Product datasheet
LIGHTIFY Plug
LIGHTIFY Plug |
__
Product benefits
_
_
_
Product features
_
_
_
Expansion of the LIGHTIFY system by integrating conventional light sources
Enables switching of conventional light sources and other electric devices
Just put LIGHIFY Plug into a socket and connect luminaires or other devices
Switchable adapter plug to connect non-ZigBee devices to the LIGHTIFY system
Control via LIGHTIFY app, LIGHTIFY Switch or by pushing button on device (on/off)
High switching power: up to 3,680 W / 16 A
January 13, 2016, 11:11:30 © 2016, OSRAM GmbH. All rights reserved.
LIGHTIFY Plug Page 1 of 3
Product datasheet
Technical data
Electrical data
Operating frequency 50 Hz
Nominal voltage 220…240 V
Maximum switchable current 16 A
Maximum switchable wattage 3680 W
Rated value of impulse withstand voltage 1500 V
Type of load Ohm resistive load
Dimensions & weight
__
Product weight 131.00 g
Length 84.0 mm
Width 60.0 mm
Height 60.0 mm
Temperatures & operating conditions
Ambient temperature range -20…+40 °C
Capabilities
Overload protection Yes
Overheating protection Yes
Certificates & standards
Protection class I
Type of protection IP20
Proof tracking index (PTI) ≥ 600
Duty type S1
Pollution degree acc. to IEC 60664 1
January 13, 2016, 11:11:30 © 2016, OSRAM GmbH. All rights reserved.
LIGHTIFY Plug Page 2 of 3
Product datasheet
Equipment / Accessories
_
LIGHTIFY APP required
_
LIGHTIFY Gateway required
Safety advice
Disconnect devices which generate heat from the mains, i.e. from the LIGHTIFY Plug, after use in order to avoid them being
accidentally switched on.
Very high capacitive and inductive loads may in some cases lead to destruction of the device or reduction in the number of
switching cycles.
Do not use the LIGHTIFY Plug in conjunction with medical equipment.
To be connected to a B16A automatic circuit breaker
Logistical Data
Product code Product description Packaging unit
(Pieces/Unit)
4052899290877 LIGHTIFY Plug Shipping carton box4211 mm x 167 mm x
Dimensions (length
x width x height)
141 mm
Volume Gross weight
4.97 dm³ 992.00 g
The mentioned product code describes the smallest quantity unit which can be ordered. One shipping unit can contain one or
more single products. When placing an order, for the quantity please enter single or multiples of a shipping unit.
__
Disclaimer
Subject to change without notice. Errors and omission excepted. Always make sure to use the most recent release.
January 13, 2016, 11:11:30 © 2016, OSRAM GmbH. All rights reserved.
LIGHTIFY Plug Page 3 of 3
