OSRAM LB L29G Technical data

®
SmartLED Enhanced Optical Power LED (ThinGaN
0603
®
Lead (Pb) Free Product - RoHS Compliant
LB L29G
)
Gehäusetyp: standard SMT Footprint 0603, farbloser diffuser Verguss
Besonderheit des Bauteils: kleinste Bauform 1,7 x 0,8 x 0,65 mm (LxBxH); mehr Licht durch erhöhten optischen Wirkungsgrad
Wellenlänge:
Abstrahlwinkel: 150°
Technologie: ThinGaN
optischer Wirkungsgrad: 7lm/W
Gruppierungsparameter: Lichtstärke, Wellenlänge, Durchlassspannung
Verarbeitungsmethode: für alle SMT-Bestücktechniken geeignet
Lötmethode: IR Reflow Löten und Wellenlöten (TTW)
Vorbehandlung: nach JEDEC Level 2
Gurtung: 8-mm Gurt mit 5000/Rolle, ø180 mm
ESD-Festigkeit: ESD empfindliches Bauteil
470 nm (blau)
®
Features
package: standard SMT footprint 0603, colorless diffused resin
feature of the device: smallest package
1.7 x 0.8 x 0.65 mm (LxWxH); more light due to higher optical efficiency
wavelength:
viewing angle: 150°
technology: ThinGaN
optical efficiency: 7lm/W
grouping parameter: luminous intensity, wavelength, forward voltage
assembly methods: suitable for all SMT assembly methods
soldering methods: IR reflow soldering and TTW soldering
preconditioning: acc. to JEDEC Level 2
taping: 8 mm tape with 5000/reel, ø180 mm
ESD-withstand voltage: ESD sensitive device
470 nm (blue)
®
Anwendungen
flache Hinterleuchtung (LCD, Mobile Phone, Schalter, Display)
Spielsachen
Signal- und Symbolleuchten
Markierungsbeleuchtung (Stufen, Fluchtwege u. ä.)
2005-10-07 1
Applications
flat backlighting (LCD, cellular phones, switches, displays)
•toys
signal and symbol luminary
marker lights (e.g. steps, exit ways, etc.)
LB L29G
Bestellinformation Ordering Information
Typ
Emissions-
Lichtstärke
1) Seite 15
Lichtstrom
farbe
Type
Color of Emission
Luminous Intensity
I
= 10 mA
F
I
(mcd)
V
1) page 15
Luminous
2) page 15
Flux
I
= 10 mA
F
Φ
(mlm)
V
LB L29G-P2R1-35-1 blue 56 ... 140 455 (typ.) Q65110A3461
2) Seite 15
Bestellnummer
Ordering Code
Anm.: Die oben genannten Typbezeichnungen umfassen die bestellbaren Selektionen. Diese bestehen aus wenigen
Note: The above Type Numbers represent the order groups which include only a few brightness groups (see page 5 for
Helligkeitsgruppen (siehe Seite 5 für nähere Informationen). Es wird nur eine einzige Helligkeitsgruppe pro Gurt geliefert. Z.B.: LB L29G-P2R1-35-1 bedeutet, dass auf dem Gurt nur eine der Helligkeitsgruppen P2, Q1, Q2 oder R1 enthalten ist. Um die Liefersicherheit zu gewährleisten, können einzelne Helligkeitsgruppen nicht bestellt werden.
Gleiches gilt für die Farben, bei denen Wellenlängengruppen gemessen und gruppiert werden . Pro Gurt wird nur e ine Wellenlängengruppe geliefert. Z.B.: LB L29G-P2R1-35-1 bedeutet, dass auf dem Gurt nur eine der Wellenlängengruppen -3, -4 oder -5 enthalten ist (siehe Seite 5 für nähere Information). Um die Liefersicherheit zu gewährleisten, können einzelne Wellenlängengruppen nicht bestellt werden.
Gleiches gilt für die LEDs, bei denen die Durchlassspannungsgruppen gemessen und gruppiert werden. Pro Gurt wird nur eine Durchlassspannungsgruppe geliefert. Z.B.: LB L29G-P2R1-35-1 bedeutet, dass nach Durchlassspannung gruppiert wird. Auf einem Gurt ist nur eine der Durchlasspannungsgruppen -3B, 4A, 4B oder -5A enthalten (siehe Seite 5 für nähere Information). Um die Liefersicherheit zu gewährleisten, können einzelne Durchlassspannungsgruppen nicht direkt bestellt werden.
explanation). Only one group will be shipped on each reel (there will be no mixing of two groups on each reel). E.g. LB L29G-P2R1-35-1 means that only one group P2, Q1, Q2 or R1 will be shippable for any one reel. In order to ensure availability, single brightness groups will not be orderable.
