OSRAM DULUX®EL electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

Contents

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

1 General 3

1.1 OSRAM DULUX®EL – Electronic energy saving lamps 3

1.2 International standards 3

1.3 Range of lamps 4

1.3.1 Overview 4

1.3.2 OSRAM DULUX®EL LONGLIFE E14 5

1.3.3 OSRAM DULUX®EL LONGLIFE E27 6

1.3.4 OSRAM DULUX®EL ECONOMY 8

1.3.5 OSRAM DULUX®EL LONGLIFE CLASSIC 10

1.3.6 OSRAM DULUX®EL ECONOMY CLASSIC 12

1.3.7 OSRAM DULUX®EL GLOBE LONGLIFE and ECONOMY 14

1.3.8 OSRAM DULUX®EL LONGLIFE REFLECTOR 15

1.3.9 OSRAM DULUX®EL FACILITY 16

1.3.10 OSRAM DULUX®EL VARIO 18

1.3.11 OSRAM DULUX®EL SENSOR Plus 19

1.3.12 OSRAM CIRCOLUX®EL 21

1.4 Economy 22

1.4.1 Comparison of operating costs 22

1.4.2 Typical replacement intervals 23

2 Function and technical design 24

2.1 Generation of light 24

2.2 Electronic control gear 25

2.2.1 Operation 25

2.2.2 Energy savings thanks to electronic control gear 26

2.2.3 Visual comfort 27

3 Lamp data and lamp properties 28

3.1 Ignition properties, start-up, switching behaviour 28

3.2 Start-up current 29

3.3 Photometric data 29

3.3.1 Spectral distributions 29

3.3.2 Luminance 30

3.3.3 Luminous intensity distribution 30

3.4 Temperature influences 32

3.4.1 Dependence on burning positions and temperature 32

3.4.2 Lamp temperatures 34

3.4.3 Notes on luminaire design 35

3.5 Power supply 35

3.5.1 Dependence on mains voltage and mains frequency 35

3.5.2 Operation on dc voltage, emergency lighting 36

3.5.2.1 OSRAM DULUX® EL LONGLIFE 5W and 7W 36

3.5.2.2 OSRAM DULUX® EL FACILITY 37

3.5.3 Dimmer operation 38

3.5.4 Operation on electronic switches 38

3.5.5 Operation on switches with load relief, spark suppression or neon lamps parallel to the switch path 39

3.5.6 Operation on motion detectors 39

Contents

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3.5.7 Parallel operation with CCG without power factor correction 39

3.5.8 Operation on BUS systems 40

3.5.9 Operation on non-sinusoidal voltage sources 40

3.5.10 Phase shift, power factor, pf correction 40

3.5.11 Mains current harmonic content 41

3.5.12 RFI suppression 41

3.5.13 Resistance to electro-magnetic interference and transient overvoltages 41

3.5.14 Interference from IR remote controls 41

3.5.15 Bases, holders 41

3.6 Reduction in luminous flux over time 42

3.7 Lamp life 43

3.8 Suitability for outdoor applications 44

3.9 Suitability for explosion-proof luminaires 44

3.10 Additional information on OSRAM DULUX® EL SENSOR Plus 45

3.11 Possible malfunctions of OSRAM DULUX® EL SENSOR Plus 46

4 OSRAM DULUX®EL and the environment 47

4.1 Energy balance 47

4.2 Substances 47

4.3 Disposal 48

4.4 Energy Efficiency Index (EEI) 48

4.5 OSRAM contacts 50

OSRAM DULUX® EL lamps are compact fluorescent lamps with integrated electronic control gear for mains voltage from 220 to 240 V. The lamps are available with E14 or E27 screw bases or B22d bayonet bases, which means they are quick and simple direct replacements for ordinary light bulbs. They offer the dual benefits of the comfort of a ordinary light bulb and the economy of a fluorescent lamp. OSRAM DULUX® EL lamps are particular economical. They have a reputation as „longdistance runners“ because they consume very little electricity. At 0.13 €/kWh, none cost more than 1/3 € Cent per hour to run.

OSRAM DULUX® EL is available in LONGLIFE and ECONOMY versions with the following characteristics:

Main areas of application for OSRAM DULUX® compact fluorescent lamps are as follows:

1. In the commercial sector: e. g. restaurants, hotels, ticket offices, foyers, corridors, offices

In view of the enormous savings in electricity and replacement costs, these lamps are ideal for areas where continous lighting is needed.

2. In the domestic sector: e. g. in living rooms and the kitchen.

OSRAM DULUX® EL LONGLIFE are needed if there are high demands to be met in terms of lamp life and frequent on/off switching.

OSRAM DULUX® EL compact fluorescent lamps carry the CE symbol of the EU and comply with all the relevant European standards, in particular the following: – EN 60968 (safety requirements) – EN 60969 (performance requirements) – EN 61000-3-2 (mains current harmonics) – EN 55015 (RFI suppression) – EN 61547 (EMC Immunity Requirements)

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

1 General

1.1 OSRAM DULUX

EL electronic energysaving lamps

1.2 International standards

OSRAM DULUX

EL LONGLIFE EL ECONOMY

Electricity savings compared with 80 % up to 80 % ordinary light bulbs of nearest light output Lamp life (at 3 h/day)* about 12 years about 6 years Average lamp life* 15000 h 8000 h Flicker-free starting Yes, warm start

Yes, cold start

Flicker-free light Yes Yes Optimised lamp dimensions 1,2,3 turn tubes 2,3 turn tubes Low weight 35 g to 165 g 63 g to 165 g Thermal output only 20% of only 20% of

input power input power Reliable starting (see also Section 3.1) down to -30ºC down to -15ºC Incandescent like light Yes Yes On/off switching with Yes *

Yes *

no reduction in life 500000 on/off 5000 on/off

switching operations switching operations

* All lifespan claims relate to a cycle of 165 minutes on, 15 minutes off as per current IEC regulations. The following switching operations should not be exceeded: For OSRAM DULUX

EL LONGLIFE: 500000 on/off operations

For OSRAM DULUX

EL ECONOMY: 5000 on/off operations

1) Start with cathode preheating, cycle 30 s on, 150 s off

2) Start without cathode preheating, cycle 30 s on, 30 s off

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

1.3 Range of lamps

1.3.1 Overview

OSRAM DULUX®EL ECONOMY

Standard Specials

Wattage Tube version Classic

Classic

GLOBE

1.3.4 1.3.6 1.3.6 1.3.7

Wattage lm

3 5 200 160 7 350 280 8 400

9 340 10 500 11 12 550 14 15 800 16 900 700 18 20 21 1200 1100 23 24 1500

OSRAM DULUX®EL LONGLIFE

Standard Specials

Wattage Tube version Classic

Classic

GLOBE FACILITY VARIO SENSOR Plus CIRCOLUX REFLECTOR

1.3.2/1.3.3 1.3.5 1.3.5 1.3.7 1.3.9 1.3.10 1.3.11 1.3.12 1.3.8

Wattage lm cd

3 100

5 240 140 150

7 400 320 280

9 10 500 500 11 630 450 12 14 800 15 900 800 700 900 335 16 18 20 1200 1155 1100 450 21 23 1500 1500/350 24 1700 30

Candle

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

1.3.2 OSRAM DULUX®EL LONGLIFE E14

➞ 3 W

➞ 5 W

➞ 7 W

➞ 11 W

15 W

25 W

40 W

60 W

OSRAM

Reference DEL DEL DEL DEL DEL

LL LL LL LL*** LL**

3 W E14 5 W E14 7 W E14 11 W E14 11 W E14

Fig. 12223 Warm start

(start with cathode preheating)

Ye s Ye s Ye s Ye s Ye s Power input (W) 3 5 7 11 11 Lamp current

rms value (mA) 30 40 55 90 90 Peak value (mA) 75 150 180 270 270

Luminous flux (lm) 100 240 400 600 630 Luminous efficacy (lm/W) 33 48 57 55 57 Colour appearance 827 827 827 827 827 Colour rendering group 1B 1B 1B 1B 1B Energy Label classification AAAAA Length L

(mm) 58,5 64 78 78 72

Length L

(mm) 115±2 122±2 136±3 148±3 126±3 Diameter d (mm) 30 36 45 45 45 Weight (g) 35 43 59 64 61 Suitable for DC operation No Yes*

)

Yes*

)

No No

Rated average life (h) 12000 15000 15000 15000 15000

* see 3.5.2 ** From January 2004 *** Will be withdrawn by the end of 2003

The high quality brand name compact fluorescent lamp with E14 base.

• About 12 years life (if used for around 3 hours a day)

• Very low weight and suitable for small luminaires

• On/off switching as for ordinary light bulbs with no reduction in life (more than 500000 switching operations possible in a 30 s on/150 s off cycle)

• A total of four wattages for the large range of E14 applications

• Luminaires restricted to 40 W incandescent lamps can be made brighter with OSRAM DULUX

EL LONGLIFE E14 11 W lamps (60 W equivalent)

• The OSRAM DULUX®EL 3 W is the most compact and economical energy saving lamp with a screw base

• OSRAM DULUX

EL LONGLIFE 5 W and 7 W with E14 bases are suitable for

continuous operation on DC power supplies with restrictions (see also 3.5.2)

• Not suitable for use with dimmers, electronic switches or motion detectors

NEW

LONGLIFE

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

25 W

40 W

60 W

75 W

100 W

120 W

➞ 5 W ➞ 7 W ➞ 11 W ➞ 15 W ➞ 20 W ➞ 23 W

1.3.3 OSRAM DULUX®EL LONGLIFE E27

Reference DEL DEL DEL DEL

LL LL LL*** LL**

5W 7W 11W 11W

Fig. 1 2 2 3 Warm start

(start with cathode preheating)

Ye s Yes Ye s Ye s Power input (W) 5 7 11 11 Lamp current rms value (mA) 40 55 90 90

Peak value (mA) 150 180 270 270

Luminous flux (lm) 240 400 600

630

Luminous efficacy (lm/W) 48 57 55 57 Colour appearance 827 827 827 827

– 840 840 840 – – 860

860

Colour rendering group 1B 1B 1B 1B Energy Label classification A A A

Length L1(mm) 62 73 73 68 Length L

(mm) 121±2 131±3 143±3 117±3 Diameter d (mm) 36 45 45 45 Weight (g) 46 67 73 62 Suitable for DC operation Yes* Yes* No No Rated average life (h) 15000 15000 15000 15000

5 % less luminous flux for colour 860

Colour 860, Energy Label B * see 3.5.2.1 ** From January 2004 *** Will be withdrawn by the end of 2003

The high quality brand name compact fluorescent lamp for standard E27 and B22d light bulb holders.

• About 12 years life (if used for around 3 hours a day)

• Wide range from 5 W to 23 W and up to four different colour appearances

• OSRAM DULUX

EL LONGLIFE E27 lamps are suitable for most light bulb fittings

because of their compact dimensions

• Ideal for all applications that require long life and an ability to withstand frequent on/off switching

• On/off switching as for ordinary light bulbs with no reduction in life (500.000 switching operations possible in a 30 s on/150 s off cycle)

• OSRAM DULUX®EL LONGLIFE 5 W and 7 W are suitable for continuous operation on DC power supplies with restrictions (see also 3.5.2.1)

• Some OSRAM DULUX

EL lamps are also available for other mains voltages

(e. g. 120 V) and other bases (with different technical data)

• Not suitable for use with dimmers, electronic switches or motion detectors

LONGLIFE

NEW

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

1.3.3 OSRAM DULUX®EL LONGLIFE E27 (Continued)

Reference DUL EL DEL DUL EL DUL EL DUL EL

LL LL** LL LL** LL

15 W 15 W 20 W 20 W 23 W

Fig. 43434 Warm start

(start with cathode preheating)

Ye s Ye s Ye s Ye s Ye s Power input (W) 15 15 20 20 23 Lamp current

rms value (mA)

120 120 160 160 185

Peak value (mA) 360 360 480 480 560

Luminous flux (lm) 900

900

1200

1500

Luminous efficacy (lm/W) 60 60 60 60 65 Colour appearance 827 827 827 827 827

840 840 840 840 840

860

Colour rendering group 1B 1B 1B 1B 1B Energy Label classification A

Length L1(mm) 81,5 73 81,5 73 83 Length L

(mm) 140±3 128±3 153,5±3 141±3 173±3 Diameter d (mm) 52 45 52 45 58 Weight (g) 92 65 95 73 100 Suitable for DC operation No No No No No Rated average life (h) 15000 15000 15000 15000 15000

5 % less luminous flux for light colour 860

Colour 860, Energy Label B * see 3.5.2 ** From January 2004

LONGLIFE

NEW

25 W

40 W

60 W

75 W

100 W

120 W

➞ 5 W ➞ 7 W ➞ 11 W ➞ 15 W ➞ 20 W ➞ 23 W

2L1

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

The low-cost brand name compact fluorescent lamp for standard lamp fittings.

