LOTUS
Page 2
LOTUS
/
The LOTUS chair integrates functionality, ergonomics
and form into a family of products suitable for
a range of uses in the education and hospitality
sectors. Representing a body of scientific research
into active dynamic seating the LOTUS shell offers
a shape which provides both flexibility and 360°
sitting positions, supporting users movements in
all directions.
Designed by Nick Pearson
Page 3
VERSIONS, SIZE & WEIGHT
LOTUS 4 Leg
(mm) W485 x D560 x H820 x SH450
(Inch) W19 x D22 x H32.25 x SH17.75
(kg) 4 (lbs) 8.8
LOTUS Cantilever
(mm) W495 x D550 x H825 x SH470
(Inch) W19.5 x D21.75 x H32.5 x SH18.5
(kg) 4.6 (lbs) 10.1
LOTUS Mid Stool
(mm) W515 x D500 x H1030 x SH660
(Inch) W20.25 x D19.75 x H41 x SH26
(kg) 4.9 (lbs) 10.8
LOTUS Task
(mm) W600 x D600 x H780/880 x SH420/520
(Inch) W23.5 x D23.5 x H30.75/34.75 x SH16.5/20.5
(kg) 6 (lbs) 13.2
LOTUS High Stool
(mm) W515 x D500 x H1110 x SH740
(Inch) W20.25 x D19.75 x H43.75 x SH29.25
(kg) 5 (lbs) 11
Page 4
VERSIONS, SIZE & WEIGHT
Pure Red
RAL 3028
Marine Blue
RAL 5002
Deep Orange
RAL 2011
Blue Lilac
RAL 4005
Shell
Polypropylene (PP)
Glass Fibre Reinforced
Sulfur Yellow
RAL 1016
Signal Grey
RAL 7004
Yellow Green
RAL 6018
Traffic White
RAL 9016
Sky Blue
RAL 5015
Traffic Black
RAL 9017
Frame
Powder coated
steel tube
White Aluminium
RAL 9006
(Standard)
Other colours
available
Task
Polyamide (PA)
+ Steel assembly
Traffic Black
RAL 9017
Pad
See spec
Camira -
Mainline
(Standard)
See our
fabric bands
document for
further info
Page 5
Page 6
OPERATION & MAINTENANCE
4 Leg, Cantilever, Sled, Sled Mid Stool, Sled High Stool, Mid Stool, High Stool, Task Chair,
Task Stool
Assembly
Versions
LOTUS is manufactured and assembled in the UK and US and should arrive in perfect condition.
LOTUS chairs / stools are supplied fully assembled. LOTUS Task chairs come part assembled
and require final components to be assembled on site.
Maintenance
LOTUS should be cleaned on a regular basis, using a clean damp cloth. Remove stains using
a mild detergent and water. Avoid contact with sharp objects, as these may leave scratches
or damage to the plastic surface.
Warranty/Life Expectation
LOTUS chairs come with a 10 year warranty for structural defects. Life expectation is 20+ years.
Upholstery - See material supplier guarantee period.
Exclusions
Feet - 4 Leg, Cantilever, Sled, Sled Mid Stool, Sled High Stool, Mid Stool, High Stool
Task parts - Task Chair, Task Stool
Recycling
The polymer (polypropylene glass fiber reinforced) component parts including the LOTUS shell
are 100% recyclable. The metallic component parts including metal frame are 100% recyclable.
Compliance
LOTUS chairs comply with the following standard, EN1729:2006 Parts 1& 2 - Educational
Standard. A test certificate can be issued upon request.