In a similar manner for colors where wavelength groups are measured and binned, single wavelength groups will be shipped on any one reel. E.g. LB L29G-P2R1-35-1 means that only 1 wavelength group -3, -4 or -5 will be shippable. In order to ensure availability, single wavelength groups will not be orderable (see page 5 for explanation).
In a similar manner for LED, where forward voltage groups are measured and binned, single forward voltage groups will be shipped on any one reel. E.g. LB L29G-P2R1-35-1 means that only 1 forward voltage group -3B, 4A, 4B or -5A will be shippable. In order to ensure availability, single forward voltage groups will not be orderable (see page 5 for explanation).
Vergleichstabelle Correlation Table
Typ
Lichtstärke
2)
Seite 15
Lichtstärke
1)
Seite 15
Lichtstärke
2)
Seite 15
Type
Luminous Intensity
I
= 5 mA
F
I
(mcd)
V
2) page 15
Luminous Intensity
I
= 10 mA
F
I
(mcd)
V
1) page 15
Luminous Intensity
I
= 20 mA
F
I
(mcd)
V
2) page 15
LB L29G-P2R1-35-1 25 ... 78 56 ... 140 100 ... 310
2005-10-07 2
Grenzwerte Maximum Ratings
LB L29G
Bezeichnung Parameter
Betriebstemperatur Operating temperature range
Lagertemperatur Storage temperature range
Sperrschichttemperatur Junction temperature
Durchlassstrom Forward current
T
=25°C)
(
A
Stoßstrom Surge current
t = 10 μs, D = 0, T
Sperrspannung Reverse voltage
=25°C
A
3) Seite 15
3) page 15
(TA=25°C) Leistungsaufnahme
Power consumption
T
=25°C)
(
A
Wärmewiderstand Thermal resistance Sperrschicht/Umgebung Junction/ambient
4) page 15
4) Seite 15
Sperrschicht/Lötpad Junction/solder point
Symbol Symbol
T
op
T
stg
T
j
I
F
I
FM
V
R
P
tot
R
th JA
R
th JS
Wert Value
Einheit Unit
– 40 … + 100 °C
– 40 … + 100 °C
+ 110 °C
20 mA
300 mA
5V
75 mW
380
160
K/W
K/W
2005-10-07 3
Kennwerte Characteristics
T
= 25 °C)
(
A
Bezeichnung Parameter
Symbol Symbol
Wert Value
LB L29G
Einheit Unit
Wellenlänge des emittierten Lichtes (typ.) Wavelength at peak emission
I
= 10 mA
F
Dominantwellenlänge Dominant wavelength
I
= 10 mA
F
Spektrale Bandbreite bei 50 % Spectral bandwidth at 50 %
I
= 10 mA
F
Abstrahlwinkel bei 50 % Viewing angle at 50 %
Durchlassspannung Forward voltage
I
= 10 mA (max.)
F
5) Seite 15
5) page 15
6) Seite 15
6) page 15
I
(typ.)
rel max
I
rel max
I
(Vollwinkel) (typ.)
V
I
V
(min.)
(typ.)
Sperrstrom (typ.) Reverse current (max.)
V
= 5 V
R
Temperaturkoeffizient von Temperature coefficient of
I
= 10 mA; –10°C T ≤ 100°C
F
Temperaturkoeffizient von Temperature coefficient of
I
= 10 mA; –10°C T ≤ 100°C
F
Temperaturkoeffizient von Temperature coefficient of
I
= 10 mA; –10°C T ≤ 100°C
F
V
λ λ
λ λ
V
peak peak
dom dom
F
F
(typ.)
(typ.)
(typ.)
Optischer Wirkungsgrad (typ.) Optical efficiency
I
= 10 mA
F
* Einzelgruppen siehe Seite 5
Individual groups on page 5
λ
λ
peak
dom
465 nm
470*
nm
± 6
Δλ 25 nm
2ϕ 150 Grad
deg.
