Ortofon SPU Moving Coil Cart ridge
Thank you for choosing an Ortofon SPU
moving coil cartridge for your turntable.
Original
The original Or tofon stereo cartridge was
born in 1958. Ever since, Ortofon SPU
cartridge models have shared the DNA from
their SPU ancestor, being true to the never
compromised original design.
The model in this manual share the authentic
so-called “Ortofon Sound” worldwide
recognised and related to the Ortofon
cartridges.
Re nements on the models have taken
bene t from the use of new materials, to gain
the outstanding reproduction qualities.
Page 3
Mounting
All SPU cartridges are designed to
bring optimum performance, when the
tonearm mounted with the cartridge is
adjusted parallel to the record surface, at
recommended tracking force.
Maintenance
To obtain optimal sound reproduction,
remove dust from the stylus regularly by
using a st ylus brush. Guide the brush gently
forward in the direction of the diamond tip.
From time to time, the car tridge system
should be removed from the tonearm, and the
gold-plated contact points on the cartridge,
and the contact points inside the tonearm,
should be cleaned with a small amount of
propyl alcohol. This helps to avoid dust
or stick y material from resulting in a bad
electrical connection.
Page 4
MC Cartridge with Built-in Transformer
This MC cartridge features an integrated
transformer, allowing it to be used with the
“MM” (Moving Magnet) input on your ampli er.
Special Repair Service
The stylus is not part of a replaceable
assembly on SPU moving coil cartridges. We
therefore offer a Special Repair Service for the
SPU cartridges, the Special Repair Service is
available through our webshop and Ortofon
Authorized dealers.
Warning
This phono cartridge is only for mounting
on tonearms and must not be used for other
purposes.
Page 5
Technical Data
SPU GTX S and SPU GTX E
Output vo ltage at 100 0 Hz, 5 cm/sec. 4 mV
Channel balance at 1 kHz 1.5 d B
Channel separation at 1 kHz 20 dB
Frequen cy respon se 20 Hz – 20 kHz ±3 dB
Tracking ab ility at 315 Hz 60 μm
Dynamic lateral compliance 10 μm /mN
Stylus t ype GTX S Spherical
Stylus t ype GTX E Elliptical
Stylus t ip radius GTX S R 18 μm
Stylus t ip radius GTX E r/R 8/18 μm
Recommended tracking force 4 g
Tracking angle 20°
Internal impedance [DC resistance] 610 Ω
Recommended load impedance 47 kΩ
Recommended load capacitance 150 – 600 pF
Coil wire m aterial OFC
Cartridge color Black
Cartridge weight 38 g
Above sp ecifi cations m ay vary
5-850058-12 Rev04
Page 6
Scan and follow the QR code for setup
information (www.ortofon.com/support).
