TV STAND
Thank you for purchasing t
Before you start, here i
1.We suggest you spend a short time reading through this leaflet and then follow the simple step-
instructions.
2.Owing to the size and weight of the TV stand, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approximate assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe and
environmentally friendly way.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that have been provided.
6.Please keep all fitting out of reach of children.
he TV STAND！
s some helpful advice:
by-step
Hardware:
A
Double-ended Bolt M8x190mm x6
Components:
B
C
D
E
F
G
H
Dowel ɸ
Nut M8 x6
Flat Washer M8 x10
Box Wrench #8 x1
Bolt M8x35mm
Allen Wrench #5 x1
Mat 40x40mm x4
8x40mm x12
x4
1
2
Top Panel x1
1
Side Panel x3
2
2
3
2
4
4
Bottom Panel x1
3
Leg x2
4
Page 1 of 4
Page 2
TV STAND
STEP 1:
Put Top Panel (1) upside down on
Insert 6 pieces of Double-ended Bolt (A) into the corresponding holes In the Top Panel (1) by hand as shown.
Tighten all the Double-ended Bolts (A) clockwise until secure.
a carpete
d or padded area.
A
A
A
A
A
1
A
Ax6
STEP 2:
Insert 4 pieces of
Repeat the same steps for the remaining 2 pieces of Side Panel (2).
Position the assembled Side Panel (2) to Top Panel (1) as shown.
Please confirm the assembled Double-ended Bolts (A) and Dowel (B) have been inserted into the pre-drilled holes
in Top Panel (1) fully as shown.
wel (B) into 4 holes of Side Panel (2) as shown.
Do
Hardware & Tool required
B
2
B
B
B
2
Bx12
2
2
B
A
B
1
A
Hardware & Tool required
Page 2 of 4
Page 3
TV STAND
STEP 3:
Put Bottom Panels (3) upside
Position 1 piece of Bottom Panel (3) to the assembled Top panel (1) and Side Panels (2) as shown.
Please confirm the assembled Double-ended Bolts (A) and Dowels (B) have been inserted into the pre-drilled holes in
Bottom Panel (3) fully.
Insert 6 pieces of
Use Box Wrench (E) to tighten all the Nuts (C) clockwise until secure.
down on a carpeted or padded area.
Nut (C) with 6 pieces of Flat Washer (D) into the assembled Double-ended Bolts (A) as shown.
2
3
E
1
2
E
2
C
D
3
Cx
6 Dx
STEP 4:
Position 1 piece of Legs (4
Insert 2 pieces of Bolt (F) with 2 pieces of Flat Washer (D) into the pre-drilled holes In ihe Bottom Panel (3) through the
holes In the Leg (4).
Use Allen Wrench (G) to tighten Bolts (F) clockwise until secure.
Repeat the same steps for the other piece of Leg (4).
Tear off the sticker on the 4 pieces of Mats (H).
Carefully attach 4 pieces of Mat (H) to Legs (4) as shown.
6 Ex1
) to the assembled Top Panel (1), Side Panels (2), and Bottom Panel (3) as shown.
Hardware & Tool required
H
4
4
G
D
3
2
F
Dx4 Fx4 Gx1
4
4
2
1
4
2
Hardware & Tool required
3
Hx
Page 3 of 4
Page 4
TV STAND
STEP 5:
Carefully turn o
ver the assembled TV stand.
Assembly is complete. Your TV
stand is ready to be used now!
Page 4 of 4