V
F
V
F
V
F
I
R
I
R
TC
TC
TC
η
opt
λpeak
λdom
V
2.75
3.0
3.35
0.01 10
V V V
μA μA
0.02 nm/K
0.02 nm/K
– 4.0 mV/K
7lm/W
2005-10-07 4
LB L29G
Wellenlängengruppen
(Dominantwellenlänge)
5) Seite 15
Wavelength Groups (Dominant Wavelength)
Gruppe Group
5) page 15
blau blue
Einheit Unit
min. max.
3 464 468 nm 4 468 472 nm 5 472 476 nm
Helligkeits-Gruppierungsschema Brightness Groups
Helligkeitsgruppe Brightness Group
P2 Q1 Q2 R1
Lichtstärke Luminous Intensity
I
(mcd)
V
56 … 71 71 … 90 90 … 112
112 … 140
Durchlassspannungsgruppen
Forward Voltage Groups
Gruppe Group
Durchlassspannung
Forward Voltage
6) page 15
min. max.
3B 2.75 2.90 V 4A 2.90 3.05 V 4B 3.05 3.20 V 5A 3.20 3.35 V
1) Seite 15
1) page 15
Lichtstrom Luminous Flux
Φ
(mlm)
V
300 (typ.) 380 (typ.) 480 (typ.) 600 (typ.)
6) Seite 15
Einheit Unit
2) Seite 15
2) page 15
Anm.: Die Standardlieferform von Serientypen beinhaltet eine Familiengruppe. Diese besteht aus
4 Helligkeitsgruppen. Einzelne Helligkeitsgruppen sind nicht bestellbar.
Note: The standard shipping format for serial types includes a family group of 4 individual brightness
groups. Individual brightness groups cannot be ordered.
Gruppenbezeichnung auf Etikett Group Name on Label
Beispiel: P2-4-4B Example: P2-4-4B
Helligkeitsgruppe Brightness Group
Farbortgruppe Chromaticity Coordinate
Durchlassspannung Forward Voltage
Group
P2 4 4B
Anm.: In einer Verpackungseinheit / Gurt ist immer nur eine Gruppe für jdede Selektion enthalten. Note: No packing unit / tape ever contains more than one group for each selection.
2005-10-07 5
LB L29G
Relative spektrale Emission Relative Spectral Emission
2) Seite 15
2) page 15
V(λ) = spektrale Augenempfindlichkeit / Standard eye response curve
I
= f (λ); TA = 25 °C; IF = 10 mA
rel
100
%
I
rel
80
V
λ
blue
60
40
20
OHL01492
0
400 550450 500 600
Abstrahlcharakteristik
2) Seite 15
Radiation Characteristic
I
= f (ϕ); TA = 25 °C
rel
50˚
60˚
70˚
80˚
90˚
2) page 15
650 nmλ700
10˚20˚30˚40˚
ϕ
1.0
OHL02360
vertical
horizontal
0.8
0.6
vertical
horizontal
0.4
0.2
0
100˚
2005-10-07 6
20˚ 40˚ 60˚ 80˚ 100˚ 120˚0.40.60.81.0
LB L29G
Durchlassstrom Forward Current
I
= f (VF); TA = 25 °C
F
2
10
2) Seite 15
2) page 15
mA
I
F
5
1
10
5
0
10
2.5
3 3.5 4 4.5 V 5
Relative Vorwärtsspannung Relative Forward Voltage
ΔVF = VF - V
0.4 V
V
Δ
F
0.3
= f (Tj); IF = 10 mA
(25 °C)
F
2) page 15
2)
Seite 15
OHL02359
V
F
OHL02397
Relative Lichtstärke
2) 7) Seite 15
Relative Luminous Intensity
I
V/IV(10 mA)
I
Relative Lichtstärke
= f (IF); TA = 25 °C
1
10
I
V
V (10 mA)
0
10
5
-1
10
0
10
5
