BTE
INSTRUCTIONS FOR USE
HIT PRO/HIT
Thank you
Contents
Thank you for choosing our product as your means to better hearing.
To support your efforts, we have put great care and attention into making sure that
your new hearing instruments are of the highest quality and that they are easy to
use and maintain.
We recommend that you read this manual carefully to achieve the maximum benefit
of your new hearing instruments.
Congratulations on your decision to actively improve your hearing with today’s most
advanced hearing technology in the market.
Instrument View BTE – 312 5a
Instrument View BTE – 13 5b
Instrument View BTE – Power 5c
Instrument View BTE with
Changing batteries 7
Turning your instrument ON and OFF 9
Left/Right ear marking 10
Putting on your instrument with earmould 11
Putting on your hearing instruments with a Corda
Push-button 13
Programs (Optional) 15
Volume Control (Optional) 17
Stand-by (Optional) 18
Tamper-resistant battery door (Optional) BTE 312 21a
Tamper-resistant battery door (Optional) BTE 13 and BTE Power 21b
Telecoil (Optional) 23
Auto Phone (Optional) 24
DAI (Direct Audio Input) 26
Corda
(thin tube) 12
d
FM 28
Caring for your hearing instrument 30
How to change Corda
Cleaning your hearing instrument with Corda
Daily maintenance with Corda
Changing the Corda
Avoiding heat, humidity and chemicals 40
Seven easy steps to better hearing 41
Common problems and their solutions 46
Warnings Yellow Pages
(thin tube) 35
Dome 38
(thin tube) Domes 37
(thin tube) 36
IMPORTANT NOTICE
Please familiarise yourself with the entire contents of this booklet before using your
hearing instru ments. It contains instructions and important informa tion about the use
and handling of your hearing instru ments and batteries.
Instrument View BTE – 312
Microphone
openings
Push-button/
Volume Control
(Optional)
Battery size: 312
Sound hook
Plastic tube
Sound outlet
Ventilation
opening
Earmould
Battery door
5a
Instrument View BTE – 13
Microphone
openings
Push-button/
Volume Control
(Optional)
Battery size: 13
Sound hook
5b
Plastic tube
Sound outlet
Ventilation
opening
Earmould
Battery door
Instrument View BTE – Power
Microphone
openings
Push-button/
Volume Control
(Optional)
Battery size: 13
Sound hook
5c
Plastic tube
Sound outlet
Ventilation
opening
Earmould
Battery door
Instrument View BTE with Corda
Not available for BTE Power
Your ear piece:
Custom Mould
Open dome:
Plus dome
Small
Medium
Large
Microphone
openings
Push-button/
Volume Control
(Optional)
Thin tube
Ear grip
Dome
Battery door
5d
Changing batteries
The correct battery size appears in the “Instrument View”
in the first section of this document.
A worn out battery should be removed immediately
and disposed of according to local regulations.
When the battery power is low, you will hear 2 beeps.
This pre-warning starts when the battery has only a
few hours of operation left. The pre-warning will be
repeated in moderate intervals to indicate it is time
to change the battery.
If the battery runs out the instrument turns off. When
that happens, 4 beeps are played to indicate that the
instrument is no longer operating.
This is not an indication of a malfunction.
7
To replace the battery, follow these instructions:
Turning your instrument ON and OFF
Open the battery door completely by pushing the raised edge on the bottom of •
the instrument. To assist with the handling of the batteries, the magnet placed
at the end of the MultiTool can be used.
Remove the sticky label from the + side of the new battery.•
The new battery may be inserted by using the magnetic end of the MultiTool. •
Ensure that the positive (+) marking faces the positive (+) sign printed on the
battery door. Close the battery door.
If any moisture on the battery surface, it should be
wiped off before use. When you change the battery,
it will take a few seconds before the battery works
to full capacity.
8 9
MultiTool
Turn ON your hearing instrument by closing the battery door completely with the battery
in place. When the battery door is closed the instrument will start up by playing a jingle.
This indicates that the battery is working and the instrument is operating.
Turn OFF your hearing instrument by opening the battery door slightly until a “click” is felt.
To preserve the battery, make sure your hearing instrument is switched off when
you are not wearing it.
IMPORTANT NOTICE
Open the battery compartment
fully to allow air to circu late
whenever you are not using your
hearing instrument, especially
at night!
ON
Click
OFF
Click
Left/Right ear marking
Putting on your instrument with earmould
Hearing instruments are fitted to the uniqueness of each ear, which means if you have
two instruments then your left hearing instrument is programmed differently from
your right. That is why it is important to distinguish between the left hearing instrument
and the right.
In order to easily identify whether it is the left ear or right ear instrument, colour markings
may be applied inside the battery door.
A blue dot marks the LEFT instrument.
A red dot marks the RIGHT instrument.
10 11
Place the tip of the earmould in your ear canal, twisting
slightly, making sure that the top part of the earmould (A)
is pushed behind and under the fold (B) of your ear.
Gently pull up your ear and press the earmould in the
direction of the ear canal.
With the earmould positioned correctly in your ear,
place the hearing instrument behind your ear by lifting
its lower part and sliding it over the top of your ear.
B
A
Putting on your hearing instruments
with a Corda
Not available for BTE Power
Putting on your hearing instrument with a thin tube correctly every
time, takes practice:
Place the hearing instrument behind your ear.1.
Hold the bend of the tube between your thumb and index finger. 2.
The dome should point towards the ear canal opening.
Gently push the dome into your earcanal until the sound tube
sits close against the side of your head.
Position the ear grip in concha using your index finger. Look in 3.
a mirror. If the sound tube is sticking out from your ear, the dome
has not been placed correctly in the ear canal. If the ear grip is
visibly sticking out from your ear it has not been positioned
correctly. To remove the instrument pull the bend of the tube.
(thin tube)
12 13
1
Concha
Dome
2
3
Push-button
Your hearing instrument has an ergonomic designed push-button for volume adjustment
and switching between different programs.
The push-button can be activated by pressing either the upper part (UP) or the
lower part (DOWN).
UP
DOWN
The push-button on your hearing instrument can be programmed to one of 3 functionalities.
Programs (Optional)
Left Right
Programme shift:
Press shortly to change programme.
Volume control:
Press shortly to adjust the volume.
Both volume control and programme shift:
Press shortly to adjust the volume and press long (about seconds)
to shift programme.
To be filled out by your Hearing Care Professional!
14 15
Your hearing instrument can have up to 4 different programs.
When switching between the different programs, your hearing instrument will beep.
The number of beeps will indicate which programme you are using.
One beep, when you switch to programme 1
e
Two beeps, when you switch to programme 2
ee
Three beeps, when you switch to programme 3
eee
Four beeps, when you switch to programme
eeee