• The quality standard for normal household sue, ideal for continuous economical lighting

• About 6 years life (if used for around 3 hours a day)

• Instant flicker-free starting as for an ordinary light bulb

• Straightforward range with two E14 wattages and five E27/B22d wattages

• Cold start (no filament preheating, up to 5000 switching operations for a 30 s on, 30 s off cycle)

• Not suitable for DC operation, emergency lighting systems, dimmers, electronic switches or motion detectors

1.3.4 OSRAM DULUX®EL ECONOMY

Reference DEL DEL DEL DEL

ECO ECO ECO ECO

8 W E14 12 W E14 8 W 12 W

Fig. 1 1 2 2 Cold start

(start without cathode preheating)

Ye s Ye s Ye s Ye s Power input (W) 8 12 8 12 Lamp current

rms value (mA) 75 120 75 120 Peak value (mA) 200 300 200 300

Luminous flux (lm) 400 550 400 550

Luminous efficacy (lm/W) 50 50 50 50 Colour appearance 827 827 827 827

– – 840 840 – 860

– 860

Colour rendering group 1B 1B 1B 1B Energy Label classification A A

Length L1(mm) 78 78 73 73 Length L

(mm) 134±3 142±3 129±3 138±3 Diameter d (mm) 45 45 45 45 Weight (g) 59 60 55 60 Available with base E14 E14 E27 E27

B22d B22d Suitable for DC operation No No No No Rated average life (h) 8000 8000 8000 8000

5 % less luminous flux for colour 860

Colour 860, Energy Label B

40 W

60 W

75 W

100 W

120 W

➞ 8 W

➞ 12 W

➞ 16 W

➞ 21 W

➞ 24 W

ECONOMY

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

1.3.4 OSRAM DULUX®EL ECONOMY (Continued)

Reference DEL DEL DEL

ECO ECO ECO

16 W 21 W 24 W

Fig. 3 3 3 Cold start

(start without cathode preheating)

Ye s Yes Ye s Power input (W) 16 21 24 Lamp current

rms value (mA) 125 160 185 Peak value (mA) 390 510 560

Luminous flux (lm) 900

1200

1500

Luminous efficacy (lm/W) 56 57 62,5 Colour appearance 827 827 827

840 840 840

860

Colour rendering group 1B 1B 1B Energy Label classification A

Length L

(mm) 81,5 81,5 81,5

Length L

(mm) 140±3 153,5±3 173±3 Diameter d (mm) 52 52 52 Weight (g) 85 88 92 Available with base E27 E27 E27

B22d B22d B22d Suitable for DC operation No No No Rated average life (h) 8000 8000 8000

5 % less luminous flux for colour 860

Colour 860, Energy Label B

40 W

60 W

75 W

100 W

120 W

➞ 8 W

➞ 12 W

➞ 16 W

➞ 21 W

➞ 24 W

ECONOMY

NEW

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

1. General

1.3.5 OSRAM DULUX®EL LONGLIFE CLASSIC

The high quality brand name compact fluorescent lamp with the classic light bulb shape combines the benefits of the incandescent lamp with those of the compact fluorescent lamp

• About 12 years life (if used for around 3 hours a day), based on the same specifications and requirements for life and on/off switching frequency as for OSRAM DULUX

EL LONGLIFE

• Ideal for decorative and free-burning applications

• Special finish outer bulb for particularly soft light

• LONGLIFE versions are particularly suitable for use in enclosed and ventilated outdoor luminaires at low ambient temperatures

• LONGLIFE versions are available in six wattages with E14 or E27/B22d bases

• OSRAM DULUX

EL CLASSIC lamps are not suitable for use with dimmers or elec-

tronic switches or motion detectors

➞ 5W

➞ 7W ➞10 W

➞11 W ➞15 W

➞20 W

20 W

25 W 25 W

35 W

40 W 50 W

60 W 75 W

75 W

100 W

Reference DEL DEL DEL DEL DEL

CL A CL B CL A CL B CL A

5W 5W E14 7W 7W E14 10W

Fig. 21212 Warm start

(start with cathode preheating)

Ye s Ye s Ye s Ye s Ye s Power input (W) 557710 Lamp current

rms value (mA) 40 40 55 55 80 Peak value (mA) 150 150 180 180 240

Luminous flux (lm) 140 150 320 280 500 Luminous efficacy (lm/W) 30 30 45 40 50 Colour appearance 827 827 827 827 827 Colour rendering group 1B 1B 1B 1B 1B Energy Label classification B B A B A Length l (mm) 109±2 131±2 111±2 131±2 123,5±2 Diameter d (mm) 60 46 60 46 60 Weight (g) 65 65 60 65 80 Base E27 E14 E27 E14 E27

B22d B22d B22d Suitable for DC operation No No No No No Rated average life (h) 12000 12000 12000 12000 10000

LONGLIFE

NEW

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

1.3.5 OSRAM DULUX®EL LONGLIFE CLASSIC (Continued)

Reference DEL DEL DEL DEL

CL A CL A CL A CL A**

11 W* 15 W 15 W 20 W

Fig. 3 3 3 3 Warm start

(start with cathode preheating)

Ye s Ye s Ye s Ye s Power input (W) 11 15 15 20 Lamp current

rms value (mA) 90 120 120 160 Peak value (mA) 270 360 360 480

Luminous flux (lm) 450 800 800 1155 Luminous efficacy (lm/W) 45 53 53 55 Colour appearance 827 827 827 827 Colour rendering group 1B 1B 1B 1B Energy Label classification B A A A Length l (mm) 147±2 149,5±2 142±2 152±2 Diameter d (mm) 70 70 65 70 Weight (g) 88 146 105 112 Base E27 E27 E27 E27

B22d B22d B22d B22d Suitable for DC operation No No No No Rated average life (h) 12000 12000 10000 10000

* Will be withdrawn from 01/2004 ** From September 2003

➞ 5W

➞ 7W ➞10 W

➞11 W ➞15 W

➞20 W

20 W

25 W

40 W

60 W

75 W

LONGLIFE

NEW

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

1.3.6 OSRAM DULUX®EL ECONOMY CLASSIC

The high quality brand name compact fluorescent lamp with the classic light bulb shape combines the benefits of the incandescent lamp with those of the compact fluorescent lamp.

• The new generation is more compact and attractive

• About 6 years life (if used for around 3 hours a day), based on the same specifications and requirements for life and on/off switching frequency as for OSRAM DULUX

ECONOMY

• Ideal for decorative and free-burning applications

• Special finish outer bulb for particularly soft light

• ECONOMY versions are available in five wattages with E27/B22d bases

• OSRAM DULUX

EL CLASSIC lamps are not suitable for use with dimmers or

electronic switches or motion detectors

➞ 5W

➞ 7W

➞ 9W

➞10 W

➞15 W

20 W

25 W

35 W

40 W

60 W

Reference DEL DEL DEL DEL

CL A CL B CL A CL B

ECO 5 W ECO 5 W ECO 7 W ECO 7 W

Fig. 2 1 2 1 Warm start

(start with cathode preheating)

Ye s Ye s Ye s Ye s Power input (W) 5 5 7 7 Lamps current

rms value (mA) 40 40 55 55 Peak value (mA) 120 120 165 165

Luminous flux (lm) 200 160 350 280 Luminous efficacy (lm/W) 40 32 50 40 Colour appearance 827 827 827 827 Colour rendering group 1B 1B 1B 1B Energy Label classification A B A B Length l (mm) 106,5±2 116,5±2 116,5±2 123,5±2 Diameter d (mm) 52 42 56 43 Weight (g) 65 65 65 65 Base E27 E14 E27 E14

B22d B22d Suitable for DC operation No No No No Rated average life (h) 6000 6000 6000 6000

ECONOMY

NEW

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

➞ 5W

➞ 7W

➞ 9W

➞10 W

➞15 W

20 W

25 W

35 W

40 W

60 W

1.3.6 OSRAM DULUX®EL ECONOMY CLASSIC (Continued)

Reference DEL DEL DEL

CL B CL A CL A

ECO 9 W ECO 10 W ECO 15 W

Fig. 1 2 2 Warm start

(start with cathode preheating)

Ye s Yes Ye s Power input (W) 9 10 15 Lamp current

rms value (mA)

70 80 120

Peak value (mA)

225 240 360 Luminous flux (lm) 340 500 800 Luminous efficacy (lm/W) 38 50 53 Colour appearance 827 827 827 Colour rendering group 1B 1B 1B Energy Label classification B A B Length l (mm) 131±2 126,5±2 142,7±2 Diameter d (mm) 46 60 65 Weight (g) 70 80 100 Base E14 E27 E27

B22d B22d Suitable for DC operation No No No Rated average life (h) 6000 6000 6000

ECONOMY

NEW

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

1.3.7 OSRAM DULUX®EL LONGLIFE GLOBE

OSRAM DULUX®EL ECONOMY GLOBE

Reference DEL DEL DEL DEL

LL LL ECO ECO

GL 15 W GL 20 W GL 16 W GL 21 W

Warm start

(start with cathode preheating)

Yes Yes No No Power input (W) 15 20 16 21 Lamp current

rms value (mA) 120 160 125 170 Peak value (mA) 360 480 390 510

Luminous flux (lm) 700

1100

700 1100 Luminous efficacy (lm/W) 47 55 44 52 Colour appearance 827 827 827 827

860

–– Colour rendering group 1B 1B 1B 1B Energy Label classification B B B B Length l (mm) 169±2 190±2 169±2 190±2 Diameter d (mm) 97 117 97 117 Weight (g) 150 155 150 155 Available with base E27 E27 E27 E27

B22d B22d B22d B22d Suitable for DC operation No No No No Rated average life (h) 15000 15000 8000 8000

5 % less for colour 860

The high quality brand name compact fluorescent lamp with new, more decorative large bulb.

• OSRAM DULUX®EL GLOBE has the same comfort and economy features as the OSRAM DULUX

EL LONGLIFE and OSRAM DULUX®EL ECONOMY lamps with 6 or 12-years lamp life (at 3 h/day based on their specifications and requirements for lamp life and on/off switching frequency)

• OSRAM DULUX®EL GLOBE offers pleasant glare-free light, uniform distribution of the light and improved impact resistance (splinter protection) thanks to its plastic bulb with locking feature (NEW)

• OSRAM DULUX®EL LONGLIFE GLOBE lamps are particularly suitable for use in enclosed, ventilated and semi-open outdoor luminaires at low ambient temperatures

• Suitable, with restrictions, for use in open luminaires outdoors, provided there is no possibility of moisture ingress (rain, splashwater, dew, etc.). Condensate can lead to premature lamp failure; this is minimised by the new bulb locking feature

• Not suitable for DC operation, emergency lighting systems, dimmers, electronic switches or motion detectors.