2) Seite 15
10
Relative Luminous Intensity
I
V/IV(25 °C)
I
= f (Tj); IF = 10 mA
1.10
I
V
V (25 ˚C)
2) 7) page 15
1
2) page 15
OHL02324
10
mA
I
F
OHL02401
2
0.2
0.1
0
-0.1
-0.2
-0.3
-60
-40 -20 0 20
˚C6040
100
T
j
2005-10-07 7
1.05
1.00
0.95
0.90
-60
-40 -20 0 20
˚C6040
100
T
j
LB L29G
Dominante Wellenlänge Dominant Wavelength
λ
= f (IF); TA = 25 °C
dom
476
nm
λ
dom
474
472
470
468
466
464
462
0mA
20 40 60 10010 30 50 70 80
2) page 15
2) Seite 15
OHL02479
I
F
2005-10-07 8
Maximal zulässiger Durchlassstrom Max. Permissible Forward Current
I
= f (T)
F
25
mA
I
F
OHL02410
20
15
T
10
5
temp. ambient
T
A
temp. solder point
T
S
0
020
40 60
80
T
S
A
˚CT100
Exemplarische mittlere Lebensdauer für Helligkeitsgruppe P1 Exemplary median Lifetime
2) page 15
for Brightness Group P1
Bedingungen
mittlere
Einheit
Lebensdauer
Conditions
median
Unit
Lifetime
IF = 10 mA T
= 25°C
A
= 5 mA
I
F
T
= 85°C
A
1000 Betriebsstunden
operating hours
500 Betriebsstunden
operating hours
LB L29G
2)
Seite 15
Zulässige Impulsbelastbarkeit
I
= f (tp)
F
Permissible Pulse Handling Capability
Duty cycle
0.35 A
I
F
0.25
0.20
0.15
0.10
0.05
0
D = parameter, T
-5 1
-4
-3 -2
10
10 10
10
D
=
D
=
0.005
0.01
0.02
0.05
0.1
0.2
0.5 1
= 25 °C
A
t
P
t
P
T
-1 0
1010
OHL02411
T
10 10s
t
p
Zulässige Impulsbelastbarkeit
I
= f (tp)
F
Permissible Pulse Handling Capability
Duty cycle
D = parameter, T
0.35 A
I
F
I
F
0.25
0.20
0.15
0.10
0.05
2
0
10
-5
-4 -310-2 -1
10
1010
D
=
T
=
D
0.005
0.01
0.02
0.05
0.1
0.2
0.5 1
= 85 °C
A
t
P
t
P
10
OHL02412
T
0
t
I
F
1
2
1010
s
p
2005-10-07 9
LB L29G
Maßzeichnung Package Outlines
8) Seite 15
8) page 15
0.8 (0.031)
0.7 (0.028)
±0.1 (0.004)
Cathode
marking
±0.05 (0.002)
0.125 (0.005)
7˚ max
±0.1 (0.004)
1.7 (0.067)
0.65 (0.026)
+0.05 (0.002)
-0.03 (0.001)
Cathode
marking
+0.02 (0.001)
-0.05 (0.002)
Gewicht / Approx. weight: 1,4 mg
Gurtung / Polarität und Lage
8) Seite 15
Method of Taping / Polarity and Orientation
8) page 15
Verpackungseinheit 5000/Rolle, ø180 mm Packing unit 5000/reel, ø180 mm
A
±0.1 (0.004)
1.3 (0.051)
C
GPLY7001
1.5 (0.059)
2 (0.079)
Empfohlenes Lötpaddesign Recommended Solder Pad
8) 9) Seite 15
8) 9) page 15
4 (0.157)
0.9 (0.035)
0.7 (0.028)
0.8 (0.031)
1.75 (0.069)
3.5 (0.138)
8 (0.315)
IR Reflow Löten IR Reflow Soldering
0.8 (0.031)
OHAPY606
C
1.8 (0.071)
A
0.8 (0.031)
OHAY1491
0.8 (0.031)
2005-10-07 10
LB L29G
Lötbedingungen Vorbehandlung nach JEDEC Level 2 Soldering Conditions Preconditioning acc. to JEDEC Level 2 IR-Reflow Lötprofil für bleifreies Löten (nach J-STD-020B) IR Reflow Soldering Profile for lead free soldering (acc. to J-STD-020B)
