Ortek Technology VUP7240 User Manual

VUP-7240 & VUP-7240RX

Wireless VoIP USB Phone & Wireless

VoIP USB Phone Receiver

User’s Manual

Version 1.0 2006/02
ID NO:

0

FAO-82265123-00

Federal Communications Commission (FCC) Statement

15.21

You are cautioned that changes or modifications not expressly approved

by the part responsible for compliance could void the user’s authority to

operate the equipment.

15.105(b)

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to part 15 of the FCC rules. These limits

are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following

measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

Operation is subject to the following two conditions:

1) this device may not cause interference and

2) this device must accept any interference, including interference that

may cause undesired operation of the device.

1

FCC Caution: Any changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority to operate

this equipment. "ORtek Technology, Inc. declare that

IMPORTANT NOTE:
FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. To maintain compliance with FCC RF exposure

compliance requirements, please avoid direct contact to the transmitting

antenna during transmitting. End users must follow the specific operating

instructions for satisfying RF exposure compliance.

This transmitter must not be co-located or operating in conjunction with any

other antenna or transmitter.

2

CONTENTS

CHAPTER 1 Welcome to USB Phone

1.1 Features………………………………………..4

1.2 System Requirements……………………….5

1.3 Driver Installation…………………………….5

1.4 Hardware Installation……………………….6

CHAPTER 2 Use of USB Phone

2.1 Run Skype………………………………………..7

2.2 Connect USB Phone to PC…………………..8

2.3 Call to regular phone (PC to Phone)…….9

2.4 Answer a call…………………………………….9

2.5 Function Keys…………………………………..9

2.6 Function operation………………..………13

2.7 FAQ………………………………….…………...13

3

CHAPTER 1

Welcome to Wireless USB Phone

1.1 Features

1. Echo cancellation, noise reduction

2. Full duplex communication

3. Customized hand phone casing designs available

4. Key-in tone function

5. Hold ring tone function

6. Clear and private conversation with Bluetooth technology

7. Works at full 360

8. Wireless freedom up to 15~20 meters

9. Talk up to 4 hours and standby up to 20 hours without

recharging

10. Easy to read wide dot-matrix graphic LCD display with 128 x 32

pixels

11. Any language characters can be displayed

12. Supported application: MSN, NetMeeting, Yahoo Messenger,

100% compatible with Skype

13. Blue LED backlight for incoming call alert or press any key

14. Cellular phone size makes this model popular for travelers (48

x 128.5 x 32.4 mm)

15. Free PC to PC call or low PC to Phone call rate over the

Internet

16. Convenient Volume Control Button

17. Miss calls and received calls indication

18. Multiple ringer tons choices

19. No Power/Memory/Sound Card required

20. USB port battery charger

21. USB dongle transceiver for best result

efficient with Bluetooth Technology

4
