OSEE UDA6801N, BDA6801N User Manual
BDA6801N/UDA6801N
Digital Audio Distribution Amplifier
USER MANUAL
Product Information
Model:
BDA6801N/UDA6801N Digital Audio Distribution Amplifier
Version:
V010000
Release Date:
March 13th, 2009
Company
OSEE TECHNOLOGY CO., LTD.
Contact Information
Address:
No.22 Building, No.68 zone, Beiqing Road, Haidian District,
Beijing, China
Post Code:
100094
Tel:
(+86) 010-62434168
Fax:
(+86) 010-62434169
Web:
http://www.osee-dig.com/
E-mail:
sales@osee-dig.com
Contents
Chapter 1 Introduction ........................................................................................................... 1
1.1 Product Overview ........................................................................................................................... 1
1.2 Features ........................................................................................................................................... 1
1.3 Module Descriptions ...................................................................................................................... 2
1.3.1 6800-C2 Frame Back Panel Connector ............................................................................. 2
1.3.2 BDA6801N/UDA6801N Module Back Connector ............................................................ 2
1.3.3 Signal Flow ........................................................................................................................... 4
Chapter 2 Installation ............................................................................................................. 4
2.1 Maximum Power Ratings for Frame ............................................................................................ 4
2.2 Unpacking the Module ................................................................................................................... 4
2.2.1 Preparing the Product for Installation .............................................................................. 4
2.2.2 Check the Packing List ....................................................................................................... 5
2.3 Installing the Module ..................................................................................................................... 5
2.4 Making the Connections ................................................................................................................ 6
2.5 Removing the Module .................................................................................................................... 6
Chapter 3 Description of LED Alarm Indicator .................................................................. 7
Chapter 4 Specifications ......................................................................................................... 7
4.1 Digital AES Audio Inputs .............................................................................................................. 7
4.2 Digital AES Audio Outputs ........................................................................................................... 8
Chapter 5 Versions .................................................................................................................. 8
Chapter 6 Warranty for osee product .................................................................................. 9
6.1 What the warranty covers: ............................................................................................................ 9
6.2 What the warranty does not cover: .............................................................................................. 9
BDA6801N/UDA6801N Operating Manual
Specifications are subject to change without notice. —1—
Chapter 1 Introduction
1.1 Product Overview
BDA6801N/UDA6801N digital audio distribution amplifiers are multi-channel digital audio
distribution amplifier function modules.
BDA6801N has one channel balanced digital audio input, and 8 channels balanced digital audio
outputs by distributing and amplifying.
UDA6801N has one channel unbalanced digital audio input and 8 channels unbalanced digital audio
outputs, by distributing and amplifying.
Both of them support various alarm indications.
The module can be installed in 6800N series frame.
Tab. 1-1 Description of BDA6801N/UDA6801N
Module Description
BDA6801N
one channel balanced digital audio input, and 8 channels balanced
digital audio outputs
UDA6801N
one channel unbalanced digital audio input and 8 channels unbalanced
digital audio outputs
1.2 Features
The BDA6801N/UDA6801N offers the following features:
One channel balanced / unbalanced digital audio input, and 8 channels balanced / unbalanced
digital audio outputs
Low cost, high reliability, high quality audio distribution amplifier
Support many kinds of alarm indication and hot-swappable
FCC Caution:
Any Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