LONGLIFE

ECONOMY

75 W

100 W

➞ 15 W/16 W

➞ 20 W/21 W

➤

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

1.3.8 OSRAM DULUX®EL LONGLIFE REFLECTOR

Reference DEL DEL

LL LL

REFL 15 W REFL 20 W

Warm start

(start with cathode preheating)

Ye s Ye s Power input (W) 15 20 Lamp current

rms value (mA) 120 160 Peak value (mA) 360 480

Luminous intensity (cd) 335 450 Half-peak angle (50 % l

) (°) 80 80 Colour appearance 827 827 Colour rendering group 1B 1B Length l

(mm) 92,5 101

Length l

(mm) 143±2 161±2 Diameter d (mm) 102 117,5 Weight (g) 145 170 Base E27 E27

B22d B22d Suitable for DC operation No No Rated average life (h) 15000 15000

The high quality brand name compact fluorescent lamp with new, more decorative integrated reflector.

• OSRAM DULUX®EL LONGLIFE REFLECTOR offers the same comfort and economy as OSRAM DULUX

EL LONGLIFE with a lamp life of about 12 years (at around

3 hours a day).

• Ideal for applications that require long life and an ability to withstand frequent on/off switching as for ordinary light bulbs with no reduction in life (more than 500000 switching operations possible in a 30 s on/150 s off cycle)

• OSRAM DULUX®EL LONGLIFE REFLECTOR is ideal in spotlights and downlights and can replace conventional incandescent reflector lamps; the heat on illuminated objects is greatly reduced as a result

• The contoured wipe-clean reflector and the lamp form an optimum directional light source

• Not suitable for DC operations, emergency lighting systems, dimmers, electronic switches or motion detectors

➞ 15 W

➞ 20 W

75 W

100 W

LONGLIFE

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

1.3.9 OSRAM DULUX®EL LONGLIFE FACILITY

Reference DEL DEL

FCY FCY

10 W 14 W

Warm start

(start with cathode preheating)

Ye s Ye s Power input (W) 10 14 Lamp current

rms value (mA) 80 110 Peak value (mA) 240 380

Luminous flux (lm) 500 800 Luminous efficacy (lm/W) 50 57 Colour appearance 827 827 Colour rendering group 1B 1B Energy Label classification A A Length l

(mm) E27 and B22d bases 64±3 72,5±3

E14 base 69±3 –

Length l

(mm) E27 and B22d bases 129±3 131±3

E14 base 134±3 – Diameter d (mm) 45 52 Weight (g) 55 80 Available with base E27/E14 E27

B22d B22d Suitable for DC operation Yes Yes Rated average life (h) 15000 15000

The electronic brand name compact fluorescent lamp for professional applications, based on Longlife technology.

• OSRAM DULUX®EL FACILITY can be switched on and off any number of times within its average life of 15000 h in accordance with IEC regulations and has the same comfort and economy features as the OSRAM DULUX

EL LONGLIFE

• Power-Boost facility so it reaches its rated luminous flux more quickly (90 % in 100 s)

• Short ignition times of less than 0.5 s

• Suitable for operation at temperatures from -30°C to +50°C; reliable starting as low as -30°C

• No need to leave the lamp off for a certain time before switching it on again

• Suitable for 220 – 240 V DC systems

• Not suitable for use with dimmers, electronic switches or systems that warn of imminent disconnection by dimming the light

➞ 10 W

➞ 14 W

40 W Bellalux Soft

75 W Bellalux Soft

L2L

NEW

LONGLIFE

NEW

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

1.3.9 OSRAM DULUX®EL LONGLIFE FACILITY

Use with stairwell lighting time switches:

The total power input of multiple OSRAM DULUX®EL FACILITY lamps should not exceed 1/8 of the permitted incandescent lamp load. This value depends on the switch design and cannot be applied to other types of energy saving lamp. In addition to the switching load, the provisions of DIN 18015-2 must also be noted: „…in the case of lighting systems in stairwells of multi-family residences, automatic disconnection circuits must be equipped with a warning function (such as dimming of the lights) to avoid sudden darkness“. The type and design of this warning function have not been standardised.

Known designs:

• Warning function with reduced brightness (dimming): The dimming function is generally achieved by half-wave rectification of the mains voltage. DEL FACILITY is not suitable for this mode of operation.

• Warning signal provided by multiple (double) flashing (interruptions of the current)

before disconnection: The lamp is not likely to suffer damage. The warning signal is noticeably changed by the preheating phase of the DEL FACILITY (approx. 0.4 s). If there is an unsuitable pulse sequence the lamp may go off (at least 0.4 s for each switching operation).

ON time:

For the benefit of the lamp, the ON time should not be less than 3 minutes.

Examples:

a) Incandescent lamp load for 2300 W cutout, the following can be connected:

OSRAM DULUX®EL FACILITY 28 x 10 W or 20 x 14 W

b) Incandescent lamp load for 1000 W cutout, the following can be connected:

OSRAM DULUX®EL FACILITY 13 x 10 W or 9 x 14 W

The high quality brand name compact fluorescent lamp with integrated option for varying the light.

• The lighting level can be varied by simply switching the lamp off and on again. Within 3 seconds the luminous flux is reduced to about 25 % of the rated value. Switching the lamp off and on again takes the lamp back up to 100 % luminous flux, irrespective of how long it is switched off. Recommendation: allow the lamps to burn in at full load for at least 1 minute each time before „dimming to around 25 %“ to achieve stable operation

• Additional energy savings from reducing power consumption to 40 %. For more information see Section 3.5.3 Dimmer operation

• In accordance with IEC regulations, OSRAM DULUX®EL LONGLIFE VARIO can be switched on and off any number of times within its average life of 15000 hours and within its permitted temperature range of +15°C to +50°C without having to be switched off for a certain amount of time before being switched on again

• Not suitable for use with existing dimmer systems, DC power, emergency lighting systems or electronic switches

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

1.3.10 OSRAM DULUX®EL LONGLIFE VARIO

Reference DEL

VAR 23 W

Warm start

(start with cathode preheating)

Ye s Technical characteristics Full load Power-Boost Vario function Power input (W) 23 24,5 9 Lamp current

rms value (mA

rms

) 185 170 70

Peak value (mA) 560 650 225

Luminous flux (lm) 1500 – 350 Luminous efficacy (lm/W) 65 – 39 Colour appearance 827 Colour rendering group 1B Energy Label classification A Length l

(mm) 83

Length l

(mm) 173±3 Diameter d (mm) 58 Weight (g) 110 Available with base E27

B22d Suitable for DC operation No Rated average life (h) 15000

L2L

LONGLIFE

NEW

120 W ➞ 23 W

Dimmer function:

35 W ➞ 9 W

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

The high quality brand name compact fluorescent lamp with microprocessor technology and control based on ambient light.

Operating principle:

OSRAM DULUX

EL SENSOR Plus automatically switches on at dusk and off again at dawn. Two light sensors at the side continually measure the ambient light and determine the infra-red content of its spectral distribution; in this way the lamp is controlled according to available daylight (for details see how it works on page 20).

• OSRAM DULUX®EL SENSOR Plus is not affected by its own light; the lamp offers

all the comfort and economy features of OSRAM DULUX®EL LONGLIFE technology; the OSRAM DULUX IC (integrated circuit) ensures optimum operation

• Simple „plug & play“installation for use in all standard fittings for incandescent

lamps; may only be used outdoors in enclosed and ventilated luminaires

• Automatic adjustment to ambient lighting conditions A setting controller, as on the

predecessor model OSRAM DULUX®EL SENSOR, is not needed

• The lamp indicates it is ready each time power is applied

• Not suitable for DC operation, emergency lighting systems, dimmers or electronic

switches

1.3.11 OSRAM DULUX®EL LONGLIFE SENSOR Plus

Reference DEL

15 W SENSOR Plus

Warm start

(start with cathode preheating)

Ye s Power input (W) 15 Lamp current rms value (mA) 120

Peak value (mA)

360 Luminous flux (lm) 900 Luminous efficacy (lm/W) 60 Colour appearance 827 Colour rendering group 1B Energy Label classification A Length l

(mm) 81,5 Length l2(mm) 140±3 Diameter d (mm) 52 Weight (g) 95 Available with base E27, B22d Suitable for DC operation No Rated average life (h) 15000

➞ 15 W75 W

L2L

LONGLIFE

NEW

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

How it works:

The lamp is controlled by infra-red (IR) radiation. Infra-red radiation is emitted by the sun, remote controls and artificial light sources such as incandescent and halogen lamps. By contrast, fluorescent lamps emit very little IR radiation once they have reached their normal operation state. The light from such lamps does not interfere the IR sensor which could make the lamps flicker or go off.

In the case of sunlight, it can be assumed that the brightness of the visible light is proportional to the intensity of the infra-red radiation. The two sensors on the lamp (behind the red covers) detect the IR radiation in the vicinity of the lamp. A measurement signal is derived from this, and this signal is then evaluated by the electronic circuitry in the lamp:

After a maximum of 30 minutes the translucence of the luminaire is measured.

In the evening

bright ⇒ dark

Large amount of IR ⇒ Small amount of IR

Switch-on value is reached

The lamp switches itself on

Self-test each time power is applied.

A complete lamp test is performed. All the components of the lamp are checked for correct operation. The lamp will light after about two seconds to indicate that the test has been successfully completed.

Power is applied

Processor test

Evaluation of the sensors

If light The lamp lights after about 2 seconds

The lamp switches off after 6 to 8 seconds

If dark The lamp lights

The light stays on

1.3.11 OSRAM DULUX

EL LONGLIFE SENSOR Plus

⇒

⇒⇒⇒

⇒

In the morning

dark ⇒ bright

Small amount of IR ⇒ Large amount of IR

Switch-of

f value is reached

The lamp switches itself off

⇒⇒

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

The brightest circular brand name compact fluorescent lamp.

• OSRAM CIRCOLUX®EL offers the same comfort and economy as OSRAM DULUX®EL LONGLIFE with a lamp life of up to 12 years (at around 3 hours a day).

• Thanks to its slim circular shape, OSRAM CIRCOLUX®EL is ideal for pendant luminaires and offers uniform light distribution for general lighting applications

• Not suitable for DC operation, emergency lighting systems, dimmers, electronic switches or motion detectors

1.3.12 OSRAM CIRCOLUX

LONGLIFE

Reference CIRCO

EL 24 T5

Power input (W) 24 Warm start

(start with cathode preheating)

Ye s

Lamp current

rms value (mA) 190 Peak value (mA) 570

Luminous flux (lm) 1700 Luminous efficacy (lm/W) 71 Colour appearance 827

840 Colour rendering group 1B Energy Label classification A Length (mm) 99 Diameter d-max. (mm) 225 Tube diameter T5 (16 mm) Weight (g) 170 Available with base E27 Suitable for DC operation No Rated average life (h) 15000

➞ 24 W150 W

LONGLIFE

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

1.4 Economy

1.4.1 Comparison of operating costs

OSRAM DULUX

EL consumes only about one fifth of the electricity of ordinary light bulbs of comparable light output. These savings from low energy consumption is an important aspect in cost/benefit analyses. In commercial applications, the price of the lamps and their maintenance costs also play a role. A comparison between the operating costs of incandescent lamps and those of the OSRAM DULUX®EL range shows that because of the lower electricity costs and longer life of OSRAM DULUX®EL lamps there are considerable benefits despite the higher purchase price. What’s more, there are savings in maintenance costs (labour costs for replacing lamps), which are much higher for incandescent lamps because of their shorter life, and possible savings in airconditioning costs.