300
˚C
250
T
200
255 ˚C 240 ˚C
217 ˚C
Maximum Solder Profile
Recommended Solder Profile
Minimum Solder Profile
10 s min
30 s max
OHLA0687
260 ˚C 245 ˚C 235 ˚C
+0 ˚C
-5 ˚C ±5 ˚C +5 ˚C
-0 ˚C
150
100
50
120 s max
Ramp Up 3 K/s (max)
25 ˚C
0
0
50 100 150 200 250 300
100 s max
Ramp Down 6 K/s (max)
Wellenlöten (TTW) (nach CECC 00802) TTW Soldering (acc. to CECC 00802)
300
C
250
T
235 C
C... 260
200
1. Welle
1. wave
150
ca 200 K/s
CC... 130100
100
10 s
5 K/s
2. Welle
2. wave
2 K/s
s
t
OHLY0598
Normalkurve standard curve
Grenzkurven limit curves
50
2 K/s
Zwangskühlung forced cooling
0
0
50 100 150 200 250
2005-10-07 11
s
t
Barcode-Produkt-Etikett (BPL) Barcode-Product-Label (BPL)
LB L29G
Gurtverpackung Tape and Reel
OSRAM Opto
Semiconductors
(6P) BATCH NO: Batch Number
Bar Code
Lot Number(1T) LOT NO: (9D) D/C: Date Code
Bar Code
(X) PROD NO: Product Code
D
0
P
0
P
2
Bin1: Bin Information Color 1
Lx xxxx
Product Name
RoHS Compliant
Product Quantity per Reel(Q)QTY:
Bar Code
Sample
W
1
±0.25
13.0
FE
A
N
W
Bin2: Bin3:
Temp ST
ML 2
260 C RT
Additional TEXT R077 DEMY PACKVAR: Packing Type
X - X - X(G) GROUP:
Forward Voltage Group
Wavelength Group
Brightness Group
OHA12043
P
1
Direction of unreeling
W
2
Label
Gurtvorlauf: Leader:
Gurtende: Trailer:
Direction of unreeling
400 mm 400 mm
160 mm 160 mm
OHAY0324
Tape dimensions in mm (inch)
W P
+ 0.3
8
– 0.1
0
4 ± 0.1 (0.157 ± 0.004)
P
1
2 ± 0.05 (0.079 ± 0.002)
P
2
2 ± 0.05 (0.079 ± 0.002)
D
0
1.5 + 0.1 (0.059 + 0.004)
E F
1.75 ± 0.1 (0.069 ± 0.004)
3.5 ± 0.05 (0.138 ± 0.002)
Reel dimensions in mm (inch)
A W N
min
W
1
W
2 max
180 (7) 8 (0.315) 60 (2.362) 8.4 + 2 (0.331 + 0.079) 14.4 (0.567)
2005-10-07 12
LB L29G
Trockenverpackung und Materialien Dry Packing Process and Materials
Moisture-sensitive label or print
L
E
V
l
E
e
e
b
e
L
a
s
.
l
,
)
e
k
H
d
n
o a l
R
c b
(
r
If
a
y
t
b
. i d
H
i
R
m
u
%
h
0
e
6
e
/
iv
g
d
t
C
a
e r
˚
la
k
a
0
c
r
S
re
f
3
a
N
E
s
R
n
p
_
<
i
%
IV
in
f
O
k
0
o
O
T
s
o
t
T
I
a
r
ta
9
I
e
s
S
u
s
C
n
d
).
r
r
p
n
o
<
e
N
o
U
e
T
o
u
s
t
(
o
d
r
i
d
E
,
c
o
D
c
H
g
n
it
u
o
e
rs
C
g
U
a
b
A
R U
is
T
h
C
E
T
IS
S
O
O
M
T
P
n
O
o
m
v
4
e
2
,
d
:
,
g
w
d
a
lo
e
b
f
n
d
re
e
e e l
p
e
e
a
o
s
s
e
a
,
is
s
h
k
o
l
n
g
n
-p
i
F
a
r
a
l
in
R o
b
b
h
fe
p
%
it
li
f
s
.
i
I
a
0
a
f
p
w
l
h
v
1
b
e
t
,
m
d
_
<
r
h
e
c
e
e
w
i
r
e
t
t
t
i
S
t
o
d
f
a
n
u
y
.
fl
n
n
u
A
I q
d
1
d
e
o
.
r
e
s
o
r
re
ty
2
i
b
i
M
o
s
b
t
)
re
id
e
2
a
S
c
P
r
m
is
i
I
)
o
u
v
b
g
e
e
H
a
c
in
D
)
n
k
2
.
