INSTRUCTIONS FOR USE RITE
Thank you
Thank you for choosing our product as your means to better hearing.
To support your efforts, we have put great care and attention into making sure that your
new hearing instruments are of the highest quality and that they are easy to use and
maintain.
We recommend that you read this manual carefully to achieve the maximum benefit of
your new hearing instruments.
Congratulations on your decision to actively improve your hearing with today’s most
advanced hearing technology in the market.
Contents
Instrument View RITE 5a
Instrument view RITE Power with Power Dome 5b
Instrument view RITE Power with Ear Mould 5c
Changing batteries 7
Turning your instruments ON and OFF 9
Left/Right ear marking 10
Putting on your instrument 11
Push-button 12
Programs (Optional) 14
Volume Control (Optional) 16
Standby (Optional) 17
Tamper-resistant battery door (Optional) 18
Telecoil (Optional) 19
Auto Phone (Optional) 20
DAI (Direct Audio Input) 22
FM 24
5a
Instrument View RITE
Your ear piece
Open Domes:
6mm
8mm 10mm
Micro mould
Plus dome
IMPORTANT NOTICE
Please familiarise yourself with the entire contents of this booklet before using your
hearing instru ments. It contains instructions and important informa tion about the use
and handling of your hearing instru ments and batteries.
CAUTION
The RITE Power is a powerful hearing instrument. In case you are fitted with RITE Power,
never allow others to wear your hearing instruments as incorrect or wrongful usage
could cause permanent damage to their hearing.
Microphone openings
Push-button
Speaker unit
Sound outlet
Battery door
Wax protection
Caring for your hearing instrument 26
Daily maintenance with Mould 28
Daily maintenance with Domes 30
Using your hearing instrument 34
Common problems and their solutions 40
Warranty Certificate 44
Warnings Yellow Pages
5b
Instrument view RITE Power with Power Dome
Your ear piece
Power Domes:
8mm
10mm 12mm Plus dome
Battery door
Push-button
Microphone openings
Speaker
Sound outlet
Wax protection
5c
Instrument view RITE Power with Ear Mould
Sound outlet +
wax protection
system
Ventilations openings
Battery door
Push-button
Microphone openings
7
Changing batteries
Your hearing instrument battery size is 312. Batteries
perform differently. Ask your hearing care professional
for help choosing a high quality battery for your hearing
instrument.
A worn out battery should be removed immediately.
When the battery power is low, you will hear 2 beeps.
This pre-warning starts when the battery has only
a few hours of operation left. The pre-warning will be
repeated with moderate intervals to indicate it is time
to change the battery.
If the battery runs out the instrument turns off. When
that happens, 4 beeps are played to indicate that the
instrument is no longer operating.
It is not an indication of a malfunction.
9
Turning your instruments ON and OFF
Turn ON your hearing instrument by closing the battery door completely with the battery
in place. When the battery door is closed the instrument will start up by playing a jingle.
This indicates that the battery is working and the instrument is operating.
Turn OFF your hearing instrument by opening the battery door slightly until a click is felt.
To preserve the battery, make sure your hearing instrument is switched off when you are
not wearing it.
IMPORTANT NOTICE
Open the battery compartment
fully to allow air to circulate
whenever you are not using
your hearing instrument,
especially at night!
ON OFF
Click Click
To replace the battery, follow these instructions:
• Open the battery door completely by pushing the raised edge in the bottom of
the instrument. Remove the old battery.
• Remove the sticky label from the + side of the new battery.
• Insert the new battery so that its + marking faces the + sign printed on the
battery door. Close the battery door.
Any moisture on the battery surface should be wiped
off before use.
When you change battery, it will take a few seconds
before the battery works to full capacity.
To assist the handling of the batteries, the magnet
placed at the end of the tool can be used.
8
MultiTool
10 11
Left/Right ear marking
Hearing instruments are fitted to the uniqueness of each ear, which means if you have
two instruments then your left hearing instrument is programmed differently from your
right. That is why it is important to distinguish between the left hearing instrument and
the right.
In order to easily identify whether it is left ear or right ear instrument, colour markings
may be applied inside the battery door.
A blue dot marks the LEFT instrument.
A red dot marks the RIGHT instrument.
Putting on your instrument
Place the speaker, with the ear piece attached, into your ear
first (1) and then place the instrument behind your ear (2).
If the power instrument has a Mould as ear piece, make sure
it is positioned in the ear so it perfectly fits the ergonomics
of the ear canal in a tight and comfortable way.
Make sure that the ear piece is placed so that the tube
follows the contour of the skin.
If the instrument has an ear grip, place it in the ear as
indicated in drawing 3 and 4 so it follows the contour of
the ear.
2
1
3
4
12 13
Push-button
Your hearing instrument has an ergonomic designed push-button for volume adjustment
and switching between different programs.
The push-button can be pressed and activated on either the upper part (UP) or the lower
part (DOWN).
UP
DOWN
The push-button on your hearing instrument can be programmed to one of 3 functionalities.
Left Right
Program shift:
Press shortly to change program.
Volume control:
Press shortly to adjust the volume.
Both volume control and Program shift:
Press shortly to adjust the volume and press long
(about 2 seconds) to shift program.
Binaural Coordination enabled (see “Using 2 instruments”).
To be filled out by your Hearing Care Professional!
14 15
Programs (Optional)
Your hearing instrument can have up to 4 different programs.
When switching between the different programs, your hearing instrument will beep.
The number of beeps will indicate which program you are using.
One beep, when you switch to program 1
Two beeps, when you switch to program 2
Three beeps, when you switch to program 3
Four beeps, when you switch to program 4
Press the upper part to go forwards in the program cycle e.g from P1-P2.
Press the lower part to go backwards in the program cycle e.g from P3-P2.
Below you can see a description of the programs available in your hearing instrument.
Prg. 1:
Prg. 2:
Prg. 3:
Prg. 4:
Using 2 instruments
If you have two Ino Pro instruments the push-button on one instrument can be programmed to change the program on both hearing instruments (Binaural Coordination).
This means, when you adjust the program for one instrument, it automatically adjusts
the other.