Table 1: Savings in operating costs with an OSRAM DULUX®EL LONGLIFE 15 W compared with a 75 W light bulb

Fig. 1: Comparison of operating costs, price of electricity: € 0.13

Operating time in years

0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

Cost in € Incandescent lamp 0.87 11.49 22.11 32.73 43.35 53.97 64.59 75.21 85.83 96.45 107.07 117.69 128.31 138.93 149.55 159.30

OSRAM DULUX EL 9.95 11.90 13.85 15.80 17.75 19.70 21.65 23.60 25.55 27.50 29.45 31.40 33.35 35.30 37.25 39.20

Lamp OSRAM DULUX®EL Incandescent

LONGLIFE lamp

Power input 15 W 75 W Quantity 1 15 Hours burned 15000 h 15000 h Life/lamp 15000 h 1000 h Electricity consumption over 15000 h 225 kWh 1125 kWh Electricity costs at € 0.13/kWh 29.25 € 146.25 € + lamp price

9.95 € 13.05 €

(1 x 9.95 €) (15 x 0.87 €)

= Total costs 39.20 € 159.30 € Savings per

OSRAM DULUX

EL LONGLIFE 120.10

€

–

Recommended retail price in Germany

Operating costs in €

Hours burned (1000)

Comparison of operating costs between an OSRAM DULUX®EL LL 15 W and a 75 W incandescent lamp

Incandescent lamp 75 W

OSRAM DULUX

EL 15 W

Savings

200

180

160

140

120

100

Glühlampe 75 W

DULUX EL 15 W

2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

Ersparnis

1. General

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

1.4.2 Typical replacement intervals

Examples of replacement intervals for OSRAM DULUX®EL LONGLIFE compared with incandescent lamps in domestic and commercial applications:

Application Operating time in hours Replacement intervals for

daily = approx. annually OSRAM Incandencent

DULUX®EL lamp LONGLIFE

Private household 3 h/day = 1100 h/year about 12 years 11 to 12 months

Commercial use 10 h/day = 3650 h/year about 4 years 2 to 3 months

2. Function and technical design

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

2. Function and technical design

2.1 Generation of light As with all fluorescent lamps, light is generated in an OSRAM DULUX®EL lamp

by low pressure gas discharge. Electrical current is passed between the two electrodes in the tube which is filled with partially ionised gas. The electrons excite mercury atoms to emit short-wave ultra-violet light, which is converted into visible light in the phosphor layer on the inside of the tube (Fig. 2). Different light colours are produced depending on the phosphor mix.

Fig. 2: Generation of light in a fluorescent lamp

Compared with an incandescent lamp, the process described for generating light needs only around 1/4 of the electrical energy (1/5 if electr

onic control gear is used). The presence of mercury in the filler gas is crucial for optimum energy conversion in the light generation process. OSRAM DULUX®EL lamps are designed so that the optimum mercury pressure is achieved in the base-up position at an ambient temperature of 25°C.

K Nucleus

H Shell electron of the atom,

on an inner orbit

e- Exciting electron due to

surge energy

A* Excited electron,

on an outer orbit

R Radiation on transition from

A* ➞ H, light and UV

Light

Ultra-violett radiation

Visible light

Phosphor

Hg atom

2. Function and technical design

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

2.2 Electronic control gear

2.2.1 Operation

Fluorescent lamps need a voltage pulse of several hundred volts in order to start, and need the current to be limited to several hundred mA in order to continue operating properly. In conventional control gear (CCG operation), these two functions are provided by an inductive resistor (choke) and starter. Chokes for a mains frequency of 50 Hz are large and heavy and cause power losses that in the case of compact lamps may be as much as 40 % of the total power input. Instead of conventional control gear, an OSRAM DULUX® EL lamp has integrated electronic control gear for starting and current limitation. The electronic circuitry is small and lightweight. The lamp starts quickly and without flickering. The power losses are only one third of those of conventional control gear.

Electronic control gear contains a number of functional elements:

Fig. 3: Block diagram of electronic control gear

First, a DC voltage of about 280 V is produced from the 50 Hz mains voltage by a rectifier with a smoothing capacitor. This voltage is converted into a square-wave AC voltage with a frequency of more than 40 kHz in the high frequency generator (oscillator), in which two transistors operate as fast acting switches. Even if electronic control gear is used, current limitation and power setting are still handled by chokes. Because of the high operating frequency, however, they have a very much smaller inductance (owing to impedance Z = H x ω) and smaller dimensions than the ones used with conventional control gear. For the lamp to start properly, a voltage of several hundred volts must be applied. In OSRAM DULUX

EL LONGLIFE lamps the lamp electrodes are heated up to the electrode emission temperature (warm start) prior to starting to achieve long life and tolerance to frequent on/off switching. With the electronic control gear used, these two conditions are met by a series resonance circuit, whose resonating for OSRAM DULUX®EL LONGLIFE lamps is deliberately delayed by a PTC thermistor (preheat phase). In the case of OSRAM DULUX®EL VARIO, OSRAM DULUX®EL FACILITY and OSRAM DULUX®EL SENSOR Plus, preheating of the filament and starting of the lamp are closely controlled by an integrated circuit (OSRAM DULUX®IC). A radio interference filter prevents the generator frequency and its harmonics from affecting the supply cables. Thanks to the electronic control gear, an OSRAM DULUX®EL can be operated on any standard mains frequency and is not affected by fluctuations in the mains frequency. Certain lamp types can also be operated on DC voltage (see 3.5.2).

230 V 50 Hz

325 V

Interference

filter

Smoothing

Rectifier

High frequency

generator

Current limiting

choke

lamp

Preheat

circuit

2. Function and technical design

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

2.2.2 Energy savings thanks to electronic control gear

Compared with fluorescent lamps with conventional control gear, there are further energy savings of around 20 % with electronic control gear.

This is due essentially to two effects:

• The losses with electronic control gear are only about one third of the losses with conventional control gear.

• The luminous efficacy of a fluorescent lamp shows a significant improvement of around 20 % at high frequencies, with saturation setting it at around 50 kHz.

Fig. 4: Luminous efficacy of a fluorescent lamp as a function of the operating frequency

Rel. luminous efficacy of the lamp

Frequency

110

105

100

rel. Lichtausbeute der Lampe

10 10

Frequenz f

2. Function and technical design

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

2.2.2 Energy savings thanks to electronic control gear (Continued)

Overall the power balance of fluorescent lamps with conventional control gear and electronic control gear is as follows:

Fig. 5: Power balance of a fluorescent lamp with a) conventional and

b) electronic control gear

Conventional control gear

Electronic control gear

2.2.3 Visual comfort

The use of electronic control gear also brings photometric benefits that considerably improve visual comfort.

Electrode flickering and luminous ripple, which are normal with conventional control gear, cannot be perceived by the human eye at these high frequencies at which the lamp is operated. The eye therefore does not tire as quickly and the light is more comfortable.

Light

2.4 %

Light 23.5 %

Heat loss:

18.3 % control gear

25.4 % gas discharge

33.8 % Conversion of UV radiation in the phosphor

UV radiation

56.3 %

20.1 %

Light

2.9 %

Light 27.8 %

Heat loss:

9.9 % control gear

20.7 % gas discharge

41.6 % Conversion of UV radiation in the phosphor

UV radiation

69.4 %

24.9 %

100 %

Licht 2,4 %

UV-Strahlung

56,3 %

20,1%

Licht 22,5 %

Wärmeverlust durch:

18,3 % Vorschaltgerät

25,4 % Gasentladung

33,8 % Umsetzung der UV-Strahlen im Leuchtstoff

100 %

Wärmeverlust durch:

Licht

2,9 %

UV-Strahlung

69,4 %

24,9%

Licht 27,8 %

9,9 % Vorschaltgerät

20,7 % Gasentladung

41,6 % Umsetzung der

UV-Strahlen im

Leuchtstoff

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3. Lamp data and lamp properties

3.1 Ignition properties/ start-up/ switching behaviour

Unless otherwise indicated, the following test conditions apply to all the technical data specified in this document:

– Supply voltage 230 V/50 Hz – Lamp installed (Base up), free burning – Ambient temperature 25°C ± 1°C

For OSRAM DULUX

EL lamps, reliable starting is assured in the mains voltage range from 198 V to 254 V and at temperatures from -30°C to +50°C, with the following exceptions:

– OSRAM DULUX®EL LONGLIFE 3 W from +5°C to +50°C – OSRAM DULUX®EL LONGLIFE 5 W from -20°C to +50°C – OSRAM DULUX®EL VARIO from +15°C to +50°C – OSRAM DULUX®EL ECONOMY from -15°C to +40°C – OSRAM DULUX®EL ECONOMY CLASSIC from -15°C to +40°C – OSRAM DULUX®EL ECONOMY GLOBE from -15°C to +40°C – OSRAM CIRCOLUX®EL 24 W T5 from -10°C to +50°C

In contrast to fluorescent lamps with conventional control gear, OSRAM DULUX®EL LONGLIFE lamps start without flickering in less than 1.5 s. This time is needed for preheating the cathodes; at low temperatures this may take up to 2 s. Immediately after starting, the lamp produces around 40 % of its rated luminous flux. At room temperature (25°C) it then takes about 2 minutes for the lamp to reach 90 % of its maximum luminous flux. Thanks to this precise cathode preheating, controlled by the electronic circuitry, the life of OSRAM DULUX®EL LONGLIFE lamps is not significantly affected by frequent on/off switching. For a switching cycle of 30 s on/150 s off, an OSRAM DULUX®EL LONGLIFE can handle more than 500000 switching operations in its lifetime.

The requirement here is that the lamp should remain off for at least two minutes before being switched on again so that the PTC thermistor, which controls the starting process in electronic control gear and which is hot while the lamp is in operation, can cool down. There will be a significant reduction in lamp life if this off time is consistantly less than two minutes.

This does not apply to OSRAM DULUX®EL VARIO, OSRAM DULUX®EL SENSOR Plus or OSRAM DULUX®EL FACILITY. These lamps can be switched on and off without restriction. This makes the OSRAM DULUX®EL FACILITY ideal, for example, for stairwell lighting with automatic switch off. If normal OSRAM DULUX®EL LONGLIFE lamps are to be used for this purpose, we recommend switching over to continuous light during the busy times morning and evening.

Because of their design (cold start within 0.2 s without cathode preheating), OSRAM DULUX®EL ECONOMY lamps should not be used in lighting systems in which the lamps are frequently switched on and off (e. g. stairwell lighting or motion detection systems). For a switching cycle of 30 s on/30 s off, OSRAM DULUX®EL ECONOMY lamps can handle more than 5000 switching operations; the average life is 8000 h for a switching cycle of 165 s on/15 s off.

3. Lamp data and lamp properties

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3.2 Start-up current

3.3 Photometric data

3.3.1 Spectral distributions

Contrary to popular belief, frequent switching does not increase energy consumption. At the moment of starting there is a short high surge of current of up to 25 A (approx. 80µs half-value width, to charge the internal smoothing capacitor, VARIO: 48 A). This small amount of energy is not lost, however, but is converted into light.

The relative spectral distribution is determined mainly by the colour appearance. Various types and wattages have little effect on this curve.

The spectral distributions shown are therefore typical of all OSRAM DULUX

lamps of the relevant colour appearance. x axis: mW/(m2x 5 nm x 1000 lx) y axis: Wavelength in nanometres.

Notes on the diagrams: The spectral radiant intensity distributions relate to an illuminance of 1000 lx. This has the advantage that the absolute values of any illuminance can be determined a simply from the following quotient:

Illuminance E (measured) x(y axis value)

1000 lx

The spectral intensities are grouped in wavelength ranges of 5 nanometres. The values integrated across 5 nm are specified, irrespective of actual distributions. This corresponds to the standard that is the basis for all calculations of subsequent results (e. g. colour, colour rendering).

