OUTXE Savage Power Bank 2 0000mAh
User Manual
OUTXE is an outdoor lifestyle brand that strives to create
well designed, rugged products for your active outdoor life.
Specifications
Package Contents
Model
PCPB20000WS
Capacity
20000mAh / 74Wh
Battery Type
Lithium-Polymer
Input
Micro USB Input: DC 5V/2A (max)
Type-C USB Input: DC 5V/3A (max)
Solar Charging: 2W (max)
Output
Quick Charge Output:
DC 5V/3A, 9V/2A,12V/1.5A (max)
Smart Output: DC 5V/2.4A (max)
Working Temperature
0-45 ℃
Higher temperature will probably make the
battery excessively active and hot.
Lower temperature make the battery less
active which impact the battery
performance.
Dimensions
170×86×30 mm / 6.7×3.4×1.2 in
Weight
525g /18.5 oz
Product Overview
Solar Panel Charging Indicators ( for PCPB100
How to Use the LED Flashlight
Double click the power button to turn the
X2
light on, and turn the light off in any mode.
X1
Press the power button in succession to
toggle from strong light to weak light, to SOS.
Indicator Instructions
This power bank has 6 LED indicators. When the first indicator
starts flashing, please charge the power bank. When the last
indicator i s red, the solar panel is charging.
How to Charge the Power Bank
Connect the power bank to a charger (Output: DC 5V 0.5A~3A),
Using the supplied USB charging cable. All indicators will stay lit
when the charging is finished.
10-11
Notes
With two inputs, you can either use the Micro USB or Type C input to
recharge. When using the Micro USB input (5V 2A), a full charge takes 13
hours. With Type-C input (5V 3A), a full charge takes 10-11 hours. If you
have a multi-port charger or multiple charges, you can use double inputs, it
takes 6-7 hours to get a full charge.
Simply leave the PCPB 20000WS in the sunlight for solar charging, there
is no need to press any buttons. When charging begins, the last indicator turns
RED. It takes about 75 hours to get a full charge due to the limited solar panel
size and conversion rate. Solar charging is recommended for emergency use
only.Please fully charge your unit from a wall outlet before going outdoors.
When the fifth indicator flashes or illuminates, the battery is too active.
Please don’t pl
ace
the po
wer b
ank in
the sun to charge,
if you do, you
may damage the battery.
How to Charge Your Device
No need to press the power button. The OUTXE power bank detects and
charges for any connected device, instantly. When the power bank is fully
charged or the connected device is removed, the unit will turn off within 30
seconds.
Notes
Please close the waterproof lid when u n i t i s not in use, to prevent water
from getting into the product.
The latest smart technology is inside every OUTXE power banks, so it
can automatically detect and deliver the optimal charge current for any
connected device to ensure an efficient
and
safe charge.
Self-Protection and Restore
This product is CE, FCC, RoHS certified and its built-in multiple circuit
protection prevents the product from over-charging, over-discharging, overheating and makes it immune to any kind of short circuits.
If the product enters to self-protection mode (all indicators start to flash),
please remove the connected device and restore the power bank by
charging it with a charger right away.
Notes
Avoid using the product in extreme heat and humidity.
Never leave the power bank or other electronic devices in an idle car
under the sun, as the temperature in the car can reach up to 70℃,
which could hamper the quality of the battery.
Do not place the power bank in a protective case while charging.
Do not knock, drop or puncture the product.
Do not dismantle or repair the device by yourself.
Keep the product away from children.
Warranty
OUTXE products are covered by a limited 18-month warranty, starting on the
purchase date. The warranty doesn't cover improper product use or products
purchased from other unauthorized s e l l e r s.
Want an Extended 3-Month W
arr
anty for
your
OUTXE?
Visit : www.outxe.com
Contact Us
support@outxe.com
www.outxe.com
https://www.facebook.com/outxefans
https://www.youtube.com/c/outxeofficial
https://www.instagram.com/outxe
Troubleshooting
Problem
What to do
The power bank doesn't
charge itself properly.
Get a different working USB charging cable
and a 5V 2A wall charger. Try charging again.
I've been trying to charge
my phone with the power
bank for 6 hours, but it
never reaches up to 33%.
1. Try a different charging cable.
2. Try to charge a different brand of
cell
phone or other device.
The last indicator doesn't
illuminate after charging it
for 10 hours.
1. If the last indicator doesn't illuminate at
all, please try a different USB cable and wall
charger (5V 2A).
2. If the last indicator flashes, the power bank
is almost fully charged, it may keep flashing
because of resistance error or recognition
issue in the charger.
I charged the power bank
for a long time,
the battery is
not fully charged.
1. If the charger you used is 5V 2A, it takes
about 10-13 hours to a full charge.
2. If the charger you used is 5A 1A, it takes
about 20-23 hours to a full charge.
I tried to charge the power
bank with solar for 3 hours,
but the battery level never
changed.
Be advised that it takes 75 hours to get a full
charge via solar. Charging speed depends
on sunlight intensity, solar panel size and
panel conversion rate. Please try to charge it
for a few more days.
