OSD Audio XMP60 User guide

XMP60 2-CHANNEL CLASS D MINI STEREO

AMPLIFIER / MIC MIXER INSTALL GUIDE

WARNING

FEATURES

The XMP amplifier series is

XMP60

AC 100-240V IN

CONTENTS

FUNCTIONS

XMP60

POWER MIC MIC VOLUME BASS TREBLE VOLUME

1. 2. 3. 4. 5. 6. 7.

1. Power Button

2. Status LED: Green; On, Red: SM

3. Microphone Input ¼”

4. Dedicated Mic Volume Knob

5. Bass Control Knob : +/- 12dB

6. Treble Control Knob: +/- 12dB

7. Master Volume Knob

CONNECTIONS

STEREO

Max

Min

BRIDGE

Min

Max

Min

LR

Max

Min

Max

1. 2. 3.&4. 5.

1. 3.5mm Stereo Aux Input

2. Right and Left Stereo Inputs

3. Stereo Left and Right Channel Speaker Level Output 4/8 ohm

4. Bridged Mono Connection

5. Unpolarized C7/C8 coupler known as figure of 8 connector.

It connects to internal switching power supply: 100V to 240V

Note: Regarding Aux and Stereo Line inputs, it is recommended you choose one or the other
of the analog inputs since they will mix the signal if both are connected and playing at the
same time. The front panel Microphone will mix as well with whatever is connected and
playing, but it has its own volume control to adjust on top of the the Master Volume Control.

SPECIFICATIONS

• Power: Stereo (8 ohm): 25W per channel, <1% THD+N

Stereo (4 ohm): 45W per channel, <1% THD+N

Bridged Mono (8 ohm): 90W, 1kHz, <1% THD+N

• Frequency Response: 20Hz ~ 20kHz, -2dB/ +1dB

• Signal to Noise Ratio: 90dB below 25W output into 8 ohms

•Channel Separation: 48dB @ 1kHz, to 25W output at 8 ohms

• Input Sensitivity: 600mV input rated 25W output 8 ohms

• Net Weight: 1.37lbs / 621g

• Dimensions: 1.77”/(45mm) x 5.62”/(143mm) x 4.92”/(125mm)

WARRANTY

All OSD Audio electronics products have a 2 Year Limited Warranty against defects in materials and workman­ship. Proof of purchase must accompany all claims. During the warranty period OSD Audio will replace any
defective part and correct any defect in workmanship without charge for either parts or labor OSD Audio may
replace returned speakers with a product of equal value and performance. In such cases, some modification to
the mounting may be necessary and are not OSD Audios responsibility.

For this warranty to apply, the unit must be installed and used according to its written instructions. If necessary,
repairs must be performed by OSD Audio. The unit must be returned to OSD Audio at the owner’s expense and
with prior written permission. Accidental damage and shipping damage are not considered defects, nor is
damaged resulting from abuse or from servicing performed by an agency or person not specifically authorized

in writing by OSD Audio

OSD Audio sells products only through authorized dealers and distributors to ensure that customers obtain
proper support and service. Any OSD Audio product purchased from an unauthorized dealer or other source,
including retailers, mail over dealers and on-line sellers will not be honored or serviced under existing OSD
Audio warranty policy. Any sale of product by an unauthorized source or other manner not authorized by OSD
Audio shall void the warranty on the applicable product.

Damage to or destruction of components due to application of excessive power voids the warranty on those
parts. In these cases, repairs will be made on the basis of the retail value of the parts and labor. To return for
repairs, you must email customer service at [e-mail] for a Returned Merchandise
Authorization (RMA) number# then the unit must be shipped to OSD Audio at the owner’s expense, along with
a note explaining the nature of service required. Be sure to pack the speaker(s) in a corrugated container with
at least 3 inches of resilient material to protect the unit from damage in transit.

This Warranty Does Not Cover: Damage caused by abuse, accident, misuse, negligence, or improper operation
(installation) • Any products that have been altered or modified • Any product whose identifying number of decal,
serial #, etc. has been altered, defaced or removed • Normal wear and maintenance.

OSD Audio | Brea, CA | osdaudio.com