Colour 827 (2700 Kelvin) LUMILUX INTERNA

Fig. 6: LUMILUX®colour appearances

Colour 860 (6000 Kelvin) LUMILUX® Daylight

Colour 840 (4000 Kelvin) LUMILUX® Cool White

3. Lamp data and lamp properties

500

400

300

200

100

250

300

500 600 700 780 nm

400

600

500

400

300

200

100

250

300

500 600 700 780 nm

400

500

400

300

200

100

250

300

500 600 700 780 nm

400

Fig. 8a: OSRAM DULUXEL LONGLIFE 11 W, 15W, 20W, 23W

OSRAM DULUX



EL ECONOMY 16W, 21W and 24W

OSRAM DULUX



EL FACILITY 10W, 14 W

OSRAM DULUX



EL SENSOR Plus 15 W

OSRAM DULUX



EL VARIO 23W

Axial and radial luminous intensity distribution curves, referred to 1000 lm

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3.3.2 Luminance

3.3.3 Luminous intensity distribution

The luminance of OSRAM DULUX

EL lamps is 2.5 cd/cm2(0.5 cd/cm2for opal

CLASSIC and GLOBE lamps)

Fig. 8b: OSRAM DULUX®EL LONGLIFE 3W, 5W and 7W

OSRAM DULUX

EL ECONOMY 8W and 12 W

Axial and radial luminous intensity distribution curves, referred to 1000 lm

3. Lamp data and lamp properties

100

Candela

C-40 C-20 C-0

150°

30°

120°

60°

90°

C-0

C-20

- 150°

- 120°

- 90°

- 60°

- 30°

C-40

180°

0°

150°

120°

90°

60°

30°

125

100

125

Candela

C-90 C-45 C-0

150°

30°

120°

60°

90°

C-0

- 150°

- 120°

- 90°

- 60°

- 30°

C-45

C-90

100

125

180°

150°

120°

90°

60°

30°

0°

Fig. 9: OSRAM DULUX®EL LONGLIFE CLASSIC 5W, 7W, 10 W, 11W, 15 W and 20W

OSRAM DULUX

EL ECONOMY CLASSIC 5W, 7W, 9 W, 10W and 15W

OSRAM DULUX

EL LONGLIFE GLOBE 15W, 20W

OSRAM DULUX

EL ECONOMY GLOBE 16W and 21 W

Axial and radial luminous intensity distribution curves, referred to 1000 lm

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

Fig. 10 OSRAM DULUX®EL LONGLIFE REFLEKTOR 15 W, 20 W

Luminous intensity distribution curves in candela (cd), illuminance in lx

3. Lamp data and lamp properties

Candela

150°

120°

90°

60°

30°

100

200

90° 80°

70° 60°

50°

335 lx

ø 168 cm

150 lx

80°, 15 W

1,0 m

1,5 m

450 lx

ø 168 cm

200 lx

80°, 20 W

1,0 m

1,5 m

300

400

40°

ø 252 cm

2,0 m

85 lx

30°

500

ø 336 cm

20°10°0°

15 W, 80° 20 W, 80°

ø 252 cm

2,0 m

110 lx

ø 336 cm

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3.4 Temperature influences

3.4.1 Dependence on burning positions and temperatures

OSRAM DULUX

EL LONGLIFE, OSRAM DULUX®EL FACILITY and OSRAM DULUX®EL

SENSOR Plus can be used in a temperature range from -30°C to +50°C.

Exceptions:

OSRAM DULUX®EL LONGLIFE 3 W from +5°C to +50°C OSRAM DULUX®EL LONGLIFE 5 W from -20°C to +50°C OSRAM DULUX®EL VARIO from +15°C to +50°C OSRAM DULUX®EL ECONOMY from -15°C to +40°C OSRAM DULUX®EL ECONOMY CLASSIC from -15°C to +40°C OSRAM DULUX®EL ECONOMY GLOBE from -15°C to +40°C OSRAM CIRCOLUX®EL 24 W T5 from -10°C to +50°C

At lower temperatures than those specified the high starting voltage may destroy the lamp. The thermal load on the components at temperatures above 50°C may lead to the premature failure on the integrated electronic control gear.

The luminous flux of Hg low pressure discharge lamps such as the OSRAM DULUX®EL is dependent on the mercury vapour pressure in the lamp and therefore on the temperature at the coolest point (cf. 2.1). When OSRAM DULUX®EL lamps are used in the base up position, the bends in the tubes act as cold spots. Optimum luminous flux is reached when these bends have a temperature of 45°C. This is the case for base up and horizontal positions at an ambient temperature of 20 to 25°C. In the base down position, the rising heat causes cold spots (controlling the Hg vapour pressure) to form in the cylindrical part of the discharge tube; the highest luminous flux in the base down position is reached when the ambient temperature is around -5°C.

For free-burning lamps the ambient temperature corresponds to the room temperature. If the lamps are operated in luminaires, the temperature in the immediate vicinity of the lamp is crucial for the luminous flux.

3. Lamp data and lamp properties

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

Fig. 11a: Typical luminous flux/temperature curve for OSRAM DULUX

LONGLIFE 15 W in base up and horizontal burning positions

Fig. 11b: Typical luminous flux/temperature curve for OSRAM DULUX®EL

LONGLIFE 15 W in the base down

burning position

3. Lamp data and lamp properties

Relative luminous flux

Ambient temperature, lamp (°C)

Rel. luminous flux

Φ (T) curve

Relative luminous flux

Ambient temperature, lamp (°C)

Rel. luminous flux

Φ (T) curve

100

-10

10 20 40 50 70

30 60

100

-10

10 20 40 50 70

30 60

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3.4.2 Lamp temperatures

The VDE (Association of German Engineers) recommends maximum temperatures at certain critical locations in luminaires to ensure safe operation. Compared with incandescent lamps, the temperatures that occur when OSRAM DULUX

EL are in operation are much lower on the glass itself and on the casing, and therefore in the luminaire. This means that OSRAM DULUX®EL lamps with higher luminous fluxes can be used in luminaires that have been approved for incandescent lamps up to a certain wattage.

Temperatures in °C at different places on OSRAM DULUX®EL LONGLIFE lamps and incandescent lamps (230 V, free-burning, base up):

Temperature measurement point 1

OSRAM DULUX®EL LONGLIFE 5 W 30 50 37 OSRAM DULUX®EL LONGLIFE 7 W 20 60 44 OSRAM DULUX®EL LONGLIFE 7 W 22 60 44 OSRAM DULUX®EL LONGLIFE 11 W 28 65 47 OSRAM DULUX®EL LONGLIFE 15 W 30 70 48 OSRAM DULUX®EL LONGLIFE 20 W 35 70 51 OSRAM DULUX®EL LONGLIFE 23 W 30 65 49 Incandescent lamp 40 W 70 130 65 Incandescent lamp 60 W 90 150 75 Incandescent lamp 75 W 105 175 85 Incandescent lamp 100 W 130 220 100

*) Base edge overtemperature to EN 60 360 (permitted limit values: IEC 60432-1)

Fig. 12: Temperature measurement points on OSRAM DULUX®EL lamps and

Incandescent lamps

3. Lamp data and lamp properties

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3.4.3 Notes on luminaire design

Burning position

Because of the thermal conditions on the lamp there are significant differences in the luminous flux/temperature curve for base down, base up and horizontal burning positions (see 3.4.1). The base down

position is recommended for all applications in

which low ambient temperatures are expected.

If lamps are to be installed in the base down

position in outdoor luminaires it is important to ensure that no water (e. g. condensate in the luminaire) can penetrate into the electronic circuitry between the glass and the base casing. (cf. 3.8/Suitability for outdoor applications)

3. Lamp data and lamp properties

3.5 Power supply

3.5.1 Dependence on mains voltage and mains frequency

OSRAM DULUX

EL lamps operate ideally on AC voltage in the range from 198 V to

254 V (according to DIN IEC 38).

The electrical data of lamps differs according to the mains voltage. The changes are substantial in the case of an incandescent lamp, but minimal in the case of OSRAM DULUX®EL. As the voltage increases, the output and the luminous flux change very little (Fig. 14). This behaviour is welcome in view of the frequent overvoltages in the mains supply. Voltages up to 254 V have virtually no effect on the life of an OSRAM DULUX®EL lamp, in contrast to the situation with incandescent lamps. The luminous efficacy of OSRAM DULUX®EL lamps as a measure of the efficiency with which electrical power is used is virtually unaffected by changes in the mains voltage in the range of - 10 % to +10 %.

Fig. 14: Electrical data as a function of the supply voltage

OSRAM DULUX

EL lamps can be operated at any standard mains frequency and are

largely unaffected by fluctuations in the mains frequency.

Luminous efficacy

Supply voltage V

Relative values

Luminous flux

Power input

130

120

110

Lichtausbeute

100

Lichtstrom

Leistungsaufnahme

200 210 220 230 240 250

Versorgungsspannung

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3.5.2 Operation on DC

voltage/emergency lighting

3.5.2.1 OSRAM DULUX

EL LONGLIFE 5 W and 7 W

OSRAM DULUX®EL LONGLIFE 5 W and 7 W E27/B22d /E14 can be operated in the usual AC voltage range and also on DC voltage in the 176V DC to 310 V DC range and on battery powered 220/240 V systems.

At a lower threshold voltage of 176 V DC the lamps will start reliably from 5°C to 50°C and are insensitive to overvoltages in the DC system up to 310 V DC. OSRAM DULUX®EL LONGLIFE lamps achieve their rated values in DC operation at around 280 V DC. For other DC voltages the differences are as follows:

Table 3: Electrical and photometric data in dc operation

Supply voltage: Power Luminous flux

System or

input

battery current

310 V DC 110 % 110 % 48 % 280 V DC 100 % 100 % 49 % 220 V DC 80 % 78 % 50 % 180 V DC 65 % 60 % 50 %

1) As a percentage of the rated value

2) As a percentage of the rms value for AC voltage

Emergency lighting:

OSRAM DULUX®EL LONGLIFE 5W and 7 W are suitable for use in emergency lighting systems. For most emergency lighting systems, VDE 0108 calls for a starting time of less than one second. Since the requirements for restart time with DC voltage are met only if the lamp is at operating temperature, they can only be used for maintained emergency lighting.

Table 4: Typical starting times for OSRAM DULUX®EL LONGLIFE 5 W and 7 W

(in seconds, cold lamp) in DC operation at different temperatures

Ambient temperature: 176 V DC 198 V DC 220 V DC 280 V DC

0°C 7 5 4 2 10°C 6 4 3 2 23°C 5 4 3 < 2 50°C 4 3 2 1

The requirements for luminous flux, luminance and so on in areas such as corridors and stairwells must be met by the system in which lighting designers use OSRAM DULUX®EL LONGLIFE lamps.

3. Lamp data and lamp properties

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3.5.2.2 OSRAM DULUX®EL LONGLIFE FACILITY

OSRAM DULUX®EL FACILITY 10 W and 14 W E27/B22d / E14 can be operated indoors on AC voltage and also on DC voltage in the 176 V DC to 310 V DC range and on battery powered 220/240 V systems.

At a lower threshold voltage of 176 V DC the OSRAM DULUX®EL FACILITY will start reliably at temperatures from -30°C to 50°C. They can handle overvoltages in the DC system up to 310 V DC. The lamps reach their rated values in DC operation at around 280 V DC. For other DC voltage values the differences are typically as follows:

Electrical and photometric data in DC operation

Emergency lighting:

With a starting time of less than 0.5 s, OSRAM DULUX®EL FACILITY lamps are suitable in accordance with VDE 0108 for use in emergency lighting systems in a DC voltage range from 176 V DC to 310 V DC. This applies to both maintained and nonmaintained emergency lighting.

With due regard to the properties of the lamps, the requirements for luminous flux and illuminance in areas such as corridors and stairwells must be met by the system in which lighting designers use OSRAM DULUX®EL FACILITY lamps.

