Wireless Site Lighting
Control Module
Wiring and installation manual
www.osram.us
Light is OSRAM
Page 2
Overview
The Wireless Site Lighting Control (WSLC) Module extends the ENCELIUM®
Networked Light Management System’s controls capability to a building’s
surroundings or site such as parking lots and short pathways, via a wireless
mesh network based on ZigBee® standards. The WSLC installs on top of a
luminaire via an ANSI C136.41 compliant 3, 5 or 7-pin twist-lock connector.
The WSLC is individually addressable via the ENCELIUM Wireless System
Manager and can switch luminaires ON/OFF via an integrated high current relay,
dim luminaires equipped with 0-10V dimming drivers or ballasts and has an
input for an external occupancy sensor.
Important Safeguards
When using electrical equipment, basic safety precautions should always
be followed including the following:
— READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
— Do not let power supply cords touch hot surfaces.
— Do not mount near gas or electric heaters. Equipment should be mounted in
locations and at heights where it will not readily be subjected to tampering
by unauthorized personnel.
— The use of accessory equipment is not recommended by OSRAM as it may
cause an unsafe condition.
— Do not use this equipment for other than the intended use.
SAVE THESE INSTRUCTIONS
Note
Tip
!
STOP
Note
Tip
!
STOP
Part Number
EN-OC-SLC-ZB
2
Ratings
Voltage
— Operating voltage: 120-347Vac;
50/60 Hz
Load Rating
— 120-347 Vac E-Ballast; 10A
— 120-347 Vac Resistive; 10A
— 120-347 Vac Tu ng sten; 10A
— 120-347 Vac General Purpose; 10A
Interface
— Dimming: 0 -10V; 10mA
(IEC 60929 Annex E)
— DEXAL™/DALI: 18-24V; 10mA
— Sensor: 18-24V, 20mA
Environmental
— Ambient temperature range:
-40°C to +65°C
— Protection classification: IP66
— Relative humidity: up to 95%
non-condensing
Listings
— UL: UL916/773
(File # E228301 USA and Canada)
Page 3
Module Installation
Ensure power to the receptacle has been disconnected before beginning
to remove/mount the receptacle.
1. Remove the shorting or open cap if supplied with the luminaire.
Note: Receptacle caps, if supplied with the luminaire, are used for closing or opening the socket circuit. In addition,
these c aps can offer weatherproof protection for the receptacles that are not yet fitted with the WS LC Module.
WSLCs can be installed on luminaires that feature ANSI C136.41-compliant
receptacles.
3
2. Place the WSLC Module firmly into the receptacle (not supplied by OSRAM)
and twist it clockwise (Install arrow) until it locks in place.
Note
Tip
!
STOP
BLACK: Line In
RED: AC to Driver
GREY/-: Control to Driver
VIOLET/ +: Control to Driver
WHITE: Neutral
ORANGE: Sensor Power Supply
BROWN: Sensor Input
3. Mount the control with the arrow and ‘N’ on the cover facing north.
Note: The re cepta cle assembly may have to be rotated to face north.
Receptacle
Control Module Cap
O
R
G
S
e
n
s
o
r
P
o
w
e
r
B
R
N
S
e
n
s
o
r
I
n
p
u
t
G
R
Y
(
-
)
/
0
-
1
0
V
V
I
O
(
+
)
/
0
-
1
0
V
O
R
G
S
e
n
s
o
r
P
o
w
e
r
B
R
N
S
e
n
s
o
r
I
n
p
u
t
G
R
Y
(
-
)
/
0
-
1
0
V
V
I
O
(
+
)
/
0
-
1
0
V
Page 4
© 2017 OSRAM SYLVANIA Inc.
LM S13 8R2 12-17
Operation
The WSLC Module is configured using ENCELIUM® Networked Light
Management System software and features the following functionalities:
— Individual addressability
— Time schedule-based control
— Daylight-based control
— Astronomical schedule-based control
— Occupancy-based control*
*Requires OSRAM approved 3rd party outdo or occupancy s ensor.
Troubleshooting
There are no user-serviceable parts inside the WSLC. Please return the device
to OSRAM if service is required.
Regulatory Approvals
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
Modifications not expressly approved by the manufacturer could void the user’s
authority to operate the equipment under FCC rules.
This equipment has been tested and found to comply with Industry Canada
ICES-003 Issue 5 (CAN ICES-3 (A)/NMB-3(A)).
Contains FCC ID: H79DFZM-E7210
Contains IC ID: 4259B-DFZM7210
OSRAM SYLVANIA Inc.
200 Ballardvale Street
Wilmington, MA 01887 USA
888-531-7573
www.osram.us/ds
OSRAM is a registered tradema rk of OSR AM GmbH.
ENCELIUM is a registerd tradema rk of OSR AM SYLVANIA Inc.
DEX AL is a trademark of OSR AM SYLVANIA Inc.
ZigBe e is a registered trademark o f the ZigBee A lliance..
Specifications subject to change without notice.
