Oregon Scientific DS6639 User Manual
086-003300-074
DS6639 Q.S.Guide (086-003300-074)
DS6639
Quick start guide
Guide de mise en marche rapide
Guía rápida
ENGLISH
FRANÇAIS
2.0 Mega-Pixel Slim Card-Sized Digital Camera (DS6639)
QUICK START GUIDE
KEY FEATURES
FRONT VIEW
Power Button
Built-In Flash
Shutter Release Button
Viewfinder
Lens
ENGLISH
FRANÇAIS
ESPAÑOL
DS6639 Q.S.Guide-Eng/8 Lang. (086-003300- )
Self-Timer Lamp
BACK VIEW
Viewfinder
Menu Button
On-Screen
Display
USB T erminal
Memory Card Slot
4-Way Controller
Video Socket
Status Lamp
Mode Switch
Strap Ring
Flash/Delete
Button
Battery Door
ESPAÑOL
MODE SWITCH
GETTING STARTED
ENGLISH
Mode Indicator
Record Mode
FRANÇAIS
4-WAY CONTROLLER
Digital Zoom-Out
ESPAÑOL
OK/DISP Button
Playback Mode
Self-Timer
Digital Zoom-In
Instant Review Function
Installing the Batteries
Your camera is
shipped with
two AAA-sized
batteries. Insert
the batteries as
shown on the
compartment lid.
You may
damage your
camera if the
batteries are
installed
incorrectly.
TIP: To maximize the performance of your camera and for greater battery life, use
NiMH rechargeable type batteries. Please refer to the "Addendum" for more details.
Attaching the Strap
1. Pass the
short, thin loop
of the strap
through the
camera’s
strap ring.
2. Pass the
other end of
the strap
through
the loop.
3. Tighten by
pulling the loop.
SECURE DIGITAL (SD) AND MULTI-MEDIA CARD (MMC)
It is recommended that all memory cards are formatted using the Format
option before using them with this digital camera. Memory cards formatted
using other devices may be incompatible.
When the SD card is installed, all images and movies taken are automatically
stored on the card. Images and movies in the internal memory cannot be
accessed until the card is removed.
The SD card will not insert fully into the slot if it is facing the wrong way. Be
careful not to apply undue force to the card.
Installing the SD / Multi-Media Card
1. Ture off the
camera.
2. Slide the
card into the
slot until it
clicks into
position.
Removing the SD / Multi-Media Card
1. Ture off the
camera.
2. Push on
the card still
lodged inside.
3. The card
automatically
ejects itself
out of the slot.
ENGLISH
FRANÇAIS
ESPAÑOL
DS6639 Q.S.Guide-Eng/8 Lang. (086-003300- )
Connecting to PC
Please read and carefully follow the user manual for instructions on connecting
ENGLISH
the camera to your PC or macintosh.
BASIC PHOTOGRAPHY
QUICK START
Preparing the Camera Holding the Camera
FRANÇAIS
1. Slide the Mode Switch to Camera Mode.
2. Press and hold the Power button to
turn the camera on.
3. Check the battery indicator, making
sure there is enough power.
Icon Description
ESPAÑOL
4. Loop the strap over your wrist.
Adequate power remains
Battery is running low
Battery is running very low.
Battery is exhausted.
Taking Basic Pictures
1. Frame your subject in the viewfinder. You can also view the subject on the OSD.
2. Press the Shutter Release Button.
3. The image taken is displayed on the OSD for approximately a second (Auto
Review).
4. Once the Auto Review has finished, you may proceed to take the next picture.
When memory is full, no more images can be stored. The camera will
beep and the words “Internal Memory Full” or “Memory Card Full” will
appear on the LCD if you press the Shutter Release Button.
5. When you have finished taking your pictures, slide the Mode Switch to Off.
1. Hold the
camera firmly.
2. Avoid blocking
the lens and flash.
3. Do not move
nor remain in
motion while
taking pictures.
Selecting a Flash Mode
Inital Flash Settings
When you turn on your camera, the inital flash setting will vary depending on the
level of your battery.
Battery Status Initial Flash Setting
or The flash setting is saved after your camera is switched off
or The inital flash setting is . However, you can manually
or the mode switch changes to another mode.
set the flash to other settings.
Toggling Between Flash Modes
Press
Press
Press
Flash Mode Options Table
Icon Function Description
Auto The flash may discharge automatically, depending on
the light conditions.
Flash On The flash discharges regardless of lighting condition.
Flash Off The flash will not discharge.
ENGLISH
FRANÇAIS
ESPAÑOL
DS6639 Q.S.Guide-Eng/8 Lang. (086-003300- )