Supply voltage: Power Luminous flux

System or

input

battery-current

310 V DC 110 % 110 % 48 % 280 V DC 100 % 100 % 49 % 220 V DC 80 % 78 % 50 % 180 V DC 65 % 60 % 50 %

1) As a percentage of the rated value

2) As a percentage of the rms value for ac voltage

3. Lamp data and lamp properties

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3.5.3 Dimmer operation

3.5.4 Operation on

electronic switches

Brightness control with standard dimmers is not possible with OSRAM DULUX®EL lamps.

The electronic control gear of the lamp contains a rectifier and smoothing capacitor (electrolytic capacitor) in the input circuit. This electrolytic capacitor is always charged to the peak value of the AC voltage; mains current flows only briefly and up to the maximum mains voltage. This design prohibits operation with standard dimmers since leading-edge and trailing-edge dimmers would damage the electrolytic capacitor with their steep voltage rises and associated high peak currents.

In addition, most dimmers require a minimum load of many times that of an OSRAM DULUX®EL lamp so that even with the dimmer fully turned up, its switching element would not find an adequate holding current, with the result that the lamp would be continually switched on and off. This would not only damage the OSRAM DULUX®EL lamp, it may also destroy the dimmer.

As an alternative to external dimmer systems, OSRAM therefore offers the OSRAM DULUX®EL VARIO, the lamp with integrated two-stage brightness control (cf. 1.3.10).

This mode of operation is possible only if certain conditions are met.

Because of the design of the input circuit, current flows only for about 4 ms per mains half-wave (cf. 3.5.3). The peak value of this current is three times the rms value. This high crest factor must be taken into account when operating the lamp with electronic switches. Simple thyristor or triac switches that are triggered only once after zero crossing are not suitable because the OSRAM DULUX®EL does not draw holding current at this point. An ohmic load (such as an incandescent lamp) would have to be operated in parallel with the OSRAM DULUX®EL. This would then ensure the holding current for the electronic switch.

More suitable are electronic switches that do not need a holding current (for example those with a MOSFET as the active switching element), or a relay and contactor.

Note the maximum switch-on current of 25 A for approx 80 µs half-value width (except VARIO: 48 A). A reduction to less than 1 A per OSRAM DULUX®EL is possible if, with appropriate control of the electronic switch, the lamp is only switched on at zero crossing.

The maximum charge taken up in the switch-on current surge is between 0.4 and 3 mAs (depending on the wattage); the maximum energy taken from the source per switch-on current surge is 1 Ws (2 Ws if switch-on takes place at maximum mains value). This applies to OSRAM DULUX®EL LONGLIFE, OSRAM DULUX®EL ECONOMY, OSRAM DULUX®EL FACILITY, OSRAM DULUX®EL SENSOR Plus and OSRAM DULUX®EL VARIO.

3. Lamp data and lamp properties

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3.5.5 Operation on

switches with load relief, spark suppression or glow lamps parallel to the switch path

3.5.6 Operation on

motion detectors

3.5.7 Operation parallel

to uncorrected CCG lamps

OSRAM DULUX®EL lamps cannot be operated on jumpered switches (even at high resistance).

Because of the parallel path to the switch the OFF setting is never fully at high resistance. If incandescent lamps are used this is of no importance. If however all the incandescent lamps are replaced by OSRAM DULUX®EL lamps, then even small currents with the switch in the OFF setting will cause the high-impedance input circuit of the OSRAM DULUX®EL to charge up until the threshold voltage at the electrolytic capacitor for starting the HF generator is reached and the lamp consumes the energy stored in the electrolytic capacitor in repeated attempts to start.

This leads to premature ageing and the brief weak flashes of light are irritating.

Necessary load relief elements have to be wired parallel to the load, and neon lamps for illuminating the switches need to be connected parallel to the mains as permanent lights or parallel to the load as signal lights.

OSRAM DULUX®EL lamps can be operated with motion detectors provided the provisions of Section 3.5.4 (for the switching element of the motion detector) and Section 3.5.5 (for any switch load relief elements parallel to the switch) are met.

If motion detectors are used in highly frequented areas, we recommend either setting the ON time as long as possible to avoid unnecessary on/off switching or installing OSRAM DULUX®EL FACILITY lamps.

For these applications the base down burning position is better than the base up position because the ECG stays cooler and the PTC thermistor cools down faster ready for the next gentle start (cf. Section 3.1).

If the lamps are used outdoors in conjunction with motion detectors, note that at low temperatures low levels of luminous flux will be available immediately after the lamp is switched on. Again, the base down position is better (cf. 3.4.1).

If uncorrected conventional control gear is used (or highly inductive loads) a large voltage surge may be generated when the control gear is switched off at maximum current.

If an OSRAM DULUX®EL is connected in parallel on thee same circuit it will be exposed to a large voltage surge which may destroy it ( see also Section 3.5.13).

3. Lamp data and lamp properties

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3.5.8 Operation on

BUS systems

3.5.9 Operation on

non-sinusoidal voltage sources

3.5.10 Phase shift

Power factor PF correction

If the OSRAM DULUX

EL lamp is controlled by a BUS system, the requirements of

Sections 3.5.4 and 3.5.5 must be met.

Operation of OSRAM DULUX®EL lamps on non-sinusoidal voltage sources (e. g.square wave and trapezoidal inverters) is not straightforward.

It should be remembered that steep signal edges with square-wave inverters mean additional reverse recovery losses for the rectifier and that frequently observed overshoots by powerful inverters may lead to increased charging currents in the electrolytic capacitor (increased crest factor) and, in the worst case scenario, to significant overvoltages. In the event of a high energy overshoot, the electrolytic capacitor charges up to its peak value.

The rms currents should under no circumstances exceed the values for sinusoidal supply and there should be no overshoots. In selecting the inverter, bear in mind that at the moment its is started an OSRAM DULUX®EL lamp has four times the current draw for less than 100 ms (or up to several seconds if the lamp is started at a low temperature) (temporary overload capacity of the inverter). It must be possible for the electrolytic capacitor (typically 1 to 6,8 µF) to be charged by the inverter (start-up current, stability of the control loop).

The phase shift factor cos ϕ indicates the phase shift between mains current and mains voltage and relates exclusively to the fundamental harmonic (50 Hz). The phase shift of harmonics that occur because of non-sinusoidal current draw is not considered here. OSRAM DULUX

EL lamps have a phase shift factor cos ϕ of ≈ 0,95 (capacitive).

The power factor (λ) is defined as: λ = active power N/(rms current l

rms

x rms voltage U

rms

For OSRAM DULUX®EL LONGLIFE and ECONOMY it is approximately 0.6. This value results from the distorted non-sinusoidal draw (mains current harmonic content) of OSRAM DULUX®EL LONGLIFE and ECONOMY and to a lesser extent from a current/voltage phase shift of the 50 Hz component. For this reason, correction of the power factor by capacitors, which is usual with fluorescent lamps in CCG mode, is not possible.

The actual energy consumption of OSRAM DULUX®EL LONGLIFE and ECONOMY lamps is only 20 % of that of an incandescent lamp of similar light output. It is independent of the power factor and is determine only by the active power, which can be measured by a standard ammeter. The savings of 80 % have a direct impact on fuel consumption (coal, oil, gas) and on emissions from power stations.

Because of the lower power factor of around 0.6, the power consumption of OSRAM DULUX®EL LONGLIFE and ECONOMY lamps is not reduced to 20 % but to around 33 %. This causes an appropriate reduction in current draw and not an increase in the losses between the generator and load, and therefore additional energy savings.

3. Lamp data and lamp properties

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3.5.11 Mains current harmonic content

3.5.12 RFI suppression

3.5.13 Resistance to electro-magnetic interference and transient overvoltages

3.5.14 Interference from IR remote controls

3.5.15 Bases/holders

Since January 1, 2001 EN 61000-3-2 „Electromagnetic Compatibility (EMC)...“ is the general standard for harmonic currents.

All OSRAM DULUX®EL and OSRAM CIRCOLUX®EL lamps comply with the provisions of EN 61000-3-2.

All OSRAM DULUX®EL and OSRAM CIRCOLUX®EL lamps are RFI suppressed to EN 55015 (identical to CISPR 15). Interference on the mains supply is prevented by the interference suppression filter connected on the incoming side of the electronics.

All OSRAM DULUX®EL and OSRAM CIRCOLUX®EL lamps comply with the immunity requirements defined in EN 61547 relating to external electromagnetic interference.

The discharge characteristics of fluorescent lamps means that a small amount of infrared radiation cannot be avoided. If conditions are less than ideal, particularly if the lamps and the IR receiver are arranged too close to one another, this may lead to interference with IR remote controls. This also depends on the modulation of the radiation emitted by the lamp (operating frequency of the ECG), the modulation frequency and the coding of the signals used for IR signal transmission. The signal-to-noise ratio also plays a role.

If interference occurs, we recommend moving the IR receiver out of the radiation range of the lamp or by making sure it is not exposed to direct light.

The IEC has produced recommendations for avoiding such interference on IR signal transmission equipment. Unfortunately, some old IR signal transmitters operated in the same frequency range as the lamps (about 35 kHz). OSRAM therefore increased the operating frequency of all OSRAM DULUX®EL and OSRAM CIRCOLUX®EL lamps to more than 40 kHz to minimise the risk of interference. The latest generation of IR controlled equipment is now making use of „intelligent“ IR receivers that continue to operate correctly even if they receive IR interference.

OSRAM DULUX®EL LONGLIFE, OSRAM DULUX®EL ECONOMY and OSRAM CIRCOLUX®EL lamps are equipped with E14 or E27 screw bases or with B22d bayonet bases on request and will therefore fit in any standard incandescent lamp fittings.

3. Lamp data and lamp properties

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3. Lamp data and lamp properties

3.6 Reduction in luminous

flux over time

Because of chemical changes in the phosphor and the glass the luminous flux of an energy saving lamp will decrease with age. This reduced is around 30 % with conventional phosphors and only around 25 to 27 % with the LUMILUX

tri-phosphors used in all OSRAM DULUX®EL and OSRAM CIRCOLUX®EL lamps.

Fig. 15a: Typical relationship between luminous flux and hours of operation for

OSRAM DULUX®EL LONGLIFE

Fig. 15b: Typical relationship between luminous flux and hours of operation for

OSRAM DULUX®EL ECONOMY

Luminous flux (%age of initial value)

Operating hours (h)

100

Decrease in luminous flux for OSRAM DULUX®EL LONGLIFE 7, 11, 15, 20 and 23 W

Luminous flux (%age of initial value)

Operating hours (h)

Decrease in luminous flux for OSRAM DULUX®ECONOMY 8, 12, 16, 21 and 24 W

100

3000 6000 9000 12000 15000 180001000 2000 4000 5000 7000 8000 10000 11000 13000 14000 16000 17000

100

3000 6000 9000 12000 15000 180001000 2000 4000 5000 7000 8000 10000 11000 13000 14000 16000 17000

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3.7 Lamp life

The life of fluorescent lamps is determined essentially by the consumption of the emitter on the lamp cathodes. The average life of OSRAM DULUX®EL LONGLIFE lamps is 15000 hours; that of OSRAM DULUX®EL ECONOMY lamps is 8000 hours. Half of any number of lamps may fail up to this time (50 % mortality).

