Outback K100 Assembly And Operating Instructions Manual
WARNING
• For outdoor use only. Not for commercial use.
• Read instructions before using the appli ance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
• Warning: accessible par ts may be very hot. Keep young children and pets away.
• CAUTION: Do not use spirit or petrol for lighting or re-lighting! Use only
firelight ers comp lying to EN1860-3!
• Do not move the appliance during use.
• Any modification of the appliance, misuse, or failur e to follow the instruction s
may be dangerous and will invalidate your warranty. This does not affect your
statutory rights.
• Retain these in structions for future reference.
• For Flare-up control please refer t o the ‘OPERATION’ section of this manual.
Photographs are not to scale.
Specifications subject to change
without prior notice.
Assembly and Operating Instructions for
Outback® Comet Kettle Charcoal
K100
2
Parts List
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
Pre-Assembled Component
Quantity varies according to model purchased
Appearanc e, size, and construction may differ according to model purchased
CODE PART QTY
Outback® Comet
Kettle Charcoal
HOOD
A1 Hood 1
A2 Hood Handle 1
A3 Heat Indicator 1
BODY
B1 Barbecue Body 1
B2 Charcoal Grill 1
B3 Cooking Grill 1
B4 Body Handle 1
B5 Vents C ombination 1
B7 Body Gasket 3
TROLLEY
C1 Front Leg 1
C2 Left Rear L eg 1
C3 Right Rear Leg 1
C4 Leg Support Rack 1
C5 Wheel 2
C6 Wheel Hubc ap 2
HARDWARE
D1 M6x15 Bolt 2
D2 M6 Washer 2
D3 M6 Nut 2
D4 Axle Nut 2
D5 M5x15 Bolt 10
D7 M5 Washer 6
D6 M5 Nut 4
B6 Ash Tray 1
B8
Grill Lifting Handle
2
3
Parts Diagram
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
A1
B2
B1
B6
A2
C5
B3
A3
B5
B4
C2
C3
C6
C4
B7
B8
C1
4
Hardware Reference Diagram
Specifications subject to change without prior notice.
D1
D2
D4
D3
D5
D6
D7
5
Assembly
IMPORTANT!
• TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver,
adjustable spanner or metric spanner set.
• Remove any internal components or packaging from the barbecue body.
• Whilst every care is taken in the manufacture of this product, care must be taken during assembly in
case sharp edges are present.
• Please read the Important Information section carefully before assembly and use of your
barbecue.
1
2
Insert the Front Leg (C1) into the leg support of the barbecue body. then insert the angled end
of Leg Support Rack (C4) into the end hole near the end of the front leg.
Attach the Body Handle (B4) onto the Barbecue Body (B1) using the M6x15 bolts
(D1x2pcs), M6 washers (D2X2pcs) and M6 Nuts(D3x2pcs) as shown.
B1
C1
C4
D1
D3
D2
B4