a
)
a re
3
b
d
b
e f
l
f I
e
a
r
.
e
4
s
n
g
a
a B
e t a
s i
D
o M
o
M
M
2
n
H
N
j
a
S
d
o
i
c
˚
u
b
s
n
7
O
E
8
H
o
e
5
u
s
o
t
4
˚C
C
e
s
4
H
e
I
c
a
±
c
2
0
m
d
e
y
M
h t e ic r o r a b r o . H in k to a m t o u q C
te a
d r u t tu s i o M
6
o
4
r
ti
be
r
h
˚C
m
e
o
l
r
i
p
<
t
it
.
il
o
t
3
c
m
t
e
)
t
r
i
w
o
2
w
t
a
n
a
l
o
C
l
m
t
t
i
˚
f
r
e
.
F
o
a
t
l
s
t
l
a
a
o
e
a
a
r
ic
r
h
F
l
o
t
d
v
t
l
o
i
u
e
n
:
a
F
o
u
s
f
d
l
b
e
e
w
4
i
q
e
l
r
a
F
,
d
l
i
5
c
e
lo
e
g
a
n
l
o
v
e
e
s
n
5
r
e
e
i
e
b
d
i
t
l
p
h
v
6
o
e
n
e
L
e
t
e
l
w
c
e
v
u
e
e
a
L
k
e
r
e
o
d
v
a
s
%
u
e
L
l
t
r
m
e
b
e
0
s
a
u
L
i
r
t
e
re
m
e
1
i
r
o
o
s
e
t
u
s
i
>
t
o
r
f
f
M
,
o
u
3
is
k
is
e
t
3
M
o
n
b
is
d
a
,
r
-0 M
o
l
g
a
D
M
b
C
r
T
if (
r
.
S
t
r
­s
ea
e
a
J
k
s
e
Y
r
e
,
C
1
u
e
d
Y
E
o
>
1
W
re
D
H
i
e
4
E
8
m
e
6
/J
i t
1
:
e
r
im t
d
o
m
e
r
e
i o l
o
n
t
m
r
F
o
e
ti
l
o
p
r F
o
o
l
o
F
e
lo
1
l
F
2
im
e
a
t
l
v
e
2
e
l
v
L
e
3
e
l
v
e
L
e
e
v
L
re
e
L
re
e u t
r s
u
i
t is o
M
A
R
S
O
Desiccant
Anm.: Feuchteempfindliche Produkte sind verpackt in einem Trockenbeutel zusammen mit einem Trockenmittel und
einer Feuchteindikatorkarte Bezüglich Trockenverpackung finden Sie weitere Hinweise im Internet und in unsere m Short Form Catalog im Kapitel “Gurtung und Verpackung” unter dem Punkt “Trockenverpackung”. Hier sind Normenbezüge, unter anderem ein Auszug der JEDEC-Norm, enthalten.
Note: Moisture-senisitve product is packed in a dry bag containing desiccant and a humidity card.
Regarding dry pack you will find further information in the internet and in the Short Form Catalog in chapter “Tape and Reel” under the topic “Dry Pack”. Here you will also find the normative references like JEDEC.
Kartonverpackung und Materialien Transportation Packing and Materials
Barcode label
Do not eat.
Avoid metal contact.
Discard if circles overrun.
bag opening.
Please check the HIC immidiately after
check dot
WET
Comparator
bake units
15%
examine units, if necessary If wet,
bake units
10%
examine units, if necessary If wet,
change desiccant
5%
parts still adequately dry. If wet,
MIL-I-8835 Humidity Indicator
OSRAM
Humidity indicator
Barcode label
OHA00539
Barcode label
L
E
V
l
E
e
e
b
e
L
a
s
l
,
).
e
k
H
d
n
o
a
l
c
b
r
If
a b
.
idity (R
m
RH
%
hu
tive
C/60
red
a
0 ˚
ckage
fr
3
N
E
rela
RS
_
<
in
f
0%
to
TO
ak pa
IO
s o
SITIV
ntains
).
UC
T
n
ND
U
a
A
RE SEN
˚C
ICO
su
e
M
C
40
roce
This bag co
ill b
SE
t p
t <
).
