OSD Audio SP650 User Manual

OSD

SP650 Square Planter Speaker

AUDIO

Amplifier and Receiver Considerations

The Planter speaker should be powered by an amplifier or receiver that provides
a minimum of 10 watts per channel.

Optional Accessories -

Tools needed for installation

- Spade or trench tool

- Direct burial rated speaker wire

16-4 AWG.............................................................................................................100 ft

14-4 AWG..................................................................................................100 - 150 ft

12-4 AWG..................................................................................................150 - 200 ft

Specifications

Design:

Tweeter: 2 x

Woofer:

Frequency Response: 72Hz - 22Hz

Power Handling: 150 Watts

Finishes: Beige

Impedance: 8 Ohm

Sensitivity: 84 dB

Dimensions: (H x W x D) H 29” x W 12

Gross Shipping Weight: 32.5 lbs

Unit of Measure:

Warranty

Technical Support Center at OSD Audio is available between the hours of 8:30
AM - 5:30 PM PST, Monday through Friday, excluding holidays.

All Weather resistant multi-purpose garden
speaker with a 6

sealed voice coil

6 ½“ Polypropylene cone

Warranty & Repair

All OSD Audio speaker products have (2) year Limited Warranty against defects in materials and
workmanship. Proof of purchase must accompany all claims. During the warranty period OSD
will replace any defective part and correct any defect in workmanship without charge for either

OSD Audio may replace returned speakers with a product of equal value and performance. In such

cases, some modifications to the mounting may be necessary and are not OSD’s responsibility.

For this warranty to apply, the unit must be installed and used according to its written instructions.
If necessary, repairs must be performed by OSD. The unit must be returned to OSD at the owner's
expense and with prior written permission. Accidental damage and shipping damage are not
considered defects, nor is damaged resulting from abuse or from servicing performed by an

OSD Audio sells products only through authorized dealers and distributors to ensure that
customers obtain proper support and service. Any OSD product purchased from an unauthorized
dealer or other source, including retailers, mail over dealers and online sellers will not be honored
or serviced under existing OSD warranty policy. Any sale of product by an unauthorized source or

other manner not authorized by OSD shall void the warranty on the applicable product.

Damage to or destruction of components due to application of excessive power voids the warranty on
those parts. In these cases, repairs will be made on the basis of the retail value of the parts and labor. To
return for repairs, you must email customer service at [e-mail] for a Returned Merchandise
Authorization (RMA) number# then the unit must be shipped to OSD at the owner's expense, along with
a note explaining the nature of service required. Be sure to pack the speaker(s) in a corrugated container

Damage caused by abuse, accident, misuse, negligence, or improper operation (installation) • Any
products that have been altered or modified • Any product whose identifying number of decal,

agency or person not specifically authorized in writing by OSD.

with at least 3 inches of resilient material to protect the unit from damage in transit.

This Warranty Does Not Cover:

serial #, etc. has been altered, defaced or removed • Normal wear and maintenance.

Outdoor Volume Control (HD-OVC300)

½“ Polyproplene cone and

½” Coaxial Polyamide dome

1 Piece

2 years

½” x D 13”

parts or labor.

Installation Manual

Step 1

Evaluate the location of the speaker.
Project the length of speaker wire you
will run.

Note: When purchasing additional direct
burial speaker wire, make sure the wire
gauge is consistent.

OSD SP650 speaker reproduces High
Fidelity sound and a few speakers will
cover a large area if properly placed and
spread out.

Step 2

Once you have decided on the placement
of your SP650 speaker, dig a trench about
2” leading from the speaker to the input
source for the speaker wire.

Step 3

Connect the wires from the SP650
speaker to the amplifier or receiver.

_

+

Step 4

Place the SP650 speaker firmly on the
ground, and run the direct burial wire
through the trench to the location of
the amplifier or receiver.

Step 5

Turn on your amplifier or receiver to test the speaker. If the speaker sounds fine,
refill the wire trench and enjoy the music.

Please make sure the polarity on the
cable and the speaker is in sync.

Optional: Using an outdoor volume
control makes it convenient for you to
adjust the volume outside.

Please note: When connecting the
additional wire be sure to use water
tight wire connectors.

+

Receiver/Amp

- - - - - - - - - - - - - - - - - -

-+-
