to Web Management
The AC.TOP can be configured using the Web management interfaces by simply typing its
IP address in the web browser. Most functions of AC.TOP can be accessed by it.
If you are placing the AC.TOP behind router or firewall, you might need to open the port 80
at virtual server on your firewall/router. This procedure is not necessary in most cases
unless there is a router/firewall between your PC and AC.TOP.
3.4.1 Getting into Web Management
You can enter the web management by entering IP addr ess int o the w eb brow ser’s address
field.
AirLive AC.TOP User’s Manual 12
3. Configuring the AC.TOP
To get into the Normal Web Management, simply type in the AC.TOP’s IP address
(default IP is 192.168.1.254) into the web browser’s address field.
3.4.2 Main Menu
After key in the correct username and password, you will enter the main Web management
screen.
Wizard:
The wizard will guide you to configure access point for first time. Please follow the
setup wizard step by step.
13 AirLive AC.TOP User’s Manual
Wireless:
You will find all the settings for wireless settings in this page. The AC.TOP’s
wireless settings are different between wireless modes.
System:
All non-wireless and router mode settings are in this category. The system
configurations including changi ng passw ord, upload firmwar e, backup con figurati on,
settings PING watchdog, and setting management.
Status:
This section for monitoring the status of AC.TOP. It provides information on device
status, Ethernet status, wireless status, wireless client table, and system log.
3. Configuring the AC.TOP
Reboot:
Please remember to save changes and reboot after you finish all settings. The
changes will take effect only after reboot.
3.5 Configuring with Setup Wizard
You can browse to activate the Setup Wizard
Step1: Login the Web UI of AC.TOP, select “Wizard” for basic settings with simple way.
AirLive AC.TOP User’s Manual 14
3. Configuring the AC.TOP
In this mode, the AC.TOP will act as a center
Step2: Select wireless mode that you deserved, and click “Next” to continue.
Step3: Setup your wireless settings for 2.4G band such as SSID, Wireless Channel and
Encryption Key…etc, and click “Next” to apply the setting or click on “Previous” to the
previous settings.
hub for the wireless network. Please choose
this mode if you already have a router and
want to create a new wireless network.
15 AirLive AC.TOP User’s Manual
3. Configuring the AC.TOP
In this mode, the AC.TOP will act as a center
Step 4: Setup your wireless settings for 5G band such as SSID, Wireless Channel and
Encryption Key…etc, and click “Finish” to apply the setting or click on “Previous” to the
previous settings.
hub for the wireless network. Please choose
this mode if you already have a router and
want to create a new wireless network.
3.6 Initial Configurations
We recommend users to browse through AC.TOP’s web management interface to get an
overall picture of the functions and interface. Below are the recommended initial
configurations for firs t ti me log in:
3.6.1 Change the Device’s IP Address
The default IP address is at 192.168.1.254. You should change it to the same subnet as
your network. Also, if you want to manage AC.TOP remotely, you have to set the Gateway
and DNS server information.
To setup the IP settings for AC.TOP, please select “System” -> LAN Interface Setup”.
After entering the IP information, click on “Apply Changes” to finish.
AirLive AC.TOP User’s Manual 16
Loading...
+ 52 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