Mortality curve for OSRAM DULUX®LONGLIFE 7, 11, 15, 20 and 23 W

Mortality curve for OSRAM DULUX®ECONOMY 8, 12, 16, 21 and 24 W

Fig. 16: Typical mortality curve for OSRAM DULUX

EL LONGLIFE

and ECONOMY lamps

3. Lamp data and lamp properties

Burning lamps (%)

Operating hours (h)

Burning lamps (%)

Operating hours (h)

100

3000 6000 9000 12000 15000 180001000 2000 4000 5000 7000 8000 10000 11000 13000 14000 16000 17000

100

3000 6000 9000 12000 15000 180001000 2000 4000 5000 7000 8000 10000 11000 13000 14000 16000 17000

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3.7 Life

(Continued)

3.8 Suitability for

outdoor applications

3.9 Suitability for

explosion-proof luminaires

The following may shorten the life of a lamp:

• Overloading of the lamp at excessive supply voltage (see 3.5)

• Failure of electronic components at excessively high/low ambient temperatures (see 3.4)

• Operation on standard leading-edge or trailing-edge dimmers (see 3.5.3)

• Operation on eletronic switches (see 3.5.4)

• Operation on switches with load relief, spark suppression or neon lamps parallel to the switch path (see 3.5.5)

• Operation parallel to non-pfc CCG lamps (see 3.5.7)

• Operation on non-sinusoidal voltage sources (see 3.5.9)

• Frequent switching – e. g. in stairwell lighting (see 3.1, exceptions: OSRAM DULUX®EL VARIO, OSRAM DULUX®EL SENSOR Plus and OSRAM DULUX®EL FACILITY)

• Excessively short OFF times (PTC thermistor) for OSRAM DULUX®EL LONGLIFE and OSRAM CIRCOLUX®EL

When lamp comes to the end of its life the lamp circuit is broken; the flickering typical of fluorescent lamps operated on chokes and starters does not occur with electronic energy saving lamps.

OSRAM DULUX®EL LONGLIFE and ECONOMY lamps are suitable for outdoor use. However, to protect them from moisture they must be used in enclosed ventilated luminaires that have a drain hole where condensate can escape. If the lamps are used outdoors in winter the luminous flux may be reduced by the low temperatures (see Section 3.4.1).

OSRAM DULUX®EL CLASSIC and OSRAM DULUX®EL GLOBE (LONGLIFE and ECONOMY) in enclosed ventilated luminaires (with drain holes) or semienclosed luminaires are ideal for outdoor use in the base down burning position. If low temperatures are expected, OSRAM DULUX®EL LONGLIFE CLASSIC (1.3.5) or GLOBE (1.3.7) should be used.

OSRAM DULUX®EL LONGLIFE and ECONOMY lamps can also be used in areas where there is a heigthened risk of fire or explosions. The requirement here is that they should be used in luminaires that comply with type of protection „flameproof enclosure“ to EN 50018. The fact that these lamps produce much less heat than incandescent lamps is advantageous here.

3. Lamp data and lamp properties

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3.10 Additional information on OSRAM DULUX

SENSOR Plus

1. Why doesn’t the lamp come on immediately in a darkened room?

• IR (= infra red) radiation from the sun may still be getting into the room

• There is an IR source in the room (such as a light bulb switched on)

• Depending on the IR level it may take up to 45 seconds for the lamp to switch on

2. Can I have several lamps in one luminaire or in neighbouring luminaires?

• Yes, provided the sensors are not pointing directly at the other lamps.

3. How can I test a lamp in a luminaire?

• You can do this by simply applying mains voltage (see Self-test)

• Further testing can only be carried out at considerable cost. Covering the sensors may cause the lamp to go out after 45 seconds. If the sensors are then uncovered again the lamp will switch on again only after a lengthy period of time and will switch off as the ambient brightness increases.

4. In one luminaire the lamp switches on too early in the evening.

• Cause: The luminaire or lamp is pointing east-north-east. In the evening very

little light (and therefore IR radiation) falls on the lamp.

• Remedy: Change the position of the luminaire, change the shade over the

luminaire, turn the sensor towards the source of light.

5. In one luminaire the lamp switches on too late in the morning.

• Cause: The luminaire or lamp is pointing west-north-west. In the morning very

little light (and therefore IR radiation) falls on the lamp. The problem may rest with the design of the luminaire – the sensors may not be „seeing“ and IR radiation.

• Remedy: Change the position of the luminaire, change the shade over the

luminaire, turn the sensor towards the source of light.

6. The lamp flashes at night in the luminaire.

• Cause: An external light source (IR) is interfering with the normal operation of

the lamp or the luminaire cover is the problem.

• Remedy: Change the luminaire cover, turn the sensors towards daylight (IR).

As an OSRAM DULUX IC is used to control the lamp, the life of the lamp will not be significantly affected by frequent on/off switching.

3. Lamp data and lamp properties

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

3.11 Possible malfunctions OSRAM DULUX

SENSOR Plus

3. Lamp data and lamp properties

Fault Possible reason Remedy

The lamp does not No power supply to switch itself on the lamp because

the lamp is not Screw in properly screwed in far enough Luminaire incorrectly Check contacts connected Contacts out of alignment Position contacts correctly Lamp faulty Consult dealer

The lamp does not The luminaire is in too Change the position of switch off in daylight much shade the luminaire

▲▲▲▲

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

4. OSRAM DULUX®EL

and the environment

4.1 Energy balance

4.2 Substances

Whenever energy is used there is an impact on the environment. This impact principally takes the form of the release of carbon dioxide (CO

) when electricity is generated in fossil fueled power stations (1 kWh of electricity = 1 kg of CO2emissions*). The CO2contributes significantly to the „greenhouse effect“, or global warming.

Saving energy is therefore of utmost importance for environmental protection and for OSRAM.

Compared with ordinary light bulbs, all OSRAM DULUX®EL LONGLIFE and ECONOMY lamps not only save energy during their lives, they need less energy for their manufacture.

* For an assumed efficiency of 37 % (power station + power distribution), a molecular weight for CO2of 44 and a thermal value of 10 kWh per 1 kg of coal (carbon), 1kg CO2is produced per 1 kWh of generated energy.

Like all discharge lamps, OSRAM DULUX®EL LONGLIFE and ECONOMY lamps are enclosed systems in normal use. Apart from emitting light, they therefore can have no impact on the environment. A major substance in discharge lamps that is potentially harmful to the environment is mercury. Without it, however, the lamps would not work. Thanks to a patented dosing procedure, OSRAM has succeeded in reducing the mercury content to less than 3 mg per lamp.

OSRAM DULUX®EL LONGLIFE and ECONOMY lamps contain no radioactive

substances.

What’s more, mercury is released when energy is generated from fossil fuels, which means that in this respect the environmental impact of incandescent lamps is much greater than that of compact fluorescent lamps even allowing for the mercury in the compact fluorescent lamp.

All OSRAM DULUX

EL LONGLIFE and ECONOMY lamps are environmentally friendly products because of their energy savings and the associated reduced environment impact (carbon dioxide and mercury).

4. OSRAM DULUX®EL and the environment

Fig. 19: Cumulative energy consumption (kWh) for the manufacture (incl. materials)

and operation of 75 W incandescent lamps and comparable 15 W OSRAM DULUX®EL lamps

12,9 kWh manufacturing energy

1125 kWh operating energy

3,4 kWh manufacturing energy

225 kWh operating energy

15 incandescent lamps

1137,9 kWh

12,9 kWh Herstellenergie

1000

800

kWh

600

400

200

1125 kWh Betriebsenergie

228,4 kWh

3,4 kWh Herstellenergie

225 kWh Betriebsenergie

15 Glühlampen 1 OSRAM DULUX® EL LONGLIFE

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

4.3 Disposal

4.4 Energy Efficiency Index EEI

In Germany, discharge lamps that contain mercury are classified as waste requiring special supervision (special waste) under the Closed Substance Cycle and Management Act (Kreislaufwirtschaftsgesetz) and its provisions. This means that these lamps have to be disposed of as special waste (EEC Code 060404 Waste containing mercury), apart from small volumes in private households.

Private users should still dispose of their old fluorescent lamps (OSRAM DULUX

)

at local recycling centres or collection points.

European Directive 98/11/EC, Energy labelling of mains voltage household lamps: The EEI (Energy Efficiency Index, e. g. EEI = A), also known as the „Energy Label“, classifies lamps according to their energy efficiency (it does not relate to luminaires however).

The seven classes are defined by certain limit values in light output relative to wattage. Lamps in class A are the most efficient at converting electrical energy into light.

* Reflector lamps are excluded from the Energy Label. B’ Candle version

Type 3W 5W 7W 8W 9W 10W 11W 12W 14W 15W 16W 20W 21W 23W 24W

OSRAM DULUX®EL AAA A LONGLIFE E14 OSRAM DULUX

EL LONGLIFE A A A A A A E27/B22d OSRAM DULUX

EL LONGLIFE B A A B A A CLASSIC A B’ OSRAM DULUX

EL LONGLIFE B B GLOBE OSRAM DULUX

EL LONGLIFE * * REFLEKTOR OSRAM DULUX

EL LONGLIFE A A FACILITY OSRAM DULUX

EL LONGLIFE VARIO A OSRAM DULUX

EL LONGLIFE A SENSOR Plus OSRAM DULUX

EL ECONOMY E14 A A OSRAM DULUX

EL ECONOMY A A A B A E27/B22d OSRAM DULUX

EL ECONOMY A A B’ A A CLASSIC A B’ B’ OSRAM DULUX

EL ECONOMY BB GLOBE OSRAM CIRCOLUX

EL A

4. OSRAM DULUX®EL and the environment

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

Formula for compact fluorescent lamps with integrated control gear: Conditions for Class A: W ≤

(

0.24 x luminous flux)+ (0.0103 x luminous flux)

Conditions for Class B: Ei< 60 %

Ei=W/WR% WR=(0.88 x luminous flux

)

+ (0.049 x luminous flux) W stands for rated power W

stands for reference power input

Eistands for % Energy Efficiency Index

German standard DIN EN 50285: 1999 „Energy efficiency of electric lamps for household use – measuring methods“

√

4. OSRAM DULUX®EL and the environment

√

Wattage of the lamp in W

Luminous flux in lm

Classification „B“ or worse

Classification „A“

Energy Label classification

300 600 900 1200 1500 1800100 200 400 500 700 800 1000 1100 1300 1400 1600 1700

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

Your contacts

Alfred Haas Thomas Heider Christian Daelman Head of Business Unit CFL Product Manager Application Engineer OSRAM GmbH OSRAM GmbH OSRAM GmbH CFL M-M CFL M-M CFL M-M Hellabrunner Str. 1 Hellabrunner Str. 1 Hellabrunner Str. 1 D-81543 Munich D-81543 Munich D-81543 Munich

Tel. (+49 89) 62 13-22 08 Tel. (+49 89) 62 13-24 23 Tel. (+49 89) 62 13-26 04 Fax (+49 89) 62 13-40 52 Fax (+49 89) 62 13-40 52 Fax (+49 89) 62 13-40 52 E-Mail: a.haas@osram.de E-Mail: t.heider@osram.de E-Mail: c.daelman@osram.de

For further product information on compact fluorescent lamps go to: http://www.osram.de/produkte/allgemein/kompakt/index.html

www.OSRAM.com

4. OSRAM DULUX®EL and the environment

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

Notes

OSRAM DULUX®EL – electronic energy saving lamps

Economical alternatives to ordinary light bulbs Technical Guide

Notes

102 T03 E 09/03 Ost OSRAM CFL M Technische Änderungen und Irrtümer vorbehalten

Umweltfreundlich gedruckt auf chlorfrei gebleichtem Papier

Head office Germany

OSRAM GmbH Hellabrunner Strasse 1 81536 München Tel.: +49-89-62 13-0 Fax: +49-89-62 13-20 20

International addresses

Albania

(supported by OSRAM Greece)

Argentina

OSRAM Argentina S.A.C.I. Ramos Mejia 2456 B 1643 ADN Beccar Pcia. de Buenos Aires Tel.: +54-11-6333-8000 Fax: +54-11-4737-0222

Australia

OSRAM Australia Pty. Limited Building 1, 11th Floor P.O. Box 673 423 Pennant Hills Road Pennant Hills 2120 New South Wales Tel.: +61-29-4 81-83 99 Fax: +61-29-4 81-94 68