OISTU
n
t w
˚C
M
le
PTO
ha
iva
nths a
O
bel
o
w
la
m
ices t
equ
v
belo
de
or
: 24
e
co
, de
r
ag
ou
a
b
e se
ned
re m
pe
ee b
aled
r tim
ase reflow,
efo
o
, s
.
h
lo
H
, b
g is o
rd is > 10%
F
a
lank
in
D
R
or-p
ing
%
ith
r C
is ba
If b
0
ak
p.
to
et.
w
1
b
J-ST
, vap
_
<
,
helf life in se
C
w
t m
ire
E
fter th
. S
at
unted
D
qu
dy tem
1
d
o
reflo
re
quired
2. A re
bo
/JE
b is no
to
) M
idity Indica
C
es
a
d:
r 2
e
is re
IP
um
vic
b) S
e
F
a o
ce
) H
pen
te
king
a
o
ren
3. D b) 2
e
al da
el 1
refe
. If ba
4
el 2
d tim
se
l 2a
n
Lev
l 3
a
re
Lev
eve
Bag
ve
L
e
ate
D
re
oistu
re L
M
oisture
M
oistu
M
oistu M
2005-10-07 13
ours d < 9 bje
t fac a
nt
-0
or tim lo loo F
urs
rs
de
, or
cted
o
u
rs
2 H
dition
o
H
u
co
o
7
H
ssing (pe
te
e
4
48
± 5 ˚C
H
e
ry con
e 2
r tim
˚C
to
ith da
e 6
23
loo
l w
t
r tim
F
loor tim
o
e.
a
F
tica
d
lo
ur
F
loor tim
en
F
ced
g, if:
n rea
ro
in
he
p
Level 4
el 5a
te is id
evel 5
l 6
w
e
L
ev
re
al da
isture
Lev
re L
o
re
for bake
M
oistu
istu
33
M
o
M
oistu
M
(if blank, se
ar
r
s
e
ea
ek
urs
e
o
W
e > 1 Y
8 H
e 1 Y
6 e 4 e 1
r tim or tim
r tim
lo
F
Floo
0
2
­0
1
2
-
-
P
1
-
:
1
Q
T
n
:
i
S
2
B
n
:
p
i
R
3
B
m
n
Y
i
C
e
R
M
B
T
T
76
0
C
E
2
R
T
D
2
L
D
0
C
X
4
T6
M
2
E
0
LE
Y
6
T
2
l
2
P
a
a
2
18
LS
n
O
o i
R
-1
3
t i
:
d
Q
R
d
lti T
7
A
A
7
V
u
0
-1+
K
R
M
C
P
A
:
P
P
U O R
G
) G (
0144
98
:
C
rs
/ D
to
)
c
D 9
u
00219
(
d n
21
o
:
4
O
2000
ic
:
N
23
Y
m
OSRAM Opto
1
H
T
e
C
H
Q
S
T
)
A
Q
( B )
23G
P
1
6
:
(
O
245
N T
1
Muster
O L
0
)
0
T 1
11
(
: O N
D O R
P
) X (
Packing Sealing label
Barcode label
0
0
-1-2
-1-2
: P
T
in1
S
B
p
in2: Q
3:
R
B
m
Y
6
e
R
Bin
T
T
7
0 C
EM
2
C
6
R
T
D
2
L
D
X
C
T
M
E
240
0
E
L
Y
2
26
l T
8
P
S
a 2
1
L
O
1
R
-
3
T
itiona
:
i
Q
R
t
dd
l
A
+
A
V
u
1
077
-
K
R
M
C
P
A
:
P
P
U O R
) G
(G
4 4 1
8
0
:
s
/C
199
) D
Opto
ctor
D
02
(9
0
10
ndu
0
2
:
0
4
O
2
3
ico
:
2
N
OSRAM
1
H
TY
em
C
H
S
T
)Q
G
(Q
3
) BA
2
P
1
:
(6
O
245
N T
1
Muster
O
0
0
11
(1T) L
: O N
D
O ) PR (X
OSRAM
OHA02044
LB L29G
Revision History: 2005-10-07
Previous Version:
Page Subjects (major changes since last revision) Date of change
5 Forward Voltage Groups 2005-10-07
Attention please!
The information describes the type of component and shall not be considered as assured characteristics. Terms of delivery and rights to change design reserved. Due to technical requirements components may contain dangerous substances. For information on the types in question please contact our Sales Organization. If printed or downloaded, please find the latest version in the Internet.
Packing
Please use the recycling operators known to you. We can also help you – get in touch with your nearest sales office. By agreement we will take packing material back, if it is sorted. You must bear the costs of transport. For packing material that is returned to us unsorted or wh ich we are not obliged to accept, we shall hav e to invoice you for any costs incurred.
Components used in life-support devices or systems must be expressly authorized for such purpose! Critical components OSRAM OS.
2005-10-07 14
10) page 15
may only be used in life-support devices or systems
11) page 15
with the express written approval of
LB L29G
Fußnoten:
1)
Helligkeitswerte werden mit einer Stromeinprägedauer von 25 ms und einer Genauigkeit von ± 11% ermittelt.
2)
Wegen der besonderen Prozessbedingungen bei der Herstellung von LED können typische oder abgeleitete technische Parameter nur aufgrund statistischer Werte wiedergegeben werden. Diese stimmen nicht notwendigerweise mit den Werten jedes einzelnen Produktes überein, dessen Werte sich von typischen und abgeleiteten Werten oder typischen Kennlinien unterscheiden können. Falls erforderlich, z.B. aufgrund technischer Verbesserungen, werden diese typischen Werte ohne weitere Ankündigung geändert.
3)
Die LED kann kurzzeitig in Sperrichtung betrieben werden.
4)
R
ergibt sich bei Montage auf PC-Board FR 4
thJA
(Padgröße 5mm
5)
Wellenlängen werden mit einer Stromeinprägedauer von 25 ms und einer Genauigkeit von ±1 nm ermittelt.
6)
Spannungswerte werden mit einer
2
je Pad)
Stromeinprägedauer von 1 ms und einer Genauigkeit von ±0,1 V ermittelt.
7)
Im gestrichelten Bereich der Kennlinien muss mit erhöhten Helligkeitsunterschieden zwischen Leuchtdioden innerhalb einer Verpackungseinheit gerechnet werden
8)
Maße werden wie folgt angegeben: mm (inch)
9)
Gehäuse hält TTW-Löthitze aus
10)
Ein kritisches Bauteil ist ein Bauteil, das in lebenserhaltenden Apparaten oder Systemen eingesetzt wird und dessen Defekt voraussichtlich zu einer Fehlfunktion dieses lebenserhaltenden Apparates oder Systems führen wird oder die Sicherheit oder Effektivität dieses Apparates oder Systems beeinträchtigt.
11)
Lebenserhaltende Apparate oder Systeme sind für (a) die Implantierung in den menschlichen Körper oder (b) für die Lebenserhaltung bestimmt. Falls sie versagen, kann davon ausgega ngen werden, dass die Gesundheit und das Leben des Patienten in Gefahr ist.
Remarks:
1)
Brightness groups are tested at a current pulse duration of 25 ms and a tolerance of ± 11%.
2)
Due to the special conditions of the manufacturing processes of LED, the typical data or calculated correlations of technical parameters can only reflect statistical figures. These do not necessarily correspond to the actual parameters of each single product, which could differ from the typical data and calculated correlations or the typical characteristic line. If requested, e.g. because of technical improvements, th ese typ . data w ill be changed without any further notice.
3)
Driving the LED in reverse direction is suitable for short term application.
4)
R
results from mounting on PC board FR 4
thJA
(pad size 5mm
5)
Wavelengths are tested at a current pulse duration of 25 ms and a tolerance of ±1 nm.
6)
Forward voltages are tested at a current pulse
2
per pad)
duration of 1 ms and a tolerance of ±0.1 V.
7)
In the range where the line of the graph is broken , you must expect higher brightness differences between single LEDs within one packing unit.
8)
Dimensions are specified as follows: mm (inch)
9)
Package able to withstand TTW-soldering heat
10)
A critical component is a component used in a life-support device or system whose failure can reasonably be expected to cause the failure of that life-support device or system, or to affect its safety or the effectiveness of that device or system.
11)
Life support devices or systems are intended (a) to be implanted in the human body, or (b) to support and/or maintain and sustain human life. If they fail, it is reasonable to assume that the health and the life of the user may be endangered.
Published by OSRAM Opto Semiconductors GmbH Wernerwerkstrasse 2, D-93049 Regensburg
www.osram-os.com
© All Rights Reserved.
2005-10-07 15
Loading...