Austria

OSRAM GmbH Lemböckgasse 49/C/5 1230 Wien Postfach 1 62 1231 Wien Tel.: +43-1-6 80 68-0 Fax: +43-1-6 80 68-7

Baltic states: Estonia, Latvia, Lithuania

(supported by OSRAM Finland)

Belgium

N.V. OSRAM S.A. Mercuriusstraat 28 1930 Zaventem Zuid 7 Tel.: +32-2-7 19 29 11 Fax: +32-2-7 20 99 75

Bosnia-Herzegovina

(supported by OSRAM Croatia)

Brazil

OSRAM do Brasil Lâmpadas Elétricas Ltda. Av. dos Autonomistas, 4229 06090-901 Osasco-SP Tel.: +55-11-36 84 74 08 Fax: +55-11-36 85 94 95

Bulgaria

OSRAM EOOD Nikola Obreschkov 1, Wh. A., App. 1 1113 Sofia / Bulgaria Tel.: +359-2-9 71 22 62 Fax: +359-2-9 71 45 46

Canada

OSRAM SYLVANIA Ltd. 2001 Drew Road Mississauga Ontario L5S 1S4 Tel.: +1-905-6 73 61 71 Fax: +1-905-6 73 62 90

Chile

OSRAM Chile Ltda. Santa Elena de Huechuraba 1135 B Huechuraba Santiago-Chile Tel.: +56-2-7 40-09 39 Fax: +56-2-7 40-04 66

China

OSRAM Foshan Lighting Co. Ltd. No.1 North Industrial Road, Postal code 528000 Foshan, Guangdong, P. R. China Tel.: +86-757-64 82-111 Fax: +86-757-64 82-222

OSRAM Shanghai Rep. Office Harbour Ring Plaza No. 18 Xi Zang Middle Road Room 2802, 2803 A Shanghai, 200001 P.R.C. Tel.: +86-21-53 85 28-48 Fax: +86-21-64 82 12-19

OSRAM Sylvania Inc. PMC Shanghai Rep. Office 2805A 28/F Harbour Ring Plaza No. 18 Xi Zang Rd. M. Shanghai Shanghai, 200001 P.R.C. Tel.: +86-21-53 85 28-48 Fax: +86-21-53 85 20 22

Colombia

OSRAM de Colombia Diagonal 109 No. 21-05 Oficina 607, 608 Bogotá Tel.: +57-1-6 19 24 07 Fax: +57-1-6 37 18 55

Croatia

OSRAM d.o.o. Ozalijska 93 10000 Zagreb Tel.: +385-1-303-20 00 Fax: +385-1-303-20 01

Czech Republic

OSRAM spol. s.r.o. Praha Tylovo námesti 3/15 12000 Praha 2 Tel.: +420-2-2 19 87-100 Fax: +420-2-2 19 87-120

Denmark

OSRAM A/S Dybendalsvaenget 3 Postboks 259 2630 Tåstrup Tel.: +45-44-77 50-00 Fax: +45-44-77 50-55

Egypt

OSRAM Cairo Rep. Office OSRAM GmbH 5th Floor, Unit No. 507 57 Giza Street Cairo, Giza Tel.: +20-2-7 48 66 46 Fax: +20-2-7 48 66 46

Ecuador

OSRAM del Ecuador S.A. Casilla 09-01-8410 Guayaquil Tel.: +593-4-2 89 36 09 Fax: +593-4-2 89 35 58

Finland

OSRAM Oy Vanha Porvoontie 229 01380 Vantaa Box 91 01301 Vantaa Tel.: +358-9-74 22 33 00 Fax: +358-9-74 22 33 74

France

OSRAM SASU 5, Rue d’Altorf 67124 Molsheim BP 1 09 67124 Molsheim Cedex Tel.: +33-388-49 75 99 Fax: +33-388-49 75 97

Great Britain

OSRAM Ltd. OSRAM House Waterside Drive Langley, Berkshire SL3 6EZ Tel.: +44-17 44-81 22 21 Fax: +44-17 44-83 19 00

Greece

OSRAM A.E. Athinon Av. 56 10441 Athen Tel.: +30-2 10-5 20 18 00 Fax: +30-2 10-5 22 72 00

Hong Kong

OSRAM Prosperity Co. Ltd. Rm 4007-09 Office Tower, Convention Plaza 1 Harbour Road, Wanchai Hong Kong Tel.: +852-25 11 22 68 Fax: +852-25 11 20 38

Hungary

OSRAM KFT. Alkotas utca 41. 1123 Budapest Pf.: 700/61 1535 Budapest Tel.: +36-1-2 25-30 55 Fax: +36-1-2 25-30 54

Iceland

Jóhann Olafsson & Co. h/f 43 Sundaborg 13 104 Reykjavik Tel.: +354-533 19 00 Fax: +354-533 19 30

India

OSRAM India Ltd. Signature Towers, 11th Floor, Tower-B South City-I 122001 Gurgaon Haryana/India Tel.: +91-124-238 31-80 Fax: +91-124-238 31-82

Indonesia

PT OSRAM Indonesia Jalan Siliwangi KM 1 Desa Keroncong Jatiuwung 15134 Tangerang Tel.: +62-21-5 90 01 27-00 Fax: +62-21-5 90 05 59

Iran

OSRAM Lamp Private Joint Stock Company (OSRAM PJS Co.) Bokharest Ave, Str. 6, No. 13 Tehran Iran Tel.: +98-21-8 73 84 76 Fax: +98-21-8 73 24 13

Italy

OSRAM Società Riunite OSRAM Edison-Clerici S.p.A. Via Savona 105 Casella Postale 1 41 06 20144 Milano Tel.: +39-02-42 49-1 Fax: +39-02-42 49-380

Japan

OSRAM-MELCO Ltd. Tobu Yokohama Bldg.No. 3 (4F) 8-29, Kitasaiwai 2-chome, Nishi-Ku 220-0004 Yokohama Tel.: +81-45-3 23 51-20 Fax: +81-45-3 23 51-55

OSRAM Ltd. Tobu Yokohama Bldg.No. 3 (6F) 8-29, Kitasaiwai 2-chome, Nishi-Ku 220-0004 Yokohama Tel.: +81-45-3 23 51-00 Fax: +81-45-3 23 51-10

Korea

OSRAM Korea Co., Ltd. 3rd. Fl. Ye-Sung Bldg. 150-30 Samsung-dong, Kangnam-Ku Seoul 135-090 Tel.: +82-2-5 54 41 12 Fax: +82-2-5 56 16 44

Macedonia

(supported by OSRAM Greece)

Malaysia

OSRAM (Malaysia) Sdn Bhd

7.05-7.06 Amoda Building 22, Jalan Imbi 55100 Kuala Lumpur Tel.: +60-3-21 45 95-33 Fax: +60-3-21 45 95-35

Mexico

OSRAM de México, S.A. de C.V. Camino a Tepalcapa No. 8 54900 Tultitlán/Edo. de México Tel.: +52-5-58 99-18 00 Fax: +52-5-58 99-65 60

Netherlands

OSRAM Nederland B.V. Vennootsweg 15 2404 CG Alphen a/d Rijn Postbus 3 32 2400 Alphen a/d Rijn Tel.: +31-172-48 38 38 Fax: +31-172-44 30 25

Norway

OSRAM Oslo OSRAM AS Strandveien 50 N-1366 Lysaker Tel.: +47-67 83 67-00 Fax: +47-67 83 67-40

Philippines

OSRAM Philippines Unit 2002–2003 Antel Global Corporate Center Julia Vargas Avenue Ortigas Center Pasig City Tel.: +632-687 60 48-50 Fax: +632-687 60 57

Poland

OSRAM Sp. z o.o. ul. Wiertnicza 117 PL 02292 Warszawa Tel.: +48-22-6 51 78 69 Fax: +48-22-6 42 14 18

Portugal

OSRAM Empresa de Aparelhagem Eléctrica Lda. Rua Alto do Montijo Nr. 15-4 andar 2795-619 Carnaxide Tel.: +351-2 14 16 58 60 Fax: +351-2 14 17 12 59

Romania

OSRAM Romania S.R.L. Sos. Pipera Nr. 41 Sector 2 7000 Romania/Bucaresti Tel.: +40-21-2 33 02-12 Fax: +40-21-2 33 02-14

Russia

OSRAM RUS Rep. Office OSRAM GmbH Ul. Malaja Kaluschskaja 15/4 119071 Moscow Tel.: +7-095-9 35 70-70 Fax: +7-095-9 35 70-76

Singapore

OSRAM Singapore (Pte.) Ltd. 159 Sin Ming Road #05-04 Amtech Building 575625 Singapore Tel.: +65-65 52 01 10 Fax: +65-65 52 71 17

Slovak Republic

OSRAM Slovakia a.s. Komárnanská cesta 7 94093 Nové Zámky Tel.: +42-1-35 64 64-409 Fax: +42-1-35 64 64-893

Slovenia

(supported by OSRAM Austria)

South Africa

OSRAM (Pty.) Ltd., 260, 15th Road 1683 Randjespark/Midrand Private BAG X 206 1685 Halfway House/Midrand Tel.: +27-11-2 07 56 00 Fax: +27-11-8 05 17 11

Spain

OSRAM, S.A. Calle de la Solana, 47 28850 Torrejón de Ardoz (Madrid) Tel.: +34-91-6 55 52 00 Fax: +34-91-6 77 92 40

Sweden

OSRAM AB Rudanvägen 1 Box 5 04 13625 Haninge Tel.: +46-8-7 07 44-00 Fax: +46-8-7 07 44-40

Switzerland

OSRAM AG In der Au 6 Postfach 2179 8401 Winterthur/Töss Tel.: +41-52-2 09 91 91 Fax: +41-52-2 09 99 99

Taiwan

OSRAM Taiwan Company Ltd. Sung Chiang Road, 7th Floor Empire Building No. 87 P.O. Box 46304 Taipei Tel.: +886-2-25 08 35 02 Fax: +886-2-25 09 67 82

Thailand

OSRAM Thailand Co., Ltd. 100/45, 24th Floor Sathorn Nakorn Tower North Sathorn Road Khwaeng Silom Khet Bangrak, Bangkok 10500 Tel.: +66-2-6 36 74 75 Fax: +66-2-6 36 74 77

Turkey

OSRAM AMPUL TIC. A.S. Meclisi Mebusan Caddesi 125 80400 Findikli Istanbul Tel.: +90-212-334-1334 Fax: +90-212-334-1142

Ukraine

OSRAM Kiev Rep. Office OSRAM GmbH ul. Vorovskogo, 36 01054 Kiev Tel.: +380-44-2 46 93 14 Fax: +380-44-2 46 99 91

United Arab Emirates

OSRAM Middle East FZE 4th Floor, New High Rise Building LOB 14 P.O. Box 17476 Jebel Ali, Dubai Tel.: +971-4-88 13-767 Fax: +971-4-88 13-769

USA

OSRAM SYLVANIA INC. 100 Endicott Street Danvers, MA 01923 Tel.: +1-978-777-19 00 Fax: +1-978-777-12 47

Vietnam

OSRAM Singapore Pte. Ltd. Rep. Office Vietnam 59A Ly Thai To Street, Hanoi Press Club Hoan Kiem District Hanoi – Vietnam Tel.: +84-4-93 49-801 Fax: +84-4-93 49-803

Yugoslavia

OSRAM Belgrad Rep. Office of OSRAM GmbH Predstavnistvo OSRAM GmbH Cika Ljubina 15/V 11000 Beograd Tel.: +381-11-30 30-860 Fax: +381-11-30 30-853

Internet

http://www.osram.de http://www.osram.com http://www.osram.de/lightatwork/ http://www.osram.com/lightatwork/

OSRAM DULUX Technical Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
